Delfield Specification Line SAF2-S User manual

ON THE JOB.
Quality, Performance, Durability,
Versatility, Usability
 e Right Refrigeration For Todays Kitchens.
SPECIFICATION LINE®

Features
• Rolled on stainless steel finish.
• Exterior LED digital thermometer.
• Easy access “flip-up” shroud.
• One-piece top mounted refrigeration system.
• Thermostatic expansion valve metering.
• Hot gas condensate removal.
• ACT -Advanced Control Technology.
• Energy saver door heater switch.
• One-piece, no seam side panels.
• Available field door rehingability.
• Recessed metal door handle.
• Built-in door locks with heavy-duty strikes.
• Stainless steel breaker strips.
• 1” shelf adjustability.
• Three chrome plated wire shelves per section.
• Tough ABS interior door liners.
• Two year parts and labor warranty.
Delfield’s Specification Line
More than just good looks.

Featured for Quality.
Featured for Performance.
Featured for Durability.
Featured for Versatility.
Featured for Usability.

SAF2-S
Two section freezer
Aluminum interior
Solid, full height hinged doors
Product
A wide and deep offering. The models and options needed to
meet your specifi c operational requirements. Solutions to your
productivity, cost containment and revenue generation challenges.
Delfi eld’s Specifi cation Line refrigeration is the right refrigeration
for today’s busy kitchens, with over 950 distinct models and a vast
array of options available.

Two Finish Sets-
Specifi cation Line is available in all corrosion resistant stainless steel inside and
out, or in a more economical, but still tough, stainless steel exterior and aluminum
interior. Both fi nish sets have the same exact performance, durability, versatility and
usability features. You have a choice as to what fi nish set works best for your opera-
tion.
Reach-Ins-
One, two and three section, full size, narrow width, shallow depth, refrigerators,
freezers, heated and dual temp. The offering is endless. Specifi cation Line has
the sizes you need and the temperatures required to keep your operation running
effi ciently and productively.
One, two and three section, full size, narrow width, shallow depth, refrigerators,
freezers, heated and dual temp. The offering is endless. Specifi cation Line has
the sizes you need and the temperatures required to keep your operation running
effi ciently and productively.
Pass-Thrus-
One, two and three section, full size, shallow depth, refrigerators, freezers and
heated units. When a Pass-Thru confi guration makes sense for your operation,
Specifi cation Line can deliver the right size and temperature.
Roll-Ins-
One, two and three section, refrigerators, freezers and heated units. Roll-In
refrigeration can be the answer to productivity issues in a high volume kitchen,
smoothing out fl ow and minimizing handling. If Roll-In refrigeration makes sense in
your operation, Specifi cation Line is there ready to meet the need.
One, two and three section, refrigerators, freezers and heated units. Roll-In
refrigeration can be the answer to productivity issues in a high volume kitchen,
smoothing out fl ow and minimizing handling. If Roll-In refrigeration makes sense in
your operation, Specifi cation Line is there ready to meet the need.
Roll-Thrus-
One, two and three section, refrigerators and heated units. Load from the
production side, unload to the serving side. Roll-Thrus can enhance productivity
even further. If it fi ts your needs, Specifi cation Line has the product.
Specialty Reach-Ins-
Convert-A-Temp can function as a refrigerator or a freezer - all at the fl ip of a switch.
Ready-Thaw can meet your food thawing needs quickly and safely by bringing frozen
product to refrigerated state under controlled temperature conditions. Wine Cabinets
store and merchandise wine with special shelving and the right temperatures. Fish/
Poultry Drawer units keep product fresh in a bed of crushed ice with easy to use
drawers. Special needs? Specifi cation Line has the special units to meet those special
needs.
Convert-A-Temp
Ready-Thaw
product to refrigerated state under controlled temperature conditions.
store and merchandise wine with special shelving and the right temperatures.
Poultry Drawer
drawers. Special needs? Specifi cation Line has the special units to meet those special
needs.
Options-
Different doors, different combinations, shelves and tray slides, legs or casters,
lamination, fi nished backs - the list goes on and on. The real story is Specifi cation
Line can be confi gured to meet your needs, you won’t have to compromise.

Smart design, reliable operation, readily available after the sale
support. These things define quality. Delfield’s Specification Line
refrigeration was designed and is produced with a focus on quality.
SSR3-S
Three section refrigerator
Stainless steel interior
Solid, full height hinged doors
Quality

2 Year Labor/2 Year parts/5 Year Compressor Warranty-
A comprehensive, reasonable length warranty demonstrates a commitment to quality.
It gives you a sense of confi dence that the manufacturer believes in quality. Delfi eld
knows you demand quality and Specifi cation Line lives up to that expectation.
24 Hour Factory Run Test-
Every Specifi cation Line unit is run at the factory for 24 hours prior to packing and
shipping. It’s a fi nal check designed to make sure you get the quality unit you expect
from Delfi eld.
Every Specifi cation Line unit is run at the factory for 24 hours prior to packing and
shipping. It’s a fi nal check designed to make sure you get the quality unit you expect
from Delfi eld.
State of the Art Leak Detection-
Refrigerant leaks can take a refrigerator down quickly. Leaks are public enemy
number 1 at Delfi eld. Our state-of-the-art leak detection equipment is designed to
fi nd even the smallest leak. If a refrigerant leak is present, we will fi nd it and remedy
the problem before the unit is shipped and installed.
Total Quality Control on the Line-
Every Delfi eld employee is committed to providing our customers with the highest
quality product possible. Each one is tasked with making sure the product they’re
assembling meets high quality standards. They are extensively trained. They are
empowered. They are serious about quality. They know you demand a quality product
and they work hard to deliver one.
Every Delfi eld employee is committed to providing our customers with the highest
quality product possible. Each one is tasked with making sure the product they’re
assembling meets high quality standards. They are extensively trained. They are
empowered. They are serious about quality. They know you demand a quality product
and they work hard to deliver one.
Parts and Service Support-
A well staffed, dedicated parts and service department assures you’ll have the support
necessary to keep your Specifi cation Line unit operating effi ciently for years. Delfi eld
has developed an authorized service network and a parts depot system to make sure
you have fast response to your Specifi cation Line service and parts needs. Parts and
service support is at your call.
High Quality Components-
Delfi eld demands a lot from our vendors. Our quality standards are high and expected
quality control procedures rigorous. This is all designed to assure only the highest
quality component parts go into Specifi cation Line refrigeration, making for a total
high quality Specifi cation Line product. Just the type of product you expect to help
make your operation run smoothly and effi ciently.
Delfi eld demands a lot from our vendors. Our quality standards are high and expected
quality control procedures rigorous. This is all designed to assure only the highest
quality component parts go into Specifi cation Line refrigeration, making for a total
high quality Specifi cation Line product. Just the type of product you expect to help
make your operation run smoothly and effi ciently.

Consistent temperatures, fast recovery, the ability to keep up under
heavy use, low energy consumption, the hallmarks to performance.
Delfi eld’s Specifi cation Line is designed to perform. The key is
our ACT (Advanced Control Technology) control system. This
coupled with other smart design features give Specifi cation Line
unbeatable performance which translates to greater effi ciency,
higher productivity and profi t saving cost containment for you.
Performance
SSR2-G
Two section refrigerator
Stainless steel interior
Solid, full height hinged glass doors

ACT-
The benefi ts of solid state electronics with the operational simplicity of standard
controls. Improved pull down, more even cabinet temperatures, reduced compressor
cycling, lower energy consumption and adaptive defrost all in one convenient,
reliable package.
Thermostatic Expansion Valve-
Refrigerant metering - the variable fl ow of refrigerant into the evaporator coil afforded
with the use of a thermostatic expansion valve instead of a fi xed fl ow capillary tube
means faster temperature recovery and more even cabinet temperatures. For you that
means you can work your Specifi cation Line unit hard with lots of door openings and
closing, in the hottest of kitchens and still get the performance you need.
Refrigerant metering - the variable fl ow of refrigerant into the evaporator coil afforded
with the use of a thermostatic expansion valve instead of a fi xed fl ow capillary tube
means faster temperature recovery and more even cabinet temperatures. For you that
means you can work your Specifi cation Line unit hard with lots of door openings and
closing, in the hottest of kitchens and still get the performance you need.
Hot Gas Condensate Removal-
We use the hot gas discharge line to generate heat to evaporate condensate that
is produced from normal refrigeration operation. It’s free energy since the line
is an integral part of refrigeration system operation. Its heat assures condensate
evaporation even in the most demanding environments. We don’t leave evaporation
to chance like some other manufacturers might by just counting on non-heat aided
evaporation to occur. We’ve designed our hot gas system to be resistant to the corrosive effects
of acids found in the condensate.
Refrigeration System Design-
Carefully engineered to the application each system is designed and built to meet the
specifi c requirements of the unit it’s placed on. We don’t buy off the shelf systems. We
have components built to our specifi cations. No compromises. Designed to work for
you in your unique application.
Carefully engineered to the application each system is designed and built to meet the
specifi c requirements of the unit it’s placed on. We don’t buy off the shelf systems. We
have components built to our specifi cations. No compromises. Designed to work for
you in your unique application.
Large Evaporator Coil-
Designed to perform without robbing your food storage environment of the humidity
it needs to keep your food fresh and appealing. We could use a smaller coil and still
maintain temperatures, but it would run colder and pull more moisture out of our
cabinet air, drying out your food. Why would we want to do that? Fresh, appealing
food means satisfi ed customers and enhanced revenues to you.
Balanced Airfl ow-
You need your food to be stored at just the right temperatures. Not too hot, not too
cold. You need those temperatures everywhere in the cabinet so you can get maximum
capacity utilization out of your investment. Specifi cation Line is designed to deliver
those consistent temperatures throughout the cabinet. Our balanced airfl ow uses a
well engineered fan design, directional air movement and well thought out ducting to
assure even, proper temperatures throughout our units.
You need your food to be stored at just the right temperatures. Not too hot, not too
cold. You need those temperatures everywhere in the cabinet so you can get maximum
capacity utilization out of your investment. Specifi cation Line is designed to deliver
those consistent temperatures throughout the cabinet. Our balanced airfl ow uses a
well engineered fan design, directional air movement and well thought out ducting to
assure even, proper temperatures throughout our units.

Built to last, built to work, built to keep you from becoming
too friendly with your repairman. Delfield’s Specification Line
refrigeration is tough and durable and it will last a long time,
justifying your investment in the best refrigeration equipment
money can buy.
Durability
SSFRI2-S
Two section roll-in freezer
Stainless steel interior
Solid, full height hinged doors

Heavy Duty Handle, Lock and Strike -
Easy to use, tough construction. Specifi cation Line hardware refl ects its intended
application - use in the most demanding applications and environments, with security
and reliability assured.
Heavy Duty Shelves and Pilasters-
Chrome plated shelves stand-up to corrosion. They are work horses - handling up
to 250 pounds per shelf. Specifi cation Lines pilasters are tough too - constructed of
heavy gauge stainless steel and providing shelf adjustability on 1” centers.
Chrome plated shelves stand-up to corrosion. They are work horses - handling up
to 250 pounds per shelf. Specifi cation Lines pilasters are tough too - constructed of
heavy gauge stainless steel and providing shelf adjustability on 1” centers.
Rolled on Stainless Steel Finish-
Instead of “traditional” abraided and polished stainless steel fi nish, we’ve chosen to
use newer technology, rolled on fi nish. Independent lab tests have shown that the
rolled on fi nish is less succeptable to pitting and corrosion and holds up better in the
harsh environments that are todays food service kitchens.
Stainless Steel Breaker Strips-
Holds up to wear and tear in an especially vulnerable area. You can be assured that
these tough strips won’t crack or break. Their clean design is what you would expect in
a sanitary environment.
Holds up to wear and tear in an especially vulnerable area. You can be assured that
these tough strips won’t crack or break. Their clean design is what you would expect in
a sanitary environment.
One-Piece Side Construction-
Solid construction. Continuous side panels with no seam at the top. Polyurethane
insulation foamed in place, from top to bottom, adds rigidity and provides a sound
deadening effect from refrigeration system noise.
Concealed Light Switch-
Can’t fi nd the door activated light switch? It’s concealed in the upper hinge to protect
it from inadvertent damage. Smart design, convenient operation with a focus on
durability.
Can’t fi nd the door activated light switch? It’s concealed in the upper hinge to protect
it from inadvertent damage. Smart design, convenient operation with a focus on
durability.
ABS Interior Door Liner-
One tough design. The inside of the door takes a lot of abuse and Specifi cation
Lines’ molded ABS material can handle it. This material is solid but resilient. It
won’t dent or crack. Pans and boxes bounce right off. We also took gasket life
into account. The Specifi cation Line door liner is molded to come out past the door
gasket, protecting it from wear and tear. You’ll fi nd yourself replacing door gaskets a
lot less frequently on Specifi cation Line refrigeration.
Polyurethane Casters-
If mounting your refrigeration on casters for mobility makes sense for you operation,
you’ll fi nd the deluxe polyurethane wheeled casters provided as an option on
Specifi cation Line refrigeration a pleasant surprise. Designed to stand up to wear
and tear for many years. These are the casters you use to see, before so many
manufacturers cost reduced their product to a less capable solid plastic design. No
compromises with Delfi elds’ Specifi cation Line refrigeration.
If mounting your refrigeration on casters for mobility makes sense for you operation,
you’ll fi nd the deluxe polyurethane wheeled casters provided as an option on
Specifi cation Line refrigeration a pleasant surprise. Designed to stand up to wear
and tear for many years. These are the casters you use to see, before so many
manufacturers cost reduced their product to a less capable solid plastic design. No
compromises with Delfi elds’ Specifi cation Line refrigeration.

Operational needs change, menus evolve, work patterns shift.
Delfi elds’ Specifi cation Line refrigeration was designed to let
you adapt to the changing needs of your operation, keeping
your productivity up and your costs down. Without having to
unnecessarily invest in new replacement equipment when your
existing equipment is still in good shape. Delfi elds’ Specifi cation
Line refrigeration is highly adaptable.
Versatility
SSR1-SH
Single section refrigerator
Stainless steel interior
Solid, half height hinged doors

ACT, Advanced Control Technology-
Our ACT system gives you an expanded temperature operating range in refrigerators.
They can operate anywhere from 27˚F to 44˚F without modifi cation. Just set the dial
to the desired temperature. Operation below 32˚F doesn’t require electric defrost
heaters. The control is smart enough to keep the evaporator coil free of ice. ACT
lets your refrigerator do its job, just like you need it to in your application.
Tray Slides and Shelves-
18”x26” bun pans, 12”x20” hotel pans, boxes, bags, jars and other miscellaneous
containers. You ask your refrigeration to handle a wide variety of items, Specifi cation
Line is up to the task. We’ve got a wide array of slide systems and shelf types
available, all designed to let you confi gure the storagability of the unit to meet your
specifi c needs.
18”x26” bun pans, 12”x20” hotel pans, boxes, bags, jars and other miscellaneous
containers. You ask your refrigeration to handle a wide variety of items, Specifi cation
Line is up to the task. We’ve got a wide array of slide systems and shelf types
available, all designed to let you confi gure the storagability of the unit to meet your
specifi c needs.
Available Field Door Rehingeability-
Your workfl ow can change. You need to keep your equipment confi gured to
maintain productivity in the new fl ow. Specifi cation Line can be ordered, at no
additional charge, with the ability to easily rehinge doors at your location, letting
your refrigeration adapt with you to your changing needs. Workfl ow stays effi cient,
productivity stays high.
Wide Variety of Door Choices-
Full doors, half doors, solid stainless doors, glass doors, hinged or sliding. Mix and
match. Specifi cation Line refrigeration offers the widest variety of door options
available today. You know what works best for your operation, Specifi cation Line
delivers on those needs.
Full doors, half doors, solid stainless doors, glass doors, hinged or sliding. Mix and
match. Specifi cation Line refrigeration offers the widest variety of door options
available today. You know what works best for your operation, Specifi cation Line
delivers on those needs.
Wide Variety of Temperature Choices-
Refrigerators, freezers, heated cabinets, dual temperature units, wine cabinets. The
Specifi cation Line offering has a unit with the right temperature performance to
fi t your storage needs. Once again, it’s one of the widest offerings available today,
because we recognize you have a variety of temperature holding needs.
One-Piece, Removable Refrigeration System-
Originally you needed a refrigerator to make your operation go. But things change,
now a freezer is needed instead. Wouldn’t it be nice if you could change the
refrigerator to a freezer and not have to buy a new freezer? You can do just that with
Specifi cation Line. Our one-piece refrigeration system is self-contained and can be
interchanged in the fi eld by a qualifi ed service technician.
Originally you needed a refrigerator to make your operation go. But things change,
now a freezer is needed instead. Wouldn’t it be nice if you could change the
refrigerator to a freezer and not have to buy a new freezer? You can do just that with
Specifi cation Line. Our one-piece refrigeration system is self-contained and can be
interchanged in the fi eld by a qualifi ed service technician.

Convenience, operational effi ciency, labor productivity, Delfi elds’
Specifi cation Line refrigeration meets the need with innovative
design features, creating a perfect fi t with your food service
operation. It’s easy to use and it’s a real hard worker.
Usability
SAF2-S
Two section freezer
Aluminum interior
Solid, full height hinged doors

Hinged Stay-Open Upper Housing-
The upper housing hinges open and stay-open with a gas strut, allowing you
convenient access to the refrigeration system. This makes it especially easy to clean
the condenser coil. A clean condenser keeps your system operating properly and
effi ciently. Shouldn’t it be easy to get at for cleaning?
Pressure Relief Vent-
Open the door, close the door, open the door - unit won’t open. It feels like there is a
500 pound gorilla inside holding it shut. Ever experience this? It’s called vapor lock
and is caused by an air pressure differential between the inside and outside of the unit.
It won’t happen with Specifi cation Line. We’ve installed pressure relief vents on all
refrigerators and freezers to eliminate vapor lock. No annoying, productivity robbing,
stuck doors.
Open the door, close the door, open the door - unit won’t open. It feels like there is a
500 pound gorilla inside holding it shut. Ever experience this? It’s called vapor lock
and is caused by an air pressure differential between the inside and outside of the unit.
It won’t happen with Specifi cation Line. We’ve installed pressure relief vents on all
refrigerators and freezers to eliminate vapor lock. No annoying, productivity robbing,
Shelf Adjustability-
Container too high to fi t on the shelf? Room for more products and more shelves?
Specifi cation Line refrigeration is easily confi gurable to get the maximum storage
capacity out of your unit. Shelves are held in place with stainless steel clips that
easily adjust in stainless steel pilasters. Mounting holes on 1” centers, giving you
unlimited fl exibility.
Attached 10’ Cord-
All 115 volt Specifi cation Line units come with a 10’ attached cord and plug from
the factory. You don’t have to worry about having an electrician wire it. It fi ts in a
standard outlet. The 10’ length gives you plenty of room to move the unit for cleaning.
All 115 volt Specifi cation Line units come with a 10’ attached cord and plug from
the factory. You don’t have to worry about having an electrician wire it. It fi ts in a
standard outlet. The 10’ length gives you plenty of room to move the unit for cleaning.
Easy to Read LED External Thermometer-
Bright and easy to read from across the room. It doesn’t depend on solar power for
a read out. If the unit is plugged in, you’ll know the interior temperature and you’ll
know your food is being kept fresh and safe. And you won’t have to strain your eyes
to see it.
Energy Saver Door Heater Switch-
Sometimes you need it, sometimes you don’t. All Specifi cation Line refrigerators have
a heater wire imbedded in the cabinet, around the door opening. It’s there to eliminate
condensation from forming and dripping down the front of the cabinet. Ambient
humidity plays a big part in condensate formation. If your kitchen is cool and dry, you
don’t need the heater. Specifi cation Line lets you make the decision. The heater can be
turned off when it’s not needed, using a switch that’s conveniently mounted behind the
fl ip up upper housing where it won’t be used incorrectly. Why pay for energy you
don’t need?
Sometimes you need it, sometimes you don’t. All Specifi cation Line refrigerators have
a heater wire imbedded in the cabinet, around the door opening. It’s there to eliminate
condensation from forming and dripping down the front of the cabinet. Ambient
humidity plays a big part in condensate formation. If your kitchen is cool and dry, you
don’t need the heater. Specifi cation Line lets you make the decision. The heater can be
turned off when it’s not needed, using a switch that’s conveniently mounted behind the
fl ip up upper housing where it won’t be used incorrectly. Why pay for energy you

Delfield Specification Line refrigeration.
Quality, Performance, Durability, Versatility, Usability
with the right product in the right configuration
to do the job right.
If we don’t have a standard model to meet your needs, we can use
our over 50 years of customizing experience to create one for you.
Many companies talk of offering solutions to meet your needs,
Delfield has been delivering solutions since 1949.
The Delfield Company
980 S. Isabella Rd.
Mt. Pleasant, MI 48858
Phone: [phone]
Fax: [phone]
Web: www.delfield.com
DBSPECLINE 09/05
Over 950 distinct models in our standard offering.
1 Section
Reach-In
2 Section
Reach-In
3 Section
Reach-In
1 Section
Pass-Thru
2 Section
Pass-Thru
3 Section
Pass-Thru
1 Section
Roll-In
2 Section
Roll-In
3 Section
Roll-In
1 Section
Roll-Thru
2 Section
Roll-Thru
3 Section
Roll-Thru
Refrigerator X X X X X X X X X X X X
Freezer X X X X X X X X X
Dual Temp X X X X
Heated X X X X X X X X X X
Narrow X X
Shallow X X X X X
Convert-A-
Temp X X
Ready thaw X
Fish Drawer X X
Wine X X
Stainless
Interior X X X X X X X X X X X X
Aluminum
Interior X X X X X X X X X X X X
Solid FH Doors X X X X X X X X X X X X
Solid HH Doors X X X X X X X X X X X X
Glass FH Doors X X X X X X X X X X X X
Glass HH Doors X X X X X X
Solid Sliding
FH Doors X
Solid Sliding
HH Doors X
Glass Sliding
FH Doors X
Glass Sliding
HH Doors X
Water Cooled X X X X X X X X X X X X
Remote X X X X X X X X X X X X
Glycol Remote X X X X X X X X X X X X
Export Package X X X X X X X X X X X X
