Delfield ST4560N User manual

Project __________________________________
Item ____________________________________
Quantity ________________________________
CSI Section 11400
Approved _______________________________
Date ____________________________________
980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858 Phone: [phone] or 989-773-7981
Fax: [phone] www.delfield.com
Exterior top is one-piece, 22-gauge stainless steel with integral
2.12” (5.4cm) square nosing on the front. The backsplash is full
width and 4” (10cm) tall.
Exterior back and bottom are two-piece 24-gauge galvanized
steel. Exterior ends are stainless steel.
Interior sides of door models are thermoformed ABS
plastic with integral shelves supports. Interior back is one-
piece 22-gauge stainless steel. Interior bottom and top
are thermoformed ABS plastic. Base is fully insulated with
high-density foamed in place environmentally friendly, Kyoto
Protocol Compliant, Non ODP (Ozone Depletion Potential),
Non GWP (Global Warming Potential) polyurethane.
Refrigeration system uses HFC-404A refrigerant. Compressor
is 1/3 H.P., with condenser coil and condensate evaporator
mounted on rear of the cabinet. Evaporator coils are located
on the interior rear wall of the cabinet. Refrigerant flow is
controlled by a txv valve. Cabinet maintains an interior cabinet
temperature of -5°F to 0°F (-21°C to -18°C).
Electronic control is located on the exterior back of the
cabinet. It allows the unit to maintain consistent temperatures
in heavy duty conditions.
Electrical connections are 115 volt, 60 Hertz, single phase.
Unit has a 6’ (1.8m) long electrical cord and NEMA 5-15P plug.
Casters: Equipment is mounted on 5” (13cm) diameter plate
casters with front two locking. Equipment clearance above the
floor is 2.5” (6cm).
Doors have a 24-gauge stainless steel exterior, with
thermoformed ABS plastic interior liner. Cabinet of door
models has one adjustable epoxy-coated wire shelf.
Specifications
Standard Features
Options &
Accessories
All 4400 and 4500 Series units are 100% front
breathing, which allows the unit to be pushed
against a wall or built into a cabinet or an
existing line up
Durable, rugged stainless steel sides, top and
front
Features Delfield’s exclusive ABS interior (on
sides). ABS is extremely durable - it won’t dent,
chip or corrode and is backed by a limited
lifetime warranty
Heavy duty self-closing hinges
“ST” prefix models have a 4” stainless steel
backsplash
Environmentally friendly R404A refrigerant
High density foamed in place environmentally
friendly, Kyoto Protocol Compliant, Non ODP
(Ozone Depletion Potential), Non GWP (Global
Warming Potential) polyurethane keeps energy
costs low
Black recessed quick grip handle
Standard on 5” casters for easy cleaning and
installation
60-cycle single phase electrical system
6’ cord and plug supplied
•
•
•
•
•
•
•
•
•
•
•
ST4560N Single section freezer, flat top with doors•
Models
ST4560N Flat Top
Front-Breathing Self-Contained Flat Top Freezer Bases
ST4560N Flat Top: Front-Breathing Self-Contained Flat Top Freezer Bases
One epoxy coated wire shelf standard,
installed per door section
Electronic control
One year parts and 90 day labor
standard warranty
18” wide single tier overshelf
Stainless steel finish on back
Plastic laminate on front
Additional wire shelves
3” casters, 3.75” ride height
Door lock (solid door models only)
Exterior thermometer (solid door
models only)
Interior lights
220V/50 Hertz electrical system*
Inclusion of this option will alter
electrical specifications of the unit
•
•
•
•
•
•
•
•
•
•
•
•
*
ST4560N

980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858
Phone: [phone] or 989-773-7981
Fax: [phone]
www.delfield.com
ST4560N Flat Top Front-Breathing Self-Contained Flat Top Freezer Bases
Printed in the U.S.A.
DSST4560N
01/11
Deleld reserves the right to make changes to the design or specications without prior notice.
INSTALLATION NOTE:
Refrigeration system is designed so that air will flow under the unit, through the compressor
area and out the front of the unit. Any restriction to this air flow path will void the warranties.
Specifications
Model # of
Shelves
Shelf
Area Volume H.P. V/Hz/Ph Amps Nema Plug Ship Weight Energy (KWH/Day)
ST4560N 2 7.19ft216.90ft31/3 115/60/1 12.0 5-15P 411lbs/186kg 7.40
ST4560N ISO View
ST4560N Elevation View ST4560N Right Side View
ALT. SHELF
SHELF
31.50" [80.00]
29.55 [75.10]
2.50" [6.30]
30.66" [77.88]
TO EDGE OF DOOR
NOSE OF UNIT
33.59" [85.31]
36.00" [91.40]
4.00" [10.20]
INTERIOR DIMENSION
55.75" [141.61]
DOOR WIDTH DIMENSION
25.94" [65.89]
60.13" [152.72]
21.94" [55.73]
26.86" [68.22]
20.75" [52.70]
6.11" [15.52]
7.53" [19.10]
12.98" [33.00]
17.35" [44.08]
23.79" [60.43]
ALT. SHELF
SHELF
31.50" [80.00]
29.55 [75.10]
2.50" [6.30]
30.66" [77.88]
TO EDGE OF DOOR
NOSE OF UNIT
33.59" [85.31]
36.00" [91.40]
4.00" [10.20]
INTERIOR DIMENSION
55.75" [141.61]
DOOR WIDTH DIMENSION
25.94" [65.89]
60.13" [152.72]
21.94" [55.73]
26.86" [68.22]
20.75" [52.70]
6.11" [15.52]
7.53" [19.10]
12.98" [33.00]
17.35" [44.08]
23.79" [60.43]
ALT. SHELF
SHELF
31.50" [80.00]
29.55 [75.10]
2.50" [6.30]
30.66" [77.88]
TO EDGE OF DOOR
NOSE OF UNIT
33.59" [85.31]
36.00" [91.40]
4.00" [10.20]
INTERIOR DIMENSION
55.75" [141.61]
DOOR WIDTH DIMENSION
25.94" [65.89]
60.13" [152.72]
21.94" [55.73]
26.86" [68.22]
20.75" [52.70]
6.11" [15.52]
7.53" [19.10]
12.98" [33.00]
17.35" [44.08]
23.79" [60.43]
