ST4532N FRONT-BREATHINGSELF-CONTAINED COMPACT FLAT TOP FREEZERS
Project __________________________
Item____________________________
Quantity _________________________
CSI Section 11400
ST4532N FLAT TOP
Front-Breathing Self-Contained Compact Flat Top Freezers
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: 800-733-8948
Fax: 800-669-0619
Email: info@delfield.com
Approval _________________
Date____________________
MODELS:
 ST4532N Single section freezer  STD4532N Single section freezer
with doors with drawers
Model ST4532N
SPECIFICATIONS
Exterior top is one-piece, 22-gauge stainless steel
with integral square nosing on the front.
Exterior back and bottom are two-piece 24-gauge
galvanized steel.
Exterior ends are stainless steel.
Interior sides are thermoformed ABS plastic with
shelves supported on plugs. Interior back is one-
piece 22-gauge stainless steel. Interior bottoms are
thermofoamed ABS plastic. Base is fully insulated with
high-density foamed in place polyurethane.
Refrigeration system uses HFC-404A refrigerant.
Compressor is 1/5 H.P., with condenser coil and hot
gas condensate evaporator mounted on rear of the
cabinet. Evaporator coils are located on the interior
rear wall of the cabinet. Refrigerant flow is controlled
by a capillary tube. Cabinet maintains an interior
cabinet temperature of -5°F to 0°F (-20°C to -18°C).
Electrical connection is 115 volt, 60 Hertz, single
phase. Unit has a 7’ (2.1m) long electrical cord and
NEMA 5-15P plug.
Casters Equipment is mounted on 2” (5.08cm) (2.5”
ride height), diameter plate casters with front two
locking.
Door has a 24-gauge stainless steel exterior, with
thermoformed ABS plastic interior liner.
Drawers have 24-gauge stainless steel exterior with
thermoformed ABS plastic interior liner. Drawer frames
are 12-gauge stainless steel. Drawer slides are 11-
gauge stainless steel with Delrin bearings. Top drawer
holds one full size 12” x 20”, 4”-6" (30.5cm x 50.8cm
x 10.2cm) deep pan, and three 1/6 size pans. Bottom
drawer holds one full size 12 x 20" and three 1/6 size
4" deep pans. Pans are supplied by others.
STANDARD FEATURES
• All 4400 and 4500 Series units are 100% front breathing,
which allows the unit to be pushed against a wall or built into
a cabinet or an existing line up
• Durable, rugged stainless steel sides, top and front
• Features Delfield’s exclusive ABS interior (on sides). ABS
is extremely durable - it won’t dent, chip or corrode and is
backed by a limited lifetime warranty
• Heavy duty self-closing hinges
• “ST” prefix models have a 4” stainless steel backsplash
• “D” prefix models feature Delfield’s exclusive new drawer
system. Drawers are backed by a 10-year warranty on the
track assembly
• Environmentally friendly R404A refrigerant
• High density foamed in place polyurethane keeps energy
costs low
• Black recessed quick grip handle
• Standard on 2” casters for easy cleaning and installation
• 60-cycle single phase electrical system
• 7’ cord and plug supplied
• Cord spring relief - prevents cord rollover
• One epoxy coated wire shelf standard, installed per door
section
• ACT solid state electronic control
• One year parts and 90 day labor standard warranty.
OPTIONS AND ACCESSORIES
 Flat lift off cover
 18” wide single tier overshelf
 Stainless steel finish on back
 Plastic laminate on front
 Additional wire shelves
 Door lock
 Exterior thermometer
 Interior lights
 Glass door(s)
 *220V/50 Hertz electrical system
*Inclusion of this option will alter electrical
specifications of the unit.
4/%$'%/&$2!7%2
./3%/&5.)4
;=
;=
;=
;=
;=
;=
;=
;=
/2$%%00!.3/.4/0
$%%00!.3/.,9/."/44/-
ST4532N Front-Breathing Flat Top Freezer Base
Model #__________
CSI Section
Printed in the USA.
07/07
DS4532N
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: 800-733-8948
Fax: 800-669-0619
Email: info@delfield.com
MODEL #OF SHELF STORAGE VOLTS/HERTZ/ NEMA SHIP
NUMBER SHELVES AREA SQ. FT. CAP. CU. FT. H.P. PHASE AMPS PLUG WEIGHT
ST4532N 1 3.97 6.9 1/3 115/60/1 9.5 5-15P 280 lbs/ 127kg
STD4532N NA NA 2.7 1/3+ 115/60/1 12 5-15P 315 lbs/ 143kg
Mechanical Data — Standard Unit
INSTALLATION NOTE:
Refrigeration system is designed
so that air will flow under the unit,
through the compressor area and out
the front of the unit. Any restriction
to this air flow path will void the
warranties.
PLEASE NOTE:
Air flow through the louver on the
back of the unit is not necessary
for operation, however, any air
which passes through the louver is
beneficial.
ST4532N ISO VIEWST4532N ELEVATION VIEW ST4532N RIGHT SIDE VIEW
STD4532N ISO VIEW
STD4532N ELEVATION VIEW STD4532N RIGHT SIDE VIEW
;= 4/%$'%/&$//2
./3%/&5.)4
;=
;=
;=
;=
;=
;=
;=
).3)$%$)-%.3)/.
;=
;=
;=
;=
;=
;=
3(%,&
!,43(%,&
;=
;=
;=
;= 4/%$'%/&$//2
./3%/&5.)4
;=
;=
;=
;=
;=
;=
;=
).3)$%$)-%.3)/.
;=
;=
;=
;=
;=
;=
3(%,&
!,43(%,&
;=
;=
;=
;= 4/%$'%/&$//2
./3%/&5.)4
;=
;=
;=
;=
;=
;=
;=
).3)$%$)-%.3)/.
;=
;=
;=
;=
;=
;=
3(%,&
!,43(%,&
;=
;=
;=
