Delfield F5MC36DV User manual

Original Instructions
Installation, Operation and Maintenance Manual
This manual is updated as new information and models are released. Visit our website for the latest manual.
Part Number: 9291460 11/17
F5 and F15 Series
Refrigerated Display Cases

Safety Notices
nWarning
Readthismanualthoroughly beforeoperating,installing
or performing maintenance on the equipment. Failure
to follow instructions in this manual can cause property
damage, injury or death.
DANGER
Do not install or operate equipment that has been
misused, abused, neglected, damaged, or altered/
modified from that of original manufactured
specifications.
DANGER
Keep power cord AWAY from HEATED surfaces. DO NOT
immerse power cord or plug in water. DO NOT let power
cord hang over edge of table or counter.
DANGER
All utility connections and fixtures must be maintained
in accordance with local and national codes.
DANGER
Use appropriate safety equipment during installation
and servicing.
nWarning
Do not damage the refrigeration circuit when installing,
maintaining or servicing the unit.
nWarning
Authorized service representatives are obligated to
follow industry standard safety procedures, including,
but not limited to, local/national regulations for
disconnection / lock out / tag out procedures for all
utilities including electric, gas, water and steam.
nWarning
Do not store or use gasoline or other flammable vapors
or liquids in the vicinity of this or any other appliance.
Never use flammable oil soaked cloths or combustible
cleaning solutions, for cleaning.
nWarning
This product contains chemicals known to the State
of California to cause cancer and/or birth defects or
other reproductive harm. Operation, installation, and
servicing of this product could expose you to airborne
particles of glasswool or ceramic fibers, crystalline
silica, and/or carbon monoxide. Inhalation of airborne
particles of glasswool or ceramic fibers is known to the
State of California to cause cancer. Inhalation of carbon
monoxide is known to the State of California to cause
birth defects or other reproductive harm.
nWarning
Do not use electrical appliances or accessories other
than those supplied by the manufacturer.
nWarning
Use caution when handling metal surface edges of all
equipment.
nWarning
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
concerning use of the appliance by a person responsible
for their safety. Do not allow children to play with this
appliance.
Notice
Proper installation, care and maintenance are
essential for maximum performance and trouble-free
operation of your equipment. Visit our website www.
mtwkitchencare.com for manual updates, translations,
or contact information for service agents in your area.

Part Number: 9291460 11/17 3
Section 1
General Information
Model Numbers..................................................................................................................5
Serial Number Information ...............................................................................................5
Warranty Information ........................................................................................................5
Regulatory Certifications ..................................................................................................5
Domestic Models....................................................................................................................................5
Export Models .........................................................................................................................................5
Section 2
Installation
Location ..............................................................................................................................7
Weight of Equipment.........................................................................................................8
Clearance Requirements.................................................................................................... 8
Dimensions .........................................................................................................................8
F15 Leg & Caster Installation.............................................................................................9
Leveling...............................................................................................................................9
Stabilizing...........................................................................................................................9
Shelf Installation ................................................................................................................9
F5 Counter Installation For 36” & 48” Units....................................................................10
F5 Counter Installation For 60” & 72” Units....................................................................11
Electrical Service ..............................................................................................................12
Voltage.................................................................................................................................................... 12
Ground Fault Circuit Interrupter ....................................................................................................12
Rated Amperages, Horsepower, Voltage & Power Cord Chart............................................ 12
Drain Connections............................................................................................................13
Refrigeration ....................................................................................................................13
Remote Option Installation.............................................................................................14
F5 Remote Models ..............................................................................................................................14
F15 Remote Models............................................................................................................................14
Section 3
Operation
Refrigerated Display Cases..............................................................................................15
Display Lock Operation ...................................................................................................15
115Volt Power Switch ......................................................................................................16
115Volt Light Switch ........................................................................................................16
115Volt Temperature Controls........................................................................................16
Temperature Control & Display...................................................................................................... 17
115Volt F15 Pressure Control..........................................................................................18
Changing Display from Fahrenheit to Celsius on ERC112 Control.................................... 19
230-240 Volt Export Operation.......................................................................................20
Table of Contents

4 Part Number: 9291460 11/17
Table of Contents (continued)
Section 4
Maintenance
General Cleaning..............................................................................................................21
Interior Cleaning ..............................................................................................................22
Gaskets.................................................................................................................................................... 22
Preventing Blower Coil Corrosion ................................................................................................. 22
Exterior Cleaning..............................................................................................................22
Drain......................................................................................................................................................... 22
Cleaning The Condenser Coil...........................................................................................23
Cleaning The Condensate Evaporator ............................................................................23
Remote Models Only.......................................................................................................................... 23
Door Maintenance............................................................................................................23
Doors With Hinges.............................................................................................................................. 23
Sliding Doors......................................................................................................................................... 23

Part Number: 9291460 11/17 5
Model Numbers
This manual covers the following refrigerated display cases:
Mirrored Back Pass-thru See-thru
Self-Contained Drop-In
F5MC36DV F5PC36DV F5SC36DV
F5MC48DV F5PC48DV F5SC48DV
F5MC60DV F5PC60DV F5SC60DV
F5MC72DV F5PC72DV F5SC72DV
Self-Contained Serview
F15MC48DV F15PC48DV F15SC48DV
F15MC60DV F15PC60DV F15SC60DV
F15MC72DV F15PC72DV F15SC72DV
Export Numbers
Mirrored Back Pass-thru See-thru
Export Self-Contained Drop-In
F5MC36D-E F5PC36D-E F5SC36D-E
F5MC48D-E F5PC48D-E F5SC48D-E
F5MC60D-E F5PC60D-E F5SC60D-E
F5MC72D-E F5PC72D-E F5SC72D-E
Export Self-Contained Serview
F15MC48D-E F15PC48D-E F15SC48D-E
F15MC60D-E F15PC60D-E F15SC60D-E
F15MC72D-E F15PC72D-E F15SC72D-E
Serial Number Information
The serial number is on the identification plate that also
includes the model number.
• Self-contained F5 series identification plate is located
near the condensing unit.
• The serial number on all self-contained F15 series units
is located behind the compressor housing.
Always have the serial number of your unit available
when calling for parts or service.
Warranty Information
Visit www.delfield.com/warranty to:
• Register your product for warranty.
• Verify warranty information.
• View and download a copy of your warranty.
Regulatory Certifications
DOMESTIC MODELS
115Volt models are certified by:
• National Sanitation Foundation (NSF)
• Underwriters Laboratories (UL)
• Underwriters Laboratories of Canada (cUL)
EXPORT MODELS
Export models are certified by:
• National Sanitation Foundation (NSF)
• Technical Inspection Association
• European Conformity
Section 1
General Information

6 Part Number: 9291460 11/17
General Information Section 1
THIS PAGE INTENTIONALLY LEFT BLANK

Part Number: 9291460 11/17 7
DANGER
Installation must comply with all applicable fire and
health codes in your jurisdiction.
Location
nWarning
This equipment must be positioned so that the plug is
accessible unless other means for disconnection from
the power supply (e.g., circuit breaker or disconnect
switch) is provided.
nWarning
Adequate means must be provided to limit the
movement of this appliance without depending on or
transmitting stress to the electrical conduit or gas lines.
nWarning
To avoid instability the installation area must be capable
of supporting the combined weight of the equipment
and product. Additionally the equipment must be level
side to side and front to back.
nWarning
This equipment is intended for indoor use only. Do not
install or operate this equipment in outdoor areas.
The location selected for the equipment must meet the
following criteria. If any of these criteria are not met, select
another location.
• Units are intended for indoor use only.
• The location MUST be level, stable and capable of
supporting the weight of the equipment.
• The location MUST be free from and clear of
combustible materials.
• Equipment MUST be level both front to back and side to
side.
• Position the equipment so it will not tip or slide.
• Front casters MUST be locked once positioned.
• Recommended air temperature is 50° - 100°F
(10° - 38°C).
• Proper air supply for ventilation is REQUIRED AND
CRITICAL for safe and efficient operation.
• Do not obstruct the flow of ventilation air. Make sure the
air vents of the equipment are not blocked.
• Do not install the equipment directly over a drain.
Steam rising up out of the drain will adversely affect
operation, air circulation, and damage electrical /
electronic components.
Section 2
Installation

8 Part Number: 9291460 11/17
Installation Section 2
Weight of Equipment
Model Export Option Weight
Self-Contained Drop-In
F5MC36DV F5MC36D-E 525lbs (238kg)
F5PC36DV F5PC36D-E 541lbs (245kg)
F5SC36DV F5SC36D-E 546lbs (248kg)
F5MC48DV F5MC48D-E 590lbs (268kg)
F5PC48DV F5PC48D-E 609lbs (276kg)
F5SC48DV F5SC48D-E 614lbs (279kg)
F5MC60DV F5MC60D-E 690lbs (313kg)
F5PC60DV F5PC60D-E 711lbs (323kg)
F5SC60DV F5SC60D-E 718lbs (326kg)
F5MC72DV F5MC72D-E 790lbs (358kg)
F5PC72DV F5PC72D-E 815lbs (370kg)
F5SC72DV F5SC72D-E 818lbs (371kg)
Self-Contained Serview
F15MC48DV F15MC48D-E 759lbs (344kg)
F15PC48DV F15PC48D-E 807lbs (366kg)
F15SC48DV F15SC48D-E 786lbs (357kg)
F15MC60DV F15MC60D-E 949lbs (430kg)
F15PC60DV F15PC60D-E 1009lbs (458kg)
F15SC60DV F15SC60D-E 983lbs (446kg)
F15MC72DV F15MC72D-E 1110lbs (503kg)
F15PC72DV F15PC72D-E 1159lbs (526kg)
F15SC72DV F15SC72D-E 1140lbs (517kg)
Clearance Requirements
• Keep the vents clean and free of obstruction.
• Casters or optional legs must be used and not removed.
Dimensions
Model Length Depth Height
Self-Contained Drop-In
F5MC36DV 36”(91cm) 31.5”(80cm) 57” (145cm)
F5PC36DV 36”(91cm) 33.38”(85cm) 57” (145cm)
F5SC36DV 36” (91cm) 33.38”(85cm) 57” (145cm)
F5MC48DV 48”(122cm) 31.5” (80cm) 57” (145cm)
F5PC48DV 48”(122cm) 33.38” (85cm) 57” (145cm)
F5SC48DV 48” (122cm) 33.38”(85cm) 57” (145cm)
F5MC60DV 60”(152cm) 31.5” (80cm) 57” (145cm)
F5PC60DV 60”(152cm) 33.38” (85cm) 57” (145cm)
F5SC60DV 60” (152cm) 33.38”(85cm) 57” (145cm)
F5MC72DV 72”(183cm) 31.5” (80cm) 57” (145cm)
F5PC72DV 72”(183cm) 33.38” (85cm) 57” (145cm)
F5SC72DV 72” (183cm) 33.38”(85cm) 57” (145cm)
Self-Contained Serview
F15MC48DV 48”(122cm) 31.5”(80cm) 78”(198cm)
F15PC48DV 48”(122cm) 33.38” (85cm) 78” (198cm)
F15SC48DV 48” (122cm) 33.38”(85cm) 78” (198cm)
F15MC60DV 60”(152cm) 31.5”(80cm) 78”(198cm)
F15PC60DV 60”(152cm) 33.38” (85cm) 78” (198cm)
F15SC60DV 60” (152cm) 33.38”(85cm) 78” (198cm)
F15MC72DV 72”(183cm) 31.5”(80cm) 78”(198cm)
F15PC72DV 72”(183cm) 33.38” (85cm) 78” (198cm)
F15SC72DV 72” (183cm) 33.38”(85cm) 78” (198cm)
Export Self-Contained Drop-In
F5MC36D-E 36” (91cm) 31.5” (80cm) 57.5” (146cm)
F5PC36D-E 36” (91cm) 33.38”(85cm) 57.5” (146cm)
F5SC36D-E 36”(91cm) 33.38”(85cm) 57.5” (146cm)
F5MC48D-E 48” (122cm) 31.5” (80cm) 57.5” (146cm)
F5PC48D-E 48” (122cm) 33.38”(85cm) 57.5” (146cm)
F5SC48D-E 48” (122cm) 33.38”(85cm) 57.5” (146cm)
F5MC60D-E 60” (152cm) 31.5” (80cm) 57.5” (146cm)
F5PC60D-E 60” (152cm) 33.38”(85cm) 57.5” (146cm)
F5SC60D-E 60” (152cm) 33.38”(85cm) 57.5” (146cm)
F5MC72D-E 72” (183cm) 31.5” (80cm) 57.5” (146cm)
F5PC72D-E 72” (183cm) 33.38”(85cm) 57.5” (146cm)
F5SC72D-E 72” (183cm) 33.38”(85cm) 57.5” (146cm)
Export Self-Contained Serview
F15MC48D-E 48” (122cm) 31.5” (80cm) 78” (198cm)
F15PC48D-E 48” (122cm) 33.38”(85cm) 78” (198cm)
F15SC48D-E 48” (122cm) 33.38” (85cm) 78”(198cm)
F15MC60D-E 60” (152cm) 31.5” (80cm) 78” (198cm)
F15PC60D-E 60” (152cm) 33.38”(85cm) 78” (198cm)
F15SC60D-E 60” (152cm) 33.38” (85cm) 78”(198cm)
F15MC72D-E 72” (183cm) 31.5” (80cm) 78” (198cm)
F15PC72D-E 72” (183cm) 33.38”(85cm) 78” (198cm)
F15SC72D-E 72” (183cm) 33.38” (85cm) 78”(198cm)

Part Number: 9291460 11/17 9
Section 2 Installation
Model Shelf
Area
Display
Volume
Base
Volume
Self-Contained Drop-In
F5MC36DV 14.2ft216.2ft3NA
F5PC36DV 15.5ft218.1ft3NA
F5SC36DV 15.5ft217.6ft3NA
F5MC48DV 19.6ft222.3ft3NA
F5PC48DV 21.4ft225ft3NA
F5SC48DV 21.4ft224.3ft3NA
F5MC60DV 25ft228.4ft3NA
F5PC60DV 27.3ft231.9ft3NA
F5SC60DV 27.3ft231ft3NA
F5MC72DV 30.5ft234.6ft3NA
F5PC72DV 33.3ft238.8ft3NA
F5SC72DV 33.3ft237.7ft3NA
Self-Contained Serview
F15MC48DV 19.6ft222.3ft39.15ft3
F15PC48DV 21.4ft225ft39.15ft3
F15SC48DV 21.4ft224.3ft39.15ft3
F15MC60DV 25ft228.4ft312.13ft3
F15PC60DV 27.3ft231.9ft312.13ft3
F15SC60DV 27.3ft231ft312.13ft3
F15MC72DV 30.5ft234.6ft318.04ft3
F15PC72DV 33.3ft238.8ft318.04ft3
F15SC72DV 33.3ft237.7ft318.04ft3
Model Shelf
Area
Display
Volume
Base
Volume
Export Self-Contained Drop-In
F5MC36D-E 14.2ft2(13192cm2) 16.2ft3 (459L) NA
F5PC36D-E 15.5ft2 (14400cm2) 18.1ft3 (513L) NA
F5SC36D-E 15.5ft2 (14400cm2) 17.6ft3 (498L) NA
F5MC48D-E 19.6ft2 (18209cm2) 22.3ft3 (631L) NA
F5PC48D-E 21.4ft2 (19881cm2) 25ft3 (708L) NA
F5SC48D-E 21.4ft2 (19881cm2) 24.3ft3 (688L) NA
F5MC60D-E 25ft2 (23226cm2) 28.4ft3 (804L) NA
F5PC60D-E 27.3ft2 (25363cm2) 31.9ft3 (903L) NA
F5SC60D-E 27.3ft2 (25363cm2) 31ft3 (878L) NA
F5MC72D-E 30.5ft2 (28335cm2) 34.6ft3 (980L) NA
F5PC72D-E 33.3ft2 (30937cm2) 38.8ft3 (1099L) NA
F5SC72D-E 33.3ft2 (30937cm2) 37.7ft3 (1068L) NA
Export Self-Contained Serview
F15MC48D-E 19.6ft2 (18209cm2) 22.3ft3 (631L) 9.15ft3 (259L)
F15PC48D-E 21.4ft2 (19881cm2) 25ft3 (708L) 9.15ft3 (259L)
F15SC48D-E 21.4ft2 (19881cm2) 24.3ft3 (688L) 9.15ft3 (259L)
F15MC60D-E 25ft2 (23226cm2) 28.4ft3 (804L) 12.13ft3 (343L)
F15PC60D-E 27.3ft2 (25363cm2) 31.9ft3 (903L) 12.13ft3 (343L)
F15SC60D-E 27.3ft2 (25363cm2) 31ft3 (878L) 12.13ft3 (343L)
F15MC72D-E 30.5ft2 (28335cm2) 34.6ft3 (980L) 18.04ft3 (511L)
F15PC72D-E 33.3ft2 (30937cm2) 38.8ft3 (1099L) 18.04ft3 (511L)
F15SC72D-E 33.3ft2 (30937cm2) 37.7ft3 (1068L) 18.04ft3 (511L)
F15 Leg & Caster Installation
DANGER
Legs or casters must be installed and the legs or casters
must be screwed in completely to prevent bending.
When casters are installed the mass of this unit will
allow it to move uncontrolled on an inclined surface.
These units must be tethered/secured to comply with
all applicable codes.
nWarning
The unit must be installed in a stable condition with
the front wheels locked. Locking the front casters after
installation is the owner’s and operator’s responsibility.
Leveling
After the cabinet has been placed in the desired location,
cabinets with legs must be leveled. Level units from front to
back and from side to side. Leveling will insure proper door
operation and removal of condensate. Cabinets with casters
must have the caster brake set so the cabinet cannot move.
Stabilizing
It is very important that all legs are properly adjusted to
keep the cabinet level, evenly distribute the weight and to
make sure the unit will not rock, lean or be unstable.
Shelf Installation
Display cases come with three epoxy coated wire shelves
that are adjustable in 3-3/4”increments.

10 Part Number: 9291460 11/17
Installation Section 2
F5 Counter Installation For 36” & 48” Units
Installation Dimensions
Counter Cutout 32.62”x 18.62” (83cm x 47cm)
2 Louver Cutouts 22”x 11” (56cm x 28cm)
Max distance between counter
top and louver cutout 4.00”(10cm)
11.00”
(28cm)
18.62”(47cm)
32.62”(83cm)
22.0”(56cm)
4.0”(10cm)
Max
11.00”
(28cm)
13.00”
(33cm)
Air duct dimensions
to match condenser face
1. Install partitions between F5 refrigerated display case
and other electrical appliances if they are located in the
same cabinet. Partitions must fully extend front to back
and top to bottom.
2. Install a GFCI receptacle a minimum of 14”(36cm) up
from the cabinet bottom inside the partitions.
3. The unit requires airflow to the compressor. Two
louvers are provided with each unit.
NOTE: Any restriction to the proper air flow will void the
compressor warranty.
• Louver cut-outs are 22” x 11”(56cm by 28cm).
• 143in (923cm) is required at both the intake and
discharge.
• Cut-outs are to begin a maximum of 4.00”(10cm)
from the counter-top.
• Install the louvers on the front and back of the
cabinet.
Discharge Air
Fresh Air
Louver
Louver
Condenser
4. Place the condensing unit through the counter cutout.
5. Construct a 13”x 11” (33cm x 28cm) air duct (not
provided) connecting the condenser face to the louver.
This will prevent recirculation of discharge air.
11.00”
(28cm)
18.62”(47cm)
32.62”(83cm)
22.0”(56cm)
4.0”(10cm)
Max
11.00”
(28cm)
13.00”
(33cm)
Air duct dimensions
to match condenser face

Part Number: 9291460 11/17 11
Section 2 Installation
F5 Counter Installation For 60” & 72” Units
Installation Dimensions
Counter Cutout 32.62”x 18.62” (83cm x 47cm)
2 Louver Cutouts 22”x 11” (56cm x 28cm)
Max distance between counter
top and louver cutout 4.00”(10cm)
11.00”
(28cm)
18.62”(47cm)
32.62”(83cm)
22.0”(56cm)
12.00”
(30cm)
14.50”
(37cm)
Cutout
to match
condenser
face
4.0”(10cm)
Max
14.50”
(37cm)
1. Install partitions between F5 refrigerated display case
and other electrical appliances if they are located in the
same cabinet. Partitions must fully extend front to back
and top to bottom.
2. Install a GFCI receptacle a minimum of 14”(36cm) up
from the cabinet bottom inside the partitions.
3. The unit requires airflow to the compressor. Two
louvers are provided with each unit.
NOTE: Any restriction to the proper air flow will void the
compressor warranty.
• Louver cut-outs are 22” x 11”(56cm by 28cm).
• 174in (1123cm) is required at both the intake and
discharge.
• Cut-outs are to begin a maximum of 4.00”(10cm)
from the counter-top.
• Install louvers on the front and back of the cabinet
or both on the front with a minimum of 12”(30cm)
between them.
Condenser
Fresh
Air
Dis-Charge
Air
Louver LouverMin
12.00"
30cm
4. Place the condensing unit through the counter cutout.
5. Construct a 14.50”x 12” (37cm x 30cm) air duct (not
provided) connecting the condenser face to the louver.
This will prevent recirculation of discharge air.
11.00”
(28cm)
18.62”(47cm)
32.62”(83cm)
22.0”(56cm)
12.00”
(30cm)
14.50”
(37cm)
Cutout
to match
condenser
face
4.0”(10cm)
Max
14.50”
(37cm)

12 Part Number: 9291460 11/17
Installation Section 2
Electrical Service
DANGER
Check all wiring connections, including factory
terminals, before operation. Connections can become
loose during shipment and installation.
nWarning
This appliance must be grounded and all field wiring
must conform to all applicable local and national
codes. Refer to rating plate for proper voltage. It is the
responsibility of the end user to provide the disconnect
means to satisfy the authority having jurisdiction.
VOLTAGE
All electrical work, including wire routing and grounding,
must conform to local, state and national electrical codes.
The following precautions must be observed:
• The equipment must be grounded.
• A separate fuse/circuit breaker must be provided for
each unit.
• Check all green ground screws, cables and wire
connections to verify they are tight before start-up.
GROUND FAULT CIRCUIT INTERRUPTER
Ground Fault Circuit Interrupter (GFCI/GFI) protection is
a system that shuts down the electric circuit (opens it)
when it senses an unexpected loss of power, presumably
to ground. Welbilt does not recommend the use of GFCI/
GFI circuit protection to energize our equipment. If code
requires the use of a GFCI/GFI then you must follow the
local code. The circuit must be dedicated, sized properly
and there must be a panel GFCI/GFI breaker. We do not
recommend the use of GFCI/GFI outlets to energize our
equipment as they are known for more intermittent
nuisance trips than panel breakers.
RATED AMPERAGES, HORSEPOWER, VOLTAGE &
POWER CORD CHART
Display cases come with maximum 8ft (2.4m) cord and
plug.
Model Amps H.P.
Volts,
Hertz,
Phase
Nema Plug
Self-Contained Drop-In
F5MC36DV
12 1/2 115,60,1 5-15P
F5PC36DV
F5SC36DV
F5MC48DV
F5PC48DV
F5SC48DV
F5MC60DV
16 3/4 115,60,1 5-20P
F5PC60DV
F5SC60DV
F5MC72DV
F5PC72DV
F5SC72DV
Self-Contained Serview
F15MC48DV
16 3/4 115,60,1 5-20P
F15PC48DV
F15SC48DV
F15MC60DV
F15PC60DV
F15SC60DV
F15MC72DV
F15PC72DV
F15SC72DV
Model Amps
Max
Lamp
Watts
H.P.
Volts,
Hertz,
Phase
Nema
Plug
Export Self-Contained Drop-In
F5MC36D-E
6.0 25 1/2 230-240,
50,1
Varies per
destination
F5PC36D-E
F5SC36D-E
F5MC48D-E
F5PC48D-E
F5SC48D-E
F5MC60D-E
6.0 40 3/4 230-240,
50, 1
Varies per
destination
F5PC60D-E
F5SC60D-E
F5MC72D-E
F5PC72D-E
F5SC72D-E
Export Self-Contained Serview
F15MC48D-E
6.0 25 3/4 230-240,
50,1
Varies per
destination
F15PC48D-E
F15SC48D-E
F15MC60D-E
6.0 40 3/4 230-240,
50, 1
Varies per
destination
F15PC60D-E
F15SC60D-E
F15MC72D-E
F15PC72D-E
F15SC72D-E

Part Number: 9291460 11/17 13
Section 2 Installation
Drain Connections
Self-contained models are standard with a condensate
evaporator. If, for some reason, a unit does not have a
condensate evaporator, or the evaporator fails, the unit’s
drain must have an outlet to an appropriate drainage area
or container.
nWarning
Moisture collecting from improper drainage can create a
slippery surface on the floor and a hazard to employees.
It is the owner’s responsibility to provide a container or
outlet for drainage.
Refrigeration
Model BTU/Hour
Capacity
Heat of
Rejection
R404A
Charge
Base Display Base Display
Self-Contained Drop-In
F5MC36DV N/A 4780 N/A 425 32oz
F5PC36DV N/A 4780 N/A 750 32oz
F5SC36DV N/A 4780 N/A 510 32oz
F5MC48DV N/A 5335 N/A 520 32oz
F5PC48DV N/A 5335 N/A 900 32oz
F5SC48DV N/A 5335 N/A 750 32oz
F5MC60DV N/A 6900 N/A 600 48oz
F5PC60DV N/A 6900 N/A 1050 48oz
F5SC60DV N/A 6900 N/A 714 48oz
F5MC72DV N/A 7450 N/A 690 48oz
F5PC72DV N/A 7450 N/A 1200 48oz
F5SC72DV N/A 7450 N/A 1020 48oz
Self-Contained Serview
F15MC48DV 3600 6800 190 450 48oz
F15PC48DV 3600 6800 190 780 48oz
F15SC48DV 3600 6800 190 630 48oz
F15MC60DV 3600 6800 220 518 48oz
F15PC60DV 3600 6800 220 900 48oz
F15SC60DV 3600 6800 220 740 48oz
F15MC72DV 3600 7350 250 600 48oz
F15PC72DV 3600 7350 250 860 48oz
F15SC72DV 3600 7350 250 1030 48oz
Export models are temperature class N.

14 Part Number: 9291460 11/17
Installation Section 2
Remote Option Installation
F5 REMOTE MODELS
1.75"
(4cm)
C
Cutout
3.00" X 12.00" (8cm X 30cm)
Centered Front To Back
0.25" (0.6cm) From End
Front Of Unit
J= Junction Box
R= Refrigeration Lines,
0.25" Liquid,
0.37" Suction
D= 0.50" I.D. Drain
R
D
J
3.75"
(10cm)
3.75"
(10cm)
F5 Typical Mechanical Access (Plan View)
F15 REMOTE MODELS
1.75"
4cm
1.00"
2.5cm C
Front Of Unit
J= Junction Box
R= Refrigeration Lines,
0.25" Liquid,
0.37" Suction
D= 0.50" I.D. Drain
R
D
D
J
3.75"
10cm
30.00"
76cm
3.75"
10cm
F15 Typical Mechanical Access (Plan View)

Part Number: 9291460 11/17 15
DANGER
The on-site supervisor is responsible for ensuring that
operators are made aware of the inherent dangers of
operating this equipment.
DANGER
Do not operate any appliance with a damaged cord
or plug. All repairs must be performed by a qualified
service company.
DANGER
Never stand on the unit! They are not designed to
hold the weight of an adult, and may collapse or tip if
misused in this manner.
DANGER
Keep power cord AWAY from HEATED surfaces. DO NOT
immerse power cord in water. DO NOT let power cord
hang over edge of table or counter.
nWarning
Do not contact moving parts.
nWarning
The operator of this equipment is solely responsible
for ensuring safe holding temperature levels for all
food items. Failure to do so could result in unsafe food
products for customers.
nWarning
Do not use electrical appliances or accessories other
than those supplied by the manufacturer.
nWarning
All covers and access panels must be in place and
properly secured, before operating this equipment.
nWarning
Damp or wet hands may stick to cold surfaces.
nWarning
Maximum weight for shelves is 75 pounds. Overloading
shelves can damage equipment or cause bodily injury.
nWarning
Do not block the supply and return air grills or the air
space around the air grills. Keep plastic wrappings,
paper, labels, etc. from being airborne and lodging in
the grills. Failure to keep the air grills clear will result in
unsatisfactory operation of the system.
,Caution
Do not throw items into the display case or storage
area. Failure to heed this recommendation could result
in damage to the interior of the cabinet or to the blower
coil.
Refrigerated Display Cases
Delfield display cases are designed to maintain 36°F to 40°F
(2°C to 4°C) operational temperature in both the display
and storage areas (F15 series only) at 55% or lower ambient
relative humidity.
Notice
If humidity is above 55%, condensation on the glass will
be present.
Display Lock Operation
At the factory, the keys are taped to the display case.
To lock: Line up key ridge with red dot.
Insert key and rotate one-half turn.
Remove key and push lock bolt in.
To open: Line up ridge with red dot.
Insert key and rotate key one-half turn.
Remove key.
Section 3
Operation

16 Part Number: 9291460 11/17
Operation Section 3
115Volt Power Switch
F5 power switch is located next to the condensing unit.
Turn the switch ON to begin operation.
F15 displays cases have one power switch. It is located
behind the louvered panel in the mechanical compartment.
Turn the switch ON to begin operation.
F15 Power Switch On Top of Base Temperature Control
115Volt Light Switch
The lights are controlled by a 3 position switch. The switch is
located in the display nosing under the display thermostat.
It has the following positions and functions:
• Top position – Motion – the lights will function
according to the motion sensors. This is the factory
recommended setting.
• Middle position – Off – the light will be off.
• Bottom position – On – the lights will be on.
115Volt Temperature Controls
The F5 and F15 display case temperature control is located
in the display nosing.
F5 & F15 Display Temperature Control
F15 display cases have two temperature controls. The
base temperature control in located in the mechanical
compartment.
F15 Base Temperature Control
Display cases are factory set at mid-range to maintain about
38ºF (3ºC) box temperature.
1. At initial start-up or anytime power is disconnected,
then reconnected to the unit, the control will go into
defrost mode.
2. The control will enter a DEFROST mode and the display
will read dEF. The compressor and condenser fan as
well as the evaporator fan will remain off until this
initial defrost is complete. This initial defrost cycle may
take up to 35 minutes to complete.
3. The display will continue to read dEF for an additional
30 minutes while the cooling cycle cools the box to the
set temperature.
4. Then the digital thermostat will display box
temperature.
5. The temperature control will cycle the compressor,
evaporator fan motor and condenser fan motor to
maintain box temperature at the control setting. For
more information see Evaporator Fan Operation on
page 18.
Defrost
The temperature control also monitors the evaporator
temperature and will turn off the compressor and
condenser fan motor when needed to allow accumulated
frost on the evaporator to clear. During this defrost cycle,
the digital temperature display will read dEF. After the
defrost cycle is complete, the temperature control will
return to a normal cooling cycle, but the display will
continue to read dEF until the evaporator returns to normal
cooling temperatures (up to 30 minutes).
The electronic temperature controller monitors evaporator
temperature and compressor run time to determine the
proper time for a positive defrost cycle. A defrost cycle
can occur as often as every 60 minutes under extremely
heavy usage. When the controller enters the defrost mode
the compressor is shut off and will remain off until the
evaporator coil temperature exceeds 41°F or the controller
reaches a time limit of 75 minutes. The defrost cycle can last
from a minimum of 2 minutes to a maximum of 75 minutes.

Part Number: 9291460 11/17 17
Section 3 Operation
TEMPERATURE CONTROL & DISPLAY
Operation / Indication
Status Displayed Comments
Normal (°C) Temp. [°C] Unit depends on setting
(parameters in control)
Normal (°F) Temp. [°F]
Show set-point Temp.
Set to Defrost dEF / Temp Depends on setting
(parameters in control
or as chosen by upper
left button)
Sensor 1 defect E01 X Air sensor
Sensor 2 defect E02 X Coil sensor
Sensor 3 defect E03 X Open
Sensor 4 defect E04 X Open
High temperature
alarm
Hi X Automatically switching
at 2 sec rate
Low temperature alarm Lo X
Line voltage too high uHi X
Line voltage too low uLi X
Control calls for cooling
for more than 24 hours
straight
LEA X Time includes defrost.
Error will go away if the
control cycles off the
compressor or if the
power is shut off. If error
is on a cold pan it could
be related to a high
ambient temperature or
not shutting the rail off
nightly.
Temperature Control & Display Operation
V
V
Press upper or lower right button.
• Display show actual set-point (blinking).
• If buttons untouched for 3 seconds returns to
normal.
• Increase set-point by pressing upper button. Max value
depends on parameters in control.
• Decrease set-point by pressing lower button. Min value
depends on parameters in control.
• If buttons untouched for 3 seconds returns to
normal and stores new set-point.
Press upper left button for 5 seconds.
• Start defrost.
Press lower left button for 5 seconds.
• Unit goes into stand-by mode.
• The display will read Off, then a period.
• Press the lower left button again for 5 seconds.
• The display will read On.
• The unit will then start up in the defrost mode,
and display will read dEF.
Temperature Alarm
The alarm will sound and flash HI or LO 90 minutes after the
unit has reached its alarm temperature point or after any
power interruption if the temperature is above or below
the alarm set points. Refrigerators are factory set at mid-
range to maintain about 38ºF (3ºC) box temperature. The
high refrigerator temperature point is 50°F (10°C). The low
refrigerator temperature point is 25°F (-4°C).

18 Part Number: 9291460 11/17
Operation Section 3
EVAPORATOR FAN OPERATION
During normal operation the evaporator fan may cycle
and/or pulse independently of the compressor. Consult
Technical Support at 1-844-724-CARE if you are unsure of
the proper function.
Cooling Cycle Defrost Cycle
Compressor On Compressor Off Compressor Off
Evap Fan On Evap Fan Cycles On
2-Min, Off 2-Min
Evap Fan On
115Volt F15 Pressure Control
F15 display cases have a high pressure limiting device.
Under severe overloading conditions, or in the event of a
condenser fan failure or a plugged or blocked condenser,
this device may shut down the refrigeration system. This
device will automatically reset, but determining the cause
of the high pressure condition should be investigated by a
qualified refrigeration technician.
,Caution
In attempting to adjust the pressure control, you can
do damage to your unit. Please contact KitchenCare +1
[phone] or your local service agent. Delfield is
not responsible for charges incurred while having the
pressure control adjusted.
Factory Recommended Settings
Cut-in 20#
Cut-out 5#
Differential 15#
F15 Base Pressure Control

Part Number: 9291460 11/17 19
Section 3 Operation
CHANGING DISPLAY FROM FAHRENHEIT TO CELSIUS
ON ERC112 CONTROL
1. Simultaneously hold the up and down arrows for
5 seconds to access menu for password protected
parameters.
2. Screen should temporarily flash PAS and then move to
a numeric screen.
3. Scroll to 187 using the up/down arrows and push the
stand-by button (lower left button) to enter.
4. Scroll to dis using the up/down arrows and push the
stand-by button (lower left button) to enter into the
display menu.
5. Scroll to CFu using the up/down arrows and push the
stand-by button (lower left button) to enter the display
unit menu.
6. -F should be displayed indicating Fahrenheit. Use
the down arrow to change it to -C for Celsius and hit
the stand-by button (lower left button) to enter the
change.
7. Push the defrost button (upper left button) to move
out of the display unit menu.
8. Push the defrost button (upper left button) to move
out of the display menu and back to the normal display.
NOTE: For steps 7 and 8, display will return back to normal
display after 30 seconds of inactivity.

20 Part Number: 9291460 11/17
Operation Section 3
230-240 Volt Export Operation
After turning the ON/OFF switch to ON the unit’s
compressor will begin operating. Located on the operator
side at the top right is an ON/OFF switch for the display
lights.
Temperature Control
Display and base temperature is controlled by separate
thermostats. The display temperature control is located in
the fan shroud. The F15 base thermostat is located in the
mechanical compartment.
• The thermostat is set at 2.5 at the factory to provide
proper operation.
• To adjust the temperature, turn the knob clockwise as
indicated on the control. Settings are from 1 through 9
(9 being the coldest).
• Adjustments should be made gradually.
• Several small adjustments will be more effective than
one large adjustment.
• It may take an hour or longer to realize the temperature
change depending on the application and location of
the unit.
Thermostat Dial
Export 230-240 Volt Pressure Control
The export display cases have a high pressure limiting
device. Under severe overloading conditions, or in the
event of a condenser fan failure or a plugged or blocked
condenser, this device may shut down the refrigeration
system. This device will automatically reset, but determining
the cause of the high pressure condition should be
investigated by a qualified refrigeration technician.
,Caution
In attempting to adjust the pressure control, you can
do damage to your unit. Please contact KitchenCare +1
[phone] or your local service agent. Delfield is
not responsible for charges incurred while having the
pressure control adjusted.
Factory Recommended Settings
Cut-in 20#
Cut-out 5#
Differential 15#
Cut In -
Knob
Controlled
Dierential
F15 Refrigerated Base Evaporator Fan Operation
When the refrigerator is initially powered up or immediately
following a power outage the unit will begin cooling after a
3-6 minute delay. During normal operation the evaporator
fan pulses independently of the compressor as dictated by
the controller as follows:
• During the cooling mode, compressor and evaporator
fan run simultaneously.
• During the compressor off mode, evaporator fan pulses
three minutes on and three minutes off.
• During an actual defrost event other than the off-cycle
defrost, compressor stays off but the evaporator fan
runs continuously.
Cooling Cycle Defrost Cycle
Compressor On Compressor Off Compressor Off
Evaporator Fan On Evap Fan Cycles On
3-Min, Off 3-Min
Evaporator Fan On
