MERIDIAN SERIES® SOLID DOOR SHALLOW REACH-IN REFRIGERATORS
Project __________________________
Item____________________________
Quantity _________________________
CSI Section 11400
MERIDIAN SERIES®
Solid Door Shallow Reach-In Refrigerators
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.deleld.com
Phone: [phone]
Fax: [phone]
Email: info@deleld.com
Approval _________________
Date____________________
MRR1S-S
SPECIFICATIONS
Exterior: Cabinet front and shroud shall be 22-gauge
stainless steel. Exterior sides shall be made of aluminum.
Facing of shroud shall be easily removable without the
use of tools.
Cabinet interior shall be anodized aluminum. Bottom &
top of liner shall be die-stamped to provide radius corners
and a recessed bottom. Base shall be fully insulated with
high-density foamed in place polyurethane.
Interior shall have three epoxy-coated wire shelves per
door section. Shelf support pilasters shall be heavy-duty
with shelves adjustable at 1.0” (2.5 cm) increments. Unit
will be mounted on 6” (15.24 cm) metal legs.
Doors: Solid doors shall have a 22-gauge stainless steel
exterior & anodized aluminum interior liner. Doors shall
be fully insulated with high density foamed in place
polyurethane. Each door shall have two self-closing, cam-
lift style hinges. Doors shall be easily removable without
use of tools. Door gaskets shall be magnetic snap-in
style to allow simple replacement. Door handles shall be
recessed.
• Please specify right or left hand hinging at time of
order.
Mechanical controls shall be located behind a removable
shroud facing.
Refrigeration: Refrigeration system shall use R404A
refrigerant. System shall be completely outside food zone
to maximize internal storage space. System shall utilize
a dual diversion high ow air distribution system, and
shall be a high capacity design. Evaporator coils shall be
coated to prevent corrosion. Cabinet shall maintain 340F
to 400F (10C to 40C) internal temperature.
Single Voltage Models Only: Electrical connections
shall be 115 volt, 60 hertz, single phase, with an
eight ft. (2.4m) long electrical cord & plug as shown
on reference chart. Cord & plug shall be wired to the
junction box on top of the unit.
Dual Voltage Models Only: Electrical connections
shall be 115/208-230 volt, 60 hertz, single phase,
and must be hard-wired to the junction box located on
top of the unit.
MODELS:
 MRR1S-S Single section  MRR2S-S Two section
Full height door Full height doors
 MRR1SR-S Remote  MRR2SR-S Remote
 MRR1S-SH Single section  MRR2S-SH Two section
Half height door Half height doors
 MRR1SR-SH Remote  MRR2SR-SH Remote
STANDARD FEATURES
• Shroud removes without tools, for easy condenser
maintenance
• Built in door locks
• Durable stainless steel doors and shroud, for lasting good
looks
• New high-density foam insulation cuts energy costs
• Big, easy grip handles are easy to nd, don’t intrude into
kitchen trafc
• Attractive aluminum side panels are easy to clean and
corrosion resistant
• Heavy-duty hinges with stay open feature
• Refrigeration system is located outside the food zone, more
space for product storage
• Mini watt door heaters eliminate condensation with
minimal energy cost
• Easy to read dial thermometer
• Tri seal door gaskets lower energy costs with a unique
insulating design
• Epoxy coated shelves—corrosion resistant, 300-lb.
capacity. Flexible placement on 1” centers allows
maximum storage
• Aluminum interior stands up to food acids without
corroding
• Lots of interior storage space for the money
• Rugged metal legs, adjustable to compensate for
uneven oors
OPTIONS AND ACCESSORIES
 Stainless steel exterior sides
 Stainless steel interior
 Stainless steel kick plate
 Door and end laminate
 Stainless steel exterior back
 Digital thermometer
 TXV
 Chrome Shelves
 Tray Slides
 220/50/1 electrical
 Electronic control
 Stainless steel legs
 Casters

Meridian Series® Solid Door Shallow Reach-In Refrigerators
Model #__________
CSI Section 11400
Printed in the USA.
08/03
DSMRS_R
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.deleld.com
Phone: [phone]
Fax: [phone]
Email: info@deleld.com
MECHANICAL DATA
SHELVES NO UNIT BTU/HR CAB BTU/HR SHIP NEMA
MODEL VOLTAGE AMPS STORAGE SQ. FT. SHELVES H.P. LOAD SYSTEM CAP WEIGHT PLUG
REFRIGERATORS
MRR1S-S 115 8.5 18.25 8.98 3 1/4 674 2015 358 5-15P
MRR1S-SH 115 8.5 18.25 8.98 3 1/4 674 2015 358 5-15P
MRR2S-S 115 10.8 37.96 19.04 6 1/3 1263 2522 562 5-15P
MRR2S-SH 115 10.8 37.96 19.04 6 1/3 1263 2522 562 5-15P
PLAN VIEW MRR1S-S PLAN VIEW MRR2S-S
ELEVATION VIEW MRR2S-S
ELEVATION VIEW MRR1S-S
DOOR CLEARANCE DETAIL
29”
73.7cm 56”
142.2cm
81”
205.6cm
27.25”
69.2cm
26”
66.0cm 26”
66.0cm
END SECTION VIEW
ALL MODELS
PERSPECTIVE VIEW
ALL MODELS
56.76”
144.2cm
12.14”
30.8cm
16.02”
40.7cm
19.75”
50.2cm
\
23.75”
60.3cm
3.80”
9.65cm
26.48”
67.25cm
26.0”
73.7cm
58”
147.3cm
25”
63.5cm 52”
132cm
6.00
15.2cm
REMOTE SHELVES NO UNIT BTU/HR CAB BTU/HR SHIP NEMA
MODEL # VOLTAGE AMPS STORAGE SQ. FT. SHELVES H.P.* LOAD SYSTEM CAP WEIGHT PLUG
REFRIGERATORS
MRR1SR-S 115 3.0 18.25 8.98 3 1/4 674 — 358 —
MRR1SR-SH 115 3.2 18.25 8.98 3 1/4 674 — 358 —
MRR2SR-S 115 4.0 37.96 19.04 6 1/3 1263 — 562 —
MRR2SR-SH 115 4.2 37.96 19.04 6 1/3 1263 — 562 —
Remote units supplied with: Evaporator coil, solenoid valve, expansion valve and temperature control. Condensing units to be sized and supplied with others.
*Recommended
J-BOX LOCATED
75" AFF FOR ST'D BOXES
83" AFF FOR RI/RT'S
8" (1) door units
11" (2&3) door units
6" (1) door units
23" (2) door units
39" (3) door units
Front of unit
MECHANICAL DETAIL
