Drop-In Self-Contained Electric Hot & Cold Pans
Model N8645
pans by others
19.87"
50.5cm
24.5"
62.23cm
26"
65.71cm
A
A – 1.37"
A – 3.48cm
A – 6"
A – 15.2cm
C
L
8"/20.3cm
B
NOTE: NOT TO SCALE
NOTE: NOT TO SCALE
8"
20.3cm
11"
27.9cm
19.18"
48.7cm
11.25"
28.6cm
NOTE: NOT TO SCALE
DRAIN IS 8.00"/20.3 cm FROM END OF BODY;
POSITION RELATIVE TO CENTER LINE
VARIES WITH LENGTH OF MODEL
16.37"
41.6cm
CONTROL PANEL
CUTOUT DIMENSIONS:
4.25" x 12.25"
(10.8cm x 31.1cm)
PLAN VIEW
8600 MODELS
ELEVATION VIEW
8600 MODELS
RIGHT END VIEW
8600 MODELS
Mechanical Data–Standard Unit
MODEL COUNTER CUTOUT VOLTS/HERTZ/ SHIP
NUMBER A B DIMENSIONS PHASE H.P. AMPS WEIGHT
N8631
31.75” (80.6cm) 5.91” (15cm) 30.75” X 25” (78.10cm x 63.5cm) 115/60/1 1/5 17.0 179 lbs/ 81 kg
N8645
45.62” (115.9cm) 12.84” (32.6cm) 44.62” x 25” (113.36cm x 63.5cm) 120/208/230 1/5 17.0 212 lbs/ 95 kg
N8659
59.5” (151.1cm) 19.78” (50.2cm) 58.5” x 25” (148.6cm x 63.5cm) 120/208/230 1/4 22.0 252 lbs/ 113 kg
N8673
73.37” (186.4cm) 26.71” (67.8cm) 72.38” x 25” (183.84cm x 63.5cm) 120/208/230 1/4 28.0 266 lbs/ 102 kg
N8687
87.25 (221.6cm) 33.65” (85.5cm) 86.25” x 25” (219.07cm x 63.5cm) 120/208/230 1/3 33.0 303 lbs/ 136 kg
Short Form Specifications
Top and well are one-piece 18-gauge stainless steel. Top has .68”
(4.26cm) overhang around perimeter. Well is 8” (20.3cm) deep and
creased to a 1” (2.5cm) diameter drain. Unit is provided with adapter
bars to allow placement of 12” 20 (30.5cm x 50.8cm) pans. Sides
are wrapped with refrigeration lines and insulated with 1” (2.5cm) of
blanket insulation. Exterior housing is 20-gauge galvanized steel.
Condensing unit is suspended below the well on a 16-gauge steel
frame. Condensing unit uses HFC-134a refrigerant. Unit has a single
temperature control and a three-way toggle switch provided in a control
panel for mounting in a counter or at a remote location. Unit has a
three-wire electrical junction box mounted to the underside of the unit.
Unit must be hard-wired at installation. Unit has one stainless steel
louver provided for field installation; cutout dimensions for louvers is
12” x 23.5” (30.5cm x 59.7cm)
Optional Accessories and Modifications
• Adapter plates and bars
• Single or double service flip-up sneezeguards
• Relocate compressor
• Telescoping cover
• *220V/50 cycle electrical system
* Inclusion of this option will alter electrical specifications of the
unit.
NOTE: Drain is located on left if facing service side.
PROJECT _____________________________________
ITEM NUMBER_________________________________
QUANTITY _______________ DATE________________
APPROVAL____________________________________
N8600
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • (800) 733-8821 • Fax (800) 669-0619 • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2003 The Delfield Company. All rights reserved. Printed in U.S.A.
DS82_8600 04/03
