MERIDIAN SERIES®SOLID/GLASS DOOR ROLL-THROUGH REFRIGERATORS
Project __________________________
Item____________________________
Quantity _________________________
CSI Section 11400
MERIDIAN SERIES®
Solid/Glass Door Roll-Through Refrigerators
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: [phone]
Fax: [phone]
Email: info@delfield.com
Approval _________________
Date____________________
MRRT2-GS
SPECIFICATIONS
Exterior: Cabinet front and shroud shall be 22-gauge
stainless steel. Exterior sides shall be aluminum. Facing
of shroud shall be easily removable without the use of
tools.
Cabinet interior shall be anodized aluminum. Bottom
& top of liner shall be die-stamped to provide
radius corners and a recessed bottom. Base shall be
fully insulated with high-density foamed in place
polyurethane.
Doors: Unit is provided with hinged glass front
door(s) on one side. Doors on refrigerated units are
constructed with double-pane tempered thermopane
glass. Glass doors are constructed with a combination
of extruded aluminum & PVC, and are provided with
magnetic gaskets. Doors will have self-closing hinges
and continuous handle along vertical dimension of
door(s). Glass door constructed to eliminate need
for heater wires. Solid doors shall have a 22-gauge
stainless steel exterior & anodized aluminum interior
liner. Doors shall be fully insulated with high density
foamed in place polyurethane. Each door shall have
two self-closing, cam-lift style hinges. Doors shall be easily
removable without use of tools. Door gaskets shall be
magnetic snap-in style to allow simple replacement. Door
handles shall be recessed.
• Please specify right or left hand hinging at time of order.
Mechanical controls shall be located behind a removable
shroud facing.
Refrigerators: All components are mounted to the
exterior cabinet ceiling, outside the food zone and are
assembled as one piece and can be removed as one piece.
Environmentally friendly R404A refrigerant is used.
System has the capability of maintaining between 27˚F and
40˚F in heavy use food service operations. Refrigerant is
metered using a highly responsive thermostatic expansion
valve. System is controlled using Delfield’s ACT-Advanced
Control Technology electronic temperature control, which
provides improved pull down times, reducing compressor
cycling and longer compressor life with lower energy
consumption.
Control system uses adaptive defrost to assure evaporator
coil is free of ice and operating at optimum efficiency.
Evaporator condensate is eliminated using an energy
efficient hot gas system.
Single Voltage Models Only: Electrical connections
shall be 115 volt, 60 hertz, single phase, with a ten foot
(3m) long electrical cord & plug as shown on reference
chart. Cord & plug shall be wired to the junction box on
top of the unit.
Dual Voltage Models Only: Electrical connections
shall be 115/208-230 volt, 60 hertz, single phase, and
must be hard-wired to the junction box located on top
of the unit.
Notes: Bottom to be reinforced with 14-gauge
channels. All units to be supplied with easily attachable
16-gauge stainless steel ramps, one per door opening.
Wiper gasket shall be provided on bottom of door for
seal to ramp.
MODELS:
 MRRT1-GS Single section  MRRT2-GS Two section  MRRT3-GS Three section
Solid full height door (one side) Solid full height door (one side) Solid full height door (one side)
Glass full height door (one side) Glass full height door (one side) Glass full height door (one side)
STANDARD FEATURES
• Shroud removes without tools, for easy condenser
maintenance
• Built in door locks
• Durable stainless steel doors and shroud, for lasting good
looks
• New high-density foam insulation cuts energy costs
• Big, easy grip handles are easy to find, don’t intrude into
kitchen traffic
• Attractive aluminum side panels are easy to clean and
corrosion resistant
• Heavy-duty hinges with stay open feature
• Refrigeration system is located outside the food zone, more
space for product storage
• Mini watt door heaters eliminate condensation with minimal
energy cost
• Exterior digital thermometer with high/low temperature
alarm
• Tri seal door gaskets lower energy costs with a unique
insulating design
• Aluminum interior stands up to food acids without corroding
• Lots of interior storage space for the money
OPTIONS AND ACCESSORIES
 Stainless steel exterior sides
 Stainless steel interior
 Door and end laminate
 Digital thermometer
 TXV
 220/50/1 electrical
 Electronic control

Meridian Series®Solid/Glass Door Roll-Through Refrigerators
Model #__________
CSI Section 11400
Printed in the USA.
03/07
DSMRTGS
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: [phone]
Fax: [phone]
Email: info@delfield.com
MECHANICAL DATA
CU. FT. SHELVES # of RACK UNIT BTU/HR SHIP NEMA
MODEL VOLTAGE AMPS STORAGE SQ. FT. SHELVES CAP. H.P. SYSTEM CAP WEIGHT PLUG
REFRIGERATORS
MRRT1-GS 115 7.0 38.58 NA NA 1 1/2 2488 469 5-15P
MRRT2-GS 115/208-230 10.1 79.74 NA NA 2 3/4 6920 686 —
MRRT3-GS 115/208-230 11.3 120.90 NA NA 3 3/4 7569 1081 —
PLAN VIEW MRRT1-GS PLAN VIEW MRRT2-GS PLAN VIEW MRRT3-GS
36.25”
93.4cm
34”
86.6cm
36.25”
93.4cm
66”
167.6cm
36.25
93.4cm
98”
248.9cm
ELEVATION VIEW MRRT3-GS
ELEVATION VIEW MRRT2-GSELEVATION VIEW MRRT1-GS
DOOR CLEARANCE DETAIL
ALL MODELS
32.25”
81.9cm
END/SECTION VIEW
ALL MODELS
89”
226.1cm
89”
226.1cm
12.14”
30.8cm
43.58”
110.7cm
73.28”
186.1cm
36.25”
92.1cm
70.75”
179.1cm
28.2”
71.6cm
PERSPECTIVE VIEW
ALL MODELS
29.12”
73.96cm
Ramp Width
3.80”
9.65cm
29.75”
75.56cm
MECHANICAL DETAIL
Ramp dimensions
see below
5.92”
15.04cm
1.06”
2.69cm
RAMP DIMENSIONS
(Not to scale)
