Deli G230LR-015 User manual

G230LR-015(3898) G330LR-016(3899)
G230LR-017(33022) G330LR-018(33023)

50 125

电源指示灯
电源线
进/退膜开关
护卡膜进膜口 工作指示灯
进膜
退膜
进膜
退膜
电源/功能开关
0
冷裱 关 热裱

开机
热裱
冷裱
退膜
关机
塑封操作说明
在热裱状态

绿灯已损坏
机器内加热装置已烧坏
此时须联系售后服务中心或专业电工解决
此时须联系售后服务中心或专业电工解决
机器温度过低或护卡膜厚
度超出最大范围
开机时间过久，导致温度
偏高
护卡膜厚度超出规定范围
机器再加热2-3分钟后过膜；
更换护卡膜（厚度在要求的范围内）
工作

cause
result
o

0
Cold Hot
Off
in a tilted position
The size of originals swaller than film
抰originals can
working ON/OFF Switch
insert

Turn on
Hot
laminating
Cool
laminating
Turn off
Connect the power plug
Open the back guide plate which is also the way to power
on(the power switch hidden inside turns on automatically).
If hot plastic cement is needed, adopt hot laminating film(50-125mic).
Turn the temperature adjusting knob to the position of hot laminating,the power indicator will on in red
After about 7mins’ for preheating the green heating indicator lightens
and stops flashing, indicating that it finishes preheating and is
ready for laminating.
After hot laminatingTurn the temperature adjusting knob to the position of the
cool laminating after cooling 5 to 10 mins,then close the back
guide plate,pull off the plug. if after cool laminating can close the back guide and pull off the plug directly.
If cool laminating is needed, adopt cool laminating film.
Turn the temperature adjusing knob to the position of
the cool laminating and begin to laminating directly.
If cool laminating is needed after the hot laminating for aperiod
of time,Turn the temperature adjusting knod to the position
of the cool laminating arrowhead and begin to laminate
only after the machine running without laminating object for 10min.
.
Rejceting
film
kfil
Do not
When laminated objects are rolled into the machine ,or if the objects is tilted, or if you need to remove the objects from the machine,
pls press the eject button, the inversion lock will pop up automatically, the machine is in inverse mode, you can start removing the
object. When pressing the inversion lock, the back button will pop up automatically ,and the machine is in forward mode.

5% more or less of the deseribed date allowed.
Max lamination width
Max lamination thickness

Power switch is off. Switch on the power
Green light has been damaged
Heating device inside the
machine is burnt.
Contact after-sales service center or
professional electrician for the solution.
Contact after-sales service center or
professional electrician for the solution.
Machine temperate is too high ,
caused by long time of warm up.
Or the thickness of the laminating
film is lower than the minimum
rated film thickness.
Machine temperate is too low,
or the thickness of the laminating
film is out of the maximum rated
film thickness.
Laminator should be warmed up for 2-3mins
more then laminating, again changing
the film thickness to the right film(consistent
with the rated film thickness.)
Should test with wasted film or paper first ,
than you can go ahead with normal
laminating.Change the film with suitable
thickness consistent with the rated film
thickness.
operation
s r
work
