Dell OptiPlex 330 User manual

DELL
™
optipLEx™330
tEchnicaL guiDEbook
insiDE thE optipLEx 330
VERSION 1.0

ovErviEw 3
Mini Tower Computer (MT) View 5
Desktop Computer (DT) View 6
MarkEting systEM configurations
Operating System, Chipset 7
Processor 8
Advanced System Manageability Modes, Deployment Mode Options 8
Memory 9
Drives and Removable Storage 10
System Board Connectors, Graphics/Video Controller 11
External Ports/Connectors 12
Communications – Network Adapter (NIC) 12
Communications – Modem 12
Audio and Speakers, Keyboard and Mouse, Security 13
Service and Support, Software 14
DEtaiLED EnginEEring spEcifications
System Dimensions (Physical) 15
System Board Connector Maximum Allowable Dimensions 15
System Level Environmental and Operating Conditions 16
Power 16
Audio 17
Communications – Network Adapter (NIC) 18
Graphics/Video Controller 20
Hard Drives 23
Optical Drives 27
BIOS Defaults 31
chassis EncLosurE anD vEntiLation rEquirEMEnts 32
rEguLatory coMpLiancE anD EnvironMEntaL
Acoustic Noise Emission Information 33
TABLE OF CONTENTS

VERSION 1.0 3
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
3
DELL
™optipLEx™330
The Dell OptiPlex 330 raises the bar in the entry-level desktop category by providing advanced features to suit
the needs of growing businesses. Configuration options include two form factor choices, blazing-fast Intel Core™
2 Duo processors, an optional energy-ecient 80PLUS®power supply, and RAID 1 support. The OptiPlex 330 delivers
essential networking capabilities and enhanced performance. Simplify desktop computing with the OptiPlex 330.
powEr EfficiEncy
Productivity and power savings in a proven, reliable design. Dell Energy Smart is a unique
approach to energy-ecient computing which includes hardware and software, tools,
and partnerships.
•Dell factory-enabled Energy Smart software settings put your system into a low-energy sleep state after 15
minutes of inactivity. Remote power policy management software delivers even greater energy savings
• Ecient hardware includes Intel Core™ 2 Duo, 80PLUS®power supplies, ENERGY STAR®4.0 and EPEAT™
Gold configurations
• Ecient Dell BTX design and HyperCool™ thermal-management technology help save energy and boost reliability
• Dell’s online Energy Calculator is a unique tool which allows you to compare systems, features, and usage models
to optimize energy savings across Dell commercial client products
• Dell is working alongside industry leaders and standards organizations worldwide to help drive revolutionary change
sMart sEcurity
Strategic, comprehensive endpoint solutions for all types of businesses.
• Simple deterrents such as physical locks help prevent theft
• RAID 1 support helps keep data intact and accessible via real-time redundancy
• CompuTrace® tracking capability incorporated into the BIOS can help reduce data loss from theft

VERSION 1.0 4
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
4
SIMPLY PUT: DELL
™OPTIPLEX™330
Easy to ManagE.
EfficiEnt to own.
EssEntiaL rEMotE ManagEMEnt
Run your IT better and have greater control with flexible hardware options and management
software. Dell Client Manager brings it all together in one management console, available as a
free download. Built-in, standards-based management helps ensure simplicity and interoperability.
• Widely installed ASF (Alert Standard Format) standards-based technology, which supports basic in- and out-of-band
hardware inventory, alerting, and power control
• Dell Client Manager Standard, available at no cost, integrates all components of Dell™ OpenManage™ into a single
remote console
DELL DEpLoyMEnt sErvicEs
Get IT Faster with custom image management, in-factory configuration, and deployment made
simple. Dell's direct, steppingstone approach to customization helps ensure the best fit for
your needs.
• Dell ImageDirect allows you to dynamically create, manage, and load your custom images to Dell client systems
• Advanced Conguration Services enable easy customization, at the point of sale
• Microsoft® Windows Vista® Assessment and Migration options help streamline and optimize your deployment processes

VERSION 1.0 5
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
55
Mini towEr coMputEr (Mt) viEw
SYSTEM BOARD COMPONENTS
1speaker connector (INT_SPKR)
2processor connector (CPU)
3processor power connector (12VPOWER)
4memory module connectors (DIMM_1, DIMM_2)
5SATA drive connectors (SATA0, SATA1)
6front-panel connector (FRONTPANEL)
7power connector (POWER)
8SATA drive connectors (SATA2, SATA3)
9RTC reset jumper (RTCRST)
10 password jumper (PSWD)
11 battery socket (BATTERY)
12 PCI Express x16 card connector (SLOT1)
13 PCI card connectors (SLOT2 and SLOT3)
14 internal buzzer (SPKR)
15 serial/PS/2 connector (PS2/SER2)
16 fan connector (FAN_CPU)
17 oppy drive connector (FLOPPY)
FRONT VIEW
1service tag
2optical drive
3floppy drive
4drive activity light
5USB 2.0 connectors (2)
6diagnostic lights
7power button
8headphone connector
9microphone connector
10 LAN indicator light
BACK VIEW
1cover-release latch
2padlock ring
3power connector
4voltage selector switch
5back panel connectors
6card slots
1
2
3
4
9
5
7
8
10
6
6
1
2
43
5
12
13
14
15
11
10
1
2
3
4
5
76
8
9
13
16 17

VERSION 1.0 6
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
6
DEsktop coMputEr (Dt) viEw
FRONT VIEW
1USB 2.0 connectors (2) 7LAN indicator light
2drive activity light 8headphone and microphone
connectors
3power button 9floppy drive
4Dell badge 10 optical drive
5power light 11 service tag
6diagnostic lights
BACK VIEW
1card slots
2back panel connectors
3power connector
4voltage selection switch
5padlock ring
6cover-release latch
2
11
10
13
4
5
7
8
6
92356
4
1
1
8
11
10
12
13
15
5
9
2
4
6
7
3
14
13
16
17
SYSTEM BOARD COMPONENTS
1speaker connector (INT_SPKR)
2processor connector (CPU)
3processor power connector (12VPOWER)
4memory module connectors (DIMM_1, DIMM_2)
5SATA drive connectors (SATA0, SATA1)
6front-panel connector (FRONTPANEL)
7power connector (POWER)
8SATA drive connectors (SATA2, SATA3)
9RTC reset jumper (RTCRST)
10 password jumper (PSWD)
11 battery socket (BATTERY)
12 PCI Express x16 card connector (SLOT1)
13 PCI card connectors (SLOT2 and SLOT3)
14 internal buzzer (SPKR)
15 serial/PS/2 connector (PS2/SER2)
16 fan connector (FAN_CPU)
17 oppy drive connector (FLOPPY)

VERSION 1.0 7
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
7
MT DT
Windows VistaOperating System Windows Vista® Ultimate, Windows Vista® Business,
Windows Vista® Home Basic
Windows XPOperating System Windows® XP Professional, Windows® XP Home Edition
Other FreeDOS (for n-series), Red Flag Linux (China only)
OS Media Support ✓ ✓
MarkEting systEM configurations
Oerings may vary by region. For more information regarding the configuration of your computer, click "Start Help"
and "Support" and select the option to view information about your computer.
opErating systEM
One of the following Operating Systems will be preinstalled.
chipsEt
7
MT DT
Chipset Intel® G31 Express Chipset (ICH7R)
Non-volatile Memory on Chipset
BIOS Conguration FWH (rmware hub) 8 MB located at SP1_FLASH on chipset
TPM 1.2 Security Device (Trusted Platform Module)
NIC EEPROM 1 MB located at LOM_FLASH on chipset

VERSION 1.0 8
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
8
procEssor
Processor numbers are not a measure of performance.
PROCESSOR (SPEED, CACHE, FSB) MT DT
IntelCore™2 Duo with Intel, Enhanced Intel SpeedStep Technology, and Execute Disable Bit
Intel Core 2 Duo E7200 Processor (2.53GHz, 3MB L2 cache, 1066MHz FSB) ✓ ✓
Intel Core 2 Duo E6850 Processor (3.0 GHz, 4 MB L2 cache, 1333 MHz FSB) ✓ ✓
Intel Core 2 Duo E6750 Processor (2.66 GHz, 4 MB L2 cache, 1333 MHz FSB) ✓ ✓
Intel Core 2 Duo E6550 Processor (2.33 GHz, 4 MB L2 cache, 1333 MHz FSB) ✓ ✓
Intel Core 2 Duo E4700 Processor (2.6 GHz, 2 MB L2 cache, 800 MHz FSB) ✓ ✓
Intel Core 2 Duo E4600 Processor (2.4 GHz, 2 MB L2 cache, 800 MHz FSB) ✓ ✓
Intel Core 2 Duo E4500 Processor (2.2 GHz, 2 MB L2 cache, 800 MHz FSB) ✓ ✓
Intel Core 2 Duo E2220 Processor (2.4Hz, 1MB L2 cache, 800MHz FSB) ✓ ✓
Intel Core 2 Duo E2200 Processor (1.8GHz, 1MB L2 cache, 800MHz FSB) ✓ ✓
Intel Core 2 Duo E2180 Processor (2.0 GHz, 1 MB L2 cache, 800 MHz FSB) ✓ ✓
Intel Core 2 Duo E2160 Processor (1.8 GHz, 1 MB L2 cache, 800 MHz FSB) ✓ ✓
IntelCeleronwith Execute Disable Bit
Intel Celeron 440 Processor (2.0 GHz, 512 K L2 cache, 800 MHz FSB) ✓ ✓
Intel Celeron 430 Processor (1.8 GHz, 512 K L2 cache, 800 MHz FSB) ✓ ✓
Intel Celeron 420 Processor (1.6 GHz, 512 K L2 cache, 800 MHz FSB) ✓ ✓
aDvancED systEM ManagEabiLity MoDEs
MT DT
Basic Client Systems Management (w/ ASF) ✓ ✓

VERSION 1.0 9
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
9
MEMory
Your computer supports a maximum of 4 GB of memory when you use two 2 GB DIMMs.
Memory modules should be installed in pairs of matched memory size, speed, and technology. If the memory modules
are not installed in matched pairs, the computer will continue to operate, but with a slight reduction in performance.
MT DT
Type: DDR2 Synch DRAM Non-ECC Memory 667 MHz or 800 MHz speeds
DIMM Slots 2 2
DIMM Capacities Up to 2 GB Up to 2 GB
Minimum Memory 512 MB 512 MB
Maximum Memory with 667 MHz Speed Memory 2 GB 2 GB
Maximum Memory with 800 MHz Speed Memory 4 GB14 GB1
Configurations:
800 MHz Memory Configurations
4 GB DDR2 Non-ECC SDRAM, 800 MHz (2 DIMM) ✓ ✓
2 GB DDR2 Non-ECC SDRAM, 800 MHz (1 DIMM) ✓ ✓
2 GB DDR2 Non-ECC SDRAM, 800 MHz (2 DIMM) ✓ ✓
1 GB DDR2 Non-ECC SDRAM, 800 MHz (1 DIMM) ✓ ✓
667 MHz Memory Configurations
2 GB DDR2 Non-ECC SDRAM, 667 MHz (2 DIMM) ✓ ✓
2 GB DDR2 Non-ECC SDRAM, 667 MHz (1 DIMM) ✓ ✓
1 GB DDR2 Non-ECC SDRAM, 667 MHz (2 DIMM) ✓ ✓
1 GB DDR2 Non-ECC SDRAM, 667 MHz (1 DIMM) ✓ ✓
512 MB DDR2 Non-ECC SDRAM, 667 MHz (1 DIMM) ✓ ✓
1The total amount of available memory will be less, depending on actual system configuration.

VERSION 1.0 10
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
10
DrivEs anD rEMovabLE storagE
MT DT
Bays:
3.5-inch Bay (External Floppy) 1 1
5.25-inch Bay (External Optical) 2 1
Hard Drives Supported (Internal) 2
1 (Normal)
2 (Second HDD support,
mutually exclusive with oppy)
Optical Drives Supported (External) 2 1
Interface:
SATA (number of connectors) 4 4
Floppy/Diskette 1 1
Hard Drive: size, type, speed, RPM
80 GB SATA 10 K RPM HDD2✓ ✓
250 GB SATA 7200 RPM HDD2✓ ✓
160 GB SATA 7200 RPM HDD2✓ ✓
80 GB SATA 7200 RPM HDD2✓ ✓
RAID 1 Data Protection: (includes two matching capacity/speed hard drives)
80 GB SATA 10 K RPM HDD2✓ ✓
250 GB SATA 7200 RPM HDD2✓ ✓
160 GB SATA 7200 RPM HDD2✓ ✓
80 GB SATA 7200 RPM HDD2✓ ✓
Optical Drive:
DVD +/- RW 16x SATA 16x SATA
DVD-ROM 16x SATA 16x SATA
Combo Drive CD-RW 48x/32x/16x SATA 48x/32x/16x SATA
CD-ROM 48x SATA 48x SATA
Floppy Diskette Drive: (SFF requires a slimline floppy drive)
Floppy Drive 1.44 MB 1.44 MB
2 For hard drives, GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and will be less.

VERSION 1.0 11
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
11
systEM boarD connEctors
See Detailed Engineering Specifications for maximum card dimensions support.
MT DT
PCI Slot(s): 2 2
PCIe x16 Slot: 1 1
PCIe x1 Slot:
Serial ATA (SATA) 4 4
Serial 1 1
graphics/viDEo controLLEr
MT supports full height card, DT supports low prole card.
MT DT
Integrated IntelGraphics Media Accelerator 31003Integrated on system board
Enhanced Graphic/Video Options
DVI (Digital) Adapter Card Optional full height or
low profile card Optional low profile card
128 MB ATI Radeon™ X13003 with DVI and TV Out Optional full height or
low profile card Optional low profile card
256 MB ATI Radeon™ HD 2400 PRO3 with DVI and TV Out Optional full height or
low profile card Optional low profile card
256 MB ATI Radeon™ HD 2400 XT Dual Monitor3with
VGA cable and TV Out
Optional full height or
low profile card Optional low profile card
256 MB ATI Radeon™ HD 2400 XT Dual Monitor3with
DVI and VGA cables and TV Out
Optional full height or
low profile card Optional low profile card
3Significant memory may be used to support graphics, depending on system memory size and other factors.

VERSION 1.0 12
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
12
ExtErnaL ports/connEctors
MT supports full height card, DT supports low prole card.
See chassis diagrams section for port/connector locations. MT DT
USB 2.0 8
Serial One rear
PS/2 and Serial (low profile card includes PS/2 dongle) Optional full height or low profile card
Parallel One rear
Network Connector (RJ-45) One rear
1394 Controller Optional full height card Optional low profile card
Video:
VGA One rear
DVI Optional (DVI adapter card)
Audio:
Microphone-in One minijack front
Headphone One minijack front
Stereo Line-in One minijack rear
Speakers Line-out One minijack rear
coMMunications – nEtwork aDaptEr (nic)
MT DT
Broadcom (BCM5787) Gigabit LAN 10/100/1000
(WOL, PXE, and ASF2.0) Integrated on system board
coMMunications – MoDEM
MT supports full height card, DT supports low prole card.
MT DT
V.92 Data/Fax Controllerless Modem Integrated on system board

VERSION 1.0 13
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
13
auDio anD spEakErs
MT DT
ADI 1984 High Definition Audio Integrated on system board
Internal Chassis Speaker Optional
Dell A225 Speakers Optional
Dell A525 Speakers Optional
Dell AS501 Flat Panel Speakers (Sound Bar) Optional
Dell AS501PA Flat Panel Speakers (Sound Bar) Optional
kEyboarD anD MousE
MT DT
Dell USB Entry QuietKey Keyboard Optional
Dell USB Enhanced Multimedia Keyboard Optional
Dell Smart Card USB Keyboard Optional
Dell Bluetooth Keyboard and Mouse Optional
Dell USB Entry 2 Button Scroll Mouse Optional
Dell USB Optical 2 Button Scroll Mouse Optional
Dell USB Premium 5 Button Mouse Optional
Dell Palmrest Optional
Dell Logo Mouse Pad Optional
sEcurity
MT DT
Trusted Platform Module (TPM) 1.2
Chassis Intrusion Switch
Dell USB External Biometric Fingerprint Reader
Chassis Lock Slot Standard

VERSION 1.0 14
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
14
sErvicE anD support
For more details on Dell Service Plans please to go to www.dell.com/service/service_plans/
softwarE
MT DT
3-Year Limited Warranty4(3-3-0) Standard
3-Year Next Business Day On-site5Warranty (3-3-3) Optional
Gold Tech Support Optional
MT DT
Dell Client Manager Standard Available via Dell.com
Norton Internet Security™ 90-Day trial or optional subscription
4 For a copy of limited warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX 78682 or visit www.dell.com/warranty
5 May be provided by third party. Technician dispatched, if necessary, following phone-based troubleshooting. Availability varies. See dell.com/servicecontracts
for details.

VERSION 1.0 15
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
15
DEtaiLED EnginEEring spEcifications
systEM DiMEnsions (physicaL)
System Weight6 and Shipping Weight7is based on a typical configuration and may vary based on PC configuration.
A typical conguration includes: integrated graphics, one hard drive, one optical drive, and one diskette drive.
MT DT
Chassis Volume l i t e r s 33 16
Chassis Weight6p o u n d s /k i l o g r a m s 27.2 lbs; 12.34 kg 23 lbs; 10.4 kg
Chassis Dimensions: (HxWxD)
Height i n c h e s /c e n t i m e t e r s 16.3"; 41.4 cm 4.5"; 11.4 cm
Width i n c h e s /c e n t i m e t e r s 7.3"; 18.5 cm 15.7"; 39.9 cm
Depth i n c h e s /c e n t i m e t e r s 17.3"; 43.9 cm 13.9"; 35.3 cm
Shipping Weight7p o u n d s /k i l o g r a m s
(includes packaging materials) 19.73 kg 12.7 kg
Packaging Parameters (HxWxD)
Height i n c h e s /c e n t i m e t e r s 22.38"; 56.8 cm 20.63"; 52.4 cm
Width i n c h e s /c e n t i m e t e r s 22.25"; 56.5 cm 20.31"; 51.6 cm
Depth i n c h e s /c e n t i m e t e r s 14.25"; 36.2 cm 11.75"; 29.8 cm
systEM boarD connEctor MaxiMuM aLLowabLE DiMEnsions
MT DT
PCI Slot(s) Dimensions: (HxL) 2 2
Height i n c h e s /c e n t i m e t e r s 4.376"; 11.115 cm 2.731"; 6.89 cm
Length i n c h e s /c e n t i m e t e r s 6.6"; 16.765 cm 6.6"; 16.765 cm
PCIe x16 Slot Dimensions: (HxL) 1 1
Height i n c h e s /c e n t i m e t e r s 4.376"; 11.115 cm 2.731"; 6.89 cm
Length i n c h e s /c e n t i m e t e r s 6.6"; 16.765 cm 6.6"; 16.765 cm
6 Weights are approximates and may change based on system conguration and included accessories.
7 Dimensions are region specic. Each region may have unique packing.

VERSION 1.0 16
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
16
systEM LEvEL EnvironMEntaL anD opErating conDitions
MT DT
Temperature
Operating 10°– 35°C (50°– 95°F) 10°– 35°C (50°– 95°F)
Non-Operating -40°– 65°C (–40°– 149°F) -40°– 65°C (–40°– 149°F)
Relative Humidity 20% – 80%
(non-condensing)
20% – 80%
(non-condensing)
Maximum Vibration
Operating 5 to 350 Hz at
0.0002 G2/Hz
0.25 G at 3 to 200 Hz
at 0.5 octave/min
Non-Operating 5 to 500 Hz at 0.001
to 0.01 G2/Hz
0.5 G at 3 to 200 Hz
at 1 octave/min
Maximum Shock
Operating
40 G +/- 5% with pulse
duration of 2 msec +/- 10%
(equivalent to 51 cm/sec
[20 in/sec])
40 G +/- 5% with pulse
duration of 2 msec +/- 10%
(equivalent to 51 cm/sec
[20 in/sec])
Non-Operating
105 G +/- 5% with pulse
duration of 2 msec +/- 10%
(equivalent to 127 cm/sec
[50 in/sec])
105 G +/- 5% with pulse
duration of 2 msec +/- 10%
(equivalent to 127 cm/sec
[50 in/sec])
Maximum Altitude
Operating –15.2 to 3,048 m
(–50 to 10,000 ft)
–15.2 to 3,048 m
(–50 to 10,000 ft)
Non-Operating –15.2 to 10,668 m
(–50 to 35,000 ft)
–15.2 to 10,668 m
(–50 to 35,000 ft)
powEr
MT DT
Power Supply Wattage 305W 280W
AC Input Voltage Range 90~135Vac,180~264Vac (PFC)
90~264Vac(EPA)
90~135Vac,180~264Vac
(PFC) 90~264Vac(EPA)
AC Input Current 9A / 4.5A(PFC), 6.5 /
4.5A(EPA) 6.5 / 4.5A(PFC)
AC Input Frequency 47~63 Hz 47~63 Hz
AC Holdup Time >16 ms >16 ms
Minimum Eciency
(Active PFC, Energy Star® Compliant) 80% 80%
Minimum Eciency (Active PFC)
Minimum Eciency (PFC) 65% 65%

VERSION 1.0 17
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
17
powEr, cont.
MT DT
DC Parameters
+3.3v Output 17A 10A
+5.0v Output 22A 15A
+12.0v Output 18A@12Va, 18A@12Vb 16A
+5.0v Auxiliary Output 4A 4A
-12.0v Output 1A 0.5A
Max Total Power 305W 280W
Max Combined +3.3v / +5.0v Power 150W 108W
Max Combined 12.0v Power
(note: only if more than one 12v rail) 264W
3.3v CMOS Battery
(type and estimated battery life) CR2032, 5 years CR2032, 5 years
RTC Accuracy (time of day) Lead 1 second/day Lead 1 second/day
Power Supply Fan 80 mm 92 mm
Compliance:
Energy Star Compliant power supply option available ✓ ✓
FEMP Executive Order 13221 ✓ ✓
UL Certified ✓ ✓
auDio
INTEGRATED ADI 1984 HIGH DEFINITION AUDIO MT DT
High Definition Stereo Support ✓ ✓
Number of Channels 2 2
Number of Bits / Audio Resolution 16, 20 and 24 16, 20 and 24
Sampling Rate (recording/playback) Up to 192 KHz Up to 192 KHz
Signal to Noise Ratio 96 dB 96 dB
Analog Audio ✓ ✓

VERSION 1.0 18
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
18
auDio, cont.
INTEGRATED ADI 1984 HIGH DEFINITION
AUDIO, CONT. MT DT
Audio Jack Impedance
Microphone 1K~2K ohm 1K~2K ohm
Line-In >10K ohm >10K ohm
Line-Out >10K ohm >10K ohm
Headphone 16~500 ohm 16~500 ohm
Internal Speaker Power Rating +5V +5V
coMMunications – nEtwork aDaptEr (nic)
MT supports full height card, DT supports low prole card.
INTEGRATED BROADCOM 5787 GIGABIT LAN MT DT
Connector Type RJ-45
Data Rates Supported 10 / 100 / 1000 M
Controller Details
Controller Bus Architecture PCIe V1.1 x 1
Integrated Memory Yes (buer memory)
Data Transfer Mode DMA
Power Consumption
(full operation per data rate connection speed) 1298 mW
Power Consumption (standby operation) 340 mW
IEEE Standards Compliance IEEE802.3, IEEE802.3u, IEEE802.3x
Hardware Certifications IEEE
Boot ROM Support ✓
Network Transfer Mode
Network Transfer Rate
10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps

VERSION 1.0 19
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
19
coMMunications – nEtwork aDaptEr (nic), cont.
INTEGRATED BROADCOM 5787 GIGABIT LAN, CONT. MT DT
Environmental
Operating Temperature 0 – 125°C; 32°–257°F
Operating Humidity
Operating System Driver Support Windows® XP (32-bit), Windows Vista® (32-bit)
Manageability WoL, PXE
Management Capabilities Alerting ASF 2.0
coMMunications – MoDEM
MT supports full height card, DT supports low prole card.
V.92 DATA/FAX CONTROLLERLESS MODEM MT DT
Connector RJ-11
Data Transmission PCM - Pulse Coded Modulation (V.92/V.90)
TCM - Trellis Coded Modulation (V.90/V.34/V.32 bis/V.32)
Data Speeds 56 Kbps receive, 48 Kbps transmit
Data Standards ITU V.92/V.90, V.34/V.32 bis/V.32
Fax Speeds 14.4 Kbps
Fax Mode Capabilities 2-wire, half-duplex, synchronous
Error Correction and Data Compression V.44, V.42, V.42bis, MNP 2-4, MNP 5
Power Management WOR (wake on ring) capable
Upgradeability Driver upgradeable
Video V.80 Synchronous Access Mode (SAM) can be supported
by software applications (not driver)
Operating Temperature 0 – 50°C; 32°– 122°F

VERSION 1.0 20
DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE
20
graphics/viDEo controLLEr
MT supports full height card, DT supports low prole card.
INTEGRATED INTEL GRAPHICS MEDIA
ACCELERATOR 3000 MT DT
Bus Type Integrated
GPU Core Clock 350 MHz Integrated 24-bit RAMDAC
Frame Buer Memory (onboard and shared) Size
and Speed Up to 256 MB of shared system memory3
Maximum Power Consumption 9.0 W
Overlay Planes ✓
Maximum Color Depth 32 bit
Maximum Vertical Refresh Rate 85 Hz
Multiple Display Support Yes, with optional DVI add-in card
Operating Systems Graphics/Video API Support OpenGL 2.0/DirectX 9.0C
Supported Resolutions and Max Refresh Rates (Hz)
(Note: Analog and/or digital)
Up to 2048x1566 @ 75 Hz
Supports at panels up to 1920x1200 @ 60 Hz or
digital CRT/HDTV at 1400x1050 @ 85 Hz
External Connectors VGA
Environmental Operating Conditions (Non-Condensing):
Operating Temperature Range 0°–106°C; 32°– 223°F
Relative Humidity Range 20% – 80% (non-condensing)
Altitude Range -15.2 – 3048 m (-50 –10,000 ft)
DVI (DIGITAL) ADAPTER MT DT
Bus Type sDVO
Maximum Supported Resolution
Up to 2048x1566 @ 75 Hz
Supports at panels up to 1920x1200 @ 60 Hz or digital
CRT/HDTV at 1400x1050 @ 85 Hz
Dimensions of Full Height Card : i n c h e s /c e n t i m e t e r s (LxH) 5.75 x 2.75 in / 14.61 x 6.99 cm
Dimensions of Low Profile Card : i n c h e s /c e n t i m e t e r s (LxH) 5.75 x 2.75 in / 14.61 x 6.99 cm
External Connectors DVI
3Significant memory may be used to support graphics, depending on system memory size and other factors.
