Dell P2418HZ User manual

Monitor Model: P2418D
Regulatory Model: P2418Dc
Regulatory Type: P2418Dc 001
Dell P2418D
User’s Guide

Copyright © 2017 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks
are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective
owners.
2017 – 07
Rev. A00
NOTE: A NOTE indicates important information that helps you make
better use of your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss
of data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.

│3
Contents
About your monitor ......................... 6
Package contents . . . . . . . . . . . . . . . . . . . . . . 6
Product features . . . . . . . . . . . . . . . . . . . . . . .8
Identifying parts and controls . . . . . . . . . . . . . . . .9
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Back View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Side View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Bottom View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Monitor specifications . . . . . . . . . . . . . . . . . . . 13
Resolution specifications . . . . . . . . . . . . . . . . . . . . . . 14
Supported video modes . . . . . . . . . . . . . . . . . . . . . . . 14
Preset display modes . . . . . . . . . . . . . . . . . . . . . . . . 15
Electrical specifications. . . . . . . . . . . . . . . . . . . . . . . 16
Physical characteristics. . . . . . . . . . . . . . . . . . . . . . . 17
Environmental characteristics . . . . . . . . . . . . . . . . . . . 18
Power management modes . . . . . . . . . . . . . . . . . . . . . 19
Pin assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Universal serial bus (USB) interface . . . . . . . . . . . 23
Plug and play capability . . . . . . . . . . . . . . . . . . 25
LCD monitor quality and pixel policy . . . . . . . . . . . 25
Maintenance guidelines . . . . . . . . . . . . . . . . . . 25
Cleaning your monitor. . . . . . . . . . . . . . . . . . . . . . . . . . 25
Setting up the monitor..........................26

4 │
Attaching the stand . . . . . . . . . . . . . . . . . . . . . . 26
Connecting your monitor . . . . . . . . . . . . . . . . . . . 28
Organizing cables . . . . . . . . . . . . . . . . . . . . . . . 30
Disconnecting the monitor stand . . . . . . . . . . . . . . . 31
Wall mounting (optional). . . . . . . . . . . . . . . . . . . .32
Operating your monitor .........................33
Power on the monitor . . . . . . . . . . . . . . . . . . . . . 33
Language options . . . . . . . . . . . . . . . . . . . . . . . 33
Using the front panel controls . . . . . . . . . . . . . . . . . 34
OSD controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Using the on-screen display (OSD) menu . . . . . . . . . . .36
Accessing the Menu System . . . . . . . . . . . . . . . . . . . . . . 36
OSD warning messages . . . . . . . . . . . . . . . . . . . . . . .45
Setting up your monitor . . . . . . . . . . . . . . . . . . . . 47
Setting the maximum resolution . . . . . . . . . . . . . . . . . . . . 47
Using the Tilt, Swivel, and Vertical Extension . . . . . . . . .48
Tilt, Swivel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Vertical Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Rotating the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Troubleshooting ...............................51
Self-test . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Built-in diagnostics. . . . . . . . . . . . . . . . . . . . . . .52
Common problems . . . . . . . . . . . . . . . . . . . . . . . 53
Product-specific problems . . . . . . . . . . . . . . . . . . .55
Universal serial bus (USB) specific problems . . . . . . . . . 55

│5
Appendix ....................................56
Safety Instructions. . . . . . . . . . . . . . . . . . . . . 56
FCC notices (U.S. Only) and other regulatory information56
Contacting Dell. . . . . . . . . . . . . . . . . . . . . . . 57

6 │About your monitor
About your monitor
Package contents
Your monitor ships with the components shown in the table below. If any
component is missing, contact Dell technical support. For more information see
Contacting Dell.
NOTE: Some items may be optional and may not ship with your monitor.
Some features or media may not be available in certain countries.
Monitor
Stand riser
Stand base
Power cable (varies by
country)

About your monitor │7
DP Cable
USB 3.0 Upstream Cable
(Enables the USB Ports on
the Monitor)
Dell P2418D
©2017 Dell Inc.
2017-07
Dell.com/support/monitors
34
1 2
567
i
i
DP
USB
2
1
5° 21°
1
2
2
1
3
DP
USB
(DELLP/N:G1FNH rev.A00)
F40G24C1700XX
•
Contents:
•
Device drivers
Quick Setup Guide
• User's Guide
• Dell Display Manager Software
DriversandUtilities
©
2
0
1
7
D
e
ll
I
n
c
.
A
ll
r
i
g
h
e
t
s
r
s
e
r
v
e
d
.
P/N K0JF7 Rev. A00
P/N F40G24C1700XX
July 2017
Made in China
K0JF7A00
Dell
™
P2418DMonitor
•
Contents:
•
Device drivers
Quick Setup Guide
• User's Guide
• Dell Display Manager Software
Drivers and Utilities
©
2
0
1
7
D
e
ll
I
n
c
.
A
ll
r
i
g
h
e
t
s
r
s
e
r
v
e
d
.
P/N K0JF7 Rev. A00
P/N F40G24C1700XX
July 2017
Made in China
K0JF7A00
Dell
™
P2418DMonitor
∞Drivers and
Documentation media
∞Quick Setup Guide
∞Safety and Regulatory
Information

8 │About your monitor
Product features
The Dell P2418D flat panel display has an active matrix, Thin-Film Transistor (TFT),
Liquid Crystal Display (LCD), and LED backlight. The monitor features include:
∞P2418D: 60.33 cm (23.75-inch) viewable area display (measured diagonally).
2560 x 1440 resolution, via HDMI/DisplayPort, plus full-screen support for
lower resolutions.
∞Wide viewing angle to allow viewing from a sitting or standing position, or
while moving from side-to-side.
∞Color gamut of 99% sRGB.
∞High Dynamic Contrast Ratio.
∞Tilt, swivel, height, and rotate adjustment capabilities.
∞Removable stand and Video Electronics Standards Association (VESA™) 100
mm mounting holes for flexible mounting solutions.
∞Digital connectivity with DisplayPort and HDMI.
∞Equipped with 1 USB upstream port and 4 USB downstream ports.
∞Plug and play capability if supported by your system.
∞On-Screen Display (OSD) adjustments for ease of set-up and screen
optimization.
∞Software and documentation media includes an Information File (INF), Image
Color Matching File (ICM), and product documentation.
∞Dell Display Manager Software included (comes in the CD shipped with the
monitor).
∞Security lock slot.
∞Stand lock.
∞Capability to switch from wide aspect to standard aspect ratio while
maintaining the image quality.
∞0.3 W standby power when in the sleep mode.
∞Analog backlight dimming control for flicker free display.
∞Optimize eye comfort with a flicker-free screen.
∞The possible long-term effects of blue light emission from the monitor
may cause damage to the eyes, including eye fatigue or digital eye strain.
ComfortView feature is designed to reduce the amount of blue light emitted
from the monitor to optimize eye comfort.

About your monitor │9
Identifying parts and controls
Front View
1 2
Front panel controls
Label Description
1Function buttons (For more information, see Operating your monitor)
2Power on/off button (with LED indicator)

10 │About your monitor
Back View
1
2
3
4
5
6
P2418D
MonitorPlano Panel /Moniteur écran plat /液晶顯示器
Modelo/N°de modelo /型號: P2418Dc
Entrade/Daya Tegangan:100-240V 50/60Hz,1.5A
輸入電源:交流電壓100-240伏特,1.5安培,50/60赫茲
Consumode energía: XX.X Wh
Consumode energía en modo de espera: 0.X Wh
Удельная мощность рабочего режима - 0.XXX Вт/см²
Потребляемая мощность изделием в режиме ожидания - 0.XX Вт
Потребляемая мощность изделием в выключенном режиме - 0.XX Вт
Apparatet må lkoples jordet skkontakt.
Apparaten skall anslutas ll jordat uag.
Laite on liiteävä suojakoskemilla varusteuun pistorasiaan.
Apparatets skprop skal lslues en skkontakt med jord,
som giver forbindelse l skproppens jord.
The equipment must be connected to an earthed mains socket-outlet.
L'appareil doit être branché sur une prise de courant munie d'une mise à la terre.
CANICES-3 (B)/NMB-3(B)
сделанный в Китай /Fabriqué en Chine/中國製造
7
XXXXXX-XX
デ
XXXXX
XXXXXXXXXXXX
MSIP-REM-TPF-P2418Dc
신청인:TPV Electronics (Fujian) Co., Ltd.
제조자:L&T Display Technology(Fujian)Ltd.
080-200-3800
警語: 使用過度恐傷害視力
F40GXXXXXXXXXX
R33037
RoHS
SVCTag:
xxxxxxx
ExpressService
Code:
xxxxxx xxx x
S/N:XXXXXXX
XXXXXXXXXXX
Date of Mfg/生产日期/生產日期: July. 2017
Flat Panel Monitor /液晶显示器
型号: P2418D
Input Rang /输入电源:
100-240V 50/60Hz,1.5A
www.dell.com Raheen Business Park Limerick Ireland
Madein China /中国制造
DELL P2418D
F40GXXXXXXXXX
Back View without monitor stand Back View with monitor stand
Label Description Use
1VESA mounting holes (100 mm
x 100 mm - behind attached
VESA Cover)
Wall mount monitor using VESA-
compatible wall mount kit (100 mm x
100 mm).
2Regulatory label Lists the regulatory approvals.
3Stand release button Release stand from monitor.
4Security lock slot Secures monitor with security
lock(sold separately).
5Barcode, serial number, and
Service Tag label
Refer to this label if you need to
contact Dell for technical support.
6Cable management slot Use to organize cables by placing
them through the slot.

About your monitor │11
Side View
1
Label Description Use
1USB downstream port
2x USB 3.0
downstream port
(including 1x USB3.0
BC1.2 charging port)
Connect your USB device.
NOTE: To use this port, you must
connect the USB cable (shipped with
your monitor) to the USB-upstream port
on the monitor and to your computer.

12 │About your monitor
Bottom View
54 6 732
1
Bottom view without monitor stand
Label Description Use
1Power port Connect the power cable.
2HDMI port Connect your computer with HDMI cable(optional).
3DP port Connect your computer to the monitor using a DP
cable.
4USB upstream port Connect the USB cable (shipped with your monitor)
to this port and your computer to enable the USB
ports on your monitor.
5USB downstream
port
Connect USB device.
NOTE:To use this port, you must connect
the USB cable (shipped with your monitor)
to the USB-upstream port on the monitor
and to your computer.
6Stand lock feature To lock the stand to the monitor using a M3 x 6mm
screw (screw not included).
7Dell Soundbar
mounting slots
Attaches the optional Dell Soundbar.
NOTE:Please remove the plastic strip
covering the mounting slots before affixing
the Dell Soundbar.

About your monitor │13
Monitor specifications
Model P2418D
Screen type Active matrix - TFT LCD
Panel type In-Plane Switching Technology
Viewable image
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
603.30 mm (23.75 in)
525.70 mm (20.70 in)
295.70 mm (11.64 in)
155,449.49 mm2(240.95 in2)
Pixel pitch 0.20535mm x 0.20535 mm
Pixel per inch (PPI) 123
Viewing angle (vertical /
horizontal)
178° (vertical) typical
178° (horizontal) typical
Brightness 300 cd/m² (typical)
Contrast ratio 1000: 1 (typical)
Aspect ratio 16:9
Display screen coating Anti-glare with 3H hardness
Backlight White LED edgelight system
Response time 8 ms (typical) for NORMAL mode
5 ms (typical) for FAST mode
Color depth 16.7 million colors
Color support 99% sRGB
Built-in devices USB 3.0 super-speed hub (with 1x USB 3.0 upstream
port, 4x USB 3.0 downstream ports, including 1x
USB 3.0 BC1.2 charging port)
Dell Display Manager
compatibility
Yes

14 │About your monitor
Connectivity 1xDP (ver 1.2)
1xHDMI (ver 1.4)
1xUSB3.0 port - Upstream
2xUSB3.0 port - Side
2xUSB3.0 port - Bottom
Border width (edge of
monitor to active area)
6.6mm(Top/Left/Right)
18.4mm(Bottom)
Security Security lock slot (cable lock sold separately)
Adjustability Height adjustable stand (130mm)
Tilt (-5°/+21°)
Swivel (-45°/+45°)
Pivot (90°)
Resolution specifications
Model P2418D
Horizontal scan
range
29 kHz to 113 kHz (automatic)
Vertical scan
range
49 Hz to 86 Hz (automatic)
Maximum preset
resolution
2560 x 1440 at 60 Hz
Supported video modes
Model P2418D
Video display capabilities (HDMI
& DP playback )
480i, 480p, 576i, 576p, 720p, 1080i, 1080p,
1440p

About your monitor │15
Preset display modes
Display Mode Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Pixel Clock
(MHz)
Sync
Polarity
(Horizontal
/ Vertical)
VESA, 720 x 400 31.5 70.1 28.3 -/+
VESA, 640 x 480 31.5 59.9 25.2 -/-
VESA, 640 x 480 37.5 75.0 31.5 -/-
VESA, 800 x 600 37.9 60.3 40.0 +/+
VESA, 800 x 600 46.9 75.0 49.5 +/+
VESA, 1024 x 768 48.4 60.0 65.0 -/-
VESA, 1024 x 768 60.0 75.0 78.8 +/+
VESA, 1152 x 864 67.5 75.0 108.0 +/+
VESA, 1280 x 768 47.8 59.9 79.5 -/+
VESA, 1280 x 1024 64.0 60.0 108.0 +/+
VESA, 1280 x 1024 79.9 75.0 135.0 +/+
VESA, 1600 x 1200 75.0 60.0 162.0 +/+
VESA, 1680 x 1050 65.3 60.0 146.3 -/+
VESA, 1920 x 1080 67.5 60.0 148.5 +/+
VESA, 1920 x 1200 74.6 59.9 193.3 -/+
VESA, 2048 x 1080 66.6 60.0 147.2 +/-
VESA, 2560 x 1440 88.8 60.0 241.5 +/-

16 │About your monitor
Electrical specifications
Model P2418D
Video input signals ∞HDMI 1.4, 600mV for each differential line,100
ohm input impedance per differential pair
∞DisplayPort 1.2, 600mV for each differential line,
100 ohm input impedance per differential pair
AC input voltage/
frequency/current
100 VAC to 240 VAC / 50 Hz or 60 Hz ±3 Hz /
1.5A (typical)
Inrush current ∞120 V: 30 A (Max.) at 0°C (cold start)
∞240 V: 60 A (Max.) at 0°C (cold start)

About your monitor │17
Physical characteristics
Model P2418D
Signal cable type ∞Digital: detachable, HDMI, 19 pins (Not
included).
∞Digital: detachable, DP, 20 pins.
∞Universal Serial Bus: USB, 9 pins.
Dimensions (with stand)
Height (extended) 486.9 mm (19.17 in)
Height (compressed) 356.9 mm (14.05 in)
Width 538.9 mm (21.22 in)
Depth 180.0 mm (7.09 in)
Dimensions (without stand)
Height 320.7 mm (12.63 in)
Width 538.9 mm (21.22 in)
Depth 51.6 mm (2.03 in)
Stand dimensions
Height (extended) 401.5 mm (15.81 in)
Height (compressed) 354.4 mm (13.95 in)
Width 242.6 mm (9.55 in)
Depth 180.0 mm (7.09 in)
Weight
Weight with packaging 7.81 kg (17.22 lb)
Weight with stand assembly
and cables
5.82 kg (12.83 lb)
Weight without stand
assembly (no cables)
3.44 kg (7.58 lb)
Weight of stand assembly 1.96 kg (4.32 lb)
Front-frame gloss 4 - 7

18 │About your monitor
Environmental characteristics
Model P2418D
Compliant Standards
Energy Saver feature for Energy Star certified Monitor.
EPEAT Gold registered in the U.S. EPEAT registration varies by country.
See www.epeat.net for registration status by country.
TCO-certified display.
BFR/PVC- Free monitor (excluding external cables).
Meets NFPA 99 leakage current requirements.
Arsenic-Free glass and Mercury-Free for the panel only.
Energy Gauge shows the energy level being consumed by the monitor in real time.
Temperature
Operating 0°C to 40°C (32°F to 104°F)
∞Storage: -20°C to 60°C (-4°F to 140°F)
∞Shipping: -20°C to 60°C (-4°F to 140°F)
Non-operating
Humidity
Operating 10% to 80% (non-condensing)
∞Storage: 10% to 90% (non-condensing)
∞Shipping: 10% to 90% (non-condensing)
Non-operating
Altitude
Operating (maximum) 5,000 m (16,400 ft)
Non-operating (maximum) 12,192 m (40,000 ft)
Thermal dissipation ∞211.69 BTU/hour(maximum)
∞68.29 BTU/hour(typical)

About your monitor │19
Power management modes
If you have VESA's DPM™ compliance display card or software installed in your
PC, the monitor can automatically reduce its power consumption when not in
use. This feature is called Power Save Mode*. If the computer detects input from
the keyboard, mouse or other input devices, the monitor automatically resumes
functioning. The following table shows the power consumption and signaling of this
automatic power saving feature.
* Zero power consumption in off mode can only be achieved by disconnecting the
main cable from the monitor.
VESA
Modes
Horizontal
Sync
Vertical
Sync
Video Power
Indicator
Power
Consumption
Normal
operation
Active Active Active White 62 W
(maximum)**
20 W (typical,
without USB
load)
Active-off
mode
Inactive Inactive Blanked White
(Glowing )
Less than 0.3 W
Switch off - - - Off Less than 0.3 W
Energy Star Power Consumption
Pon 20 W
ETEC 63 kWh
** Maximum power consumption with max luminance.
This document is informational only and reflects laboratory performance. Your
product may perform differently, depending on the software, components and
peripherals you ordered and shall have no obligation to update such information.
Accordingly, the customer should not rely upon this information in making
decisions about electrical tolerances or otherwise. No warranty as to accuracy or
completeness is expressed or implied.

20 │About your monitor
NOTE: This monitor is ENERGY STAR-compliant.
NOTE:
Pon: Power consumption of on mode as defined in Energy Star 7.0
version.
ETEC: Total energy consumption in kWh as defined in Energy Star 7.0
version.
