Dell Precision Workstation T7600 User manual

DELL PRECISION™
T7600
Technical
Guidebook

TABLE OF CONTENTS
O V E R V IE W
External Chassis Views 3
Motherboard Layout 4-5
M A R K E T I N G S Y S T E M C O N F I G U R A T I O N S
Operating System, Chipset 6
Processor 7
Memory 8
Graphics/Video Controllers 9
Drives and Removable Storage, Integrated Hard Drive Controller 10-11
System Expansion Slots, External Ports/Connectors 11
Communications—Network Adapter, Audio and Speakers, Keyboard and Mouse 12
Security, Service and Support, Software 12
DETAILED ENGINEE RING S PECIF IC ATIONS
System Dimensions (Physical), System Expansion Slots 14
System Level Environmental and Operating Conditions, Power 15-16
Audio—Integrated, Communications– Integrated LAN 17-18
Communications—Add in Network Interface Card (NIC) 18
Communications—Add in 1394 card, 19
Graphics/Video Controllers 20-30
Hard Drives 31-41
Optical Drive 42-43
Media Card Reader 44
BIOS Defaults 45-46
Chassis Enclosure and Ventilation Requirements 47
AD DI TIONAL INFORMATION
Statement of Volatility (SOV) 48-50
March 2012

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
3
MINI TOWER COMPUTER
FRONT VIEW
1Power button, power light 7Microphone connector
2USB 3.0 connector (1) 8Headphone connector
3Optical drive 9Diagnostic lights (4)
4Optical drive eject button 10 Optical drive
5USB 2.0 connectors (3) 11 Optical drive eject button
6Drive activity light 12 Hard drive access cover-
release latch
BACK VIEW
13 Power supply unit (PSU)
release latch
17 Security cable slot
14 Power connector 18 Back Panel
15 * Expansion card slots (2) 19 Active expansion slots (5)
16 Padlock ring 20 Inactive expansion card
slot (1)
BACK PANEL CONNECTORS
1Line-out connector 7Line-in/microphone
connector
2Network link Integrity
light
8Serial connector
3Network adapter
connectors (2)
9USB 2.0 connectors (4)
4Network activity light 10 Ps/2 keyboard connect-
or
5PS2/mouse connector 11 USB 3.0 connector (1)
6USB 2.0 connector (1)
* Note: These PCIe slots are only active when a second CPU is installed

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
4
System Board Components
Number Name Number Name
1PCI slot 13 DIMM slots (available only when
optional second CPU is installed)
2PCIe x16 slot 14 PCIe X16 slots (available only when
optional second CPU is installed)
3PCIe x16 slot (wired as x4) 15 HDD3 fan connector
4Accelerated graphics port (PCIe
x16) 16 HDD2 fan connector
5PCIe open-ended slot (wired as
x4) 17 System fan 1 connector
6USB 3.0 front panel connector 18 24-pin power2 connector
7Intruder 19 DIMM slots
8DIMM slots (available only when
optional second CPU is installed) 20 CPU1
9(not populated) 21 DIMM slots
10 CPU2 22 CPU1 fan socket
11 CPU2 fan socket 23 System 2 fan connector
12 Front panel audio connector 24 (not populated)

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
5
System Board Components (continued)
Number Name Number Name
25 (not populated) 33 SATA connectors
26 System 3 fan connector 34 Internal USB 2.0 connector
27 Speaker enable 35 SAS0 connector -disabled
28 Internal speaker connector 36 SAS1 connector -disabled
29 (not populated) 37 HDD temperature sensor con-
nector
30 Remote power enable 38 Internal USB 2.0 connector
31 Front panel & USB 2.0 connector 39 HDD1 fan connector
32 24-pin power1 connector 40 Battery

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
6
MARKETING SYSTEM CONFIGURATIONS
NO TE : O e ring s ma y v ar y by count ry. For mor e inf orma ti on re ga rd ing the congu rati on of yo ur co mputer , c li ck
St ar t> Help and Su ppor t an d se le ct the o p tion t o vi ew in forma t io n ab ou t yo u r comput er .
OPER ATING SYSTEMS
Windows 7® operating system—
Factory Installed
Microsoft® Windows 7® Professional (32 and 64 bit),
Microsoft® Windows 7® Ultimate (32 and 64 bit),
Windows Vista® operating system—
Driver availability only via Dell.com
Windows Vista® Business SP2 (32 and 64 bit),
Windows Vista® Ultimate SP2 (32 bit and 64 bit)
Windows XP® operating system
Driver availability only via Dell.com
Microsoft® Windows XP® Professional (32 and 64 bit),
Note: Loading and booting an XP image requires a discrete PCIe
hard disk controller (like the PERC H310 or PERC H710P) with XP
driver
Red Hat Enterprise Linux RHEL workstation 6.1 Factory installed
RHEL 5.7 supported
Other FreeDOS drop in the box for (N-series),
Ubuntu® Linux version 11.10 (factory installed in China only)
CHIPSET
Chipset Intel C600 Chipset
Non-volatile memory on chipset
BIOS Conguration SPI (Serial Peripheral Interface) 64Mbit (8MB) & 32Mbit (4MB)
TPM 1.2 Security Device (Trusted Platform Module)118KB
Non-TPM Available in select countries
NIC EEPROM LOM conguration contained within SPI_FLASH – no dedicated
LOM EEPROM

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
7
PROCESSOR
NOTE: Global Standard Products (GSP) are a subset of Dell’s relationship products that are managed for availability and synchro-
nized transitions on a worldwide basis. They ensure the same platform is available for purchase globally. This allows customers to
reduce the number of congurations managed on a worldwide basis, thereby reducing their costs. They also enable companies
to implement global IT standards by locking in specic product congurations worldwide. The following GSP processors identi-
ed below will be made available to Dell customers.
NOTE: Processor numbers are not a measure of performance. Processor availability subject to change and may vary by region/
country.
Intel® Eight Core Processors
Intel® Xeon E5-2687W
3.16GHz, 20M, 8.0GT/s, 150W VT-x, VT-d, TXT (vPro™)
Intel® Xeon E5-2680
2.7GHz, 20M, 8.0GT/s, 130W VT-x, VT-d, TXT (vPro™) X—GSP
Intel® Xeon E5-2665
2.4GHz, 20M, 8.0GT/s, 115W VT-x, VT-d, TXT (vPro™)
Intel® Xeon E5-2650
2.0GHz, 20M, 8.0GT/s, 95W VT-x, VT-d, TXT (vPro™)
Intel® Six Core Processors
Intel® Xeon E5-2667
2.9GHz, 15M, 8.0GT/s, 130W VT-x, VT-d, TXT (vPro™) X—GSP
Intel® Xeon E5-2630
2.3GHz, 15M, 7.2GT/s, 95W VT-x, VT-d, TXT (vPro™) X—GSP
Intel® Xeon E5-2620
2.0GHz, 15M, 7.2GT/s, 95W VT-x, VT-d, TXT (vPro™) X—GSP
Intel® Four Core Processors
Intel® Xeon E5-2643
3.30GHz, 10M, 8.0GT/s, 130W VT-x, VT-d, TXT (vPro™) X—GSP
Intel® Xeon E5-2609
2.4GHz, 10M, 6.4GT/s, 80W VT-x, VT-d, TXT (vPro™) X—GSP
Intel® Xeon E5-2603
1.8GHz, 10M, 6.4GT/s, 80W VT-x, VT-d, TXT (vPro™)

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
8
1 The total amount of available memory will be less than 4GB. The amount less depends on the actual system configuration. To fully utilize 4GB or
more of memory requires a 64-bit enabled processor and 64-bit operating system.
Type: DDR3 RDIMM (ECC)/ LRDIMM (ECC)
Max Frequency 1600 MHz RDIMM/1333MHz LRDIMM
(DIMM Slots 8 or 16 (with 2nd CPU installed)
DIMM Capacities Up to 32GB (LRDIMM)
Minimum Memory 4GB (8GB with 2nd CPU installed
Maximum System Memory 512GB1
Memory congurations
LRDIMM ECC Memory
512GB (16x 32GB) DDR3, 1333 MHz X
256GB (8x 32GB) DDR3, 1333 MHz X
RDIMM ECC Memory
256GB (16x 16GB) DDR3, 1600 MHz X
256GB (16x 16GB) DDR3, 1600 MHz X
128GB (16x 8GB) DDR3, 1600 MHz X
128GB (8 x 16GB) DDR3, 1600 MHz X
64GB (8 x 8GB) DDR3, 1600 MHz X
64GB (4 x 16GB) DDR3, 1600 MHz X
32GB (4 x 8GB) DDR3, 1600 MHz X
16GB (4 x 4GB) DDR3, 1333/1600 MHz X
8GB (4 x 2GB) DDR3, 1333/1600 MHz X
4GB (2 x 2GB) DDR3, 1333/1600 MHz, Single CPU only X
MEMORY
NOTES: The Dell Precision T7600 has a four channel memory bus architecture. Dell recommends that all four
memory channels be populated with DIMMs for maximum memory performance.
Maximum memory speed is tied to processor.
1600MHz memory will run at reduced speeds - 1333MHz with 7.2GT/s processors and at 1066MHz with 6.4GT/s processors
1333MHz memory will run at reduced speed - 1066MHz with 6.4GT/s processors

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
9
GRAPHICS/VIDEO CONTR OLLER
NOTE: System supports full height (FH) cards unless specied
NOTE: Dual Graphic options (incl. dual C2075 Tesla cards) available on select cards. Dual Graphics with NVIDIA SLI (Scalable
Link Interface) options available
Optional Graphic/Video Options Included Dongle
High End 3D
6.0GB NVIDIA Quadro 6000 with (2) DP and (1) DVI (1) DP-DVI
2.5GB NVIDIA Quadro 5000 with (2) DP and (1) DVI (1), DP-DVI, (1) DVI-VGA
Mid-range 3D
2.0GB NVIDIA Quadro 4000 with (2) DP and (1) DVI (1) DP-DVI, (1) DVI-VGA
2.0GB AMD FirePro V7900 with (4) DP (1) DP-DVI
1.0GB NVIDIA Quadro 2000 with (2) DP and (1) DVI (1) DP–DVI, (1) DVI-VGA
2.0GB AMD FirePro V5900 with (2) DP and (1) DVI 1) DP–DVI
Entry 3D
1.0GB NVIDIA Quadro 600 with (1) DP and (1) DVI (1) DP–DVI, (1) DVI-VGA
1.0GB AMD FirePro V4900 with (2) DP and (1) DVI 1) DP–DVI, (1) DVI-VGA
Professional 2D
512MB NVIDIA NVS 300 with (1) DMS-59 (1) DMS-59–Dual DVI
512MB AMD FirePro 2270 with (1) DMS-59 (1) DMS-59–Dual DVI
Multi Core Compute (GPGPU)
6GB NVIDIA Tesla C2075 Computing GPGPU - no I/O

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
10
DRIVES AND REMOVABLE STORAGE
Bays:
5.25-inch Optical Bay Supported (External) 1
Slimline Optical Bay Supported (External) 1
Optical Drives Supported (maximum) 2
3.5” Hard Drive Bays Supported (Internal) 4
Hard Drives Supported 3.5”/2.5” (maximum) 4/8
Interface:
SATA 3.0 (AHCI) 2
3.5” Hard Drives:
3TB1 SATA 7200 RPM HDD X
2TB1 SATA 7200 RPM HDD X
1TB1 SATA 7200 RPM HDD X
500GB1 SATA 7200 RPM HDD X
250GB1 SATA 7200 RPM HDD X
2.5” Hard Drives:
256GB1 SATA Solid State Drive X
900GB1 SAS 10k RPM HDD X
600GB1 SAS 10k RPM HDD X
146GB1 SAS 15k RPM HDD X
500GB1 SATA 7200 RPM HDD X
320GB1 SATA 7200 RPM HDD X
1 For hard drives, GB means 1 billion bytes; actual capacity varies with preloaded material and operating environment and will be less.
HARD DRIVE CONTROLLER
Dell PERC H310 for Dell Precision
SATA/SAS 6Gb/s, host based RAID 0/1/5/10 ( 8 ports max) Base
Dell PERC H710P for Dell Precision
SATA/SAS 6Gb/s, hardware based RAID 0/1/5/10 (8 ports max) Optional

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
11
DRIVES AND REMOVABLE STORAGE (CON’T)
1 Discs burned with this drive may not be compatible with some existing drives and players; using DVD+R media provides maximum compatibility.
2 DVD-ROM drives may have write-capable hardware that has been disabled via firmware modifications.
NOTE: Dell 19 in 1 Media Card Reader (MCR) is supported via a F5 to F3 bay converter in the 5.25” Optical Drive Bay
Optical Drive:
Slimline Blu-ray Writer SATA 1.5Gbit/s X
Slimline DVD+/-RW1 SATA 1.5Gbit/s X
Slimline DVD-ROM1 SATA 1.5Gbit/s X
5.25” DVD+/-RW1 SATA 1.5Gbit/s X
Media Card Reader:
Dell 19 in 1 Media Card Reader X
EXTERNAL POR TS/CONNECTORS
USB 3.0 1 Front, 1 Rear
USB 2.0 3 Front, 5 Rear
Serial 1 Rear
Network Connector (RJ-45) 2 Rear
PS/2 2 Rear
1394 Controller via optional PCI card Optional FH card
Audio:
Line in for microphone 1 Front
Line in for microphone or stereo 1 Rear
Line out for headphones or speakers 1 Front, 1 Rear
Format enter simpleslots
SYSTEM EXPANSION SLOTS
NOTE: See Detailed Engineering Specications for supported voltage, maximum wattage and card dimensions.
PCIe x16 Slot Gen 3 2 (4 with optional 2nd CPU installed)
PCIe x8 (wired x4) Slot Gen 3 1
PCIe x4 Slot Gen 2 1
PCI 32/33 Slot 1
Serial ATA (SATA) connectors 10 (8 HDD, 2 optical) (5-8 HDDs requires option choice at
time of purchase)

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
12
COMMUNICATIONS - INTEGRATED LAN
1 This term does not connote an actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and
network infrastructure is required.
INTEGRATED INTEL® 82579 GIGABIT1
ETHERNET LAN 10/100/1000
INTEGRATED INTEL® 82574 GIGABIT1
ETHERNET LAN 10/100/1000 (CONT)
Support
Operating System Driver Support Windows 7 32/64, Vista 32/64
Red Hat Linux 6
Manageability (examples WOL, PXE) WOL, PXE 2.1
Management Capabilities Alerting Intel® Standard Manageability, Intel Xeon
Processor with vPro Technology
COMMUNICATIONS – OPTIONAL ADD-IN NETWORK CARD
Intel(R) Ethernet Server Adapter X520-T2
Connector Type 2X RJ45
Data Rates supported 10/100/1000/100001 Mbps Half/Full duplex
Controller Details
Controller bus architecture (example PCIe 1.0a x1) PCIe Gen 2 X8
Data transfer mode (example Bus-Master DMA) Bus-Master DMA
Power consumption (full operation per data rate connection speed) 25W maximum
Power consumption (standby operation) Less than 300mW
IEEE standards compliance (example 802.1P) 802.1p, 802.1q, 802.2,
802.3, 802.3ad
Hardware Certications (example FCC, B, GS mark…) FCC B, UL, CE, VCCI, BSMI, CTICK, KCC
Boot ROM Support No
Network Transfer Mode
Network Transfer Rate (example 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps
1000BASE-T (full-duplex) 2000 Mbps Max
10GBASE-T (full-duplex) 20000 Mbps Max
Support
Operating System Driver Support Windows® 7 32- & 64-bit, Windows Vista® 32–
and 64-bit
Manageability (examples WOL, PXE) WOL, ACPI
Management Capabilities Alerting (example ASF 2.0) None
1 This term does not connote an actual operating speed of 10 Gb/sec. For high speed transmission, connection to a 10 Gigabit Ethernet server and
network infrastructure is required.

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
13
AUDIO AND SPEAKERS
Realtek ALC269Q High Denition Audio Codec Integrated on system board
Internal Chassis Speaker Optional
Dell AY410 2.1 Desktop Speakers Optional
Dell AX210 2.0 Desktop Speakers Optional
Dell AX510/AX510PA Flat Panel Soundbar Speakers Optional
KEYBOARD AND MOUSE
Dell USB Entry Keyboard Optional
Dell Multimedia Pro Keyboard Optional
Dell Smartcard Keyboard Optional
Dell USB Optical Mouse Optional
Dell Laser Mouse Optional
SECURITY
Trusted Platform Module (TPM) 1.21Integrated on system board
Chassis Intrusion Switch Optional
Dell Smartcard Keyboard Optional
Chassis lock slot and loop support Standard
Dell Data Protection | Encryption Accelerator Card Optional
SERVICE AND SUPPORT
NO TE : Fo r mo re d etai l s on D ell Servi ce P la ns p lease to go to: ww w. de ll .co m/s ervi ce/se rv ic e_pl an s
3 Year Warranty1 Next Business Day On-site2 (3-3-3) Standard
ProSupport Optional
SOFTWARE
Dell Client Manager Available via Dell.com
Dell Data Protection/Access (DDPA) Standard
Dell Data Protection | Encryption (DDPE) Optional

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
14
DETAILED ENGINEERING SPECIFICATIONS
SYSTEM DIMENSIONS (P HYSICAL)
“ NOTE: System Weight and Shipping Weight is based on a typical conguration and may vary based on PC conguration. A typical
conguration includes: one graphics card, one hard drive, one optical drive”
SYSTEM EXPANSION SLOTS
*Total allowed graphics power allowed in 3 x16 slots is 225W. Total graphics power allowed in system is 600W.
Both require optional 2nd CPU to be installed. Slot 4 and Slot 2 is defaults for PERC controller.
Chassis Volume (liters) 48.82 l
Chassis Weight (pounds/kilograms) 54.28 lbs / 24.62 kg
Chassis Dimensions: (HxWxD)
Height (inches/centimeters) 16.95 in / 43.05 cm
Width (inches/centimeters) 8.50 in / 21.60 cm
Depth (inches/centimeters) 20.67 in / 52.50 cm
Shipping Weight (pounds/kilograms - includes packaging materials) 66.54 lbs / 30.18 kg
Packaging Parameters (HxWxD)
Height (inches/centimeters) 17.13 in / 43.51 cm
Width (inches/centimeters) 26.44 in / 67.16 cm
Depth (inches/centimeters) 21.94 in / 55.73 cm
Slot Type Voltage supported Max Height
(in,cm)
Max Length
(in, cm)
Max
Wattage
Cards
Supported Notes
1PCIe x16 (x4) 3.3V / 12V Standard Height
4.38 in / 11.13 cm
Full Length
12.28in / 31.20cm
25
2PCIe x16 3.3V / 12V Standard Height
4.38 in / 11.13 cm
Full Length
12.28in / 31.20cm
300* Default for fac-
tory installed
graphics card
3PCIe x16 (x4) 3.3V / 12V Standard Height
4.38 in / 11.13 cm
Full Length
12.28in / 31.20cm
25
4PCIe x 16 3.3V / 12V Standard Height
4.38 in / 11.13 cm
Full Length
12.28in / 31.20cm
300* PERC controller,
Second graphics
card
5PCI 3.3V / 5V / 12V / -12V Standard Height
4.20in / 10.67cm
Full Length
12.28in / 31.20cm
25
6Mechanical Slot n/a
2-1PCIe x16 3.3V / 12V Standard Height
4.38 in / 11.13 cm
Full Length
12.28in / 31.20cm
225* Only available
when optional
2nd CPU is pre-
sent
2-2PCIe x16 3.3V / 12V Standard Height
4.38 in / 11.13 cm
Full Length
12.28in / 31.20cm
225* Only available
when optional
2nd CPU is pre-
sent

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
15
SYSTEM LEVEL ENVIRONMENTAL AND OPERATING CONDITIONS
Temperature
Operating 10° to 35° C (50° to 95° F)
Non-Operating (Storage) -40° to 60° C (-40° to 140° F)
Relative Humidity 20% to 80% (non-condensing)
Maximum vibration
Operating 5 to 350 Hz at 0.0002 G²/Hz
Non-Operating 5 to 500 Hz at 0.001 to 0.01 G²/Hz
Maximum Shock
Operating 40 G +/- 5% with pulse duration of 2 msec +/-
10% (equivalent to 51 cm/sec [20 in/sec])
Non-Operating 105 G +/- 5% with pulse duration of 2 msec +/-
10% (equivalent to 127 cm/sec [50 in/sec])
Maximum Altitude
Operating –15.2 to 3048 m (–50 to 10,000 ft)
Non-Operating –15.2 to 10,668 m (–50 to 35,000 ft)
POWER
NOTE: The T7600 utilizes an Active Power Factor Correction (APFC) power supply to enhance eciency. Dell recommends only Universal
Power Supplies (UPS) based on Sine Wave output for APFC power supplies, not an approximation of a Sine Wave, Square Wave, or quasi-Square
Specications
Power Supply Wattage
1300W (for AC input voltages of 181—240 Vac)
1100W (for AC input voltages of 108—180 Vac)
1000W (for AC input voltages of 100—107 Vac)
AC input Voltage Range 100 - 240 Vac
AC input current (low ac range/high AC range) 14.0 A / 7.0 A
AC input Frequency 47 Hz / 63Hz
AC holdup time (80% load) 16 MSEC
Average Eciency (Energy Star 5.2 Compliant) 87 – 90 – 87% @ 20 – 50 – 100% load
DC parameters
+12.0v output 12VABCDEFGHIJ ; 18.0A
+5.0v auxiliary output 4.0A
-12.0v output 0.5A
Max total power 1300W
BTUs/h (based on PSU max wattage) 4113.0 BTU
Power Supply Fan 60*25mm (x2)
Compliance:
1watt requirement Yes
Climate Savers / 80Plus Compliant Yes
FEMP (CECP) Standby Power Compliant Yes

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
16
POWER CONTINUED
3.0v CMOS battery (Type and estimated battery life)
Brand Type Voltage Composition Life
PANASONIC CR-2302L/BE 3V Lithium Continuous Discharge Under 15 kΩ Load to 2.5V End-
Voltage: 1100 hours or longer
MITSUBISHI CR2302 3V Lithium
Manganese
Dioxide
Continuous Discharge Under 15 kΩ Load to 2.5V End-
Voltage: 1000 hours or longer

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
17
AUDIO
INTEGRATED REALTEK ALC269 HIGH DEFINITION AUDIO
High Denition Stereo support X
Number of channels 2
Number of Bits / Audio resolution 16, 20, and 24-bit resolution
Sampling rate (recording/playback) Support 44.1K/48K/96K/192 kHz sample rates
Signal to Noise Ratio 98 dB DAC outputs, 90 dB for ADC inputs
Analog Audio X
Dolby Digital
THX
Digital out (S/PDIF)
Audio Jack Impedance
Microphone 32K ohms
Line-In 32K ohms
Line-Out 200 ohms
Headphone 1 ohm
Internal Speaker Power Rating 2.3 Watts (max) / 2.0 Watts (typ)
COMMUNICATIONS - INTEGRATED LAN
INTEGRATED INTEL® 82579 GIGABIT1
ETHERNET LAN 10/100/1000
External Connector Type RJ45
Data Rates supported 10/100/10001 Mbps
Controller Details
Controller bus architecture Intel direct-connect
Integrated memory N/A
Data transfer mode (example Bus-Master DMA) N/A
Power consumption (full operation per data rate connection speed) 711mW (Max.)
Power consumption (standby operation) 227mW (Max.)
IEEE standards compliance (example 802.1P) 802.3
Hardware Certications (example FCC, B, GS mark…) N/A
Boot ROM Support EEPROM (located in SPI)
Network Transfer Mode (example Full Duplex, Half Duplex)
Network Transfer Rate (example 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps
10 Mb (full/half-duplex)
100 Mb (full/half-duplex)
10001 Mb (full-duplex)

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
18
COMMUNICATIONS - INTEGRATED LAN (CONT.)
INTEGRATED INTEL® 82579 GIGABIT
ETHERNET LAN 10/100/1000 (CONT.)
Support
Operating System Driver Support Windows 7 32/64, Vista 32/64
Red Hat Linux 6
Manageability (examples WOL, PXE) WOL, PXE 2.1
Management Capabilities Alerting Intel® Standard Manageability, Intel Xeon
Processor with vPro Technology
1 This term does not connote an actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and
network infrastructure is required.
COMMUNICATIONS – OPTIONAL ADD-IN NETWORK INRERFACE CARD (NIC)
Intel(R) X520-T2 Ethernet 10GbE1 Server Adapter
Connector Type 2X RJ45
Data Rates supported 10/100/1000/100001 Mbps Half/Full duplex
Controller Details
Controller bus architecture (example PCIe 1.0a x1) PCIe Gen 2 X8
Data transfer mode (example Bus-Master DMA) Bus-Master DMA
Power consumption (full operation per data rate connection speed) 25W maximum
Power consumption (standby operation) Less than 300mW
IEEE standards compliance (example 802.1P) 802.1p, 802.1q, 802.2,
802.3, 802.3ad
Hardware Certications (example FCC, B, GS mark…) FCC B, UL, CE, VCCI, BSMI, CTICK, KCC
Boot ROM Support No
Network Transfer Mode
Network Transfer Rate (example 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps
1000BASE-T (full-duplex) 2000 Mbps Max
10GBASE-T (full-duplex) 20000 Mbps Max
Support
Operating System Driver Support Windows® 7 32- & 64-bit, Windows Vista® 32–
and 64-bit
Manageability (examples WOL, PXE) WOL, ACPI
Management Capabilities Alerting (example ASF 2.0) None
Ron environmental & support

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
19
COMMUNICATIONS – OPTIONAL 1394 NETWORK CARD
1394 NETWORK ADD-IN CARD
Connector Type PCI 2.3
Controller Details
Controller bus architecture (example PCIe 1.0a x1) PCI 2.3
IO Ports 2 External 1394a 6-pin connectors
1 Internal 1394a 10-pin header
Power Consumption Under 30 mA
Connector 1394a
OS Support Windows® 7 32- & 64-bit, Windows Vista® 32– and 64-bit

DELL™ PRECISION™ T7600 TECHNICAL GUIDEBOOK
20
GR AP HI CS /V ID EO C ONT R OL LE R
NVIDIA NVS 300
Bus Type (example integrated or PCIe x16) PCIEx16
GPU core clock 520 MHz
Frame Buffer Memory (onboard and shared) Size and Speed 512MB DDR3 @ 790 MHz
Maximum power consumption 17.5W
Maximum Color Depth 24 bit RGB (True Color)
Maximum Vertical Refresh Rate 85Hz analog, 60Hz digital
Multiple Display Support 2
Operating Systems Graphics/ Video API Support Microsoft Windows 7, Vista, XP all with 32bit and
64Bit. Redhat Linux, Open GL 4.1, DirectX 11
Supported Resolutions and Max Refresh Rates (Hz) (Note: Analog and/or
digital)
DisplayPort Max 2 digital displays at up to 2560 X
1600 @60Hz, Single–link DVI Max: 2 digital dis-
plays up to 1920 x 1200 @ 60Hz: VGA Max 2 ana-
log displays up to : 2048 x 1536 @ 85Hz
External connectors DMS59
DisplayPort Audio Support Yes
Dimensions of full height card inches/centimeters Low Prole 2.7” H x 5.7” L Single Slot
68mm H x 145mm L
Environmental Operating Conditions (Non-Condensing):
Operating Temperature Range 0 °C to 55 °C
Relative Humidity Range 5% to 90% RH
Altitude Range Not specied
