Dell PRECISION T1650 User manual

DELL PRECISION™
T1650
Technical
Guidebook

TABLE OF CONTENTS
OVERVIEW
External Chassis Views 3
Motherboard Layout 4
MARKETING SYSTEM CONFIGURATIONS
Operating System, Chipset 5
Processor 6
Memory 7
Graphics/Video Controllers 8
Drives and Removable Storage 9
System Expansion Slots, External Ports/Connectors 10-11
Hard Drive Controller, Communications—Network Adapter, Audio and Speakers, Keyboard and Mouse 11
Security, Service and Support, Software 12
DETAILED ENGINEERING SPECIFICATIONS
System Dimensions (Physical), System Expansion Slots 13
System Level Environmental and Operating Conditions, Power 14-15
Audio—Integrated, Communications– Integrated LAN 16-17
Communications—Add in Network Interface Card (NIC) 17
Communications—Add in 1394 card, Add in Parallel / Serial Card 18
Graphics/Video Controllers 19-25
Hard Drives 26-35
Optical Drive 34-35
Media Card Reader 36
BIOS Defaults 37
Chassis Enclosure and Ventilation Requirements 38
ADDITIONAL INFORMATION
Statement of Volatility (SOV) 39-41

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
3
EXTERNAL CHASSIS VIEWS
FRONT VIEW
1 power button, power light 6 USB 2.0 connectors (2)
2 optical drive bay
(optional)
7 Drive activity light
3 headphone connector 8 optical drive bay
(optional)
4 microphone connector 9 optical drive bay eject
button
5 USB 3.0 connectors (2)
BACK VIEW
10 power supply diagnostic
light
15 security-cable slot
12 power connector
13 back panel connectors
11 power supply diagnostic
button
16 padlock ring
14 expansion card slots (4)
1 PS2/mouse connector 8 PS/2 keyboard
connector
2 network link Integrity
light
9 USB 2.0 connectors (2)
3 network connector 10 DisplayPort connectors
(2)
4 network activity light 11 USB 3.0 connector (2)
BACK PANEL CONNECTORS
5 USB 2.0 connectors (2) 12 VGA connector
6 serial connector 13 Line-in/microphone
connector
7 line-out connector

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
4
Number Name Number Name
1 Internal Speaker Connector (INT_SPKR) 13 PCI-e 4x Connector(SLOT4)
2 Front IO Connector (FRONTPANEL) 14 Buzzer (BEEP)
3 Thermal Sensor Connector(THRM_2) 15 LPC Debug Connector (LPC_DEBUG)
4 SATA 0 Connector(SATA0)- SATA III 16 Intrusion Switch Connector (INTRUDER)
5 SATA 1 Connector(SATA1)- SATA III 17 System Fan Connector (FAN_HDD)
6 SATA 2 Connector(SATA2)- SATA II 18 P2 Power Connector(12V_PWRCONN)
7 SATA 3 Connector(SATA3)- SATA II 19 Processor Socket (N/A)
8 Internal USB Connector (INT_USB) 20 CPU fan Connector (FAN_CPU)
9 Battery Connector (BATTERY) 21 Memory Connectors(DIMM1, DIMM2, DIMM3, DIMM4)
10 PCI-e 16x Connector(SLOT1) 22 Power Switch Connector (PWR_SW)
11 PCI-e 1x Connector(SLOT2) 23 P1 Power Connector (POWER)
12 PCI Connector(SLOT3) 24 Front USB3.0 Connector (Front _USB )
MT System Board Components
MOTHERBOARD LAYOUT

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
5
MARKETING SYSTEM CONFIGURATIONS
NOTE: Oerings may vary by country. For more information regarding the configuration of your computer, click
Start>Help and Support and select the option to view information about your computer.
OPERATING SYSTEM
CHIPSET
Chipset Intel C216 Chipset
Non-volatile memory on chipset
BIOS Configuration SPI (Serial Peripheral Interface) 64Mbit (8MB) & 32Mbit (4MB)
TPM 1.2 Security Device (Trusted Platform Module)14KB
Non-TPM Available in select countries
NIC EEPROM LOM configuration contained within SPI_FLASH – no dedicated
LOM EEPROM
Windows 7® operating system—
Factory Installed
Microsoft® Windows 7® Professional (32 and 64 bit)
Microsoft® Windows 7® Ultimate (32 and 64 bit)
Windows XP® operating system Driver availability only via Dell.com
Microsoft® Windows XP® Professional (32 and 64 bit)
Red Hat Enterprise Linux RHEL workstation 6.2 Factory installed
RHEL 5.8 supported
Other FreeDOS drop in the box for (N-series),
Ubuntu® Linux version 11.10 (factory installed in China only)

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
6
PROCESSOR
NOTE: Global Standard Products (GSP) are a subset of Dell’s relationship products that are managed for availability and synchro-
nized transitions on a worldwide basis. They ensure the same platform is available for purchase globally. This allows customers to
reduce the number of configurations managed on a worldwide basis, thereby reducing their costs. They also enable companies
to implement global IT standards by locking in specific product configurations worldwide. The following GSP processors identi-
fied below will be made available to Dell customers.
NOTE: Processor numbers are not a measure of performance. Processor availability subject to change and may vary by region/
country.
NOTE: Intel Core i5/i7 processors can only be paired with Non-ECC memory.
Intel® Xeon Four Core Processors
Intel® Xeon E3-1290 v2
3.70GHz, 8M, 87W, HT, Turbo VT-x, VT-d, TXT (vPro™) X None
Intel® Xeon E3-1280 v2
3.60GHz, 8M, 69W, HT, Turbo VT-x, VT-d, TXT (vPro™) X None
Intel® Xeon E3-1270 v2
3.50GHz, 8M, 69W, HT, Turbo VT-x, VT-d, TXT (vPro™) X None
Intel® Xeon E3-1240 v2
3.40GHz, 8M, 69W, HT, Turbo VT-x, VT-d, TXT (vPro™) X—GSP None
Intel® Xeon E3-1225 v2
3.30GHz, 8M, 77W, Turbo VT-x, VT-d, TXT (vPro™) X Intel HD P4000 Graphics
Intel® Xeon E3-1220 v2
3.10GHz, 8M, 69W, Turbo VT-x, VT-d, TXT (vPro™) X—GSP None
Intel® Core Four Core Processors
Intel® Core i7-3770
3.40GHz, 8M, 77W, Turbo VT-x, VT-d, TXT (vPro™) X—GSP Intel HD 4000 Graphics
Intel® Core i5-3550
3.30GHz, 6M, 77W, Turbo VT-x, VT-d, TXT (vPro™) X—GSP Intel HD 2500 Graphics
Intel® Core i5-3470*
3.20GHz, 6M, 77W, Turbo VT-x, VT-d, TXT (vPro™) X—GSP Intel HD 2500 Graphics
Intel® Core Two Core Processors
Intel® Core i3-2130
3.4GHz, 3M, 65W, HT VT-x XIntel HD 2000 Graphics
Intel® Core i3-2120
3.30GHz, 3M, 65W, HT VT-x XIntel HD 2000 Graphics
Integrated Graphics Support

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
7
MEMORY
NOTE: The Dell Precision T1650 has a dual channel memory bus architecture. Dell recommends that two memory channels be
populated with DIMMS for maximum memory performance. Please note, UDIMM ECC and NECC memory cannot be mixed.
NOTE: Maximum memory speed is tied to processor. 1600 MHz memory will run at a reduced speed of 1333 MHz when paired
with the Intel® Core i3-2120 or Intel® Core i3-2130 processors.
1 The total amount of available memory will be less than 4GB on systems running 32-bit operating systems. The amount less depends on the actual
system configuration. To fully utilize 4GB or more of memory requires a 64-bit operating system.
Type: DDR3 Synch DRAM Non-ECC and ECC
Max Frequency 1600 MHz
DIMM Slots 4
DIMM Capacities Up to 8GB
Minimum Memory 2GB
Maximum System Memory 32GB
Memory configurations
ECC UDIMM Memory
32GB (4 x 8 GB) DDR3, 1600 MHz X
16GB (4 x 4 GB) DDR3, 1600 MHz X
8GB (2 x 4 GB) DDR3, 1600 MHz X
8GB (4 x 2 GB) DDR3, 1333 MHz X
4GB1(2 x 2 GB) DDR3, 1600 MHz, X
4GB1(2 x 2 GB) DDR3, 1333 MHz, X
Non- ECC Memory (NECC)
16GB (4 x 4GB) DDR3, 1600 MHz X
4GB1(2 x 2 GB) DDR3, 1600 MHz, X
2GB (1 x 2 GB) DDR3, 1600 MHz, X
8GB (2 x 4 GB) DDR3, 1600 MHz X
8GB (4 x 2 GB) DDR3, 1600 MHz X
8GB (4 x 2 GB) DDR3, 1600 MHz X

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
8
GRAPHICS/VIDEO CONTROLLER
NOTE: System supports full height (FH) cards unless specified
NOTE: Dual Graphic options available on NVIDIA NVS 300
Optional Graphic/Video Options Included Dongle
Mid-range 3D
1.0GB NVIDIA Quadro 2000 with (2) DP and (1) DVI (1) DP–DVI, (1) DVI-VGA
Entry 3D
1.0GB NVIDIA Quadro 600 with (1) DP and (1) DVI (1) DP–DVI, (1) DVI-VGA
1.0GB AMD FirePro V4900 with (2) DP and (1) DVI 1) DP–DVI, (1) DVI-VGA
Professional 2D
512MB NVIDIA NVS 300 with (1) DMS-59 (1) DMS-59–Dual DVI
512MB AMD FirePro 2270 with (1) DMS-59 (1) DMS-59–Dual DVI
Integrated Graphic*
Integrated Intel® HD Graphics P4000 with (2) DP + (1 )VGANone included
Integrated Intel® HD Graphics 4000 with (2) DP + (1 )VGANone included
Integrated Intel® HD Graphics 2000 with (1) DP + (1 )VGANone included
Integrated Intel® HD Graphics 2500 with (2) DP + (1 )VGANone included
*NOTE: Intel Integrated Graphics is only available on select processors. The specific processor determines which type of inte-
grated graphics is available..

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
9
DRIVES AND REMOVABLE STORAGE
Bays:
5.25-inch Optical Bay Supported (External) 2
Optical Drives Supported (maximum) 2
Hard Drive Bay Supported (Internal) 4 (2x 3.5” or 4x 2.5”)
Hard Drives Supported 3.5”/2.5” (maximum) 2/4
Interface:
SATA 2.0 (optical) 2
SATA 3.0 2
3.5” Hard Drives:
2TB1SATA 7200 RPM HDD X
1TB1SATA 7200 RPM HDD X
500GB1SATA 7200 RPM HDD X
250GB1SATA 7200 RPM HDD X
2.5” Hard Drives:
256GB1SATA Solid State Drive X
500GB1SATA 7200 RPM HDD X
320GB1OPAL SED with FIPS SATA 7200 RPM HDD X
32GB1mSATA SSD2 X-Part of Intel Smart Response Technology
1For hard drives, GB means 1 billion bytes; actual capacity varies with preloaded material and operating environment and will be less.
2 Please note that the 32GB mSATA is part of the Intel Smart Response Technology (SRT) and must be purchased with additional Hard Drive(s). The
mSATA SSD is installed in a 2.5” carrier.

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
10
DRIVES AND REMOVABLE STORAGE (CON’T)
SYSTEM EXPANSION SLOTS
NOTE: See Detailed Engineering Specifications for supported voltage, maximum wattage and card dimensions.
PCIe x16 Slot Gen 3 1
PCIe x16 (wired x4) Slot Gen 2 1
PCIe x1 Slot Gen 2 1
PCI 32/33 Slot 1
Serial ATA (SATA) connectors 4
Optical Drive:
5.25” Blu-ray Writer SATA 1.5Gbit/s X
Slimline Blu-ray Writer SATA 1.5Gbit/s X
Slimline DVD+/-RW1 SATA 1.5Gbit/s X
Slimline DVD-ROM2 SATA 1.5Gbit/s X
Media Card Reader:
Dell 19 in 1 Media Card Reader X
5.25” DVD+/-RW1 SATA 1.5Gbit/s X
5.25” DVD-ROM2 SATA 1.5Gbit/s X
EXTERNAL PORTS/CONNECTORS
NOTE: See chassis diagrams section for port/connector locations
USB 3.0 2 Front, 2 Rear
USB 2.0 2 Front, 4 Rear, 2 Internal
Serial 1 Rear (2nd via optional Add in Card)
Network Connector (RJ-45) 1 Rear
PS/2 2 Rear
1394 Controller via optional PCI card Optional via Add in Card
Parallel Optional via Parallel / Serial Add in Card
1 Discs burned with this drive may not be compatible with some existing drives and players; using DVD+R media provides maximum compatibility.
2 DVD-ROM drives may have write-capable hardware that has been disabled via firmware modifications.
NOTE: Dell 19 in 1 Media Card Reader (MCR) is supported via a F5 to F3 bay converter in the 5.25” Optical Drive Bay.
NOTE: Slimline Optical drives can only be configured when a Memory Card Reader is configured.

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
11
Intel® 82579 Gigabit Ethernet LAN 10/100/10001Integrated on system board
Broadcom NetXtreme 10/100/1000 PCIe Gigabit1Networking
Card Optional card
1This term does not connote an actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and
network infrastructure is required.
Realtek ALC269Q High Definition Audio Codec Integrated on system board
Internal Chassis Speaker Optional
Dell AX210 2.0 Desktop Speakers Optional
Dell AX510/AX510PA Flat Panel Soundbar Speakers Optional
AUDIO AND SPEAKERS
KEYBOARD AND MOUSE
COMMUNICATIONS - NETWORK ADAPTER (NIC)
Dell USB Entry Keyboard Optional
Dell Multimedia Pro Keyboard Optional
Dell Smartcard Keyboard Optional
Dell USB Optical Mouse Optional
Dell Laser Mouse Optional
Intel Rapid Storage Controller 11.0 supporting SATA 6Gb/s (2
ports– SATA0, SATA1), host based RAID 0/1/5/10 Integrated
HARD DRIVE CONTROLLER
EXTERNAL PORTS/CONNECTORS (CONT.)
NOTE: See chassis diagrams section for port/connector locations
Audio:
Line in for microphone 1 Front
Line in for microphone or stereo 1 Rear
Line out for headphones or speakers 1 Front, 1 Rear

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
12
SECURITY
SERVICE AND SUPPORT
NOTE: For more details on Dell Service Plans please to go to: www.dell.com/service/service_plans
SOFTWARE
Trusted Platform Module (TPM) 1.21Integrated on system board
Chassis Intrusion Switch Optional
Dell Smartcard Keyboard Optional
Chassis lock slot and loop support Standard
Dell Data Protection | Encryption Accelerator Card Optional
1TPM is not available in all countries. Depending on your country regulations, no-TPM system boards may be available.
1 Year Warranty1 Next Business Day On-site2(3-3-3) Standard
ProSupport Optional
1For a copy of our guarantees or limited warranties, please write Dell USA L.P., Attn: Warranties, One Dell Way, Round Rock, TX 78682. For more
information, visit www.dell.com/warranty.
2Service may be provided by third-party. Technician will be dispatched if necessary following phone-based troubleshooting. Subject to parts
availability, geographical restrictions and terms of service contract. Service timing dependent upon time of day call placed to Dell. U.S. only.
Dell Data Protection | Access (DDPA) Standard
Dell Data Protection | Encryption (DDPE) Optional

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
13
DETAILED ENGINEERING SPECIFICATIONS
SYSTEM DIMENSIONS (PHYSICAL)
NOTE: System Weight and Shipping Weight is based on a typical configuration and may vary based on PC configuration. A typical configuration
includes: one graphics card one hard drive, one optical drive.
SYSTEM EXPANSION SLOTS
Chassis Volume (liters) 27.4 l
Chassis Weight (pounds/kilograms) 20.37 lbs / 9.24 kg
Chassis Dimensions: (HxWxD)
Height (inches/centimeters) 14.17 in. / 36.0 cm
Width (inches/centimeters) 6.89 in. / 17.5 cm
Depth (inches/centimeters) 17.13 in. / 43.5 cm
Shipping Weight (pounds/kilograms - includes packaging materials) 26.2 lbs / 11.88 kg
Packaging Parameters (HxWxD)
Height (inches/centimeters) 22.44 in. / 57 cm
Width (inches/centimeters) 18.75 in. / 47.6 cm
Depth (inches/centimeters) 14.09 in. / 35.8 cm
` Type Voltage supported Max Height
(in,cm)
Max Length (in,
cm)
Max Watt-
age Cards supported
1 PCIe x16 Gen3 3.3V/12V Standard Height
4.38 in / 11.13 cm
Half Length
6.6 in / 16.77 cm
75* Graphics, Gigabit NIC,
Parallel / Serial
2 PCIe x1 3.3V/12V Standard Height
4.38 in / 11.13 cm
Half Length
6.6 in / 16.77 cm
25 Gigabit NIC, Parallel /
Serial
3 PCI 3.3V/5V/12V/-12V Standard Height
4.38 in / 11.13 cm
Half Length
6.6 in / 16.77 cm
25 1394
4 PCIe x16 (x 4) Gen2 3.3V/12V Standard Height
4.38 in / 11.13 cm
Half Length
6.6 in / 16.77 cm
75* Graphics, Gigabit NIC,
Parallel / Serial
*Please note that total power consumption for both Slot 1 + Slot 4 <= 100W.
NOTE: Slot 1 is default for factory installed graphics card.

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
14
SYSTEM LEVEL ENVIRONMENTAL AND OPERATING CONDITIONS
Temperature
Operating 10° to 35° C (50° to 95° F)
Non-Operating (Storage) -40° to 60° C (-40° to 140° F)
Relative Humidity 20% to 80% (non-condensing)
Maximum vibration
Operating 0.25 G at 3 to 200 Hz at 0.5 octave/min
Non-Operating 0.5 G at 3 to 200 Hz at 1 octave/min
Maximum Shock
Operating Bottom half-sine pulse with a change in velocity
of 50.8 cm/sec (20 inches/sec)
Non-Operating 27-G faired square wave with a velocity change
of 508 cm/sec (200 inches/sec)
Maximum Altitude
Operating –15.2 to 3048 m (–50 to 10,000 ft)
Non-Operating –15.2 to 10,668 m (–50 to 35,000 ft)
POWER
NOTE: These form factors utilize a more ecient Active Power Factor Correction (APFC) power supply. Dell recommends only Universal Power
Supplies (UPS) based on Sine Wave output for APFC PSUs, not an approximation of a Sine Wave, Square Wave, or quasi-Square Wave. If you
have questions, please contact the manufacture to confirm the output type.
Entry Upsell
Power Supply Wattage 275W 320W
AC input Voltage
Range 90 – 264Vac 90 – 264Vac
AC input current (low
ac range/high AC
range)
5.0A / 2.5A 5.0A / 2.5A
AC input Frequency 47Hz /63Hz 47Hz / 63Hz
AC holdup time (80%
load) 16 MSEC 16 MSEC
Average Eciency
(ENERGY STAR 5.2
qualified)
87 – 90 – 87% @ 20 – 50 – 100% load
Typical Eciency
(Active PFC) 65%

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
15
POWER (CONT)
Entry Upsell
DC parameters
+12.0v output 12VA,17.0A;
12VB, 10.0A
12VA,17.0A;
12VB, 1030A
+5.0v auxiliary output 4.0A 4.0A
-12.0v output 0.5A 0.5A
Max total power 275W 320W
BTUs/h (based on PSU
max wattage) 938BTU 1093 BTU
Power Supply Fan 80*25mm 80*25mm
Compliance:
1watt requirement Yes Yes
80Plus Compliant No Yes—GOLD
FEMP (CECP) Standby
Power Compliant Yes Yes
Brand Type Voltage Composition Life
PANASONIC CR-2302L/BE 3V Lithium Continuous Discharge Under 15 kΩLoad to 2.5V End-
Voltage: 1100 hours or longer
MITSUBISHI CR2302 3V Lithium
Manganese
Dioxide
Continuous Discharge Under 15 kΩLoad to 2.5V End-
Voltage: 1000 hours or longer
3.0V CMOS BATTERY

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
16
AUDIO—INTEGRATED
COMMUNICATIONS—INTEGRATED LAN
REALTEK ALC269 HIGH DEFINITION AUDIO
High Definition Stereo support X
Number of channels 2
Number of Bits / Audio resolution 16, 20, and 24-bit resolution
Sampling rate (recording/playback) Support 44.1K/48K/96K/192 kHz sample rates
Signal to Noise Ratio 98 dB DAC outputs, 90 dB for ADC inputs
Analog Audio X
Dolby Digital
THX
Digital out (S/PDIF)
Audio Jack Impedance
Microphone 40K ohm~60K ohm
Line-In 40K ohm~60K ohm
Line-Out 100~150 ohm
Headphone 1~4 ohm
Internal Speaker Power Rating 2Watt (peak) / 1Watt (average)
INTEL® 82579 GIGABIT ETHERNET LAN 10/100/10001
External Connector Type RJ45
Data Rates supported 10/100/1000 Mbps
Controller Details
Controller bus architecture PCIe-based interface for S0 state, SMBus for Sx
low power state
Integrated memory N/A
Data transfer mode (example Bus-Master DMA) N/A
Power consumption (full operation per data rate connection speed) 711mW (Max.)
Power consumption (standby operation) 227mW (Max.)
IEEE standards compliance (example 802.1P) 802.3
Hardware Certifications (example FCC, B, GS mark…) N/A
Boot ROM Support EEPROM (located in SPI)
Network Transfer Mode (example Full Duplex, Half Duplex)
Network Transfer Rate (example 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps
10 Mb (full/half-duplex)
100 Mb (full/half-duplex)
1000 Mb (full-duplex)
1This term does not connote an actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and
network infrastructure is required.

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
17
COMMUNICATIONS—INTEGRATED LAN (CONT.)
1This term does not connote an actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and
network infrastructure is required.
INTEL® 82579 GIGABIT ETHERNET LAN 10/100/10001(CONT.)
Environmental
Operating temperature 0° C to 85° C (32° F to 185° F)
Operating humidity 20% to 80% (non-condensing)
Operating System Driver Support Windows 7 32/64, Vista 32/64
Manageability (examples WOL, PXE) WOL, PXE 2.1
Management Capabilities Alerting Intel® Standard Manageability, Intel Xeon Pro-
cessor with vPro Technology
Broadcom NetXtreme 10/100/1000 PCIe Gigabit1Networking Card
Connector Type RJ45
Data Rates supported 10/100/1000 Mbps Half/Full duplex
Controller Details
Controller bus architecture (example PCIe 1.0a x1) PCIe c1.0a x1
Data transfer mode (example Bus-Master DMA) Bus-Master DMA
Power consumption (full operation per data rate connection speed) 2.84W (860mA @ +3.3V)
Power consumption (standby operation) Less than 300mW
IEEE standards compliance (example 802.1P) 802.3, 802.2, 802.3x, 802.1p
Hardware Certifications (example FCC, B, GS mark…) FCC B, VCCI B, CE
Boot ROM Support No
Network Transfer Mode (example Full Duplex, Half Duplex)
Network Transfer Rate (example 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps
10BASE-T (full-duplex) 20 Mbps Max*
100BASE-TX (half-duplex) 100 Mbps Max*
100BASE-TX (full-duplex) 200 MbpsMax*
1000BASE-T (full-duplex) 2000 Mbps Max*
* Depends on the system environment.
Integrated memory 64KBytes RX, 8KBytes TX
Environmental
Operating temperature 0° C to 55° C (32° F - 131° F)
Operating humidity 5% ~ 85% (non-condensing)
Operating System Driver Support Windows® 7 32- & 64-bit, Windows Vista® 32–
and 64-bit, Linux
Manageability (examples WOL, PXE) WOL, PXE2.1, ACPI
Management Capabilities Alerting (example ASF 2.0) None
COMMUNICATIONS—ADD IN NETWORK INTERFACE CARD (NIC)

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
18
1394 FIREWIRE PCI ADD IN CARD
Connector Type PCI 2.3
Controller Details
Controller bus architecture (example PCIe 1.0a x1) PCI 2.3
IO Ports 2 External 1394a 6-pin connectors
1 Internal 1394a 10-pin header
Power Consumption Under 30 mA
Connector 1394a
OS Support Win XP, Win Vista and Win 7
COMMUNICATIONS—ADD IN 1394 CARD
SERIAL / PARALLEL PORT PCIE ADD-IN CARD
Connector Type RS-232 and IEEE1284
Data Rates supported 50bps ~115.2Kbps(Serial)&Maximum 1.8MBp(Parallel)
Controller Details
Controller bus architecture (example PCIe 1.0a x1) PCI Express one lane (x1)
Driver Support
Microsoft Client XP/Vista/7 (X86/X64)
Microsoft Server 2000/2003/2008 (X86/X64)
Microsoft Embedded XP Embedded/POS Ready 2009/
Embedded System 2009
Linux Linux 2.4.x/2.6.x
DOS DOS
Full height Serial / Parallel add-in card
Environment
Operation Temperature 0 to 60°C (32 to 140°F)
Operation Humidity 5 to 95% RH
Storage Temperature -20 to 85°C (-4 to 185°F)
Optional
COMMUNICATIONS—ADD IN SERIAL / PARALLEL PORT CARD

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
19
GRAPHICS/VIDEO CONTROLLER
INTEGRATED INTEL HD P4000 / 4000 GRAPHICS*
Bus Type (example integrated or PCIe x16) Integrated
GPU core clock 650 MHz
Frame Buffer Memory (onboard and shared) Size and Speed Dynamically shared system memory
Maximum power consumption N/A, see processor TDP
Maximum Color Depth 32 bit RGB (True Color)
Maximum Vertical Refresh Rate 75 Hz
Multiple Display Support Yes
Operating Systems Graphics/ Video API Support
Microsoft Windows 7, Vista, XP all with 32bit and
64Bit. Redhat Linux, Open CL 1.1, Open GL 3.1,
DirectX 11
Supported Resolutions and Max Refresh Rates (Hz) (Note: Analog and/or
digital)
DisplayPort Max 2 digital displays at up to 2560 X
1600 @60Hz; VGA Max up to : 1920 x 1200 @ 60Hz
External connectors (2) DP, (1) VGA
DisplayPort
Bus Type DDPC
DisplayPort Audio Support Yes
Bus Type CRT
CRT Audio Support No
VGA
*Only available on select Intel Xeon processors

DELL™ PRECISION™ T1650 TECHNICAL GUIDEBOOK
20
GRAPHICS/VIDEO CONTROLLER
*Only available on select Intel Core processors
INTEGRATED INTEL HD 2000/2500 GRAPHICS*
Bus Type (example integrated or PCIe x16) Integrated
GPU core clock 650 MHz (HD 2500) / 850 MHz (HD 2000)
Frame Buffer Memory (onboard and shared) Size and Speed Dynamically shared system memory
Maximum power consumption N/A, see processor TDP
Maximum Color Depth 32 bit RGB (True Color)
Maximum Vertical Refresh Rate 75 Hz
Multiple Display Support Yes
Operating Systems Graphics/ Video API Support
Microsoft Windows 7, Vista, XP all with 32bit and
64Bit. Redhat Linux, Open CL 1.1, Open GL 3.1,
DirectX 11
Supported Resolutions and Max Refresh Rates (Hz) (Note: Analog and/or
digital)
DisplayPort Max 2 digital displays at up to 2560 X
1600 @60Hz; VGA up to : 1920 x 1200 @ 60Hz
External connectors (2) DP, (1) VGA
DisplayPort
Bus Type DDPC
DisplayPort Audio Support Yes
Bus Type CRT
CRT Audio Support No
VGA
