Dell™ SmartPC™ 200N and 250N
Owner’s Manual
7T097bk1.book Page 1 Thursday, September 26, 2002 6:47 AM

Hints, Notices, and Cautions
HINT: A HINT indicates important information that helps you make better
use of your computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of
data and tells you how to avoid the problem.
CAUTION: A CAUTION indicates a potential for property damage,
personal injury, or death.
Abbreviations and Acronyms
For a complete list of abbreviations and acronyms, see the Te ll M e H o w help
file (click the Start button on the Microsoft®Windows®desktop, point to
Help and Support→User’s Guides, and then click Tell Me How).
____________________
Information in this document is subject to change without notice.
© 2002 Dell Computer Corporation. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Computer
Corporation is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, Inspiron, Dell Precision, Dimension, OptiPlex,
Latitude, DellNet, TrueMobile, and SmartStep are trademarks of Dell Computer Corporation; Intel,
Celeron,and Pentium are registered trademarks of Intel Corporation; Microsoft and Windows are
registered trademarks of Microsoft Corporation; EMC is the registered trademark of EMC
Corporation.
Othertrademarksandtradenamesmaybeusedinthisdocumenttorefertoeithertheentitiesclaiming
themarksandnamesortheirproducts.DellComputerCorporationdisclaimsanyproprietaryinterest
in trademarks and trade names other than its own.
Model PP06L
September 2002 P/N 7T097 Rev. A01
7T097bk1.book Page 2 Thursday, September 26, 2002 6:47 AM

Contents 3
Contents
CAUTION: Safety Instructions . . . . . . . . . . . . . . . . . . . 7
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Air Travel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
EMC Instructions . . . . . . . . . . . . . . . . . . . . . . . . 10
When Using Your Computer . . . . . . . . . . . . . . . . . . . . 11
Ergonomic Computing Habits . . . . . . . . . . . . . . . . . . 12
When Working Inside Your Computer . . . . . . . . . . . . . . 12
Protecting Against Electrostatic Discharge . . . . . . . . . . . 13
Battery Disposal . . . . . . . . . . . . . . . . . . . . . . . . 13
1Information Resources
Finding Information and Assistance . . . . . . . . . . . . . . . . 16
2Setting Up and Using Your Computer
A Tour of Your Computer . . . . . . . . . . . . . . . . . . . . . . 20
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Left View . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Right View . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Back View . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Bottom View . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Setting Up a Printer . . . . . . . . . . . . . . . . . . . . . . . . 26
Printer Cable . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Connecting a Parallel Printer . . . . . . . . . . . . . . . . . . 26
7T097bk1.book Page 3 Thursday, September 26, 2002 6:47 AM

4Contents
Connecting a USB Printer . . . . . . . . . . . . . . . . . . . 27
Installing the Printer Driver . . . . . . . . . . . . . . . . . . 28
Printer Problems . . . . . . . . . . . . . . . . . . . . . . . . . 29
Transferring Information to a New Computer With
Microsoft®Windows®XP . . . . . . . . . . . . . . . . . . . . . 29
Setting Up a Home and Office Network With Windows XP. . . . 30
Connecting to the Internet . . . . . . . . . . . . . . . . . . . . 30
Setting Up Your Internet Connection . . . . . . . . . . . . . . 31
Copying CDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Using Easy CD Creator Basic . . . . . . . . . . . . . . . . . 33
Using Blank CD-R Discs or Blank CD-RW Discs . . . . . . . . 33
Helpful Tips . . . . . . . . . . . . . . . . . . . . . . . . . . 33
How to Copy a CD . . . . . . . . . . . . . . . . . . . . . . . 34
3How Do I?
Turning On Your Computer . . . . . . . . . . . . . . . . . . . . 38
Turning Off Your Computer . . . . . . . . . . . . . . . . . . . . 38
Power Problems . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Installing and Removing a Battery . . . . . . . . . . . . . . . . 39
Installing a Battery . . . . . . . . . . . . . . . . . . . . . . 39
Removing a Battery . . . . . . . . . . . . . . . . . . . . . . 40
Storing a Battery . . . . . . . . . . . . . . . . . . . . . . . 40
Swapping Modules in the Module Bay . . . . . . . . . . . . . . 40
Playing a CD or Movie . . . . . . . . . . . . . . . . . . . . . . . 40
Connecting a Television to the Computer . . . . . . . . . . . . . 41
S-Video Connection . . . . . . . . . . . . . . . . . . . . . . 42
Enabling the Display Settings for a Television . . . . . . . . . 44
7T097bk1.book Page 4 Thursday, September 26, 2002 6:47 AM

Contents 5
Using the Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . 45
Numeric Keypad . . . . . . . . . . . . . . . . . . . . . . . . 45
Easy-Launch Keys . . . . . . . . . . . . . . . . . . . . . . . . 46
Keyboard Shortcuts . . . . . . . . . . . . . . . . . . . . . . . 47
4Maintaining Your Computer
Using Microsoft®Windows®System Restore . . . . . . . . . . . 50
Creating a Restore Point . . . . . . . . . . . . . . . . . . . . 51
Restoring the Computer to an Earlier Operating State . . . . . . 51
Undoing the Last System Restore . . . . . . . . . . . . . . . . 52
Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
What Is a Driver? . . . . . . . . . . . . . . . . . . . . . . . . 53
Identifying Drivers . . . . . . . . . . . . . . . . . . . . . . . 53
Reinstalling Drivers . . . . . . . . . . . . . . . . . . . . . . . 54
Manually Reinstalling Drivers for Windows XP . . . . . . . . . 55
Resolving Software and Hardware Incompatibilities . . . . . . . 56
Reinstalling Microsoft®Windows®XP . . . . . . . . . . . . . . . 57
Before You Reinstall . . . . . . . . . . . . . . . . . . . . . . 57
Reinstalling Windows XP . . . . . . . . . . . . . . . . . . . . 57
Reinstalling Drivers and Software . . . . . . . . . . . . . . . . 60
5Adding and Replacing Parts
Adding Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Replacing the Hard Drive . . . . . . . . . . . . . . . . . . . . . . 66
Returning a Hard Drive to Dell . . . . . . . . . . . . . . . . . 68
7T097bk1.book Page 5 Thursday, September 26, 2002 6:47 AM

6Contents
6Appendix
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
BIOS and Standard Settings . . . . . . . . . . . . . . . . . . . 76
Viewing the System Setup Screens . . . . . . . . . . . . . . . 76
System Setup Screens . . . . . . . . . . . . . . . . . . . . . 76
Commonly Used Options . . . . . . . . . . . . . . . . . . . . 77
Returning Items for Warranty Repair or Credit . . . . . . . . . . 78
Before You Call . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Contacting Dell . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Regulatory Notices . . . . . . . . . . . . . . . . . . . . . . . . 96
Limited Warranties and Return Policy . . . . . . . . . . . . . . 97
Limited Warranty Terms for Canada . . . . . . . . . . . . . . 97
"Total Satisfaction" Return Policy . . . . . . . . . . . . . . . . 101
Dell Software and Peripherals . . . . . . . . . . . . . . . . . 102
Intel®Warranty Statement for Pentium®and
Celeron®Processors Only (U.S. and Canada Only) . . . . . . . 103
7T097bk1.book Page 6 Thursday, September 26, 2002 6:47 AM

CAUTION: Safety Instructions 7
CAUTION: Safety Instructions
Use the following safety guidelines to help ensure your own personal safety and to help protect
your computer and working environment from potential damage.
General
• Do not attempt to service the computer yourself unless you are a trained service
technician. Always follow installation instructions closely.
• If you use an extension power cable with your AC adapter, ensure that the total ampere
rating of the products plugged in to the extension power cable does not exceed the
ampere rating of the extension cable.
• Do not push objects into air vents or openings of your computer. Doing so can cause fire
or electric shock by shorting out interior components.
• Do not store your computer in a low-airflow environment, such as a carrying case or a
closed briefcase, while the computer is turned on. Restricting airflow can damage the
computer or cause a fire.
• Keep your computer away from radiators and heat sources. Also, do not block cooling
vents. Avoid placing loose papers underneath your computer; do not place your computer
in a closed-in wall unit or on a bed, sofa, or rug.
• Place the AC adapter in a ventilated area, such as a desk top or on the floor, when you use
it to run the computer or to charge the battery. Do not cover the AC adapter with papers
or other items that will reduce cooling; also, do not use the AC adapter inside a carrying
case.
• The AC adapter may become hot during normal operation of your computer. Use care
when handling the adapter during or immediately after operation.
• Do not allow your portable computer to operate with the base resting directly on exposed
skin for extended periods of time. The surface temperature of the base will rise during
normal operation (particularly when AC power is present). Allowing sustained contact
with exposed skin can cause discomfort or, eventually, a burn.
• Do not use your computer in a wet environment, for example, near a bath tub, sink, or
swimming pool or in a wet basement
• If your computer includes an integrated or optional (PC Card) modem, disconnect the
modem cable if an electrical storm is approaching to avoid the remote risk of electric
shock from lightning via the telephone line.
7T097bk1.book Page 7 Thursday, September 26, 2002 6:47 AM

8CAUTION: Safety Instructions
www.dell.com | support.dell.com
• To help avoid the potential hazard of electric shock, do not connect or disconnect any
cables or perform maintenance or reconfiguration of this product during an electrical
storm. Do not use your computer during an electrical storm unless all cables have been
disconnected and the computer is operating on battery power.
• If your computer includes a modem, the cable used with the modem should be
manufactured with a minimum wire size of 26 American wire gauge (AWG) and an FCC-
compliant RJ-11 modular plug.
• Before you open the memory module/Mini PCI card/modem cover on the bottom of your
computer, disconnect all cables from their electrical outlets and disconnect the telephone
cable.
• If your computer has a modem RJ-11 connector and a network RJ-45 connector, insert the
telephone cable into the RJ-11 connector, not the R-45 connector.
• PC Cards may become very warm during normal operation. Use care when removing PC
Cards after their continuous operation.
• Before you clean your computer, disconnect the computer from the electrical outlet.
Clean your computer with a soft cloth dampened with water. Do not use liquid or aerosol
cleaners, which may contain flammable substances.
Power
• Use only the Dell-provided AC adapter approved for use with this computer. Use of
another AC adapter may cause a fire or explosion.
• Before you connect the computer to an electrical outlet, check the AC adapter voltage
rating to ensure that the required voltage and frequency match the available power
source.
• To remove the computer from all power sources, turn the computer off, remove the
battery pack, and disconnect the AC adapter from the electrical outlet.
• To help prevent electric shock, plug the AC adapter and device power cables into properly
grounded power sources. These power cables may be equipped with 3-prong plugs to
provide an earth grounding connection. Do not use adapter plugs or remove the
grounding prong from the power cable plug. If you use a power extension cable, use the
appropriate type, 2-prong or 3-prong, to mate with the AC adapter power cable.
• Be sure that nothing rests on your AC adapter’s power cable and that the cable is not
located where it can be tripped over or stepped on.
CAUTION: Safety Instructions (continued)
7T097bk1.book Page 8 Thursday, September 26, 2002 6:47 AM

CAUTION: Safety Instructions 9
• If you are using a multiple-outlet power strip, use caution when plugging the AC
adapter’s power cable into the power strip. Some power strips may allow you to insert the
plug incorrectly. Incorrect insertion of the power plug could result in permanent damage
to your computer, as well as risk of electric shock and/or fire. Ensure that the ground
prong of the power plug is inserted into the mating ground contact of the power strip.
Battery
• Use only Dell™ battery modules that are approved for use with this computer. Use of
other types may increase the risk of fire or explosion.
• Do not carry a battery pack in your pocket, purse, or other container where metal objects
(such as car keys or paper clips) could short-circuit the battery terminals. The resulting
excessive current flow can cause extremely high temperatures and may result in damage
to the battery pack or cause fire or burns.
• The battery poses a burn hazard if you handle it improperly. Do not disassemble it.
Handle a damaged or leaking battery pack with extreme care. If the battery is damaged,
electrolyte may leak from the cells and may cause personal injury.
• Keep the battery away from children.
• Do not store or leave your computer or battery pack near a heat source such as a radiator,
fireplace, stove, electric heater, or other heat-generating appliance or otherwise expose it
to temperatures in excess of 60ºC (140ºF). When heated to excessive temperatures,
battery cells could explode or vent, posing a risk of fire.
• Do not dispose of your computer’s battery in a fire or with normal household waste.
Battery cells may explode. Discard a used battery according to the manufacturer’s
instructions or contact your local waste disposal agency for disposal instructions. Dispose
of a spent or damaged battery promptly.
CAUTION: Safety Instructions (continued)
7T097bk1.book Page 9 Thursday, September 26, 2002 6:47 AM

10 CAUTION: Safety Instructions
www.dell.com | support.dell.com
Air Travel
• Certain Federal Aviation Administration regulations and/or airline-specific restrictions
may apply to the operation of your Dell computer while you are on board an aircraft. For
example, such regulations/restrictions may prohibit the use of any personal electronic
device (PED) that has the capacity for intentional transmission of radio frequency or
other electromagnetic signals while on an aircraft.
– In order to best comply with all such restrictions, if your Dell portable computer is
equipped with Dell TrueMobile™ or some other wireless communication device,
please disable this device before you board the aircraft and follow all instructions
provided by airline personnel with regard to such device.
– Additionally, the use of any PED, such as a portable computer, may be prohibited in
aircraft during certain critical phases of flight, for example, takeoff and landing. Some
airlines may further define the critical flight phase as any time the aircraft is below
3050 m (10,000 ft). Please follow the airline’s specific instructions as to when the use
of a PED is allowed.
EMC Instructions
Use shielded signal cables to ensure that you maintain the appropriate EMC classification for
the intended environment. For parallel printers, a cable is available from Dell. If you prefer, you
can order a cable from Dell at its worldwide website at www.dell.com.
Static electricity can harm electronic components inside your computer. To prevent static
damage, discharge static electricity from your body before you touch any of your computer’s
electronic components, such as a memory module. You can do so by touching an unpainted
metal surface on the computer’s input/output panel.
CAUTION: Safety Instructions (continued)
7T097bk1.book Page 10 Thursday, September 26, 2002 6:47 AM

When Using Your Computer 11
When Using Your Computer
Observe the following safe-handling guidelines to prevent damage to your computer:
• When setting up the computer for work, place it on a level surface.
• When traveling, do not check the computer as baggage. You can put your computer
through an X-ray security machine, but never put your computer through a metal
detector. If you have the computer checked by hand, be sure to have a charged battery
available in case you are asked to turn on the computer.
• When traveling with the hard drive removed from the computer, wrap the drive in a
nonconducting material, such as cloth or paper. If you have the drive checked by hand, be
ready to install the drive in the computer. You can put the hard drive through an X-ray
security machine, but never put the drive through a metal detector.
• When traveling, do not place the computer in overhead storage compartments where it
could slide around. Do not drop your computer or subject it to other mechanical shocks.
• Protect your computer, battery, and hard drive from environmental hazards such as dirt,
dust, food, liquids, temperature extremes, and overexposure to sunlight.
• When you move your computer between environments with very different temperature
and/or humidity ranges, condensation may form on or within the computer. To avoid
damaging the computer, allow sufficient time for the moisture to evaporate before using
the computer.
NOTICE: When taking the computer from low-temperature conditions into a warmer environment
or from high-temperature conditions into a cooler environment, allow the computer to acclimate to
room temperature before turning on power.
• When you disconnect a cable, pull on its connector or on its strain-relief loop, not on the
cable itself. As you pull out the connector, keep it evenly aligned to avoid bending any
connector pins. Also, before you connect a cable make sure both connectors are correctly
oriented and aligned.
• Handle components with care. Hold a component such as a memory module by its edges,
not its pins.
• When preparing to remove a memory module from the system board or disconnect a
device from the computer, turn off the computer, disconnect the AC adapter cable, and
then wait 5 seconds before proceeding to help avoid possible damage to the system board.
7T097bk1.book Page 11 Thursday, September 26, 2002 6:47 AM

12 When Using Your Computer
www.dell.com | support.dell.com
• Clean the display with a soft, clean cloth and water. Apply the water to the cloth; then
stroke the cloth across the display in one direction, moving from the top of the display to
the bottom. Remove moisture from the display quickly and keep the display dry. Long-
term exposure to moisture can damage the display. Do not use a commercial window
cleaner to clean your display.
• If your computer gets wet or is damaged, follow the procedures described in the Tell Me
How help file. To access the help file, see page 17. If, after following these procedures, you
confirm that your computer is not operating properly, contact Dell (see "Contacting Dell"
on page 79 for the appropriate contact information).
Ergonomic Computing Habits
CAUTION: Improper or prolonged keyboard use may result in injury.
CAUTION: Viewing the display or external monitor screen for extended periods of
time may result in eye strain.
For comfort and efficiency, observe the ergonomic guidelines in the Tell Me How help file when
setting up and using your computer. To access the help file, see page 17.
This portable computer is not designed for continuous operation as office equipment. For
extended use in an office, Dell recommends that you connect an external monitor and an
external keyboard.
When Working Inside Your Computer
Before removing or installing memory modules, Mini PCI cards, or modems, perform the
following steps in the sequence indicated.
NOTICE: The only time you should ever access the inside of your computer is when you are
installing memory modules, a Mini PCI card, or a modem.
NOTICE: Wait 5 seconds after turning off the computer before disconnecting a device or removing
a memory module, Mini PCI card, or modem to help prevent possible damage to the system board.
1Shut down your computer and turn off any attached devices.
2Disconnect your computer and devices from electrical outlets to reduce the potential for
personal injury or shock. Also, disconnect any telephone or telecommunication lines from
the computer.
3Remove the main battery from the battery bay and, if necessary, the secondary battery
from the module bay.
When Using Your Computer (continued)
7T097bk1.book Page 12 Thursday, September 26, 2002 6:47 AM

When Using Your Computer 13
4Ground yourself by touching the unpainted metal surface of the I/O panel on the back of
the computer.
While you work, periodically touch the I/O panel to dissipate any static electricity that
might harm internal components.
Protecting Against Electrostatic Discharge
Static electricity can harm electronic components inside your computer. To prevent static
damage, discharge static electricity from your body before you touch any of your computer’s
electronic components, such as a memory module. You can do so by touching an unpainted
metal surface on the computer’s I/O panel.
As you continue to work inside the computer, periodically touch an I/O connector to remove
any static charge your body may have accumulated.
You can also take the following steps to prevent damage from electrostatic discharge (ESD):
• When unpacking a static-sensitive component from its shipping carton, do not remove
the component from the antistatic packing material until you are ready to install the
component. Just before unwrapping the antistatic packaging, be sure to discharge static
electricity from your body.
• When transporting a sensitive component, first place it in an antistatic container or
packaging.
• Handle all sensitive components in a static-safe area. If possible, use antistatic floor pads
and workbench pads.
Battery Disposal
Your computer uses lithium ion battery and a NiMH battery. For instructions about replacing
the lithium ion battery in your computer, refer to the section about replacing the battery in
your Dell computer documentation. The NiMH battery is a long-life battery, and it is very
possible that you will never need to replace it. However, should you need to replace it, the
procedure must be performed by an authorized service technician.
Do not dispose of the battery along with household waste. Contact your local waste disposal
agency for the address of the nearest battery deposit site.
When Using Your Computer (continued)
7T097bk1.book Page 13 Thursday, September 26, 2002 6:47 AM

14 When Using Your Computer
www.dell.com | support.dell.com
7T097bk1.book Page 14 Thursday, September 26, 2002 6:47 AM

SECTION 1
Information Resources
Finding Information and Assistance
7T097bk1.book Page 15 Thursday, September 26, 2002 6:47 AM

16 Information Resources
www.dell.com | support.dell.com
Finding Information and Assistance
The following table lists the resources that Dell provides as support tools.
Additional resources may be shipped with your computer.
Resource Contents Using the Resource
Drivers and Utilities CD
• Dell Diagnostics
• Drivers
• Utilities
• Computer and device
documentation
See the main menu on the Drivers and Utilities CD
that came with your computer. Use the pull-down
menu to make selections appropriate for your
computer.
Documentation and drivers are already installed on
your computer when shipped from Dell. You can use
this CD to access documentation or reinstall drivers.
You can also use the CD to run diagnostic tools if
you are unable to run the diagnostics located on your
hard drive.
Service and Registration Labels
•Express Service Code and Service
Tag Se quence
•Product Key (also called the
Product ID or Certificate of
Authenticity [COA])
The Express Service Code and Service Tag Sequence
are unique identifiers for your Dell™ computer.
You will need the Product Key (or Product ID)
number to complete the operating system setup.
Operating System CD To reinstall your operating system, use the Operating
System CD that came with your computer.
NOTE: The Operating System CD may not include
all the latest drivers for your computer. If you
reinstall your operating system, use the
Drivers and
Utilities
CD to reinstall drivers for the devices
shipped with your computer. Alternatively, you can
go to support.dell.com to obtain the latest drivers.
7T097bk1.book Page 16 Thursday, September 26, 2002 6:47 AM

Information Resources 17
Dell Tell Me How See the Tell Me How help file on your hard drive for
additional information about your computer.
NOTE: To access the
Tell Me How help file, click
the Start button, click Help and Support, click
User’s Guides, and then click Tell Me How.
Dell Support website
• Frequently asked questions
• Downloads for your computer
• Documentation
• Online discussions about your
computer
• Searchable database
Go to support.dell.com and complete the one-time
registration:
• Get help with general usage, installation, and
troubleshooting questions (Ask Dudley, Dell
Knowledge Base)
• Access documentation about your computer and
devices (Dell Documents)
• Get the latest versions of the drivers for your
computer (Downloads for Your Dell)
• Join online discussions with other Dell customers
and Dell technical professionals (Dell Talk)
• Explore a list of online links to Dell's primary
vendors
GOTO THE DELL SUPPORT WEBSITE —Go to support.dell.com for help with general usage, installation, and
troubleshooting questions. See "Returning Items for Warranty Repair or Credit" on page 78 for a description of the
hardware and software support provided by Dell.
E-MAIL DELL —Go to support.dell.com and then click E-Mail Dell in the Communicate list. Send an e-mail
message to Dell about your problem; you can expect to receive an e-mail message from Dell within hours. See "Returning
Items for Warranty Repair or Credit" on page 78 for a description of the hardware and software support provided by Dell.
CONTACT DELL —If you cannot solve your problem using the Dell™ support website or e-mail service, call Dell for
technical assistance. See "Contacting Dell" on page 79 for a list of phone numbers and addresses.
Resource Contents Using the Resource
7T097bk1.book Page 17 Thursday, September 26, 2002 6:47 AM

18 Information Resources
www.dell.com | support.dell.com
7T097bk1.book Page 18 Thursday, September 26, 2002 6:47 AM

SECTION 2
Setting Up and Using
Your Computer
A Tour of Your Computer
Setting Up a Printer
Printer Problems
Transferring Information to a New Computer With
Microsoft®Windows®XP
Setting Up a Home and Office Network With
Windows XP
Connecting to the Internet
Copying CDs
7T097bk1.book Page 19 Thursday, September 26, 2002 6:47 AM

20 Setting Up and Using Your Computer
www.dell.com | support.dell.com
A Tour of Your Computer
Front View
DISPLAY LATCH —Keeps the display closed.
STATUS LIGHTS —LEDs that show the status of the computer and its functions
and components.
module bay
keyboard
power button
touch pad
battery bay
display latch
status lights
easy-launch keys
four-directional
scroll pad
touch pad
buttons
7T097bk1.book Page 20 Thursday, September 26, 2002 6:47 AM
