Dell W19B001 User manual

Inspiron 22-3277 All-in-One
Service Manual
Regulatory Model: W19B
Regulatory Type: W19B001
October 2022
Rev. A02

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid
the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2018-2022 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries.
Other trademarks may be trademarks of their respective owners.

Chapter 1: Before working inside your computer............................................................................7
Before you begin .................................................................................................................................................................7
Safety instructions.............................................................................................................................................................. 7
Recommended tools........................................................................................................................................................... 8
Screw list............................................................................................................................................................................... 8
Chapter 2: After working inside your computer............................................................................10
Chapter 3: Removing the stand.................................................................................................... 11
Easel Stand...........................................................................................................................................................................11
Pedestal stand.................................................................................................................................................................... 12
Chapter 4: Replacing the stand.................................................................................................... 13
Easel stand...........................................................................................................................................................................13
Pedestal stand.................................................................................................................................................................... 13
Chapter 5: Removing the back cover............................................................................................14
Prerequisite..........................................................................................................................................................................14
Procedure.............................................................................................................................................................................14
Chapter 6: Replacing the back cover............................................................................................15
Procedure............................................................................................................................................................................ 15
Post-requisite......................................................................................................................................................................15
Chapter 7: Removing the hard drive.............................................................................................16
Prerequisites....................................................................................................................................................................... 16
Procedure............................................................................................................................................................................ 16
Chapter 8: Replacing the hard drive............................................................................................. 18
Procedure.............................................................................................................................................................................18
Post-requisites....................................................................................................................................................................18
Chapter 9: Removing the system-board shield............................................................................. 19
Prerequisites....................................................................................................................................................................... 19
Procedure............................................................................................................................................................................ 19
Chapter 10: Replacing the system-board shield........................................................................... 20
Procedure............................................................................................................................................................................20
Post-requisites...................................................................................................................................................................20
Chapter 11: Removing the memory module................................................................................... 21
Prerequisites........................................................................................................................................................................21
Procedure.............................................................................................................................................................................21
Contents
Contents 3

Chapter 12: Replacing the memory module.................................................................................. 23
Procedure............................................................................................................................................................................23
Post-requisites................................................................................................................................................................... 23
Chapter 13: Removing the wireless card...................................................................................... 24
Prerequisites.......................................................................................................................................................................24
Procedure............................................................................................................................................................................24
Chapter 14: Replacing the wireless card...................................................................................... 26
Procedure............................................................................................................................................................................26
Post-requisites................................................................................................................................................................... 27
Chapter 15: Removing the antenna.............................................................................................. 28
Prerequisites.......................................................................................................................................................................28
Procedure............................................................................................................................................................................28
Chapter 16: Replacing the antenna.............................................................................................. 29
Procedure............................................................................................................................................................................29
Post-requisites...................................................................................................................................................................29
Chapter 17: Removing the media-card reader.............................................................................. 30
Prerequisites.......................................................................................................................................................................30
Procedure............................................................................................................................................................................30
Chapter 18: Replacing the media-card reader...............................................................................31
Procedure.............................................................................................................................................................................31
Post-requisites....................................................................................................................................................................31
Chapter 19: Removing the power-button board........................................................................... 32
Prerequisites.......................................................................................................................................................................32
Procedure............................................................................................................................................................................32
Chapter 20: Replacing the power-button board........................................................................... 33
Procedure............................................................................................................................................................................33
Post-requisites................................................................................................................................................................... 33
Chapter 21: Removing the microphone........................................................................................ 34
Prerequisites.......................................................................................................................................................................34
Procedure............................................................................................................................................................................34
Chapter 22: Replacing the microphone........................................................................................ 35
Procedure............................................................................................................................................................................35
Post-requisites...................................................................................................................................................................35
Chapter 23: Removing the camera............................................................................................... 36
Prerequisites.......................................................................................................................................................................36
Procedure............................................................................................................................................................................36
4Contents

Chapter 24: Replacing the camera............................................................................................... 38
Procedure............................................................................................................................................................................38
Post-requisites...................................................................................................................................................................38
Chapter 25: Removing the coin-cell battery................................................................................ 39
Prerequisites.......................................................................................................................................................................39
Procedure............................................................................................................................................................................39
Chapter 26: Replacing the coin-cell battery................................................................................. 41
Procedure.............................................................................................................................................................................41
Post-requisites....................................................................................................................................................................41
Chapter 27: Removing the fan..................................................................................................... 42
Prerequisites.......................................................................................................................................................................42
Procedure............................................................................................................................................................................42
Chapter 28: Replacing the fan..................................................................................................... 43
Procedure............................................................................................................................................................................43
Post-requisites................................................................................................................................................................... 43
Chapter 29: Removing the heat sink............................................................................................ 44
Prerequisites.......................................................................................................................................................................44
Procedure............................................................................................................................................................................44
Chapter 30: Replacing the heat sink............................................................................................ 45
Procedure............................................................................................................................................................................45
Post-requisites...................................................................................................................................................................45
Chapter 31: Removing the speakers............................................................................................. 46
Prerequisites.......................................................................................................................................................................46
Procedure............................................................................................................................................................................46
Chapter 32: Replacing the speakers.............................................................................................47
Procedure............................................................................................................................................................................ 47
Post-requisites................................................................................................................................................................... 47
Chapter 33: Removing the system board..................................................................................... 48
Prerequisites.......................................................................................................................................................................48
Procedure............................................................................................................................................................................48
Chapter 34: Replacing the system board..................................................................................... 50
Procedure............................................................................................................................................................................50
Post-requisites...................................................................................................................................................................50
Flashing the BIOS..............................................................................................................................................................50
Chapter 35: Removing the display panel...................................................................................... 52
Prerequisites.......................................................................................................................................................................52
Contents 5

Procedure............................................................................................................................................................................52
Chapter 36: Replacing the display panel...................................................................................... 54
Procedure............................................................................................................................................................................54
Post-requisites...................................................................................................................................................................56
Chapter 37: Removing the middle frame...................................................................................... 57
Prerequisites.......................................................................................................................................................................57
Procedure............................................................................................................................................................................57
Chapter 38: Replacing the middle frame......................................................................................60
Procedure............................................................................................................................................................................60
Post-requisites...................................................................................................................................................................60
Chapter 39: Removing the rubber feet......................................................................................... 61
Prerequisites....................................................................................................................................................................... 61
Procedure............................................................................................................................................................................ 61
Chapter 40: Replacing the rubber feet........................................................................................ 62
Procedure............................................................................................................................................................................62
Post-requisites...................................................................................................................................................................62
Chapter 41: Downloading drivers................................................................................................. 63
Downloading the audio driver.........................................................................................................................................63
Downloading the graphics driver................................................................................................................................... 63
Downloading the USB driver.......................................................................................................................................... 64
Downloading the chipset driver..................................................................................................................................... 64
Downloading the network driver................................................................................................................................... 65
Chapter 42: System setup........................................................................................................... 66
Boot Sequence...................................................................................................................................................................66
Navigation keys..................................................................................................................................................................66
BIOS overview................................................................................................................................................................... 66
Entering BIOS setup program........................................................................................................................................ 67
System Setup Options..................................................................................................................................................... 67
Flashing the BIOS..............................................................................................................................................................70
Chapter 43: Troubleshooting........................................................................................................71
Flashing the BIOS...............................................................................................................................................................71
Reinstall Windows using a USB recovery drive...........................................................................................................71
Enhanced Pre-Boot System Assessment (ePSA) diagnostics............................................................................... 72
Running the ePSA diagnostics................................................................................................................................. 72
Display built-in self test....................................................................................................................................................72
Diagnostics..........................................................................................................................................................................73
Flea power release............................................................................................................................................................ 73
Wi-Fi power cycle..............................................................................................................................................................74
Chapter 44: Getting help and contacting Dell.............................................................................. 75
6Contents

Before working inside your computer
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Before you begin
Steps
1. Save and close all open files and exit all open applications.
2. Shut down your computer. Click Start > Power > Shut down.
NOTE: If you are using a different operating system, see the documentation of your operating system for shut-down
instructions.
3. Disconnect your computer and all attached devices from their electrical outlets.
4. Disconnect all attached network devices and peripherals, such as keyboard, mouse, and monitor from your computer.
5. Remove any media card and optical disc from your computer, if applicable.
6. After the computer is unplugged, press and hold the power button for 5 seconds to ground the system board.
CAUTION: Place the computer on a flat, soft, and clean surface to avoid scratches on the display.
7. Place the computer face down.
Safety instructions
Use the following safety guidelines to protect your computer from potential damage and ensure your personal safety.
NOTE: Before working inside your computer, read the safety information that shipped with your computer. For more safety
best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
NOTE: Disconnect all power sources before opening the computer cover or panels. After you finish working inside the
computer, replace all covers, panels, and screws before connecting to the electrical outlet.
CAUTION: To avoid damaging the computer, ensure that the work surface is flat and clean.
CAUTION: To avoid damaging the components and cards, handle them by their edges, and avoid touching pins
and contacts.
CAUTION: You should only perform troubleshooting and repairs as authorized or directed by the Dell technical
assistance team. Damage due to servicing that is not authorized by Dell is not covered by your warranty. See the
safety instructions that shipped with the product or at www.dell.com/regulatory_compliance.
CAUTION: Before touching anything inside your computer, ground yourself by touching an unpainted metal
surface, such as the metal at the back of the computer. While you work, periodically touch an unpainted metal
surface to dissipate static electricity, which could harm internal components.
CAUTION: When you disconnect a cable, pull on its connector or on its pull tab, not on the cable itself. Some
cables have connectors with locking tabs or thumb-screws that you must disengage before disconnecting
the cable. When disconnecting cables, keep them evenly aligned to avoid bending any connector pins. When
connecting cables, ensure that the ports and connectors are correctly oriented and aligned.
CAUTION: Press and eject any installed card from the media-card reader.
1
Before working inside your computer 7

Recommended tools
The procedures in this document may require the following tools:
●Phillips screwdriver #1
●Plastic scribe
Screw list
The following table provides the list of screws that are used for securing different components to the computer.
Table 1. Screw list
Component Secured to Screw type Quantity Screw image
Stand System-board shield M3x5 4
Hard-drive bracket Display-assembly base M3x5 1
Hard-drive bracket Hard drive M3x3.5 4
System-board shield Display-assembly base M3x5 5
Media-card reader
cover
Display-assembly base M3x5 1
Media-card reader Display-assembly base M3x5 1
Power-button board Display-assembly base M3x5 1
Microphone Display-assembly base M2x2.5 2
Speakers Display-assembly base M3 4+7.1 XZN 4
Fan Display-assembly base M2x2.5 3
Camera assembly Display-assembly base M3x5 2
System board Display-assembly base M3x5 6
Wireless-card shield System board M2x2.5 2
Wireless card System board M2x2.5 1
8 Before working inside your computer

Table 1. Screw list (continued)
Component Secured to Screw type Quantity Screw image
Display panel Display-assembly base M3x5 8
Middle frame Display-assembly base M3x5 black 13
Rubber feet Display-assembly base M3x5 black 4
Before working inside your computer 9

After working inside your computer
About this task
CAUTION: Leaving stray or loose screws inside your computer may severely damage your computer.
Steps
1. Replace all screws and ensure that no stray screws remain inside your computer.
2. Connect any external devices, peripherals, or cables you removed before working on your computer.
3. Replace any media cards, discs, or any other parts that you removed before working on your computer.
4. Connect your computer and all attached devices to their electrical outlets.
5. Turn on your computer.
2
10 After working inside your computer

Removing the stand
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Easel Stand
Steps
1. CAUTION: Place the computer on a flat, soft, and clean surface to avoid scratches on the display.
Place the computer on a clean and flat surface.
2. Using your fingertips, pry the stand cover off the back cover.
3. Remove the four screws (M3x5) that secure the stand to the system-board shield.
4. Lift and slide the stand from the system-board shield.
3
Removing the stand 11

Pedestal stand
Steps
1. CAUTION: Place the computer on a flat, soft, and clean surface to avoid scratches on the display.
Place the computer on a clean and flat surface.
2. Extend the stand upward.
3. Using your fingertips, pry the stand cover off the back cover.
4. Remove the four screws (M3x5) that secure the stand bracket to the system-board shield.
5. Lift the handle, and slide it out from the system-board shield.
12 Removing the stand

Replacing the stand
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Easel stand
Steps
1. Insert the tabs on the stand bracket into the slots on the system-board shield.
2. Align the screw holes on the stand with the screw holes on the system-board shield.
3. Replace the four screws (M3x5) that secure the stand to the system-board shield.
4. Replace the stand cover.
5. Place the computer in its upright position.
Pedestal stand
Steps
1. Insert the tabs on the stand bracket into the slots on the system-board shield.
2. Align the screw holes on the stand with the screw holes on the system-board shield.
3. Replace the four screws (M3x5) that secure the stand bracket to the system-board shield.
4. Replace the stand cover.
5. Place the computer in its upright position.
4
Replacing the stand 13

Removing the back cover
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisite
About this task
Remove the stand.
Procedure
About this task
CAUTION: Do not remove the computer cover unless you must install or replace internal components on your
computer.
Steps
Use one hand to stabilize your computer, and use another hand to pull the back cover from the center to lift it off the display
assembly base.
5
14 Removing the back cover

Replacing the back cover
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
About this task
CAUTION: Make sure that no cables are caught between the back cover and the display-assembly base.
Align the tabs on the back cover with the slots on the display-assembly base and snap the back cover into place.
Post-requisite
About this task
Replace the stand.
6
Replacing the back cover 15

Removing the hard drive
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
CAUTION: Hard drives are fragile. Exercise care when handling the hard drive.
CAUTION: To avoid data loss, do not remove the hard drive while the computer is in sleep or on state.
Prerequisites
Steps
1. Remove the stand.
2. Remove the back cover.
Procedure
Steps
1. Remove the screw (M3x5) that secures the hard-drive assembly to the display-assembly base.
2. Slide and lift the hard-drive assembly off the display-panel base.
3. Remove the four screws (M3x3.5) that secure the hard-drive bracket to the hard drive.
4. Lift the hard drive off the hard-drive bracket.
7
16 Removing the hard drive

Removing the hard drive 17

Replacing the hard drive
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
CAUTION: Hard drives are fragile. Exercise care when handling the hard drive.
Procedure
Steps
1. Place the hard drive in the hard-drive bracket with the label facing up.
2. Align the screw holes on the hard drive with the screw holes on the hard-drive bracket .
3. Replace the four screws (M3x3.5) that secure the hard-drive bracket to the hard drive.
4. Align the socket on the hard-drive assembly with the connector on the system board.
5. Slide the hard-drive assembly to connect the hard-drive assembly to the system board.
6. Replace the screw (M3x5) that secures the hard-drive assembly to the display-assembly base.
Post-requisites
Steps
1. Replace the back cover.
2. Replace the stand.
8
18 Replacing the hard drive

Removing the system-board shield
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
Steps
1. Remove the stand.
2. Remove the back cover.
Procedure
Steps
1. Remove the five screws (M3x5) that secure the system-board shield to the display-assembly base.
2. Use the handle to lift the system-board shield off the display-assembly base.
9
Removing the system-board shield 19

Replacing the system-board shield
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
Steps
1. Align the slots on the system-board shield with the ports on the system board and place the system-board shield on the
display-assembly base.
2. Align the screw holes on the system-board shield with the screw holes on the display-assembly base.
3. Replace the five screws (M3x5) that secure the system-board shield to the display-assembly base.
NOTE: Ensure that no cable is pinched by the system-board shield.
Post-requisites
Steps
1. Replace the back cover.
2. Replace the stand.
10
20 Replacing the system-board shield
