Inspiron 7300 2n1 Black
Service Manual
Regulatory Model: P125G
Regulatory Type: P125G001

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2020 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its
subsidiaries. Other trademarks may be trademarks of their respective owners.
April 2020
Rev. A00

1 Working inside your computer....................................................................................................... 5
Before working inside your computer................................................................................................................................. 5
Safety instructions................................................................................................................................................................ 5
Electrostatic discharge—ESD protection.......................................................................................................................... 6
ESD field service kit ..............................................................................................................................................................6
Transporting sensitive components.................................................................................................................................... 7
After working inside your computer.................................................................................................................................... 7
2 Removing and installing components............................................................................................. 8
Recommended tools..............................................................................................................................................................8
Screw list................................................................................................................................................................................ 8
Major components of Inspiron 7300 2n1 Black..................................................................................................................9
Base cover............................................................................................................................................................................. 11
Removing the base cover.............................................................................................................................................. 11
Installing the base cover................................................................................................................................................ 13
Battery...................................................................................................................................................................................14
Lithium-ion battery precautions................................................................................................................................... 14
Removing the battery....................................................................................................................................................15
Installing the battery...................................................................................................................................................... 16
Solid-state drive/Intel Optane............................................................................................................................................ 17
Removing the M.2 2230 solid-state drive................................................................................................................... 17
Installing the M.2 2230 solid-state drive..................................................................................................................... 17
Removing the M.2 2280 solid-state drive/Intel Optane H10................................................................................... 18
Installing the M.2 2280 solid-state drive/Intel Optane H10......................................................................................19
Display assembly..................................................................................................................................................................20
Removing the display assembly................................................................................................................................... 20
Installing the display assembly......................................................................................................................................22
Fans.......................................................................................................................................................................................25
Removing the fan.......................................................................................................................................................... 25
Installing the fan.............................................................................................................................................................26
Power-adapter port............................................................................................................................................................ 26
Removing the power-adapter port............................................................................................................................. 26
Installing the power-adapter port................................................................................................................................ 27
Coin-cell battery.................................................................................................................................................................. 29
Removing the coin-cell battery....................................................................................................................................29
Installing the coin-cell battery...................................................................................................................................... 29
I/O board..............................................................................................................................................................................30
Removing the I/O board...............................................................................................................................................30
Installing the I/O board.................................................................................................................................................. 31
Touchpad..............................................................................................................................................................................32
Removing the touchpad............................................................................................................................................... 32
Installing the touchpad..................................................................................................................................................33
Speakers............................................................................................................................................................................... 34
Removing the speakers.................................................................................................................................................34
Contents
Contents 3

Installing the speakers...................................................................................................................................................35
Heat sink...............................................................................................................................................................................36
Removing the heat sink................................................................................................................................................ 36
Installing the heat sink...................................................................................................................................................37
Power button with fingerprint reader...............................................................................................................................38
Removing the power-button with fingerprint reader............................................................................................... 38
Installing the power-button with fingerprint reader..................................................................................................39
System board.......................................................................................................................................................................40
Removing the system board........................................................................................................................................ 40
Installing the system board............................................................................................................................................41
Pen garage cable................................................................................................................................................................. 44
Removing the pen-garage cable..................................................................................................................................44
Installing the pen-garage cable.................................................................................................................................... 45
Keyboard...............................................................................................................................................................................46
Removing the keyboard................................................................................................................................................46
Installing the keyboard...................................................................................................................................................47
Palmrest................................................................................................................................................................................49
Removing the palm-rest assembly.............................................................................................................................. 49
Installing the palm-rest assembly................................................................................................................................ 50
3 Drivers and downloads................................................................................................................ 51
4 System setup.............................................................................................................................52
Entering BIOS setup program............................................................................................................................................52
Navigation keys....................................................................................................................................................................52
Boot Sequence.................................................................................................................................................................... 52
One time boot menu........................................................................................................................................................... 53
System setup options......................................................................................................................................................... 53
Clearing CMOS settings..................................................................................................................................................... 62
Clearing BIOS (System Setup) and System passwords.................................................................................................62
5 Troubleshooting......................................................................................................................... 63
System diagnostic lights.....................................................................................................................................................63
Recovering the operating system..................................................................................................................................... 64
Flashing the BIOS................................................................................................................................................................ 64
Flashing BIOS (USB key)................................................................................................................................................... 65
Backup media and recovery options.................................................................................................................................65
WiFi power cycle................................................................................................................................................................. 65
Flea power release.............................................................................................................................................................. 65
6 Getting help and contacting Dell..................................................................................................66
4Contents

Working inside your computer
Before working inside your computer
About this task
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Steps
1. Save and close all open files and exit all open applications.
2. Shut down your computer. Click Start > Power > Shut down.
NOTE: If you are using a different operating system, see the documentation of your operating system for shut-down
instructions.
3. Disconnect your computer and all attached devices from their electrical outlets.
4. Disconnect all attached network devices and peripherals, such as keyboard, mouse, and monitor from your computer.
CAUTION: To disconnect a network cable, first unplug the cable from your computer and then unplug the cable from
the network device.
5. Remove any media card and optical disc from your computer, if applicable.
Safety instructions
Use the following safety guidelines to protect your computer from potential damage and to ensure your personal safety. Unless otherwise
noted, each procedure included in this document assumes that you have read the safety information that shipped with your computer.
NOTE: Before working inside your computer, read the safety information that is shipped with your computer. For more
safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
NOTE: Disconnect your computer from all power sources before opening the computer cover or panels. After you finish
working inside the computer, replace all covers, panels, and screws before connecting your computer to an electrical
outlet.
CAUTION: To avoid damaging the computer, ensure that the work surface is flat, dry and clean.
CAUTION: To avoid damaging the components and cards, handle them by their edges, and avoid touching the pins and
the contacts.
CAUTION: You should only perform troubleshooting and repairs as authorized or directed by the Dell technical
assistance team. Damage due to servicing that is not authorized by Dell is not covered by your warranty. See the safety
instructions that is shipped with the product or at www.dell.com/regulatory_compliance.
CAUTION: Before touching anything inside your computer, ground yourself by touching an unpainted metal surface,
such as the metal at the back of the computer. While you work, periodically touch an unpainted metal surface to
dissipate static electricity which could harm internal components.
CAUTION: When you disconnect a cable, pull it by its connector or its pull tab, not the cable itself. Some cables have
connectors with locking tabs or thumb-screws that you must disengage before disconnecting the cable. When
disconnecting cables, keep them evenly-aligned to avoid bending the connector pins. When connecting cables, ensure
that the ports and the connectors are correctly oriented and aligned.
CAUTION: Press and eject any installed card from the media-card reader.
1
Working inside your computer 5
