Dell Latitude 131L User manual

www.dell.com | support.dell.com
Dell™ Latitude™ 131L
User’s Guide
Model PP23LB
book.book Page 1 Wednesday, April 4, 2007 7:31 AM

Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you make better use of your computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.
Abbreviations and Acronyms
For a complete list of abbreviations and acronyms, see "Glossary" on page 151.
If you purchased a Dell™ n Series computer, any references in this document to Microsoft
®
Windows
®
operating systems are not applicable.
____________________
Information in this document is subject to change without notice.
© 2006–2007 Dell Inc. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, Inspiron, Dell Precision, Dimension, OptiPlex, Latitude, PowerEdge, PowerConnect,
PowerVault, PowerApp, XPS, and Strike Zone are trademarks of Dell Inc.; Microsoft,Outlook,and Windows are registered trademarks of
Microsoft Corporation; AMD, Sempron, Turion and combinations thereof are trademarks of Advanced Micro Devices, Inc. IBM is a registered
trademark of IBM Corporation; EMC is a registered trademark of EMC Corporation; ENERGY STAR is a registered trademark of the U.S.
Environmental Protection Agency.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.
Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
Model PP23LB
March 2007 P/N MY881 Rev. A01
book.book Page 2 Wednesday, April 4, 2007 7:31 AM

Contents 3
Contents
Finding Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1 About Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Determining Your Computer’s Configuration . . . . . . . . . . . . . . . . . . 15
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Left Side View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Right Side View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Back View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Bottom View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2 Setting Up Your Computer. . . . . . . . . . . . . . . . . . . . . . . . 27
Connecting to the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Setting Up Your Internet Connection . . . . . . . . . . . . . . . . . . . . 27
Transferring Information to a New Computer . . . . . . . . . . . . . . . . . . 28
Running the Files and Settings Transfer Wizard With the Operating System CD 28
Running the Files and Settings Transfer Wizard Without the Operating System CD
29
Setting Up a Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Printer Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Connecting a USB Printer. . . . . . . . . . . . . . . . . . . . . . . . . . 31
Power Protection Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Surge Protectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Line Conditioners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Uninterruptible Power Supplies . . . . . . . . . . . . . . . . . . . . . . 33
3 Using the Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Adjusting Brightness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
book.book Page 3 Wednesday, April 4, 2007 7:31 AM

4Contents
Switching the Video Image . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Setting Display Resolution. . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4 Using the Keyboard and Touch Pad . . . . . . . . . . . . . . . . . 37
Numeric Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Key Combinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
System Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
CD or DVD Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Display Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Speaker Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Microsoft®Windows®Logo Key Functions . . . . . . . . . . . . . . . . 39
Adjusting Keyboard Settings . . . . . . . . . . . . . . . . . . . . . . . . 39
Touch Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Customizing the Touch Pad . . . . . . . . . . . . . . . . . . . . . . . . . 40
5 Using a Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Battery Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Checking the Battery Charge . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Dell™ QuickSet Battery Meter . . . . . . . . . . . . . . . . . . . . . . . 42
Microsoft Windows Power Meter . . . . . . . . . . . . . . . . . . . . . 42
Charge Gauge. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Low-Battery Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Conserving Battery Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Power Management Modes . . . . . . . . . . . . . . . . . . . . . . . . 43
Configuring Power Management Settings . . . . . . . . . . . . . . . . . 44
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Replacing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Storing a Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
book.book Page 4 Wednesday, April 4, 2007 7:31 AM

Contents 5
6 Using Multimedia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Playing a CD or DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Adjusting the Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Copying CDs and DVDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
How to Copy a CD or DVD. . . . . . . . . . . . . . . . . . . . . . . . . . 49
Using Blank CDs and DVDs . . . . . . . . . . . . . . . . . . . . . . . . . 49
Helpful Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
7UsingCards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
ExpressCards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
ExpressCard Blanks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Installing an ExpressCard. . . . . . . . . . . . . . . . . . . . . . . . . . 51
Removing an ExpressCard or Blank . . . . . . . . . . . . . . . . . . . . 52
Media Memory Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Installing a Media Memory Card . . . . . . . . . . . . . . . . . . . . . . 53
Removing a Media Memory Card. . . . . . . . . . . . . . . . . . . . . . 54
8 Setting Up a Network. . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Physically Connecting to a Network or Broadband Modem . . . . . . . . . . 55
Network Setup Wizard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Wireless Local Area Network (WLAN) . . . . . . . . . . . . . . . . . . . . . 56
What You Need to Establish a WLAN Connection . . . . . . . . . . . . . 56
Checking Your Wireless Network Card . . . . . . . . . . . . . . . . . . . 56
Setting Up a New WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Connecting to a Wireless Local Area Network. . . . . . . . . . . . . . . 58
Enabling/Disabling the Wireless Network Card . . . . . . . . . . . . . . 59
9 Securing Your Computer. . . . . . . . . . . . . . . . . . . . . . . . . 61
Security Cable Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
book.book Page 5 Wednesday, April 4, 2007 7:31 AM

6Contents
Computer Tracking Software . . . . . . . . . . . . . . . . . . . . . . . . . . 62
If Your Computer Is Lost or Stolen . . . . . . . . . . . . . . . . . . . . . . . . 62
10 Solving Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Dell Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Drive Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
CD and DVD drive problems . . . . . . . . . . . . . . . . . . . . . . . . 66
If you cannot eject the CD, CD-RW, DVD, or DVD+RW drive tray . . . . . 67
If you hear an unfamiliar scraping or grinding sound . . . . . . . . . . . 67
Hard drive problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
E-Mail, Modem, and Internet Problems . . . . . . . . . . . . . . . . . . . . . 67
Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
ExpressCard Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Keyboard Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
External Keyboard problems . . . . . . . . . . . . . . . . . . . . . . . . 73
Unexpected characters. . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Lockups and Software Problems . . . . . . . . . . . . . . . . . . . . . . . . 74
The computer does not start up . . . . . . . . . . . . . . . . . . . . . . 74
The computer stops responding . . . . . . . . . . . . . . . . . . . . . . 74
A program stops responding or crashes repeatedly . . . . . . . . . . . . 74
A program is designed for an earlier Microsoft®Windows®operating system 74
A solid blue screen appears . . . . . . . . . . . . . . . . . . . . . . . . 74
Other software problems . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Memory Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Network Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Power Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Ensuring Sufficient Power for Your Computer . . . . . . . . . . . . . . . 77
Printer Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Scanner Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Sound and Speaker Problems . . . . . . . . . . . . . . . . . . . . . . . . . . 78
No sound from integrated speakers . . . . . . . . . . . . . . . . . . . . 78
No sound from external speakers . . . . . . . . . . . . . . . . . . . . . 78
book.book Page 6 Wednesday, April 4, 2007 7:31 AM

Contents 7
No sound from headphones . . . . . . . . . . . . . . . . . . . . . . . . 79
Touch Pad or Mouse Problems . . . . . . . . . . . . . . . . . . . . . . . . . 79
Video and Display Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . 80
If the display is blank . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
If the display is difficult to read . . . . . . . . . . . . . . . . . . . . . . . 80
If only part of the display is readable . . . . . . . . . . . . . . . . . . . . 81
Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
What Is a Driver? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Identifying Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Reinstalling Drivers and Utilities . . . . . . . . . . . . . . . . . . . . . . 82
Resolving Software and Hardware Incompatibilities . . . . . . . . . . . . . 83
Restoring Your Operating System . . . . . . . . . . . . . . . . . . . . . . . . 84
Using Microsoft Windows XP System Restore . . . . . . . . . . . . . . . 84
Using Dell PC Restore by Symantec . . . . . . . . . . . . . . . . . . . . 86
Using the Operating System media . . . . . . . . . . . . . . . . . . . . . 87
11 Adding and Replacing Parts . . . . . . . . . . . . . . . . . . . . . . 89
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Recommended Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Turning Off Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . 89
Before Working Inside Your Computer . . . . . . . . . . . . . . . . . . . 90
Optical Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Returning a Hard Drive to Dell . . . . . . . . . . . . . . . . . . . . . . . 94
Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Hinge Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Wireless Mini-Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Coin-Cell Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
book.book Page 7 Wednesday, April 4, 2007 7:31 AM

8Contents
12 Dell™ QuickSet Features . . . . . . . . . . . . . . . . . . . . . . . 109
13 Traveling With Your Computer. . . . . . . . . . . . . . . . . . . . 111
Identifying Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Packing the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Travel Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Traveling by Air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
14 Contacting Dell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
15 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
16 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Using the System Setup Program . . . . . . . . . . . . . . . . . . . . . . . 143
Entering System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Commonly Used Options . . . . . . . . . . . . . . . . . . . . . . . . . 144
Cleaning Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Computer, Keyboard, and Display . . . . . . . . . . . . . . . . . . . . 146
Touch Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Floppy Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
CDs and DVDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Dell Technical Support Policy (U.S. Only) . . . . . . . . . . . . . . . . . . . 147
Definition of "Dell-Installed" Software and Peripherals . . . . . . . . . 147
Definition of "Third-Party" Software and Peripherals. . . . . . . . . . . 148
FCC Notice (U.S. Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
FCC Class B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
book.book Page 8 Wednesday, April 4, 2007 7:31 AM

Contents 9
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
book.book Page 9 Wednesday, April 4, 2007 7:31 AM

10 Contents
book.book Page 10 Wednesday, April 4, 2007 7:31 AM

Finding Information 11
Finding Information
NOTE: Some features or media may be optional and may not ship with your computer. Some features or media may
not be available in certain countries.
NOTE: Additional information may ship with your computer.
What Are You Looking For? Find It Here
• A diagnostic program for my computer
• Drivers for my computer
• My computer documentation
• My device documentation
• Notebook System Software (NSS)
Drivers and Utilities Media (also known as ResourceCD)
NOTE: The Drivers and Utilities media may be optional and
may not ship with your computer.
Documentation and drivers are already installed on your
computer. You can use the media to reinstall drivers or run
the Dell Diagnostics (see "Dell Diagnostics" on page 63.)
Readme files may be
included on your media to
provide last-minute
updates about technical
changes to your computer
or advanced technical-
reference material for
technicians or experienced
users.
NOTE: Drivers and documentation updates can be found at
support.dell.com.
• Warranty information
• Terms and Conditions (U.S. only)
• Safety instructions
• Regulatory information
• Ergonomics information
• End User License Agreement
Dell™ Product Information Guide
book.book Page 11 Wednesday, April 4, 2007 7:31 AM

12 Finding Information
• How to set up my computer
• How to care for my computer
• Basic troubleshooting information
• How to run the Dell Diagnostics
• Error codes and diagnostic lights
• Tools and utilities
• How to set up a printer
• Additional information about setting up my computer
• How to troubleshoot and solve problems
• How to remove and install parts
• How to open my computer cover
• Specifications
• How to contact Dell
Quick Reference Guide
NOTE: This document may be optional and may not ship with
your computer.
NOTE: This document is available as a PDF at
support.dell.com.
• Service Tag and Express Service Code
• Microsoft Windows License Label
Service Tag and Microsoft
®
Windows
®
License
These labels are located on the bottom of your computer.
• Use the Service Tag to identify your computer when you
use
support.dell.com or contact technical support.
• Enter the Express
Service Code to direct
your call when
contacting technical
support.
What Are You Looking For? Find It Here
book.book Page 12 Wednesday, April 4, 2007 7:31 AM

Finding Information 13
• Solutions — Troubleshooting hints and tips; articles
from technicians; online courses; and frequently asked
questions
• Community — Online discussion with other Dell
customers
• Upgrades — Upgrade information for components, such
as memory, the hard drive, and the operating system
• Customer Care — Contact information, service call and
order status, warranty, and repair information
• Service and support — Service call status and support
history, service contract, online discussions with
technical support
• Reference — Computer documentation, details on my
computer configuration, product specifications, and
white papers
• Downloads — Certified drivers, patches, and software
updates
Dell Support Website — support.dell.com
NOTE: Select your region to view the appropriate support
site.
• How to use the Windows operating system
• How to work with programs and files
• How to personalize my desktop
Windows Help and Support Center
1 Click the Start button and click Help and Support .
2 Type a word or phrase that describes your problem and
click the arrow icon.
3 Click the topic that describes your problem.
4 Follow the instructions on the screen.
What Are You Looking For? Find It Here
book.book Page 13 Wednesday, April 4, 2007 7:31 AM

14 Finding Information
• How to reinstall my operating system Operating System media
NOTE: The Operating System media may be optional and may
not ship with your computer.
The operating system is already installed on your computer.
To reinstall your operating system, use one of the following
methods:
• Microsoft Windows System Restore — Microsoft
Windows
System Restore returns your computer to an
earlier operating state without affecting data files.
•Dell
PC Restore — Dell PC Restore returns your computer
to its original operating state. Dell
PC Restore may not
ship with your computer.
•
Operating System media — If you received an Operating
System
media with your computer, you can use it to
restore your operating system.
For more information, see "Restoring Your Operating
System" on page 84.
After you reinstall your
operating system, use the
Drivers and Utilities media
(see page 82) to reinstall
drivers for the devices that
came with your computer.
Your operating system
product key label is located
on your computer.
NOTE: The color of your media varies, based on the
operating system you ordered.
• Service call status and support history
• Top technical issues for my computer
• Frequently asked questions
• File downloads
• Details on my computer configuration
• Service contract for my computer
Dell Premier Support Website — premiersupport.dell.com
The Dell Premier Support website is customized for
corporate, government, and education customers. This
website may not be available in all regions.
What Are You Looking For? Find It Here
book.book Page 14 Wednesday, April 4, 2007 7:31 AM

About Your Computer 15
About Your Computer
Determining Your Computer’s Configuration
Based on selections that you made when purchasing your computer, your computer has one of
several different video controller configurations. To determine your computer’s video controller
configuration:
1
Access the Microsoft
®
Windows
®
Help and Support Center. For instructions, see "Windows Help
and Support Center" on page 13
.
2 Under Pick a Task , click Use Tools to view your computer information and diagnose problems.
3 Under My Computer Information , select Hardware .
From the My Computer Information - Hardware screen, you can view the type of video controller
installed in your computer, as well as the other hardware components.
book.book Page 15 Wednesday, April 4, 2007 7:31 AM

16 About Your Computer
Front View
DISPLAY LATCH RELEASE —Press to release the display latches and open the display.
DISPLAY LATCHES —Keep the display closed.
DISPLAY —For more information about your display, see "Using the Display" on page 35.
POWER BUTTON —Press the power button to turn on the computer or to enter or exit a power management mode.
1display latch release 2display latches (2) 3display
4power button 5device status lights 6touch pad
7speakers (2) 8touch pad buttons 9keyboard
10 keyboard and wireless
status lights
1
9
3
6
8
4
7
5
10
2
book.book Page 16 Wednesday, April 4, 2007 7:31 AM

About Your Computer 17
See "Power Management Modes" on page 43.
DEVICE STATUS LIGHTS
If the computer is connected to an electrical outlet, the light operates as follows:
• Solid green: The battery is charging.
• Flashing green: The battery is almost fully charged.
If the computer is running on a battery, the light operates as follows:
• Off: The battery is adequately charged (or the computer is turned off).
• Flashing orange: The battery charge is low.
• Solid orange: The battery charge is critically low.
Turns on when you turn on the computer, and blinks when the computer is in a power
management mode.
Turns on when the computer reads or writes data.
NOTICE: To avoid loss of data, never turn off the computer while the light is flashing.
Turns on steadily or blinks to indicate battery charge status.
book.book Page 17 Wednesday, April 4, 2007 7:31 AM

18 About Your Computer
TOUCH PAD —Provides the functionality of a mouse. Silk screening on the touch pad indicates scrolling
capabilities.
SPEAKERS —To adjust the volume of the integrated speakers, press the media control buttons or speaker-volume
keyboard shortcuts. For more information, see "Speaker Functions" on page 39.
TOUCH PAD BUTTONS —Touch pad buttons provide the functionality of a mouse.
KEYBOARD —The keyboard includes a numeric keypad as well as the Microsoft Windows logo key. For information
on supported keyboard shortcuts, see "Key Combinations" on page 38.
book.book Page 18 Wednesday, April 4, 2007 7:31 AM

About Your Computer 19
KEYBOARD AND WIRELESS STATUS LIGHTS
The green lights located above the keyboard indicate the following:
Turns on when the numeric keypad is enabled.
Turns on when the uppercase letter function is enabled.
Turns on when the scroll lock function is enabled.
Turns on when wireless networking is enabled. To enable
or disable wireless networking, press <Fn><F2>.
9
A
book.book Page 19 Wednesday, April 4, 2007 7:31 AM

20 About Your Computer
Left Side View
CAUTION: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your
computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting the airflow
can damage the computer or cause a fire.
AIR VENT —The computer uses fans to create airflow through the vents, which prevents the computer from
overheating.
NOTICE: Before you buy an antitheft device, ensure that it will work with the security cable slot.
SECURITY CABLE SLOT —Lets you attach a commercially available antitheft device to the computer. For more
information, see the instructions included with the device.
1air vent 2security cable slot 3optical drive bay
4optical-drive-tray eject
button
3241
book.book Page 20 Wednesday, April 4, 2007 7:31 AM
