Dell Latitude XPi CD Service Manual Update 1
Dell
®
Latitude
®
XPi CD
Service Manual Update
T
his document updates information contained in the Dell Latitude XPi CD
Service Manual and in the Dell Latitude XPi CD Parts Removal and Replace-
ment Guide.
N
ew System Features
Additional system features include:
•Now available with a 166-MHz Intel®Pentium® microprocessor with
MMX™technology in the Dell Latitude XPi CD M166ST, which otherwise
has the same features as other models of the computer.
•Support for up to 80 MB of system memory on the Latitude XPi CD
M166ST, by installing a combination of 8-, 16-, and 32-MB memory mod-
ules in the two sockets on the system board. (The standard minimum
configuration is 16 MB of nonremovable EDO memory on the system
board.)
•The Pentium microprocessor with MMX technology has twice the internal
cache memory (32 KB) as the standard Pentium microprocessor.
•A Texas Instruments PCI 1131 CardBus controller.
•A NeoMagic 2093 video controller for a video subsystem that includes
1.1 MB of video memory.
•An ESS 1887 audio controller.
•10X CD-ROM drive.
NOTE: Your computer may not appear exactly as shown in some of the figures
in the Service Manual. EMI shields may have been changed or added.

2 Dell Latitude XPi CD Service Manual Update
T
echnical Specifications
The following information updates Table 1-2, “Technical Specifications,” in
Chapter 1 of the Service Manual.
Technical Specifications
Microprocessor
Microprocessor:
Latitude XPi CD
M166ST . . . . . . . . . . . . . . Intel Pentium microprocessor with
MMX technology running at 166 MHz
Latitude XPi CD
P150ST. . . . . . . . . . . . . . . Intel Pentium microprocessor
running at 150 MHz
Internal cache:
Latitude XPi CD
M166ST . . . . . . . . . . . . . . 32 KB
Latitude XPi CD
P150ST. . . . . . . . . . . . . . . 16 KB
External cache . . . . . . . . . . . . 256-KB pipelined burst SRAM
Math coprocessor . . . . . . . . . . internal to the microprocessor
Chip Set and Bus
Local bus:
Latitude XPi CD
M166ST . . . . . . . . . . . . . . 66 MHz
Latitude XPi CD
P150ST. . . . . . . . . . . . . . . 60 MHz
PCI bus:
Latitude XPi CD
M166ST . . . . . . . . . . . . . . 33 MHz
Latitude XPi CD
P150ST. . . . . . . . . . . . . . . 30 MHz

Dell Latitude XPi CD Service Manual Update 3
PC Card
PC Card controller:1
Latitude XPi CD
M166ST . . . . . . . . . . . . . . Texas InstrumentsPCI 1131CardBus controller
Latitude XPi CD
P150ST . . . . . . . . . . . . . . . Texas InstrumentsPCI 1130CardBus controller
Data width (maximum):
PCMCIA. . . . . . . . . . . . . . 16 bits
CardBus . . . . . . . . . . . . . . 32 bits
Memory
Memory module capacities:
Latitude XPi CD
M166ST . . . . . . . . . . . . . . 8-, 16-, and 32-MB fast-page mode
Latitude XPi CD
P150ST . . . . . . . . . . . . . . . 8- or 16-MB fast-page mode
Maximum RAM:
Latitude XPi CD
M166ST . . . . . . . . . . . . . . 80 MB
Latitude XPi CD
P150ST . . . . . . . . . . . . . . . 48 MB
Connectors
IDE hard-disk drive . . . . . . . . one 40-pin connector
1The device driver for the PCI 1131 CardBus controller is compatible with the PCI 1130
CardBus controller. However, the device driver for the PCI 1130 CardBus controller is not
compatible with the PCI 1131 CardBus controller.
Technical Specifications (continued)

4 Dell Latitude XPi CD Service Manual Update
Audio
Audio controller:2
Latitude XPi CD
M166ST . . . . . . . . . . . . . . ESS 1887;
ESS 690 wavetable music synthesizer;
ESS9383D audiospatializer(on systems using
Windows 95)
Latitude XPi CD
P150ST. . . . . . . . . . . . . . . ESS 1888;
ESS 690 wavetable music synthesizer;
ESS9383D audiospatializer(on systems using
Windows 95)
Video
Video type. . . . . . . . . . . . . . . . 128-bit hardware accelerated
Data bus . . . . . . . . . . . . . . . . . PCI
Video controller:3
Latitude XPi CD
M166ST . . . . . . . . . . . . . . NeoMagic 2093
Latitude XPi CD
P150ST. . . . . . . . . . . . . . . NeoMagic 2090
Video memory . . . . . . . . . . . . 1.1 MB (2.0-MB performance equivalent)
Display
Dimensions (active area):
Height. . . . . . . . . . . . . . . . 184.5 mm (7.26 inches)
Width . . . . . . . . . . . . . . . . 246.0 mm (9.68 inches)
Controls . . . . . . . . . . . . . . . . . brightness can be controlled through a key
combination or the Display window in the Dell
Control Center
2The device driver for ESS 1887 audio controller is compatible with the ESS 1888 audio
controller. However, the device driver for the ESS 1888 audio controller is not compatible
with the ESS 1887 audio controller.
3The device driver for NeoMagic 2093 video controller is compatible with the NeoMagic
2090 video controller. However, the device driver for the NeoMagic 2090 video controller is
not compatible with the NeoMagic 2093 video controller.
Technical Specifications (continued)

Dell Latitude XPi CD Service Manual Update 5
CD-ROM Drive
Data transfer rate (minimum):4
Sustained. . . . . . . . . . . . . . 900 KB/sec (6X); 1500 KB/sec (10X)
Burst . . . . . . . . . . . . . . . . . 14.4 MB/sec (6X and 10X)
Physical (Computer)
Weight:5
Latitude XPi CD
M166ST . . . . . . . . . . . . . . 3.4 kg (7.4 lb)
Latitude XPi CD
P150ST . . . . . . . . . . . . . . . 3.3 kg (7.3 lb)
Power (Advanced Port Replicator)
Voltage . . . . . . . . . . . . . . . . . . requires 18.5 VDC from AC adapter
Amperage . . . . . . . . . . . . . . . . 3.5 A
Physical (Advanced Port Replicator)
Height . . . . . . . . . . . . . . . . . . . 31.75 mm (1.25 inches)
Depth. . . . . . . . . . . . . . . . . . . . 76.20 mm (3.00 inches)
Width. . . . . . . . . . . . . . . . . . . . 266.7 mm (10.50 inches)
Weight. . . . . . . . . . . . . . . . . . . 0.6 kg (1.3 lb)
SCSI Controller (Advanced Port Replicator)
Chip set . . . . . . . . . . . . . . . . . . AIC 6360; SCSI-2 compliant
Data bus width . . . . . . . . . . . . 16-bit ISA host bus interface
Data transfer rate. . . . . . . . . . . 10.0 MB/sec
I/O address . . . . . . . . . . . . . . . 140h
IRQ . . . . . . . . . . . . . . . . . . . . . IRQ11
4The data transfer rate of the CD-ROM drive in your system may be faster, depending on
when you purchased the computer.
5With battery and hard-disk drive.
Technical Specifications (continued)

6 Dell Latitude XPi CD Service Manual Update
R
emoving and Replacing Parts Changes
The following information updates the removal and replacement procedures for
some parts and assemblies as described in Chapter 4, “Removing and Replacing
Parts,” of the Service Manual and in the Parts Removal and Replacement Guide
(which is the same as Chapter 4 of the Service Manual). However, some of the
parts and assemblies used are different.
Palmrest Assembly
Revise the Palmrest Assembly removal procedure to include the following:
Use a scribe to pry out the three screw covers for the palmrest-retaining screws
A1, A2, and A3.
Disengage the palmrest assembly from the bottom case assembly by sliding the
palmrest assembly about 1/8-inch toward the front of the computer. Then, gen-
tly lift the front of the palmrest assembly and pull it toward the front to release
the back hooks.
Display Assembly Latch and Latch Spring
Your computer may have a plastic clip or mylar pad attached to the latch
assembly.
LCD Panel
Your computer may have a metal spacer attached to the top of the LCD panel.
Ethernet Network Controller (Advanced Port Replicator)
Chip set. . . . . . . . . . . . . . . . . . 3Com®3C913B; 10Base-T Ethernet
Data bus width . . . . . . . . . . . . 16-bit Plug and Play ISA host bus interface
I/O address . . . . . . . . . . . . . . . 300h (default)
IRQ. . . . . . . . . . . . . . . . . . . . . IRQ10
Token Ring Network Controller (Advanced Port Replicator)
Chip set. . . . . . . . . . . . . . . . . . IBM04H8297; 16/4 Mbps Token Ring (default
ring speed is 16 Mbps)
Data bus width . . . . . . . . . . . . 16-bit ISA host bus interface
I/O address . . . . . . . . . . . . . . . A20h (default)
IRQ. . . . . . . . . . . . . . . . . . . . . IRQ10
Technical Specifications (continued)

Dell Latitude XPi CD Service Manual Update 7
LCD Inverter Board
The inverter board assembly with order name SVC,LCD/INVTR,IBM,LXPiCD
(see the “Factory Repair Parts and Assemblies” table found later in this
document) is different from the inverter board assembly with order name
SVC,LCD/INVTR,SMSNG,LXPiCDX.
If the back light on the LCD panel is not working, replace both the inverter
board and the LCD panel.
Bottom Case Assembly Removal
The parts of your computer may be different from the parts shown in Fig-
ure 4-22, “Bottom Case Assembly Removal,” of the Service Manual (Figure 22
of the Parts Removal and Replacement Guide). The superpart docking EMI clip
and superpart serial EMI clip may be smaller. The superpart assembly may also
look different. The upper I/O bracket clip has been renamed the deck buoy.
Diskette/CD-ROM Drive Assembly
There may be a bracket spacer on the diskette/CD-ROM assembly in your
computer.
Deck Buoy
The deck buoy in your computer may have an EMI clip attached to it.
System Board Assembly Removal
The parts of your computer may be different from the parts shown in Fig-
ure 4-27, “System Board Assembly Removal,” of the Service Manual (Figure 27
of the Parts Removal and Replacement Guide). The battery compartment may
have a plastic cover.
Advanced Port Replicator Connector Dust Cover
The callout in Figure 4-31 (Figure 31 of the Parts Removal and Replacement
Guide) refers to the Advanced Port Replicator connector dust cover.
Audio Board
The parts of your computer may be different from the parts shown in
Figure 4-32, “Audio Board Removal,” of the Service Manual (Figure 32 of the
Parts Removal and Replacement Guide). The hard-disk drive bracket and the
audio board may have a shield, a clip, an insulator, and standoffs added.
F
actory Repair Parts Changes
Removal and replacement procedures for all factory components and subassem-
blies are the same as those described in Appendix A, “Factory Repair Parts,” of

8 Dell Latitude XPi CD Service Manual Update
the Service Manual. However, some of the components and subassemblies used
are different. The following information updates Table A-1, “Factory Repair
Parts and Assemblies,” in Appendix A.
Factory Repair Parts and Assemblies
Part or Assembly Name Order Name Figure
CD-ROM Drive Assembly
CD-ROM drive assembly
service kit SVC,ASSY,CD,INT,I,10X, LXPiCD 4-23
CD-ROM drive CD,650M,I,INT,10X,LXPiCD
M166ST
Technical booklet,
service manual
update
TSH,SRV MNL UPD,LXPiCD
M166ST
Hard-Disk Drive Assemblies
Hard-disk drive assembly
service kit, 3-GB CUS,HD,3.0G,17MM,IBM,NBK 4-6
Hard-disk drive, sub-
assembly, 3-GB SUBAS- SY,HD,3.0G,17MM,IBM,LXP
Hard-disk drive HD,3.0GB,I,F2,17MM,IBM
LCD Assemblies
LCD inverter board service
kit SVC,LCD/INVTR,SMSNG,
LXPiCDX
LCD panel LCD,TFT,SVGA,12.1”,CISPR
SMSNG 4-17
Cable/Bobbin
assembly ASSY,CBL/BBN,TFT,LXPiCD 4-20
Technical booklet,
service manual
update
TSH,SRV MNL UPD,LXPiCD
M166ST
Cable/Bobbin service kit SVC,ASSY,CBL/BBN,SMSNG,
LXPiCD
Cable/Bobbin
assembly ASSY,CBL/BBN,TFT, LXPiCD
Technical booklet,
service manual
update
TSH,SRV MNL UPD,LXPiCD
M166ST

Dell Latitude XPi CD Service Manual Update 9
LCD Assemblies
(continued)
LCD inverter board service
kit SVC,LCD/INVTR,IBM LXPiCD
LCD panel LCD,TFT,SVGA,12.1”,IBM,
CISPR
Cable/Bobbin
assembly ASSY,CBL/BBN,TFT,IBM, LXPiCD 4-20
Spacer assembly,
LCD panel ASSY,LCD SPACER,IBM, LXPiCD
Spacer SPCR,LCD,12.1”,LXPiCD,IBM
Tape TAPE,SPCR,LCD,12.1”,
LXPiCD,IBM
Technical booklet,
service manual
update
TSH,SRV MNL UPD,LXPiCD
M166ST
Cable/Bobbin service kit SVC,ASSY,CBL/BBN,IBM,
LXPiCD
Cable/Bobbin
assembly ASSY,CBL/BBN,TFT,IBM LXPiCD
Technical booklet,
service manual
update
TSH,SRV MNL UPD,LXPiCD
M166ST
Memory
Memory module, 32-MB,
customer kit CUS,MEM,32M,LXPiCD 4-8
Memory module,
32-MB DIMM,32MB,70NS,8X32,NBK, G,72P
Factory Repair Parts and Assemblies (continued)
Part or Assembly Name Order Name Figure

10 Dell Latitude XPi CD Service Manual Update
Miscellaneous Parts
Lefttilt-supportfootservice
kit SVC,FOOT,BACK,LF, LXPiCD 4-5
Right tilt-support foot
service kit SVC,FOOT,BACK,RT, LXPiCD 4-5
Keel plate assembly ASSY,PLT,KEEL,CISPR,
LXPiCD A-12
Keel plate PLT,KEEL,TIN PLATED,
LXPiCD
Clip, keel plate CLP, KEEL BUOY,CISPR,
LXPiCD
Foam, keel plate FOAM,BLCK,PORON,CNDCT
COAT
Thermal clamp assembly ASSY,CLMP,THRM,CISPR,
LXPiCD
Thermal clamp CLMP,THRM,TIN PLATED,
LXPiCD
Clip, thermal clamp CLP, GND,CPU,CISPR,
LXPiCD
Fan/Speaker service kit SVC,ASSY,PLN,FAN/SPKR
LXPiCD
Fan/Speaker board
assembly ASSY,PWA,FAN/SPKR,CISPRII, XPiCD
Fan/Speaker board PWA,FAN/SPKR,CISPRII,
LXPiCD,NBK
Technical booklet,
service manual update TSH,SRV MNL UPD,LXPiCD M166ST
Factory Repair Parts and Assemblies (continued)
Part or Assembly Name Order Name Figure

Dell Latitude XPi CD Service Manual Update 11
System Board Assemblies
System board assembly,
LXPi CD, 166-MHz,
service kit
SVC,PLN,LXPiCD
M166ST,WB,0M 4-27
System board sub-
assemblywithBIOS,
LXPi CD, 166-MHz
SUBASSY,PLN,LXPiCD-166ST,
WB,0M
Audio board
assembly,
MMX
ASSY,PWA,AUD,LXPiCD
M166ST,NBK 4-32
Audio board PWA,AUD,LXPiCD
M166ST,NBK
Clip, audio CLP,AUDIO,HDD,CISPR,
LXPiCD
Shield, audio SHLD,AUDIO,HDD,CISPR,
LXPiCD
Insulator,
audio INSUL,AUDIO,HDD,CISPR, LXPiCD
Speaker,
audio jack SPCR,AUDIO JACK,CISPR, LXPiCD
Screw SCR,M2X14MM,PHH,MS,ZPS,
W/WSHR
Screw SCR,M2X3MM,PHH,MS,BLO,
W/WSHR
Standoff STDF,M2X5MM,FEM/FEM,
NBK
Cover, mylar CVR,MYLAR,PCMCIA,
CISPRII,XPiCD
Powersupply
board CRD,PWR SPLY,LXPiCD, 2.5V 4-29
System
board,
166-MHz
PWA,PLN,LXPiCD 166ST,
CISPRII
Factory Repair Parts and Assemblies (continued)
Part or Assembly Name Order Name Figure

12 Dell Latitude XPi CD Service Manual Update
Exploded Views of Components and Assemblies
The parts of your computer may be different from the parts shown in
Figure A-3, “Exploded View—Bottom Case Assembly.” The superpart docking
EMI clip and superpart serial EMI clip may be smaller. The superpart assembly
may look different. The upper I/O bracket clip has been renamed the deck buoy.
Bottom-Case Assembly Components
The spreader plate in your computer may be different from that shown in
Figure A-10, “Bottom-Case Assembly Components.”
Spreader and Keel Plates
The spreader plate in your computer may be different from that shown in
Figure A-12, “Spreader and Keel Plate Removal.”
System Board Assemblies
(continued)
BIOS chip IC,PROG,FLASH,28FO20,PRG
84719
Spreader
assembly ASSY,PAN SPRDR,CISPR, LXPiCD
Clip,
spreader CLP,EMI,PAN SPRDR,CISPR, LXPiCD
Insulator,
spreader INSUL,PAN SPRDR,CISPR, LXPiCD
Ground
assembly ASSY,LD GRD,CISPR,LXPiCD
Clip, CPU CLP,CPU,BTM,CISPR,LXPiCD
Technical booklet,
service manual
update
TSH,SRV MNL UPD,LXPiCD
M166ST
Factory Repair Parts and Assemblies (continued)
Part or Assembly Name Order Name Figure
