Dell Professional P2412H User manual

Dell Professional
P2412H 24”
Monitor with
LED backlights
Get optimal productivity with comfort enabling features all in an
eco-friendly design with the Dell Professional P2412H 24" monitor
with LED
Designed to minimize environmental impact, the P2412H is halogen-free except for its cables,
and made from environmentally preferable materials such as an arsenic-free, mercury-free
panel and more than 25% post consumer recycled plastics in its chassis.
Its comfort-enabling features include an improved height adjustability range which oers
you optimal viewing height, and also tilt, swivel, pivot — full adjustability features. Its wide
range of connectivity options oers seamless connectivity with your notebooks, desktops
and peripherals, while remote asset management gives you the convenience of monitoring,
accessing, troubleshooting and managing multiple Dell monitors from the comfort of your desk.
Get comfort, convenience and energy-conscious features with the Dell Professional P2412H.
Dell also oers a completely halogen-free monitor, the Dell Professional P2412H-HF in the USA, UK
and Japan. Ask your Dell representative for more information.

The P2412H combines high performance
and stylish design with compliance to tough
environmental requirements, and is 20% more
ecient than conventional options.
Dell Professional P2412H
24" Monitor with LED backlights
Designed for optimal comfort
• Improved height adjustability (130 mm vs. previous Dell
models with 100 mm) — Maximize your viewing comfort
by easily adjusting the monitor to the desired height
• Additional comfort-enabling features such as tilt, swivel
and pivot (with enhanced menu rotation) — Adjust the
screen to the preferred angle (tilt — 4 degrees forward/
21 degrees backward — plus swivel). Change the
orientation of the screen from horizontal to vertical (pivot)
to easily read newsletters, flyers, or web pages without the
need to scroll using manual adjustment and an enhanced
menu rotation
• Remote asset management (Enabled when used with Dell
computers in a network managed by Dell Client Manager)
— Enjoy the comfort and convenience of troubleshooting,
accessing, monitoring and managing multiple Dell monitors
at different locations from a remote
• Connectivity options
- VGA, DVI (HDCP), 2 x USB ports — Seamlessly connect
your monitor with your desktop, laptop and other
peripherals with the wide array of connectivity ports.
Plus, get convenient and easy access to USB ports found
at the side of the monitor.
- TCO Certified Displays 5 — Ensures high visual
performance and comfortable viewing positions.
Excellent screen performance
• Screen clarity
- Experience great work productivity with a crystal clear
1920 x 1080 resolution
- High dynamic contrast ratio of 2 million:1 so you can see
your work in razor-sharp clarity, and experience smooth,
jitter-free moving images
• High color gamut of 82% and 16.7 million colors — Get a
wide range of true-to-life colors
• Premium Panel Guarantee — A free panel exchange is
guaranteed in the event that you discover even one bright
pixel in the Professional series monitors during the Limited
Hardware Warranty⁵ period, thus ensuring the quality of
the monitor
Eco-design
• Made of environmentally-preferable materials
- Halogen-free ready (except for its cables), helping you
make a greener choice without compromising on cost,
performance or reliability
- Easy to recycle and will help to lower power
consumption
- Arsenic-free glass
- Mercury-free LED panel
- More than 25% post-consumer recycled plastics in
its chassis
• PowerNap1 software — Helps to dim the monitor to its
minimum brightness level or puts it into sleep mode when
not in use
• Dynamic dimming2 software — Adjusts onscreen
brightness when images displayed consist of predominantly
large bright and white areas
• Remote asset management (Enabled when used with Dell
computers in a network managed by Dell Client Manager)
— Save energy by scheduling tasks such as turning off Dell
monitors at specific times after office hours, especially with
the P2412H’s extremely low active-off mode of <0.1W
• Environmental compliance — Meets the latest
environmental standards such as ENERGY STAR®, EPEAT
Gold, TCO Certified Displays 5.2, and CECP
• Eco-friendly packaging — Environmentally responsible
packaging free of expanded polystyrene foam (EPS) plus
corrugated cardboard, both of which are easy to recycle
and do not contribute to environmental waste
Dell Professional
P2412H 24" Monitor

Monitor
Viewable image size (diagonal) 60.97 cm (24 inches)
Preset display area:
Horizontal
Vertical
158,818 sq-mm (246.23 sq-inches)
531.36 mm (20.92 inches)
298.89 mm (11.77 inches)
Maximum resolution 1920 x 1080 at 60 Hz
Pixel pitch 0.277 mm
Brightness (typical) 250 cd/m2
Color gamut (typical) 81%1
Color depth 16.7 million colors
Contrast ratio (typical)
Dynamic contrast ratio (typical)
1,000:1
2 million:1
Viewing angle (typical)
(vertical/horizontal) 160°/170°
Response time (typical) 5ms (black to white)
Panel type TN (active matrix – TFT LCD)
Backlight LED
Connectivity
Connectors VGA, DVI-D (HDCP), 2 X USB 2.0 ports
Remote asset management Yes, used with PCs managed by Dell Client Manager
Design features
Stand Height adjustable stand (130 mm), tilt, swivel, pivot and built-in
cable management
Security Security lock slot and stand lock (security lock and M3x6mm
screw for stand lock not included)
Power
AC input
voltage/frequency/current 100 to 240 VAC/50 or 60 Hz ± 3 Hz/1.2A (maximum)
Power consumption (typical) 21 W
Power consumption
standby/sleep mode <0.1W
Dimensions (with stand)
Height (compressed ~ extended) 370 mm ~ 500 mm (14.50 inches ~ 19.69 inches)
Width 569.0 mm (22.36 inches)
Depth 180.3 mm (7.10 inches)
Weight
Weight without stand assembly
(for wall mount or VESA mount
considerations – no cables)
4.04 kg (8.89 lbs)
Weight with stand assembly
and cables 6.18 kg (13.60 lbs)
Weight with packaging 7.62 kg (16.76 lbs)
Environmental Compliance
ENERGY STAR 5.1, TCO 5.2, EPEAT Gold, China Energy Label, (CEL) Grade 1, China Energy Conservation Program
(CECP), WEEE, ErP(EuP) Standards, Korea E-Standby
Service & Warranty
• 3 years Advanced Exchange Service2 & Limited Hardware Warranty3
• Premium Panel Guarantee – 100% replacement of Professional series monitors sold with systems or as
standalone units if any bright pixel is found, valid within the warranty period, standard or extended where
applicable (replacement units may be refurbished).
*Registered in US and Canada only.
1 Color gamut (typical) is based on CIE1976 (81%) and CIE1931 (72%) test standards.
2 Advanced Exchange Service: Replacement part/unit dispatched, if needed, following completion of phone/online diagnosis.
Fee charged for failure to return defective unit. Availability varies. Other conditions apply.
3 For a copy of the Limited Hardware Warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX 78682
or see www.dell.com/warranty.
www.dell.com/monitors
v.1 7/2011
Dell Professional P2412H 24" Monitor with LED backlights
Dell recommends that customers dispose
used computer hardware, including
monitors, in an environmentally sound
manner. Potential methods include reuse
of parts or whole products and recycling
of product, components and/or materials.
For more information, please visit
http://dell.com/recycling_programs
and www.dell.com/environment
Designed for comfort,
convenience and ease-of-use
*
Pivot
Connectors
Power-saving features
PowerNap dims the monitor to the
minimum brightness level or puts it into
sleep mode based on user preference
Dynamic Dimming automatically dims
onscreen brightness when displayed
images consist of predominantly large
bright and white areas
Height adjustment
130 mm
4°
21°
Tilt
45°
Swivel
