Dell External OEMR XL R210II Quick start guide

Technical Guide
1-socket 1U rack
server providing
the features you
need without a
lot of the
unnecessary
extras.
Dell PowerEdge R210

Dell
PowerEdge R210 Technical Guide 2
This document is for informational purposes only. Dell reserves the right to make
changes without further notice to any products herein. The content provided is as is
and without express or implied warranties of any kind.
Dell, PowerEdge, PowerVault, OpenManage, and ReadyRails are trademarks of Dell,
Inc. Citrix®and XenServer™ are trademarks of Citrix Systems, Inc. and/or one or more
of its subsidiaries, and may be registered in the United States Patent and Trademark
Office and in other countries. ENERGY STAR is a registered trademark of the
Environmental Protection Agency (EPA). Intel, Xeon, and Pentium are registered
trademarks and Core is a trademark of Intel Corporation in the U.S. and other
countries. HP and COMPAQ are trademarks of Hewlett-Packard Company. Broadcom is
a registered trademark and NetXtreme is a trademark of Broadcom Corporation and/or
its affiliates in the United States, certain other countries and/or the EU. CommVault
Galaxy®or Simpana®are registered trademarks of CommVault Systems, Inc. InfiniBand
is a registered trademark and service mark of the InfiniBand Trade Association. Matrox
is a registered trademark of Matrox Electronic Systems Ltd. Microsoft and SQL Server
are either registered trademarks or trademarks of Microsoft Corporation in the United
States and/or other countries. Mellanox is a registered trademark of Mellanox
Technologies, Inc. and ConnectX, InfiniBlast, InfiniBridge, InfiniHost, InfiniRISC,
InfiniScale, and InfiniPCI are trademarks of Mellanox Technologies, Inc. Red Hat is a
registered trademark of Red Hat, Inc. in the United States and other countries. Linux
is a registered trademark of Linus Torvalds. Symantec and Backup Exec are trademarks
owned by Symantec Corporation or its affiliates in the U.S. and other countries.
Novell, SUSE, PlateSpin, and PowerConvert are registered trademarks of Novell, Inc.
QLogic and PathScale are registered trademarks of Qlogic Corporation. VMware is a
registered trademark and vSphere is a trademark of VMware, Inc. in the United States
and/or other jurisdictions. Vizioncore, vRanger, vConverter, and vFoglight are
trademarks of Vizioncore Inc. in the United States of America and other countries.
Winbond is a registered trademark of Winbond Electronics Corporation. Other
trademarks and trade names may be used in this document to refer to either the
entities claiming the marks and names or their products. Dell disclaims proprietary
interest in the marks and names of others.
©Copyright 2010 Dell Inc. All rights reserved. Reproduction or translation of any part
of this work beyond that permitted by U.S. copyright laws without the written
permission of Dell Inc. is unlawful and strictly forbidden.
Initial Release April 2010

Dell
PowerEdge R210 Technical Guide 3
Table of Contents
1Product Comparison...........................................................................7
2New Technologies ........................................................................... 11
2.1 Overview................................................................................ 11
2.2 Detailed Information.................................................................. 11
2.2.1 System Management ............................................................ 11
2.2.2 Software RAID.................................................................... 11
2.2.3 eSATA.............................................................................. 13
3System Overview ............................................................................ 14
4Mechanical.................................................................................... 16
4.1 Chassis Description.................................................................... 16
4.2 Dimensions and Weight............................................................... 16
4.3 Front Panel View and Features...................................................... 17
4.4 Back Panel View and Features ...................................................... 18
4.5 Power Supply Indicators.............................................................. 18
4.5.1 Power Button LED ............................................................... 18
4.5.2 System Status/ID LED........................................................... 18
4.6 NIC Indicators .......................................................................... 18
4.7 Side View ............................................................................... 19
4.8 Internal Chassis View ................................................................. 20
4.9 Rails ..................................................................................... 21
4.10 Fans...................................................................................... 22
4.11 Control Panel LED ..................................................................... 22
4.12 Security ................................................................................. 22
4.12.1 Top Cover Lock Mechanism .................................................... 22
4.12.2 Bezel............................................................................... 22
4.12.3 Trusted Platform Module (TPM)............................................... 22
4.12.4 Power Switch Security.......................................................... 23
4.12.5 Intrusion Alert.................................................................... 23
4.12.6 Secure Mode...................................................................... 24
4.13 USB Ports ............................................................................... 24
4.14 Battery .................................................................................. 24
4.15 Field Replaceable Units (FRU)....................................................... 25
4.16 User Accessible Jumpers, Sockets, and Connectors ............................. 25
5Power, Thermal, Acoustic ................................................................. 26
5.1 Power Supplies......................................................................... 26
5.2 Power Supply Connectors on the Planar........................................... 26
5.3 Environmental Specifications........................................................ 27
5.3.1 Temperature ..................................................................... 27
5.3.2 Relative Humidity ............................................................... 27
5.3.3 Maximum Vibration.............................................................. 27
5.3.4 Maximum Shock.................................................................. 27
5.3.5 Altitude ........................................................................... 27
5.3.6 Airborne Contaminant Level................................................... 27
5.4 Power Supply Unit (PSU) Specifications............................................ 28
5.5 ENERGY STAR®Compliance .......................................................... 28
5.6 Thermal................................................................................. 28

Dell
PowerEdge R210 Technical Guide 4
5.7 Acoustics................................................................................ 29
6Processors .................................................................................... 31
6.1 Overview................................................................................ 31
6.2 Supported Processors ................................................................. 31
6.3 Processor Configurations............................................................. 31
7Memory........................................................................................ 32
7.1 Overview................................................................................ 32
7.2 DIMMs Supported ...................................................................... 32
7.3 Slots/Risers............................................................................. 33
7.4 Speed.................................................................................... 33
7.5 Sparing .................................................................................. 33
7.6 Mirroring ................................................................................ 33
7.7 RAID...................................................................................... 33
8Chipset........................................................................................ 34
8.1 Overview................................................................................ 34
8.2 Direct Media Interface................................................................ 34
8.3 PCI Express Interface ................................................................. 34
8.4 SATA Interface......................................................................... 34
8.5 AHCI ..................................................................................... 34
8.6 PCI Interface ........................................................................... 34
8.7 Low Pin Count (LPC) Interface ...................................................... 35
8.8 Serial Peripheral Interface (SPI) .................................................... 35
8.9 Compatibility Module ................................................................. 35
8.10 Advanced Programmable Interrupt Controller (APIC) ........................... 35
8.11 USB Interface........................................................................... 35
8.12 Real-Time Clock (RTC)................................................................ 36
8.13 GPIO ..................................................................................... 36
8.14 Enhanced Power Management....................................................... 36
8.15 System Management Features....................................................... 36
8.15.1 TCO Timer ........................................................................ 36
8.15.2 Processor Present Indicator.................................................... 36
8.15.3 Error Code Correction (ECC) Reporting ...................................... 36
8.15.4 Function Disable................................................................. 37
8.16 System Management Bus (SMBus 2.0) .............................................. 37
8.17 Intel Anti-Theft Technology ......................................................... 37
8.18 Intel Virtualization Technology for Directed I/O................................. 37
8.19 JTAG Boundary-Scan.................................................................. 38
9BIOS............................................................................................ 39
9.1 Overview................................................................................ 39
9.2 ACPI...................................................................................... 40
9.3 Power Management Modes........................................................... 40
9.3.1 Dell Active Power Controller .................................................. 40
9.3.2 Power Saving BIOS Setting (OS Control) ..................................... 41
9.3.3 Maximum Performance ......................................................... 41
10 I/O Slots....................................................................................... 43
10.1 Overview................................................................................ 43
10.2 PCI Devices ............................................................................. 44
10.3 Boot Order.............................................................................. 47
10.4 NICs...................................................................................... 47

Dell
PowerEdge R210 Technical Guide 5
11 Storage........................................................................................ 48
11.1 Overview................................................................................ 48
11.2 Drives.................................................................................... 48
11.3 RAID Configurations................................................................... 49
11.4 Optical Disk Drive (ODD) ............................................................. 49
11.5 Tape Drives............................................................................. 50
12 Video and Audio ............................................................................. 51
12.1 Video .................................................................................... 51
12.2 Audio .................................................................................... 51
13 Rack Information ............................................................................ 52
13.1 Overview................................................................................ 52
13.2 Rails ..................................................................................... 52
13.3 Cable Management Arm (CMA) ...................................................... 52
14 Operating Systems .......................................................................... 53
15 Virtualization................................................................................. 55
16 Systems Management ....................................................................... 56
16.1 Overview................................................................................ 56
16.2 Server Management ................................................................... 56
16.3 Embedded Server Management ..................................................... 57
16.4 Lifecycle Controller and Unified Server Configurator ........................... 57
16.5 iDRAC6 Express ........................................................................ 58
16.6 iDRAC6 Enterprise ..................................................................... 58
17 Peripherals ................................................................................... 61
17.1 USB....................................................................................... 61
17.2 USB Device.............................................................................. 61
17.3 External Storage....................................................................... 62
18 Packaging Options........................................................................... 62
Tables
Table 1. Comparison of PowerEdge Server Features ......................................8
Table 2. Comparison Overview PERC S100 and S300..................................... 12
Table 3. eSATA Modes ........................................................................ 13
Table 4. Product Feature Summary ........................................................ 14
Table 5. Overall Dimensions and Weight .................................................. 16
Table 6. Specific Measurements ............................................................ 16
Table 7. TPM Pin Signals ..................................................................... 23
Table 8. Power Supply 24 Pins and Signals................................................ 26
Table 9. Power Supply 4 Pins and Signals ................................................. 26
Table 10. PSU Specifications.................................................................. 28
Table 11. Acoustical Specifications.......................................................... 29
Table 12. Processor Information ............................................................. 31
Table 13. Supported Processor Configurations............................................. 32
Table 14. Wake Up Events and States....................................................... 40
Table 15. Summary of R210 Power Management Features............................... 41
Table 16. Power Profiles that R210 BIOS will Expose in BIOS Setup.................... 42

Dell
PowerEdge R210 Technical Guide 6
Table 17. I/O Slot Information ............................................................... 45
Table 18. PCI Card Dimensions ............................................................... 46
Table 19. Bandwidth, Quantities, and Priorities........................................... 46
Table 20. Available Drives..................................................................... 48
Table 21. RAID Configurations................................................................ 49
Table 22. Supported Tape Drives............................................................. 50
Table 23. PowerEdge R210 Rail Information ............................................... 52
Table 24. Supported Microsoft Operating Systems ........................................ 53
Table 25. Supported Linux Operating Systems............................................. 54
Table 26. Supported Virtualization OS ...................................................... 55
Table 27. Unified Server Configurator Features and Description ....................... 58
Table 28. Features List for BMC, iDRAC6, and vFlash..................................... 59
Table 29. USB Controller Priorities .......................................................... 61
Table 30. External Storage.................................................................... 62
Table 31. AMF Single Pack Dimensions and Weights ...................................... 63
Table 32. EMF Single Pack Dimensions and Weights ...................................... 63
Table 33. PowerEdge R210 Volatility........................................................ 66
Table 34. Volatility: Data Writing and Purpose............................................ 68
Table 35. Methodology for Data Input to Memory......................................... 69
Table 36. Methodology for Memory Protection and Clearing ............................ 71
Figures
Figure 1. Server Dimensions.................................................................. 17
Figure 2. Front Panel View ................................................................... 17
Figure 3. Back Panel View .................................................................... 18
Figure 4. Power Button LED .................................................................. 18
Figure 5. Side View ............................................................................ 19
Figure 6. Internal Chassis View .............................................................. 20
Figure 7. R210 Static Rails.................................................................... 21
Figure 8. R210 Mounted In Four-Post Square-Hole Rack ................................. 21
Figure 9. System Fans ......................................................................... 22
Figure 10. Intrusion Switch.................................................................. 23
Figure 11. Internal USB Ports............................................................... 24
Figure 12. Battery on Motherboard........................................................ 25
Figure 13. PCIe x16 Riser Card ............................................................. 43
Figure 14. SAS 6/iR Adapter Card Installed............................................... 44
Figure 15. Rack Adjustability Range....................................................... 52
Figure 16. Packaging ......................................................................... 64

Dell
PowerEdge R210 Technical Guide 7
1Product Comparison
Dell aims to add value to your business by including the features you need without a lot of the
unnecessary extras. Our goal is to deliver value through tailored solutions based on industry
standards, as well as purposeful, innovative design of our servers.
The Dell™ PowerEdge™ R210 was developed with a purposeful design, energy-optimized
technology, simplified systems management, and the flexibility that make it a great first rack
server for the small business or as a specialized application server or edge server for larger
corporations. Dell’s entry 1-socket 1U rack server, the PowerEdge R210, offers value, the
performance of Intel®Xeon®3400 series processors, DDR3 memory, eSATA external storage
expandability, and enterprise-class manageability in an ultra-compact chassis.
Purposeful Design: The PowerEdge R210 follows the 11th generation PowerEdge portfolio
specifications and features the same system design commonality and reliability true to the
entire portfolio. All 11th generation PowerEdge servers are built to make the user experience
easier. We put all external ports, power supplies, and LED lights in the same location for
familiar experience as well as easy installation and deployment.
Robust, metal hard drive carriers and organized cabling are designed to help improve
component access and airflow across the server. The PowerEdge R210’s design also provides a
LED display positioned on the front of the server for ease of monitoring and troubleshooting
condition of the server. It was designed to meet the needs of many IT environments with a
short 15.5 inch chassis to allow for flexible deployment almost anywhere, including space-
constrained environments.
Energy Efficiency: The PowerEdge R210 incorporates Energy Smart design using a low 250 watt
power supply, low-flow fans and logical component layout of the internal components which
aids with airflow direction, helping to keep the server cool and reduce noise as much as
possible. The result is a server with the smallest power footprint within the 11th generation
PowerEdge server portfolio.
Simplified System Management: With the optional advanced embedded systems management
capabilities of Lifecycle Controller, Dell brings comprehensive enterprise class manageability
into the 1-socket space. Lifecycle Controller is delivered as part of the optional iDRAC Express
or iDRAC Enterprise in the PowerEdge R210. The Lifecycle Controller helps to simplify
administrator tasks by performing a comprehensive set of provisioning functions such as system
deployment, system updates, hardware configuration and diagnostics from a single intuitive
interface called Unified Server Configurator (USC) in a pre-OS environment. This helps
eliminate the need to use and maintain multiple pieces of disparate CD/DVD media.
Also part of the Dell OpenManage™ portfolio is the Dell Management Console which is included
with every Dell server and provides IT administrators with a consolidated console view of their
IT infrastructure.
Built with cost-effective RAID options to further protect your valuable data, new eSATA
external storage connectivity options, and the latest Intel®Xeon®processor technology, the
PowerEdge R210 is an ideal entry 1 socket 1U rack for small businesses and larger offices
needing flexibility and manageability in a very small chassis.

Dell
PowerEdge R210 Technical Guide 8
Table 1. Comparison of PowerEdge Server Features
Feature R210 R200
(Predecessors) R310
(Next level up)
Processor Quad-core Intel®
Xeon®processor 3400
series
Dual-core Intel®
Celeron®G1101
Dual-core Intel®
Pentium®G6950
Dual-core Intel®Core
i3 530
Dual-core Intel®Core
i3 540 processors
Single Quad-Core
Intel®Xeon®3300
series
Single Dual-Core
Intel®Xeon®E3100
series
Single Quad-Core
Intel®Xeon®3200
series
Single Dual-Core
Intel®Xeon®3000
series
Single Intel®CoreTM 2
Duo®E4000 series
Single Intel®CoreTM 2
Duo®E7000 series
Single Intel®Pentium®
Dual-Core E2000
series
Single Intel®Celeron®
E1000 and 400 series
Quad-core Intel®
Xeon®processor 3400
series
Dual-core Intel®
Celeron®G1101
Dual-core Intel®
Pentium®G6950
Dual-core Intel®Core
i3 530
Dual-core Intel®Core
i3 540 processors
Front Side Bus DMI 1333MHz DMI @2.5 Gb/s
# Processors 1 1 1
# Cores Dual or Quad Dual or Quad Dual or Quad
L2/L3 Cache 4MB or 8MB 512K~6M Intel®Xeon®: 8M
DT proc: 4, 3 or 2M
Chipset Intel®3420 chipset Intel®3210
chipset+ICH9R Intel®3420 chipset
DIMMs 4 DDR3
Unbuffered w/ECC
1333/1066 MHz
4 DDR2
Unbuffered w/ECC
800/ 667MHz
6 DDR3
Unbuffered w/ECC or
Registered w/ECC
1333/1066MHz
Min/Max RAM 1GB/16GB 512MB/8GB 1GB/32GB
HD Bays 2 x 3.5” or
2 x 2.5” 2 x 3.5” 4 x 3.5” Optional Hot-Swap
Support 2.5" HDDs via
Hot-Swap tray
HD Types Default SATA.
Optional SAS and SSD
via add-in controller
Default SATA.
Optional SAS via add-
in controller
Default SATA.
Optional SAS and SSD
via add-in controller
Ext Drive Bay(s) 1 for slim ODD 1 for slim ODD 1 for slim ODD

Dell
PowerEdge R210 Technical Guide 9
Feature R210 R200
(Predecessors) R310
(Next level up)
Embedded HD
Controller Chipset based SATA Chipset based SATA Chipset based SATA
Optional Storage
Controller NON-RAID:
SAS 5/E
LSI 2032 (For TBU
only)
RAID:
SAS 6/iR Adapter
PERC S100
PERC S300
PERC H200 PERC 6/E
PERC H800
NON-RAID:
SAS 5/E
LSI 2032 (For TBU
only)
RAID:
SAS 6/iR Adapter
PERC 6/E
NON-RAID:
SAS HBA LSI 2032 (For
TBU only), PERC H800
RAID:
SAS 6/iR Modular
PERC H200 (6Gb/s)
PERC H700 (6Gb/s)
with 512MB
PERC H700 (6Gb/s)
NV DRAM with 512MB
or 1G
PERC S100 (software
based)
PERC S300 Modular
(software based)
Availability ECC Memory, ADD-in
RAID, TPM/CTPM ECC memory, Add-in RAID, toolless
chassis
Hot-swap HDD;
Redundant PSU;
Quad-pack LED
diagnostic/LCD with
Hot-swap HDD
chassis
;ECC Memory
Server Mgt. BMC, IPMI 2.0
compliant; Full Dell™
OpenManage™ suite
Optional; iDRAC6
Express, iDRAC6
Enterprise, vFlash
DRAC4
Full Dell™
OpenManage™ suite
BMC, IPMI 2.0
compliant; Full Dell™
OpenManage™ suite
Optional; iDRAC6
Express, iDRAC6
Enterprise, vFlash
I/O Slots 1 x PCIe x16 (True
x16, Gen2); full
height, half length
Support x16
bandwidth card under
25W
Riser 1: One PCIex 8,
one PCIe x4 (w/ x8
connector)
Riser 2: One PCI-X
64/133 and one PCIe
x8
Riser 1: PCIe x16 (x8
routing), Full Height/
Half Length, Gen 2
Riser 2: PCIe x8 (x8
routing), Full Height /
Half Length, Gen 2
2 PCIe G2 slots:
Slot 1: PCIe x16 (x8

Dell
PowerEdge R210 Technical Guide 10
Feature R210 R200
(Predecessors) R310
(Next level up)
RAID See Optional Storage
Controller row above See Optional Storage Controller row above See Optional Storage Controller row above
NIC/LOM 2x GbE LOM w/o TOE
Optional: various NIC
available
2x GbE LOM
Optional: various NIC
available
2x GbE LOM
Optional: various NIC
available
USB 2 front/2 rear/2
internal 2 front/2 rear 2 front/2 rear/2 internal
Power Supplies Non-redundant, 250W
(80+ Bronze)
Auto Ranging
(100V~240V)
Non-redundant, 345W
Non-redundant, 350W
(80+ Bronze)
Optional redundant,
400W (80+ Silver)
Auto Ranging
(100V~240V)
Fans Non-redundant, non-
hot swappable Non-redundant, non- hot swappable Non-redundant, non- hot swappable
Form Factor 1U rack 1U rack 1U rack
Dimensions (HxWxD) 42.6 x 431 x 393.7
(mm) (w/o ear and
bezel)
1.67” x 17.1” x 15.5”
42.67 x 447.0 x 546.1
(mm) (w/o ear and
bezel)
1.68” x 17.6” x 21.5”
42.4 x 434.0 x 610
(mm) ( w/o bezel)
1.67” x 17.10” x
24.00”
Weight Max. 17.76 lbs
(8.058 Kg) Max. 28.7 lbs (13.01 Kg) Max. 33.02 lbs (15 Kg)

Dell
PowerEdge R210 Technical Guide 11
2New Technologies
2.1 Overview
A number of new technologies are used in the PowerEdge R210, including:
•iDRAC6 (new Dell server remote management controller)
•Software RAID PERC S100 and PERC S300
•E-SATA connector
2.2 Detailed Information
2.2.1 System Management
The PowerEdge R210 supports iDRAC6 Express and Enterprise for advanced manageability. For
more information on iDRAC 6 options, please see Section 16, Systems Management.
2.2.2 Software RAID
Dell PowerEdge RAID controller portfolio now offers Enterprise Software RAID in the
PERC S100 and PERC S300 options. PERC S100 and S300 are supported in PowerEdge
11th generation value-based servers.
Software RAID code uses the CPU of the computer system to execute the RAID tasks
including leveraging the CPUs (calculating power as well as sharing memory), internal
bus resources, operating system, and all associated applications. Software-based RAID
uses drives which are attached to the computer system via a built-in I/O interface or a
processor-less host bus adapter (HBA). The RAID function becomes active as soon as
the operating system has loaded the RAID driver software.
Previous generations of PERC controllers have been based on Hardware RAID
technology, the PERC S100 and PERC S300 are based on Software RAID technology. The
software based RAID options provide a cost effective entry-level RAID. Both the
PERCS100 and S300 versions offer similar RAID level support, including RAID 0, 1, 5, 10.
In the case of the PERC S100, it offers a minimal RAID option where the I/O Controller
Hub (ICH) chipset of the motherboard enables a SATA RAID option. There is no new
hardware involved. The PERC S100 controller solution supports up to 4 cabled SATA
Hard Disk Drives (HDD) or Solid State Disk (SSD) drives and is ideal for SMB usage
scenarios.
For the PERC S300, the hardware component of the controller is based on the Dell SAS
HBA (leveraging SAS 6/iR) and allows for both SAS and SATA connectivity. PERC S300
controller solution supports up to 8 cabled or hot plug SAS/SATA Hard Disk Drives
(HDDs).

Dell
PowerEdge R210 Technical Guide 12
Table 2. Comparison Overview PERC S100 and S300
Feature/Spec S100 S300
Interface 3Gb SATA
(SATA II) 3Gb SAS/SATA (SAS 1.1)
I/O Controller Intel® ICH10R Dell 3Gb/s SAS Adapter
(2 internal connectors with x4
SAS ports)
System
Communication Integrated PCIe Lanes
Cache Memory N/A N/A
Battery-backed cache No No
Max Number of
Physical Drives 4 8
HDD Support SATA
(Cabled) SAS & SATA (Cabled or hot plug)
SSD Support SATA
(Cabled) Not Supported
SED Support Not Supported Not Supported
RAID Levels 0, 1, 5, 10 0, 1, 5, 10
Non-RAID Volumes Yes Yes
Max Number of
Virtual Disks per
Controller
8 8
Global Hotspare
Support Yes Yes
Operating System
Support
(Windows Server
Only)
Microsoft®Windows Server®
2003 R2 SP2, 32/64-bit,
Standard & Enterprise
Editions*
Microsoft®Windows Server®
2003 R2 SP2 32-bit Web
Edition
Microsoft®Windows Server®
2008 SP2, 32/64-bit, Standard
& Enterprise Editions
Microsoft®Windows Server®
2008 R2, 64-bit, Web,
Standard, and Enterprise
Editions
Microsoft®Windows Server®2003
R2 SP2, 32/64-bit, Standard &
Enterprise Editions*
Microsoft®Windows Server®2003
R2 SP2 32-bit Web Edition
Microsoft®Windows Server®2008
SP2, 32/64-bit, Standard &
Enterprise Editions
Microsoft®Windows Server®2008
R2, 64-bit, Web, Standard, and
Enterprise Editions
Virtualization
Support Not Supported Not Supported
Storage Management OpenManage™ 6.2 or later OpenManage 6.2™ or later
Note: Microsoft Windows Server 2003 R2 is supported with Service Pack 2. For the most

Dell
PowerEdge R210 Technical Guide 13
up-to-date information, see the Operating System Support Matrix for Dell PowerEdge
Systems on Dell.com.
2.2.3 eSATA
External Serial Advanced Technology Attachment (eSATA) serves as an external
interface for SATA technologies. For customers who want fast (up to 1.5Gbit/s), easy-
to-use external storage that has advanced features such as S.M.A.R.T. (Self-
Monitoring, Analysis, and Reporting Technology) protection, eSATA may be a good
choice.
eSATA devices are not bootable when BIOS is set to RAID mode and are not supported
as a part of Virtual Disks when in RAID mode for S100.
To operate eSATA devices in the Red Hat®Enterprise Linux®4.8 environment, the BIOS
mode must be manually switched from default (AHCI mode) to ATA mode.
Table 3. eSATA Modes
Mode Bootable Hot-Pluggable Restrictions
ATA mode Yes No
AHCI mode Yes Yes RHEL 4.8 is not supported.
RAID mode (S100
enabled) No No Linux and Virtualization OS are not supported

Dell
PowerEdge R210 Technical Guide 14
3System Overview
Table 4. Product Feature Summary
Feature Product Description
Form Factor Rack
Processors Quad-core Intel®Xeon®3400 series processors
Dual-core Intel®Celeron®G1101
Dual-core Intel®Pentium®G6950
Dual-core Intel®Core™ i3 530
Dual-core Intel®Core™ i3 540 processors
Processor Sockets 1
Front Side Bus or
HyperTransport DMI (Direct Media Interface)
Cache 8MB
Chipset Intel®3420 chipset
Memory Up to 16GB (4 U-DIMMs): 1GB/2GB/4GB DDR3 1066MHz or
1333MHz
I/O Slots 1 PCIe x16 G2 slot
RAID Controllers Internal Controllers:
SAS 6/iR
PERC S100 (software-based)
PERC S300 (software-based)
PERC H200
External Controllers:
PERC 6/E with 256MB or 512MB of battery-backed cache
SAS 5/E
PERC H800
LSI2032 PCIe SCSI HBA
Drive Bays Cabled options available:
Up to two 2.5”/ 3.5” SAS, SATA or SSD drives
Maximum Internal
Storage 4TB
Hard Drives 3.5 inch SATA (7.2K rpm): 160GB, 250GB, 500GB, 1TB, 2TB
3.5 inch Near-line SAS (7.2 rpm): 1TB, 2TB
3.5 inch SAS (10K rpm): 600GB
3.5 inch SAS (15K rpm): 146GB, 300GB, 450GB, 600GB
2.5 inch SAS (10K rpm): 146GB, 300GB
Network Interface
Cards 1 Broadcom®NetXtreme™ 5709 with Dual Port Gigabit Ethernet
NIC, Copper, w/TOE PCIe x4
Broadcom®NetXtreme™ 5709 Dual Port Gigabit Ethernet NIC,
Copper, TOE/ISCI PCIe x4

Dell
PowerEdge R210 Technical Guide 15
Feature Product Description
Intel®PRO/ 1000PT Single Port Adapter, Gigabit Ethernet NIC, PCIe
x1
Intel®Gigabit ET Dual Port Adapter, Gigabit Ethernet NIC, PCIe x4
Intel®Gigabit ET Quad Port Adapter, Gigabit Ethernet NIC, PCIe x4
Power Supply Single-cabled power supply (250W)
Availability Quad-pack LED diagnostics, ECC Memory, add-in RAID, TPM/C-
TPM
Video Matrox®G200eW w/ 8MB memory
Remote Management iDRAC6 optional
Systems Management BMC, IPMI 2.0 compliant
Dell™ OpenManage™ featuring Dell Management Console
Unified Server Configurator
Lifecycle Controller enabled via optional: iDRAC6 Express, iDRAC6
Enterprise and vFlash
Rack Support Support for Static ReadyRails™ 4-post and 2-post racks
Operating Systems Microsoft®Factory Installed OS Options:
Microsoft®Windows®Small Business Server 2008, 64-bit Standard
and Premium Edition
Microsoft®Windows Server®2003 R2 with SP2 32-bit Standard and
Enterprise Edition
Microsoft®Windows Server®2003 R2 with SP2 64-bit, Standard and
Enterprise Editions
Microsoft®Windows Server®2008 32-bit, Web, Standard and
Enterprise Edition
Microsoft®Windows Server®2008 64-bit, Web, Standard and
Enterprise Editions
Microsoft®Windows Server®2008 SP2 32-bit, Web, Standard and
Enterprise Edition
Microsoft®Windows Server®2008 SP2 64-bit, Web, Standard and
Enterprise Edition
Microsoft®Windows Server®2008 R2 64-bit Web, Standard and
Enterprise Edition
Microsoft®Windows Server®2008 Foundation
Microsoft®Windows Server®2008 Foundation R2
Microsoft®Non- Factory Installed OS Option:
Microsoft®Windows®Essential Business Server 2008 64-bit
Standard and Premium Edition
Factory Installed Linux OS Options:
Novell®SUSE®Linux®Enterprise Server 11
Red Hat®Enterprise Linux®5.3
Virtualization OS Option:
Microsoft®Windows Server®2008, with Hyper-V™

Dell
PowerEdge R210 Technical Guide 16
4Mechanical
4.1 Chassis Description
The PowerEdge R210 is a 1-socket 1U server. The configuration details are as follows:
•HDD Type : 2x 3.5” Cabled HDD or 2 x 2.5”cabled HDD
•PSU Type: Single Non-Redundant PSU
•Diagnostic: LED
4.2 Dimensions and Weight
Table 5. Overall Dimensions and Weight
Dimensions (HxWxD)
(w/o ear and bezel) 1.68” x 17” x 15.5” (42.6 x 431 x 393.7 mm)
Max Weight 17.76 lbs (8.058kg)
Measurements in Table 6 correspond to the diagram shown in Figure 1 below.
Table 6. Specific Measurements
Xa Xb Ya Yb Yc Za with bezel
Za
without
bezel Zb* Zc
L6 Sys
Wgt
(Kg)
434.0
482.58
42.4
N/A
N/A
31.35
NA
393.7
397.49
5.95

Dell
PowerEdge R210 Technical Guide 17
Figure 1. Server Dimensions
* Zb goes to the nominal rear wall external surface where the motherboard I/O connectors
reside.
4.3 Front Panel View and Features
Figure 2. Front Panel View

Dell
PowerEdge R210 Technical Guide 18
4.4 Back Panel View and Features
Figure 3. Back Panel View
4.5 Power Supply Indicators
4.5.1 Power Button LED
The Power button controls the system's power, turning the unit on and off.
All PowerEdge servers have the Power LED light-pipe integrated in the Power button. The color
of the power LED is green. The lighting pattern must be in the form of a standard Power icon.
Figure 4. Power Button LED
4.5.2 System Status/ID LED
The System Status/ID LED, present on non-modular rack-dense and rackable tower PowerEdge
servers, has the following states:
•No light—System is in the off state (S5, or mechanical (no AC power)
•Blinking Amber—System fault/error condition.
•Steady Blue—Normal operating state (S0)
•Blinking Blue—System ID engaged
This LED remains powered during non-operational (standby, shutdown) modes to enable system
identification.
4.6 NIC Indicators
See the Hardware Owner’s Manual for information.

Dell
PowerEdge R210 Technical Guide 19
4.7 Side View
Figure 5. Side View

Dell
PowerEdge R210 Technical Guide 20
4.8 Internal Chassis View
Figure 6. Internal Chassis View
