dellonda DG113 User manual

Model No. DG113
Thank you for purchasing a Dellonda product. Manufactured to a high standard, this product will,
if used according to these instructions, and properly maintained, give you years of trouble free performance.
DG113 Issue:1 26/04/21
www.dellonda.co.uk
Galvanized Steel Garden/Outdoor/
Storage Shed 1.5 x 0.8 x 1.9m, Pent
Roof - Green

About the Product
Green painted galvanized steel panels, easily assembled to form a rigid and secure structure. Features a pent style roof. Single door tted with
cross bolt and eyelet that accepts padlock (not included) for additional security. Supplied with bolt-down kit for secure xing.
• SPECIFICATION
• Model no: .......................................... DG113
• Width: ............................................. 1500mm
• Depth: ............................................... 800mm
• Height: .......................................... 1900*mm
• Roof type: .............................................. Pent
* Denotes minimum wall height
Safety Instructions
• WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when building this shed.
• Keep children and unauthorised persons away from the working area
• DO NOT use the shed for any purpose other than that for which it is designed.
• Use appropriate safety clothing including eye protection.
• NOTE: The assembly of this product will require assistance.
• DO NOT attempt assembly in windy conditions.
Tools required
• Drill, measuring tape, cross head screwdriver, rivet gun, rubber mallet, sturdy ladder, adjustable spanner, 2 saw horses, 3mm steel drill
bit, 9mm masonry drill bit.
Important Information
Please read these instructions carefully. Note the safe operational requirements, warnings & cautions. Use the product correctly and with care
for the purpose for which it is intended. Failure to do so may cause damage and/or personal injury and will invalidate the warranty. Keep these
instructions safe for future use.
