DeLonghi EAM3500 Installation instructions manual

IMPORTANT INSTRUCTIONS
SAVE THESE INSTRUCTIONS
MODE D’EMPLOI IMPORTANT
CONSERVEZ LES PRESENTES INSTRUCTIONS
INSTRUCIONES IMPORTANTES
REPASE Y GUARDE ESTAS INSTRUCCIONES
LEA ESTE INSTRUCTIVO ANTES DE UTILIZAR EL APARATO
ISTRUZIONI IMPORTANTI
CONSERVARE LE ISTRUZIONI
COFFEE MAKER TYPE EAM3500/CAFETERIE MODÈLE EAM3500/
CAFETERA ELECTRICA MODELO EAM3500/ MACCHINA DA CAFFÈ EAM3500
Register this product on-line and receive a free trial issue of Cook's Illustrated. Visit www.prodregister.com/delonghi.
Visit www.delonghi.com for a list of service centers near you. (U.S. and Canada)
Enregistrez ce produit en ligne et recevez un numéro gratuit de Cook's Illustrated. Visitez www.prodregister.com/delon-
ghi.
Visitez www.delonghi.com pour y voir une liste des centres de réparation proches de chez vous. (É.-U. et Canada).
Registre este producto en línea y reciba un ejemplar gratis de Cook's Illustrated. Visite www.prodregister.com/delonghi.
Visite www.delonghi.com para ver la lista de centros de servicios cercanos a usted. (Estados Unidos y Canada)
Registra questo prodotto "on-line" per ricevere una copia omaggio della rivista. Visita www.prodregister.com/delonghi.
Visita www.delonghi.com per una lista dei centri di servizio a te piu vicini. (Stati Uniti e Canada)
ELECTRONIC CHARACTERISTICS: CARACTÉRISTIQUES ÉLECTRIQUES: CARACTERISTICAS ELECTRICAS:
CARATTERISTICHE ELETTRICHE: 120V˜60HZ 1100W

CDF
L
N
O
Q
U
P
E
G
BA
T
M
S
V
X
Z
H
K
J
I
R
Z1
Z2
I
1
5
3
7
8
9
10
12
11
6
2
4

16
5
1234
678
10
14 15
5
911 12
13

18
18
19
19
20
20
22
22
23
23
24
24
26
26
31
31
21
21
25
25
27
27
28
28
32
32
29
29
17
17
1
2
30
30

INDEX
IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
1 DESCRIPTION OF THE APPLIANCE (see page 3) . . . . . . . . . . . . . . . . . . . . . . . .8
2 SAFETY WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
3 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
4 USING FOR THE FIRST TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
5 TURNING ON AND PREHEATING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
6 PREPARING COFFEE (USING COFFEE BEANS) . . . . . . . . . . . . . . . . . . . . . . . .10
7 CHANGING THE QUANTITY OF COFFEE IN THE CUP . . . . . . . . . . . . . . . . . .12
8 REGULATING THE COFFEE MILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
9 PREPARING ESPRESSO COFFEE WITH PRE-GROUND COFFEE
(INSTEAD OF BEANS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
10 RUNNING OFF HOT WATER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
11 CHANGING THE QUANTITY OF HOT WATER . . . . . . . . . . . . . . . . . . . . . . . .14
12 PREPARING CAPPUCCINOS (FROTHED MILK AND COFFEE) . . . . . . . . . . . . . .14
13 PREPARING FROTHED MILK (WITHOUT COFFEE) . . . . . . . . . . . . . . . . . . . . . . .15
14 CHANGING THE QUANTITY OF COFFEE AND MILK FOR CAPPUCCINOS . . . .15
15 CLEANING AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
15.1 CLEANING THE COFFEE MAKER . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
15.2 CLEANING THE INFUSER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
15.3 CLEANING THE MILK CONTAINER . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
16 CHANGING AND SETTING THE MENU PARAMETERS . . . . . . . . . . . . . . . . . .17
16.1 SETTING THE CLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
16.2 SETTING AUTO-START TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
16.3 DESCALING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
16.4 CHANGING COFFEE TEMPERATURE . . . . . . . . . . . . . . . . . . . . . . . . . . .19
16.5 CHANGING THE LENGTH OF TIME THE APPLIANCE REMAINS ON . . . . .20
16.6 SETTING WATER HARDNESS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
16.7 RESETTING FACTORY DEFAULT SETTINGS . . . . . . . . . . . . . . . . . . . . . . .20
16.8 WASHING PROCESS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
17 CHANGING THE LANGUAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
18 MEANING OF MESSAGES AND WHAT TO DO . . . . . . . . . . . . . . . . . . . . . . .21
19 PROBLEMS THAT CAN BE RESOLVED BEFORE CALLING THE SERVICE CENTER .22
6
Coffee has been used to factory test the appliance and it is therefore completely normal for there to be
traces of coffee in the mill. This appliance is however guaranteed to be new.

7
SHORT CORD INSTRUCTIONS
-Ashort power cord is provided to reduce risks resulting from becoming entangled in or tripping over
a longer cord.
-Longer, detachable power supply cords or extension cords are available and may be used if care is
exercised in their use.
-If an extension cord is used, the marked electrical rating should be at least as great as the electrical
rating of the appliance. If the appliance is provided with 3- wire, grounding type cord, the extension
should be a GROUNDING TYPE 3 - WIRE CORD. The longer cord should be arranged so that it will
not drape over the counter-top or table top where it can be pulled on by children or tripped over.
-Your product is equipped with a polarized alternating current line plug (a plug having one blade
wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If
you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail
to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the
polarized plug.
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed, including the fol-
lowing:
•Read all instructions.
•Do not touch hot surfaces. Use handles and knobs.
•To protect against fire, electrical shock and personal injury, do not immerse cord, plug or appliance
in water or other liquid.
•Never allow the appliance to be used by children
•Unplug from the outlet when not in use and before cleaning. Allow to cool before fitting or taking off
parts, and before cleaning the appliance.
•Do not operate with a damaged cord or plug, or after the appliance malfunctions, or has been dam-
aged in any manner. Return the appliance to the nearest authorized service facility for examination,
repair or adjustment.
•The use of accessory attachments or spare parts not recommended by the appliance manufacturer
may result in fire, electrical shock or personal injury.
•Do not use outdoors.
•Do not let the cord hang over the edge of the table or counter, or touch hot surfaces.
•Do not place on or near a hot gas or electrical burner, or in a heated oven.
•Plug cord into the wall outlet. To disconnect, turn any control to “off”, then remove plug from wall
outlet.
•Do not use the appliance for other than the intended use. This appliance is to be utilized for domes-
tic use only. Any other use is to be considered improper and therefore, dangerous.
WARNING: To reduce the risk of fire or electric shock, do not remove the cover.
No user serviceable parts inside. Repair should be done by authorized servicepersonnel only!
SAVE THESE INSTRUCTIONS
THIS PRODUCT IS FOR HOUSEHOLD USE ONLY

8
1 DESCRIPTION OF THE APPLIANCE (SEE PAGE 3)
A. Grinding coarseness regulator
B. Coffee beans container
C. Bean container lid
D. Central lid for ground coffee
E. Compartment for measuring scoop
F. Cup warmer tray
G. Ground coffee funnel
H. Milk container lid with the wording "FROTHED
MILK - CAPPUCCINO"
I. Milk spouts
J . Milk intake tube for lid with the wording "FRO-
THED MILK – CAPPUCCINO"
K. Nozzle
L. Water tank (removable)
M. Milk container
N. Power cable
O. Cup tray
P. Measuring scoop for pre-ground coffee
Q. Drip tray (removable)
R. Hot water spout
S. Service door
T. Coffee grounds container (removable)
U. Coffee spout (adjustable in height)
V. Mobile drawer
X. Infuser
Z. Control panel
Z1.Milk container lid with the wording "STEAMED
MILK – LATTE"
Z2.Milk intake tube for lid with the wording
"STEAMED MILK – LATTE"
Control Panel
1. Display
2. MENU light.
3. Button to activate or deactivate menu parame-
ter setting mode
4. Button to select ground coffee or, if the MENU
light is on, to display the next parameter on the
menu
5. Button to rinse the appliance or, if the MENU
light is on, to confirm the menu parameters
6. Button to select hot water or, if the MENU light
is on, to confirm the menu parameters
7. Appliance ON/OFF button
8. Coffee strenght selection button
9. One or two cups short coffee button
10.One or two cups normal coffee button
11.One or two cups long coffee button
12.Single Touch Cappuccino - Latte button
2 SAFETY WARNINGS
READ THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE CONSULTATION!
•This appliance is designed to "make espresso coffee" and "heat drinks". Use with care to avoid scalds
from the water and steam jets or through incorrect use.
•This appliance is intended for domestic use only. Any other use is considered improper and thus dange-
rous.
•The manufacturer cannot be held responsible for any damage caused through incorrect, wrong or unrea-
sonable use.
•When using the appliance, do not touch the hot surfaces.
•Never touch the appliance with wet or damp hands or feet.
•The appliance is not intended for use by young children or infirm persons without supervision.
•Never allow children to play with the appliance.
•In the event of failure or malfunction, unplug the appliance from the outlet and do not tamper with it in
any way. If it requires repair, contact an authorized service center only and ask for original spare parts
to be used. Failure to respect the above could reduce the safety of the appliance.

9
3 INSTALLATION
•After unpacking, make sure the appliance is complete and undamaged. If in doubt, do not use it. Contact
professionally qualified personnel.
•The packing elements (plastic bags, polystyrene foam, etc.) should be kept out of the reach of children as
they are a safety hazard.
•Place the appliance on a work surface far away from water taps, basins and sources of heat.
•After positioning the appliance on the work top, leave a space of at least 2 in between the surfaces of
the appliance and the side and rear walls and at least 8 in above the coffee maker.
•Never install the appliance in environments where the temperature may be freezing (the appliance could
be damaged if the water freezes).
•Connect the appliance to a grounded socket with a minimum current rating of 10 amps. The manufac-
turer is not liable for possible accidents caused by failure to do so.
•If the power socket does not match the plug on the appliance, have the socket replaced with a suitable
type by a qualified professional.
•The power cable on this appliance must not be replaced by the user as this operation requires the use of
special tools.
If the cable is damaged or requires replacing, contact an authorized service center only to avoid all risks.
•You should personalize water hardness as soon as possible following the instructions in section 16.6.
To correctly learn how to use the appliance, when starting it for the first time, carefully follow the step-by-step
instructions described in the following paragraphs.
4 USING FOR THE FIRST TIME
1. The first time you use the appliance, select the language.
To set English, plug the appliance into the outlet socket and wait for the following message to be displa-
yed:
PRESS OK TO INSTALL ENGLISH
While the message is displayed, press the button (fig. 1) for at least three seconds until the display
shows:
ENGLISH INSTALLED
The appliance then displays the setting message in English. If you select the wrong language by mistake, fol-
low the instructions in section 17 to choose the right one.
2. After 5 seconds, the appliance displays:
FILL TANK
To fill, remove the tank (fig. 2), rinse and fill with fresh water. Never exceed the MAX line.
Put the tank back and push as far as it will go.
3. Place a cup under the hot water spout (fig. 3). (If the water spout is not in place, INSERT WATER SPOUT
is displayed. Attach it as shown in figure 4, making sure the arrow on the spout is lined up with the arrow
on the control panel of the appliance, fig. 4). The appliance now displays:
PRESS OK
4. Press the OK button (fig. 1) and after a few seconds, a little water will run from the spout (running water
stops automatically)

10
5. The appliance displays:
TURNING OFF PLEASE WAIT
and it goes off.
6. Fill the container with coffee beans (fig. 5).
IMPORTANT: to prevent malfunction, never fill with ground coffee, freeze dried coffee, caramelized beans
or anything else which could damage the appliance.
5 TURNING ON AND PREHEATING
1. Press the button (fig. 6). The appliance displays:
HEATING UP PLEASE WAIT...
to indicate preheating is underway.
2. Once preheating is completed, the appliance displays
RINSING PLEASE WAIT...
and performs an automatic rinse cycle (a little hot water runs from the spouts and is collected in the drip
tray below).
Tip: if you want short coffee (less than 2 oz), to make it hotter, fill the cup with this hot rinsing water first.
Leave it for a few seconds then empty it to preheat the cup.
8. The appliance now displays the ready message:
READY STANDARD TASTE
6 PREPARING COFFEE (USING COFFEE BEANS)
1. The appliance is preset to make coffee with a normal taste. You can also choose coffee with an extra-
light, light, strong or extra-strong taste. To choose the required taste, press the button (fig. 7). The
selected coffee taste will be displayed.
2. Place 1 cup under the spouts to make 1 coffee (fig. 8) or 2 cups for 2 coffees (fig. 9). For a creamier cof-
fee, lower the spouts to bring them as close to the cups as possible (Fig. 10).
3. Press the button to make a short coffee (fig. 11), the button for a normal coffee or the but-
ton for a long coffee.
To make 2 coffees, press the button twice (within 2 seconds).
To change the quantity of coffee delivered automatically into the cup, follow the instructions in section
7.
(The appliance now grinds the beans and starts brewing the coffee into the cup.
Once the desired quantity has been reached, the appliance automatically stops delivering the coffee and
ejects the grounds into the coffee grounds container).
4. After a few seconds, the ready message is displayed again and you can make another coffee.
5. To turn the appliance off, press the button.
Before going off, the appliance performs an automatic rinse cycle (a little hot water runs out from the
spouts and is collected in the drip tray beneath. Take care to avoid scalds).
NOTE 1: If the coffee is delivered a drop at a time or not at all, turn the grinding coarseness regulator (fig.
12) one click clockwise (see section 8).
Turn one click at a time until the coffee is delivered adequately.
