DeLonghi EC7 User manual

instructions
Coffee Maker
EC5/7

Coffee Maker EC5/7 2
Boiler outlet
Water tank
Cap with safety valve
Steam tube
Drip tray
Carafe with lid
Steam nozzle
Adaptor for cups (if fitted)
Filter
Measuring spoon
ON/OFF Switch
Drip tray
Strength selector
(depending on model)
ilter holder
F
Nozzles
Steam knob

Thank you for choosing this coffee machine. To get the very
best out of your new coffee machine it is advisable to read
these instructions before using the appliance. This is the only
way to ensure optimum results and maximum safety.
Using for the first time
Carefully unpack the coffee maker and remove all the packaging
material. Before using wash the accessories and surfaces. Do not
immerse the coffee maker in water; simply wipe with a cloth and
mild detergent if necessary. Do not put in the dishwasher or use
harsh, abrasive cleaners.
For the best tasting results prior to making coffee we recommend
that you flush the coffee maker out with cold water only, without
using coffee to remove any dust which may still be inside the cof-
fee maker. To do this follow the directions ‘Preparing the coffee’.
Installation
• Place the coffee maker on a flat work surface at a safe distance
from taps and sinks.
• Check that the voltage corresponds to that indicated on the
appliance rating plate.The appliance must always be connected
to a well-earthed socket rated at 10A minimum.The manufac-
turer is not liable for damage caused by inadequate earthing of
the appliance.
• In the event of incompatibility between the plug on the appli-
ance and the socket, have the plug replaced by a qualified serv-
ice engineer.
If the cable is damaged or requires replacing, contact a service
centre authorised by the manufacturer only.
• Never install the machine in an environment that can reach a
temperature less than or equal to 0°C (the appliance may be
damaged if the water freezes).
Coffee Maker EC5/7
3

fig. 7
Coffee Maker EC5/7 4
How to prepare the espresso coffee
1Unscrew the water tank cap by turning it anti-clockwise.
2Using the carafe supplied (fig. 1) pour water into the boiler (fig.
2) according to the amounts shown in the table on page 10.
Do not exceed the amounts shown as this could cause the
appliance to malfunction.
While filling the boiler make sure the ON/OFF switch is in the
OFF position.
3Carefully close the boiler cap by turning it clockwise.
4Insert the filter into the filter-holder. (fig. 3).
5Fill the filter with ground coffee using the measures described in
the table (page 10) about 7 g per cup. Fill the filter evenly in
small doses to prevent the ground coffee from overflowing. (fig.
4).
IMPORTANT: Before adding the ground coffee to the filter
holder, make sure there is no coffee left from previous usage.
It is important to use medium ground coffee. (Avoid using too
finely ground coffee otherwise the filter can become blocked).
6Remove any excess coffee from the filter rim (fig. 5).
7Attach the filter holder to the machine by positioning the han-
dle to the left of the boiler outlet, then pushing upwards and
turning the handle to the right (fig. 6).
8Place the carafe with the lid on the drip tray, make sure the
nozzles on the filter holder fit inside the opening on the carafe’s
lid (fig. 7).
Make sure that the steam knob is turned off.
6
fig. 6
fig. 1
fig. 2
fig. 3
fig. 4
fig. 5

9If the machine is supplied with a strength selector, position the
lever according to the flavour of coffee desired,“light”,“medi-
um” or “strong” (fig.8).
10 Press the ON/OFF switch (fig. 9). The switch will light up.
11 The coffee will start to flow after approximately three minutes.
Turn off the power switch after sufficient coffee has been dis-
pensed.
12 Before unscrewing the boiler cap or removing the filter holder,
residual pressure must be released by slowly turning the steam
knob (fig. 10) so that the residual steam can escape.
Note: for safety reasons the cap turns freely and cannot be
opened when the boiler is hot.The tank therefore cannot be
refilled until all the water has been used or the boiler cools
down (to make this a quicker process, open the steam knob).
13 To detach the filter holder, turn the handle from right to left.
To r emove the used coffee lock the filter with the built-in lever
and let the coffee fall out by knocking the over turned filter
holder.
Coffee made directly into cups
The carafe can be used to make 2 or 4 cups of coffee.
If you prefer to make 2 cups only, fit the adaptor for cups to the
lower section of the filter-holder (fig. 12) and place the cups direct-
ly underneath the nozzles. In this way, the coffee will flow directly
into the cups.
1
fig. 10
fig. 11
fig. 12
Coffee Maker EC5/7
5
8
fig. 8
fig. 9

Making Cappuccino
A cappuccino is an espresso coffee with a froth topping made by
heating milk.
•Fill a heat resistant container/jug with approximately 3 fl.oz. of
cold milk for each cappuccino or refer to the table (page 10).
The milk should be cold from the refrigerator and semi-
skimmed as this gives the best results.When choosing the con-
tainer bear in mind that the volume of milk will increase 2 or 3
times.
Models without strength selector
1Follow the steps 1-10 in the paragraph "Making Espresso
Coffee".
Note that the amount of water needed to make 2 cups of cap-
puccino is greater than that required for 2 cups of normal cof-
fee as it is also necessary to produce the steam to froth the
milk.
2Place the steam nozzle in the milk ensuring that the nozzle
opening is just under the surface of the milk, as shown in fig. 13
and open the steam valve by turning the steam knob anti-clock-
wise.
3Move the jug up and down under the steam nozzle as in fig. 14
(this will give maximum froth).
4Froth the milk until there is sufficient froth, then turn the steam
knob clockwise to close the steam valve.
5Allow the coffee to drip through the filter holder into the
carafe, it takes about 3 minutes,then switch the appliance OFF.
Warning: always empty the boiler of any residual water or
steam after using the appliance by slowly turning the
steam knob which will release the residual steam.
6Pour the coffee into 2 large cups then gently pour, or preferably
spoon the frothy milk onto the coffee, then sprinkle on a little
chocolate powder for perfect cappuccino coffee.
7If more cups of cappuccinos are required follow the instructions
above, first ensuring that the boiler has cooled down.
Models fitted with strength selector
1 Follow the steps 1-10 in the paragraph "Making Espresso
Coffee".
For best results the strength selector should be set to “MEDIUM”.
2Allow the coffee to drip into the jug until it reaches the number
2 marked on the side of the jug, then select "CAPPUCCINO".
Follow steps 2-3 in the paragraph “Models without strength
selector” to froth the milk for cappuccino.
1
fig. 13
fig. 14
fig. 15
fig. 16
Coffee Maker EC5/7 6

3Froth the milk until the steam in the boiler has been completely
used then turn the steam knob clockwise to close the steam valve
and set the ON/OFF switch to “OFF”.
Follow steps 6-7 to finish your cappuccino.
Cleaning the milk frother
IMPORTANT: always clean the milk frother and steam
nozzle immediately after use.
Proceed as follows:
•By turning the steam knob (fig. 15), allow a little steam to
come out for a few seconds.
•Unscrew the steam nozzle by turning clockwise (carefully to
avoid being burnt). Check that the 3 holes shown in fig. 16 are
not blocked. If necessary, clean them with the help of a pin
•Wash the steam tube and steam nozzle thoroughly with warm
water.
•Re-attach the steam nozzle.
Hints
Making good espresso and cappuccino is not difficult however it
does require practice.The following tips will help you get the best
results from your machine:
•Warm the cups before filling with coffee.
•Use an espresso coffee for best results.
•Freshly ground coffee provides the best flavour.To maintain
flavour, fresh coffee is best stored in an airtight container in a
cool place, even in the fridge.
Coffee Maker EC5/7
7

Cleaning the filter holder
About every 300 coffees, clean the filter holder for ground coffee
as follows:
•Remove the filter
•Clean the inside of the filter holder. Never wash in a dishwash-
er.
•Rinse all components and clean the metal filter thoroughly in hot
water using a brush (fig. 17). Make sure the holes in the metal fil-
ter are not blocked. If necessary, clean with a pin (fig. 18).
Failure to clean as described above invalidates the guarantee.
Cleaning the espresso boiler outlet
About every 300 coffees, the espresso boiler outlet must be
cleaned as follows:
• check that the coffee machine is not warm and unplug from the
mains;
•using a screwdriver, unscrew the two screws that hold the out-
let of the espresso boiler (fig. 19);
•clean the boiler with a damp cloth (fig. 20);
•clean the outlet thoroughly in hot water using a brush. Make
sure the holes are not blocked. If necessary, clean with a pin.
• rinse the outlet under the tap, still scrubbing it;
• replace the outlet of the espresso boiler ensuring the screws
are replaced firmly.
Failure to clean as described above invalidates the guarantee.
Descaling
It is advisable to clean the calcium from the machine every 300
cups of coffee. It is recommended that the specific (store-bought)
products for descaling espresso coffee machines be used.
Safety Warnings
•This appliance is designed to make coffee.Take care during use
to avoid burns caused by sprays of hot water or steam and
avoid any improper use
•When the appliance is in use, do not touch any of the machine’s
hot surfaces.
•After unpacking, make sure that the machine is complete and
undamaged. In case of doubt, do not use the appliance and seek
the advice of a qualified service professional.
• Packaging materials (plastic bags, foam polystyrene, etc.) should
not be left within the reach of children as this could be a
potential source of danger.
•This appliance is to be used for domestic use only. Any other
use is to be considered improper and therefore, dangerous.
Coffee Maker EC5/7 8
2
fig. 18
fig. 19
fig. 20
fig. 17

•The manufacturer takes no responsibility for damage derived
from improper use.
•Never touch the appliance with wet or damp hands.
•Never allow the appliance to be used by children or unfit per-
sons.
•Do not allow children to play with the appliance.
•In the event of breakdown or malfunctioning, turn the appliance
off immediately and do not touch. For repairs, please contact a
Service Centre authorized by the manufacturer. Failure to observe
the above points may affect the safe use of the appliance.
•The power cable must never be replaced by the user. If the
cable should become damaged, or needs to be replaced, please
contact a Service Centre authorized by the manufacturer.
•When the appliance is not in use, turn off and disconnect the
plug from the socket.
•As with any electrical appliance, whilst the instructions aim to
cover as many eventualities as possible, caution and common
sense should be applied when operating your appliance, particu-
larly in the vicinity of young children.
Coffee Maker EC5/7
9

2
4
4
2
4
2
2
4
Coffee Maker 10
Water quantity in the carafe Coffee quantity
in the filter
Milk quantity
in the carafe
Water level must coincide with steam
symbol on the carafe
Water level must coincide with the
bottom part of the metal band
Use Max. 1 carafe filled to the
level 4
Use Max. 2 carafes filled to the
level 4
To make
2 espressos
2 cappuccinos
4 espressos
4 cappuccinos
Ta b l e
