DeLonghi ECAM22.320 User manual

5713218471/06.12

DE
GB
BEAN TO CUP ESPRESSO AND CAPPUCCINO MACHINE
Instructions for use
ECAM22.320

2
C
C2
C4
BC1
C3
B8
B2 B3 B4 B5 B6 B7
B9 B11 B12B10 C5
B1
2
ELECTRICAL REQUIREMENTS
Before using this appliance ensure that the voltage indicated on the product corresponds with the main voltage in your home, if you are in any doubt
about your supply contact your local electricity company. The exible mains lead is supplied connected to a B.S. 1363 fused plug having a fuse of 13
amp capacity. Should this plug not t the socket outlets in your home, it should be cut o and replaced with a suitable plug, following the procedure
outlined below.
Note: Such a plug cannot be used for any other appliance and should therefore be properly disposed of and not left where children might nd it and
plug it into a supply socket - with the obvious consequent danger.
N.B.We recommend the use of good quality plugs and wall sockets that can be switched o when the machine is not in use.
IMPORTANT: the wires in the mains lead tted to this appliance are coloured in accordance with the following code:
GREEN AND YELLOW EARTH
BLUE NEUTRAL
BROWN LIVE
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:
- The wire which is coloured green and yellow must be connected to the terminal in the plug which is marked with the letter E or by the earth symbol or
coloured green or green and yellow.
- The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.
- The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.
When wiring the plug, ensure that all strands of wire are securely retained in each terminal. Do not forget to tighten the mains lead clamp on the plug. If your electricity
supply point has only two pin socket outlets, or if you are in doubt, consult a qualied electrician. Should the mains lead ever require replacement, it is essential that this
operation be carried out by a qualied electrician and should only be replaced with a exible cord of the same size. After replacement of a fuse in the plug, the fuse cover
must be retted. If the fuse cover is lost, the plug must not be used until a replacement cover is obtained. The colour of the correct replacement fuse cover is that of the
coloured insert in the base of the fuse recess or elsewhere on the plug. Always state this colour when ordering a replacement fuse cover. Only 13amp replacement fuses
which are asta approved to B.S. 1362 should be tted.This appliance conforms to the Norms EN 55014 regarding the suppression of radio interference.
Warning - this appliance must be earthed
Green and Yellow to Earth
13 amp
Fuse
Brown to
live
Cord Clamp
Blue to
neutral

3
3
A14
A17
A18
A15
A
A2 A5
A6
A7
A4
A3
A13
A16
A21
PUSH
A11
A12
A10
A8
A9
A19
C
A
P
P
U
C
C
I
N
O
H
O
T
M
I
L
K
A20
A1

4
PUSH
PUSH
B
A
A B
34A
4B
5678
9101112
13 14 15 16
1817 19
21
25 26
27
28
30
29 31A
31B
23
12
HOT MILK
20
24A
24B
12
22
4

5
PUSH
PUSH
B
A
A B
34A
4B
5678
9101112
13 14 15 16
1817 19
21
25 26
27
28
30
29 31A
31B
23
12
HOT MILK
20
24A
24B
12
22
5

6
CONTENTS
INTRODUCTION .......................................................7
Symbols used in these instructions ...........................................7
Letters in brackets..................................................................... 7
Troubleshooting and repairs .................................................... 7
SAFETY ...................................................................7
Basic safety warnings................................................................7
INTENDED USE.........................................................7
INSTRUCTIONS FOR USE ...........................................7
DESCRIPTION ..........................................................8
Description of the appliance ..................................................... 8
Description of the control panel................................................8
Description of the accessories ...................................................8
BEFORE USE ............................................................8
Checking the appliance............................................................. 8
Installing the appliance ............................................................8
Connecting the appliance .........................................................8
Setting up the appliance........................................................... 8
TURNING THE APPLIANCE ON ...................................9
TURNING THE APPLIANCE OFF .................................9
MENU SETTINGS ......................................................9
Descale ..................................................................................... 9
Adjust time ............................................................................... 9
Auto-o.................................................................................... 9
Auto-start...............................................................................10
Setting the temperature......................................................... 10
Energy saving..........................................................................10
Setting water hardness...........................................................10
Setting the language ..............................................................10
Install lter ............................................................................. 10
Replacing the lter .................................................................10
Default values (reset)..............................................................10
Statistics function ................................................................... 10
MAKING COFFEE ....................................................11
Selecting the coee taste ......................................................11
Selecting the quantity of coee in the cup.............................. 11
Adjusting the grinder..............................................................11
Tips for a hotter coee............................................................11
Making coee using coee beans........................................... 11
Making coee using pre-ground coee ..................................12
MAKING LONG COFFEE............................................12
MAKING CAPPUCCINO AND HOT MILK
NOT FROTHED .....................................................12
Making hot milk (not frothed) ................................................12
Cleaning the cappuccino maker after use................................13
MAKING HOT WATER ..............................................13
CLEANING .............................................................13
Cleaning the machine............................................................. 13
Cleaning the coee grounds container.................................... 13
Cleaning the drip tray and condensate tray............................. 13
Cleaning the inside of the coee machine .............................. 13
Cleaning the water tank..........................................................14
Cleaning the coee spouts......................................................14
Cleaning the pre-ground coee funnel................................... 14
Cleaning the infuser................................................................ 14
DESCALING............................................................ 14
SETTING WATER HARDNESS.................................... 15
Measuring water hardness...................................................... 15
Set water hardness ................................................................. 15
WATER SOFTENER FILTER .......................................15
Installing the lter.................................................................. 15
Replacing the lter .................................................................16
Removing the lter.................................................................16
TECHNICAL DATA....................................................16
DISPOSAL..............................................................16
MESSAGES DISPLAYED ...........................................17
TROUBLESHOOTING...............................................18

7
INTRODUCTION
Thank you for choosing the ECAM 22.320 automatic coee and
cappuccino maker.
We hope you enjoy using your new appliance.
Please take a few minutes to read these instructions for use.
This will avoid all risks and damage to the appliance.
Symbols used in these instructions
Important warnings are identied by these symbols.
It is absolutely vital that these warnings are respected.
Danger!
Failure to observe the warning may result in life threatening
injury from electrical shock.
Important!
Failure to observe the warning may result in injury or damage
to the appliance.
Danger of scalding!
Failure to observe the warning may result in scalding or burns.
Please note :
This symbol indicates important advice or information for the
user.
Letters in brackets
The letters in brackets refer to the caption in the Description of
the Appliance (page 3).
Troubleshooting and repairs
In the event of problems, rst try and resolve them by reading
the information given in the sections on“Messages Displayed”
on page 17 and“Troubleshooting”on page 18.
If this does not resolve the problem or should you require
further information, you should consult Customer Services by
calling the number given on the annexed “Customer Services”
leaet. If your country is not among those listed on the sheet,
call the number given in the guarantee.
If repairs are required, contact De’Longhi Customer Services
only. The addresses are given in the guarantee leaet provided
with the machine.
SAFETY
Basic safety warnings
Danger!
This is an electrical appliance and may cause electrical shocks.
You should therefore follow these safety warnings:
• Nevertouchtheappliancewithdamphandsorfeet.
• Never touch the plug with damp hands.
• Make sure the socket used is freely accessible at all times,
enabling the appliance to be unplugged when necessary.
• Unplug by grasping the plug only. Never pull the power
cable as you could damage it.
• To disconnect the appliance completely, switch o the
main switch at the back of the appliance (g. 2).
• If the appliance is faulty, do not attempt to repair it. Turn
it o, unplug from the mains socket and contact Customer
Services.
• If the plug or power cable is damaged, it must be replaced
by De’Longhi Customer Services only to avoid all risk.
Important!
• Keepallpackaging(plasticbags,polystyrenefoam)away
from children.
• The appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure
that they do not play with the appliance.
Danger : Risk of burns!
This appliance produces hot water and steam may form while
it is in operation.
Avoid contact with splashes of water or hot steam.
INTENDED USE
This appliance is designed and made to prepare coee and heat
drinks.
All other use is considered improper.
This appliance is not suitable for commercial use.
The manufacturer is not liable for damage deriving from
improper use of the appliance.
This is a household appliance only.
It is not intended to be used in:
• sta kitchen areas in shops, oces and other working
environments
• farmhouses
• by clients in hotels, motels and other residential type
environments
• bedandbreakfasttypeenvironments
INSTRUCTIONS FOR USE
Read these instructions carefully before using the appliance.
- Failure to observe these instructions may result in injury
or damage to the appliance.
The manufacturer is not liable for damage deriving from
failure to observe these instructions for use.
Please note :

8
Keeptheseinstructions.
If the appliance is passed to other persons, they must also be
provided with these instructions.
DESCRIPTION
Description of the appliance
(page 3 - A )
A1 Control panel
A2 Grinding dial
A3 Cup shelf
A4 Beans container lid
A5 Pre-ground coee funnel lid
A6 Pre-ground coee funnel
A7 Beans container
A8 Main switch
A9 Socket for power cable connector
A10 Water tank
A11 Infuser door
A12 Infuser
A13 Coee spout (adjustable height)
A14 Coee grounds container
A15 Condensate tray
A16 Cup rest
A17 Drip tray water level indicator
A18 Drip tray
A19 Cappuccino maker
A20 Cappuccino/hot milk ring
A21 Steam/hot water knob
Description of the control panel
(page 2 - B )
A number of buttons on the panel have a dual function. This is
indicated in brackets in the description.
B1. Display: guides the user in using the appliance
B2. button : turns the appliance on and o
B3. MENU button to access the menu (When in the settings
MENU this button functions as an ESC button to exit the
function selected and go back to the main menu)
B4. button to deliver steam to make hot milk-based
drinks
(Quando si accede al MENU’ programmazione, ha la
funzione di <: si preme per scorrere indietro)
B5. button : to perform a rinse cycle.
(When in the settings MENU this button functions as a >
button to scroll forward)
B6. button : to make coee using pre-ground coee.
(When in the settings MENU this button functions as an OK
button to conrm selection made)
B7. Aroma selection button : press to select coee
taste
B8. button : to make 1 cup of short espresso coee
B9. button : to make 2 cups of short espresso coee
B10. LONG button : to make 1 cup of LONG coee
B11. button : to make 1 cup of long espresso coee
B12. button : to make 2 cups of long espresso coee
Description of the accessories
(page 2 - C )
C1. Measure
C2. Descaler
C3. Water softener lter (certain models only)
C4. Total Hardness Test indicator paper
C5. Power cable
BEFORE USE
Checking the appliance
After removing the packaging, make sure the product is
complete and undamaged and that all accessories are present.
Do not use the appliance if it is visibly damaged. Contact
De’Longhi Customer Services .
Installing the appliance
Important!
When you install the appliance, you should observe the
following safety warnings:
• The appliance gives o heat. After positioning the
appliance on the worktop, leave a space of at least 3 cm
between the surfaces of the appliance and the side and
rear walls and at least 15 cm above the coee machine.
• Water penetrating the appliance could cause damage. Do
not place the appliance near taps or sinks.
• The appliance could be damaged if the water inside it
freezes. Do not install the appliance in a room where the
temperature could drop below freezing point.
• Arrange the power cable in such a way that it cannot be
damaged by sharp edges or contact with hot surfaces
(e.g. electrical hot plates).
Connecting the appliance
Important!
Check that the mains power supply voltage corresponds to that
indicated on the rating plate on the bottom of the appliance.
Connecttheappliancetoanecientlyearthedandcorrectly
installed socket with a minimum current rating of 10A only.
If the power socket does not match the plug on the appliance,
have the socket replaced with a suitable type by a qualied
professional.
Setting up the appliance
Please note :
• Coeehasbeenusedtofactorytesttheapplianceandit
is therefore completely normal for there to be traces of

9
coee in the grinder. The machine is, however, guaranteed
to be new.
• Youshouldcustomisewaterhardnessassoonaspossible
following the instructions in the section “Setting water
hardness”(page 15).
1. Insert the power cable connector in socket at the back
of the appliance and connect the appliance to the mains
electricity supply (g. 1). Make sure the main switch at the
back of the appliance is pressed down (g. 2).
You must choose the language (the languages scroll through at
intervals of about 3 seconds):
2. when English appears press the button for a few
seconds (g. 3) until the display shows“ENGLISH set”.
Then follow the instructions indicated on the display:
3. “FILL TANK” : remove the water tank, ll to the MAX
line with fresh water (g. 4A) then insert back into the
appliance (g. 4B).
4. Place a container with a minimum capacity of 100 ml under
the cappuccino maker (g. 5).
5. “TURNSTEAMKNOB”:turnthesteamknobtotheIposition
(g. 5).“HOTWATER Conrm?”appears on the display;
6. To conrm press : the appliance delivers hot
water from the cappuccino maker and then turns o
automatically.
7. Turn the steam knob to the“O”position.
The coee machine is now ready for normal use.
Please note :
• When setting up the appliance, you need to make 4-5
cups of coee or 4-5 cappuccinos before the appliance
starts to give satisfactory results.
TURNING THE APPLIANCE ON
Please note :
Before turning the appliance on, make sure the main switch at
the back of the appliance is pressed down (g. 2).
Each time the appliance is turned on, it performs an automatic
preheat and rinse cycle which cannot be interrupted.
The appliance is ready for use only once this cycle is complete.
Danger of scalding!
During rinsing, a little hot water comes out of the coee spouts
and is collected in the drip tray underneath. Avoid contact with
splashes of water.
• Pressthe button to turn on the appliance (g. 6).
The message“Heating up Please wait”is displayed.
When the heating up is complete, the message changes to
“Rinsing”. By circulating hot water, the appliance heats both
the boiler and the internal circuits.
The appliance is at temperature when the message indicating
the taste and quantity of coee is displayed.
TURNING THE APPLIANCE OFF
Each time the appliance is turned o, it performs an automatic
rinse cycle which cannot be interrupted.
Danger of scalding!
During rinsing, a little hot water comes out of the coee spouts.
Avoid contact with splashes of water.
To turn the appliance o, press the button (g. 6). The
appliance performs a rinse cycle then turns o (stand-by).
Please note:
If you will not be using the appliance for some time, unplug it
from the mains socket:
• rstturntheapplianceobypressingthe button
(g. 6);
• pressthemainswitch(g.2).
Important!
Never press the main switch while the appliance is switched
on.
MENU SETTINGS
When you access the settings menu by pressing the MENU button, the
following menu items can be selected: Descale, Adjust time, Auto-
o, Auto-start, Set temperature, Energy saving, Water hardness, Set
language, Install lter, Replace lter, Default values, Statistics.
Descale
For instructions on descaling, see page 14.
Adjust time
To adjust the time on the display, proceed as follows:
1. Press the MENU button to access the menu;
2. Press the or button until “Adjust time” is
displayed;
3. Press the button ;
4. Pressthe or button to change the hour;
5. Press the button to conrm;
6. Pressthe or button to change the minutes;
7. Press the button to conrm.
The time is set: press MENU to exit menu.
Auto-o
Auto-o can be set so that the appliance turns o after 15 or 30
minutes, or after 1, 2 or 3 hours.
1. Press the MENU button to access the menu;
2. Press the or button until“Auto-o”is displayed;
3. Press the button ;
4. Press the or until the number of minutes/hours

10
of operation is displayed (15 or 30 minutes, or 1, 2 or 3
hours);
5. Press the button to conrm.
The auto-o is set. Press MENU to exit menu.
Auto-start
You can set the auto-start time in order to have the appliance
ready for use at a certain time (for example in the morning) so
you can make coee immediately.
Please note :
To enable this function you must ensure the time is set
correctly.
1. Press the MENU button to access the menu;
2. Press the or button until “Auto-start” is
displayed;
3. Press the button and“Enable?”is displayed;
4. Press the button to conrm;
5. Press the or button to choose the hour;
6. Press the button to conrm;
7. Press the or button to change the minutes;
8. Press the button to conrm;
9. Then press MENU to exit menu.
Once the time has been conrmed, activation of auto-start is
indicated by the symbol which is displayed alongside the
time and under the Auto-start item in the menu.
To disable the function:
1. Select auto-start from the menu;
2. Press the button and“Disable?”is displayed;
3. Press the button to conrm.
The symbol is no longer displayed.
Setting the temperature
If you want to modify the temperature of the water used to
make the coee (low, medium, high), proceed as follows:
1. Press the MENU button to access the menu;
2. Press the or button until “Set temperature” is
displayed;
3. Press the button ;
4. Press the or button until the required
temperature is displayed (low, medium, high);
5. Press the button to conrm.
The temperature is set. Press MENU to exit menu.
Energy saving
Use this function to enable or disable Energy Saving. When
enabled, the function reduces energy consumption in
compliance with EU regulations. When energy saving mode
is enabled an asterisk appears under “Energy saving” in the
menu.
1. Press the MENU button to access the menu;
2. Press the or button until “Energy saving” is
displayed;
3. Press the button and “Enable?” or “Disable?” is
displayed;
4. Press the button to enable or disable the energy
saving mode;
Then press MENU to exit menu.
When the function is enabled, if the machine is not used for
about 1 minute“Energy saving”is displayed.
Please note :
When in energy saving mode, a few seconds may elapse before
the rst coee is delivered as the appliance must heat up
again.
Setting water hardness
For instructions on setting water hardness, see page 15.
Setting the language
To change the language on the display, proceed as follows:
1. Press the MENU button to access the menu;
2. Press the or button until “Set language” is
displayed;
3. Press the button ;
4. Press the or button until the required language
is displayed ;
5. Press the button to conrm;
The language is set. Press MENU to exit menu.
Install lter
For instructions on installing the lter, see section on“Installing
the lter”(page 15).
Replacing the lter
Forinstructionsonreplacingthe lter,seesection on“Replacing
the lter”(page 16).
Default values (reset)
This resets all menu settings and programmed quantities back
to the default values (with the exception of the language
which remains as set).
1. Press the MENU button to access the menu;
2. Press the or button until “Default values” is
displayed;
3. Press the button ;
4. The message“Conrm?”appears on the display;
5. Press the button to conrm and exit.
Statistics function
This displays statistics relating to the machine. To display,
proceed as follows:

11
1. Press the MENU button to access the menu;
2. Press the or button until “Statistics” is
displayed;
3. Press the button ;
4. By pressing the or button you can check:
- how many coees have been made;
- how many times the machine has been descaled;
- the total number of litres of water delivered;
- how many times the water lter has been replaced.
5. Then press the button twice to exit menu.
MAKING COFFEE
Selecting the coee taste
The appliance is set by default to make coee with a standard
taste.
You can also choose one of these tastes:
Extra-mild taste
Mild taste
Standard taste
Strong taste
Extra-strong taste
To change the taste, press the button repeatedly
(g. 7) until the required taste is displayed.
Selecting the quantity of coee in the cup
The appliance is set by default to automatically make the
following quantities of coee:
- short espresso coee, when the button is pressed
(≃40ml);
- long espresso coee when the button is pressed
(≃120ml);
- two short espresso coees when the button is
pressed;
- two long espresso coees when the button is
pressed.
To change the quantity of coee the appliance delivers
automatically into the cup, proceed as described below:
- press the button corresponding to the quantity to be
modied and hold it down until “Program quantity” is
displayed, then release the button;
- when the coee in the cup reaches the desired level, press
the same button again to memorise the new amount.
The machine is now reprogrammed with the new quantities.
Adjusting the grinder
The coee mill is set by default to prepare coee correctly and
should not require regulating initially.
However, if after making the rst few coees you nd that the
coee is either too weak and not creamy enough or delivery
is too slow (in drops), this can be corrected by adjusting the
grinding dial (g. 8).
Please note :
The grinding dial must only be turned while the coee mill is
in operation.
If the coee is delivered too slowly or
not at all, turn one click clockwise.
For fuller bodied creamier coee,
turn one click anticlockwise (do not
turn more than one click at a time
otherwise the coee could be delive-
red in drops).
These adjustments will only be evident after at least 2 cups of
coee have been delivered.
If this adjustment does not obtain the desired result, turn the
dial another click.
Tips for a hotter coee
For hotter coee, you should:
• before delivering the coee, perform a rinse cycle by
pressing the button. Hot water is delivered from
the spout, heating the internal circuits of the appliance
and thus raising the coee temperature;
• warmthecupsbyrinsingthemwithhotwater(usingthe
hot water function);
• increasethetemperatureofthecoeeinthemenu(page
10).
Making coee using coee beans
Important!
Do not use caramelised or candied coee beans as they could
stick to the coee mill and damage it.
1. Fill the container with coee beans (g. 9).
2. Place under the coee spouts:
- 1 cup, if you want to make 1 coee (g. 10);
- 2 cups, if you want 2 coees (g. 11).
3. Lower the spout as close as possible to the cup(s). A
creamier coee is obtained in this way (g. 12).
4. Press the button for delivery of the required coee.
RISTRETTO LUNGO
5. Delivery begins and the selected quantity and taste are
displayed.
Once the coee has been made, the appliance is ready to be
used again.
SHORT LONG

12
Please note :
• While the machine is making coee, delivery can be
interrupted at any moment by pressing one of the coee
buttons.
• At the end of delivery, to increase the quantity of coee in
the cup, just press and hold (within 3 seconds) one of the
coee buttons.
Please note :
For hotter coee, see the section“Tips for a hotter coee”.
Important!
• Ifthecoeeisdeliveredindrops,tooweakandnotcreamy
enough or too cold, read the tips in the“Troubleshooting”
section on page 18.
• Various warning messages could be displayed while
the machine is in use. Their meaning is explained in the
section“Messages displayed”on page 17.
Making coee using pre-ground coee
Important!
• Neverplacecoeebeansinthepre-groundcoeefunnel
as this could damage the appliance.
• Never add pre-ground coee when the machine is turned
o or it could spread through the inside of the appliance
and dirty it.This could damage the appliance.
• Never use more than 1 level measure or it could dirty the
inside of the appliance or block the funnel.
Please note :
If you use pre-ground coee, you can only make one cup of
coee at a time.
1. Make sure the appliance is turned on.
2. Press the button.
3. Make sure the funnel is not blocked, and then add one
level measure of pre-ground coee (g. 13).
4. Place a cup under the coee spouts.
5. Press the 1 cup or button.
6. Delivery begins.
MAKING LONG COFFEE
L0NG coee can be made using either coee beans or pre-
ground coee.
Follow the directions above to prepare the machine and press
the LONG button.
MAKING CAPPUCCINO AND HOT MILK NOT
FROTHED
Danger of scalding!
Be careful of scalding as steam escapes during preparation of
these drinks.
1. When preparing cappuccino, make the coee in a large
cup;
2. Fill a container with about 100 grams of milk for each
cappuccino. In choosing the size of the container, bear in
mind that the milk will double or triple in volume;
Please note :
For a richer denser froth, use skimmed or partially
skimmed milk at refrigerator temperature (about 5°C).
To avoid milk with poor froth or large bubbles, always
clean the cappuccino maker as described in the section
“Cleaning the cappuccino maker after use”.
3. Make sure the cappuccino/hot milk ring is positioned
downwards in the CAPPUCCINO position (g. 14);
4. Press the button. “Heating up Please wait” is
displayed, followed after a few
secondsby“TURNSTEAMKNOB”;
5. Turn the cappuccino maker
outwards and immerse it in the
milk container (g. 15). Take care
not to immerse the black ring;
6. Turn the steam knob to the I position (g. 5). Steam
is delivered from the cappuccino maker, giving the
milk a creamy frothy appearance and making it more
voluminous;
7. For a creamier froth, rotate the container with slow
movements in an upward direction. (You should not
discharge steam for more than 3 minutes at a time);
8. When you have obtained the required froth, stop
steam delivery by turning the steam knob back to the 0
position.
Danger of scalding!
Stop steam delivery before removing the container with
the frothed milk to avoid burns caused by splashes of
boiling milk.
9. Add the milkfroth to the cup ofcoee preparedpreviously.
The cappuccino is ready. Sweeten to taste and, if desired,
sprinkle the froth with a little cocoa powder.
Making hot milk (not frothed)
To make hot milk without froth, proceed as described in the
above section, making sure the cappuccino/hot milk ring of
thecappuccinomakerispositionedupwardsinthe“HOTMILK”
position.

13
Cleaning the cappuccino maker after use
Clean the cappuccino maker each time you use it to avoid the
build-up of milk residues or blockages.
Danger of scalding!
When cleaning the cappuccino maker, a little hot water is
delivered. Avoid contact with splashes of water.
1. Let a little water run for a few seconds by rotating the
steam knob to the I position.Then turn the steam knob to
the 0 position to stop the ow of hot water.
2. Wait a few minutes for the cappuccino maker to cool
down. To remove the cappuccino maker turn it outwards
and slide it down (g. 16).
3. Move the cappuccino/hot milk ring upwards (g. 17).
4. Slide the nozzle downwards (g. 18).
5. Make sure the two holes shown by the arrows in g. 19 are
not blocked. If necessary, clean with a pin.
6. Replace the nozzle, move the ring downwards and put the
cappuccino maker back on the nozzle (g. 20), turning it
and pushing it upwards until it is attached.
MAKING HOT WATER
Danger of scalding!
Never leave the machine unsupervised while hot water is being
delivered. As shown below, stop delivery of hot water when the
cup is full.
The cappuccino maker becomes hot while hot water is being
delivered and must be held by the black ring only.
1. Place a container under the cappuccino maker (as close as
possible to avoid splashes) (g. 15).
2. Turn the steam knob to the I position (g. 5).“HOTWATER”
is displayed and delivery begins.
3. Stop by turning the steam knob to the 0position.
Please note :
If “Energy Saving”mode is active, you may have to wait a few
seconds before the hot water is delivered.
CLEANING
Cleaning the machine
The following parts of the machine must be cleaned regularly:
- coee grounds container (A14),
- drip tray (A18) and condensate tray (A15),
- water tank (A10),
- coee spouts (A13),
- pre-ground coee funnel (A6),
- inside of the machine, accessible after opening the infuser
door (A11),
- infuser (A12).
Important!
• Do not use solvents, abrasive detergents or alcohol to
clean the machine.
You do not need to use chemical products to clean
De’Longhi superautomatic coee machines.
• None of the components can be washed in a dishwasher.
• Do not use metal objects to remove encrustations or coee
deposits as they could scratch metal or plastic surfaces.
Cleaning the coee grounds container
When“EMPTY GROUNDS CONTAINER”is displayed, the grounds
container must be emptied and cleaned.
Unless you clean the grounds container, the above message
will continue to be displayed and the appliance cannot be used
to make coee. To clean (with the machine turned on):
• Removethedriptray(g.21),emptyandclean.
• Empty the grounds container and clean thoroughly to
remove all residues left on the bottom.
• Check the red condensate tray and empty if necessary.
Important!
When removing the drip tray, the grounds container must be
emptied, even if it contains few grounds.
If this is not done, when you make the next coees, the
grounds container may ll up more than expected and clog the
machine.
Cleaning the drip tray and condensate tray
Important!
If the drip tray is not emptied regularly, the water could
overow and seep inside or around the machine.
This could damage the machine, the surface it rests on or the
surrounding area.
The drip tray is tted with a oating level indicator (red)
showing the level of water it contains (g. 22).
Before the indicator protrudes from the cup rest, the drip tray
must be emptied and cleaned.
To remove the drip tray:
1. Remove the drip tray and the grounds container (g. 21);
2. Empty the drip tray and grounds container and wash
them;
3. Check the red condensate tray and empty if necessary.
4. Replace the drip tray and grounds container.
Cleaning the inside of the coee machine
Danger!
Before cleaning internal parts, the machine must be turned
o (see “Turning o”) and unplugged from the mains power

14
supply. Never immerse the machine in water.
1. Check regularly (about once a month) that the inside of
the appliance (accessible after removing the drip tray)
is not dirty. If necessary, remove coee deposits with a
brush and a sponge.
2. Remove the residues with a vacuum cleaner (g. 23).
Cleaning the water tank
1. Clean the water tank (A9) regularly (about once a month)
and each time you replace the water softener lter (if
provided) with a damp cloth and a little mild washing up
liquid.
2. Remove the lter (if present) and rinse with running
water.
3. Replace the lter (if provided), ll the tank with fresh
water and replace the tank.
Cleaning the coee spouts
1. Clean the coee spouts with a sponge or cloth (g. 24A).
2. Check the holes in the coee spout are not blocked. If
necessary, remove coee deposits with a toothpick (g.
24B).
Cleaning the pre-ground coee funnel
Check regularly (about once a month) that the pre-ground
coee funnel (A6) is not blocked.
If necessary, remove coee deposits with a brush.
Cleaning the infuser
The infuser (A12) must be cleaned at least once a month.
Important!
The infuser may not be extracted when the machine is on.
1. Make surethemachine is correctlyturned o (see“Turning
o”on page 9).
2. Remove the water tank.
3. Open the infuser door (g. 25) positioned on the right side
of the machine.
4. Press the 2 red release buttons inwards and at the same
time pull the infuser outwards (g. 26).
Important!
RINSE WITH WATER ONLY
NO WASHING UP LIQUID  NO DISHWASHER
Do not use washing up liquid to clean the infuser as it may
damage it.
5. Soak the infuser in water for about 5 minutes, then rinse
under the tap.
6. Use a brush to remove any coee residues left in the
infuser housing, visible through the infuser door.
7. After cleaning, replace the infuser by sliding it onto the
internal support, then push the PUSH symbol fully in until
it clicks into place.
Please note :
Iftheinfuserisdiculttoinsert,beforeinsertion,squeezethe
two levers shown in the gure to make it smaller.
7. Once inserted, make sure the two red buttons have
popped out again.
8. Close the infuser door.
9. Replace the water tank.
DESCALING
Descale the machine when the message “DESCALE” ashes on
the display.
Important!
Descaler contains acids which may irritate the skin and eyes.
It is essential that you observe the manufacturer’s safety
warnings indicated on the descaler packet and the warnings
relating to the procedure to follow in the event of contact with
the skin and eyes.
Please note:
Use descaler recommended by De’Longhi only. Failure to
descale the appliance as described above also invalidates the
guarantee.
1. Turn the coee machine on.
PUSH

15
2. Press the MENU button to access the menu.
3. Press the or button until“Descale”is displayed.
4. Select by pressing the button. The message
“Descale Conrm?” appears on the display. Press again
to enable the function.
5. “Add descaler Conrm?”appears on the display.
6. Empty the water tank (A10) completely and remove the
water softener lter (if present).
7. Pour the descaler into the tank up to the level A(equal
to one 100ml packet) marked on the back of the tank(g.
27), then add water (1 litre) up to level B (g. 27).
8. Place an empty container with a minimum capacity of 1.5
litres under the cappuccino maker (A19) (g. 5).
Danger of scalding!
Hot water containing acid is delivered from the cappuccino
maker. Avoid contact with splashes of water.
9. Press the button to conrm that the solution has
beenintroduced.“TURN STEAM KNOB” thenappearson
the display.
10. Turn the steam knob to the I position (g. 5). The descaling
programme starts and the descaler liquid comes out
of the cappuccino maker. The descaling programme
automatically performs a series of rinses and pauses to
remove all the scale residues inside the coee machine.
Afterabout30minutes,themessage“FILLTANK!”isdisplayed.
The appliance is now ready for rinsing through with clean
water.
11. Empty the container used to collect the descaler solution
and replace it empty under the cappuccino maker.
12. Remove the water tank, empty, rinse under running
water, ll with clean water and replace.“Rinsing”appears
on the display.
13. Hot water comes out of the cappuccino maker.
14. When the water tank is completely empty, “TURN STEAM
KNOB”isdisplayed.
15. Turn the knob to the 0 position, insert the lter in the tank
(if present), ll the water tank and the machine is ready
for use.
SETTING WATER HARDNESS
The DESCALE message is displayed after a period of operation
established according to the water hardness.
The machine is set by default for a hardness value of 4.
The machine can also be programmed according to the
hardness of the mains water in the various regions so that the
machine needs to be descaled less often.
Measuring water hardness
1. Remove the TOTAL HARDNESS TEST indicator paper
attached to this manual from its pack.
2. Immerse the paper completely in a glass of water for
about one second.
3. Remove the paper from the water and shake lightly. After
about a minute, 1, 2, 3, or 4 red squares form, depending
on the hardness of the water. Each square corresponds to
one level.
Level 1
Level 2
Level 3
Level 4
Set water hardness
1. Press the MENU button to access the menu.
2. Press the or button until “Water hardness” is
displayed.
3. Press the button to conrm the selection.
4. Press the or button repeatedly to set the level as
measured by the indicator paper (see previous section).
5. Press the button to conrm setting.
The machine is now reprogrammed with the new water
hardness setting. Press the MENU button again to exit menu.
WATER SOFTENER FILTER
Certain models are tted with a water softener lter. If this
is not the case with your model, you are recommended to
purchase one from authorised De’Longhi Customer Services.
To use the lter correctly, follow the instructions below.
Installing the lter
1. Remove the lter from the packaging.
2. Turn the date indicator disk (see g. 28) until the next two
months of use are displayed.
Please note :
The lter lasts about two months if the appliance is used
normally. If the coee machine is left unused with the lter
installed, it will last a maximum of three weeks.
3. To activate the lter run tap water into the hole as
indicated in the diagram letting the water run out of the
side openings for at least one minute (g. 29).
4. Take out the tank from the appliance and ll with water.
5. Place the lter in the water tank and submerge it
completely for ten seconds, tilting it to enable the air
bubbles to escape (g. 30).

16
6. Insert the lter into the lter housing and press as far as it
will go (g. 31A).
7. Close the tank with the lid (g. 31B), and then replace the
tank in the machine.
When you install the lter you must notify the appliance of its
presence.
8. Press the MENU button to access the menu;
9. Press the or button repeatedly until “Install
lter”is displayed.
10. Press the button .
11. The message“Enable?”appears on the display.
12. Press the button to conrm selection. “TURN
STEAMKNOB”appearsonthedisplay.
13. Place a container under the cappuccino maker (min.
capacity of 100 ml).
14. Turn the steam knob (g. 5). “HOT WATER Conrm?” is
displayed.
15. Pressthe buttontoconrmselection.Theappliance
begins hot water delivery and the message “Please wait”
is displayed.
16. Once delivery is completed, “TURN STEAM KNOB” is
displayed.
17. Turn the steam knob to the 0 position (g. 5). The
appliance automatically resets to“Coee ready”status.
The lter is now active and indicated by an asterisk displayed
in the menu under the item“Install lter”. You can now use the
coee machine.
Replacing the lter
When the message “Replace lter” is displayed or after two
months (see date indicator) or when the appliance has not
been used for 3 weeks, you should replace the lter.
1. Remove the water tank and used up lter;
2. Take the new lter out of its packet and proceed as
illustrated in points 3, 4, 5 and 6 in the previous section.
3. Place a container under the cappuccino maker (min.
capacity of 100 ml).
4. Press the MENU button to access the menu;
5. Press the or button repeatedly until “Replace
lter”is displayed.
10. Press the button;
11. The message“Conrm?”is displayed.
12. Press the button to conrm selection. “TURN
STEAMKNOB”appearsonthedisplay;
13. Turn the steam knob.“HOT WATER Conrm?”is displayed.
14. Pressthe buttontoconrmselection.Theappliance
begins hot water delivery and the message “Please wait”
is displayed.
15. Oncedeliveryiscompleted,“TURNSTEAMKNOB”appears
on the display. Turn the steam knob to the 0 position. The
appliance automatically resets to“Coee ready”status.
The new lter is now active and you can use the coee
machine.
Removing the lter
If you want to continue use the appliance without the lter, you
must remove it and notify the appliance of its removal. Proceed
as follows:
1. Remove the water tank and used up lter;
2. Press the MENU button to access the menu;
3. Press the or button repeatedly until “Install
lter”is displayed.
4. Press the button ;
5. The message“Disable?”appears on the display;
6. Press the button to conrm and the MENU button
to exit the menu.
TECHNICAL DATA
Voltage: 220-240 V~ 50/60 Hz max. 10A
Absorbed power: 1450W
Pressure: 15 bar
Max. capacity water tank: 1,8 litres
Size: LxHxD: 238x345x430 mm
Cable length: 1,15 m
Weight: 9,1Kg
Max. capacity beans container: 250 g
The appliance complies with the following EU directives:
• Stand-byDirectiveno.1275/2008;
• Low Voltage Directive 2006/95/EC and subsequent
amendments;
• EMC Directive 2004/108/EC and subsequent
amendments;
• All materials and accessories coming into contact with
food conform to EC regulation 1935/2004.
DISPOSAL
In compliance with European directive 2002/96/EC,
the appliance must not be disposed of with
household waste, but taken to an authorised waste
separation and recycling centre.

17
MESSAGES DISPLAYED
MESSAGE DISPLAYED POSSIBLE CAUSE SOLUTION
FILLTANK Insucientwaterinthetank. Fill the tank with water and/or insert it correctly, pushing it
as far as it will go until it clicks into place (g. 4).
EMPTY GROUNDS CONTAINER The grounds container (A13) is full. Empty the grounds container and drip tray, clean and repla-
ce (g. 23).
Important: When removing the drip tray, the grounds con-
tainer must be emptied, even if it contains few grounds.
If this is not done, when you make the next coees, the
grounds container may ll up more than expected and clog
the machine.
GROUND TOO FINE ADJUST
MILL
alternating
WITHTURNSTEAMKNOB
The grinding is too ne and the coee is delivered too slowly
or not at all.
Repeat coee delivery and turn the grinding dial (g. 8) one
click clockwise towards “7” while the coee mill is in ope-
ration. If after making at least 2 coees delivery is still too
slow, repeat the correction procedure, turning the grinding
dial another click until delivery is correct (see the section
“Adjusting the grinder”on page 11).
If the problem persists, turn the steam knob to the I position
and let some water run from the cappuccino maker.
INSERT GROUNDS CONTAINER After cleaning, the grounds container has not been
replaced.
Remove the drip tray and insert the grounds container.
ADD PRE-GROUND COFFEE The“pre-ground coee”function has been selected without
placing any pre-ground coee in the funnel.
Place pre-ground coee in the funnel or deselect the pre-
ground function.
DESCALE The machine must be descaled. The descaling procedure described in the“Descaling”section
(page 14) needs to be performed as soon as possible.
LESS COFFEE Too much coee has been used. Select a milder taste or reduce the quantity of pre-ground
coee.
FILL BEANS CONTAINER The coee beans have run out. Fill the beans container.
The pre-ground coee funnel is clogged. Empty the funnel with the help of a brush, as described in
the section“Cleaning the pre-ground coee funnel”.
INSERT INFUSER ASSEMBLY The infuser has not been properly replaced after cleaning. Insert the infuser as described in the section “Cleaning the
infuser”(page 14).
INSERTTANK The tank is not correctly in place. Insert the tank correctly and press as far as it will go.
GENERAL ALARM The inside of the appliance is very dirty. Clean the inside of the appliance thoroughly, as described
in the section “Cleaning” (page 13). If the message is still
displayed after cleaning, contact De’Longhi Customer Ser-
vices.
REPLACE FILTER The water softener lter has been used up. Replace the lter or remove it as described in the section
“Water softener lter”(page 15).
EMPTY CIRCUIT FILL CIRCUIT
alternating
WITHHOTWATERPRESSOK
The water circuit is empty. PressOKtodeliverwaterfromthespoutuntilitowsout
normally.

18
TROUBLESHOOTING
Below is a list of some of the possible malfunctions.
If the problem cannot be resolved as described, contact customer services.
PROBLEM POSSIBLE CAUSE SOLUTION
The coee is not hot. The cups were not preheated. Warm the cups by rinsing them with hot water.
(N.B. you can use the hot water function).
The infuser has cooled down because 2/3 minutes have
elapsed since the last coee was made.
Before making coee, heat up the infuser by pressing the
button.
A low coee temperature is set. Set a high coee temperature in the menu.
The coee is weak or not
creamy enough.
The coee is ground too coarsely. Turn the grinding dial one click anticlockwise towards “1”
while the coee mill is in operation (g. 8).
Continue one click at a time until coee delivery is satisfac-
tory.
The eect is only visible after 2 coees have been made (see
the section“Adjusting the grinder”on page 11).
The coee is unsuitable. Use pre-ground coee for espresso machines.
The coee is delivered too
slowly or in drops.
The coee is ground too nely. Turn the grinding dial one click clockwise to “7” while the
coee mill is in operation (g. 10). Continue one click at a
time until coee delivery is satisfactory. The eect is only
visible after 2 coees have been made (see the section
“Adjusting the grinder”on page 11).
Coee does not come out of
one or both spouts.
The spouts are blocked. Clean the spouts with a toothpick.
The frothed milk has large
bubbles
The milk is not cold enough or is not semi-skimmed. You should ideally use skimmed or semi-skimmed milk at
refrigerator temperature (about 5°C). If the result is not as
you wished, try changing brand of milk.
The milk is not frothed Cappuccino maker is dirty. Clean as described in the section “Cleaning the cappuccino
maker after use”(page 13).
The ring on the cappuccino maker is NOT in the cappunccino
position.
Place the ring in the CAPPUCCINO position.
Steam delivery stops A safety device stops steam delivery after 3 minutes. Wait, and then enable the steam function again.
The appliance does not turn
on.
It is not plugged into the mains socket. Plug into the mains socket.
The main switch (A8) is not turned on. Push the main switch in the I position (g. 1).
