DeLonghi PRIMADONNA SOUL ECAM61 3 Series User manual

BEAN TO CUP ESPRESSO AND
CAPPUCCINO MACHINE
Instructions for Use
Instructions videos available at:
http://PrimadonnaSoul.delonghi.com
ECAM61X.3Y - 61X.5Y - 61X.7Y

2
A15 A16
A5 A6 A7
A
A17
A18
A8
A10
A9
A11
A14
A12A13
A19
A20
A21
A22
A24
A23 A25
A26
A1
A2
A3A4

3
EN
page 4
Cappuccino MacchiatoEspresso 2X
Espresso
Coffee
B6
B5
D3
D2
D1
D10*
B4
B3
B7 B9
B8 B1 B2
C2
D9
D7
D8
D5D4
D6
B
C D
C8* C9*
C1
C5
C6
C7
C4*
C3
De’LonghiAppliances s.r.l.
ViaL. Seitz, 47 31100 Treviso - ITALY
Tel.[phone]
5413218631/04.15
Decalcificantepermacchinedacaffè
Descalerforcoffee machines
Détartrantpourmachinesà café
EntkalkerfürKaffeemaschinen

4
CONTENTS
1. INTRODUCTION..........................................5
1.1 Letters in brackets .........................................5
1.2 Troubleshooting and repairs..........................5
1.3 Download the App! .......................................5
2. DESCRIPTION.............................................5
2.1 Description of the appliance (page 2 - A) ......5
2.2 Description of the homepage (main screen)
(page 3 - B) ...................................................5
2.3 Description of the accessories (page 3 - C )....5
2.4 Description of the milk container" (page 3 - D)
....................................................................6
3. SETTING UP THE APPLIANCE U..................6
4. TURNING THE MACHINE ON U................... 7
5. TURNING THE APPLIANCE OFF ....................7
6. MENU SETTINGS U...................................7
6.1 Rinsing .........................................................7
6.2 Descaling ......................................................7
6.3 Connectivity..................................................7
6.4 Adjust mill.....................................................8
6.5 Coee temperature .......................................8
6.6 Selecting the language .................................8
6.7 Edit prole.....................................................8
6.8 Auto-o ........................................................8
6.9 General .........................................................9
6.10 Water lter ..................................................9
6.11 Water hardness ............................................9
6.12 Default values ..............................................9
6.13 Emptying the circuit ....................................9
6.14 Statistics........................................................9
7. MAKING COFFEEU.................................. 10
7.1 Making coee using coee beans................10
7.2 Your coee at a touch..................................10
7.3 Customising the beverages .........................10
7.4 Making coee using pre-ground coee.......10
7.5 Bean Adapt Technology & Espresso SOUL ...11
7.6 General indications for making coee-based
beverages....................................................11
7.7 Tips for a hotter coee.................................11
8. COFFEE POT U........................................ 11
8.1 Cleaning the coee pot ..............................12
9. OVER ICE (ECAM61X.7Y ONLY).....................12
10. MAKING MILKBASED BEVERAGES U....... 12
10.1 Filling and attaching the milk container .....12
10.3 Your milk-based beverage at a touch ..........13
10.4 Customising the beverages .........................14
10.5 Cleaning the milk container after use ........14
11. MUG TO GO (ECAM61X.7Y ONLY)..................14
11.1 Cleaning the travel mug after use ...............15
12. TEA FUNCTION......................................... 15
13. DELIVERING HOT WATER U..................... 16
13.1 Your beverage at a touch.............................16
13.2 Customising the beverages .........................16
14. GUIDED BEVERAGE CUSTOMISATION MY U
............................................................... 16
15. SELECTING YOUR PERSONAL PROFILE U.. 17
16. CLEANING U.......................................... 17
16.1 Cleaning the machine .................................17
16.2 Cleaning the internal circuit........................17
16.3 Cleaning the coee grounds container........17
16.4 Cleaning the drip tray and drip tray grille....18
16.5 Cleaning the inside of the machine ............18
16.6 Cleaning the water tank..............................18
16.7 Cleaning the coee spouts ..........................18
16.8 Cleaning the pre-ground coee funnel .......19
16.9 Cleaning the infuser....................................19
16.10Cleaning the milk container (D)...................19
17. DESCALING U......................................... 20
18. SETTING WATER HARDNESS U................. 21
18.1 Measuring water hardness..........................21
18.2 Setting water hardness ...............................21
19. WATER SOFTENER FILTER U.................... 21
19.1 Installing the lter ......................................22
19.2 Replacing the lter......................................22
19.3 Removing the lter .....................................22
20. TECHNICAL DATA...................................... 22
20.1 Tips for Energy Saving.................................23
21. DISPLAYED MESSAGES U........................ 23
22. TROUBLESHOOTING U............................ 28

5
1. INTRODUCTION
Thank you for choosing this bean to cup espresso and cappuc-
cino machine.
Take a few minutes to read this Instruction for Use. This will
avoid all risks and damage to the appliance.
1.1 Letters in brackets
The letters in brackets refer to the legend in the description of
the appliance on pages 2-3.
1.2 Troubleshooting and repairs
In the event of problems, rst try and resolve them by reading
the information given in sections “21. Displayed messages u”
and “22. Troubleshooting u”.
If this does not resolve the problem or you require further in-
formation, you should consult customer services by calling the
number given on the annexed "Customer Service" sheet.
If your country is not among those listed on the sheet, call the
number given in the guarantee. If repairs are required, contact
De’Longhi customer services only.The addresses are given in the
guarantee certicate provided with the machine.
1.3 Download the App!
Download the App then follow the instructions in the App to
create your account.
A number of functions can be controlled remotely using the
De’Longhi Coee Link App.
In the App, you can also nd information, tips and curious facts
about the world of coee, together with information on your
machine at your ngertips.
UThis symbol highlights the functions you can control or consult using the App.
You can also create new beverages and save them in your
appliance.
Please note:
• To access the functions from the App, enable connec-
tivity from the appliance's settings menu (see “6.3
Connectivity”).
• Check compatible devices on "compatibledevices.delong-
hi.com".
2. DESCRIPTION
2.1 Description of the appliance (page 2 - A)
A1. Cup shelf
A2. Pre-ground coee funnel lid
A3. Pre-ground coee funnel (removable)
A4. Pre-ground coee measure compartment
A5. Beans container lid
A6. Beans container
A7. Main switch (ON/OFF)
A8. Power cord connector socket
A9. button: to turn the appliance on and o (standby)
A10. Infuser door
A11. Removable infuser
A12. Milk container and descaling spout connector door
A13. Milk container and descaling spout connector
A14. Coee/hot water spouts (adjustable height)
A15. Central outlet cover
A16. Top coee spout
A17. Bottom coee spout
A18. Condensate tray
A19. Water tank lid
A20. Water tank
A21. Cup tray
A22. Tray grille
A23. Drip tray water level indicator
A24. Drip tray
A25. Coee grounds container
A26. Coee grounds container support
2.2 Description of the homepage (main screen)
(page 3 - B)
B1. Bean Adapt Technology (enable from App): see “7.5 Bean
AdaptTechnology & Espresso SOUL”
B2. Customisable proles (see “15. Selecting your personal
prole u”)
B3. To display and customise the beverage settings
B4. Directly selectable beverages
B5. Display
B6. Appliance settings menu
Maintenance required lights
B7. Descaling required light
B8. Milk container cleaning required
B9. Filter exhausted light
2.3 Description of the accessories (page 3 - C )
C1. "Total Hardness Test" indicator paper (attached to the
Quick Guide)
C2. Pre-ground coee measure (in the compartment (A4))
Accessories in the Starter Set:
C3. Descaler

6
C4. Water softener lter (*certain models only)
C5. Cleaning brush
C6. Power cord
C7. Descaling spout (keep the spout safely after each use)
Accessories with certain models only:
C8. Coee pot (*certain models only)
C9. Travel mug (*certain models only)
2.4 Description of the milk container" (page 3 - D)
D1. Milk container lid
D2. Milk rell lid
D3. Froth adjustment/Clean dial)
D4. Dial seat
D5. Milk container connector (removable for cleaning)
D6. Milk spout seat
D7. Milk spout (adjustable height)
D8. Milk spout extension (adjustable
D9. Milk intake tube
D10. Milk container (*thermal in certain models)
3. SETTING UP THE APPLIANCE U
Please note:
• Possible traces of coee in the mill are the result of settings
tests performed on the appliance before sale, proof of the
meticulous care and attention we invest in our products.
• The rst time you use the appliance, all removable ac-
cessories (milk container (D), travel mug (C9), coee pot
(C8), water tank (A20)) destined to come into contact with
water or milk should be rinsed with hot water. We recom-
mend washing the milk container in a dishwasher.
• You should customise water hardness as soon as possible
following the instructions in section “18. Setting water
hardness u”.
1 2
1. Plug the power cord connector (C6) into the socket (A8) at
the back of the appliance and connect the appliance to the
mains power supply (g. 1). Make sure the main switch (A7)
at the back of the appliance is pressed (g. 2);
2. Press the ag corresponding to the desired language.
Then follow the instructions which appear on the appliance
display (B5):
3 4
3. Remove the water tank (A20) (g. 3) and ll to the MAX
line (marked on the inside of the tank) with fresh water
(g. 4);
4. Then put the tank back (g. 5) and conrm by pressing
"Next";
56
5. Fill the beans container (A6) (g. 6), then conrm by press-
ing "Next".
78
6. Insert the descaling spout (C7) (in the Starter Set) on the
milk container connector (A13) (g. 7) and place a contain-
er with a minimum capacity of 100 ml under the coee
spouts (A14) and descaling spout (g. 8);

7
7. Press "OK" to ll the water
circuit: the appliance
delivers water from the
spouts (g. 9);
8. At the end of delivery, the
appliance proceeds with
heating by performing
a rinse cycle, delivering
hot water from the coee
spouts (A14). When at
temperature, the appli-
ance proposes an intro-
ductory video explaining
the home page (B).
Please note:
• The rst time you use the appliance, you need to make
4-5 cappuccinos before the results in the cup will be
satisfactory.
• The rst time you use the machine, the water circuit is
empty and the appliance could be very noisy.The noise
becomes less as the circuit lls.
• After turning the appliance on for the rst time, remove
the spout (C7) and store safely. You will need it to perform
certain maintenance operations on the appliance.
4. TURNING THE MACHINE ON U
Please note:
• Before turning the appliance on, make sure the main
switch (A7) is pressed (g. 2).
• Each time the appliance is turned on, it performs an auto-
matic preheat and rinse cycle which cannot be interrupted.
The appliance is ready for use only after completion of this
cycle.
1. To turn the appliance on,
press the button
(A9) (g. 10): the appli-
ance comes on;
2. When at temperature,
the appliance performs
a rinse cycle delivering
hot water from the coee
spouts (A14). As well as
heating the boiler, this
also heats the internal
circuits by circulating hot
water.
5. TURNING THE APPLIANCE OFF
Whenever the coee machine is turned o after being used to
make coee, it performs an automatic rinse cycle.
9
10
1. To turn the appliance o, press the button (A9) (g.
10).
2. I f envisaged, the appliance performs a rinse cycle, deliver-
ing hot water from the coee spouts (A14), then goes o
(stand-by).
Please note:
If you will not be using the appliance for some time, unplug
from the mains socket:
3. Release the main switch (A7) at the back of the appliance
(g. 2).
Important!
Never press the main switch while the appliance is on.
6. MENU SETTINGS U
6.1 Rinsing
Use this function to deliver hot water from the coee/hot water
spouts (A14) (and, if inserted, the descaling spout (C7)), to clean
and heat the appliance’s internal circuit.
Place a container with a minimum capacity of 100ml under the
spouts (g. 8).
To enable the function, proceed as follows:
1. Press the settings menu (B6);
2. Select "Rinsing";
3. Press "OK" to start delivery: after a few seconds, hot water
is delivered to clean and heat the appliance’s internal cir-
cuit (g. 9);
4. To stop rinsing, press "Cancel" or wait for rinsing to stop
automatically.
Please note:
• If the appliance is not used for more than 3-4 days, when
you turn it on again, we strongly recommend performing
2-3 rinses before use;
• After cleaning, it is normal for the grounds container (A25)
to contain water.
6.2 Descaling
For instructions on descaling, see section“17. Descaling u”.
6.3 Connectivity
Use this function to enable or disable connectivity. Proceed as
follows:
1. Press the settings menu (B6);
2. Select "Connectivity";
3. Press "Next";
4. Enable the Wi-Fi connection and remote control (via the
Delonghi Coee Link App);
5. The appliance PIN, needed to connect by App, is displayed
on the screen;
6. Press "←" to save the new selection and go back to the
homepage (B).

8
In the settings menu (B6), the symbol indicating the connection
status alternates with the other symbols (e.g. descaling, etc.)
Symbol on homepage Meaning
The appliance is connected
The appliance is connected
to the home Wi-Fi, but there
is no network, or the cloud
cannot be reached
--
Connection disabled. To en-
able, enter the "Settings"
menu" (B6)
Please note:
If remote connection is o, a number of the App's functions will
not be available (e.g. beverage delivery).
If you change name of password of the wi or if you connect to
a new wi network, you need to reset connectivity as follows:
1. proceed as explained from step 1 to 3;
2. press“Reset”;
3. press“Ok”to conrm the delating of the network settings;
4. reconnect with the App selecting the new settings.
6.4 Adjust mill
We suggest you access Bean AdaptTechnology in the Cof-
fee Link App to adjust this parameter to an appropriate setting
for the coee beans used
If, on the other hand, you want to adjust the parameter from the
settings menu, proceed as follows:
1. Press the settings menu (B6);
2. Select "Adjust mill". A tutorial appears on the display (B5)
with suggestions on the grinding level; if you want to skip
this presentation, press "Skip" or "Next" to continue with
the tutorial;
3. Follow the previous instructions in the tutorial to select the
required grinding neness by pressing directly on one of
the selectable numbers in the highlighted interval;
4. Press "OK" to conrm the selection: "The result in the cup
will be perceived after about 5 deliveries";
5. Press "OK" to conrm and go back to the homepage (B)
with the new selection saved.
Please note:
• After carrying out the above procedure, we recommend
delivering at least 5 coees before adjusting again. If cof-
fee delivery is still not correct, repeat the procedure.
• You cannot adjust more than one grinding level at
a time unless at least two coee-based beverages
have been made.
• Press "Default" to reset the default values of the coee mill
(indicated by a star).
6.5 Coee temperature
To change the temperature of the water used to make the cof-
fee, proceed as follows:
1. Press the settings menu (B6);
2. Select "Coee temperature";
3. Access Bean Adapt Technology from the App to get
the best from this function. If, on the other hand, you want
to proceed from the settings menu, press "OK";
4. Select the required temperature from those proposed;
5. Press "←" to save the new selection and go back to the
homepage (B).
Please note:
• A dierent temperature can be set for each prole (see sec-
tion“14. Guided beverage customisation (My) u”).
• Varying the temperature has most eect for long
beverages.
6.6 Selecting the language
To modify the language of the display (B5), proceed as follows:
1. Press the settings menu (B6);
2. Select "Select language";
3. Press the ag corresponding to the language you want
to set (press "Next" or "Back" to display all the languages
available). The display is immediately updated with the
selected language;
4. Press "←" to save the new selection and go back to the
homepage (B).
6.7 Edit prole
You can use this function to modify the image and colour of the
icon for each prole. To customise the icon, proceed as follows:
1. Press the settings menu (B6);
2. Select "Edit prole";
3. Select the prole and press "Next";
4. Customise as you wish, then press "OK" to continue.
5. Press "←" to save the new selection and go back to the
homepage (B).
Please note:
Depending on the model, 3 or 5 proles can be customised.
6.8 Auto-o
Auto-o can be set so that the appliance goes o after 15 or 30
minutes, or 1, 2 or 3 hours.
To programme Auto-o, proceed as follows:
1. Press the settings menu (B6);
2. Select "Auto-O";
3. Select the desired time interval (15 or 30 minutes, or 1, 2
or 3 hours).

9
4. Press "←" to save the new selection and go back to the
homepage (B).
6.9 General
1. Press the settings menu (B6);
2. Select "General";
Here you can enable or disable the following functions with a
simple touch:
- "Beep": when enabled, the appliance beeps whenever an
operation is performed.
- "Energy saving": use this function to enable or disable en-
ergy saving. When enabled, the function reduces energy
consumption in compliance with European regulations.
When enabled, the symbol appears on the icon in the
settings menu (B6).
6.10 Water lter
For instructions on the lter (C7), see section“19.Water softener
lter u”.
6.11 Water hardness
For instructions on setting water hardness, see section “18. Set-
ting water hardness u”.
6.12 Default values
This resets all menu settings and user customisation back to
the default values (with the exception of the language, which
remains as set, and the statistics).
Proceed as follows:
1. Press the settings menu (B6);
2. Select "Default values";
- To reset the appliance to the default values, press "OK";
otherwise to reset the individual prole, press the arrow
to pass to the next screen, select the prole to reset and
press "OK";
3. Press "OK" again to conrm the reset to default values;
4. Press "OK" to exit the menu and go back to the homepage
(B).
Please note:
When the appliance (not the individual prole) has been reset
to the default values, the machine proposes the introductory
video again.
6.13 Emptying the circuit
To avoid the water in the circuit freezing if the appliance is to be
left idle for a long period of time, or before taking it to customer
services, we recommend emptying the water circuit.
Proceed as follows:
1. Press the settings menu (B6);
2. Select "Empty water circuit";
3. Press "OK" to start the guided procedure;
4. Empty the grounds container (A25) and drip tray (A24) (g.
11), then press "Next";
11 12
5. Insert the spout (C7) on the milk container connector (A13)
(g. 7);
6. Position a 0.5 litre container under the spout (g. 8). Press
"OK";
7. The appliance performs a rinse cycle with hot water from
the spouts;
8. At the end of rinsing, remove the water tank (A20) (g. 12)
and empty; if present, remove the water softener lter (C7)
from the water tank and press "Next";
9. Put the empty water tank back in the appliance and press
"OK";
10. Wait for the appliance to empty the circuit; (Important:
hot water from the spouts!). As the water circuit empties,
the appliance could become noisier. This is part of normal
operation.
11. When the circuit is empty, extract and empty the drip tray,
put back in the appliance and press "Next";
12. Press "OK". The appliance goes o (standby).
The next time the appliance is turned on, follow the instructions
in section“3. Setting up the appliance U”.
6.14 Statistics
This displays statistics relating to the machine. To view the sta-
tistics, proceed as follows:
1. Press the settings menu (B6);
2. Select "Statistics". To display the information and scroll be-
tween screens, press "Next" or "Back".
3. Press "←" to go back to the homepage (B).

10
7. MAKING COFFEEU
7.1 Making coee using coee beans
Important!
Do not use green, caramelised
or candied coee beans as they
could stick to the coee mill
and make it unusable.
1. Place 1 or 2 cups under
the coee spouts (A14);
2. Lower the spouts as near
as possible to the cup (g.
13). This makes a creami-
er coee.
3. Select the coee you want
to make as described in
the following paragraphs.
7.2 Your coee at a touch
To deliver coee-based bever-
ages, press the image on the
homepage (B) corresponding
to the desired coee (e.g. es-
presso, g. 14). The appliance
proceeds with preparation.
The image of the selected
beverage appears on the
display (B5), together with a
progress bar which gradually
lls as the operation proceeds
and a description of each indi-
vidual phase (grinding, brew-
ing coee).
At the end of preparation, the message "Your beverage is
ready!" appears on the display “. The appliance is now ready to
be used again.
7.3 Customising the beverages
To make coee-based bever-
ages with customised param-
eters, proceed as follows:
1. Press (B3) at the
bottom of the image cor-
responding to the desired
coee (e.g. espresso, g.
15). The parameters that
can be customised ac-
cording to your tastes ap-
pear on the display (B5):
13
Espresso
ONE TOUCH
14
Espresso
Full
adjustable
drink SETTINGS
15
Quantity
Aroma
2. After setting the parameters, press "Start". The appliance
starts making the coee and the image of the selected
beverage appears on the display, together with a progress
bar which gradually lls as the operation proceeds and a
description of each individual phase (grinding, brewing
coee);
3. When delivery has ended, press "Save" to save the new
settings, or "Cancel" to retain the previous parameters.
Please note:
If you save the new settings, they are memorised ONLY in the
selected prole.
4. Press "OK" to go back to the homepage (B).
The appliance is ready to be used again.
7.4 Making coee using pre-ground coee
Important!
• Never add pre-ground coee when the machine is o or it
could spread through the inside of the machine and dirty
it.This could damage the machine.
• Never use more than 1 level measure (C2) as it could soil
the inside of the coee machine or block the funnel (A3).
• When using pre-ground coee, only one cup can be made
at a time.
• Making LONG coee: halfway through preparation, when
requested by the appliance, add one level measure of pre-
ground coee and press "OK".
• You cannot make a DOPPIO+ coee using pre-ground
coee.
1. Press (B3) at the bottom of the image corresponding
to the desired coee (e.g. Espresso, g. 15).The parameters
that can be customised according to your tastes appear on
the display (B5);
2. Select pre-ground coee:
Coee type
3. Lift the pre-ground coee funnel lid (A3), make sure the
funnel (A3) is not blocked, then add one level measure (C2)
of pre-ground coee (g. 16): press "OK";

11
16
4. Select the coee quanti-
ty and press "Start". The
appliance starts making
the coee and the image
of the selected beverage
appears on the display,
together with a progress
bar which gradually lls
as the operation proceeds
and a description of each
individual phase (grind-
ing, brewing coee).
7.5 Bean Adapt Technology & Espresso SOUL
A coee expert at your ngertips to help you optimise coee
brewing and the result in your cup in just a few steps.
The smart technology automatically adjust the machine accord-
ing to the coee beans used - from grinding neness to brew-
ing, each phase will be regulated to get the best results from
the coee bean.
Download the Coee Link App to nd out more.
Once the settings have been saved in the "Bean Adapt Technol-
ogy" section of the App, you can use the "Espresso SOUL" bever-
age on the homepage.
To make espresso coee, follow the instructions in section “7.2
Your coee at a touch”.
Please note:
You can modify the quantities in the “Espresso SOUL” recipe as
described in section“7.3 Customising the beverages”.
7.6 General indications for making coee-based
beverages
• While the machine is making coee, delivery can be inter-
rupted at any moment by pressing "Stop" or "Cancel".
• As soon as delivery has ended, to increase the quantity of
coee, just press "Extra". When the required quantity is
reached, press "Stop".
• Various alarm messages may appear on the display (B5)
while using the appliance "FILL TANK WITH FRESH
WATER", "EMPTY GROUNDS CONTAINER", "EMPTY DRIP
TRAY" etc.). Their meaning is explained in section“21. Dis-
played messages u”.
• If the coee emerges drop-by-drop, too weak and not
creamy enough, or too cold, read the tips in sections “6.4
Adjust mill”and“22. Troubleshooting u”.
• If "Energy Saving" mode is active, you may have to wait a
few seconds before the rst coee is delivered
7.7 Tips for a hotter coee
For hotter coee, proceed as follows:
• perform a rinse cycle by selecting "Rinsing" in the settings
menu (B6) (section“6.1 Rinsing”);
• warm the cups with hot water using the hot water function
(see section“13. Delivering hot water u”);
• increase the coee temperature (section “6.5 Coee
temperature”).
8. COFFEE POT U
Based on espresso coee, this beverage is light and balanced,
with a ne layer of froth, ideal to share in company.
Optional accessory in certain models:
Pot
(capacity 1 litre)
Type: DLSC021
EAN: 8004399333642
To make the beverage, proceed as follows:
1. On the homepage (B), press the image corresponding to
the coee pot;
2. Select the taste required for each single cup and the num-
ber of cups required:
Taste per single
cup
Quantity in
cup* Number of cups
Extra mild Extra-large cup
(≃ 250 ml) from 1to 3
Mild Large cup
(≃ 190 ml) from 1to 4
Medium Medium cup
(≃ 150 ml) from 1to 5
Strong Small cup
(≃ 125 ml) from 1to 6
* The quantities indicated are approximate and may vary ac-
cording to the type of coee.
3. Press "Next" to move on to the next step;
3. Fill the tank (A20) with water and ll the beans container
(A6) (g. 17). Once you have made sure there is sucient
water and coee for the beverages you want to prepare,
press "Next";
1817

12
4. Place the coee pot (C8) under the spouts (g. 18). Press "OK";
5. The appliance proceeds with delivery and the image of the
selected beverage appears on the display (B5), together
with a progress bar which gradually lls as the operation
proceeds and a description of each individual phase (grind-
ing, brewing coee).
Please note:
"Cancel "or Stop": press to stop preparation completely and go
back to the homepage.
6. When delivery has ended, press "Save" to save the new
settings, or "Cancel" to retain the previous parameters.
7. Press "OK" to go back to the homepage (B).
The appliance is ready to be used again.
Please note:
If you save the new settings, they are memorised ONLY in the
selected prole.
SAFETY WARNING:
After making a pot of coee, leave the ap-
pliance to cool for 5 minutes before making
another beverage. Risk of overheating!
8.1 Cleaning the coee pot
After each use, you should clean the coee pot with hot water
and mild washing up liquid. Rinse thoroughly with hot water to
eliminate all detergent residues.
9. OVER ICE (ECAM61X.7Y only)
To make the beverage, proceed as follows:
1. On the homepage (B), press the image corresponding to
over ice:
2. Select the parameters to be customised according to your
tastes by pressing "Next" after each selection:
Aroma
Quantity
3.
4. Place the ice cubes in the
glass (suggested quanti-
ty: 6 cubes);
5. Place the glass under the
coee spouts (A14) (g.
19) and press "OK". The
appliance starts making
the coee and the image
of the selected beverage
appears on the display,
together with a progress
bar which gradually lls
19
as the operation proceeds and a description of each indi-
vidual phase (grinding, brewing coee);
Please note:
• "Cancel "or Stop": press to stop preparation completely and
go back to the homepage.
• As soon as delivery has ended, to increase the quantity of
coee, just press "Extra". When the required quantity is
reached, press "Stop".
6. When delivery has ended, press "Save" to save the new
settings, or "Cancel" to retain the previous parameters.
Please note:
If you save the new settings, they are memorised ONLY in the
selected prole.
7. Press "OK" to go back to the homepage (B).
The appliance is ready to be used again.
10. MAKING MILKBASED BEVERAGES U
Please note:
To avoid milk with poor froth or large bubbles, always clean the
milk container (D) as described in sections “10.5 Cleaning the
milk container after use”and“16.10 Cleaning the milk container
(D)”.
10.1 Filling and attaching the milk container
1. Lift the lid (D1) (g.20);
20 21
MILK
5°C
2. Fill the milk container (D10) with a sucient quantity of
milk, not exceeding the MAX level marked on the container
(g. 21). Each mark on the container corresponds to about
100 ml of milk;
3. Make sure the milk intake tube (D9) is correctly inserted on
the bottom of the milk container lid (g. 22);

13
22 23
4. Put the lid back on the milk container;
5. Attach the milk container (D) to the connection nozzles
(A13) and push as far as it will go (g. 23). The machine
emits a beep (if the beep function is enabled);
24 25
6. Place a suciently large cup under the coee spouts (A14)
and milk spout (D7) (g. 24). To lengthen the milk spout,
adjust the extension (D8);
7. Select the desired beverage as described in the following
paragraphs.
Please note:
• The milk container lid incorporates a rell lid (D2) to top
up the milk (g. 25). If during preparation you notice that
the level of the milk is low, add milk through the rell lid
without extracting the container, then complete prepara-
tion of the beverage.
• For a denser more even froth, you must use skimmed or
partially skimmed milk at refrigerator temperature (about
5°C).
• ECAM61X.7Y: When using milk at the ideal temperature
(about 5°C), the thermal casing guarantees the eciency
of the MilkCream system for about 30 minutes outside the
refrigerator.
• If "Energy Saving" mode is enabled (see section “6.9 Gen-
eral”), you may have to wait a few seconds before the bev-
erage is delivered.
• The quality of the froth will vary depending on:
• type of milk or vegetable beverage;
• brand used;
• ingredients and nutritional value.
10.2 Adjusting the amount of froth
Turn the froth adjustment
dial (D3) (g. 26) to adjust
the amount of froth on the
milk delivered while making
cappuccinos and milk-based
coees.
Dial
position
Description Recommended for…
No froth HOT MILK (not frothed) /
CAFFELATTE
Min. froth CORTADO / FLAT WHITE
Max. froth CAPPUCCINO/ CAPPUCCI
NO+ / CAPPUCCINO MIX/
ESPRESSO MACCHIATO/
LATTE MACCHIATO / LATTE
CALDO (frothed)
10.3 Your milk-based beverage at a touch
To deliver milk-based beverages, on the homepage (B), press
the image corresponding to the desired beverage.The appliance
proceeds with preparation and the image of the selected bev-
erage appears on the display (B5), together with a progress bar
which gradually lls as the operation proceeds and a description
of each individual phase (grinding, brewing coee, milk deliv-
ery, etc.).
At the end of preparation, the message "Your beverage is
ready!" appears on the display. The appliance is now ready to
be used again.
Please note:
As soon as delivery has ended, to increase the quantity of coee,
just press "Extra". When the required quantity is reached, press
"Stop".
26

14
10.4 Customising the beverages
To deliver a customised milk-based beverage, proceed as
follows:
1.Press(B3)at the bottom of the image correspond-
ing to the desired beverage. The parameters that can be
customised according to your tastes appear on the display
(B5):
Quantity
Aroma
Coee type
2. After setting the parameters, press"Start";
3. The appliance proceeds with preparation and the image of
the selected beverage appears on the display, together with
a progress bar which gradually lls as the operation proceeds
and a description of each individual phase (grinding, milk
delivery, brewing coee, etc.).
4. When delivery has ended, press "Save" to save the set-
tings, or "Cancel" to retain the previous parameters.
Please note:
If you save the new settings, they are memorised ONLY in the
selected prole.
5. Press "OK" to go back to the homepage (B).
The appliance is ready to be used again.
10.5 Cleaning the milk container after use
Each time you make a milk-based beverage, a request to clean
the milk frother appears on the display (B5). To start cleaning,
proceed as follows:
1. Leave the milk container (D) in the machine (you do not
need to empty it);
2. Place a cup or other recipient under the frothed milk spout
(D7) (g. 27);
27 28
Clean
29
3. Turn the froth adjust-
ment dial (D3) to "Clean"
(g. 28). Hot water and
steam are delivered
from the milk spout
(g. 29). Cleaning stops
automatically;
4. Turn the dial back to one
of the froth selections;
5. Remove the milk con-
tainer and place in the
refrigerator.
Please note:
• To prepare a number of cappuccinos and milk based cof-
fees, clean the milk container after you have prepared
the last beverage only. To proceed with making the next
beverages, when the "Clean" message is displayed, press
"Cancel".
• If you do not clean the milk container, the symbol
(B8) appears on the display to remind you that cleaning
is required.
• The milk container can be kept in the refrigerator.
• In some cases, to clean you must wait for the appliance to
heat up.
• To ensure correct cleaning, wait for the CLEAN function to
end. You can, however, interrupt cleaning of the milk con-
tainer by pressing "Stop".
11. MUG TO GO (ECAM61X.7Y only)
The Mug to Go function is perfect for all those wanting to create
a customised beverage to take with them. Choose the ingredi-
ents (coee only, coee with milk or coee with hot water) and
the delivery order, then customise the quantity.
To make the beverage, proceed as follows:
1. Remove the lid from the
travel mug (C9);
2. Raise the coee spouts
(A14) and place the travel
mug container under-
neath (g. 30);
3. On the homepage (B),
press the image corre-
sponding to the Mug to Go
function;
If the beverage
has already
been saved, the appliance pro-
ceeds with preparation.
If you are making the beverage for the rst time, proceed as
follows:
30

15
4. Select up to 2 ingredients in the required order of delivery,
then press "Next";
5. Select the preferences for the selected ingredients, then
press "Next";
6. Press "OK" to start preparation;
7. When the required quantity of the ingredient being deliv-
ered is reached, press "Stop";
8. When delivery has ended, press "Save" to save the recipe, or
"Cancel" if you do not want to save it
9. Press "OK" to go back to the homepage .
The appliance is ready to be used again.
Table of quantities programmable for each single in-
gredient (make sure the total quantity of the 2 ingredients
does not exceed the capacity of the travel mug)
Ingredient Minimum
quantity
Maximum
quantity
Coee 40 ml 240 ml
Milk 50 ml 470 ml
Water 50 ml 260 ml
Please note:
• If you save the new settings, they are memorised ONLY in
the selected prole.
• For best performance, heat the mug with hot water.
• You should only use the travel mug for the beverages pres-
ent in the machine.
• Recipes using the milk container (D): at the end of
preparation, clean the milk container (see section “10.5
Cleaning the milk container after use”), then place in the
refrigerator.
• To use a travel mug other than the one supplied, make sure
it is no taller than 14 cm.
Important
• Do not use for baby milk preparations.
• You should use the contents within a maximum of 2 hours.
After that time, empty and clean as described in the fol-
lowing section.
11.1 Cleaning the travel mug after use
For hygiene reasons, the travel mug (C9) should always be
cleaned after use.
Proceed as follows:
1. Open the travel mug and rinse the container and lid with
hot drinking water (40°C).
2. Remove visible dirt with a sponge.
3. Immerse all the components in hot water at 40°C with
mild/neutral washing up liquid for at least 30 minutes,
then rinse thoroughly with water at 40°C. Do not use
scented detergents.
4. Clean the inside of the container with mild/neutral wash-
ing-up liquid and rinse with hot drinking water at 40°C.
Do not use abrasive materials as these could damage the
surface of the container.
5. Dry all the components with a clean, dry cloth or absorbent
paper, then reassemble.
6. Each week, wash the lid in
a dishwasher. The travel
mug container is not dish-
washer safe.
12. TEA FUNCTION
To make tea, proceed as
follows:
1. Place the teabag in the
cup and position it under
the spout (A14) (g. 31);
2. On the homepage (B),
press the image cor-
responding to the tea
function;
3. Adjust the parameters that can be customised according to
your tastes:
"Quantity"
"Temperature"
A dierent tea (white, green, oolong
or black) appears with each water
temperature
4. Press "Start" to begin delivery: the appliance proceeds
with preparation and the image of the beverage appears
on the display (B5) together with a progress bar which
gradually lls as the operation proceeds and a description
of the phase (water delivery);
5. When delivery has ended, press "Save" to save the settings,
or "Cancel" to retain the previous parameters;
6. Press "OK" to go back to the homepage .
The appliance is now ready to be used again.
Please note:
• If you save the new settings, they are memorised ONLY in
the selected prole.
• If "Energy Saving" mode is active, you may have to wait a
few seconds before the hot water is delivered.
• To stop delivery manually, press "Stop" or "Cancel".
• As soon as delivery has ended, to increase the quantity
of water in the cup, just press "Extra". When the required
quantity is reached, press "Stop".
31

16
13. DELIVERING HOT WATER U
To deliver hot water, proceed as follows:
1. Place a cup under the spout (A14).
2. Select the function as described in the following
paragraphs.
13.1 Your beverage at a touch
On the homepage (B), press the image corresponding to hot
water. The appliance proceeds with preparation and the image
of the beverage appears on the display (B5) together with a pro-
gress bar which gradually lls as the operation proceeds and a
description of the phase (water delivery).
At the end of preparation, the message "Your beverage is
ready!" appears on the display. The appliance is now ready to
be used again.
Please note:
As soon as delivery has ended, to increase the quantity of water
in the cup, just press "Extra". When the required quantity is
reached, press "Stop".
13.2 Customising the beverages
To deliver the desired quantity of hot water, proceed as follows:
1. Press (B3) at the bottom of the image corresponding
to hot water: the quantity to be customised according to
your tastes appears on the display (B5):
"Quantity"
2. After selecting the quantity, press "Start": The appliance
proceeds with preparation and the image of the beverage
appears on the display together with a progress bar which
gradually lls as the operation proceeds and a description
of the phase (water delivery).
3. When delivery has ended, press "Save" to save the settings,
or "Cancel" to retain the previous parameters.
4. Press "OK" to go back to the homepage .
The appliance is now ready to be used again.
Please note:
• If "Energy Saving" mode is active, you may have to wait a few
seconds before the hot water is delivered.
• To interrupt delivery of hot water manually, press "Stop"
and "Cancel".
• As soon as delivery has ended, to increase the quantity of
coee, just press "Extra". When the required quantity is
reached, press "Stop".
14. GUIDED BEVERAGE CUSTOMISATION MY U
You can use this function to customise all beverages with the
MY symbol at the bottom of the image in beverage settings
(on the homepage (B), press at the bottom of the image
corresponding to the required beverage). To customise, proceed
as follows:
1. Make sure the prole (B2) for which you want to customise
the beverage is active;
2. Press (B3) at the bottom of the image corresponding
to the desired beverage;
3. Press at the bottom of the image corresponding to the
beverage;
4. Press "OK" to follow the guided procedure;
5. Select your preference and press "Next" to move on to the
next step (or "Back" to go back to the previous screen);
6. Press "OK" to begin delivery;
7. Preparation begins and the appliance displays the quantity
customising screen in the form of a vertical bar (in the case
of beverages with more than one ingredient, customise
both ingredients).
8. When the quantity reaches the minimum amount you can
set, "Stop" appears on the display (B5).
9. When the required quantity has been delivered into the
cup, press "Stop".
10. If you are satised with the result in the cup, press "Save"
to save the settings, or "Cancel" to retain the previous
parameters.
11. Press "OK" to go back to the homepage .
The appliance goes back to the homepage.
Please note:
• If you save the new settings, they are memorised ONLY in
the selected prole.
• When you customise a single beverage, the respective
double version is also customised and the appliance dis-
plays the message "Settings saved on both double and
single option";
• You can also customise the beverages by connecting with
the DeLonghi Coee Link App.
• Press "Cancel" to exit programming at any moment. The
values will not be saved.
• When a beverage has been customised, "Reset" (under the
image) and "my" (among the quantity selections) appear
in the settings. Press "Reset" to reset the default values for
the beverage.
Beverage quantity table
Beverage Standard
quantity
Programmable
quantity
ESPRESSO 40 ml 20-180 ml
IDEAL
ESPRESSO
40 ml 30-60 ml
2X ESPRESSO 40 ml + 40 ml 20-180 ml +
20-180 ml

17
COFFEE 180 ml 100-240 ml
LONG 160 ml 115-250 ml
DOPPIO+ 120 ml 80-180 ml
AMERICANO 150 ml 70-480 ml
TEA 150 ml 20-420 ml
HOT WATER 250 ml 20-420 ml
61x.7y models only
LONG BLACK 200 ml 90-480 ml
OVER ICE 100 ml 40-240 ml
15. SELECTING YOUR PERSONAL PROFILE U
According to the model, you can memorise 3 or 5 dierent pro-
les, each associated with a dierent icon.
The customised beverage settings are saved in each prole (see
section “14. Guided beverage customisation (My) u”). The
order in which all the beverages are displayed is based on the
frequency of selection.
To select a prole, proceed as follows:
1. From the homepage (B), press the prole currently in use
(B2). A list of selectable proles appears;
2. Then select the required prole.
Please note:
• After making your selection, the beverage settings bars
will all appear in the same colour as the prole;
• You can rename your personal prole by connecting with
the DeLonghi Coee Link App;
• To customise the prole icon, see section“6.7 Edit prole”.
16. CLEANING U
16.1 Cleaning the machine
The following parts of the machine must be cleaned regularly:
- the appliance’s internal circuit;
- coee grounds container (A25);
- drip tray (A24) and drip tray grille(A22);
- water tank (A20);
- coee spouts(A14);
- pre-ground coee funnel (A3);
- infuser (A11), accessible after opening the infuser door
(A10);
- milk container (D).
Important!
• Do not use solvents, abrasive detergents or alcohol to clean
the coee machine.With De’Longhi superautomatic coee
machines, no chemical products are required for cleaning
purposes.
• The following components are dishwasher safe:
• milk container (D)
• grounds container (A25)
• drip tray (A24)
• drip tray grille (A22)
• coee spouts (A16) and (A17)
• Do not use metal objects to remove encrustations or coee
deposits as they could scratch metal or plastic surfaces.
16.2 Cleaning the internal circuit
If the appliance is not used for more than 3/4 days, before using
it again, we strongly recommend switching it on and perform-
ing 2/3 rinse cycles by selecting the "Rinse" function (section
“6.1 Rinsing”).
Please note:
After cleaning, it is normal for the grounds container (A25) to
contain water.
16.3 Cleaning the coee grounds container
When "Empty grounds container" appears on the display (B5),
the grounds container must be emptied and cleaned. The ap-
pliance cannot be used to make coee until you have cleaned
the grounds container (A25). Even if not full, the empty grounds
container message is displayed 72 hours after the rst coee has
been prepared. For the 72 hours to be calculated correctly, the
machine must never be turned o with the main switch (A7).
Important! Danger of burns
If you make a number of milk-based beverages one after the
other, the metal cup tray (A21) becomes hot. Wait for it to cool
down before touching it and handle it from the front only.
To clean (with the machine on):
1. Remove the drip tray
(A24) and grounds con-
tainer (A25) (g. 32);
2. Empty the drip tray and
grounds container and
clean thoroughly to re-
move all residues left on
the bottom. This can be
done using the spatula on
the brush (C5) provided.
3. Put the drip tray complete
with grille and grounds
container back in the
appliance.
Important!
When removing the drip tray, the grounds container must be
emptied, even if it contains few grounds. If this is not done,
32

18
when you make the next coees, the grounds container will ll
up more than expected and clog the machine.
16.4 Cleaning the drip tray and drip tray grille
Important!
The drip tray (A24) is tted with a level indicator (A23) (red)
showing the amount of water it contains (g. 33). Before the
indicator protrudes from the cup tray (A21), the drip tray must
be emptied and cleaned, otherwise the water may overow the
edge and damage the appliance, the surface it rests on or the
surrounding area. To remove the drip tray, proceed as follows:
1. Remove the drip tray and grounds container (A25) (g. 32);
2. Check the condensate tray (red) and empty if necessary;
3. Remove the cup tray
(A21), and drip tray grille
(A22), then empty the
drip tray and grounds
container and wash all
components.
4. Put the drip tray complete
with grille and grounds
container back in the
appliance.
Important!
When removing the drip tray, the grounds container must be
emptied, even if it contains few grounds. If this is not done,
when you make the next coees, the grounds container will ll
up more than expected and clog the machine.
16.5 Cleaning the inside of the machine
Danger of electric shock!
Before cleaning internal parts, the machine must be turned o
(see section“5. Turning the appliance o”) and unplugged from
the mains power supply. Never immerse the machine in water.
1. Check regularly (about once a month) that the inside of the
appliance (accessible after removing the drip tray (A24))
is not dirty. If necessary, remove coee deposits with the
brush (C5) supplied and a sponge.
2. Remove all residues with a vacuum cleaner (g. 34).
34 35
33
16.6 Cleaning the water tank
Clean the water tank (A20) regularly, about once a month and
whenever you replace the water softener lter (C7).
1. Remove the water tank (g. 3), remove the water softener
lter (if present) and rinse it with running water;
2. Empty the water tank and clean with a damp cloth and a
little washing up liquid. Rinse thoroughly with water;
3. Put the lter back in the appliance (g. 35), ll the tank
with fresh water up to the MAX level (marked inside) (g.
4), put the tank back (g. 5);
4. (models with water softener lter only) Deliver 100ml of hot
water to reactivate the lter.
Please note:
If the appliance is not used for more than 3-4 days, you should
clean the tank as described above.
16.7 Cleaning the coee spouts
Clean the coee spouts (A16) and (A17) when requested by the
appliance (about once a month) as described below.
Please note:
To clean later, press "Cancel". The next time the appliance is
turned on, the message is displayed again.
36
1. Remove the central outlet cover (A15) by pulling outwards,
then remove the coee spouts downwards (g. 36). Press
“Next”;
2. Separate the two spouts
(A16) and (A17) (g. 37);
3. Rinse the spouts with
running water (g. 38).
We recommend washing
in a dishwasher. Alterna-
tively, wash thoroughly
with warm water and mild
washing-up liquid;
4. Clean the seat of the re-
movable spouts with a
sponge (g. 39);
37

19
38 39
5. Reassemble the spouts, then attach them to the central
outlet. Make sure the word "INSERT" is at the top and is
visible when the spouts have been inserted;
6. Replace the central outlet cover.
7. Press "OK" to conrm cleaning.
16.8 Cleaning the pre-ground coee funnel
Clean the pre-ground coee funnel (A3) regularly (about once a
month) with a damp cloth. Proceed as follows:
1. Open the lid (A2) (g. 16);
2. Extract the funnel (g. 40)
and clean with the brush
provided (C5);
3. If necessary, clean the
funnel with hot water and
washing up liquid or in a
dishwasher;
4. Put the funnel back in the
appliance;
5. Close the lid.
16.9 Cleaning the infuser
The infuser (A11) must be cleaned at least once a month.
Important!
The infuser cannot be removed when the machine is on.
1. Make sure the machine is correctly turned o (see section
“5. Turning the appliance o”);
2. Remove the water tank (A20) (g. 4);
3. Open the infuser door (A10) (g. 41) on the right side of
the appliance;
40
PUSH
41 42
PUSH
4. Press the two coloured release buttons inwards and at the
same time pull the infuser outwards (g. 42);
5. Soak the infuser in water for about 5 minutes, then rinse
under the tap;
Important!
RINSE WITH WATER ONLY
NO WASHING UP LIQUID  NO DISHWASHER
6. Clean the infuser without
using washing up liquid
as it could be damaged.
7. Use the brush (C5) to re-
move any coee residues
left in the infuser hous-
ing, visible through the
infuser door;
8. After cleaning, replace the
infuser by sliding it onto
the internal support, then
push the PUSH symbol
fully in until it clicks into
place;
Please note:
If the infuser is dicult to insert, before insertion, adapt it to the
right size by pressing the two levers (g. 43).
9. Once inserted, make sure the two coloured buttons have
snapped out;
10. Close the infuser door;
11. Put the water tank back.
16.10 Cleaning the milk container (D)
Clean the milk container each time you prepare milk as de-
scribed below:
1. Lift the milk container lid (D1) (g. 20);
2. Remove the milk spout (D7), milk spout extension (D8) and
milk intake tube (D9) (g. 44);
43

20
44 45
Insert
3. Turn the froth adjustment dial (D3) clockwise to the "In-
sert" position (g. 45) and pull;
4. Turn and remove the milk container connector (D5)(g.
46).
46 47
5. All components and the
container are dishwasher
safe, placing them in the
top basket. If you do not
have a dishwasher, wash
by hand as described in
the note at the end of the
section.
6. Make sure there are no
milk residues on the hol-
low and groove under the
dial (g. 47):
If necessary, scrape the groove with a toothpick;
7. Rinse inside the froth adjustment dial seat and milk con-
tainer connector hole with running water (g. 48);
8. Check that the intake tube and spout are not clogged with
milk residues;
9. Reassemble all the lid components;
10. Attach the lid back on the milk container.
48
Please note: washing by hand
Washing in a dishwasher guarantees the perfect hygiene of all
the milk container components. When washing by hand, wash
all components of the milk container thoroughly withhot water
and immerse them in a basin of hot water for 30 minutes before
proceeding as described in point (6).
17. DESCALING U
Important!
• Before use, read the instructions and the labelling on the
descaler pack.
• It is important to use De’Longhi descaler only. Using un-
suitable descaler and/or performing descaling incorrectly
may result in faults not covered by the manufacturer's
guarantee.
• Descaler could damage delicate surfaces. If the product is
accidentally spilt, dry immediately.
To descale
Descaler De’Longhi descaler
Container Recommended capacity: 2 l
Time ~50min
Descale the appliance when the corresponding message ap-
pears on the display (B5).To descale the appliance immediately,
press "OK" and follow the instructions from point (8).
To descale the appliance later, press "Cancel". The symbol
(B7) appears on the homepage (B) to remind you that the ap-
pliance needs descaling. (The message appears each time you
turn the appliance on).
To access the descaling menu:
1. On the display , press the settings menu icon (B6);
2. Select "Descale";
3. Press "Next" to enter the guided descaling procedure;
4. Press "OK" to start;
5. Insert the hot water spout
(C7) (g. 7);
6. Remove and empty the drip tray (A24) and coee grounds
container (A25) (g. 11), then put both back in the appli-
ance and press "Next";
7. Remove the water tank(A20), lift the lid(A19) and (if in-
serted) remove the lter(C7);
8. Pour the descaler into the tank up to the level A marked in-
side the tank (equal to one 100ml packet), then add water (1
litre) up to level B (g. 49). Put the water tank (with lid) back
in the appliance, close the front door and press "Next"
;
9. Place an empty 2 litres container under the spouts (g. 8).
Press OK to start descaling ("Back" to go back to the previ-
ous screen or "Cancel" to exit the procedure, remembering
to remove the descaling solution from the tank)
