DeLonghi DFG 905 Operation instructions

DFG 905
Gas Cooker
Users Operating Instructions
Before operating this oven,
please read these instructions carefully
GB

2
Introduction
Congratulations on your purchase of this Delonghi gas cooker which has been carefully
designed and produced to give you many years of satisfactory use.
Before using this appliance it is essential that the following instructions are carefully read and
fully understood.
We would emphasise that the installation section must be fully complied with for your safety
to ensure that you obtain the maximum benefits from your appliance.
CE Declaration of conformity
This cooker has been designed, constructed and marketed in compliance with:
- safety requirements of EEC Directive “Gas” 90/396;
- safety requirements of EEC Directive “Low voltage” 73/23;
- protection requirements of EEC Directive “EMC” 89/336;
- requirements of EEC Directive 93/68.
This appliance is designed and manufactured solely for the cooking of domestic
(household) food and in not suitable for any none domestic application and therefore
should not be used in a commercial environmement.
The appliance guarantee will be void if the appliance is used within a none domestic
environnement i.e. a semi commercial, commercial or communal environment.
GB

3
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS
After having unpacked the appliance, check to ensure that it is not damaged.
In case of doubt, do not use it and consult your supplier or a professionally qualified techni-
cian.
Packing elements (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.) should not
be left around within easy reach of children, as these may cause serious injuries.
■Do not attempt to modify the technical characteristics of the appliance as this
may become dangerous to use.
■Do not carry out cleaning or maintenance operations on the appliance without
having previously disconnected it from the electric power supply.
■After use, ensure that the knobs are in off position.
■Do not allow children or other incapable people to use the appliance without
supervision.
■During and after use of the cooker, certain parts will become very hot. Do not
touch hot parts.
■Keep children away from the cooker when it is in use.
■Some appliances are supplied with a protective film on steel and aluminium parts.
This film must be removed before using the appliance.
■Fire risk! Do not store flammable material in the oven, and in the storage
compartment.
■Make sure that electrical cables connecting other appliances in the proximity of
the cooker cannot come into contact with the hob or become entrapped in the
oven door.
■Do not line the oven walls with aluminium foil. Do not place baking trays or the
drip tray on the base of the oven chamber.
■The manufacturer declines all liability for injury to persons or damage to property
caused by incorrect or improper use of the appliance.
■To avoid any possible hazard, the appliance must be installed by qualified
personnel only. Any repairs by unqualified persons may result in electric shock or
short circuit. In order to avoid possible injuries to your body or to the appliance,
do not attempt any repairs by yourself. Such work should be carried out by
qualified service personnel only.
■Danger of burns! The oven and cooking accessories may become very hot
during operation. Make sure children are kept out of reach and warn them
accordingly. To avoid burns use kitchen clothes and gloves when handling hot
parts or utensils.
■Never clean the oven with a high-pressure steam cleaning device, as it may
provoke a short circuit.
■This appliance is intended for use in your household. Never use the appliance for
any other purpose!

4
1 Features and technical data
Gas burners
1. Auxiliary burner (A) 1,00 kW
2. Semi-rapid burner (SR) 1,75 kW
3. Rapid burner (R) 3,00 kW
4. Triple-ring burner (TC) 3,50 kW
Fig. 1.1
23
1
2
4
4
NOTE:
✓The electric ignition is incorporated in the knobs

5
2 Control panel
1 2 34 56 789
CONTROL PANEL - Controls description
1. Gas oven / gas grill control knob
2. Minute counter
3. Front left burner control knob
4. Rear left burner control knob
5. Front central burner control knob
6. Rear central burner control knob
7. Rear right burner control knob
8. Front right burner control knob
9. Oven light control knob
Fig. 2.1

6
3 Minute counter
Minute counter
The minute counter is a timed acoustic warning device which can be set for a
maximum of 60 minutes.
The knob (Fig. 3.1) must be rotated clockwise as far as the 60 minute position and
then set to the required time by rotating it anticlockwise.
•
10
•
20
•
30
•
40
•
50
•
Fig. 3.1

7
4 How to use the hob burners
Hob burners
Each hob burner is controlled by a separate
gas tap operated by a control knob (fig. 4.1)
which has 3 positions marked on the knob
itself, these are:
– Symbol ●: tap closed (burner off)
– Symbol : High (maximum)
– Symbol : Low (minimum)
Push in and turn the knob anti-clockwise to
the selected position.
Low High
To turn the burner off, fully rotate the knob clockwise to the off position: ●.
The maximum setting of the control tap is for boiling, the minimum setting is for slow
cooking and simmering.
All working positions must be choosen between the maximum and minimum setting, never
between the maximum setting and the “OFF” position.
Fig. 4.1
Electric ignition
The sparks generated by the electrodes close to the burners will ignite the choosen
burner. Whenever the lighting of the burners is difficult due to peculiar conditions of
the gas features or supply, it is advised to repeat the ignition with the knob on
“minimum” position.
Lighting of the hob burners
To ignite the burner, the following instructions are to be followed:
1) Lightly press and turn the knob anti-clockwise, and position the knob symbol
to the indicator printed on the control panel (fig. 4.1).
2) Press the knob to operate the electric ignition; or, in the case of a mains failure light the
burner with a match or lighted taper.
3) Adjust the burner according to the setting required.

8
Burners Pan diameter
Auxiliary 12 ÷ 14 cm
Semi-rapid 16 ÷ 24 cm
Rapid 24 ÷ 26 cm
Triple-ring 26 ÷ 28 cm
do not use pans with concave or convex bases
Fig. 4.2
Choice of burner
The burner must be choosen according to the diameter of the pans and energy required.
Saucepans with handles which are excessively heavy, in relationship to the weight of the
pan, are safer as they are less likely to tip.
Pans which are positioned centrally on burners are more stable than those which are offset.
It is far safer to position the pan handles in such a way that they cannot be accidentally
knocked.
When deep fat frying fill the pan only one third full of oil.
DO NOT cover the pan with a lid and DO NOT leave the pan unattended.
In the unfortunate event of a fire, leave the pan where it is and turn off all controls.
Place a damp cloth or correct fitting lid over the pan to smother the flames.
DO NOT use water on the fire.
Leave the pan to cool for at least 30 minutes.

9
Correct use of the triple-ring burner
The flat-bottomed pans are to be placed directly onto the pan-support.
To use the WOK you need to place the proper stand in order to avoid any faulty
operation of the triple-ring burner (Fig. 4.3a - 4.3b).
IMPORTANT:
The special grille for wok pans (fig. 4.3b) MUST BE PLACED ONLY over the pan-rest for the
triple-ring burner.
Fig. 4.3a
WRONG
Fig. 4.3b
CORRECT

10
5 How to use the gas oven
General features
Attention: the oven door becomes very hot during operation.
Keep children away.
The oven is supplied completely clean; it is advisable, however, upon first use, to turn the
oven on to the maximum temperature (position ) to eliminate possible traces of grease
from the oven burner. The same operation should be completed for grill burner.
The gas oven is provided with two burners:
a) Oven burner, mounted on the lower part of the oven (wattage: 6,20 kW)
b) Grill burner, mounted on the upper part of the oven (wattage: 4,65 kW).
If hob burners are already in use it is preferable to await about 10 minutes before
operating the oven.
Oven burner
This burner carries out the normal “oven cook-
ing”.
The gas flow to the burner is regulated by a ther-
mostat which maintains the oven at a constant
temperature.
The temperature of the oven is controlled by a
thermostatic probe positioned inside the oven.
The probe must always be kept in its housing, in
a clean condition, as an incorrect position or
encrustment may cause an alteration in the con-
trol of the temperature.
Oven thermostat
The temperature knob is numbered from 1 to (fig. 5.1) indicating the increasing oven
temperature value.
The thermostat which regulates the flow of gas to the oven burner has a safety valve which
automatically shuts off the gas supply when the flame goes out.
The temperature is kept constant on the regulated value.
1
2
3
4
5
6
7
8
9
10
Fig. 5.1

11
Lighting the oven gas burner
To ignite the oven burner:
1 – Open the oven door to its full extent.
WARNING: Risk of explosion! The oven door must be open during this operation.
2 – Lightly press and turn the temperature knob anti-clockwise to max position “ ”.
3 – Press the knob right down to prime the electric ignition. Keep the knob pressed.
Never continue this operation for more than 15 seconds. If the burner has still
not ignited, wait for about 1 minute prior to repeating the ignition.
In case of a power cut, press the knob and immediately bring a lighted match to the
opening ‘A’ of the oven floor (fig. 5.2).
4 – After lighting the burner, wait a few seconds before releasing the knob (until the safety
valve stays open).
5 – Gently close the oven door and set the oven control knob to the required temperature.
If the flame extinguishes for any reason, the safety valve will automatically shut off the gas
supply to the burner.
To re-light the burner, first turn the oven control knob to position ●, wait for at least 1 minute
and then repeat the lighting procedure.
For efficient oven preheating, we recommend that grill trays and racks are removed
from the oven and replaced after about 15 minutes.
Attention: the oven door becomes very hot during operation.
Keep children away.
Fig. 5.2
A

12
How to use the gas grill
Lighting the grill gas burner
The grill burner generates the infra-red rays for grilling.
To light the grill burner operate as follow:
1 – Open the oven door to its full extent. WARNING: Risk of explosion!
The oven
door must be open during this operation.
2 – Lightly press and turn the temperature knob clockwise to the position (fig. 5.4).
3 – Press the knob right down to prime the electric
ignition. Keep the knob pressed.
Never continue this operation for more than
15 seconds. If the burner has still not ignit-
ed, wait for about 1 minute prior to repeat-
ing the ignition.
In case of a power cut, press the knob and
immediately put a lighted match to the right and
left side of the burner (fig. 5.3).
4 – After lighting the burner, wait a few seconds
before releasing the knob (until the safety valve
stays open).
Do not close the oven door completely. The grill
must always be used with the oven door slightly
open and with shield "P” fitted (Fig. 5.5).
Do not grill with oven door closed.
Always fit the heat shield supplied with the cooker under the front panel before
commencing operations (Fig. 5.5).
WARNING. The heat shield and the oven door reaches a very high temperature
whilst in use. Keep children away and allow to cool before removing.
Fig. 5.3
Fig. 5.4

13
Fig. 5.5
IMPORTANT WARNING
For best results when using the grill, place the shelf on the second level and when using the
grill pan handle avoid contact with the heat shield which will be
HOT during use
Use of the grill
IMPORTANT: the grill must always be used with the oven door slightly open and with
the shield "P” fitted (Fig. 5.5).
Fit shield “P” (fig. 5.5) to protect the control panel from the heat.
Turn on the grill, as explained in the preceding paragraphs and let the oven preheat for
about 5 minutes with the door ajar.
Introduce the food to be cooked, positioning the rack as close to the grill as possible.
The drip tray pan should be placed under the rack to catch the cooking juices and fats.
Note: It is recommended that you do not grill for longer than 30 minutes at any one
time.
Attention: the oven door becomes very hot during operation.
Keep children away.
The oven door must always be kept half-open when the grill is in operation. See spe-
cific instructions in ‘USE OF THE GRILL’.
If the flame extinguishes for any reason, the safety valve will automatically shut off the gas
supply to the burner.
To re-light the burner, first turn the oven control knob to position ●, wait for at least 1
minute and then repeat the lighting procedure.
P

14
Oven light
Fig. 5.6
The cooker is equipped with a light that illuminates
the oven to enable visually controlling the food
that is cooking.
This light is controlled by a switch knob (fig. 5.6).

15
Oven cooking temperatures
MARK APPROX. HEAT OF TYPE OF DISH TO COOK
TEMP. OVEN
1 150°C Very cool Meringue cakes,
oven slow cooking items
2 165°C Cool or Milk puddings, very rich fruit
slow oven cakes, i.e., Christmas
3 180°C Cool or Stews, casseroles, braising,
slow oven rich fruit cakes, i.e., Dundee
4 195°C Warm oven Biscuits, rich plain cakes
i.e., Madeira. Low temp. roasting
5 210°C Moderate Plain cakes, Victoria
oven sandwich, raised meat pies
6 225°C Fairly hot Small cakes, savoury flans,
oven fish
7 240°C Hot oven Plain cakes and buns, swiss rolls,
fruit pies. High temp. roasting
8 245°C Moderately Bread and bread rolls etc., scones,
hot oven flaky and rough puff pastry,
yorkshire pudding
9 270 Very hot Sausage rolls, mince pies, puff
285 oven pastry, pizza
Browning ready cooked dishes
Cooking guide
Temperature and times given are approximate, as they will vary depending on the quality
and amount of food being cooked.
Remember to use ovenproof dishes and to adjust the oven temperature during cooking if
necessary.

16
Important notes
Installation, and any demonstration, information or adjustments are not included in the
warranty.
The cooker must be installed by a qualified person in accordance with the Gas Safety
(Installation and Use) (Amendment) Regulations 1990 and the relevant building/l.E.E
Regulations.
Failure to install the appliance correctly could invalidate any manufacturers warranty and
lead to prosecution under the above quoted regulation.
In the UK C.O.R.G.I registered installers are authorised to undertake the installation and
service work in compliance with the above regulations. All Comet authorised installers are
C.O.R.G.I. registered.
Attention
The appliance gets very hot, mainly around the cooking areas. It is very
important that children are not left alone in the kitchen when you are
cooking.
After Sales Service
Should you require to book a service call telephone [phone].
For product information and advise telephone [phone]

17
Do’s and do not’s
Do’s and do not’s
• Do always grill with the oven door ajar and with heat baffle mounted.
• Do read the user instructions carefully before using the cooker for first time.
• Do allow the oven to heat for one and a half hours, before using for the first time, in order
to expel any smell from the new oven insulation, without the introduction of food.
• Do clean your oven regularly.
• Do remove spills as soon as they occur.
• Do always use oven gloves when removing food shelves and trays from the oven.
• Do not allow children near the cooker when in use.
• Do not allow fat or oils to build up in the oven trays, or oven base.
• Do not place cooking utensils or plates directly onto the oven base.
• Do not grill food containing fat without using the grid.
• Do not cover the grilling grid with aluminium-foil.
• Do not use the oven tray for roasting.
• Do not place hot enamel parts in water. Leave them to cool first.
• Do not allow vinegar, coffee, milk, saltwater, lemon or tomato juice to remain in contact
with enamel parts (inside the oven and on the oven tray).
• Do not use abrasive cleaners or powders that will scratch the surface of the stainless steel
and the enamel.
• Do not attempt to repair the internal workings of your oven.
• Do remove the protective film before the first use.
• Fire risk! Do not store flammable material in the oven and in the storage compartment.
For your safety
The product should only be used for its intended purpose which is for the cooking of
domestic foodstuffs.
Under no circumstances should any external covers be removed for servicing or
maintenance except by suitably qualified personnel.

18
Cleaning the hob
Spillage on the hob can usually be removed by a damp soapy cloth. More obstinate stains
can be removed by rubbing gently with a soapy scouring pad or mild household cleaner.
Important:
As a safety measure, before you start cleaning the cooker be sure to disconnect it from the
mains supply.
Do not use a steam cleaner because the moisture can get into the appliance thus
make it unsafe.
6 Care and maintenance
Gas taps
If a tap becomes stiff, do not force; contact your local COMET Service Centre.
Flexible tube
From time to time, check the flexible tube connecting the gas supply to the cooker.
It must be always in perfect condition; in case of damage arrange for it to be replaced by a
C.O.R.G.I. registered installer.
Cleaning oven parts after use
The oven interior and the chromium plated shelves can be cleaned by damp soapy cloth.
Obstinate stains can be removed with nylon scouring pads and gentle, non-abrasive, liquid
cleaner. Provided the oven is wiped over immediately after roasting, only the minimum of
cleaning should be necessary.
Stainless steel aluminium parts and silk-screen printed
surfaces
Clean using an appropriate product. Always dry thoroughly.
IMPORTANT: these parts must be cleaned very carefully to avoid scratching and abrasion.
You are advised to use a soft cloth and neutral soap.
CAUTION: Do not use abrasive substances or non-neutral detergents as these will
irreparably damage the surface.

19
Burners
T hey can be removed and washed with soapy water only.
They will remain always perfect if cleaned with products used for silverware.
After cleaning or wash, check that burner-caps and burner-heads are dry before placing
them in the respective housings.
It is very important to check that the burner flame distributor and the cap has been correctly
positioned - failure to do so can cause serious problems.
Note: To avoid damage to the electric ignition do not use it when the burners are
not in place.
Correct replacement of the burners
It is very important to check that the burner flame distributor Fand the cap C has been cor-
rectly positioned (see fig. 6.1 - 6.2) - failure to do so can cause serious problems.
Check that the electrode “S” (fig. 6.1) is always clean to ensure trouble-free sparking.
Note:
The electrode S must be very carefully cleaned.
S
F
C
Fig. 6.1 Fig. 6.2

Changing the oven light
1. Disconnect the electrical power supply (for example, by switching off the main
power switch).
2. Unscrew the light cover
3. Fit a new bulb.
4. Refit the cover.
Note:
Use only bulbs designed to resist up to 300°C with the following characteristics: 15 W,
230 V, type E-14.
20
Triple ring burner
The triple ring burner must be correctly positioned (see fig. 6.3); the burner rib must be
enter in their logement as shown by the arrow.
The burner correctly positioned must not rotate (fig. 6.4).
Then position the cap Aand the ring B(fig. 6.4).
Fig. 6.3 Fig. 6.4
AB
