DeLonghi TR 906-G Operating instructions

DE’LONGHI
COOKING
USER & INSTALLATION INSTRUCTIONS
DTR 906-G
DOUBLE OVEN GAS COOKER
GB

2
CONTENTS Page Number
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Important Safety Precautions & Recommendations . . . . . . . . . . . . . . . . . . . .
Cooking Hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Use of the Hob Burners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Left Main Gas Oven with Grill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Right Small Gas Oven . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . .
Oven Temperature Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
60’ Minute Timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning & Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Advice for the Installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gas Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Guarantee & After sales Service. . . . . . . . . . . . . . . . . . . . . . . . . .
3
4 - 8
9
10
11 - 13
14 - 17
18 - 19
20
21
22 - 30
31
32 - 36
37 - 46
47 - 48
49

3
Dear Customer,
Thank you for purchasing the DeLonghi DTR 906-G
double oven gas cooker.
The safety precautions and recommendations listed
below are for your own safety and that of others. They
will also provide a means by which to make full use of the
features offered by your appliance.
Please retain this booklet for future reference.
This appliance must be used only for the task it
has explicitly been designed for, that is for cooking
foodstuffs. Any other form of usage is to be considered
as inappropriate and therefore potentially dangerous.
The manufacturer declines all responsibility in the
event of damage caused by improper, incorrect or
illogical use of the appliance.
DECLARATION OF CE CONFORMITY
• This appliance has been designed to be used only for cooking. Any other use (such as
heating a room) is improper and dangerous.
• This appliance has been designed, constructed, and marketed in compliance with:
-Safety requirements of the “Gas” Directive 2009/142/EC (until the 20/04/2018) OR
Regulation (EU) 2016/426 (starting from the 21/04/2018);
-Safety requirements of the “Low voltage” Directive 2014/35/EU;
-Safety requirements of the “EMC” Directive 2014/30/EU;
-Requirements of EU Directive 93/68/EEC;
-Requirements of EU Directive 2011/65/EU.
GB

4
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS
IMPORTANT: This appliance is designed and manufactured
solely for the cooking of domestic (household) food and is
not suitable for any non domestic application and therefore
should not be used in a commercial environment.
The appliance guarantee will be void if the appliance is used
within a non domestic environment i.e. a semi commercial,
commercial or communal environment.
Read the instructions carefully before installing and using
the appliance.
• This appliance has been designed and manufactured in
compliance with the applicable standards for the household
cooking products and it fullls all the safety requirements shown
in this manual, including those for surface temperatures.
Some people with sensitive skin may have a more pronounced
temperature perception with some components although these
parts are within the limits allowed by the norms.
The complete safety of the appliance also depends on the correct
use, we therefore recommend to always pay a extreme attention
while using the product, especially in the presence of children.
• After having unpacked the appliance, check to ensure that it is
not damaged and that the oven door closes correctly.
In case of doubt, do not use it and consult your supplier or a
professionally qualied technician.
• Packing elements (i.e. plastic bags, polystyrene foam, nails,
packing straps, etc.) should not be left around within easy reach
of children, as these may cause serious injuries.
• Some appliances are supplied with a protective lm on steel and
aluminium parts. This lm must be removed before using the
appliance.
• IMPORTANT: The use of suitable protective clothing/gloves is
recommended when handling or cleaning this appliance.

5
• Do not attempt to modify the technical characteristics of
the appliance as this may become dangerous to use. The
manufacturer declines all responsibility for any inconvenience
resulting from the inobservance of this condition.
• CAUTION: this appIiance must only be installed in a permanently
ventilated room in compliance with the applicable regulations.
• Do not carry out cleaning or maintenance operations on the
appliance without having previously disconnected it from the
electric power supply.
• WARNING: Ensure that the appliance is switched off before
replacing the oven lamp to avoid the possibility of electric shock.
• Do not use a steam cleaner because the moisture can get into
the appliance therefore making it unsafe.
• Do not touch the appliance with wet or damp hands (or feet).
• Do not use the appliance whilst in bare feet.
• If you should decide not to use this appliance any longer (or
decide to substitute another model), before disposing of it, it
is recommended that it be made inoperative in an appropriate
manner in accordance to health and environmental protection
regulations, ensuring in particular that all potentially hazardous
parts be made harmless, especially in relation to children who
could play with unused appliances.
• The various components of the appliance are recyclable. Dispose
of them in accordance with the regulations in force in your country.
If the appliance is to be scrapped, remove the power cord.
• After use, ensure that the knobs are in the off position.
• Children less than 8 years of age shall be kept away unless
continuously supervised.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.

6
• The manufacturer declines all liability for injury to persons or
damage to property caused by incorrect or improper use of the
appliance.
• WARNING: During use the appliance and its accessible parts
become hot; they remain hot for some time after use.
– Care should be taken to avoid touching heating elements (on
the hob and inside the oven).
– The door is hot, use the handle.
– To avoid burns and scalds, young children should be kept
away.
• Make sure that electrical cables connecting other appliances in
the proximity of the cooker cannot come into contact with the hob
or become entrapped in the oven door.
• WARNING: Unattended cooking on a hob with fat or oil can be
dangerous and may result in re. NEVER try to extinguish a re
with water, but switch off the appliance and then cover ame e.g.
with a lid or a re blanket.
• WARNING: Danger of re: do not store items on the cooking
surfaces.
• WARNING: When correctly installed, your product meets all
safety requirements laid down for this type of product category.
However special care should be taken around the rear or the
underneath of the appliance as these areas are not designed or
intended to be touched and may contain sharp or rough edges,
that may cause injury.
• FIRST USE OF THE OVEN - it is advised to follow these
instructions:
– Furnish the interior of the oven as described in the chapter
“CLEANING AND MAINTENANCE”.
– Switch on the empty oven on max to eliminate grease from the
heating elements.
– Disconnect the appliance from the electrical power supply, let
the oven cool down and clean the interior of the oven with a
cloth soaked in water and neutral detergent; then dry carefully.

7
• CAUTION: Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can scratch the
surface, which may result in shattering of the glass.
• Do not line the oven walls or base with aluminium foil. Do not place
baking trays or the drip tray on the base of the oven chamber.
• Do not cover the hob with aluminium foils.
• FIRE RISK! Do not store ammable material in the oven or in the
storage compartment.
• Always use oven gloves when removing the shelves and food
trays from the oven whilst hot.
• Do not hang towels, dishcloths or other items on the appliance or
its handle – as this could be a re hazard.
• Clean the oven regularly and do not allow fat or oils to build up in
the oven base or tray. Remove spillages as soon as they occur.
• Do not stand on the cooker or on the open oven door.
• Always stand back from the appliance when opening the oven
door to allow steam and hot air to escape before removing the
food.
• SAFE FOOD HANDLING: Leave food in the oven for as short
a time as possible before and after cooking. This is to avoid
contamination by organisms which may cause food poisoning.
Take particular care during warmer weather.
• WARNING: Take care NOT to lift the cooker by the door handle.
• CAUTION: The cooking process has to be supervised. A short
term cooking process has to be supervised continuously.
• The appliance must not be installed behind a decorative door in
order to avoid overheating.
• The oven accessories (e.g. oven wire rack) must be tted
correctly as indicated at page 25.
• If the power supply cable is damaged, it must be replaced only
by an authorized service agent in order to avoid a hazard.

8
ENERGY LABELLING/ECODESIGN
• Commission delegated regulation (EU) No 65/2014 (supplementing Directive 2010/30/EU
of the European Parliament and of the Council).
• Commission regulation (EU) No 66/2014 (implementing Directive 2009/125/EC of the
European Parliament and of the Council).
Reference to the measurement and calculation methods used to establish compliance with
the above requirements:
• Standard EN 15181 (gas ovens).
• Standard EN30-2-1 (hobs: gas red burners).
USE OF THE APPLIANCE, ENERGY SAVING TIPS
OVEN
• Check the oven door always closes properly and the door gasket is clean and in order.
During use, open the oven door only when strictly necessary to avoid heat losses (for
some functions it may be necessary to use the oven with the door half-closed, check
the oven operating instructions).
• Turn off the oven 5-10 minutes before the end of the theoretical cooking time to
recuperate the stored heat.
• We recommend using oven proof dishes and adjusting the oven temperature during
cooking if necessary.
HOB
GAS FIRED BURNERS
• It is important that the diameter of the pot be suitable to the size of the burner so as
not to compromise the high output of the burners and therefore energy waste. A small
pot on a large burner does not give you a boiling point in a shorter amount of time
since the capacity of heat absorption of a liquid mass depends on the volume and the
surface of the pot.
• Avoid keeping a burner on without something on it (without pot)..
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN
ACCORDANCE WITH EC DIRECTIVE 2012/19/EC.
At the end of its working life, the product must not be disposed of as
urban waste. It must be taken to a special local authority differentiated
waste collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible negative
consequences for the environment and health deriving from inappropriate
disposal and enables the constituent materials to be recovered to obtain
signicant savings in energy and resources. As a reminder of the need
to dispose of household appliances separately, the product is marked
with a crossed-out wheeled dustbin.

9
GAS BURNERS
1. Auxiliary burner (A) 1,00 kW
2. Semi-rapid burner (SR) 1,75 kW
3. Rapid burner (R) 3,00 kW
4. Triple-ring burner (TR) 3,50 kW
Fig. 1.1
1 - COOKING HOB
2
4
2
3 1
Notes:
• The electric ignition is incorporated in the knobs.
• The appliance has a safety valve system tted, the ow of gas will be stopped if and
when the ame should accidentally go out.
CAUTION:
If the burner is accidentally extinguished, turn the gas off at the control knob and wait at
least 1 minute before attempting to relight.
CAUTION:
Gas hobs produce heat and humidity in the environment in which they are installed.
Ensure that the cooking area is well ventilated by opening the natural ventilation grilles or
by installing an extractor hood connected to an outlet duct that vents to the outside.
CAUTION:
If the hob is used for a prolonged time it may be necessary to provide further ventilation by
opening a window or by increasing the suction power of the extractor hood (if tted).

10
CONTROLS DESCRIPTION
1. Right small oven: Gas oven control knob
2. Front right burner control knob
3. Rear right burner control knob
4. Central burner control knob
5. Rear left burner control knob
6. Front left burner control knob
7. Right small oven: Oven light control knob
8. 60’ alarm control knob
9. Left main oven: Oven light control knob
10. Left main oven: Gas oven / gas grill control knob
Fig. 2.1
130
155
180
205 230
Max
5
10
15
20
25
30
35
40
45
50
55
130
155
180
205 230
Max
5 4 3 2 17 68910
2 - CONTROL PANEL
Please note: This appliance incorporates a safety cooling fan which you will hear operating
whenever the oven or grill is being used.
The cooling fan may even run on after the appliance has been switched off.
The duration of this time is dependent on several factors, including previous cooking
temperature, duration and ambient temperature. Times in excess of 30 minutes are not
uncommon.

11
3 - USE OF THE HOB BURNERS
Caution!
The cooking hob becomes very hot
during operation.
Keep children well out of reach.
N.B. When the cooker is not being
used, set the gas knobs to their closed
positions.
GAS BURNERS
Gas ow to the burners is adjusted by
turning the knobs (illustrated in g. 3.1)
which control the safety valves.
Turning the knob, so that the indicator line
points to the symbols printed on the panel,
achieves the following functions:
- symbol closed valve
- symbol maximum
aperture or ow
- symbol minimum
aperture or ow
√The maximum aperture position
permits rapid boiling of liquids, whereas
the minimum aperture position allows
slower warming of food or maintaining
boiling conditions of liquids.
√ To reduce the gas ow to minimum
rotate the knob further anti-clockwise
to point the indicator towards the small
ame symbol.
√Other intermediate operating
adjustments can be achieved by
positioning the indicator between the
maximum and minimum aperture
positions, and never between the
maximum aperture and closed
positions.
Fig. 3.2
Fig. 3.1
Caution!
Do not cover the hob with aluminium
foils.

12
DEEP FAT FRYING
For safety purposes when deep fat frying,
do not ll the pan more than one third full
of oil.
DO NOT cover the pan with a lid and DO
NOT leave the pan unattended.
In the unfortunate event of a re, leave
the pan where it is and turn off the control
knobs.
Place a damp cloth or lid over the pan to
smother the ames. Leave the pan to cool
for at least 30minutes before moving the
pan.
DO NOT USE WATER ON THE FIRE.
CHOICE OF THE BURNER
On the control panel, near every knob
there is a diagram that indicates which
burner is controlled by that knob.
The suitable burner must be chosen
according to the diameter and the capacity
used.
As an indication, the burners and the pots
must be used in the following way:
DIAMETERS OF PANS WHICH MAY BE
USED ON THE BURNERS
BURNERS MINIMUM MAXIMUM
Auxliliary 12 cm 14 cm
Semi-rapid 16 cm 24 cm
Rapid 24 cm 26 cm
Triple-ring 26 cm 28 cm
Wok max 36 cm
do not use pans with concave or convex
bases
Fig. 3.3
It is important that the diameter of the pot
be suitable to the potentiality of the burner
so as not to compromise the high output
of the burners and therefore energy waste.
A small pot on a large burner does not give
you a boiling point in a shorter amount of
time since the capacity of heat absorption
of a liquid mass depends on the volume
and the surface of the pot. Too large a
pot can cause damage to the burner and
surrounding hob area.
LIGHTING THE BURNERS
To ignite the burner, the following
instructions are to be followed:
1. Press in the corresponding knob and
turn counter-clockwise (g. 3.2) to the
full ame position marked by the
symbol (g. 3.1); hold the knob in unt il
the ame has been lit.
In the case of a mains failure light the
burner with a match or lighted taper.
2. Wait for a few seconds after the gas
burner has been lit before letting go of
the knob (valve activation delay).
3. Adjust the gas valve to the desired
position.
If the burner ame should go out for some
reason, the safety valve will automatically
stop the gas ow.
To re-light the burner, return the knob to
the closed “ ” position, wait for at least
1 minute and then repeat the lighting
procedure.
If your local gas supply makes it difcult
to light the burner with the knob set to
maximum, set the knob to minimum and
repeat the operation.

13
CORRECT USE OF THE TRIPLE-RING BURNER
Only at bottom pans of the correct size are to be placed on the pan support above the
Triple-ring burner.
When using a WOK, the supplied wok stand must be placed onto the pan stand to avoid
any faulty operation of the triple-ring burner (g. 3.4a). The wok should not be placed
directly onto the pan support without the use of the supplied wok stand (g. 3.4b).
IMPORTANT:
When using the wok stand it MUST ONLY BE PLACED over the pan support for the triple-
ring burner (g.3.4a). Under no circumstances should the wok stand be placed under
the pan supports (gs 3.5a - 3.5b). Incorrect placement of the wok stand in this manner
may impinge the ame resulting in incomplete combustion and give rise to harmful levels
of Carbon Monoxide (CO).
WRONG
Fig. 3.4b
Fig. 3.5a Fig. 3.5b
WRONG WRONG
CORRECT
Fig. 3.4a

14
Attention: The oven door becomes
very hot during operation.
Keep children away.
GENERAL FEATURES
It is advisable, upon rst use, to turn the
oven on to the maximum temperature
(position Max ) to eliminate possible
traces of grease from the oven burner.
The same operation should be followed for
the grill burner.
The gas oven is provided with two burners:
a. Oven burner, mounted on the lower
part of the oven (wattage: 3,70 kW)
providing safety device and electric
ignition.
b. Grill burner, mounted on the upper
part of the oven (wattage: 2,50 kW)
providing safety device and electric
ignition.
WARNING:
The door is hot, use the handle.
During use the appliance becomes
hot. Care should be taken to avoid
touching heating elements inside the
oven.
THERMOSTAT
The numbers 130 to Max printed on
the control panel (g. 4.1) indicate the
increasing oven temperature value (see
table 4.2).
To regulate the temperature, make the
indicator on the knob match with the
number on the control panel.
The temperature is kept constant on the
regulated value.
The gas thermostat controlling the gas
supply to the burner is equipped with a
safety device which automatically stops the
gas ow in case of ame extinction.
OVEN BURNER
It carries out normal “oven cooking”.
The gas ow to the burner is regulated by
a thermostat which allow to maintain the
oven temperature constant.
The control of the temperature is assured
by a thermostatic probe positioned inside
the oven.
The probe must be always kept in its
housing, in a clean condition, as an
incorrect position or encrustment may
cause an alteration in the control of the
temperature.
4 - LEFT MAIN GAS OVEN WITH GRILL
130
155
180
205 230
Max
Fig. 4.1
Table 4.2
TEMPERATURE CHART
Gas Marking Oven temperature
130 130 °C
142 °C
155 155 °C
168 °C
180 180 °C
192 °C
205 205 °C
218 °C
230 230 °C
Max 240 °C
Smells and fumes produced during this
burn off process are not a cause of alarm.
Adequate ventilation should however be
provided in the room where the appliance
is installed, e.g. by opening a window.

15
CAUTION:
To assure a correct air ow to the
burner, make sure there is no material
in the warming drawer during operation
of the gas oven.
IGNITION OF THE OVEN BURNER
ATTENTION: Never turn the control
knob before opening the oven door.
To light the oven burner operate as follows:
1. Open the oven door to the full extent.
WARNING: Risk of explosion! The
oven door must be open during this
operation.
2. Lightly press and turn the thermostat
knob anti-clockwise (g. 4.4) to max
position Max (g. 4.1). Press the
knob rmly until the burner lights.
Never continue this operation for
more than 15 seconds. If the burner
has still not ignited, wait for about
1 minute prior to repeating the
ignition.
In case of mains failure, press the
knob rmly and immediately approach
a lighted match or taper to the opening
“A” (g. 4.3).
3. Wait a few seconds after the burner
lighting before releasing the knob
(time of priming of the valve).
4. Close the oven door slowly and adjust
the burner according to the power
required.
If the ame extinguishes for any reason,
the safety valve will automatically shut off
the gas supply to the burner.
To re-light the burner, rst turn the oven
control knob to the off position “ ” , wait
for at least 1 minute and then repeat the
lighting procedure.
OVEN COOKING
Before introducing the food, preheat the
oven to the desired temperature.
For a correct preheating operation, it is
advisable to remove the tray from the oven
and introduce it together with the food,
when the oven has reached the desired
temperature.
Check the cooking time and turn off the
oven 5 minutes before the theoretical time
to recuperate the stored heat.
A
Fig. 4.3
Fig. 4.4
For correct use of the gas oven, always
preheat it (bottom burner) for at least
15 minutes.
Preheating should always be carried
out with the oven empty: remove the
trays and racks from the oven cavity.

16
IGNITION OF THE GRILL BURNER
IMPORTANT: The grill must always be
used with the oven door ajar and with
shield “A” mounted (g. 4.7).
Do not grill with the oven door closed.
Attention: The oven door becomes very
hot during operation.
Keep children away.
WARNING. The heat shield and the oven
door reach a very high temperature
whilst in use.
1. Open the oven door to the full extent.
WARNING: Risk of explosion! The
oven door must be open during this
operation.
2. Lightly press and turn the thermostat
knob clockwise (g. 4.5) to the position
(g. 4.1).
3. Press the knob rmly until the burner
lights.
Never continue this operation for
more than 15 seconds. If the burner
has still not ignited, wait for about 1
minute prior to repeating the ignition.
In case of mains failure, press the
knob rmly and immediately approach
a lighted match or taper to the pipe of
the burner (g. 4.6).
4. Wait a few seconds after the burner
lighting before releasing the knob
(time of priming of the valve).
Do not close the oven door
completely. The grill must always
be used with the oven door slightly
open and with shield “A” mounted
(g. 4.7).
 See specic instructions in the section
‘USE OF THE GRILL’.
If the ame extinguishes for any reason,
the safety valve will automatically shut off
the gas supply to the burner.
To re-light the burner, rst turn the grill
control knob to position “ ”, wait for at
least 1 minute and then repeat the lighting
procedure.
Fig. 4.5
Fig. 4.6

17
USE OF THE GRILL
Very important: the grill must always be
used with the oven door slightly open
and with shield “A” mounted (g. 4.7).
Mount shield “A” which serves to protect
the control panel from the heat.
Turn on the grill, as explained in the
preceding paragraphs and let the oven
preheat for about 5 minutes with the door
ajar.
Introduce the food to be cooked, positioning
the rack as close to the grill as possible.
The drip tray should be placed under the
rack to catch the cooking juices and fats.
Note: It is recommended that you do
not grill for longer than 30 minutes at
any one time (Grilling for longer than
the recommended time may mean the
appliance overheats).
Attention: the oven door becomes very
hot during operation.
Keep children away.
Notes:
• The grill burner has only one setting,
that is full-on
• It is important that the heat shield is
tted the correct way up, as shown in
the gure 4.7.
IMPORTANT WARNING
For best results when using the grill, place
the shelf on the second level and when
using the grill pan handle avoid contact
with the heat shield which will be HOT
during use.
OVEN LIGHT
The cooker is equipped with a light that
illuminates the oven to enable visually
controlling the food that is cooking.
This light is controlled by a control knob
(g. 4.8).
H O T ZO N E
A
Fig. 4.7
Fig. 4.8
WARNING:
Hot part allow to cool
before removing

18
5 - RIGHT SMALL GAS OVEN
GENERAL FEATURES
It is advisable, upon rst use, to turn the
oven on to the maximum temperature
(position Max ) to eliminate possible
traces of grease from the oven burner.
The gas oven is provided with one burner:
a. Oven burner, mounted on the lower
part of the oven (wattage: 2,20 kW)
providing safety device and electric
ignition.
THERMOSTAT
The numbers 130 to Max printed on
the control panel (g. 4.1) indicate the
increasing oven temperature value (see
table 4.2).
To regulate the temperature, make the
indicator on the knob match with the
number on the control panel.
The temperature is kept constant on the
regulated value.
The gas thermostat controlling the gas
supply to the burner is equipped with a
safety device which automatically stops the
gas ow in case of ame extinction.
130
155
180
205 235
Max
Fig. 5.1
Table 5.2
Attention: The oven door becomes
very hot during operation.
Keep children away.
WARNING:
The door is hot, use the handle.
During use the appliance becomes hot.
Care should be taken to avoid touching
heating elements inside the oven.
TEMPERATURE CHART
Gas Marking Oven temperature
130 130 °C
142 °C
155 155 °C
168 °C
180 180 °C
192 °C
205 205 °C
218 °C
230 230 °C
Max 240 °C
Smells and fumes produced during this
burn off process are not a cause of alarm.
Adequate ventilation should however be
provided in the room where the appliance
is installed, e.g. by opening a window.
For correct use of the gas oven, always
preheat it for at least 15 minutes.
Preheating should always be carried
out with the oven empty: remove the
trays and racks from the oven cavity.
OVEN BURNER
It carries out normal “oven cooking”.
The gas ow to the burner is regulated by a
thermostat which allow to maintain the oven
temperature constant.
The control of the temperature is assured
by a thermostatic probe positioned inside
the oven.
The probe must be always kept in its
housing, in a clean condition, as an incorrect
position or encrustment may cause an
alteration in the control of the temperature.

19
F
OVEN LIGHT
The cooker is equipped with a light that
illuminates the oven to enable visually
controlling the food that is cooking.
This light is controlled by a control knob
(g. 5.5).
Fig. 5.3
Fig. 5.5
IGNITION OF THE OVEN BURNER
ATTENTION: Never turn the control
knob before opening the oven door.
To light the oven burner operate as follows:
1. Open the oven door to the full extent.
WARNING: Risk of explosion! The
oven door must be open during this
operation.
2. Lightly press and turn the thermostat
knob anti-clockwise (g. 5.4) to max
position Max (g. 5.1). Press the
knob rmly until the burner lights.
Never continue this operation for
more than 15 seconds. If the burner
has still not ignited, wait for about
1 minute prior to repeating the
ignition.
In case of mains failure, press the
knob rmly and immediately approach
a lighted match or taper to the opening
“F” (g. 5.3).
3. Wait a few seconds after the burner
lighting before releasing the knob
(time of priming of the valve).
4. Close the oven door slowly and adjust
the burner according to the power
required.
If the ame extinguishes for any reason,
the safety valve will automatically shut off
the gas supply to the burner.
To re-light the burner, rst turn the oven
control knob to the off position “ ”, wait
for at least 1 minute and then repeat the
lighting procedure.
OVEN COOKING
Before introducing the food, preheat the
oven to the desired temperature.
For a correct preheating operation, it is
advisable to remove the tray from the oven
and introduce it together with the food,
when the oven has reached the desired
temperature.
Check the cooking time and turn off the
oven 5 minutes before the theoretical time
to recuperate the stored heat.
Fig. 5.4

20
6 - OVEN TEMPERATURE GUIDE
Cooking process Oven heat Gas mark
Electric oven temperature
°C °F
Keeping food hot,
milk puddings very cool ½120 250
Egg custards cool 1 140 275
Rich fruit cakes,
braising cool 2 150 300
Low temperature
roasting, shortbread moderate 3 160 325
Victoria sandwich,
plain fruit cake,
baked sh moderate 4 180 350
Small cakes, choux
pastry fairly hot 5 190 375
Short pastry, Swiss
rolls, soufés fairly hot 6 200 400
High temperature
roasting, aky
pastry, scones
hot 7 220 425
Puff pastry, bread very hot 8 230 450
Small puff pastries,
browning cooked
foods
very hot 9 240 475
These temperatures relate to the centre oven temperature.
Remember to use ovenproof dishes and to adjust the oven temperature during cooking if
necessary.
