INTRODUCTION
Thank you for choosing a De’Longhi product.
Please take few moments to read the instructions to avoid risks
or damage to the appliance.
Symbols used in these instructions
Important warnings are identied by the symbols below.
It is important to respect the warnings.
Failure to respect the warnings could lead to electric shock,
serious injury, burns, re or damage to the appliance.
Danger!
Failure to observe the warning may result in life threatening
injury by electric shock.
Important!
Failure to observe the warning could result in injury or damage
to the appliance.
Danger of burns!!
Failure to observe the warning could result in burns or scalds.
Please note:
This symbol indicates recommendations and important
information for the user.
IMPORTANT WARNINGS
Safety warnings
Danger!
- Before plugging the appliance into the
mains, make sure that:
• The voltage indicated on the appliance
rating plate corresponds to your mains
voltage;
• The mains socket is earthed and has a
minimum rating of 16A. Failure to follow
these important safety instructions
absolves the manufacturer of all liability.
- Never use the appliance outdoors.
- Never unplug from the mains socket by
pulling on the cable.
- If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualied persons in
order to avoid a hazard.
- Before starting cleaning, unplug the cord
from the wall outlet and disconnect the
connection. The grill plate connections
must be dried thoroughly before using
again.
Important!
- This appliance is designed to cook food.
It must never be used for other purposes,
modied or tampered with in any way.
- Wait until the appliance is completely
cold before putting away.
- Do not move the appliance during use.
- The appliance is not intended to be
operated by means of an external timer
or separate remote-control system.
- The appliance is designed and produced
for domestic use only.
It is not suitable for use in: sta kitchens
in shops, oces and other workplaces,
farm houses, hotels, motels or other
holiday accommodation, guest houses.
- OnlytheappropriateDe'Longhiconnector
must be used: PPH-BG500-818-2 for
the BG510/BG510C appliance; PPH-
BG400-817-2 for the BG410 appliance.
- This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved.
Children shall not play with the
appliance.
Cleaning and user maintenance shall
not be made by children unless they are
older than 8 and supervised.
- Keep the appliance and its cord out of
reach of children less than 8 years.
- Always use the appliance on a dry, level,
heat resistant surface at a height of at
least 85 cm, out of reach of children.

9
- Allow the Grill to cool down before
handling (at least 30 minutes).
- Do not pull on the power cord, but rather
on the plug, to separate the appliance
from the mains.
- Do not leave the appliance unattended
when it is switched on, as this may be a
source of danger.
- The temperature of accessible surfaces
may be high when the appliance is
operating.
- Never immerse the connector in water.
If necessary clean the connector body
with a damp cloth.
Danger of burns!!
- When the appliance is in operation, the
outside may become very hot. Always
use the handgrip or oven gloves if
necessary.
- Do not place ammable products near
the appliance.
- WARNING: Charcoal or similar
combustible fuels must not be used with
this appliance.
- CAUTION: Cook only with the drip tray in
place. Pour o the drip tray only when
the appliance is completely cool. Pay
caution when pull out the drip tray in
order to avoid pour out of liquids.
Please note:
- To avoid the risk of re, do not cook food
wrapped in plastic lm or tinfoil or in
plastic bags.
This appliance conforms to EC Regulation 1935/2004 on
materials and articles intended to come into contact with food.
Disposing of the appliance
The appliance must not be disposed of with household
waste, but taken to an authorised waste separation and
recycling centre.
DESCRIPTION (pag. 3)
1. Connector
2. Oil Drip Tray
3. Base
4. Safety Interlock
5a. BG410 Grill Plate with non-stick coating
5b. Grill Plate with non-stick coating (BG510) / Grill Plate with
ceramic coating (BG510C)
6. Grill plate handles
7. Appliance handles
8. Fat Spray protector (Only on BG510C)
9. Spatula (Only on BG510C)
The unit can have dierent grill plate based on model.
• The grilling plate with the ribbed surface is suitable for the
typical grilling of steaks, cutlets or the like.
• The at plate with the smooth surface is used to
fry hellsh, eggs, sliced vegetables or the like (Only on
BG510\BG510C).
TECHNICAL DATA
BG410
Voltage: 220-240V ~ 50/60Hz
Absorbed power: 1800W
Size LxHxD: 480 x 90 x 345
Weight: 3,920Kg
BG510
Voltage: 220-240V ~ 50/60Hz
Absorbed power: 2000W
Size LxHxD: 570 x 90 x 345
Weight: 4,250Kg
BG510C
Voltage: 220-240V ~ 50/60Hz
Absorbed power: 2000W
Size LxHxD: 570 x 130 x 345
Weight: 4,640Kg
INSTALLATION AND MAINTENANCE
Before rst use
• Remove all packaging materials and any promotional
labels from the grill plate and the tray.
• Detach the connector and clean the grill plate by washing
with soap and water in a sink. Rinse and dry thoroughly.
Make sure the connector inlet on the plate is fully dry.
• Condition the grill surface by applying a light coating of
vegetable oil or use a non-stick cooking spray. Wipe o
excess oil.

10
Food Quantity Cooking time (minutes) Notes
Beef steak 4 pieces 6 -8 Marinate and turn over halfway through cooking
Frankfurters 6 pieces 8 - 10 Turn over 2-3 times during cooking
Pork chops 4 pieces 13 - 15 Marinate and turn over 2-3 times during cooking
Chicken breasts 6 pieces 6 - 8 Marinate and turn over halfway through cooking
Hamburgers 6 pieces 18 - 20 Turn the hamburgers over after around 10-12 minutes
Sausages 6 pieces 15 - 18 Prick the sausages with a fork and turn them over 2-3
times during cooking
Courgettes 8-10 slices 10 - 12 Drizzle with oil and turn over halfway through cooking
Aubergines 8 slices 10 - 12 Drizzle with oil and turn over halfway through cooking
Fish slices 4 pieces 15 - 20 Marinate and turn over halfway through cooking
Preparing the unit
• Set base on countertop. Insert in the drip tray. Match the
grill plate to the base as shown in gure. The terminal /
socket of the grill plate should be on the same side as the
safety interlock.
• Do not use the appliance if it is not installed following the
sequence as shown on page 3.
Switching the unit on
• Plug the connector fully into the terminal of the grill plate.
The connector cannot be plugged in completely unless the
grill plate is tted properly to the base.
• Plug the power cord into the wall outlet.
• Adjust the temperature dial to maximum setting. The
indicator light will light on. Preheat 4-6 minutes. The light
will cycle on and o during preheat. This is normal.
• Be sure the temperature control dial is on MAX for best
browning results and grill marks when barbecuing
hamburger, steaks, hot dogs, sausage, sh steaks,
chicken breasts and other meat. Use MIN or MED setting
to reheat previously cooked foods, to keep foods warm,
and when grilling more delicate foods with lower cooking
temperature.
Switching the unit o
• Turn the temperature connector to lwhen cooking is
completed.
• Unplug the power cord from the wall outlet and allow to
cool before cleaning or removing any part.
• Hold the unit by the handles when turning it over.
• Never transport the unit when is hot. To transport the grill
plate use the handles (6).To transport the whole appliance
use the appliance handles (7).
Cooking times
• Use the following table as a guideline for food amounts and
cooking times. Recipe cooking times are estimate. Cooking
time will vary based on the temperature of the grill, the
surrounding air, and the food itself. The food to be cooked
should always be at room temperature. Never put frozen
food directly onto the grill plate. Watch food carefully and
adjust the cooking time as necessary. Turn frequently for
more even cooking.

11
GRILLING TIPS
• For best results, preheat the cooking plate before grilling.
• Tender slices of meat are generally more suitable for
grilling. Somewhat tougher meat will become tender if it
has been marinated overnight.
• To prevent scratching the cooking surface when turning
over the food, always use plastic or wood spatula. Never cut
foods on the plate surface.
• If cooking vegetables, sh, or lean meat, spray the cooking
surface with a cooking spray or a light coating of vegetable
oil. If cooking meat with any amount of fat, or if the food
has been marinated, there is no need to treat the grill.
• Never cook meat too long.
• If the food being cooked sticks to the cooking plate, wipe
down the cooking plate from time to time with a paper
towel dipped in oil.
Please note:
• The rst time you use the Grill; it may have a slight odor and
may smoke a bit. This is normal and common to appliances
with nonstick surfaces.
• A plastic cleaning spatula can be used for cleaning the
grilling plate after you have nished cooking and the unit
has cooled down completely (at least 30 minutes). Using
the cleaning tool on a hot surface for too long will cause
the plastic to melt.
CARE AND CLEANING
• When nished cooking, unplug from the outlet and allow
the grill to cool completely before cleaning. Never transport
the unit when it is hot.
• Pull out the connector. If cleaning is necessary, wipe over
unit with a slightly damp cloth. DO NOT IMMERSE THE
CONNECTOR INWATER OR ANY OTHER LIQUID.
• Lift the cooking plate o the base and pour o any excess
grease liquid from the drip tray.
The cooking plate and the drip tray can be washed in the
dishwasher. Frequent washing could reduce the properties
of the ceramic coating.
The metal body must be cleaned by hand.
• Do not use steel wool pads or harsh, abrasive cleaners
on the cooking surface as they may damage the nonstick
coating. Never use a caustic oven cleaner as this will
damage the cooking surface.
• To remove cooked on food, use a plastic spatula. Be sure to
clean the handles after each use.
Dry thoroughly with a soft cloth or paper towel.
• The power cord assembly must not be placed in the
dishwasher.
• The appliance inlet must be carefully dried before the
appliance is used again.
DISCLAIMER
Updates to hardware components are made regularly. Therefore
some of the instruction, specications and pictures in this
documentation may dier slightly from your particular situation.
All items described in this guide for illustration purposes only
and may not apply to particular situation. No legal right or
entitlements may be obtained from the description made in this
manual.
