DeLonghi xu1837w User manual

TOASTER OVEN BROILER WITH THIRD HEATING ELEMENT
FOUR À CONVECTION NATURELLE AVEC CUISSON SIMULTANÉE
SUR DEUX NIVEAUX
HORNO DE CONVECCIÓN NATURAL CON COCCIÓN SIMULTÁNEA
EN DOS NIVELES
FORNO A CONVEZIONE NATURALE CON COTTURA SIMULTANEA
SU DUE LIVELLI

2
CONTENTS
CHAP. 1 GENERAL
1.1 Description and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.2 Important safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Summary of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
CHAP. 2 USING THE CONTROLS AND SETTING THE MODES
2.1 Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.2 How to keep food warm “KEEP WARM” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.3 Instructions for baking “BAKE” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.4 Instructions for low baking “SLOW BAKE” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.5 Instructions for baking with “DOUBLE BAKE/TOAST” function . . . . . . . . . . . . . . . . . .8
2.6 Top brown “SINGLE BAKE/TOAST” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.7 Instructions for broiling “BROIL” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.8 Instructions for toasting with “DOUBLE BAKE/TOAST” function . . . . . . . . . . . . . . . .10
CHAP. 3 CLEANING AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
ELECTRICAL CONNECTIONS
All it requires is a nearby 120 Volt 60 Hz three-prong grounded power outlet.
GROUNDING INSTRUCTIONS
BE SURE THAT YOUR OUTLET
IS PROPERLY GROUNDED
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric current.
This appliance is equipped with a cord having a grounding wire with a grounding plug.
The plug must be plugged into an outlet that is properly installed and grounded.
WARNING: IMPROPER USE OF THE GROUNDING PLUG CAN RESULT IN A RISK OF ELECTRIC SHOCK.
If you are uncertain that your outlets are properly grounded, please contact a qualified electrician or ser-
viceman.
If it is necessary to use an extension cord, use only a three-wire extension cord that has a 3-blade ground-
ing plug, and a 3-slot outlet that will accept the plug on the appliance. The marked rating of the extension
cord shall be equal to or greater than the electrical rating of the appliance.
•The cord length of this product has been selected to reduce the possibility of tangling in or tripping
over a longer cord. If more cord length is needed, an extension cord may be used. It should be rated
no less than 15 amps., 120 volts, and have Underwriters Laboratories/CSA listing.
•Asix foot long, 15 amp. extension cord may be purchased from your local authorized service facility.
When using a longer cord, be sure not to let it drape over the working area or dangle where someone
could accidentally pull or trip over it.
•Handle the cord carefully for longer life; avoid jerking or straining the cord at the plug and appliance
connections.

3
A Top heating element
B Oven light (if fitted)
C Side guides
D Third heating element
connector
E Thermostat knob
F Pilot light
G On/off and toast
programming knob
H Function selector knob
I Control panel
L Bottom heating element
MGlass door
N Two aluminum beke pans
O Wire rack
P Removable heating element
Q Broiling rack (if provided)
RCookie sheet (if provided)
SCrumb tray
TCurve wire rack
SIDE GUIDES
The oven has three guides to position
baking pans and wire racks at different
heights. Guide 2 is also used to insert the
removable heating element for the "dou-
ble oven" function, see page 6.
Guide 1
Guide 2
Guide 3
REMOVABLE HEATING ELEMENT HOUSING
When not in use, the removable heating element
(P) can be placed in the special housing under the
oven as show in the figure right.
CONVERSION TABLE:
°C °F
120 250
135 275
150 300
163 325
177 350
190 375
205 400
218 425
233 450
240 470
CHAPTER 1 - GENERAL
1.1 - DESCRIPTION OF THE OVEN AND THE ACCESSORIES

4
1.2 - IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed, including the
following:
1. READ ALL INSTRUCTIONS.
2. Do not touch hot surfaces. Use handles or dials.
3. Before using this appliance, move it two to four inches away from the wall or any object on the counter top.
Remove any object that may have been placed on top of the appliance. Do not use on surfaces where heat may
cause a problem.
4. To protect against electrical shock, do not place unit in or under water. See instructions for cleaning.
5. Close supervision is necessary when any appliance is used by or near children.
6. Unplug from outlet when not in use and before cleaning. Always turn the ON/OFF knob to "OFF" and the
temperature dial to " " before unplugging.
7. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or has been
damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair or
adjustment.
8. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.
9. Do not use outdoors.
10. Do not let cord hang over edge of table or counter, or touch hot surfaces.
11. Do not place on or near a hot gas or electric burner.
12. If the plug gets hot, please call a qualified electrician.
13. Do not use this appliance for other than intended use.
14. Use extreme caution when removing the oven pan or disposing of hot grease.
15. Do not clean with metal scouring pads. Pieces can break off the pad and touch electrical parts, creating a risk of
electric shock.
16. To assure safe operation, oversized foods or utensils must not be inserted into the oven.
17. A fire may occur if this appliance is covered or touching flammable material, including curtains, draperies, walls,
etc., when in operation.
18. CAUTION: Never leave the toaster-oven-broiler unattended when in use (especially when broiling and toasting).
19. When broiling, the oven pan, the broiling rack and wire rack must be used according to the instructions on page 10.
20. Extreme caution should be exercised when using containers other than oven proof metal glass or ceramic.
21. Do not store any materials, other than the manufacturer's recommended accessories, in the oven when not in use.
22. Do not place any of the following materials in the oven: paper, cardboard, plastic and the like.
23. Do not cover any part of the oven with metal foil. This will cause overheating of the oven.
24. To switch off the toaster-oven broiler, turn the ON/OFF knob to "OFF" and the temperature dial
to " ".
THIS PRODUCT IS FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
WARNING: Once having removed the appliance from the packaging, check that the door is intact. As
the door is made from glass, it is fragile, and should be replaced if visibly chipped, scored or scratched.
Furthermore, when using, cleaning or moving the appliance, do not slam or bang the door or pour cold
liquids on the glass when the appliance is hot.
Chapter 1 - General
-

5
Chapter 1 - General
Ideal for meat, pizza,
cakes, baked
casseroles, fruit
desserts, fish, stuffed
vegetables, puddings
and other moist foods
that do not require
browning and crisping.
KEEP WARM
(to keep warm the foods)
GUIDES
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
Turn to this setting to
keep hot food warm.
Do not hold food more
than an hour or reheat
cold food. If not hot
enough for serving turn
thermostat knob up.
Ideal for all types of tra-
ditional grilling; ham-
burgers, hot dogs,
kebabs, toast, etc. Place
the food directly on the
wire rack. The aluminum
bake pan is used to col-
lect any drops of fat. Or
place the broiling rack
(Q) (if included) in the
aluminum bake pan (N).
1
2
3
1.3 - SUMMARY OF OPERATION
PROGRAM
POSITION ON/OFF
AND TOAST
PROGRAM KNOB
POSITION OF
THERMOSTAT
KNOB
POSITION OF
FUNCTION
SELECTOR KNOB
POSITION OF WIRE
RACK
AND ACCESSORIES NOTES/TIPS
ON KEEP
WARM BAKE
ON
ON
UP TO
470° F
or
or
BAKE 1
2
3
1
2
3
or
or
TOAST
BROIL
BROIL
BAKE
(to bake only one dish)
BROIL
(to broil or grill the foods)

6
Set the ON/OFF knob
to the color desired.
Some breads, muffins
etc. will take longer
than others. Reset
knob if results are too
light. Place the bread
to be toasted
following instructions.
GUIDES
1
2
3
1
2
3
1
2
3
Use the two wire racks
(O-T as show in figure)
to cook two frozen
pizzas only; For all
other foods, use the
aluminum bake pan
(N).
Ideal for sandwich,
hot dogs etc.
1
2
3
= aluminum bake pan (N) = Wire rack (O) = Removable heating element (P)
PROGRAM POSITION OF WIRE
RACK
AND ACCESSORIES NOTES/TIPS
ON UP TO
470° F
DOUBLE
BAKE/TOAST
RANGE OF
LIGHT TO
DARK
TOAST
BROIL
or
DOUBLE
BAKE/TOAST
ON UP TO
470° F SLOW BAKE
1
2
3
1
2
3
Use the aluminum
bake pan, sliding it
directly into the lower
guide, or a pan on
the wire rack (O) in
the lower guide.
RANGE OF
LIGHT TO
DARK
TOAST
BROIL
SINGLE
BAKE/TOAST
1
2
3
Chapter 1 - General
POSITION ON/OFF
AND TOAST
PROGRAM KNOB
POSITION OF
THERMOSTAT
KNOB
POSITION OF
FUNCTION
SELECTOR KNOB
= Curve wire rack (T)
DOUBLE BAKE/TOAST
(to bake/toast simultaneously
on two levels)
TOAST
(to toast simultaneously
on two levels)
SLOW BAKE
(to cook delicate food using
only the lower heating element)
TOP BROWN
(to top brown the food)

7
2.1 - OPTIONAL ACCESSORIES (NOT FOR ALL MODELS)
COOKIE SHEET (R)
Must be placed directly on the wire rack. Indispensable for baking biscuits and pastries.
BROILING RACK (Q)
may be inserted inside of the aluminum bake pan (N):
2.2 - HOW TO KEEP FOOD WARM “KEEP WARM”
Place the food to be kept warm on the wire rack (O)
• Set the thermostat knob (E) to the KEEP WARM position.
• Set the ON/OFF knob (G) to ON position.
• Set the function selector knob (H) to the BAKE position.
Once the KEEP WARM function is no longer needed, turn the thermostat knob (E) to “•” and the ON/OFF knob
(G) to OFF.
This feature is designed to keep foods warm, after they are cooked for short periods of time without overcooking.
We do not recommend keeping foods warm for prolonged periods or using this feature to reheat frozen or cold
foods.
2.3 - INSTRUCTIONS FOR BAKING “BAKE”
You can bake foods in your oven, just as in your regular oven. Casseroles or baking dishes may be placed
directly on the removable wire rack (O) or on the curved wire rack (T). Use the aluminum bake pan (N) (or
cookie sheet, if provided) to bake such items as cookies, biscuits, rolls and uncovered casserole dishes.
• Close the door
• Set the thermostat knob (E) to the desired position/temperature
• Set the ON/OFF knob (G) to ON position.
•Set the function selector knob (H) to the BAKE position.
When baking is finished turn the thermostat knob (E) to “•” and the ON/OFF knob (G) to OFF.
NOTE:
We do not recommend the use of glass covers on casseroles.
Glass cooking dishes should never be closer than one inch from the
heating element.
During the bake and toast function, do not put the dripping pan (or any other
accessory/container) directly on the lower heating element.
HELPFUL BAKING HINTS
To obtain best performance from this toaster-oven-broiler:
•Do not overfill the oven. Whenever possible, place foods in center of oven.
•Avoid opening the door too frequently to prevent heat loss.
•Foil may be used to cover the baking dish or pan. Be sure the ends of foil are tucked closely against the
edge of the baking dish/pan.
CHAPTER 2 - USING THE CONTROLS AND SETTING THE MODES

8
CHAPTER 2 - USING THE CONTROLS AND SETTING THE MODES
Food Temperature
setting Notes and tips
(For wire rack position refer to table on page 4)
Approximate time
Whole chicken
2.5-3 lbs. (1-1,5 kg.)
Unstuffed
400 °F
Turning at half of cooking time is not
required. It is possible to cook also
above the broiling rack inverted (lower
position) inside the oven pan, in order to
reduce spattering.
80-90 min. or until internal
temperature of 175 °F in thigh
and breast
Pork loin or Rib Roast
2-3 lbs (1-1,5 kg.) 400 °F Roast as for whole chicken.
80-90 min. or until internal
temperature of 170 °F is reached
Beef Sirloin or Rib Roast
3 lbs (1,5 kg.) 400 °F No turning is needed.
60-70 min. or until tender
and brown
Meat loaf
2-2.5 lbs (900/1300 gr. ) 350 °F
Use the oven pan.
No turning is needed. Mix and beat together
1,5-2 lbs (700 g - 1 kg) at minced meat
(beef). With eggs, bread-crumbs, salt, pepper
and flavoring.
50-60 min.
Baking potatoes
3-4 large cut into pieces 400 °F
Cut the potatoes into small pieces,
use the oven pan, mix three times when
cooking and after at least 20 minutes.
50-60 min.
Loaf cakes 320 °F Use metal rectangular molds.
Follow traditional recipe
timing (slightly lowered)
Pies, uncovered 320 °F Use metal moulds for cakes
Follow traditional recipe
timing (slightly lowered)
Cookies: rolled and cut,
sliced, formed 375 °F
Insert the rack as for TOASTING function. Use
the cookie sheet (if provided) or the aluminum
bake pan.
10-20 min.
2.4 - INSTRUCTIONS FOR LOW BAKING “SLOW BAKE”
Ideal for pastries and cakes with icing. Good results are also achieved when completing the cooking of the
base of foods or for cooking that requires heat above all at the bottom. Insert the dripping pan or wire rack
(O) (with a pan on top) in guide 3.
•Turn the function selector knob (H) to position SLOW BAKE.
•Select the desired temperature using the thermostat knob (E).
•Turn the ON/OFF and toast programming knob (G) to the time desired.
A bell will ring when the set time has elapsed; if the food being kept warm is served before the end of the
set time, manually turn the ON/OFF and toast programming knob (G) to position OFF.
TEMPERATURE AND TIME FOR TYPICAL FOODS ( baking and roasting)
The suggested temperature and times will vary depending on the temperature of the food placed in the oven, the
quantity and personal preference. Times given for meat and poultry are for refrigerator temperature. Add five
minutes for preheating the oven. In order to avoid overcooking when using for the first time we suggest you to set
a low temperature. As you use the oven, the best settings will become familiar.

9
2.5 - INSTRUCTIONS FOR BAKING WITH “DOUBLE BAKE/TOAST” FUNCTION
Insert the removable heating element (P) into the central guide (2) as shown in the figure below. Make sure
the prongs of the removable heating element are correctly and completely inserted into the connector (D).
•Rotate the function selector knob (H) into the DOUBLE BAKE/TOAST position.
•Select the required temperature using the thermostat knob (E).
•Turn the ON/OFF and timer knob (G) to the required time.
Wait for the oven to reach the required temperature (the indicator light goes out), then insert the two alu-
minum bake pans or wire racks (Oand T) into guides 1 and 3 as show in figure on page 6. The end of
cooking will be indicated by a beep.
Each time you finish double oven cooking:
•Turn the thermostat knob (E) to the “•” position and if cooking ends before the time set, turn the timer
knob (G) to the "0" position.
•NEVER rest anything directly on the removable heating element (P), but always use the two wire racks
and aluminum bake pans provided inserted in guides 1 and 3.
•When using the wire racks we suggest you to turn over the food halfway.
Wait for the oven to cool down before removing the heating element (P) and replacing it in the spe-
cial housing.
CHAPTER 2 - USING THE CONTROLS AND SETTING THE MODES
CHICKEN AND
POTATOES
Add about 10 minutes to the cooking time for preheating the oven.
MUFFINS
KEBABS Use the two aluminum bake pans
(N) provided
1200 g
2.5-3 lbs 430 °F 45 min. 1 and 3
1200 g
2.5-3 lbs 400 °F 1 and 3 Use the two aluminum bake pans
(N) provided
1400 g
3 lbs 430 °F 1 and 3
BAKED POTATOES 1200 g
2.5-3 lbs 430 °F
BAKED BEAM 2000 g
4-4.5 lbs 400 °F
COURGETTES WITH
TUNA 2000 g
4-4.5 lbs 400 °F 1 and 3
TARTS 1500 g
3-3.5 lbs 400 °F 1 and 3
FRESH PIZZAS
FROZEN PIZZAS
CHICKEN
1 and 3
2000 g
4-4.5 lbs 430 °F 17 min. 1 and 3 Use the two wire racks (O-T) provid-
ed. Turn over halfway
1000 g
2 lbs 430 °F 30 min. Use the two aluminum bake pans
(N) provided
PIES 1400 g
3 lbs 400 °F 30 min. 1 and 3 Use the two aluminum bake pans
(N) provided
1400 g
3 lbs 430 °F 60 min. 1 and 3 Use the two aluminum bake pans
(N) provided
1 and 3
1 and 3
20 min.
60 min. Use the two aluminum bake pans
(N) provided
60 min. Use the two aluminum bake pans
(N) provided
40 min. Use the two aluminum bake pans
(N) provided
45 min. Use the two aluminum bake pans
(N) provided
45 min. Use the two aluminum bake pans
(N) provided
RECIPE QUANTITY THERMOSTAT
KNOB TIME
WIRE RACK/
ALUMINUM BAKE
PAN POSITION
OBSERVATIONS AND TIPS

2.6 - TOP BROWN “SINGLE BAKE/TOAST”
Top browning is ideal for melting, crisping food surfaces. Use it for open face sandwiches, pre-buttered
muffins or browning cooked casseroles.
•Place the food on the aluminum bake pan or on the wire rack (O) (or cookie sheet, if provided).
•Close the door, both the function selector knob (H) and thermostat knob (E) to BROIL.
•Turn the ON/OFF and toast programming knob (G) to MEDIUM or to ON (for longer browning times).
When experimenting with new uses, watch the food to avoid overbrowning.
When the browning cycle is completed (top surface with desired color) turn the thermostat knob (E) to "•"
and the ON/OFF and toast programming knob (G) to OFF.
2.7 - INSTRUCTIONS FOR BROILING “BROIL”
Always use the aluminum bake pan with the broiling rack (if provided) for broiling. No preheating of the
broiler is necessary.
Do not leave the broiler unattended when in use. Before using the broiler for the first time and after use,
wash the pan and the rack with warm, sudsy water. Do not cover the oven wire rack with foil.
This prevents fat and oils from draining, causing spatter and smoking, and also restricts air circulation for
proper ventilation.
•Place the curved wire rack (T) as shown in the table on page 5.
•Place the food to be broiled on the broiling rack (Q) (if provided) (set inside the aluminum bake pan),
then put the assembly on the wire rack.
•Always leave the oven door open to the stop position (as shown below).
•Turn the thermostat knob (E) and the function selector knob (H) to BROIL.
•Turn the ON/OFF and toast programming knob (G)toON.
•When broiling is finished, turn the ON/OFF and toast programming
knob (G) to the OFF position and the thermostat knob (E) to the "•"
position. Care should be taken when turning food, removing the
aluminum bake pan and disposing of the grease collected while browning. Use oven mitts.
NOTE:
While smoke is an inherent characteristic of good broiling, the following tips should eliminate or greatly
reduce smoking:
Trim excess fat from meat and score the edges to prevent curling. Dry meat, fish and poultry surfaces with
paper towel.
For best results, thaw frozen meats before broiling. These two precautions will reduce or eliminate smoke
from the broiler.
Placing the food on the broiling rack allows the juices and fat to drip into the dripping pan and decreases
spattering while broiling.
If frozen steaks and chops are broiled, allow 1 and a half to 2 times the required broiling time as that
required for unfrozen meat.
If grease "pops" during broiling, turn the temperature control dial to a lower setting.
Remove grease from the pan and wash the pan and broiling rack after use.
The broiler should be cleaned inside after each use. Too much grease accumulation causes smoking. Use
any non-abrasive cleaner and hot water.
For very thick steaks and other thick foods, we recommend using the lower broiling rack position.
Since fish is non-fatty it can be broiled directly on the oven pan. Broil until it flakes easily with a fork. Thin
fillets do not need to be turned.
CHAPTER 2 - USING THE CONTROLS AND SETTING THE MODES
10

2.8 - INSTRUCTIONS FOR TOASTING WITH “DOUBLE BAKE/TOAST” FUNCTION
The capacity of the wire racks (O and T) allows you to toast of 6 slices of bread per rack. However better
results are obtained with 8 slices (4+4).
For toasting, place the slices of bread as shown below:
•For consecutive toasting, turn the ON/OFF and toast programming knob (G) to a LIGHT position.
Always use the oven wire rack for toasting bread, sandwiches, English muffins, shelf foods and frozen
waffles automatically.
•Place the wire racks (O-T) as shown in the table on page 6.
•Center the food to be toasted on the wire rack. Close the door.
•Set the thermostat knob (E) to TOAST BROIL position and the function selector knob to DOUBLE
BAKE/TOAST.
•The ON/OFF and toast programming knob (G) can be set clockwise for LIGHT, MEDIUM or DARK toast
or any shade desired in between.
When using the toaster-oven-broiler for the first time, set the ON/OFF and toast programming knob (G)
to a MEDIUM position. Toast a few pieces of bread to check for desired brownness. If necessary, adjust
the control to suit your preference.
•When toasting, both the top and bottom heating element switch on to brown both sides of the food at the
same time. Condensation may build up on the inside of the glass door. This is normal.
The condensation will evaporate during the toasting cycle.
•Aring indicates the end of the set time. The toasting cycle has been completed and the heating elements
will shut off automatically. Turn the thermostat knob (E) to the "•" position.
NOTE:
This toaster-oven-broiler is capable of toasting in a wide range of colors, automatically from light to dark.
However, if you prefer a lighter shade of toast, simply interrupt the automatic toast cycle by turning the
ON/OFF and toast programming knob (G) to OFF. This will shut the unit off without damaging the oven.
If you prefer a darker shade, restart the toasting cycle by turning the ON/OFF and toast programming knob
(G) clockwise until the desired color is obtained.
Then switch the thermostat knob (E) off manually and the ON/OFF and toast programming knob (G) as
described earlier.
As you use the oven, the best settings for favorite breads will become familiar.
HINTS FOR TOASTING SUCCESS
Heavier breads and frozen breads will require a darker setting. One slice of bread will require a lighter
setting than several slices.
CHAPTER 2 - USING THE CONTROLS AND SETTING THE MODES
Removable
heating
element
wire rack (O)
curved wire rack (T)
11

12
CHAPTER 3 - CLEANING AND MAINTENANCE
Always unplug the toaster-oven-broiler and allow it to cool before cleaning. This unit has been designed
and engineered with your safety in mind. To assure maximum safe operation, keep unit free of grease and
build up of food particles.
1. Remove the wire oven rack.
2. To clean the inside walls, use a damp cloth and a mild liquid soap solution. Never use harsh abrasives,
corrosive products or spray detergents.
•NOTE:
Do not clean interior with metal scouring pads. Pieces can break off and touch electrical parts, creating
risk of electrical shock.
3. To clean the glass door, use a glass cleaner or a damp cloth. Wipe dry with a clean cloth.
4. To clean the exterior finish, use a damp, sudsy cloth. For stubborn stains, a non-abrasive liquid cleaner
or spray glass cleaner may be used. Do not use metal scouring pads, as they might mar the finish.
Always remove cleaning agents by polishing with a dry cloth.
5. The wire rack, the oven pan and the broiling rack may be washed like other kitchen ware.
IF YOUR OVEN HAS A CRUMB TRAY:
Slide the crumb tray out from under the bottom of your oven (see figure). Wash by hand. Should the food
particles be difficult to remove, rinse the crumb tray with hot soapy water and if necessary, scour it
delicately, without scratching
it.
OTHER SERVICING
Any servicing requiring disassembly should be performed by an authorized service representative.
OVEN LIGHT
The oven light (B) is always on when the oven is on. To
replace the bulb, proceed as follows:
•unplug the appliance from the power socket
•unscrew the protective glass cover (X), by turning it
counter-clockwise, and replace the bulb (Y) with a new
one of the same type (see Figure). Replace the protec-
tive glass cover (X).
Only use bulbs suitable for ovens (T300°C)
Note: The oven can still be used even if the bulb is burned-
out
X Y
