Delta Design WS1003 User manual

Insert the 4 leg tubes (rubber feet on bottom)
into the corners of a shelf.
Slide on next shelf to rest on the bottom
Insert extension tubes with joiners
Keep holes facing inwards.
Place top shelf onto plastic collars on extension tubes.
12
34

Copyright 2010
3 SHELF UNIT WS1003
ASSEMBLY DIAGRAM
Delta Cycle Corporation
125 Washinton Street
Foxborough, MA 02035 USA
SEE OVER
Note: Shelves can be mounted either way, as tray or at shelf
Note: Holes face inwards
“CLICK”
IMPORTANT: READ ENTIRE INSTRUCTION BEFORE ASSEMBLY
PARTS LIST
SHELF X 3
LEG TUBE X 4
EXTENSION TUBE X 4
TOP TUBE X 2
JOINER X 2 COLLAR X 4

SEE OVER
Connect the two top tubes to the 4 extension tubes. Determine the desired height of the middle shelf
and then slide shelf above the selected holes.
Attach the four plastic collars at the desired height.
Press the corners of middle shelf
onto the 4 plastic collars. Seat all
corners of each shelf onto its plastic
collar to keep unit rigid.
56
7
©
Copyright 2010
3 SHELF UNIT WS1003
ASSEMBLY DIAGRAM
Delta Cycle Corporation
125 Washington Street
Foxborough, MA 02035 USA
TOP
“CLICK”
Maximum load per shelf (spread evenly): 160lbs (75kgs)
SAFTEY WARNING: Do not use as a step ladder. Never allow children to climb on rack
IMPORTANT: READ ENTIRE INSTRUCTION BEFORE ASSEMBLY
Tab inside ts into tube hole
INCLUDED:
2 spare Joiners allow
for stacking extra racks.
