Balt Split-Level-36 User manual

1
Split-Level-36
Task Table
Assembly Instructions

2
P1 MonitorPlatform 1 EA
P2 KeyboardPlatform 1 EA
P3 UpperInsert 2 EA
P4 UpperInsert 2 EA
P5 Stability Panel 2 EA
P6 Crossbrace 3 EA
P7 LegReceiver 2 EA
Part Drawing Description Qty Part Drawing Description Qty
WOW Task Table
Split-Level-36
Hardware List
A 9/16”Socket Screw 16 EA
A1 1-7/8” Socket Screw 10 EA
A2 1-1/2” Socket Screw 4 EA
B 2-3/8” Socket Screw 8 EA
C Square Nut 8 EA
E Plastic Grommet 1 EA
F Glide 6 EA
G Allen Wrench 1 EA
P8 CPU Rail 1 EA
P9 CPU Foot 2 EA
P10 CPU Platform 1 EA
We recommend that you assemble this
unit on a table.
Toolsrequired: AdjustableCrescent Wrench
Do not use unless all screws are tight. At least every six months, check all screws to be sure
they are tight. If parts are missing, broken, damaged, or worn, stop use of the product
until repairs are made by your dealer using factory authorized parts.
Should you require assistance during assembly,
please call our Customer Service Department
Monday - Friday 8 a.m. - 5 p.m.
Central Standard Time
1-800-749-2258
Missing Parts or UPS Damaged Parts
ForYourConvenienceyoucan
EMAILusat
[email protected]
24HOURS 7 DAYS A WEEK
Left Front & Right Back
Right Front & Left Back

3
Split-Level-36
AssemblyDiagram
P-1
IdentifyandSeparate all the Parts
andHardware.
PlacetheMonitor Platform(P1)with the
insertnutsfacing up. Attach1each
UpperInsert(P3) and 1eachUpper Insert
(P4)using 4 each (B) screws.
(Finger tighten only)
Illustration # 1
Illustration # 2
B
AttachStability Panel (P5)to the
UpperInserts (P3& P4)using 4
Screws( A)as shownin
illustration#2.
P3
P1
A
1.)
2.)
4.)
AttachCrossbrace (P6)
betweentheUpperInserts
(P3 & P4) using 2 Screws (A1)
asshowninillustration #1.
3.)
A1
B
P3
P4
P5
R EAD T HROUGH I NSTRUCTIONS FROM BEGINNING
TO
END BEFORE STARTING TO ASSEMBLE UNIT .
P4
P6

4
AttachCrossbrace (P6)
betweenLeg Receivers
(P7) using 2 Screws (A1)
asshowninillustration #4.
B
5.)
6.)
7.)
A
10.)
Illustration # 3
Illustration # 4
Slide 2 Leg Receivers (P7) over 2
UpperInserts (P3) and2 Upper
Inserts(P4)asshowninillustration
#4. Secure at desired height using 8
each (A) Screws and 8 each (C)
Squarenuts(flat side ofthenut
shouldbenexttothemetal).
AttachCrossbrace (P6)to the
UpperInserts (P3& P4)using 2
Screws(A1) asshown in
illustration#3.
Placethe Keyboard Platform(P2) with
theinsertnuts facing up.Attach1 each
UpperInsert(P3) and 1eachUpper Insert
(P4)using 4 each (B) screws.
(Finger tighten only)
AttachStability Panel (P5)to
theUpper Inserts (P3& P4)
using4 Screws( A)as shown
inillustration#3.
P6
A1
B
P5 P3
P2
P4
C
A
C
F
A1 P7
P7
P6
Attach4 each (F)Leveling
Glides to the 2 each Leg
receivers(P7) .
(Tighten all the screws at this
time using Allen Wrench (G)).
9.)
8.)
A
P3
P4

5
A1
CPU
Assembly
A1
Attach 2 each Glides (F) to the 2 Feet(P9)
asshowninillustration #5.
Placethe CPU Platform (P10) with the
insertnuts facing up.Attach 2 eachCPU
Feet (P9) using 4 each (A2) screws.
(Finger tighten only)
Attach 1 each CPU Rail (P8) to the CPU
Platform(P10) using 2 each (A1)screws.
(Finger tighten only)
(Tighten all the screws at this time
using Allen Wrench (G)).
11.)
12.)
13.)
P9
P9
A2
A1
A2
F
F
P8
P10
Attach1 each CPU Assembly to theout-
side of Leg Receiver(P7) using 2 Screws
(A1)asshown in illustration #6.
P7
Illustration # 5
Illustration # 6
14.)

6SplitLevel36- 12/30/02
TheBaltproductyouhavepurchasedis guaranteed against materialandworkmanshipdefects. This
guaranteeextends1yearfromdateofpurchase. Shouldthisproductfailto function satisfactorily under normal
usedue to defectorimperfection, the defectivepartor productwillbe replaced. Damage causedbycommon
carriersduringshipmentisnotincludedin thisguarantee.
This guarantee sets forth all applicable guarantees and remedies. No other warranty, expressed or
impliedshallapply. Failureto followinstructionsfoundin ImportantInformationSectionofOwner
Sheetshall void theguarantee. Consequential orincidentaldamages andorcosts arenot refundable.
Important
Cap
Grommet(E) installation
Illustration # 6
ToinstallGrommet(E),separate parts
andpressGrommet Sleeve inrectangu-
laropening in Monitor Platform (P1)as
showninillustration#6.
Snap 2 plastic Caps over top of Sleeve
asshowninillustration #6.
15.)
Cap
Sleeve
Grommet (E)
Sleeve
Cap
Cap
P1

7
Split-Level-36
TaskTable
36”
24”
5½”
splitlevel - 12/07/01
19
17
36
Carton 1
8¾
ShippingInformation
2.8 Cubic Feet
35 lbs.
Adjustable
Height
25 ½ - 31 ½
Formore information
1-800-749-2258
