L.L.Bean Platform Bed User manual

L.L.Bean
Platform Bed
Thank you for purchasing our Platform Bed. Assembly of this product requires Phillips
and flat head screwdrivers. We have found it helpful to have a second person present
in at least one step of the assembly.

1 of 4 00000050209
STEP 1
Read through these instructions thoroughly before
beginning assembly. We have found this to be of great
value when first assembling this product.
STEP 2
Remove all parts and hardware from packing material.
Wooden pieces should be placed on a non-abrasive
surface (like the carton or carpet) to prevent damage to
the finish.
STEP 3 Identify and count hardware using diagram at
right.
PARTS
STEP 4 Identify all parts using diagram at right
Assembly of this product requires a Phillips head and a
flat head screwdriver. We have found it helpful to have
a second person present in at least one step of the
assembly.
STEP 5
Locate the headboard panel, headboard brace, and the
two headboard posts. The headboard panel will have two
holes drilled on one side; this side is the back and the
holes are located at the top. The headboard brace will
have two holes drilled on one side; this side is the back
and the holes are located at the top.
STEP 6
Place the headboard panel and headboard brace front side
down on a flat, solid, protected surface. Position the
headboard posts on either side of the headboard panel
and brace making sure to position the side of the
headboard post with the 4 holes to face the headboard
panel and brace; the side of the headboard post with the
two smaller holes and a wood button should be face
down at this point

2 of 4 00000050209
STEP 7
There are two holes drilled on each edge of the
headboard panel. Place a dowel in the lower (and
slightly larger) hole on each side. There are two holes
drilled on each edge of the headboard brace. Place a
dowel in the lower (and slightly larger) hole on each side.
STEP 8
Place a barrel nut in each of the holes on the back of the
headboard panel and headboard brace so that the groove
on the barrel nut is facing up and runs in the direction of
the headboard panel or headboard brace.
STEP 9
Line up the holes in one of the headboard posts with the
holes on the edge of the headboard panel. Starting from
the outside of the headboard post, thread a 4” bolt
through the top hole in the headboard post so that it
connects with the barrel nut in the headboard panel.
Using a Phillips head screwdriver, tighten until the bolt is
threaded into the barrel nut, but DO NOT tighten all the
way (the use of a flat head screwdriver to hold the barrel
nut in the correct position is recommended). Repeat this
process for the first side of the headboard brace, making
sure the dowels also line up. Line up the holes on the
second headboard post and repeat this process on the
other side.
STEP 10
Once all the bolts are connected, go back and tighten all
4 bolts completely. Your headboard is now assembled.
STEP 11
Locate the two side rails, the footboard, and the
headboard.
STEP 12
Stand the headboard upright.
STEP 13
Locate the eight 3½” bolts and eight barrel nuts. Insert
the barrel nuts into the holes on the inside of the side rails
with the groove facing up. Turn the groove on each
barrel nut so that it is running the length of the rail.

3 of 4 00000050209
STEP 14
Line up the end of one rail (finished side out) with the
pre-drilled holes in the headboard (finished side with the
wood button facing towards the rail). Insert a bolt
through each hole so that it screws into the barrel nut in
the rail. Using a Phillips head screwdriver, tighten the
bolt (the use of a flat head screwdriver to hold the barrel
nut in the correct position is recommended).
STEP 15
Place footboard end (wood button side in) at the foot of
the bed. Repeat step #14 to attach.
NOTE: Full, Queen, and King sizes –Leave the bolts
loose for steps 16 and 17.
Twin side skip to step #18
STEP 16
FULL and QUEEN size: Locate the long support bar
with screws attached to either end, and the small wooden
leg with the 2” wooden dowels attached. Line up the
dowels in the wooden leg with the pre-drilled holes in
the center of the support bar. Tap into place. Line up the
support bar so that the screws at either end fit into the
notch on the metal brackets found on the frame ends.
Push down to lock into place.
KING size: Follow Full/Queen instructions for both
support bars.
STEP 17
Tighten all bolts
STEP 18 ALL SIZES
Locate the four 1¼” fluted dowels. Put one dowel into
each of the pre-drilled holes located on the inside edges
of the rails. Tap into place. Unroll the webbed slat
system into the frame. The dowels will hold the last slat
on each end in position. Using the screws provided,
secure the middle slat onto the rails through the pre-
drilled holes.
STEP 19
Tap the wood buttons into place on the outside of the
headboard and footboard and on the headboard posts to
cover the bolt holes.
CARE
Use a clean soft cloth to dust.

4 of 4 00000050209
www.llbean.com
Product Support 1 800 341 4341
