Delta Electronics VFD-M Series User manual

Preface
Thank you for choosing DELTA’s high-performance VFD-M Series. The VFD-M Series is
manufactured with high-quality components and materials and incorporate the latest microprocessor
technology available.
This manual is to be used for the installation, parameter setting, troubleshooting, and daily
maintenance of the AC motor drive. To guarantee safe operation of the equipment, read the following
safety guidelines before connecting power to the AC motor drive. Keep this operating manual at
hand and distribute to all users for reference.
To ensure the safety of operators and equipment, only qualified personnel familiar with AC motor
drive are to do installation, start-up and maintenance. Always read this manual thoroughly before
using VFD-M series AC Motor Drive, especially the WARNING, DANGER and CAUTION notes.
Failure to comply may result in personal injury and equipment damage. If you have any questions,
please contact your dealer.
PLEASE READ PRIOR TO INSTALLATION FOR SAFETY.
DANGER!
1. AC input power must be disconnected before any wiring to the AC motor drive is made.
2. A charge may still remain in the DC-link capacitors with hazardous voltages, even if the power
has been turned off. To prevent personal injury, please ensure that power has turned off before
opening the AC motor drive and wait ten minutes for the capacitors to discharge to safe voltage
levels.
3. Never reassemble internal components or wiring.
4. The AC motor drive may be destroyed beyond repair if incorrect cables are connected to the
input/output terminals. Never connect the AC motor drive output terminals U/T1, V/T2, and
W/T3 directly to the AC mains circuit power supply.
5. Ground the VFD-M using the ground terminal. The grounding method must comply with the
laws of the country where the AC motor drive is to be installed. Refer to the Basic Wiring
Diagram.
6. VFD-M series is used only to control variable speed of 3-phase induction motors, NOT for 1-
phase motors or other purpose.
7. VFD-M series shall NOT be used for life support equipment or any life safety situation.

WARNING!
1. DO NOT use Hi-pot test for internal components. The semi-conductor used in AC motor drive
easily damage by high-voltage.
2. There are highly sensitive MOS components on the printed circuit boards. These components
are especially sensitive to static electricity. To prevent damage to these components, do not
touch these components or the circuit boards with metal objects or your bare hands.
3. Only qualified persons are allowed to install, wire and maintain AC motor drives.
CAUTION!
1. Some parameters settings can cause the motor to run immediately after applying power.
2. DO NOT install the AC motor drive in a place subjected to high temperature, direct sunlight,
high humidity, excessive vibration, corrosive gases or liquids, or airborne dust or metallic
particles.
3. Only use AC motor drives within specification. Failure to comply may result in fire, explosion or
electric shock.
4. To prevent personal injury, please keep children and unqualified people away from the
equipment.
5. When the motor cable between AC motor drive and motor is too long, the layer insulation of the
motor may be damaged. Please use a frequency inverter duty motor or add an AC output
reactor to prevent damage to the motor. Refer to appendix B Reactor for details.
6. The rated voltage for AC motor drive must be ≤240V for 230V models (≤120V for 115V models;
≤480V for 460V models; ≤600V for 575V models) and the mains supply current capacity must
be ≤5000A RMS.

Table of Contents
Preface ............................................................................................................. i
Table of Contents .......................................................................................... iii
Chapter 1 Introduction ................................................................................ 1-1
1.1 Receiving and Inspection....................................................................1-2
1.1.1 Nameplate Information................................................................ 1-2
1.1.2 Model Explanation ...................................................................... 1-2
1.1.3 Series Number Explanation ........................................................ 1-2
1.1.4 External Parts and Labels........................................................... 1-3
1.1.5 Remove Instructions ................................................................... 1-4
Remove Keypad.............................................................................. 1-4
Remove Front Cover....................................................................... 1-4
1.2 Preparation for Installation and Wiring................................................1-5
1.2.1 Ambient Conditions..................................................................... 1-5
1.2.2 Minimum Mounting Clearances................................................... 1-5
1.3 Dimensions.........................................................................................1-7
Chapter 2 Installation and Wiring .............................................................. 2-1
2.1 Basic Wiring Diagram .........................................................................2-2
2.2 External Wiring ...................................................................................2-5
2.3 Main Circuit.........................................................................................2-6
2.3.1 Main Circuit Connection.............................................................. 2-6

2.3.2 Main Circuit Terminals................................................................. 2-8
2.4 Control Terminal Wiring (Factory Settings) ........................................ 2-9
Chapter 3 Keypad and Start Up ..................................................................3-1
3.1 Keypad............................................................................................... 3-1
3.1.1 Description of the Digital Keypad ................................................ 3-1
3.1.2 How to Operate the Digital Keypad LC-M02E ............................. 3-2
3.1.3 LC-M02E ..................................................................................... 3-3
3.2 Operation Method .............................................................................. 3-5
3.3 Trial Run ............................................................................................ 3-5
Chapter 4 Parameters..................................................................................4-1
4.1 Summary of Parameter Settings ........................................................ 4-2
4.2 Parameter Settings for Applications ................................................. 4-14
4.3 Description of Parameter Settings.................................................... 4-20
Chapter 5 Troubleshooting .........................................................................5-1
5.1 Over Current (OC).............................................................................. 5-1
5.2 Ground Fault ...................................................................................... 5-2
5.3 Over Voltage (OV).............................................................................. 5-2
5.4 Low Voltage (Lv) ................................................................................ 5-3
5.5 Over Heat (OH1) ................................................................................ 5-4
5.6 Overload ............................................................................................ 5-4
5.7 Keypad Display is Abnormal .............................................................. 5-5
5.8 Phase Loss (PHL) .............................................................................. 5-5
5.9 Motor cannot Run............................................................................... 5-6
5.10 Motor Speed cannot be Changed .................................................... 5-7
5.11 Motor Stalls during Acceleration....................................................... 5-8

5.12 The Motor does not Run as Expected ..............................................5-8
5.13 Electromagnetic/Induction Noise ......................................................5-9
5.14 Environmental Condition...................................................................5-9
5.15 Affecting Other Machines ...............................................................5-10
Chapter 6 Fault Code Information and Maintenance................................ 6-1
6.1 Fault Code Information .......................................................................6-1
6.1.1 Common Problems and Solutions............................................... 6-1
6.1.2 Reset .......................................................................................... 6-5
6.2 Maintenance and Inspections .............................................................6-5
Appendix A Specifications........................................................................ A-1
Appendix B Accessories........................................................................... B-1
B.1 All Brake Resistors & Brake Units Used in AC Motor Drives ............. B-1
B.1.1 Dimensions and Weights for Brake Resistors& Brake Units....... B-3
B.2 Non-fuse Circuit Breaker Chart ......................................................... B-5
B.3 Fuse Specification Chart ................................................................... B-6
B.4 AC Reactor........................................................................................ B-7
B.4.1 AC Input Reactor Recommended Value..................................... B-7
B.4.2 AC Output Reactor Recommended Value..................................B-7
B.4.3 Applications ................................................................................ B-8
B.5 Zero Phase Reactor (RF220X00A) ................................................. B-10
B.6 Remote Controller RC-01................................................................ B-11
B.7 PU06 ............................................................................................... B-12
B.7.1 Description of the Digital Keypad VFD-PU06 ........................... B-12
B.7.2 Explanation of Display Message............................................... B-12

B.7.3 Operation Flow Chart................................................................B-13
B.8 AMD - EMI Filter Cross Reference .................................................. B-14
B.8.1 Dimensions ...............................................................................B-17
B.9 Din Rail ............................................................................................ B-19
B.9.1 Din Rail-DR01 Adapter .............................................................B-19
B.9.2 Din Rail-DR02 Adapter .............................................................B-20
Appendix C How to Select the Right AC Motor Drive ............................. C-1
C.1 Capacity Formulas.............................................................................C-2
C.2 General Precaution............................................................................C-4
C.3 How to Choose a Suitable Motor .......................................................C-5

Revision May 2008, ME14, SW V3.04 1-1
Chapter 1 Introduction
The AC motor drive should be kept in the shipping carton or crate before installation. In order to
retain the warranty coverage, the AC motor drive should be stored properly when it is not to be used
for an extended period of time. Storage conditions are:
CAUTION!
1. Store in a clean and dry location free from direct sunlight or corrosive fumes.
2. Store within an ambient temperature range of -20 °C to +60 °C.
3. Store within a relative humidity range of 0% to 90% and non-condensing environment.
4. Store within an air pressure range of 86 kPA to 106kPA.
5. DO NOT place on the ground directly. It should be stored properly. Moreover, if the surrounding
environment is humid, you should put exsiccator in the package.
6. DO NOT store in an area with rapid changes in temperature. It may cause condensation and
frost.
7. If the AC motor drive is stored for more than 3 months, the temperature should not be higher
than 30 °C. Storage longer than one year is not recommended, it could result in the degradation
of the electrolytic capacitors.
8. When the AC motor drive is not used for longer time after installation on building sites or places
with humidity and dust, it’s best to move the AC motor drive to an environment as stated above.

Chapter 1 Introduction|
1-2 Revision May 2008, ME14, SW V3.04
1.1 Receiving and Inspection
This VFD-M AC motor drive has gone through rigorous quality control tests at the factory before
shipment. After receiving the AC motor drive, please check for the following:
Check to make sure that the package includes an AC motor drive, the User Manual/Quick Start
and CD, and rubber bushings.
Inspect the unit to assure it was not damaged during shipment.
Make sure that the part number indicated on the nameplate corresponds with the part number
of your order.
1.1.1 Nameplate Information
Example of 1HP 230V AC motor drive
MODE :VFD007M23A
INPUT :3PH 200-240V 50/60Hz 6.0A
OUTPUT :3PH 0-240 V 5.0A 1.9kVA 1HP
Freq. Range :0.1~400Hz
007M23A0T0011230
03.04
AC Drive Model
Input Spec.
Output Spec.
Output Frequency Range
Bar Code
Serial Number
Software Version
1.1.2 Model Explanation
VFD
M
M Series
007
Applicable motor capacity
Series Name 007: 1 HP(0.7kW)
022: 3 HP(2.2kW)
037: 5 HP(3.7kW)
055: 7.5HP(5.5kW)
004: 0.5 HP(0.4kW)
075: 10HP(7.5kW)
A
Version Type
23
Input Voltage
21:Single phase 230V
23:Three phase 230V 43:Three phase 460V
11:Single phase 115V
53:Three phase 575V
1.1.3 Series Number Explanation
Production number
Production year 2005
Production factory
01
Production week
5
T
(Taoyuan)
D007M23A0
Model
230V 3-phase 1HP(0.75kW)
If the nameplate information does not correspond to your purchase order or if there are
any problems, please contact your distributor.

Chapter 1 Introduction|
Revision May 2008, ME14, SW V3.04 1-3
1.1.4 External Parts and Labels

Chapter 1 Introduction|
1-4 Revision May 2008, ME14, SW V3.04
1.1.5 Remove Instructions
Remove Keypad
Remove Front Cover
RST Side UVW Side

Chapter 1 Introduction|
Revision May 2008, ME14, SW V3.04 1-5
1.2 Preparation for Installation and Wiring
1.2.1 Ambient Conditions
Install the AC motor drive in an environment with the following conditions:
Air Temperature: -10 ~ +50°C (14 ~ 122°F) for UL & cUL
-10 ~ +40°C (14 ~ 104°F) for 5.5kw models and above
Relative Humidity: <90%, no condensation allowed
Atmosphere
pressure: 86 ~ 106 kPa
Installation Site
Altitude: <1000m
Operation
Vibration: <20Hz: 9.80 m/s2(1G) max
20 ~ 50Hz: 5.88 m/s2(0.6G) max
Temperature: -20°C ~ +60°C (-4°F ~ 140°F)
Relative Humidity: <90%, no condensation allowed
Atmosphere
pressure: 86 ~ 106 kPa
Storage
Transportation
Vibration: <20Hz: 9.80 m/s2(1G) max
20 ~ 50Hz: 5.88 m/s2(0.6G) max
Pollution
Degree 2: good for a factory type environment.
1.2.2 Minimum Mounting Clearances
150mm
150mm
50mm
50mm
Air Flow

Chapter 1 Introduction|
1-6 Revision May 2008, ME14, SW V3.04
CAUTION!
1. Operating, storing or transporting the AC motor drive outside these conditions may cause
damage to the AC motor drive.
2. Failure to observe these precautions may void the warranty!
3. Mount the AC motor drive vertically on a flat vertical surface object by screws. Other directions
are not allowed.
4. The AC motor drive will generate heat during operation. Allow sufficient space around the unit
for heat dissipation.
5. The heat sink temperature may rise to 90°C when running. The material on which the AC motor
drive is mounted must be noncombustible and be able to withstand this high temperature.
6. When AC motor drive is installed in a confined space (e.g. cabinet), the surrounding
temperature must be within 10 ~ 40°C with good ventilation. DO NOT install the AC motor drive
in a space with bad ventilation.
7. Prevent fiber particles, scraps of paper, saw dust, metal particles, etc. from adhering to the
heatsink.
8. When installing multiple AC more drives in the same cabinet, they should be adjacent in a row
with enough space in-between. When installing one AC motor drive below another one, use a
metal separation between the AC motor drives to prevent mutual heating.
Installation with Metal Separation Installation without Metal Separation
150mm
150mm
150mm
150mm
Air Flow
Side View
150mm
150mm
B
B

Chapter 1 Introduction|
Revision May 2008, ME14, SW V3.04 1-7
1.3 Dimensions
H
DD1
H1
W1
W
H2
Unit: mm [inch]
Model Name W W1 H H1 H2 D D1
VFD004M21A/23A,
VFD007M21A/23A,
VFD015M21A/23A
85.0
[3.35]
74.0
[2.91]
141.5
[5.57]
130.5
[5.14]
10.0
[0.39]
113.0
[4.45]
10.0
[0.39]
VFD002M11A,
VFD004M11A/21B,
VFD007M11A/21B/43B/53A,
VFD015M21B/43B/53A,
VFD022M23B/43B/53A
100.0
[3.94]
89.0
[3.50]
151.0
[5.94]
140.0
[5.51]
10.0
[0.39]
116.5
[4.59]
10.5
[0.41]
D1 D
H2 H
H1
W
W1
Unit: mm [inch]
Model Name W W1 H H1 H2 D D1
VFD022M21A,
VFD037M23A/43A/53A,
VFD055M23A/43A/53A,
VFD075M43A/53A
125.0
[4.92]
110.0
[4.33]
220.0
[8.66]
205.0
[8.07]
15.0
[0.59]
166.3
[6.55]
8.2
[0.32]

Chapter 1 Introduction|
1-8 Revision May 2008, ME14, SW V3.04
This page intentionally left blank

Revision May 2008, ME14, SW V3.04 2-1
Chapter 2 Installation and Wiring
After removing the front cover, check if the power and control terminals are clear. Be sure to observe
the following precautions when wiring.
General Wiring Information
Applicable Codes
All VFD-M series are Underwriters Laboratories, Inc. (UL) and Canadian Underwriters
Laboratories (cUL) listed, and therefore comply with the requirements of the National Electrical
Code (NEC) and the Canadian Electrical Code (CEC).
Installation intended to meet the UL and cUL requirements must follow the instructions provided
in “Wiring Notes” as a minimum standard. Follow all local codes that exceed UL and cUL
requirements. Refer to the technical data label affixed to the AC motor drive and the motor
nameplate for electrical data.
The "Line Fuse Specification" in Appendix B, lists the recommended fuse part number for each
VFD-M Series part number. These fuses (or equivalent) must be used on all installations where
compliance with U.L. standards is a required.
CAUTION!
1. Make sure that power is only applied to the R/L1, S/L2, T/L3 terminals. Failure to comply may
result in damage to the equipment. The voltage and current should lie within the range as
indicated on the nameplate.
2. All the units must be grounded directly to a common ground terminal to prevent lightning strike
or electric shock.
3. Please make sure to fasten the screw of the main circuit terminals to prevent sparks which is
made by the loose screws due to vibration.
4. Check following items after finishing the wiring:
A. Are all connections correct?
B. No loose wires?
C. No short-circuits between terminals or to ground?

Chapter 2 Installation and Wiring|
2-2 Revision May 2008, ME14, SW V3.04
DANGER!
1. A charge may still remain in the DC bus capacitors with hazardous voltages even if the power
has been turned off. To prevent personal injury, please ensure that the power is turned off and
wait ten minutes for the capacitors to discharge to safe voltage levels before opening the AC
motor drive.
2. Only qualified personnel familiar with AC motor drives is allowed to perform installation, wiring
and commissioning.
3. Make sure that the power is off before doing any wiring to prevent electric shock.
2.1 Basic Wiring Diagram
Users must connect wires according to the following circuit diagram shown below.
B2 U/T1
V/T2
W/T3
IM
3~
MO1
MCM
RS-485
NOTE: Do not plug a Modem or telephone line to the RS-485 communication
port, permanent damage may result. Terminal 1& 2 are the power
sources for the optional copy keypad and should not be used while
using RS-485 communication.
6←1
B1
E
RA
RB
RC
120VAC/250VAC 5A
24VDC less than 2.5A
M0
M1
M2
M3
M4
M5
GND
AVI
GND
+10V 10mA(MAX)
3
2
1
VR
0 ～ 10VDC
VR
： 3K ～ 5KΩ
AFM
GND
+
-
VR(1KΩ)
DC 0
～ 10V
RJ-11
1:15V
2:GND
3:SG-
4:SG+
5:Reserved
6:Reserved
Brake Resistor (optional)
Main Circuit Power
The spec. of main circuit
terminal is M3.0
Factory default
Forward/Stop
Reverse/Stop
Reset
Multi-step 1
Multi-step 2
Multi-step 3
Common signal
Master Frequency setting
factory default is VR which is
on the digital keypad
Analog voltage
Analog current
Power for speed setting
series interface
AC Motor
Grounding
Multi-function indication
output contact
Factory default:
indicates malfunction
Multi-function Photocoupler
output contact 48VDC 50mA
Factory default: Indicates
during operation
Analog output
Factory default:
output frequency
For adjustment
Main circuit (power)
terminals
Control circuit terminals
Shielded leads
* If it is single phase model, please select any of the two input power
terminals in main circuit power.
* Single phase model can be input 3-phase power.
S/L2
T/L3
NFB
R/L1
S/L2
T/L3
SA
OFF
ON
MC
MC
RB
RC
Recommended Circuit
when power supply
is turned OFF by a
fault output
R/L1
ACI
E
E
E

Chapter 2 Installation and Wiring|
Revision May 2008, ME14, SW V3.04 2-3
CAUTION!
1. The wiring of main circuit and control circuit should be separated to prevent erroneous actions.
2. Please use shield wire for the control wiring and not to expose the peeled-off net in front of the
terminal.
3. Please use the shield wire or tube for the power wiring and ground the two ends of the shield
wire or tube.
4. Damaged insulation of wiring may cause personal injury or damage to circuits/equipment if it
comes in contact with high voltage.
5. The AC motor drive, motor and wiring may cause interference. To prevent the equipment
damage, please take care of the erroneous actions of the surrounding sensors and the
equipment.
6. When the AC drive output terminals U/T1, V/T2, and W/T3 are connected to the motor terminals
U/T1, V/T2, and W/T3, respectively. To permanently reverse the direction of motor rotation,
switch over any of the two motor leads.
7. With long motor cables, high capacitive switching current peaks can cause over-current, high
leakage current or lower current readout accuracy. To prevent this, the motor cable should be
less than 20m for 3.7kW models and below. And the cable should be less than 50m for 5.5kW
models and above. For longer motor cables use an AC output reactor.
8. The AC motor drive, electric welding machine and the greater horsepower motor should be
grounded separately.
9. Use ground leads that comply with local regulations and keep them as short as possible.
10. No brake resistor is built in the VFD-M series, it can install brake resistor for those occasions
that use higher load inertia or frequent start/stop. Refer to Appendix B for details.
11. Multiple VFD-M units can be installed in one location. All the units should be grounded directly
to a common ground terminal, as shown in the figure below. Ensure there are no ground
loops.
Excellent
