Delta Electronics Igniter IGT005 User manual

Mechanical Dimension:
Gas Igniter
Features
Input voltage:3 Vdc
Switching frequency: 5Hz Min.
oo
Operation temperature:-10C to +55C
oo
Storage temperature:-20C to +70C
Insulated with epoxy resin
PRIMARY SECONDARY OUTPUT VOLTAGE
PART NO. WEIGHT
INDUCTANCE (uH) INDUCTANCE (mH) (KVo-p)
IGT-005 57.0 20% 360.0 20% 37.0 3.0 72g
Recommended Circuit:
Unit: mm
Applications
Via 3 Vdc externally supplied from battery and the functioning of the trigger board, the
high voltage coil is stimulated and results into 37 KVo-p to start up the ignition.
o
AT 25 C, 65%RH, INDUCTANCE TESTED@1KHz/1V
IGT005 Type
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
-
+
TRIGGER
CIRCUIT
IGNITER
6
5
3
4
2
1
A
C
D
B
60.0 Max.
30.0 Max.
70.0 Max.
+ -
A B C D
4.5
73
Electrical Characteristics:
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: [phone]; FAX: [phone]
http://www.deltaww.com
T1
DC 3V
Igniter
