Delta Electronics HMP1350 User manual

Mechanical Dimension :
Features
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG) 252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: [phone]; FAX: [phone]
http://www.deltaww.com
SMT Power Inductor
HMP1350 Type
N
M
L
K
O
C
J
E
D
H
A
B
¡Ó
UNIT : mm/inch
D = 7.80/ 0.307
F = 2.50/ 0.098
G = 2.50/ 0.098
H = 8.00/ 0.315
J = 3.20/ 0.126
K = 7.00/ 0.276
L = 14.00/ 0.551
M = 3.70/ 0.146
121
G
F
1
UNIT : mm/inch
Electrical Characteristics : At 25 : 100KHz, 1V
oC
PART NO. C (MAX) ENO
B
A
1. Tolerance of inductance is 20%.
2. Isat is the DC current which cause the inductance drop to Li.
O
3. Irms is the DC current which cause the surface temperature of the part increase less than 45 C.
OO
4. Operating temperature : -20 C to 105 C ( including self-temperature rise ).
rms
L
(uH)
Li
(uH) MIN
I
(Adc)
(m ) MAX
DCR
sat
I
(Adc)
13
2
HMP1350 12.70 0.5 / 0.50 0.02 13.00 0.5 / 0.512 0.02 5.00 / 0.197 2.40 / 0.094 11.20 / 0.441 4.40 / 0.173
HMP1350S 12.70 0.5 / 0.50 0.02 13.00 0.5 / 0.512 0.02 5.00 / 0.197 2.00 / 0.079 10.80 / 0.425 4.80 / 0.189
RECOMMENDED PAD PATTERNS
RoHS compliant.
Low profile, SMD type.
High current.
Magnetic shielded.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Ideal for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.
HMP1350M-0R5 0.5 0.40 1.3 40.0 30.0
HMP1350-0R6 0.6 0.48 1.3 30.0 30.0
HMP1350-0R7 0.7 0.56 1.3 30.0 30.0
HMP1350-1R0 1.0 0.80 2.1 30.0 26.0
HMP1350-1R5 1.5 1.20 2.1 20.0 26.0
HMP1350-2R0 2.0 1.60 3.5 20.0 17.0
HMP1350M-2R2 2.2 1.76 4.3 18.0 15.8
HMP1350-3R3LD 3.3 2.30 4.3 14.0 15.8
HMP1350BM-4R7 4.7 3.76 6.3 13.5 12.5
HMP1350-150 15.0 12.00 26.0 5.4 7.5
HMP1350S-R85 0.85 0.68 1.3 20.0 30.0
