SMT Power Inductor (MOLDING TYPE)
MPL10X Type
Mechanical Dimension:
Electrical Characteristics:
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
At 25 : 100KHz, 0.25V
oC
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: [phone]; FAX: [phone]
http://www.deltaww.com
142
6.40/0.252
12.0/0.472
4.20/0.165
Mechanical Dimension:
B
A
E
D
UNIT : mm/inch
A =11.50 /0.452 Max.
B = 10.00 0.30 / 0.394 0.012
E = 2.30 / 0.091
C
1. Isat is the DC current which cause the inductance drop approximately 30% of its nominal inductance without current.
O
2. Ir is the DC current which cause the surface temperature of the part increase approximately than 40 C.
RECOMMENDED PAD PATTERNS
Applications
Features
Notebook/Desktop/Server/Video Card applications.
High current POL converters.
Low profile, high current power supplies.
Battery powered devices.
Ideal for power source circuits, DC-DC converter.
DC-AC inverters inductor application.
RoHS compliant.
Low profile, high current SMD type.
Frequency range up to 1MHz.
Lowest DCR/ H, in this package size.
Low buzz noise due to its gap-less structure.
MPL104-0R2 0.20 20% 0.75 0.90 40 32 3.5 / 0.138 4.0 / 0.157
MPL104-R33 0.33 20% 1.00 1.20 35 30 3.5 / 0.138 4.0 / 0.157
MPL104-0R4 0.40 20% 1.05 1.20 32 30 3.5 / 0.138 4.0 / 0.157
MPL104-0R5 0.50 20% 1.50 1.70 32 28 3.5 / 0.138 4.0 / 0.157
MPL104-0R6 0.60 20% 1.50 1.70 30 28 3.5 / 0.138 4.0 / 0.157
MPL104-0R9 0.90 20% 2.30 2.50 27 25 3.0 / 0.118 4.0 / 0.157
MPL105-1R0 1.00 20% 2.30 2.50 35 25 3.0 / 0.118 5.0 / 0.197
PART NO.
(uH)
Lo
1
DCR
(m ) TYP.
DCR
(m ) MAX.
1
Isat
(Adc)
2
Ir
(Adc)
Dimension "D"
mm / inch
MAX
Dimension "C"
mm / inch
0.5 / 0.02
