Delta Electronics SMT Power Inductor HCB0730 Installation instructions

7.5
ED
C
A
B
3.5
2.0
UNIT : mm/inch
A = 7.0 / 0.276 Max.
B = 7.0 / 0.276 Max.
C = 3.0 / 0.118 Max.
D = 2.5 / 0.098
E = 2.0 / 0.079
Features
SMT Power Inductor
HCB0730 Type
Mechanical Dimension :
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG) 252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: [phone]; FAX: [phone]
http://www.deltaww.com
Electrical Characteristics :
(nH)
Isat
(Adc)
At 25 : 100KHz, 1V
oC
3
Irms
(Adc)
2
PART NO. DCR
(m ) MAX
1
L
107
1. Tolerance of inductance is 20%.
2. Isat is the DC current which cause the inductance drop approximately 30% of its nominal inductance without current.
O
3. Irms is the DC current which cause the surface temperature of the part increase less than 45 C.
OO
4. Operating temperature : -20 C to 105 C ( including self-temperature rise ).
RECOMMENDED PAD PATTERNS
HCB0730-470 47 0.3 42 39
HCB0730-680 68 0.3 32 39
HCB0730-820 82 0.3 26 39
HCB0730-101 100 0.3 22 39
HCB0730-121 120 0.3 18 39
RoHS compliant.
Small size, low profile, SMD type.
Magnetic shielded, suitable for high density mounting..
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Ideal for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
