Delta Electronics SMT Power Inductor SILM730 Installation instructions

SMT Power Inductor
SILM730 Type
25 : 100KHz, 0.1V
oC
57
Features
RoHS compliant.
Low profile (3.0mm max. height) SMD type.
Magnetically shielded, suitable for high density mounting.
Self-leads, suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Idel for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.
Electrical Characteristics:
0.00 0.01 0.10 1.00 10.00
CURRENT (A)
1.00
10.00
100.00
INDUCTANCE (uH)
6R0
7R3
8R7
100
120
150
180
220
270
330
390
470
560
680
820
101
5R0
3R9
3R0
SILM730 -3R0 3.0 0.024 3.00
SILM730 -3R9 3.9 0.027 2.60
SILM730 -5R0 5.0 0.031 2.40
SILM730 -6R0 6.0 0.035 2.25
SILM730 -7R3 7.3 0.054 2.10
SILM730 -8R6 8.6 0.058 1.85
SILM730 -100 10.0 0.065 1.70
SILM730 -120 12.0 0.070 1.55
SILM730 -150 15.0 0.084 1.40
SILM730 -180 18.0 0.095 1.32
SILM730 -220 22.0 0.128 1.20
SILM730 -270 27.0 0.142 1.05
SILM730 -330 33.0 0.165 0.97
SILM730 -390 39.0 0.210 0.86
SILM730 -470 47.0 0.238 0.80
SILM730 -560 56.0 0.277 0.73
SILM730 -680 68.0 0.304 0.65
SILM730 -820 82.0 0.390 0.60
SILM730 -101 100.0 0.535 0.54
1. Tolerance of inductance:
2. Irated is the DC current which cause the inductance drop less than 35% of its nominal inductance without current
and the surface temperature of the part increase less than 45
3. Operating temperature : -20 to 105 (including self-temperature rise).
30%.
oC.
oo
C C
2
Irated
(Adc)
PART NO.
1
(uH)
L DCR
(m ) MAX
Mechanical Dimension:
A
D
E
B
9.2
4.0
3.7
C
UNIT : mm/inch
A =7.0 / 0.276Max.
B = 7.0/ 0.276 Max.
C = 3.0/ 0.118Max.
D = 8.5/ 0.335 Max.
E = 4.8 0.3 / 0.189 0.012
F = 3.0 0.2 / 0.118 0.008
F
RECOMMENDED PAD PATTERNS
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG) 252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
