Delta-Opti VM-3402Q User manual
34 inch 4K 165hz gaming monitor
2
EMC COMPLIANCE
This device has been tested and found to comply with the standards for a
class B digital device, pursuant to Part 15 of FCC Rules. Those standards
are designed to provide reasonable protection against harmful interference
in a residential installation. This device generates and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
If this device does cause harmful interference to radio or television
reception, which can be determined by turning the device off and on, user
is encouraged to try to correct the interference by one or more of the
following measures:
---Reorient or relocate the receiving antenna
—Increase the separation between the device and receiver
一Plug the device into a wall outlet different from that connected to the
receiver.
…Consult the dealer or an experienced radio/ technician for help.
CAUTION: any change or modification not expressly illustrated in this manual may void the
warranty.
34 inch 4K 165hz gaming monitor
3
A NOTE: any unshielded cable is not allowed to be used in the
device!
IMPORTANT PRECAUTIONS
1. Before using this device, please read all the instructions in this manual carefully.
2. Please keep the manual carefully for future reference.
3. Unplug this device from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp or wet cloth to clean. Please use LCD
screen detergent for cleaning if it is still dirty.
4. Do not use the parts not recommended by the manufacturer, otherwise it may
cause a hazard.
5. When unplugging the power cord of the monitor or adapter, please hold the
plug with your hand, do not pull the cord directly.
6. Do not place any object on the power cord. Do not trample it either.
7. Do not use the device near water sources, e.g. bathtub, basin, kitchen sink, or
washing machine. Do not place the device on a wet floor, or near a swimming
pool etc. Do not touch the screen with your fingers or other hard objects.
8. Slots and openings on the housing and its back or bottom are provided for
ventilation. To ensure reliable operation of the components and to protect them
from overheating, these openings must not be blocked or covered placing the
device on a bed, sofa, rug, or other similar surface. The device should never be
placed near or over a radiator or heater and should not be placed in a built-in
installation unless proper ventilation is provided.
9. Make sure that the device is at least 5cm distance from the wall or other objects
around when it is in use.
10. The power supply must respond to that stated on the rating plate. If you have
any query about the power supply, please refer to the dealer or local power
supply provider.
11. As a safeguard measure, the monitor or adapter is equipped with a power cord
with three-terminal plug, the third terminal is grounded. If the plug cannot be
inserted into the outlet, please contact an electrical technician for replacing the
original outlet while keeping the safeguard measure in effect.
12. Ensure that the power socket and cord in use are able to take the sum of the
rated currency of all the products.
13. Do not put the device at the place where user is subject to mal-operation.
14. Observe all the warnings and instructions described in the manual.
15. Do not overload the power outlet or use any extension cord, otherwise it may
cause fire or electric shock.
16. 16.Do not attempt to repair this device yourself since opening or removing
covers may expose you to dangerous voltage or other hazards. Refer servicing
34 inch 4K 165hz gaming monitor
4
to qualified service personnel.
17. 17.Unplug this monitor or AC adaptor from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
a.When the power cord or plug is damaged or worn.
b.If the device has been dropped or its housing has been damaged.
c.When the performance of the device deteriorates distinctly.
18. The power cord is the main facility to turn on/off the device; unplug it if the
device is not used for a long period of time.
19. Store the device at a place of good ventilation; avoid strong sunlight, high
temperature or humidity.
20. Store the device at a place at -10°C~55°C room temperature. Otherwise, it
may cause permanent damage.
34 inch 4K 165hz gaming monitor
5
Manual catalog
1．Introduction .........................................................................................................1
1) General...............................................................................................................1
2) Features .............................................................................................................1
2．Packing list............................................................................................................2
3.Connection instructions...........................................................................................3
4.Operation ................................................................................................................5
1) Power Switch......................................................................................................5
2) Power Indicator ..................................................................................................5
3) AUTOButton .......................................................................................................5
4) - Button ..............................................................................................................5
5) Menu Button ......................................................................................................5
6) +Button ..............................................................................................................5
5.OSD two (option)...................................................................................................14
1) Power on-off switch..........................................................................................14
2) Indicator light ...................................................................................................15
3) Function keys....................................................................................................15
4) OSD menu ........................................................................................................15
a. main menu....................................................................................................15
b. submenu.......................................................................................................15
5) Settinh of display mode ....................................................................................17
6) Visual in spection..............................................................................................18
7) OPeration Warranty..........................................................................................19
34 inch 4K 165hz gaming monitor
1
1．Introduction
1) General
Thank you for purchasing the latest model of LCD monitor, with advantages of
high display performance and light weight etc, meanwhile with the power
saving and no-radiation features, the latest LCD will bring you comfortable,
safe and environmental-protection brand-new visual experience.
Your purchase and use of this product is highly appreciated!
2) Features
.- High performance intelligent multi-frequency scanning, use active matrix
Thin film transistor liquid crystal display (TFT).
---Micro Computer digital technology control, no radiation, no glare 旧uilt-in
multimedia speaker system (option).
—Built-in AV signal connection terminal and 8 terminal (option).
---Comply with VESA DPMS International Power Saving Regulation.
・・・ Support DDC 1/2B and Windows PNP Plug & Play.
Microprocessor based with OSD (On Screen Display) control, be able to adjust
the image to optimum.
―Built-in hoisting hole complying with International Standard(VESA), which is
able to hang the display on the wall
34 inch 4K 165hz gaming monitor
2
2．Packing list
Please make sure the following items are included with your LCD display before
installation:
— A LCD monitor (with pedestal)
…A HDMI signal cable, DP signal cable (option)
---TYPE-C line
…A power cord cable
---User's manual
If any of there items are missing, please contact with your dealer for technical
support and customer service.
Stand Riser
DP
HDMI
Power Cable
USB Type-C Cable
User Manual
34 inch 4K 165hz gaming monitor
3
3.Connection instructions
1) Connection bracket
For flat monitors, place the product screen face down on a level, stable surface.
For curved monitors, place the product screen vertically facing forward, and protect
the whole machine with both hands on the left and right sides.
Removing the bracket: Operate in the order of 2 and 1 above.
Remarks: There may be differences in disassembly and assembly of different
models, and the actual product shall prevail.
2) Connection of signal cable
Before connecting your monitor and PC with signal cable please turn off your
monitor and computer. And then insert one end of the signal cable into the VGA
or DVI jack on your computer and lock it with two fixed screw for ensured
grounding. Finally please insert another end of signal cable to the VGAor DVI
signal input jack of monitor and lock it with fixed screw.
34 inch 4K 165hz gaming monitor
4
3) Connection of power cord
First, insert one end of power cord cable into the power input jack of monitor, and
another end into power outlet.
4) Connection of Audio cable
Please insert one end of audio cable into the sound card audio output terminal on
Your computer another end into the audio input terminal of monitor
5) Power on
Turn on the monitor and computer, and then indicator will light green(or blue)
when the screen is under normal condition.Please check to see if there is any
wrong with the connection of video signal cable if the indicator lights red.
6) Self-inspection
If the monitor inspects there is no horizontal and vertical signalit will prompt to
Check the videvo input please refer to the illustration below and the monitor will
Enterin to power saving mode after several seconds, the indicator will light red.The
screen will restore to normal display once receiving video signal.
（1）
（2）
（3）
（4）
34 inch 4K 165hz gaming monitor
5
7) Lmage Adjustment
Please adjust the image according to your need;please refer to the"Operation
In Section Three.
4.Operation
OSD one
1) Power Switch
Digital control light-touch switch,used for turningon or off monitor power.
2) Power Indicator
When the monitor is under normal working conditionthe indicator will light green
(or blue): if the monitor is under saving mode,the indicator will light red or off.And
the indicator will turn off under the power offmode.When the power indicator
turns off, it means that the monitor is under offmodeplease disconnect the
Power cable when the monitor isn ot used for the purpose of safety
3) AUTOButton
Auto adjust/exit
4) - Button
Select and adjust the OSDitems(Decrease the value)
5) Menu Button
Activate OSD, enter sub menu, select items,confirm selection.
6) +Button
SelectandadjusttheOSDitemslncreasethevalue
Rotation angle Description: -5 ~ 15 degrees
1) According to your requirements, the upper and lower heights of the liquid crystal
display can be adjusted appropriately.
Left and right angles, and elevation angles.
2) Hold the base of the monitor when you adjust the angle of the monitor
to prevent the display from shaking;
34 inch 4K 165hz gaming monitor
6
3) The adjustment angle of each model is different, please refer to the actual model.
Power Indicator
When the monitor is under normal working condition, the indicator will light green
(or blue); if the monitor is under saving mode, the indicator will light red or off. And
the indicator will turn off under the power off mode. (When the power indicator
turns off, it means that the monitor is under off mode,please disconnect the power
cable when the monitor is not used for the purpose of safety.
MENU Adjustment Setting
1.Press Menu into Main Function choice Menu
2.Press + or - to switch the image of Main Function changing settings.
3.Press Menu to switch to submenu changing setting and
1) Press + or - to adjust the setting.
2) Press AUTO to return back Main Menu.
OSD menu and operation menu introduction
Press the MENU to call out the OSD menu (main menu), please see the illustration as
below:
slope
left and right
optional
up and down
34 inch 4K 165hz gaming monitor
7
To Press + or - into this menu.
With + or - to select the desired items, and then press the MENU button for
adjustment, with + or - button to adjust the display items to optimum, press again for
confirmation and exit adjustment.
Brightness/Contrast Adjustment
Brightness: use + or - to adjust the brightness to optimum.
Contrast: use + or - to adjust the contrast to optimum..
Exit: back to previous menu.
34 inch 4K 165hz gaming monitor
8
color setting :
Gamma：2.0/2.2/2.4 optional
scene mode selection : After entering the mode + or - Select
Standard/Picture/Movie/Game/FPS/RTS/SRGB/AdobeRGB/DCI-P3 Select Confirm
Color temperature: + or - select Standard/Warm/Cool/User confirmed
Hue/Saturation/Blue Light Filter select + or - select to confirm
Exit:bacto previous menu
Pivture Quality Setting
34 inch 4K 165hz gaming monitor
9
Clarity:+ or - select
Response Time: + or - Select High/Middle/Low/Off/Select Confirm
Noise reduction:+ or - Select High/Middle/Low/Off/Select Confirm
Dynamic Brightness:off
Dark balance: + or - select size to confirm
Exit:bacto previous menu
34 inch 4K 165hz gaming monitor
10
Display
Image mode: + or - Select image ratio Widescreen/4:3/1:1/Auto Select Confirm
Exit:bacto previous menu
34 inch 4K 165hz gaming monitor
11
Audio
Mute: Confirm + or - Select Off/On to confirm
Sound: confirm + or - select the sound size to confirm
Exit:bacto previous menu
34 inch 4K 165hz gaming monitor
12
multi-window
Multi-window: confirm + or - split screen mode open
Picture input source: confirm + or - select 2 picture DP/HDMI channel switching
PIP Size: Confirm + or - Select Resize Confirm
Picture-in-picture position: confirm + or - select left and right to move the position
switch
Multi-screen: After switching multiple screens, DP resolution 1720*1440/HDMI
resolution 1720*1440-60hz
as the picture shows
34 inch 4K 165hz gaming monitor
13
OSD Tool Adjustment Menu
language selection: Confirm button to select. English/Chinese/Korean/Japanese/etc.
multi-language selection
H-position adjustment：useortoadjustthehorizontalpositiontooptimum
V-position adjustment: use+or -to adjust the vertical position to optimum.
Phase adjustment: use+ or -to adjust the focus and definition to optimum.
Clock adjustment:use+or-toadjust the clockimage display to track stability.
Sharpness:1 2 3 4 5 6
34 inch 4K 165hz gaming monitor
14
Exit:bacto previous menu
Other
FreeSync (Adaptive Sync): + or - confirmation on/off
HDR: + or - Select On/Off to confirm
Lighting effect: confirm + or - confirm on/off
Reset: Confirm + or - to restore the factory settings in the future menu
Exit:bacto previous menu
5.OSD two (option)
1) Power on-off switch
This key is digital control, working by slightly touch, used for turn on or turn off the
display power supply.
34 inch 4K 165hz gaming monitor
15
2) Indicator light
When monitor is working normally , the indicator light looks green (or blue), when
the monitor is under electricity saving, the indicator light looks red or extinct, when
power off, the indicator light will extinct, but the adapter still under the power-on
condition, in view of safety, should cut off the adapter power supply.
3) Function keys
a. AUTO/SELECT key
Only in DP mode: When there is no OSD menu, this key is used for automatic
adjustment to adjust the geometry settings to the best state. Under OSD menu, this
key is used as confirmation. In DP+HDMI mode, this key is used to switch between DP
and HDMI signals
b. +/- or >/< key
Under OSD menu, these two keys are used for scan and select menu from left or
right, meanwhile adjust the volume. When under without menu condition, if the
monitor either without audio signal, -/< Can used as shortcut key of brightness;
if the monitor with audio signal function, +/- or >/<l only used for adjusting volume.
c. MENU key
Menu key , used for enter into menu and exit from menu.
4) OSD menu
a. main menu
Item: 1. Color adjusting; 2. Picture adjusting; 3. Auto-adjusting; 4. Item adjusting;
5. Others; 6. Exit
b. submenu
Item: 1 .brightness 2.contract ratio 3.auto image adjustment 4.auto color adjustment
5.color temp 6.red 7.green 8.blue 9.Aspect ratio 10.H-position 11.V- position 12.clock
13.phase 14.language 15.Menu H- position 16.Menu V-position 17.OSD timer
18.reset
Table of contents
Other Delta-Opti Monitor manuals
