Delta UNOnext User manual

【UNOnext indoor air quality monitor】
Quick start guide ver 1.3
Delta Electronics, Inc.
No. 256 Yangguang St., Neihu, Taipei11491, Taiwan
TEL:[phone]
Email: [e-mail]
[e-mail]
2020
【Overview】
UNOnext is an all-in-one air quality monitor that can detect temperature, humidity, carbon dioxide, PM2.5,
PM10, total volatile organic compounds (VOCs), formaldehyde, carbon monoxide, and ozone, which can all
be monitored visually through sensors. It can be directly connected to a fresh air system to improve air
quality, which not only saves energy, but also lets users breathe fresh air with peace of mind. It is suitable for
many different types of environments, including residentialbuildings, commercial buildings, medical
institutions, and places sensitive to air quality, such as nursing homes and day carecenters.
This product detects various types of air pollution that may have an adverse effect on the human body.
【Display and button functions】
Appearance Displaylayout
Function definition
Theproduct has two functions which are “smart control” and “IAQ sensing", default is "IAQ sensing".
【Detailed description】
‧The power indicator lights up after power is connected. If the power indicatordoes not light up, please
make sure that the power cord is firmly installed.
‧The air quality indicator turns blue after the device is turned on, which means that it is booting up. After
booting is complete, it changes color according to the air quality status, in which green is good, yellow is
moderate, red is bad, and purple is polluted.
‧The product has built-in multiple sensors, and the values are displayed in rotation. If the value of a sensor
exceeds the threshold, the warning icon is been displayed in the upper left of the screen.
‧In “smart control”. double-press the button (within 5 seconds) to change the fan speed and control mode.
The default is “IAQ sensing” and may be switched into the following modes. If the interval between key
presses is more than five seconds, the equipment is turned on and off. It willenter “smart control” when it
is turned on again. In "IAQ sensing", the button can turn on/off night mode (the screen and indicators
on/off).
Smart control IAQ sensing
‧Use the APP for Wi-Fi configuration. The APP provides instructions on operating procedures. Please verify
that the controller you purchased is the Wi-Fi version. The Wi-Fi connection indicator turns on after
connecting to Wi-Fi.
‧The product was calibrated in the factory, and no additionalcalibration is required. If a sensor value is
affected by the environment at your site, please contact the distributor for manual calibration.
‧This controller has built-in multiple sets of precision sensors. Collision and vibration during transportation
may affect its readings. It is recommended that you turn it on and install it, and then wait for about one hour
until the chamber reaches balance.
‧After you turn on the device, these sensors needs to warm-up for 5 minute or less for PM2.5, PM10, and
carbon dioxide, and 5 minutes for formaldehyde, carbon monoxide, ozone, and TVOC. Sensor data is
updated every 10 seconds.
‧The CO2sensor uses an Automatic Baseline Calibration (ABC) algorithm to maintain accuracy. If the
component encounters vibration when it is reinstalled in a different place, values may drift. Please keep
operation for weeks to find the baseline in this case.
【Note】Follow the instructions below to facilitate the automatic calibration of CO2components.
‧This product needs a continuous power supply, please installit in a fixed position
‧Theindoor environment reaches the level of the outdoor environment for four consecutive hours each week
By-pass
valvestatus
Fanspeed
Filterhealth
Sensor
values
Control
mode
Sensorcategory
Reminder of
exceeding
threshold
Turnoff
ventilation
equipment Smart
mode Manual
control
lowspeed
Manual
control
medium
speed
Manual
controlhigh
speed
"Smart mode" will turn ventilation equipment on and off depending on whether the air quality exceeds the
threshold or not. There are two control modes: Turbo and UNOECO. Users can set a threshold on the
APP to determine activation conditions.
Indoor air quality indicator description
Indoor air quality indicator color (status) PM2.5(ug/m3)PM10(ug/m3)CO2(ppm)
Green(Good) 0-28 0-60 400-800
Yellow(Moderate) 29-35 61-75 801-1000
Red(Bad) 36-140 76-300 1001-4000
Purple(Polluted) >140 >300 >4000
Function Screen layout Button function
Smart control Sensor values, controlstatus
and mode, filter health Switch control mode and fanspeed
IAQ sensing Sensor values iteration Screen and indicator on/off switch
Pin
Pinname
Definition
1GND Ground
2AI1Analog input-1 External temperature sensor
3AI2 Analog input 2
4NO4 Digital output - HF
5NO3 Digital output - MF
6NO2 Digital output - LF
7NO1 Digital output –ON/OFF
8B2 Modbus slave B
9A2 Modbus slave A
10 B1 Modbus master B
11 A1 Modbus master A
12 GND Ground
13 Vin 9-24V DC input
14 Vout 9-24V DC output
Number Switch Definition ON
OFF
1Modbus terminalresistor
2Modbus slave position[3]
3Modbus slave position[2]
4Modbus slave position[1]
5Modbus slave position[0]
6Maximum fan speed [1]
7Maximum fan speed [0]
8Control mode selection
* The above are the default states of the DIPswitches
【Note】The default activation standard for CO2is 1,000 ppm, PM2.5 is 28 ug/m3, PM10 is 60ug/m3,
which can be selected in the APP. The color of the indicator breathing light is pre-defined by it.
Avoid Indoor use Keep away from Keep away from light Keep away Keep away from Do not use a direct
sunlight only air-conditioning outlet heat source from fire cooking area cleaning agent
【Layout Considerations】
【Note】The temperature module built into this product has been calibrated in the factory, but the
accuracy may be impacted by the installation environment, such as nearness to a heat source or high
air flow. To get more accuracy, calibrate the product after installation. Wait for one hour after
installation for calibration. Please contact dealers and local sales for detailed information.
Terminal block Filter reset DIP switch Adapterconnector
Table1. Terminal block pin function definition Table2. DIP switch function definition
Wi-Fi power LED(red)
Wi-Fi connection LED(green)
Multi-func.button
mode/fanspeed/bind
Power Wi-Fi link Filterhealth
Bluetoothlink Equipmentstatus NFC tag IAQindicator
Icon Smart mode
plan
Description
Turbo If it exceeds the threshold, the equipment will operate at full speed and
exchange air until the air quality improves.
UNOECO It’s smart and balanced control strategy by using self-learning from historical
IAQ trend, it will turn the equipment on earlier and try to keep IAQ index under
the threshold.
For any Delta’s indoor air quality monitors, we recommend an area coverage of 160 m2with the area of
enclosed space calculated individually. For example:
‧One open space of 160 m2requires one monitor.
‧Three conference rooms of 80 m2each requires three monitors, one in each room.
Space over 160 m2should consider installing multiple monitors throughout the room to achieve
optimal coverage. It is also recommended to align the sensor deployment area with the HVAC thermal
zoning plan.

【Wiring diagram –Connect the equipment via RS485】
Connect A1 and B1 with the equipment’s A and B, the recommended wire to use is 22AWG Shielded Foil
Twisted-Pair (SFTP)
Power onverification
‧After the product has been installed, the power indicator lights up after the power is connected, and the air
quality indicator turns blue, which means the device is turning on at this time. If green or yellow appears, it
means that the device has completed booting and the current air quality status is displayed. If the power
indicatordoes not light up, pleaseverify that the power cord is properly connected and that there is a
supply of power.
‧Wireless model has Bluetooth and Wi-Fi functionality. Users can go to the iPhone app store or Android play
store to download the APP.
【Installation guide】
Installation steps
‧The product is recommended to be installed at a height of 80-150 cm (31.5-59 inches).
‧Use the wall mount included in the box to install it on the wall, or install in a power box. The wall mount has
screw hole spacing (60mm and 84mm) suitable for power boxes in multiple countries, but the power box
must be installed horizontally as shown in Figure 1.
‧Verify that the power supply and data lines are laid out according to specifications before installation
‧As shown in Figure 2, install it on the wallmount and verify that all four buckles are installed and fixed.
‧As shown in Figure 3, usea hexagonal screwdriver to fasten the M4 hex socket screws to complete the installation
【Note】Power source notice
This product uses a 9-24V DC power supply. AC power must be converted to the required power source or
use the specified power adapter . The output voltage Vout is the same with input voltage Vin. Output
voltage should be 12V when using a 12V power adapter.
Fig 1. Fig2. Fig 3.
Do not inject contaminants
Do not directly inject contaminants containing gases or particulate matter. Exposure to excessive
contaminants can permanently damage the sensor.
Do not repair this product yourself
The product does not have components that users can repair themselves. Do not attempt to open it. Once the
warranty sticker breaks, the warranty is void.
【Note】Do not insert objects through the vents, which may be dangerous and damaging.
Cleaning the exterior of UNOnext
To clean the product, unplug the power cord and all wiring.
Wipe with a soft, cotton-free cloth. Avoid moisture at any openingson the device body. Please do not spray
liquids directly onto it.
Prohibit live line operation
When the installer configures DIP switches and terminal connector, be sure to power off before execution
and then power on after.
‧In RS485 control mode, if the equipment is successfully connected, the equipment status indicator is
static on/off . If it is not correctly connected, the equipment status indicator will keep blinking.
‧The installer can verify ventilation volume by switching to manual mode and corresponding fan speed.
‧After a period, the health of the filter will return to zero. At this time, it is recommended to replace the filter.
After the replacement, you can press and hold the filter reset button on the back of the product toreset.
DIP switches
1 2 3 4 5 6 7 8
Enable smart control function
‧Turn all the DIP switches up, press the multi-func. button then power on, release the button after the filter
health LED blinks, and confirm that the screen has changed successfully after restarting, and then restore the
DIP switches as previously stated.
【Wiring diagram –Connect the equipment via digital output】
【Note】
To connect multiple equipment, you must set different Modbus slave address. Please reference the
user manual of that equipment to config slave address.
Connect multiple equipment
‧The product can connect to the 4 same equipment via RS485 in series through daisy chain - linear
topology. At this time, each device will follow the same control mode and fan speed level.
Wiringdiagram Fan speedlevels Controlinterface
12V GND BA
6 7
Unlimited 1level
6 7
3levels
6 7
2levels
6 7 8
RS485
Delta ERV“VEB250AT3”
Dipswitches
1110 12 13
B1 A1 Vin 14
Vout
65 789
21 34B2 A2
NO2 NO1
NO3
NO4
AI2
AI1
GND
Low fan
speed
Medium fan
speed
High fan
speed
NO4
COM
NC C NO
12VDC
AC250V +
-
Relay
+
-
Relay
ON/OFF NO1
COM
【Place of origin】
This product is made in Taiwan. The place of origin is No. 256, Yangguang St., Neihu Dist., Taipei City,
Taiwan (R.O.C.).
【APP and website links】
The product is equipped with wireless technology and can use an APP and website to monitor the air
quality status, which can be obtained using the following QR codes. (For the wireless model only). Please
go to the official website to learn about how to use the product.
iOSAPP AndroidAPP UNOweb Doc. &Resources
1 level output (ON/OFF)
3 level output (FAN speed)
12VDC
AC250V
or/and
【Note】
•DIP switches pin8 should be turned ON
•External relay requirement : AC250V resistive, and 12VDC SPDT, 15A
Using right connectors and ports
‧Do not force the connector into the port. Check the port for foreign objects. If the connectors and ports
do not fit easily, it may be because they do not match each other. Make sure that the connector
matches the port, and that the connector is aligned to the correct location corresponding to the port.
‧Insert the wrong pin may result in damage to the product, it will not be responsible for the product
warranty.
+
12VDC
AC250V
+
12VDC
AC250V
NO3
NO2
COM
COM
-
-
5
6
4
(depend on equipment)
【Note】Not following instructions may result in damage to the product or other items.
【Note 】
The product supports control of energy recovery ventilation and inline fan. Regarding the compatibility
of equipment brands and models, please contact your dealer and local sales for technical evaluation
before purchasing. No matter RS485 or digital output, control logic is fixed for smart ventilation
control, PLEASE DON’T TO USE FOR OTHER APPLICATIONS
0 - 100 ug/m3±25 ug/m3
100 - 1000 ug/m3±25%
0 - 100 ug/m3±10 ug/m3
100 -1000 ug/m3±10%
±30 ppm ±3%
Measurement Range Accuracy
0.5-10 ppm
Wall mount, NTC thermistor (Optional)
Connectivity
0.01 ppm
±20 ppm or ±5%
±15% at 20~50 ºC
±15% in lab test (Ethanol)
±0.3 ºC at 25 ºC and 50% rH
±5% at 25 ºC and 50% rH
±1ºC at 25 ºC and 50% rH
For background ambient
light reference
0-30000 ppb
0-5000 ppb
0-10000 lux
0-1000 ug/m3
0-1000 ug/m3
0-500 ppm
400-10000 ppm
0-100% rH
0 -50 ºC
NTC10k Thermistor
