Instruction Manual
Manuel d’Utilisation
Manual de Instrucciones
20-950
FRANÇAIS (20) ESPAÑOL (38)
A28328-08-22-08
Copyright © 2006, 2008 Delta Machinery
INSTRUCTIVO DE OPERACIÓN, CENTROS
DE SERVICIO Y PÓLIZA DE GARANTÍA.
LÉASE ESTE INSTRUCTIVO
ANTES DE USAR EL PRODUCTO.
2
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
Read and understand all warnings and operating instructions before using any tool
or equipment. Always follow basic safety precautions to reduce the risk of personal injury. Improper
operation, maintenance, or modification of tools or equipment could result in serious injury and property
damage. Our tools and equipment are designed for certain applications. DO NOT modify and/or use this
product for any application other than that for which it was designed.
SAFETY GUIDELINES - DEFINITIONS
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities
contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
IMPORTANT SAFETY INSTRUCTIONS ....................2
SAFETY GUIDELINES - DEFINITIONS .....................2
GENERAL SAFETY RULES .......................................3
ADDITIONAL SPECIFIC SAFETY RULES ................4
FUNCTIONAL DESCRIPTION ...................................6
CARTON CONTENTS ...............................................7
ASSEMBLY .................................................................8
OPERATION ...............................................................13
If you have any questions relative to its application DO NOT use the product until you have written Delta Machinery and
we have advised you.www.deltaportercable.comTechnical Service Manager, Delta
Machinery, 4825 Highway 45 North, Jackson, TN 38305. In Canada,
• PowerToolInstitute, www.powertoolinstitute.org
• NationalSafetyCouncil,
• AmericanNationalStandardsInstitute,www.ansi.org - ANSI 01.1
Safety Requirements for Woodworking Machines
• U.S.DepartmentofLaborwww.osha.gov
SAVE THESE INSTRUCTIONS!
TROUBLESHOOTING................................................17
MAINTENANCE..........................................................17
SERVICE.....................................................................18
ACCESSORIES...........................................................19
WARRANTY................................................................19
FRANÇAIS ..................................................................20
ESPAÑOL....................................................................38
will death or serious
injury
could death or serious
injury.
mayminor or moderate
injury.
mayproperty damage
For your own safety, read the instruction manual before operating the machine.
Wear eye and hearing protection and always use safety glasses.
Wear proper apparel.
Do not use the machine in a dangerous environment.
Maintain all tools and machines in peak condition.
Check for damaged parts.
Keep the work area clean.
Keep children and visitors away.
Reduce the risk of unintentional starting.
Use the guards.
Remove adjusting keys and wrenches before starting the machine.
Use the right machine.
Use recommended accessories.
Use the proper extension cord.
Secure the workpiece.
Feed the workpiece against the direction of the rotation of the blade, cutter, or abrasive surface.
Don’t force the workpiece on the machine.
Don’t overreach.
Never stand on the machine.
Never leave the machine running unattended.
Turn the machine “ OFF”, and disconnect the machine
from the power source before installing or removing
accessories, changing cutters, adjusting or changing
set-ups.
Make your workshop childproof with padlocks, master switches, or by removing starter keys.
Stay alert, watch what you are doing, and use common sense.
Use of this tool can generate and
disburse dust or other airborne particles, including
wood dust, crystalline silica dust and asbestos dust.
GENERAL SAFETY RULES
Failure to follow these rules may result in serious personal injury.
ADDITIONAL SPECIFIC SAFETY RULES
Do not operate this machine until it is completely
assembled and installed according to the instructions.
Obtain advice from your supervisor, instructor, or
another qualified person if you are not thoroughly
familiar with the operation of this machine.
Follow all wiring codes and recommended electrical
connections to prevent shock or electrocution.
Secure the machine to a supporting surface.
Never start the machine before clearing the table of
all objects (tools, scrap pieces, etc.).
. Never start the machine with the drill bit, cutting tool,
or sanding drum against the workpiece.
Properly lock the drill bit, cutting tool, or sanding
drum in the chuck before operating this machine.
Remove the chuck key before starting the machine.
Tighten all lock handles before starting the machine.
Use only drill bits, cutting tools, sanding drums, or
other accessories with shank size recommended in
your instruction manual.
Use only drill bits, cutting tools, or sanding drums
12. Use recommended speeds
Avoid awkward operations and hand positions.
. Keep arms, hands, and fingers
Hold the workpiece firmly against the table.
Turn the machine “off” and wait for the drill bit, cutting
tool, or sanding drum to stop turning
Properly support long or wide work-pieces.
Never perform layout, assembly or set-up work on the
table/work area when the machine is running.
Turn the machine “OFF”, disconnect the machine
from the power source, and clean the table/work
area before leaving the machine.
ADDITIONAL INFORMATION
SAVE THESE INSTRUCTIONS
Refer to them often
and use them to instruct others
RISK OF UNSAFE OPERATION. Failure to follow these rules may result in serious injury.
5
Fig. A Fig. B
GROUNDED OUTLET BOX
CURRENT
CARRYING
PRONGS
GROUNDING BLADE
IS LONGEST OF THE 3 BLADES
GROUNDED OUTLET BOX
GROUNDING MEANS
ADAPTER
POWER CONNECTIONS
“OFF”
Electrocution hazard. Do not expose the machine to rain or operate the machine in damp
locations.
MOTOR SPECIFICATIONS
“OFF”
GROUNDING INSTRUCTIONS
Electrocution hazard. This machine must be grounded while in use to protect the operator from
electric shock.
1. All grounded, cord-connected machines:
2. Grounded, cord-connected machines intended for use on a supply circuit having a nominal rating less than
150 volts:
NOTE:
Electrocution hazard. In all cases, make certain that the receptacle in question is properly
grounded. If you are not sure, have a qualified electrician check the receptacle.
FOREWORD
FUNCTIONAL DESCRIPTION
NOTICE:
Fig. D-1 Fig. D-2
MINIMUM GAUGE EXTENSION CORD
Ampere Total Length Gauge of
Rating Volts of Cord in Feet Extension Cord
0-6 120
up to
25 18 AWG
0-6 120 25-50 16 AWG
0-6 120 50-100 16 AWG
0-6 120 100-150 14 AWG
6-10 120
up to
25 18 AWG
6-10 120 25-50 16 AWG
6-10 120 50-100 14 AWG
6-10 120 100-150 12 AWG
10-12 120
up to
25 16 AWG
10-12 120 25-50 16 AWG
10-12 120 50-100 14 AWG
10-12 120 100-150 12 AWG
12-16 120
up to
25 14 AWG
12-16 120 25-50 12 AWG
12-16 120
MINIMUM GAUGE EXTENSION CORD
Ampere Total Length Gauge of
Rating Volts of Cord in Feet Extension Cord
0-6 240
up to
50 18 AWG
0-6 240 50-100 16 AWG
0-6 240 100-200 16 AWG
0-6 240 200-300 14 AWG
6-10 240
up to
50 18 AWG
6-10 240 50-100 16 AWG
6-10 240 100-200 14 AWG
6-10 240 200-300 12 AWG
10-12 240
up to
50 16 AWG
10-12 240 50-100 16 AWG
10-12 240 100-200 14 AWG
10-12 240 200-300 12 AWG
12-16 240
up to
50 14 AWG
12-16 240 50-100 12 AWG
12-16 240
3. 230 VOLT SINGLE PHASE OPERATION
In all cases, make certain that the
receptacle in question is properly grounded. If you
are not sure, have a qualified electrician check the
receptacle.
EXTENSION CORDS
Use proper extension cords. Make sure your extension cord is in good condition and is a 3-wire
extension cord which has a 3-prong grounding type plug and matching receptacle which will accept the machine’s
plug. When using an extension cord, be sure to use one heavy enough to carry the current of the machine. An
undersized cord will cause a drop in line voltage, resulting in loss of power and overheating. Fig. D-1 or D-2, shows
the correct gauge to use depending on the cord length. If in doubt, use the next heavier gauge. The smaller the gauge
number, the heavier the cord.
Fig. C
Includes: (3)
M8x1.25x125mm carriage head screws;
(4) flat washers; (2) lockwashers; and (2) hex
nuts
CARTON CONTENTS
UNPACKING AND CLEANING
FIRE HAZARD.
6
7
8
9
10
4
3
1
5
2
11
12
13
14
15
16
20
21
22
23
17
18
19
24
25
26
3" (7.6 cm)
MINIMUM
28" (71 cm)
MINIMUM
21" (53 cm) MINIMUM
ASSEMBLY TOOLS REQUIRED
•
•
ASSEMBLY TIME ESTIMATE
RISK OF UNSAFE OPERATION. If you
do not fasten your drill press in a permanent manner,
you must fasten the drill press to a plywood mounting
board to prevent the drill press from tipping over
during normal use.
RISK OF UNSAFE OPERATION. Use a
good grade of plywood with a minimum 3/4" (19 mm)
thickness. Do not make the mounting board from
particle board since particle board breaks easily.
RISK OF UNSAFE OPERATION. Make
sure that the plywood extends a minimum of 3" (7.6
cm) on all four sides of the base as shown in Fig. 3.
NOTE:
RISK OF UNSAFE OPERATION. You must
secure the plywood base to the floor or supporting
surface if the drill press has any tendency to vibrate,
slide, or walk during normal operation.
ASSEMBLY
To reduce the risk of injury, turn unit off and disconnect it from power source before installing and
removing accessories, before adjusting or when making repairs.
Fig. 2
Fig. 3
C
E
D
A
B
Fig. 1
A
A
A
C
Fig. 4
71 cm
3" (7.6 cm)
MINIMUM
3" (7.6 cm)
MINIMUM
3" (7.6 cm)
MINIMUM
NOTE:
F
I
Fig. 5
Fig. 6
Fig. 7 Fig. 8 Fig. 9
Fig. 10A Fig. 10B
L
K
G
H
J
K
M
N
J
Fig. 16A
M
L
K
ATTACHING THE HEADSTOCK TO THE COLUMN
Fig. 16B
N
RISK OF PERSONAL INJURY -
RISK OF UNSAFE OPERATION AND PERSONAL INJURY. Do not leave the table unattended without
fully tighetening the 12 mm screw into place.
Fig. 11
O
Fig. 13 Fig. 14
Fig. 15A Fig. 15B
P
Q
R
P
S
11
IMPORTANT:
NOTE:
IMPORTANT:
IMPORTANT:
NOTE:
Fig. 18
Fig. 17
T
V
U
PO
INSTALLING THE CHUCK
Fig. 19
Q
Fig. 20
S
RISK OF PROPERTY DAMAGE.
ATTACHING THE PINION SHAFT HANDLES
R
12
ROUTING THE LAMP CORD
NOTE:
F
H
I
Fig. 22
Fig. 23
E
D
C
A
A
Fig. 21B
B
C
F
G
H
Z
Y
Fig. 21A
E
E
G
OPERATIONAL CONTROLS AND ADJUSTMENTS
OPERATION
“ON”,“ON”
“OFF”,“OFF”
Make sure that the switch is in the “OFF” position before plugging cord into outlet. Do not touch
the plug’s metal prongs when unplugging or plugging in the cord.
STARTING AND STOPPING THE DRILL PRESS
IMPORTANT: "OFF"
In the event of a power outage (such as a breaker or fuse trip), always move the switch to the “OFF”
position until the main power is restored.
FIRE HAZARD. To reduce the risk of
fire, use a 40 watt or less, 120 volt, reflector track-
type light bulb (not supplied). DO NOT USE a stan-
dard household light bulb. Do not allow the reflector
track-type light bulb to extend below the lamp
shade.
To reduce the risk of injury, turn unit off
and disconnect it from power source before installing
and removing accessories, before adjusting or when
making repairs.
A
FLEXIBLE LAMP
“ON”“OFF”
Fig. 26
SPINDLE SPEED ADJUSTMENT
ONLY
"ON"
AB
Fig. 25A Fig. 25B
Fig. 24A
A
Fig. 24B
TABLE ADJUSTMENTS
RISK OF PERSONAL INJURY.
B
A
Fig. 27 Fig. 28
E
F
Fig. 29
T-SLOTS
L
Fig. 31
C
G
Fig. 30
15
To reduce the risk of injury, turn unit off and disconnect it from power source before installing and
removing accessories, before adjusting or when making repairs.
DRILLING HOLES TO DEPTH
Fig. 40
NOTE:
ADJUSTING THE SPINDLE RETURN SPRING
To reduce the risk of injury, turn unit off and disconnect it from power source before installing and
removing accessories, before adjusting or when making repairs.
IMPORTANT:
NOTE:
R
AISING AND LOWERING THE SPINDLE
Fig. 43
A
B
C
C
E
A
F
G
B
C
A
B
Fig. 41 Fig. 42
E
D
NOTE:
NOTE:
The use of accessories and attachments not recommended by Delta may result in risk of injury.
IMPORTANT:
Fig. 44
A
B
MACHINE USE
Fig. 45
A
B
D
C
NOTE:
To reduce the risk of injury, turn unit off
and disconnect it from power source before installing
and removing accessories, before adjusting or when
making repairs.
INSTALLING AND REMOVING DRILL BITS
CORRECT DRILLING SPEEDS
Use the recommended speed for the the drill press bit and workpiece.
DRILLING WOOD
DRILLING METAL
TROUBLESHOOTING
www.deltaportercable.com
MAINTENANCE
To reduce the risk of injury, turn unit off and disconnect it from power source before installing and
removing accessories, before adjusting or when making repairs.
KEEP MACHINE CLEAN
Wear certified safety equipment for eye, hearing and respiratory protection while using compressed air
FAILURE TO START
LUBRICATION & RUST PROTECTION
AC
P
REPLACEMENT PARTS
SERVICE AND REPAIRS
SERVICE
ANNUAL MAINTENANCE STEPS
To reduce the risk of injury, user must read tool instruction manual before operating product.
To reduce the risk of serious personal injury, turn tool off and disconnect tool from power source before
installing and removing accessories, before adjusting or changing set-ups or when making repairs.
FOLLOW THESE STEPS ANNUALLY to properly maintain the 20-950 Drill Press.
Fig. 46
B
•
www.deltaportercable.com
Since accessories other than those offered by Delta have not been tested with this product, use
of such accessories could be hazardous. For safest operation, only Delta recommended accessories should be
used with this product.
ACCESSORIES
FREE WARNING LABEL REPLACEMENT
Five Year Limited New Product Warranty
Delta will repair or replace, at its expense and at its option, any new Delta machine, machine part, or machine accessory which in normal
use has proven to be defective in workmanship or material, provided that the customer returns the product prepaid to a Delta factory service
center or authorized service station with proof of purchase of the product within five years and provides Delta with reasonable opportunity
to verify the alleged defect by inspection. For all refurbished Delta product, the warranty period is 180 days. Delta will not be responsible for
any asserted defect which has resulted from normal wear, misuse, abuse or repair or alteration made or specifically authorized by anyone
other than an authorized Delta service facility or representative. Under no circumstances will Delta be liable for incidental or consequential
damages resulting from defective products. Some states do not allow the exclusion or limitation of incidental or consequential damages, so
the above limitation or exclusion may not apply to you. This warranty is Delta’s sole warranty and sets forth the customer’s exclusive remedy,
with respect to defective products; all other warranties, express or implied, whether of merchantability, fitness for purpose, or otherwise, are
expressly disclaimed by Delta. For further detail of warranty coverage and warranty repair information, visit www.deltaportercable.com or call
(888) 848-5175. This warranty gives you specific legal rights and you may have other rights which vary in certain states or provinces.
WARRANTY
LATIN AMERICA:
LES INSTRUCTIONS IMPORTANTES DE SURETE
Lire toutes instructions d'avertissements et opération avant d'utiliser n'importe
quel outil ou n'importe quel équipement. En utilisant les outils ou l'équipement, les précautions de
sûreté fondamentales toujours devraient être suivies pour réduire le risque de blessure personnelle.
L'opération déplacée, l'entretien ou la modification d'outils ou d'équipement ont pour résultat la
blessure sérieux et les dommages de propriété. Il y a de certaines applications pour lequel outils et l'équipement
sont conçus. La Delta Machinery recommande avec force que ce produit n'ait pas modifié et/ou utilisé pour
l'application autrement que pour lequel il a été conçu.
www.deltamachinery.com
Information en ce qui concerne l'opération sûre et correcte de cet outil est disponible des sources suivantes:
•
MESURES DE SÉCURITÉ - DÉFINITIONS
causera la mort ou des
blessures graves.
pourrait
décès ou des blessures graves.
pourrait
des blessures mineures ou modérées
pourraitpar des dommages à la propriété.
Certaines poussières produites par les travaux de ponçage, de sciage, de meulage, de
perçage et par toute autre activité de construction contiennent des produits chimiques reconnus par l’État de la
Californie comme pouvant causer le cancer, des anomalies congénitales ou d’autres problèmes liés aux fonctions
reproductrices. Voici quelques exemples de ces produits chimiques :
Table of contents
Languages:
Other Delta Power Tools manuals
Delta
Delta 4'' Jointer User manual
Delta
Delta 37-071 User manual
Delta
Delta 902118 43-505 User manual
Delta
Delta DJ-15 User manual
Delta
Delta 11-950 User manual
Delta
Delta 32" Radial Drill Press User manual
Delta
Delta 17-965 User manual
Delta
Delta 43-460 User manual
Delta
Delta 36-205 User manual
Delta
Delta DJ-30 User manual
Delta
Delta ShopMaster CL180JS User manual
Delta
Delta 22-590X User manual
Delta
Delta 43-431 User manual
Delta
Delta ShopMaster DP250 User manual
Delta
Delta 6" Deluxe jointer User manual
Delta
Delta S Series User manual
Delta
Delta DJ-15 User manual
Delta
Delta 432-01-651-0006 User manual
Delta
Delta 37-280 User manual
Delta
Delta 37-195 User manual
Popular Power Tools manuals by other brands
Bahco
Bahco P-SL specification
Grizzly
Grizzly AGS 72 Lion-Set Translation of the original instructions for use
TE Connectivity
TE Connectivity 2063527-1 instruction sheet
Omer
Omer 90.38 CLD2-5 Use, maintenance and spare parts manual
Cooper Tools
Cooper Tools Cleco LIVEWIRE 47BA B Series instruction manual
Makita
Makita 4324 instruction manual
AGP
AGP P4K Original instructions
MGF
MGF i-press mini MAP2LMGF instruction manual
LAGENDA
LAGENDA B363 instruction manual
Rothenberger
Rothenberger Universal ROTIGER VARIO Electronic Instructions for use
Parkside
Parkside PMFW 280 A1 - 7 manual
MULTIPRESS
MULTIPRESS M6P Series Operating instructions and service manual
