10” Tilting Arbor Saw
SPECIFICATIONS
High quality and feature loaded.
•Magnetic motor starter with thermal
overload and no-voltage protection.
•Full cabinet with motor cover
for sawdust containment.
•Built-in storage for miter
gage, rip fence and blade
wrench.
•Extra-large cast-iron table with
extension wings provides ample
support for large work.
•Integral T-slot grooves prevent
miter gage from falling during wide
cut-off operations.
•Convenient up-front blade raising and
tilting controls for safe, easy operation.
Model 36-755 10ÓTilting Arbor Saw.
Includes basic machine with Jet-Lock®,
Micro-Set®rip fence; see-thru blade guard,
splitter and anti-kickback attachment; front
graduated guide bar, rear guide bar, miter
gage, 10Ódia. saw blade, table insert, arbor
and motor pulleys, V-belt, (2) table extension
wings, motor cover; 2HP, 230V, single phase,
60 Hz., TEFC motor; motor starter and
instruction manual.
Model 36-751 10ÓTilting Arbor Saw with 30ÓUnifence®
Saw Guide. Same as Model 36-755 above less Jet-Lock®,
Micro-Set®rip fence with front and rear guide bars and (1)
table extension wing, but with Unifence®Saw Guide which
includes fence, carriage assembly, front guide bar, table
frame, legs and mounting hardware. Less table board.
Model 36-752 10ÓTilting Arbor Saw with 52ÓUnifence®
Saw Guide. Same as Model 36-755 above less Jet-Lock®,
Micro-Set®rip fence with front and rear guide bars and (1)
table extension wing, but with Unifence®Saw Guide which
includes fence, carriage assembly, front guide bar, table
frame, legs, shelf support brackets and mounting hardware.
Less table and shelf boards.
Cuts stock 31⁄8Óthick; a full
21⁄8Óat 45° blade tilt. 2 HP
motor delivers plenty of power
for fast, efficient cutting.
Unique “table top located”
adjusting screws for accurate
setting of 45° and 90° positive
blade stops.
Motor ........................................... 2 HP, 230V, 60 Hz., single phase
Blade:
Diameter .................................................................... 10Ó(254 mm)
Arbor ............................................................................. 5⁄8Ó(16 mm)
Speed ............................................................................... 4000 rpm
Capacity:
Max. depth of cut 90° ................................................. 31⁄8Ó(79 mm)
Max. depth of cut 45° ................................................. 21⁄8Ó(54 mm)
Max. rip R of blade .................................................... 25Ó(635 mm)
Max. rip L of blade .................................................. 151⁄2Ó(394 mm)
Max. rip R of blade w/30ÓUnifence Saw Guide ........ 30Ó(762 mm)
Max. rip R of blade w/52ÓUnifence Saw Guide ...... 52Ó(1321 mm)
Max. rip L of blade w/30Óor
52ÓUnifence Saw Guide ....................................... 83⁄4Ó(222 mm)
Table in front of saw blade at
max. cutting height .............................................. 121⁄4Ó(311 mm)
Max. width of dado ..................................................... 13⁄16Ó(21 mm)
Table:
Size w/extension wings .......................... 36Óx 27Ó(914 x 686 mm)
Size w/ext. wing and 30Ó
Unifence Saw Guide ...................... 621⁄2Óx 27Ó(1588 x 686 mm)
Size w/ext. wing and 52Ó
Unifence Saw Guide ...................... 781⁄2Óx 27Ó(1994 x 686 mm)
Height ...................................................................... 341⁄4" (870 mm)
Miter gage groove ........................................ 3⁄8Óx 3⁄4Ó(10 x 19 mm)
Overall Dimensions:
Width ....................................................................... 45Ó(1143 mm)
Width w/30ÓUnifence Saw Guide ........................ 671⁄2Ó(1715 mm)
Width w/52ÓUnifence Saw Guide ........................... 83Ó(2108 mm)
Depth ......................................................................... 32Ó(813 mm)
Height ........................................................................ 39Ó(991 mm)
Weight: Model 36-755 ......................................... 288 Ibs. (131 kg)
Model 36-751 ......................................... 290 Ibs. (132 kg)
Model 36-752 ......................................... 293 Ibs. (133 kg)
Model 36-755 10ÓTilting Arbor Saw
Model 36-752 10ÓTilting Arbor Saw
with 52ÓUnifence Saw Guide
and 34-998 Accessory Table and
Shelf Boards.
Model 36-751 10ÓTilting Arbor Saw
with 30ÓUnifence Saw Guide and
34-914 Accessory Table Board.
For accessories, see page 27
®

6
10” Contractor’s Saw®
For accessories, see page 27
Model 36-444
10ÓContractor’s Saw®
Model 36-445
10ÓContractor’s Saw®
with 30ÓUnifence
Saw Guide
Model 36-440
10ÓContractor’s
Saw®with
29ÓPrecision
Saw Guide
®
New Series 2000 10˝ Contractor’s
Saws take woodworking into the
next century.
•Series 2000 10˝ Contractor’s Saws are available
with your choice of the UniRip Fence, Unifence®,
Precision Saw Guide or Biesemeyer Saw Fence
systems.
•New UniRip T-Square style fence (model 36-444
only) offers up to 30˝ of right-hand cutting capaci-
ty. Provides additional stock support in front of the
blade and includes built-in T-slots for adding jigs or
other accessories.
•Each Series 2000 10˝ Contractor’s Saw comes
with a new sturdy steel stand that features an inte-
gral dust chute for improved dust collection and
built-in storage for rip fence, miter gage and blade
wrenches.
•Maximum 31Ú8Ódepth of cut at 90°; 21Ú8Óat 45°
for clean cutting of standard stock sizes.
•Patented Auto-Set®T-Slot miter gage with
adjustable stops at 90° and 45° positions
for accurate straight and angle cutting.
•Integral T-slot table grooves prevent miter gage
from falling during wide cut-off operations.
•Extra-large table provides ample support for
large work.
•Unique “table top located” adjusting screws for
accurate setting of 45° & 90° positive blade stops.
•Large on/off paddle switch is positioned near the
top of the table for quick access.
•Convenient up-front blade raising and tilting
controls for safe, easy operation.
•Heavy-duty 11⁄2HP induction motor delivers
plenty of extra power and speed for the toughest
cutting jobs.
Model 36-444 10ÓContractor’s Saw®.Includes basic
machine with two table extension wings, stand, belt and
pulley guard, see-thru blade guard with splitter and
anti-kickback attachment, miter gage, UniRip fence with
front and rear guide bars, 10Ósaw blade, V-belt, arbor and
motor pulleys plus 11⁄2 HP, 115/230V, single phase motor.
Model 36-445 10ÓContractor’s Saw®with 30Ó
Unifence®Saw Guide. Same as model 36-444 but with
one table extension wing and 30ÓUnifence®Saw Guide
which includes front and rear guide bars, table support
legs and mounting hardware. Less table board.
Model 36-440 10ÓContractor’s Saw®with 29Ó
Precision Saw Guide. Same as model 36-444 but with
one table wing extension and 29ÓPrecision Saw Guide
which includes fence, carriage assembly, front guide rail,
table frame and mounting hardware. Less table board
and legs.
Model 36-450 10ÓContractor’s Saw®with 50Ó
Precision Saw Guide. Same as model 36-444,
but with one table extension wing and 50ÓPrecision Saw
Guide which includes fence, carriage assembly, front
guide rail, table frame, table support legs and mounting
hardware. Less table board.

7
10” Contractor’s Saw®
For additional accessories, see page 28
SPECIFICATIONS
Model 36-460 10ÓContractor’s Saw®with 28Ó
BiesemeyerT-Square®Home Shop Saw Fence
System. Same as model 36-444, but with one table
extension wing and 28ÓBiesemeyer T-Square®Home
Shop Saw Fence System which includes T-Square
fence, front and rear rails, guide tube and mounting
hardware. Less table board and legs.
Model 36-470 10ÓContractor’s Saw®with 40Ó
BiesemeyerT-Square®Home Shop Saw Fence
System. Same as model 36-444, but with one table
extension wing and 40ÓBiesemeyer T-Square®Home
Shop Saw Fence System which includes T-Square
fence, front and rear rails, table support legs, guide
tube and mounting hardware. Less table board.
Model 36-480 10ÓContractor’s Saw®with 52Ó
BiesemeyerT-Square®Home Shop Saw Fence
System. Same as model 36-444, but with one table
extension wing and 52ÓBiesemeyer T-Square®Home
Shop Saw Fence System which includes T-Square
fence, front and rear rails, table support legs, guide
tube and mounting hardware. Less table board.
Model 36-490 10ÓContractor’s Saw’ with 30Ó
Biesemeyer T-Square®Commercial Saw Fence
System. Same as model 36-444, but with one table
extension wing and 30ÓBiesemeyer T-Square®
Commercial Saw Fence System which includes
T-Square fence, front and rear rails, guide tube and
mounting hardware. Less table board and legs.
Model 36-490
10ÓContractor’s Saw®
with 30ÓBiesemeyer
T-Square®Commercial
Saw Fence System
Motor ................... 11⁄2HP,115/230V, 60 Hz.,
single phase
Blade:
Diameter................................. 10Ó(254 mm)
Arbor.......................................... 5Ú8Ó(16 mm)
Speed ........................................... 3000 rpm
Capacities:
Max. depth of cut .................... 31Ú8Ó(79 mm)
Max. depth of cut at 45° ......... 21Ú8Ó(54 mm)
Max. rip to right of blade for:
Model 36-444 .................... 30Ó(762 mm)
Model 36-445 .................... 30Ó(762 mm)
Model 36-440 .................... 29Ó(737 mm)
Model 36-450 .................. 50Ó(1270 mm)
Model 36-460 .................... 28Ó(711 mm)
Model 36-470 .................. 40Ó(1016 mm)
Model 36-480 .................. 52Ó(1321 mm)
Model 36-490 .................... 30Ó(762 mm)
Max. rip to left of blade for:
Model 36-444 ................. 131Ú2Ó(343 mm)
Model 36-445 ................... 83Ú4Ó(222 mm)
Models 36-440, 36-450, 36-460, 36-470,
36-480 and 36-490 ........ 12Ó(305 mm)
Table in front of saw at
max. depth of cut .......... 121Ú4Ó(311 mm)
Max. width of dado ................. 13Ú16Ó(21 mm)
Table:
Size ................... 20Óx 27Ó(508 x 686 mm)
Size with extension wings ............ 40Óx 27Ó
(1016 x 686 mm)
Size with extension wing and:
Unifence table board ................62Óx 27Ó
(1575 x 686 mm)
29ÓPrecision Saw Guide table
board .......... 54Óx27Ó(1372x686 mm)
50ÓPrecision Saw Guide table
board ........ 78Óx 27Ó(1981 x 686 mm)
28ÓBiesemeyer T-Square Home Shop
Saw Fence System .................. 52Óx 27Ó
(1321 x 686 mm)
40ÓBiesemeyer T-Square Home Shop
Fence System .......................... 64Óx 27Ó
(1626 x 686 mm)
52ÓBiesemeyer T-Square Home Shop
Fence System .......................... 76Óx 27Ó
(1930 x 686 mm)
30ÓBiesemeyer T-Square Commercial
Saw Fence System .................. 54Óx 27Ó
(1372 x 686 mm)
Miter gage groove .......................... 3Ú8Óx 3Ú4Ó
(10 x 19 mm)
Height on steel stand ......... 341Ú4Ó(185 mm)
Overall Dimensions:
Height (on steel stand) ...........39Ó(991 mm)
Width with wings and guide bar ..............57Ó
(1448 mm)
Width with wing and:
Model 36-445 .................. 62Ó(1575 mm)
Model 36-440 .................. 59Ó(1499 mm)
Model 36-450 .................. 80Ó(2032 mm)
Model 36-460 .................. 58Ó(1473 mm)
Model 36-470 .................. 70Ó(1778 mm)
Model 36-480 .................. 82Ó(2083 mm)
Model 36-490 .................. 60Ó(1524 mm)
Depth Model 36-444 ........... 42Ó(1067 mm)
Models 36-445, 36-440
and 36-450 .......................43Ó(1092 mm)
Models 36-460, 36-470
and 36-480 .........................36Ó(914 mm)
Model 36-490 ...................42Ó(1067 mm)
Weight:
Model 36-444 .................. 220 lbs. (99 kg)
Model 36-445 ................ 248 lbs. (112 kg)
Model 36-440 ................ 245 lbs. (111 kg)
Model 36-450 ................ 266 lbs. (120 kg)
Model 36-460 ................ 267 lbs. (121 kg)
Model 36-470 ................ 275 lbs. (125 kg)
Model 36-480 ................ 282 lbs. (128 kg)
Model 36-490 ................ 286 lbs. (130 kg)
Model 36-480
10ÓContractor’s Saw®
with 52ÓBiesemeyer
T-Square®Home Shop
Saw Fence System

8
10” Contractor’s Saw®II
SPECIFICATIONS
Solid construction and
quality features make this
saw one smooth operator.
•Powerful 11⁄2HP, single phase induction
motor provides the power to handle any
cutting operation.
•Auto-Set®T-Slot miter gage has adjustable stops at 45°
and 90° for precision straight and angle cutting jobs.
•Rack and worm gear blade elevating mechanism
raises and lowers blade smoothly and easily.
•See-through blade guard with splitter and anti-
kickback fingers promotes operator safety.
•Accessory dust collector connector mounts to saw
carriage for attaching a dust collection system
right at the source of dust and chips.
•Large on/off paddle switch.
Model 36-630 10ÓContractor’s Saw®Il. Includes basic
machine with 11⁄2HP, single phase motor, blade guard,
splitter and anti-kickback fingers, Jet-Lock®rip fence, guide
bars, Auto-Set®miter gage, 10Ósaw blade, table insert,
arbor pulley, motor pulley, V-belt, two extension wings,
steel leg stand and instruction manual.
Model 36-640 10ÓContractor’s Saw®Il with Precision
Saw Guide. Same as above less Jet-Lock®rip fence with
front and rear guide bars and one table extension wing,
but with 29ÓPrecision Saw Guide, carriage assembly, front
guide rail, table frame, mounting hardware and
instruction manual. Less table board.
Model 36-630
10ÓContractor's Saw®II
Self-aligning Jet-Lock®
Micro-Set®rip fence glides
on chrome-plated rails.
Model 36-640 10ÓContractor’s Saw II
with 29ÓPrecision Saw Guide
Cast iron 20Óx 27Ótable with
T-slotted miter gage grooves
and two extension wings.
Motor ................................. 11⁄2HP, 115/230V, single phase, 60 Hz.
Blade:
Diameter .................................................................... 10Ó(254 mm)
Arbor ............................................................................. 5⁄8Ó(16 mm)
Speed ............................................................................... 3000 rpm
Capacity:
Maximum depth of cut at 90° ..................................... 31⁄8Ó(79 mm)
Maximum depth of cut at 45° ..................................... 21⁄8Ó(54 mm)
Maximum rip to right of blade:
Model 36-630 ....................................................... 24Ó(610 mm)
Model 36-640 ....................................................... 29Ó(737 mm)
Maximum rip to left of blade ................................... 121⁄4Ó(311 mm)
Table in front of saw blade at max. cut ................... 121⁄4Ó(311 mm)
Maximum width of dado ............................................. 13⁄16Ó(21 mm)
Table:
Size ........................................................ 20Óx 27Ó(508 x 686 mm)
Size with extension wings .................... 40Óx 27Ó(1016 x 686 mm)
Height ..................................................................... 351⁄2Ó(902 mm)
T-slotted miter gage grooves ....................... 3⁄8Óx 3⁄4Ó(10 x 19 mm)
Overall Dimensions:
Length:
Model 36-630 ..................................................... 44Ó(1118 mm)
Model 36-640 ..................................................... 42Ó(1067 mm)
Width:
Model 36-630 ..................................................... 48Ó(1219 mm)
Model 36-640 ..................................................... 59Ó(1499 mm)
Height:
Model 36-630 ..................................................... 40Ó(1016 mm)
Model 36-640 .................................................. 401Ú2Ó(1029 mm)
Weight:
Model 36-630 ..................................................... 188 lbs. (85 kg)
Model 36-640 ..................................................... 202 lbs. (92 kg)
For accessories, see page 27
®

9
For accessories, see page 27
10” Table Saw
The home shop saw
that combines power
with precision
T-square®accuracy.
•Powerful 15 amp. motor provides
5500 rpm blade speed.
•Full 221⁄4Óx 383⁄8Ótable with
extension wings provides ample
work support for ripping large
panels.
•Maximum 31⁄8Ódepth of cut at
90°, 21⁄8Óat 45° blade tilt. Rips to
the center of a 4Õpanel.
•T-Square®Fence System for
precision accuracy.
•See-thru blade guard with
anti-kickback fingers.
•Miter gage with 45° R&L and 90°
stops for accurate angle cutting.
•T-slot miter gage grooves hold
miter gage beyond table.
Model 36-600 10ÓTable Saw. Includes
basic machine with 15 amp., 115V, sin-
gle phase motor, stand, miter gage, T-
Square rip fence, table insert,
see-thru blade guard with splitter
and anti-kickback fingers,
10Ócarbide-tipped saw blade,
wrench and instruction manual.
Model 36-600
10ÓTable Saw
Full 221⁄4Óx 383⁄8Ótable with
extension wings and T-slot
grooves provides ample work
support for ripping large panels.
Saw can be converted for
moulding operations with
accessory cutterhead and
table insert.
Cut dados in any width up to
13⁄16Ósimply by mounting
accessory dado and table
insert.
Miter gage has positive stops
at 45° and 90° for accurate
angle cutting. Compound
angles can be achieved by tilt-
ing blade.
Motor ........................................................... 15 amp., 115V, 60 Hz.
Blade:
Diameter of Arbor ......................................................... 5⁄8Ó(16 mm)
Speed ............................................................................... 5500 rpm
Diameter of Blade ...................................................... 10Ó(254 mm)
Capacity:
Max. depth of cut at 90° ............................................. 31⁄8Ó(79 mm)
Max. depth of cut at 45° ............................................. 21⁄8Ó(54 mm)
Table distance in front of blade at
1Ódepth of cut ...................................................... 113⁄4Ó(298 mm)
Max. width of dado ..................................................... 13⁄16Ó(21 mm)
Max. rip to right of blade ............................................ 27Ó(686 mm)
Table:
Size .................................................. 221⁄4Óx 203⁄8Ó(565 x 518 mm)
Size with both extension wings ................................. 221⁄4Óx 383⁄8Ó
(565 x 975 mm)
Height on stand ...................................................... 347⁄8Ó(886 mm)
Miter gage groove ........................................ 3⁄8Óx 3⁄4Ó(10 x 19 mm)
Overall Dimensions:
Height ...................................................................... 40Ó(1016 mm)
Width ....................................................................... 51Ó(1295 mm)
Depth ...................................................................... 351⁄2Ó(902 mm)
Weight .................................................................... 145 Ibs. (66 kg)
SPECIFICATIONS
®

10
For accessories, see page 29
Sidekick®81⁄4” Builder’s Saw®
SPECIFICATIONS
The Builder’s Saw that’s
got it all.
•Cuts 21⁄4Óat 90°; 15⁄8Óat 45° blade
tilt—enough capacity to cut dimen-
sional 2 x 4 lumber.
•Diecast aluminum table, with inte-
gral outfeed work support and T-slot
miter gage grooves, measures a full
26Óx 20Ó.
•Miter gage with adjustable positive
stops at 90° and 45° R&L for accu-
rate straight and angle cutting.
•Self-aligning rip fence with single
control handle and easy-to-read
English/Metric rip scale.
•Carbide-tipped 81⁄4Ódia. x 18 ATB
saw blade included as standard
equipment.
•Built-in holders and compartments
for miter gage, cord, rip fence,
blade guard, extra blade and
wrench set storage.
Model 36-275 Sidekick®81⁄4ÓBuilder’s
Saw®.Includes basic machine with
15 amp., 120V, 60 Hz. motor; rip fence,
miter gage, see-through blade guard with
splitter and anti-kickback fingers, carbide-
tipped 81⁄4Ódia. x 18 ATB saw blade, table
insert, wrenches and instruction manual. Model 36-275
Sidekick®81⁄4ÓBuilder’s
Saw®
Integral outfeed work sup-
port handles large panels and
long stock; slides in, out of the
way, when not in use.
Built-in holders and compart-
ments for out-of-the-way miter
gage, rip fence, blade guard, extra
blade and wrench set storage;
easier accessibility when needed.
Convenient carrying handle
and cord holder bracket for
safe and easy transport from
job to job.
T-slot grooves hold miter
gage securely beyond front of
table, preventing it from falling
during wide cut-off operations.
Motor ..................................... 15 amp., 120V, single phase, 60 Hz.
Blade:
Diameter ................................................................... 81⁄4Ó(210 mm)
Arbor ............................................................................. 5⁄8Ó(16 mm)
Speed ............................................................................... 4500 rpm
Capacity:
Maximum depth of cut at 90° ..................................... 21⁄4Ó(57 mm)
Maximum depth of cut at 45° ..................................... 15⁄8Ó(41 mm)
Maximum rip to right of blade .................................... 12Ó(305 mm)
Table in front of blade at 1Ódepth of cut ..................... 8Ó(203 mm)
Maximum width of dado ............................................. 13⁄16Ó(21 mm)
Table:
Size ........................................................ 26Óx 20Ó(660 x 508 mm)
with accessory extension wing ............ 32Óx 20Ó(813 x 508 mm)
Height ..................................................................... 121⁄8Ó(308 mm)
T-slot ............................................................ 3⁄8Óx 3⁄4Ó(10 x 19 mm)
Overall Dimensions:
Height ..................................................................... 157⁄8Ó(403 mm)
Width ......................................................................... 26Ó(660 mm)
Depth ...................................................................... 253⁄8Ó(645 mm)
Weight ................................................................... 481⁄2Ibs. (22 kg)
®

11
10” Bench Saw
Big saw capacity in an
economical package.
•Lightweight for portability; goes where
you go, when you need it.
•Ample capacity to cut 3Óat 90°;
21⁄2Óat 45°.
•Powered by a heavy duty 13 amp.,
115V motor for dependability.
•Rip fence locks front and rear to
maintain accuracy at the cut.
•Blade tilting and height control knobs are
up-front for convenience.
•Self-aligning rip fence aligns and locks itself
parallel to blade with single control lever.
•Big 171⁄4Óx 26Ótable provides ample
support for large ripping operations.
•Removable on-off switch to prevent
unauthorized use.
•Convenient holder for out-of-the-way
miter gage storage.
•See-thru blade guard with integral
splitter and anti-kickback fingers for oper-
ator safety.
Model 36-540Type 2 10ÓBench Saw. Includes
basic machine with 13 amp., 115V, 60 Hz. motor;
rip fence, miter gage, see-thru blade guard with
splitter and anti-kickback fingers, 10Ócarbide-
tipped saw blade, standard table insert, blade
wrenches and instruction manual.
Model 36-540
10ÓBench Saw
Cuts stock 3Óthick at 90°, offers full 21⁄2Ó
cutting capacity at 45° blade tilt. Model 36-545 10ÓBench Saw with Stand. Same as above, but with
steel stand.
T-slot table groove prevents miter gage
from falling during wide cut-off operations.
For accessories, see page 29
®
SPECIFICATIONS
Motor .......................................13 amp., 115V, single phase, 60 Hz.
Blade:
Diameter ......................................................................10Ó(254 mm)
Arbor ............................................................................. 5⁄8Ó(16 mm)
Speed .................................................................................4700 rpm
Capacity:
Max. depth of cut at 90° .................................................3Ó(76 mm)
Max. depth of cut at 45° ...............................................21⁄2Ó(64 mm)
Max. rip to right of blade.............................................97⁄8Ó(252 mm)
Max. width of cut-off at 1Ódepth of cut
with T-slot miter gage................................................10Ó(254 mm)
Max. width of dado .........................................................1⁄2Ó(13 mm)
Table:
Size.......................................................171⁄4Óx 26Ó(438 x 660 mm)
T-slot...............................................................3⁄16Óx 5⁄8Ó(5 x 16 mm)
Overall Dimensions:
Model 36-540...........15ÓHx 26ÓWx 24ÓD(381 x 660 x 610 mm)
Model 36-545...........39ÓHx 26ÓWx 24ÓD(991 x 660 x 610 mm)
Weight:
Model 36-540........................................................ 40 Ibs. (18 kg)
Model 36-545........................................................ 51 Ibs. (23 kg)

12
Sidekick®Saw Stand
SPECIFICATIONS
Adds sturdy support and
complete job-site mobility.
•Holds Delta 81⁄4Óand 10ÓBench
Saws as well as most other
competitive models.
•Storage slots hold rip fence out
of the way when not in use.
•Two-year limited warranty.
Model 50-170 Sidekick®Saw Stand.
Includes stand, folding legs, fence guide
rail, 13Ódiameter wheels, hardware and
instruction manual.
Overall Dimensions:
Length ....................................................................... 73Ó(1854 mm)
Width ........................................................................... 27Ó(686 mm)
Height ...................................................................... 351Ú2Ó(902 mm)
Opening Size: ..................................... 221Ú4Óx 23Ó(565 x 584 mm)
Weight: (without saw) .............................................. 65 lbs. (29 kg)
Rip Capacity (to right of blade):
With Model 36-275 Sidekick 81Ú4ÓBuilder’s Saw ........ 27Ó(686 mm)
Note: Rip capacity may vary according to your bench saw model.
ACCESSORIES
No. 50-171 Rear Outfeed Work Support. Provides an additional
12Óof stock support.
Precision fence and guide rail
included for ripping operations to
the right and left of saw blade.
Folds flat for storing or
transporting from job to job. The Sidekick Saw Stand helps you move your bench saw quickly
and easily.
Large 13Ódiameter wheels
for quick, easy movement—
even up steps.
Model 50-170 Sidekick®Saw Stand.
Sidekick 81Ú4ÓBuilder’s Saw not included.

13
Deluxe Sawbuck®Frame and Trim Saw
SPECIFICATIONS
Try it once and you won’t be
able to get along without it.
•Perfect for crosscuts up to 16Óat 90°,
12Óat 45° on hard and soft woods, vinyl
and aluminum siding.
•Saw head miters and tilts for angle and
compound cutting operations.
•Large 2913⁄16Ómiter scale has 1⁄4Óbetween
degree markings for easy reading with
positive stops at 0°, 221⁄2° and 45° R and L
including a special 31.62° position for cut-
ting crown mouldings.
•Exclusive SMC construction eliminates
table rust and corrosion; steel guide bars
are Nitrotec™ treated for rust-free,
smooth gliding operation.
•Powerful 15 amp. gear driven motor
features an electric brake that
automatically stops blade in seconds
after the switch trigger is released.
Model 33-055 Deluxe Sawbuck®
Frame and Trim Saw. Includes
basic machine with 15 amp., 115V,
25-60 Hz., AC motor with electric
automatic brake, 6 foot cord, leg
set, blade guard with retractable
leaf guard, 8Ódiameter crosscut
saw blade, blade wrench and
instruction manual.
Table is made of an entirely new reinforced polyester resin
compound that prevents warping, springing and rusting. Cutting
head is supported at both ends by corrosion-proof steel guide rails.
Set-up is simple and fast.
Table rotates with track arm for
mitering. Motor tilts around
common table-level pivot point
for beveling.
Deluxe Sawbuck accommo-
dates accessory 6Ódiameter
stackable type dado head to
cut grooves up to 13⁄16Ówide.
Motor ............................................... 15 amp., 115V, 25-60 Hz., AC
Brake .................................................................. Electric, automatic
Blade:
Diameter ...................................................................... 8Ó(203 mm)
Arbor ............................................................................. 5⁄8Ó(16 mm)
Speed ............................................................................... 5500 rpm
Capacity:
Cut-Off at 90° ............................................................ 16Ó(406 mm)
Cut-Off at 45° ............................................................ 12Ó(305 mm)
Depth of cut at 90° ..................................................... 23⁄4Ó(70 mm)
Depth of cut at 45° ..................................................... 13⁄4Ó(44 mm)
Dado ....................................................... 13⁄16Ó(21 mm) Width using
6ÓDiameter Stackable Type
Cutting Head Height Adj. ................................ 11⁄4Ó(32 mm) max.
Table:
Diameter of cutting surface .................................... 281⁄2Ó(724 mm)
Extension on both sides of table ............................ 113⁄4Ó(298 mm)
Overall length .......................................................... 52Ó(1321 mm)
Height ..................................................................... 351⁄4Ó(895 mm)
Fences .............................................. 23Ó(584 mm) R & L of Blade
Positive Stops:
Miter ............................................... 0°, 221⁄2°, 31.62° & 45° R & L
Overall Dimensions ........................................... 37Óx 671⁄2Óx 47Ó
(940 x 1715 x 1194 mm)
Weight ...................................................................... 96 Ibs. (44 kg)
For accessories, see page 29
Model 33-055
Deluxe Sawbuck®
Frame and Trim Saw
Special 31.62° miter stop and
33.85° bevel setting facilitates
compound cutting standard
52°/38° crown moulding.

Sidekick®10” Sliding Compound Miter Saw
SPECIFICATIONS
Packed with features that
place it on the cutting edge.
•Cuts 111⁄2Óat 90° and 8Óat 45° miter; 35⁄8Ó
depth of cut at 90° and 2Óat 45° bevel.
•Powerful 15 amp. motor provides plenty of
cutting power.
•Built-in arbor lock for easy blade changes.
•Standard-equipped stand features built-in
left and right table extensions, with stock
stops and wrench storage, that total 59" in
length.
•Carbide-tipped 10Ódia. x 40 ATB saw
blade included as standard equipment.
•Electric blade brake automatically stops
blade in seconds.
•Dust bag collects fine dust and chips for
cleaner work environment.
•Extra long 10Õcord for increased on-the-job
mobility.
Model 36-250 Sidekick®10ÓSliding Compound
Miter Saw. Includes basic machine with 15 amp.,
120V, 60 Hz. motor; 10Õ3-conductor cord with
ground-type plug, electric blade brake, carbide-
tipped 10Ódia. x 40 ATB saw blade, base mount-
ing feet, stand with table extensions and stock
stops, work clamp, retractable saw blade guard,
dust bag, wrench and instruction manual.
Model 36-250 Sidekick®
10ÓSliding Compound
Miter Saw
Quick-action miter lock elimi-
nates use of traditional screw
locks for faster miter setting.
One-piece die-cast aluminum
table has dual rod, linear ball
bearing guide system for preci-
sion cutting.
Work clamp secures stock,
preventing material shifting for
increased cutting accuracy and
operator safety.
Patented stand folds quickly
for carrying saw easily;
removes for bench mounting.
Motor ........................................................... 15 amp., 120V, 60 Hz.
Blade:
Diameter .................................................................... 10Ó(254 mm)
Arbor ............................................................................. 5⁄8Ó(16 mm)
Speed ............................................................................... 5000 rpm
Capacity:
Cut-off at 90° ......................................................... 111⁄2Ó(305 mm)
Cut-off at 45° miter ...................................................... 8Ó(203 mm)
Depth of cut at 90° ..................................................... 35⁄8Ó(92 mm)
Depth of cut at 45° bevel ............................................... 2Ó(51 mm)
Table:
Diameter of cutting surface ....................................... 19Ó(483 mm)
Fence:
Length ........................................................................ 19Ó(483 mm)
Fence length with extensions .................................. 59Ó(1499 mm)
Positive miter stops .......................... 0°, 221⁄2° 31.62° & 45°, R&L
Bevel stops ................................................................. 0° and 45° L
Overall Dimensions with Stand and Table Extensions:
Height ................................................................... 541⁄2Ó(1384 mm)
Width ....................................................................... 59Ó(1499 mm)
Depth ...................................................................... 251⁄2Ó(648 mm)
Without Stand:
Height ..................................................................... 253⁄4Ó(654 mm)
Width ...................................................................... 281⁄2Ó(724 mm)
Depth ......................................................................... 25Ó(635 mm)
Weight with Stand ................................................... 56 lbs. (25 kg)
For accessories, see page 29
®
14

Built-in head lock keeps saw
head in place for transporting
safely from job to job.
15
Sidekick®10” Sliding Compound Miter Saw
SPECIFICATIONS
A powerful, portable compound
slide saw built for today’s job sites.
•Powerful 15 amp. motor handles the toughest
cutting jobs.
•Die-cast aluminum table with large, easy-to-read
English/Metric miter scale.
•Dual rod, linear ball-bearing guide system provides
precision cutting performance.
•Secondary left and right fence supports to handle
thick workpieces or long stock.
•Patented base mounts on job site 2 x 4’s for
fast, easy on-site setup.
•Quick-action miter lock is designed for faster
miter settings.
•Handy work clamp prevents stock from shifting to
maintain cutting accuracy.
Model 36-240 Delta Sidekick 10˝ Sliding
Compound Miter Saw. Includes basic machine
with 15 amp., 120V motor, 10-ft.
3-conductor cord with grounding plug,
electric blade brake, carbide-tipped
10˝ dia. saw blade, work clamp,
retractable blade guard, dust bag,
wrench and instruction manual.
Patented base fits over 2 x 4’s
for setting up shop anywhere
around the job site.
Designed for large cutting
capacity, this saw cuts stock up
to 35⁄8˝ deep and up to 2˝ deep
when positioned at a 45°
bevel.
Large, easy-grip handle is
positioned horizontally for
better operating control and to
reduce operator fatigue.
Motor ........................................................... 15 amp., 120V, 60 Hz.
Blade:
Diameter .................................................................... 10Ó(254 mm)
Arbor ............................................................................. 5⁄8Ó(16 mm)
Speed ............................................................................... 5000 rpm
Capacity:
Cut-Off at 90° ......................................................... 111⁄2Ó(292 mm)
Cut-Off at 45° Miter ..................................................... 8Ó(203 mm)
Depth of Cut at 90° .................................................... 35⁄8Ó(92 mm)
Max. Depth of Cut at 45° Bevel...................................... 2Ó(51 mm)
Table:
Diameter of Cutting Surface ...................................... 19Ó(483 mm)
Fence:
Length ........................................................................ 19Ó(483 mm)
Fence Length with Supports ...................................... 26Ó(660 mm)
Positive Miter Stops ....................... 0°, 221⁄2°, 31.62° & 45° R & L
Bevel Stops ................................................................ 0° and 45° L
Overall Dimensions:
Length ........................................................................ 26Ó(660 mm)
Width ......................................................................... 27Ó(686 mm)
Height ........................................................................ 19Ó(483 mm)
Weight ...................................................................... 51 Ibs. (23 kg)
®
Model 36-240 Sidekick®
10ÓSliding Compound
Miter Saw
For accessories, see page 29

Now with improved extra-tall fence,
increased work support and more!
•Powerful 15 amp., 3500 rpm motor for maximum
cutting power.
•Large bevel scale for quick, easy tilt settings with
adjustable positive stops at 0° and 45° L.
•Quick-action miter lock for faster miter settings.
•High-quality 40T carbide-tipped blade included
as standard equipment.
•Patented base designed for either bench or
job site 2 x 4 sawhorse mounting.
•Electric blade brake automatically stops blade
in seconds.
•Work clamp secures stock, prevents material
shifting for increased cutting accuracy and
operator safety.
•Built-in arbor lock for easy, single wrench blade
changes.
•Dust bag collects fine dust particles
and wood chips.
•See-through blade guard covers blade at all times;
automatically retracts as cut is being made.
Model 36-235 Sidekick®12ÓCompound Miter Saw.
Includes basic machine with 15 amp., 120V, 60 Hz. motor; 9Õ
cord with grounding type plug, electric blade brake, 12Ódiame-
ter, 40T carbide-tipped saw blade, retractable blade guard, work
clamp, dust bag, wrenches and instruction manual.
16
Sliding fence adjusts for increased work support and is extra tall for handling large workpieces,
or cutting crown moulding on edge instead of flat on the table. Large, easy-grip handle is positioned horizontally to
reduce operator fatigue and
provide better control during
operation.
For accessories, see page 29
Sidekick®12” Compound Miter Saw
SPECIFICATIONS
Motor ........................................................... 15 amp., 120V, 60 Hz.
Blade:
Diameter .................................................................... 12Ó(305 mm)
Arbor................................................................................1Ó(25 mm)
Speed .................................................................................3500 rpm
Capacity:
Crosscut......................................................8Óx 21⁄2Ó(203 x 64 mm)
7Óx 31⁄2Ó(178 x 89 mm)
Miter at 45° R&L .................................... 53⁄4Óx 21⁄2Ó(146 x 64 mm)
Bevel at 45° L 61⁄2Óx 21⁄2Ó(165 x 64 mm)
8Óx 13⁄8Ó(203 x 35 mm)
Compound 45° x 45° ............................. 51⁄4Óx 11⁄2Ó(133 x 38 mm)
45⁄8Óx 21⁄4Ó(117 x 57 mm)
Fence Size:
Right Side .......................................... 25⁄8Ó x 101⁄8Ó(67 x 257 mm)
Left Side ............................................... 5Ó x 163⁄8Ó(127 x 416 mm)
Left Side (w/fence extended) ................ 5Ó x 235⁄8Ó(127 x 600 mm)
Table:
Diameter ................................................................ 137⁄8Ó(352 mm)
Sides .......................................................................... 33⁄4Ó(95 mm)
Miter Stops ..................................... 0°, 15°, 22.5°, 31.62°, 45° R&L
Bevel Stops .................................................................. 0° and 45° L
Overall Dimensions:
Height ...................................................................... 223⁄4Ó578 mm)
Width (w/ fence extended) ........................................ 35Ó(889 mm)
Depth ......................................................................... 36Ó(914 mm)
Weight ...................................................................... 50 lbs. (23 kg)
Model 36-235 Sidekick®
12ÓCompound Miter Saw
®

Sidekick®10” Compound Miter Saw
SPECIFICATIONS
From crosscuts to
compounds—this one’s got
all the angles covered.
•Powerful 15 amp., motor provides plenty of
power for tough cutting jobs.
•Electric blade brake automatically stops saw
blade in seconds.
•Bevel scale for quick, easy blade tilt settings
with adjustable positive stops at 0° and 45° L.
•Built-in arbor lock for easy, single
wrench blade changes.
•Work clamp to securely hold stock
for more accurate cutting.
•Convenient lock handle vertically
clamps the rotating table at the
selected miter setting; lessening
distortion or variances in miter settings
common to table edge locking systems.
•Lubricated-for-life ball bearings at vital wear
points to assure trouble-free performance with
less maintenance.
•High-quality steel 10Ódiameter, 40T carbide-
tipped blade included as standard equipment.
Model 36-210 Sidekick®10ÓCompound Miter Box.
Includes basic machine with 15 amp., 120V, 60Hz.
motor; 5Õ3-conductor cord with grounding type plug,
electric blade brake, 10Ódiameter carbide-tipped saw
blade, retractable blade guard, dust bag, work clamp,
wrench and instruction manual.
Aggressive 15 amp. motor
develops plenty of power to
crosscut a nominal 2x6 or 4x4
at 90°; miter 2x4 flat or on
edge at 45° R&L.
Patented trigger-controlled
miter indexing mechanism
facilitates quick, easy and
accurate selection of 0°, 221⁄2°
and 45° R & L miter settings.
Multi-position handle is verti-
cally adjustable for operator
preference, comfort and conve-
nience. Provides better control;
lessens operator fatigue.
Versatile tilting blade allows
you to bevel cut a nominal
2 x 6 at 45°, compound angle
cut a 2x4 at 45° miter and 45°
bevel cutting position.
Motor ........................................................... 15 amp., 120V, 60 Hz.
Blade:
Diameter .................................................................... 10Ó(254 mm)
Arbor ............................................................................. 5⁄8Ó(16 mm)
Speed ............................................................................... 5000 rpm
Capacity:
Crosscut ................................................ 55⁄8Óx 21⁄2Ó(143 x 64 mm)
31⁄2Óx 31⁄2Ó(89 x 89 mm)
Miter at 45° R & L ..................................... 4Óx 21⁄2Ó(102 x 64 mm)
31⁄2Óx 21⁄2Ó(89 x 64 mm)
Bevel at 45° L ........................................ 55⁄8Óx 15⁄8Ó(143 x 41 mm)
Compound 45° x 45° ................................ 4Óx 15⁄8Ó(102 x 41 mm)
Fence Size R & L ................................. 21⁄2Óx 81⁄2Ó(64 x 216 mm)
Table:
Diameter ................................................................. 103⁄8Ó(264 mm)
Sides ........................................................................... 33⁄4Ó(95 mm)
Miter Stops ................................................ 0°, 221⁄2° and 45° R & L
Bevel Stops .................................................................. 0° and 45° L
Overall Dimensions:
Height ........................................................................ 20Ó(508 mm)
Width ...................................................................... 181⁄4Ó(464 mm)
Depth ......................................................................... 28Ó(711 mm)
Weight ...................................................................... 30 Ibs. (14 kg)
®
Model 36-210 Sidekick®
10ÓCompound Miter Box
17
For accessories, see page 29

18
Sidekick®10” Motorized Miter Box
A true cutting friend that will help
cut those big jobs down to size.
•Powerful 12 amp. motor provides plenty of power
for tough cutting jobs.
•Electric blade brake automatically stops saw
blade in seconds.
•Lightweight aluminum alloy construction—weighs
only 30 pounds. Easily carried from job to job.
•Extra-wide one-piece fence for maxi-
mum support of extra-wide materials.
•Efficient dust collection system with
strategically positioned baffle and
dust spout, collects up to 80% of all
fine dust particles and wood chips.
•Patented base design for either bench
or job site 2x4 sawhorse mounting.
•Built-in arbor lock for easy, single
wrench blade changes.
•See-through blade guard covers blade at all
times, automatically retracts as cut is being
made.
Model 36-090 Sidekick®10ÓMotorized Miter Box.
Includes basic machine with 12 amp., 120V, 25-60 Hz.
motor; 6 foot 3-conductor cord with grounding type plug,
electric blade brake, 10Ódiameter carbide-tipped saw
blade, retractable blade guard, dust bag, wrench and
instruction manual.
Multi-position D-handle con-
trol. Vertically adjustable, for
operator preference, comfort
and convenience. Provides bet-
ter control for easier, more effi-
cient cutting with less operator
fatigue regardless of working
height.
Exclusive poly-v belt drive
system. Unique rear-mounted
motor delivers plenty of power
and speed to a separate, inde-
pendent saw arbor through an
extra-wide poly-v belt drive.
Runs quieter; eliminates costly
repairs of gear driven systems.
Big cutting capacity.
Crosscuts a nominal 2x6 or
4x4; miters a 2x4, flat or on
edge, at 45°—all in a single
pass, using a 10" diameter
blade and without having to
adjust the fence.
Trigger-controlled miter
indexing mechanism.
Facilitates quick, easy and
accurate selection of 0°, 221⁄2°
and 45° R&L settings. Easy-to-
read scale for in-between
angles is accurate to 1⁄2of a
degree.
Motor ...................................................... 12 amp., 120V, 25-60 Hz.
Blade:
Diameter .................................................................... 10Ó(254 mm)
Arbor ............................................................................. 5⁄8Ó(16 mm)
Speed ............................................................................... 6000 rpm
Capacity:
Crosscut Max.WxH ............................... 51⁄2Óx 21⁄2Ó(140 x 64 mm)
Max. HxW ................................................ 31⁄2Óx 31⁄2Ó(89 x 89 mm)
Miter at 45° R&L Max.WxH .................... 37⁄8Óx 21⁄2Ó(98 x 64 mm)
Max HxW ................................................ 31⁄2Óx 21⁄2Ó(89 x 64 mm)
Miter at 221⁄2° R&L Max. WxH .................. 5Óx 21⁄2Ó(127 x 64 mm)
Max HxW ................................................. 31⁄2Óx 31⁄4Ó(89 x 83 mm)
Fence size R&L ................................. 21⁄2Óx 85⁄8Ó(64 x 219 mm)
Table:
Diameter ................................................................ 105⁄16Ó(262 mm)
Sides .......................................................................... 33⁄4Ó(95 mm)
Miter Stops ..................................................... 0°, 221⁄2° & 45° R&L
Overall Dimensions:
Height ........................................................................ 24Ó(610 mm)
Width ......................................................................... 18Ó(437 mm)
Depth ......................................................................... 20Ó(508 mm)
Weight ...................................................................... 30 Ibs. (14 kg)
SPECIFICATIONS
For accessories, see page 29
®
Model 36-090 Sidekick®
10ÓMotorized Miter Box

For accessories, see page 29
10” Compound Miter Saw
Efficiently handles bevel and
compound angle cutting jobs in
addition to big capacity miter
and square cuts.
•Double insulated construction for operator
safety.
•D-handle design with trigger switch for posi-
tive control; lock-out button to prevent acci-
dental starts.
•Electric brake automatically stops blade in
seconds.
•Built-in arbor lock for easy single wrench
blade changes.
•Automatic retracting see-through blade guard.
•Dust bag to collect fine dust particles and
wood chips.
•Replaceable cut-through table insert for
optimum chipbreaking.
Model 36-220 10ÓCompound Miter Saw. Includes
basic machine with 15 amp., 120V, 60 Hz. motor;
cord with 2-prong plug; electric blade brake,
10Ódiameter saw blade, retractable
blade guard, dust bag, work supports,
clamp and stock stop, wrench and
instruction manual.
Aggressive 15 amp. motor
develops plenty of power to
crosscut standard 2 x 6 or
4 x 4 stock at 90°; miter a
2 x 4 at 45°.
Extra-wide fence for extra
support with a work clamp to
securely hold the workpiece,
assures accurate cutting; sim-
plifies compound angle cutting
crown moulding.
Work supports for cutting
extra-long material, with a
stock stop to facilitate repetitive
cut-off work are included as
standard equipment.
Bevel cuts at full 13⁄4Óx 53⁄4Ó
at 45° blade tilt compound
angle cuts 13⁄4Óx 41⁄8Óat its
maximum 45° miter and bevel
cutting position.
Motor ........................................................... 15 amp., 120V, 60 Hz.
Blade:
Diameter ................................................................. 10Ó(254.0 mm)
Arbor .......................................................................... 5⁄8Ó(15.8 mm)
Speed ............................................................................... 4900 rpm
Capacity with Fence in Front Position:
Crosscut ................................................ 23⁄4Óx 51⁄8Ó(70 x 130 mm)
31⁄2Óx 4Ó(89 x 102 mm)
Miter 45° R&L .......................................... 23⁄4Óx 31⁄2Ó(70 x 89 mm)
Bevel 45° L ............................................ 13⁄4Óx 51⁄8Ó(44 x 130 mm)
Compound 45° x 45° ............................... 13⁄4Óx 31⁄2Ó(44 x 89 mm)
Capacity with Fence in Rear Position:
Crosscut ................................................. 23⁄4Óx 53⁄4Ó(70 x 146 mm)
31⁄2Óx 45⁄8Ó(89 x 117 mm)
Miter 45° R&L ........................................ 23⁄4Óx 41⁄8Ó(70 x 105 mm)
Bevel 45° L ............................................ 13⁄4Óx 53⁄4Ó(44 x 146 mm)
Compound 45° x 45° ............................ 13⁄4Óx 41⁄8Ó(44 x 105 mm)
Fence Size:
Left ............................................................ 3Óx 71⁄2Ó(76 x 191 mm)
Right ......................................................... 21⁄2Óx 8Ó(64 x 203 mm)
Table:
Diameter ..................................................................101⁄2Ó(267 mm)
Sides ........................................................................... 33⁄4Ó(95 mm)
Bevel Positive Stops ................................................. 0° and 45° L
Miter Stops................................. 0°, 15°, 221⁄2°, 30° and 45° R & L
Overall Dimensions .................................... 201⁄2Óx 381⁄2Óx 201⁄2Ó
(521 x 978 x 521 mm)
Weight ...................................................................... 49 Ibs. (22 kg)
SPECIFICATIONS
Model 36-220
10ÓCompound Miter Saw
®
19

10” Compound Power Miter Saw
SPECIFICATIONS
High performance
without the high price.
•Electric blade brake automatically stops
blade in seconds.
•Lubricated-for-life ball bearings assure
trouble-free performance with less
maintenance.
•Powerful 13 amp. motor provides plenty
of power for tough cutting jobs.
•Easy-to-read bevel scale with adjustable
positive stops for quick tilt settings.
•Convenient miter indexing mechanism
for quick, easy miter settings.
•Large one-piece fence for maximum
support of extra-wide materials.
•Lightweight aluminum alloy construction,
weighs only 28 Ibs.
•Dust bag collects fine dust and woodchips.
Model 36-075 10˝ Compound Power Miter Saw.
Includes basic machine with 13 amp., 120V,
60 Hz. motor; 8´ cord with grounded plug,
electric blade brake, 10˝ diameter crosscut blade,
retractable blade guard, dust bag, blade wrench
and instruction manual.
Model 36-075
10ÓCompound Power Miter Saw
Motor ........................................................... 13 amp., 120V, 60 Hz.
Blade:
Diameter .................................................................... 10Ó(254 mm)
Arbor ............................................................................. 5⁄8Ó(16 mm)
Speed ............................................................................... 5200 rpm
Capacity:
90° Crosscut ..................................... 53⁄4ÓWx 23⁄8ÓH(146 x 60 mm)
33⁄8ÓWx 311⁄16ÓH(86 x 94 mm)
Miter 45° R&L ................................... 41⁄8ÓWx 23⁄8ÓH(105 x 60 mm)
25⁄8ÓWx 35⁄8ÓH(67 x 92 mm)
Bevel 45° L (90° miter) .................... 57⁄8ÓWx 19⁄16ÓH(149 x 40 mm)
35⁄8ÓWx 29⁄16ÓH(92 x 65 mm)
Compound 45° x 45° ....................... 41⁄8ÓWx 19⁄16ÓH(105 x 40 mm)
27⁄16ÓWx 27⁄8ÓH(62 x 73 mm)
Fence Size R&L ............................ 175⁄8ÓWx 21⁄2ÓH(448 x 63 mm)
Table:
Diameter ................................................................. 111⁄2Ó(279 mm)
Sides ...................................................................... 3Ó R&L (76 mm)
Miter Stops ................................................... 0°, 221⁄2° and 45° R&L
Miter Range ........................................................................ 47° L&R
Bevel Stops ......................................................... 0°, 45° Adjustable
Bevel Range ....................................................................... -3°/+48°
Overall Dimensions:
(L x W x H) .................. 32Óx 173⁄4Óx 201⁄2Ó(813 x 451 x 521 mm)
Weight ...................................................................... 28 Ibs. (13 kg)
For accessories, see page 29
20
®
Crosscuts a nominal 2 x 6 or 4 x 4 at 90°.
Miters a 2 x 4 flat or on edge at 45° R&L. Makes quick work out of cutting compound angles on crown moulding or
nominal 2 x 4’s.
Convenient miter indexing mechanism for
quick and easy miter settings

21
10” Power Miter Saw
SPECIFICATIONS
Power. Capacity. Portability.
Everything you could ask
for in a miter saw!
•Convenient miter indexing control with
positive stops at 0°, 221⁄2° and 45° R&L.
Easy-to-read scale for in-between
angles is accurate to 1⁄2°.
•Extra-wide one-piece fence for
maximum support of wide materials.
•See-through blade guard covers blade
at all times; automatically retracts as cut
is being made.
•Electric blade brake automatically stops
blade in seconds.
•Pre-drilled base holes for easy bench
mounting.
Model 36-070 10ÓPower Miter Saw. Includes
basic machine with 13 amp., 120V, 60 Hz.
motor; 6Õ3-conductor cord with ground-type
plug, electric blade brake, 10Ódia. saw blade,
retractable saw blade guard, dust bag, wrench-
es and instruction manual.
Model 36-070
10ÓPower Miter Saw
Motor ........................................................... 13 amp., 120V, 60 Hz.
Blade:
Diameter .................................................................... 10Ó(254 mm)
Arbor ............................................................................. 5⁄8Ó(16 mm)
Speed ............................................................................... 5200 rpm
Capacity:
Crosscut ................................................. 53⁄4Óx 21⁄4Ó(146 x 57 mm)
33⁄4Óx 33⁄4Ó(95 x 95 mm)
Miter at 45° R&L .................................... 41⁄8Óx 21⁄4Ó(105 x 57 mm)
31⁄2Óx 31⁄8Ó(89 x 79 mm)
Fence Size R&L ................................... 21⁄2Óx 77⁄8Ó(64 x 200 mm)
Table:
Diameter .................................................................... 11Ó(279 mm)
Sides ........................................................................... 31⁄4Ó(83 mm)
Miter stops ................................................... 0°, 221⁄2° and 45° R&L
Overall Dimensions:
Height ..................................................................... 201⁄4Ó(514 mm)
Width ...................................................................... 173⁄4Ó(451 mm)
Depth ........................................................................... 32Ó(81 mm)
Weight ...................................................................... 28 Ibs. (13 kg)
®
13 amp., 5200 rpm motor provides plenty
of power and speed for tough cutting jobs. Crosscuts a nominal 2 x 6 or 4 x 4 at 90°. Miters a 2 x 4 flat or on
edge in a single pass, at 45°.
Constructed of a lightweight aluminum
alloy—weighs only 28 Ibs. for easy carrying
from job to job.
For accessories, see page 29

22
81⁄4” Compound Miter Saw
The straightforward
answer to angle cutting.
•Full 9 amp. motor powers through
crosscuts up to 21⁄8Óx 51⁄8Óthick.
•Large 11Ódiameter table has positive
ball detents at 0°, 15°, 221⁄2°, 30° and
45° right and left. Bevel scale has
stops at 0° and 45° for quick setting of
common compound angles.
•Nominal 153⁄4Ib. weight makes it per-
fect for moving around the workshop
or the job site.
•Articulating blade guard continuously
adjusts to cover the blade as it's
raised and lowered.
•Built-in arbor lock for easy, single
wrench blade changes.
•Replaceable cut-through table insert
for optimum chipbreaking.
•Equipped with an electric brake that
automatically stops blade in seconds.
Model 36-040 81⁄4ÓCompound Miter Saw.
Includes basic machine with 9 amp.,
115V, 60 Hz., universal motor, 7Õcord with
2-prong plug; automatic electric blade brake,
81⁄4Ódiameter saw blade, retractable blade
guard, dust bag and instruction manual.
Compound angle and bevel
cutting is easy and accurate. Accurately cuts stock 2Ó
thick and a full 5Ówide. Positive detents on table
facilitate miter cutting.
Blade tilts 0° to 45° left for
bevel and compound angle
cutting.
Motor ...................................................... 9 amp., 115V, 60 Hz., AC
Blade:
Diameter ................................................................... 81⁄4Ó(210 mm)
Arbor ............................................................................. 5⁄8Ó(16 mm)
Speed ............................................................................... 5200 rpm
Capacity:
Crosscut ................................................. 21⁄8Óx 51⁄8Ó(54 x 130 mm)
Miter 45° R & L ........................................ 21⁄8Óx 31⁄2Ó(54 x 89 mm)
Bevel 45° L ............................................ 11⁄2Óx 51⁄8Ó(38 x 130 mm)
Compound 45° R & L w/45° ................... 11⁄2Óx 31⁄2Ó(38 x 89 mm)
Table:
Diameter of cutting surface ....................................... 11Ó(279 mm)
Extension on sides ........................................................ 2Ó(51 mm)
Bevel positive stops ..................................................... 0° and 45° L
Miter ball detent stops ... 0°, 15°, 221⁄2°, 30° and 45° Right and Left
Overall Dimensions ........................................ 141⁄2Óx 151⁄4Óx 16Ó
(368 x 387 x 406 mm)
Weight ..................................................................... 153⁄4Ibs. (7 kg)
Double insulated construction for operator safety.
Model 36-040
81⁄4ÓCompound Miter Saw
SPECIFICATIONS
®
For accessories, see page 29

23
’kickstand Portable Work Stand
Unique stock lift inhibitor for
safety. Prevents the cut-off
workpiece from lifting up, and
falling off the table, after the
cut, when working with
extra-long materials.
Stock stop is Included to
facilitate repetitive cut-off and
dimensional jobs.
Adjustable roller work sup-
ports help maintain correct
stock alignment; make handling
extra-long materials a one-man
operation.
Built-on cord holder bracket
for convenient, out-of-the-way
cord storage. Bracket arm
swivels for quick, easy cord
removal – no unwinding
necessary.
Overall Dimensions:
Width ..................................................................... 114Ó(2896 mm)
Depth ......................................................................... 21Ó(533 mm)
Height ...................................................................... 42Ó(1067 mm)
Weight ...................................................................... 63 Ibs. (29 kg)
Shown with Model 36-075
10ÓCompound Power Miter Saw.
SPECIFICATIONS
No. 50-175 ’kickstand Portable Work Stand.
Includes stand with fiberboard tool mounting
base, fold-up legs and adjustable roller work
supports; wheels; fence and table extension
with stock stop, stock lift inhibitor, cord holder
brackets and instruction manual.
Helps make good tools even better by increasing
their mobility and performance level.
•Designed to accommodate Delta Model 36-040, 36-
070, 36-075, 36-090, 36-210 and 36-220 miter saws
and compound miter saws. Can also be adapted to
hold other bench top tools.
•Fence and table extension provide additional work
support, lessening material shifting and tipping.
•Stock stop allows for repetitive cut-off and dimen-
sioning jobs.
•Adjustable roller work supports help maintain proper
stock alignment and make handling extra-long stock
a one-man job.
•Rugged 13˝ diameter wheels maneuver easily
around the job site even up and down steps.
•Portable work stand folds quickly
and easily for storing or rolling to
the next job.

14” Abrasive Cut-Off Saw
SPECIFICATIONS
For accessories, see page 29
24
The saw with the mettle
to handle your toughest
metal-cutting jobs.
•Fold-down cutting head with locking
chain and carrying handle for safe,
easy transport.
•Switch can be padlocked to
prevent unauthorized use.
•Extra-long 12-foot cord for
on-the-job mobility
•Heavy-duty helical gear drive plus ball
and needle bearing construction for
smooth, efficient transmission of power.
•Heavy-duty steel base with foot pads
for stable operation and less vibration.
•Full grip handle design for positive
operating control.
•Built-in arbor lock for easy single
wrench abrasive wheel changes.
•Sturdy metal wheel guard for
operator safety.
Model 20-140 14ÓAbrasive Cut-Off Saw.
Includes basic machine with 15 amp., 115V
motor, 12-foot cord and grounding-type plug,
work clamp, 14Óabrasive wheel, wheel guard,
wrench and instruction manual.
Motor .............................................................. 15 amp., 115V, 60 Hz.
Abrasive Wheel:
Diameter ....................................................................... 14Ó(356 mm)
Arbor Hole ........................................................................ 1Ó(25 mm)
Speed .................................................................................. 3900 rpm
Cutting Capacity at 90° (Using Vise):
Round ......................................................................... 43Ú4Ó(121 mm)
Rectangular ............................................. 21Ú2Óx 91Ú2Ó(64 x 241 mm)
Square ................................................... 41Ú4Óx 41Ú4Ó(108 x 108 mm)
Overall Dimensions:
Length .......................................................................... 22Ó(559 mm)
Width ............................................................................ 12Ó(305 mm)
Height ....................................................................... 251Ú2Ó(648 mm)
Weight ......................................................................... 38 lbs. (17 kg)
Powerful 15 amp. motor provides plenty of
power and speed to “gang cut” metal studs
and perform other tough metal-cutting jobs.
Work clamp secures workpiece for opera-
tor safety; swivels 45° during angle cutting
operations.
Large 14Ódiameter x 1Ú8Óabrasive wheel
cuts most types of ferrous materials; pro-
vides long-lasting performance.
No. 20-140
14ÓAbrasive Cut-Off Saw
®
