Delta VIVOTEK IP9191-LPC-v2 User manual

User’s Manual
License Plate Capture Camera
5/8MP • License Plate Capture • P-iris/i-CS lens • H.265 • WDR Pro II • Remote Back Focus
Smart Stream III • SNV II • 3DNR • Smart VCA
IP9181-LPC-v2 / IP9191-LPC-v2
Rev. 1.0

VIVOTEK
2 - User's Manual
Table of Contents
Overview ....................................................................................................................................................................3
Revision History ..................................................................................................................................................... 3
Read Before Use.................................................................................................................................................... 4
Package Contents .................................................................................................................................................. 4
Symbols and Statements in this Document............................................................................................................ 4
Physical Description ............................................................................................................................................... 5
Hardware Installation.............................................................................................................................................. 8
Software Installation ............................................................................................................................................. 15
Network Deployment ............................................................................................................................................ 18
Accessing the Network Camera ...........................................................................................................................23
Using Web Browsers............................................................................................................................................ 23
Using RTSP Players............................................................................................................................................. 26
Using 3GPP-compatible Mobile Devices.............................................................................................................. 27
Using VIVOTEK Recording Software ................................................................................................................... 28
Main Page................................................................................................................................................................29
Client Settings.........................................................................................................................................................34
Conguration...........................................................................................................................................................39
System > General settings ................................................................................................................................... 40
System > Homepage layout ................................................................................................................................ 43
System > Logs ..................................................................................................................................................... 46
System > Parameters .......................................................................................................................................... 48
System > Maintenance......................................................................................................................................... 49
Media > Image ................................................................................................................................................... 53
Media > Video ...................................................................................................................................................... 68
Media > Audio....................................................................................................................................................... 79
Media proles ....................................................................................................................................................... 81
Network > General settings.................................................................................................................................. 82
Network > Streaming protocols .......................................................................................................................... 89
Network > SNMP (Simple Network Management Protocol)................................................................................. 98
Network > FTP ..................................................................................................................................................... 99
Bonjour ............................................................................................................................................................... 100
Security > User accounts ................................................................................................................................... 101
Security > HTTPS (Hypertext Transfer Protocol over SSL) ..................................................................... 103
Security > Access List ...................................................................................................................................... 110
PTZ > PTZ settings ............................................................................................................................................ 116
PTZ..................................................................................................................................................................... 119
Mechanical PTZ Operation................................................................................................................................. 119
Event > Event settings........................................................................................................................................ 122
Applications > Motion detection.......................................................................................................................... 139
Applications > DI and DO ................................................................................................................................. 140
Applications > Tampering detection ................................................................................................................... 141
Applications > Audio detection ......................................................................................................................... 142
Applications > Shock detection ......................................................................................................................... 144
Applications > Package management - a.k.a., VADP (VIVOTEK Application Development Platform) ............. 145

VIVOTEK
User's Manual - 3
Recording > Recording settings ..............................................................................................................148
Storage > Storage management ..............................................................................................................153
Storage > Content management ..............................................................................................................156
Appendix .................................................................................................................................................... 159
URL Commands for the Network Camera................................................................................................ 159
Technology License Notice.......................................................................................................................423
Electromagnetic Compatibility (EMC).......................................................................................................424
Overview
VIVOTEK’s IP9181-LPC-v2 / IP9191-LPC-v2 is a professional H.265 Full HD box network
camera offering specialized solutions for License Plate Capture with a unique headlight
lter design for trafc monitoring. Featuring dedicated LPC rmware and a compatible lens,
the camera provides three different scene modes: LPC-Parking, LPC-Street, and LPC-
Highway to match different traffc applications in which cars move at different speeds. With
a suitable selection of external IR illuminators, the camera is ideal for 24/7 license plate
capture, producing high-detail polished images for reliable license plate recognition of cars
travelling up to speeds of 110mph (180km/h).
Equipped with a P-iris lens and a headlight lter design, the camera is capable of capturing
clear, high quality video with a resolution of 1920x1080 at a smooth 60 fps in any condition.
Further, by employing VIVOTEK’s WDR Pro II, 3DNR and SNV II technologies, no matter
whether in high contrast or in low light environments, the camera will ensure clear image
quality for license plate capture or traffc monitoring. Finally, VIVOTEK’s RBF (Remote Back
Focus) system for easy focus adjustments and value-added features like DIS and support
for i-CS lens ensure image stability and intelligent, precise focus, and in conjunction make
the camera the perfect LPR solution for any application, in any condition.
Revision History
■ Rev. 1.0: Initial release.

VIVOTEK
4 - User's Manual
Read Before Use
The use of surveillance devices may be prohibited by law in your country. The Network Camera
is not only a high-performance web-ready camera but can also be part of a exible surveillance
system. It is the user’s responsibility to ensure that the operation of such devices is legal before
installing this unit for its intended use.
It is important to first verify that all contents received are complete according to the Package
Contents listed below. Take note of the warnings in the Quick Installation Guide before the Network
Camera is installed; then carefully read and follow the instructions in the Installation chapter to
avoid damage due to faulty assembly and installation. This also ensures the product is used
properly as intended.
The Network Camera is a network device and its use should be straightforward for those who
have basic networking knowledge. It is designed for various applications including video sharing,
general security/surveillance, etc. The Configuration chapter suggests ways to best utilize the
Network Camera and ensure proper operations. For creative and professional developers, the URL
Commands of the Network Camera section serves as a helpful reference to customizing existing
homepages or integrating with the current web server.
Package Contents
■ IP9181-LPC-v2 / IP9191-LPC-v2
■ Lens module (separately purchased)
■ Screws
■ Camera stand, L wrench
■ Quick Installation Guide
Symbols and Statements in this Document
i
INFORMATION: provides important messages or advices that might help prevent
inconvenient or problem situations.
NOTE: Notices provide guidance or advices that are related to the functional integrity of
the machine.
Tips: Tips are useful information that helps enhance or facilitae an installation, function,
or process.
WARNING! or IMPORTANT!: These statements indicate situations that can be
dangerous or hazardous to the machine or you.
Electrical Hazard: This statement appears when high voltage electrical hazards might
occur to an operator.

VIVOTEK
User's Manual - 5
Physical Description
Front Panel
Light Sensor
Lens
Ethernet 10/100 RJ45 Socket
Recessed Reset Button
General I/O Terminal Block
Audio Out
Status LED
MicroSD Card Slot
Audio In
Rear Panel
Grounding screw
IMPORTANT:
If DC power is preferred, it should comply with: O/P: 12VDC, 2A min., L.P.S. per IEC
60950-1.
Si l'alimentation CC est préférable, elle devrait être conforme avec ce qui suit : Sortie : 12
VCC, 2 A min., alimentation limitée à conformité CEI 60950-1.
BNC connector
IMPORTANT:
Please contact VIVOTEK's certied dealers for power adapters.

VIVOTEK
6 - User's Manual
IMPORTANT:
1. The wire gauge for the required protective earth conductor is 18AWG (green and yellow).
2. Ensure to connect one end to the protective earth terminal and the other to earth.
NOTE:
Camera Hardware Preventative Maintenance:
1. Visual inspection of all major components including accessories, cabling and
connections where accessible for signs of deterioration or damage.
2. Check and clean cameras, lenses and housings inside and out as needed.
• Please do not scratch, damage, or leave ngerprints on the dome/front cover and/or
lens because this may decrease image quality.
• For general cleaning of dirty areas, it is suggested to use compressed air to remove
dust and/or other debris in order not to damage the on-board components.
• In order to clean oil stains, it is recommended to use a spray-type decomposing cleaner
(absolutely avoid reciprocating wipes on the surface). After the oil has decomposed,
spray it with water, dry with air, and/or absorb water with a cotton cloth or a soft cloth
(dab, please avoid wiping).
• Do not use harsh detergents, gasoline, benzene or acetone, etc. to clean as they may
deform or cause damage to the product. Also, excessive cleaning could damage the
surface.
3. Check images for correct field of view (pan, tilt and zoom focus) and adjust as
necessary.
4. Check and replace the Micro SD memory card as needed.
• Stop edge recording before removing the Micro SD memory card.
• Make sure that the Micro SD memory card is right side up and do not insert it with
force, otherwise it may be damaged.
• When it is raining or the humidity is high, insertion or ejection of the Micro SD memory
card is not recommended.
5. Disassembly of the dome/front cover carries the risk of internal dew condensation, so
please remember to replace the desiccant bags on the inside of the cameras before
reassembly.
6. Check that the camera view has not been blocked by obstacles and that you can see
the property perimeter clearly.
7. Make sure the interiors of cameras and accessories, like mounting kits and/or
enclosures, are clean and dry.
8. Make sure cameras are securely attached to the wall/ceiling/mounting kits.
IMPORTANT:
1. Please contact VIVOTEK's certied dealers for power adapters.
2. Installation and maintenance service should only be performed by qualied technicians.
3. If powered by a power adapter, the adapter should be properly grounded.

VIVOTEK
User's Manual - 7
IMPORTANT:
For some customers who already have their own web site or web control application, the
Network Camera/Video Server can be easily integrated through URL syntax. This section
specifies the external HTTP-based application programming interface. The HTTP-based
camera interface provides the functionality to request a single image, control camera
functions (PTZ, output relay etc.), and get and set internal parameter values. The image
and CGI-requests are handled by the built-in Web server.
• To send URL commands in the address bar of your web browser, please remember to
disable the Cross-Site Request Forgery (CSRF) protection in Conguration > Security
> Miscellaneous.
• For up-to-date documentation of URL commands, please go to VIVOTEK’s website,
register an account with a business mail address and submit for authorization for SDK
in Support > Downloads > SDK.
• For any further technical support, please contact our technical support department.

VIVOTEK
8 - User's Manual
Hardware Installation
2.Install the lens module to the camera.
3. Connect the iris control cable to the socket on the camera.
1.Jot down the camera's MAC address for later reference.
Network Camera
Model No: XXXXXX
MAC: 0002D1083236
Pat. 6,930,709
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
Made in Taiwan

VIVOTEK
User's Manual - 9
When choosing the lens for your camera, please notice the specications as below. The
screw mount (distance A-C) must be shorter than 5.2mm; in case that the bottom of screw
mount may hit the IR Cut Filter.
4. Install the camera stand to camera.
5. Connect an Ethernet cable to the camera.
A C

VIVOTEK
10 - User's Manual
6. Install a MicroSD card, and, if preferred, connect DI/DO wires to the terminal block. The
AC/DC pins can accept either 12V or 24V power input. AC24V has no polarity.
The DO pin can provide a 12V output, and the max. load is 50mA.
12345678910
64 GB
10
I
1
1 AC/DC- pw 12V or 24V
2 AC/DC+ pw
3 RS485+
4 RS485-
5 DI- (common GND for all DIs)
6 DI2+
7 DI1+
8 DO2-
9 DO1-
10 DO+ (12V)
Pin 1 is on the left.
Connect the ground wire to a grounded earth rod with a resistance smaller than 4Ω, thicker
than 18AWG, to a ground rod 1.5 meters into the ground.
The grounding wire is user-supplied.

VIVOTEK
User's Manual - 11
DI/DO Diagram
DI-
DO+
DI+
DO-
Switch
External Device
External DC power
Dry contact with external DC power source to supply a relay. Dry contact is the safest connecon
to protect devices.
NC
NO
Relay
Coupler
DC
DC 0V
DC 0V
External AC power
with Protected Eart
h
AC
PE
PE
DI-
DO+
DI+
DO-
Switch
External Device
External DC power
Wet contact with external DC power source to supply a relay.
NC
NO
Relay
DC
External AC power
with Protected Earth
AC
PE
PE
DC 0V
1. The DO+ pin provides 12V output voltage, and the max. load is 50mA.
2. The max. voltage for DO- pins is 30VDC (External power).
In order to control AC devices, the above diagram can be taken in consideration. The
diagram uses a relay to control the ON/OFF condition of the AC device.
3. An external relay can be triggered by using DO+ or by an external power source,
depending on the type of relay you use.
4. In case of using an individual relay (instead of using a relay module), for protection
against voltage or current spikes, a transient voltage suppression diode must be
connected in parallel with the inductive load.

VIVOTEK
12 - User's Manual
7. Please visit VIVOTEK’s website to Install the "Shepherd” software utility. The program
will search for VIVOTEK Video Receivers, Video Servers or Network Cameras on the
same LAN.
Double-click on the camera’s MAC address to open a web console to the camera.
Browser
LAN
Shepherd
DI-
DO+
DI+
DO-
Switch
External Device
Dry contact and using camera’s DO+ to supply a relay.
NC
NO
Relay
AC
External AC power
with Protected Eart
h
PE
PE

VIVOTEK
User's Manual - 13
9. With a live view on screen, enter Conguration > Image > Focus to adjust the image
zoom and focus. Click on the Auto focus button and let the camera nd an optimal
focus.
8. Remove the sticker on the light sensor.

VIVOTEK
14 - User's Manual
LED Denitions
Item LED status Description
LED De`nitions
1 Steady Red Powered and system booting, or network
failed
Red LED off Power off
Green LED off Network is disconnected
2Steady Red and Green LED blinks every 1
sec.
Connected to network
3Green LED blinks every 1 sec. and RED
LED blinks consecutively every 0.15 sec.
Upgrading rmware
4Green and RED blink every 0.15 sec, Green
and RED light on, then blink again.
Restoring defaults
5RED LED is on, Green LED blinks and RED
LED is constantly on.
Status after a reset (network connected)
Green and RED LEDs are constantly on. Status after a reset (network
disconnected)
You can purchase the AE-23E-V2/AE-24 enclosure for outdoor installations.
If you purchased a larger lens, make sure the light sensor is not blocked by the
lens.

VIVOTEK
User's Manual - 15
Software Installation
10. Install the Shepherd utility, which helps you locate and congure your Network Camera
in the local network. If your camera comes without the CD, go to VIVOTEK’s website,
and locate the utility in the Downloads > Software page.
10-1. Run the Shepherd utility.
10-2. The program will conduct an analysis of your network environment.

VIVOTEK
16 - User's Manual
0002D1730202
IB8360-W 192.168.4.151 00-02-D1-73-02-02
IP9165-LPC-v2
Network Camera
Model No: IP9165-LPC-v2
Made in Taiwan
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
MAC:0002D1730202
R o H S
10-3. The program will search for all VIVOTEK network devices on the same LAN.
10-4. After a brief search, the installer window will prompt. Click on the MAC and model
name that matches the one printed on the product label. You can then double-click on
the address to open a management session with the Network Camera.
Forceful Password Conguration
11. The first time you log in to the camera, the firmware will prompt for a password
conguration for security concerns.
11-1. Enter the combination of alphabetic and numeric characters to fulfill the password
strength. requirement. The default name for the camera administrator is “root”, and can
not be changed.

VIVOTEK
User's Manual - 17
Some, but not all special ASCII characters are supported: !, $, %, -, ., @, ^, _, and ~.
You can use them in the password combination.
11-2. Another prompt will request for the password you just congured. Enter the password
and then you can start congure your camera and see the live view.

VIVOTEK
18 - User's Manual
Hardware Reset
The reset button is used to reset the system or restore the factory default settings. Sometimes
resetting the system can return the camera to normal operation. If the system problems remain
after reset, restore the factory settings and install again.
Reset: Press the recessed reset button. Wait for the Network Camera to reboot.
Restore: Press and hold the reset button until the status LED rapidly blinks. Note that all settings
will be restored to factory default. Upon successful restore, the status LED will blink green and
red during normal operation.
SD/SDHC/SDXC Card Capacity
This network camera is compliant with SD/SDHC/SDXC 16GB / 8GB / 32GB / 64GB / , and up
to 512 / 1024GB and other preceding standard SD cards.
Reset Button
Network Deployment
General Connection (PoE)
When using a PoE-enabled switch
The Network Camera is PoE-compliant, allowing transmission of power and data via a sin-
gle Ethernet cable. Follow the below illustration to connect the Network Camera to a PoE-
enabled switch via Ethernet cable.
PoE Switch
802.3af

VIVOTEK
User's Manual - 19
Internet connection via a router
Before setting up the Network Camera over the Internet, make sure you have a router and
follow the steps below.
1. Connect your Network Camera behind a router, the Internet environment is illustrated below.
Regarding how to obtain your IP address, please refer to Software Installation on page 21 for
details.
IP address : 192.168.0.3
Subnet mask : 255.255.255.0
Default router : 192.168.0.1
IP address : 192.168.0.2
Subnet mask : 255.255.255.0
Default router : 192.168.0.1
LAN (Local Area Network)
Router IP address : 192.168.0.1
WAN (Wide Area Network )
Router IP address : from ISP
Cable or DSL Modem
POWER COLLISION
LINK
RECEIVE
PARTITION
12345
Internet
When using a non-PoE switch
Use a PoE power injector (optional) to connect between the Network Camera and a non-
PoE switch.
PoE Power Injector
(optional)
NOTE:
1. The camera is only to be connected to PoE networks without routing to outside plants.
2. For PoE connection, use only UL listed I.T.E. with PoE output.
1. La caméra ne doit être raccordée qu’à des réseaux PoE, sans routage vers des installations
extérieures.
2. Pour les raccordements PoE, utilisez uniquement un équipement de TI homologué UL, avec une sortie
PoE.
Non-PoE Switch

VIVOTEK
20 - User's Manual
Congure the router, virtual server or rewall, so that the router can forward any data com-
ing into a pre-congured port number to a network camera on the private network, and
allow data from the camera to be transmitted to the outside of the network over the same
path.
From Forward to
122.146.57.120:8000 192.168.2.10:80
122.146.57.120:8001 192.168.2.11:80
... ...
When properly congured, you can access a camera behind the router using the HTTP
request such as: http://122.146.57.120:8000
If you change the port numbers on the Network conguration page, please open the ports
accordingly on your router. For example, you can open a management session with your
router to congure access through the router to the camera within your local network.
Please consult your network administrator for router conguration if you have troubles with
the conguration.
2. In this case, if the Local Area Network (LAN) IP address of your Network Camera is
192.168.0.3, please forward the following ports for the Network Camera on the router.
■ HTTP port: default is 80
■ RTSP port: default is 554
■ RTP port for video: default is 5556
■ RTCP port for video: default is 5557
If you have changed the port numbers on the Network page, please open the ports
accordingly on your router. For information on how to forward ports on the router, please
refer to your router’s user’s manual.
3. Find out the public IP address of your router provided by your ISP (Internet Service
Provider).
Use the public IP and the secondary HTTP port to access the Network Camera from the
Internet. Please refer to Network Type on page 83 for details.
Internet connection with static IP
Choose this connection type if you are required to use a static IP for the Network Camera.
Please refer to LAN setting on page 82 for details.
Internet connection via PPPoE (Point-to-Point over Ethernet)
Choose this connection type if you are connected to the Internet via a DSL Line. Please
refer to PPPoE on page 83 for details.
