Demtech ART-0100/A SRT-0200/A User manual
SRT/ART Removal Tool
Operator’s Manual
Model Numbers: ART-0100/A
SRT-0200/A
Revision: A
Rev. A, March 2022
SRT Operator’s Manual Page ii
© Copyright 2022 by DEMTECH Services, Inc.
All Rights Reserved
Scope of Manual:
This manual contains procedures for safety, general unpacking,
set-up, and operation of your DEMTECH Services, Inc. Stud/ Anchor Removal Tool.
The text of this publication, or any part thereof, may not be reproduced or transmitted in any
form or by any means, electronic or mechanical, including photocopying, recording, storage in
an information retrieval system, or otherwise, without prior written permission of DEMTECH
Services, Inc.
Notice
Patents have been granted and/or patent applications are pending or are in the process of
preparation on all DEMTECH Services, Inc. developments.
The material in the manual is for informational purposes only and is subject to change without
notice.
DEMTECH Services, Inc. assumes no responsibility for any errors that may appear in this
manual.
Printed in the USA
Manual Number: SRT-OPERATORS-MANUAL, Revision: A
DEMTECH Services, Inc.
6414 Capitol Avenue Diamond Springs, CA 95619 U.S.A.
Telephone: (530) 621-3200
Toll Free: (888) 324-9353
Fax: (530) 621-0150
Web Site: www.demtech.com
Rev. A, March 2022
SRT Operator’s Manual Page iii
Table of Contents
1
SAFETY PRECAUTIONS………………………………………………….PAGE 1
2
GENERAL SAFETY & MAINTENANCE INFORMATION……………PAGE 2
2.1
Intended Use…………………………………………………………Page 2
2.2
Maintenance…………………………………………………………Page 2
3
GENERAL PRODUCT DATA……………………………………………...PAGE 3
4
SITE PREPARATION……………………………………………………….PAGE 3
5
WHAT’S INCLUDED………………………………………………………..PAGE 4
6
SETTING UP YOUR ART/SRT REMOVAL TOOL……………………...PAGE 5
6.1
Attachment Plate Selection…………………………………………...Page 5
6.2
Installing Attachment Plate…………………………………………..Page 6
6.3
Setting Cut Depth…………………………………………………….Page 7
6.4
Changing Bits………………………………………………………...Page 8
7
FACTORY SERVICING…………………………………………………….PAGE 9
Rev. A, March 2022
Page 1 SRT Operator’s Manual
1Safety Precautions
Safety precautions for operating personnel and equipment:
WARNING 1: Operating personnel should perform only the procedures described and
recommended in this manual.
WARNING 2: To avoid serious injury ensure all hardware is fastened prior to use.
WARNING 3: The locations of potentially dangerous voltages and other hazards are
identified and labeled on the equipment. Be careful to observe these warnings when installing,
operating, maintaining or servicing the equipment. Observe all warnings in this manual.
WARNING 4: Make sure to disconnect all input power prior to performing any maintenance
or repairs.
WARNING 5: This product is intended for operator attended operation only. This product
should never be left unattended at any time while the Grinder is on. Incorrect use of the product
will cause damage to the Stud Removal Tool and/or the operator.
WARNING 6: Wear proper eye protection, router bit may kick up dirt and debris.
CAUTION 1: Observe the precautions given on the equipment and within this manual to
prevent damage to the equipment.
CAUTION 2: Unauthorized personnel should not remove from the equipment those panels or
covers that are provided for protection and/or require a tool to remove.
Rev. A, March 2022
Page 2 SRT Operator’s Manual
2General Safety & Maintenance Information
The DEMTECH Services, Inc. Stud/Anchor Removal Tool system, hereinafter referred to
as the SRT is a high voltage piece of equipment. Always disconnect the power before
performing any service and/or maintenance. At all times while operating the SRT keep
hands, fingers, and other body parts well clear of the router bit.
2.1
Intended Use
The SRT Removal Tool is intended as professional use equipment and is not intended for
sale to the general public.
The SRT has been manufactured utilizing the latest technology and current safety
standards and regulations. However, improper use or abuse may lead to hazardous
conditions for the user or other personnel or cause damage to the SRT.
Always keep this manual with the SRT at or near the location where the SRT is being used
so that it can be referred to quickly and easily.
The technician assigned to operate this SRT must have read through and become familiar
with this manual, particularly all safety information, before operating the SRT.
No changes and/or modifications shall be made to the SRT especially as it relates to safety.
2.2
Maintenance
Maintenance, inspection and adjustment of the SRT shall only be carried out by qualified
personnel. Before removing or installing spare parts or performing other repair operations
to the SRT, consult DEMTECH Services, Inc. or your authorized DEMTECH service
center for advice on proper procedures. This will help insure a safe and successful
outcome. Always make sure all screw connections are tight before attempting to operate
the SRT after maintenance and/or repair procedures. Also make sure all covers, guards,
and other safety devices have been fully reinstalled before use.
Rev. A, March 2022
Page 3 SRT Operator’s Manual
3General Product Data
The DEMTECH Services, Inc. Stud/Anchor Removal Tool hereinafter referred to as the
SRT, is a durable easy to use non-destructive on-site Stud Removal Tool. This design
allows for easy high-volume removal of rows of Studs and/or Anchors from concrete
embedment liner. DEMTECH Services, Inc. strives to make our systems easy to use and
built to last.
4Site Preparation
Before proceeding with the unpacking and installation instructions in the following
section(s) make sure the work site is prepared and ready to use the SRT. The SRT has been
designed to handle the roughest jobsite conditions, prior to placing the SRT onto the liner
area ensure there are no rocks or debris. Failure to do so may cause damage to the machine
and/or injure the operator.
Carefully follow the detailed unpacking and installation instructions provided in this
manual.
Rev. A, March 2022
Page 4 SRT Operator’s Manual
5What’s Included
SRT-0200/A
ART-0100/A
1XSRT‐015
2X22mmWrench
3x8‐32–½”Screws
1XSRT‐0301XSRT‐035
1xSRT‐040
1XSRT‐015
2X22mmWrench3x8‐32–½”Screws
1xSRT‐020
1XART‐0101XART‐025
Rev. A, March 2022
Page 5 SRT Operator’s Manual
6Setting up your ART/SRT Removal Tool
6.1
Attachment Plate Selection
a. Prior to Stud removal, ensure the correct attachment plate has been selected. A labeled
machine and transverse attachment plate has been provided. This allows users to
remove Studs in any direction (See Figure 5.1). Contact DemTech Services to ensure
you have the correct attachments for the job.
Figure 5.1
SRT‐030,TransverseDirectionSRT‐035,MachineDirection
ART‐010,TransverseDirectionART‐025,MachineDirection
Rev. A, March 2022
Page 6 SRT Operator’s Manual
6.2
Installing Attachment Plate
a. Install 3x screws (Item 2, Figure 5.2) into router housing using a Phillips head
screwdriver.
Figure 5.2
1
222
Rev. A, March 2022
Page 7 SRT Operator’s Manual
6.3
Setting Cut Depth
a) Unclamp Item 1, Figure 5.3.
b) Press both levers (Item 2, Figure 5.3) in and adjust router base height.
c) Ensure the router bit is flush to bottom of the attachment plate (Item 3, Figure 5.3).
Figure 5.3
1
2
3
2
Rev. A, March 2022
Page 8 SRT Operator’s Manual
d) Once the router attachment is flush to the liner, flip the power switch (Item 1,
Figure 5.4) to the ‘ON’ position. Note, router shown without power cord.
Figure 5.4
6.4
Changing Bits
a) Prior to changing bits, ensure no attachment plate is fastened to Router. Utilize
provided Wrench set to loosen the Router Bits collet. Hold Item 1, Figure 5.5 and
loosen Item 2, Figure 5.5 to release the Router Bit.
Figure 5.5
1
1
2
Rev. A, March 2022
Page 9 SRT Operator’s Manual
7Factory Servicing
In the event your Stud Removal Tool should require factory service, the motor can be
detached and sent in for service. Refer to the following step for preparing the V-Plate for
return. Unless previous arrangements are made, shipping charges and insurance are the
responsibility of the customer. Ship the packaged V-Plate to DEMTECH Services, Inc. at:
DemTech Services, Inc
Ship to address: 6414 Capitol Avenue
Diamond Springs, CA 95619
U.S.A.
Rev. A, March 2022
Page 10 SRT Operator’s Manual
Warranty
DEMTECH Services, Inc. warrants all equipment of its manufacture to be free from defects in
materials, workmanship, mechanical parts, and labor for a period of one year from the date of shipment
to the original buyer and ninety days for electrical. This warranty excludes normal wear items such as
gears, bearings and chains. The liability under this warranty is limited to replacement parts and labor
on equipment when the equipment is returned prepaid to the factory or its authorized service center with
prior authorization from DEMTECH Services, Inc., and upon examination by DEMTECH Services, Inc.,
is determined to be defective. At DEMTECH Services, Inc.'s option, a service representative may be
dispatched to the equipment location.
As an additional protection, DEMTECH Services, Inc. warrants that for a period of 90 days from the
date of shipment to the original buyer, pending prior authorization from DEMTECH Services, Inc., there
will be no charge for service related shipping of parts and/or equipment or for authorized travel of a
service representative to the equipment location. After 90 days, all costs incurred for shipping the
equipment or parts thereof or for travel are the responsibility of the buyer. Our warranty for this equipment
is rendered void if the unit has been repaired, taken apart or modified, or attempted to be, unless such
actions have been taken in accordance with written instructions received from DEMTECH Services,
Inc. The warranty is also void if the equipment has been subjected to abuse, accident or other abnormal
conditions.
IF ANY FAULT DEVELOPS,
THE FOLLOWING STEPS SHOULD BE TAKEN:
1.
Notify DEMTECH Services, Inc. by calling 1-888-324-9353. Overseas customers should contact
the local DEMTECH authorized service center. Please be prepared with the model number, serial
number and full details of the difficulty. Upon receipt of this information, service data or shipping
instructions will be provided by DEMTECH Services, Inc. Do not return the unit for repair without
first contacting the factory or its representative for instructions.
2.
After the initial 90 day period, on receipt of shipping instructions, forward the equipment prepaid
to the factory or its authorized service center as instructed. If requested, an estimate of the
charges will be made before work begins, especially with those cases where the DEMTECH Services,
Inc. product is not covered by the warranty.
3.
If the original carton and packing are not available, the product should be packed in a container
with a strong exterior and surrounded by a protective layer of shock-absorbing material.
DEMTECH Services, Inc. advises returning the equipment at full value to the carrier.
DEMTECH Services, Inc. reserves the right to make changes in design at any time without incurring
any obligation to install the same changes on units previously purchased.
This warranty states the essence of the obligations or liabilities on the part of DEMTECH Services, Inc.
THE FORMAL, COMPLETE AND EXCLUSIVE STATEMENT OF DEMTECH SERVICES, INC.’S
WARRANTY IS CONTAINED IN ITS QUOTATIONS, ACKNOWLEDGEMENTS AND INVOICES.
DEMTECH Services, Inc. neither assumes, nor authorizes any person to assume for it, any liability in
connection with the sale of its equipment other than those set forth herein
