DHT-FS 5
Home Theater System

It’s very easy now to enjoy the excitement of
surround sound with the whole family.
The DHT-FS5 is a single, compact unit,
but it gives you a hefty dose of dynamic surround sound.
Not just movies but also TV programs, games, sports,
live videos and more are all available for you to enjoy with
the compact, easy-to-use DHT-FS5 home theater system.
The primary feature of the DHT-FS5 is that it lets you enjoy the full ambiance of
5.1-channel surround sound throughout your room from a single unit. It’s compact
enough to t pretty much wherever you’d like to have it, and if you know how to
operate a TV, you’ll nd that operating the DHT-FS5 is a pleasure as well.
Home Theater
Sound Quality
Easy Set-up and
Easy Operation Compact Design

• Easy set-up with no difcult settings required
Just choose one of three room sizes and you'll get the
optimum acoustic effects for your room.
• Includes simple remote controller
The DHT-FS5 also comes with a simple remote controller
that has buttons for the most commonly used functions.
Button labels are also larger and easier to read, making it
easy for all members of the family to use.
• Useful audio modes
The DHT-FS5 comes with 4 handy audio modes (MOVIE / MUSIC / STEREO /
NEWS) to suit the type of audio you are listening to. If you are listening
to a news program or documentary, you might choose NEWS mode to
make the spoken words easier to hear. If you are listening to music, you
might switch to MUSIC mode as it is better suited for music programs.
• For greater clarity in spoken words
Since the sonic waves reach listeners’ ears after being radiated from the
speakers throughout the room, the use of full-range speakers in the
DHT-FS5 makes it much easier to hear scripts, narrations, and other types
of spoken words.
• Night Mode, to enjoy surround sound even at low volume levels
When the audio tracks of movies are recorded on DVD, music and sudden
sound effects are generally recorded at higher volume levels than the
dialogue. If you watch a movie at night and lower the volume of the sound
effects, the dialogue will be harder to hear. Night Mode makes it easier for
you to hear the dialogue after lowering the volume of sound effects.
• Compact design ts easily into a TV rack (*1)
*1) Please rst check the dimensions of your TV stand.
• Includes feet that can be adjusted the height of
the speaker unit ts the size of the TV stand
• Wall mount brackets are included
• Easy connection
The DHT-FS5 comes with a digital optical cable and an analog audio cable, as well as an
easy-to-follow connection guide. You can have your home theater ready in minutes!
• Connect up to 4 input devices
The DHT-FS5 has 4 audio inputs that let you connect devices such as a TV, DVD
player, game console, and satellite TV. You can easily switch inputs from
the DHT-FS5’s remote controller.
Beautiful 5.1-channel surround sound from a single unit combining
original bass reex speaker design and Denon X-SPACE SURROUND technology
• X-SPACE SURROUND masterfully reproduces the surround sound and
expands the listening area
The cabinet of the front unit contains 6 full-range
speakers. X-SPACE SURROUND is technology that
uses those speakers to generate surround algorithms.
The sound waves released from the speakers irradiate
throughout the room, so that listeners hear the sound
from the front left and right, the center, and the rear left
and right. Since X-SPACE SURROUND sends the sound
waves out over a wide area, listeners can enjoy surround
sound at any location in the room.
• Bass reex, to produce a deep, robust bass sound from a compact unit
A duct inside the DHT-FS5’s body ensures that the phases of sound from both the
rear and front of the speakers are irradiated into the room with perfect alignment.
This is why the bass that comes from the compact DHT-FS5 sounds so clean and deep.
• Supports all audio formats (Dolby Digital, DTS, Dolby Pro Logic II)
The DHT-FS5 is equipped with Dolby Pro Logic II, Dolby Digital, and DTS, decoders
to reproduce not only digital sound from DVD or STB but also analog video sound
with the surround ambiance that you might experience in a real cinema.
Just connect your TV and player,
and your home theater is ready!
The DHT-FS3, an easy-to-use home theater system
with even more dynamic sound
The DHT-FS3 X-SPACE SURROUND home theater system includes a subwoofer.
This system is for you if you are after surround sound with a deeper, more powerful bass.
• Comes with a subwoofer that reproduces
deep, dynamic bass sounds.
• Piano-black gloss nish with matching subwoofer
• Supports Dolby Digital, DTS, Dolby Pro Logic II
• Dolby Headphone
Listen to your iPod®or Internet radio, too.
With the separately-sold Denon ASD-3W, you can use
the DHT-FS5 to enjoy your iPod or Internet radio programs
(via wired/wireless LAN connection).
An illustration on the back cover of this brochure shows you how this
environment is set up. For more details on the ASD-3W,
have a look at URL: http://blog.denon.com/asd-3/
(The wired ASD-3N is also available.)
Place the DHT-FS5 where you like
Home Theater Sound Quality – 5.1-channel Real Surround Quality Easy Set-up and Easy Operation Compact Design

17280308 NA E
*Design and specications are subject to change without notice.
*Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.
*DTS is a registered trademark & the DTS logos and symbol are of DTS, Inc.
*iPod is a trademark of Apple Inc., registered in the U.S. and other countries.
Specications
Speaker unit
Type 1-way 6-speaker
Rated output 25 W x 4 (6 ohms) + 50 W x 1 (3 ohms)
Input sensitivity 500 mV/22 kohms / 250 mV/22 kohms
(selectable)
S/N ratio 100 dB
Preout output 1 Vrms
Frequency response 12 - 150 Hz
Power supply AC 120 V, 60 Hz
Power consumption 33 W
standby: 0.5 W
Speaker units 3-5/32" cone type x 6
Maximum external dimensions (W x H x D)
Without feet 29-17/32" x 4-41/64" x 5-7/16"
(750 x 118 x 138 mm)
With feet 29-17/32" x 5-1/8" x 5-7/16"
(750 x 130 x 138 mm)
Weight 11 lbs 4 oz (5.1 kg)
Denon Brand Company
D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,
Kanagawa, 210-8569, Japan
www.denon.com
Denon Electronics (USA), LLC.Denon Electronics (USA), LLC.
100 Corporate Drive, Mahwah, New Jersey 07430 USA
TEL: [phone]
usa.denon.com
Denon Canada Inc.
505 Apple Creek Blvd, Unit 5, Markham, Ontario, Canada L3R 5B1
TEL: [phone]
ca.denon.com
Without feet
Inch (mm)
29-17/32" (750) 4-41/64" (118)
5-7/16" (138)
