Denon AVR-3808CI Administrator guide

2007/07/06
1/21
DENON AVR3808 RC CODE
FORMAT SHARP
DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED
REMOTE ID : 1
SYSTEM ADDRESS(C1～C5) : ０１０００ , EXTENSION BIT(C12,C13) : １１
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
0 ００００００ 16 ００００１０ FR LEVEL DOWN
1 １０００００ POWER 17 １０００１０
2 ０１００００ FL LEVEL UP 18 ０１００１０
3 １１００００ PHONO 19 １１００１０
4 ００１０００ CD 20 ００１０１０
5 １０１０００ TUNER 21 １０１０１０
6 ０１１０００ 22 ０１１０１０ SR LEVEL UP
7 １１１０００ FL LEVEL DOWN 23 １１１０１０ SR LEVEL DOWN
8 ０００１００ SAT 24 ０００１１０ VIDEO SELECT
9 １００１００ TV/CBL 25 １００１１０
10 ０１０１００ HDP 26 ０１０１１０
11 １１０１００ FR LEVEL UP 27 １１０１１０
12 ００１１００ V.AUX 28 ００１１１０ INPUT MODE ANALOG
13 １０１１００ VCR 29 １０１１１０ CURSOR RIGHT
14 ０１１１００ DVR 30 ０１１１１０ STATUS
15 １１１１００ 31 １１１１１０ ON SCREEN
SYSTEM ADDRESS(C1～C5) : ０１０００ , EXTENSION BIT(C12,C13) : １１
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
32 ０００００１ ENTER 48 ００００１１ MUTING
33 １００００１ POWER ON 49 １０００１１ MASTER VOLUME UP
34 ０１０００１ POWER OFF 50 ０１００１１ MASTER VOLUME DOWN
35 １１０００１ DVD 51 １１００１１ SL LEVEL UP
36 ００１００１ STANDARD(DOLBY/DTS SURR.) 52 ００１０１１ SL LEVEL DOWN
37 １０１００１ SW LEVEL DOWN 53 １０１０１１ CENTER LEVEL UP
38 ０１１００１ DSP SIMULATION 54 ０１１０１１ CENTER LEVEL DOWN
39 １１１００１ SB/SBL LEVEL UP 55 １１１０１１ SBR LEVEL UP
40 ０００１０１ 56 ０００１１１ SBR LEVEL DOWN
41 １００１０１ 57 １００１１１ TONE DEFEAT ON
42 ０１０１０１ TEST TONE 58 ０１０１１１ TONE DEFEAT OFF
43 １１０１０１ SB/SBL LEVEL DOWN 59 １１０１１１
44 ００１１０１ SW LEVEL UP 60 ００１１１１
45 １０１１０１ SPEAKER 61 １０１１１１
46 ０１１１０１ 62 ０１１１１１
47 １１１１０１ 63 １１１１１１

2007/07/06
2/21
DENON AVR3808 RC CODE
FORMAT SHARP
DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED
REMOTE ID : 1
SYSTEM ADDRESS(C1～C5) : ００１１０ , EXTENSION BIT (C12,C13) : ０１
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
0 ００００００ ALL BASS DOWN 16 ００００１０ ZONE2 CD
1 １０００００ 17 １０００１０ ZONE2 TUNER
2 ０１００００ SURROUND BACK 18 ０１００１０ ZONE2 HDP
3 １１００００ MASTER VOL. PRESET1(0dB) 19 １１００１０ ZONE2 V.AUX
4 ００１０００ 20 ００１０１０ ZONE2 VCR
5 １０１０００ MASTER VOL. PRESET2(-20dB) 21 １０１０１０
6 ０１１０００ MASTER VOL. PRESET3(-40dB) 22 ０１１０１０ MULTI PRESET UP
7 １１１０００ ZONE2 VOL. PRESET1(0dB) 23 １１１０１０ MULTI PRESET DOWN
8 ０００１００ ZONE2 VOL. PRESET2(-20dB) 24 ０００１１０
9 １００１００ ZONE2 VOL. PRESET3(-40dB) 25 １００１１０ ZONE2 DVR
10 ０１０１００ ZONE2 SAT 26 ０１０１１０
11 １１０１００ 27 １１０１１０ ZONE2 TV/CBL
12 ００１１００ ZONE3 VOL. PRESET1(0dB) 28 ００１１１０
13 １０１１００ ZONE2 VOLUME UP 29 １０１１１０ STEREO
14 ０１１１００ ZONE2 VOLUME DOWN 30 ０１１１１０ DIRECT
15 １１１１００ ZONE2 PHONO 31 １１１１１０ ZONE3 VOL. PRESET2(0dB)
SYSTEM ADDRESS(C1～C5) : ００１１０ , EXTENSION BIT (C12,C13) : ０１
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
32 ０００００１ SYSTEM SETUP 48 ００００１１ CH VOLUME UP
33 １００００１ SURROUND PARAMETER 49 １０００１１ CH VOLUME DOWN
34 ０１０００１ ZONE3 VOL. PRESET2(0dB) 50 ０１００１１
35 １１０００１ CURSOR UP 51 １１００１１
36 ００１００１ CURSOR DOWN 52 ００１０１１
37 １０１００１ 53 １０１０１１ INPUT MODE EXT.IN
38 ０１１００１ 54 ０１１０１１ INPUT MODE
39 １１１００１ 55 １１１０１１ ALL TREBLE UP
40 ０００１０１ 7CH STEREO 56 ０００１１１ ALL TREBLE DOWN
41 １００１０１ 57 １００１１１ TUNER SHIFT A
42 ０１０１０１ 58 ０１０１１１ TUNER SHIFT B
43 １１０１０１ TUNER SHIFT F 59 １１０１１１ TUNER SHIFT C
44 ００１１０１ 60 ００１１１１ TUNER SHIFT D
45 １０１１０１ 61 １０１１１１ TUNER SHIFT E
46 ０１１１０１ TUNER SHIFT G 62 ０１１１１１ ZONE2 DVD
47 １１１１０１ CH SELECT 63 １１１１１１ ALL BASS UP

2007/07/06
3/21
DENON AVR3808 RC CODE
FORMAT SHARP
DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED
REMOTE ID : 1
SYSTEM ADDRESS(C1～C5) : ００１１０ , EXTENSION BIT (C12,C13) : １０
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
32 ０００００１ 48 ００００１１
33 １００００１ 49 １０００１１
34 ０１０００１ 50 ０１００１１
35 １１０００１ 51 １１００１１
36 ００１００１ 52 ００１０１１
37 １０１００１ 53 １０１０１１
38 ０１１００１ 54 ０１１０１１
39 １１１００１ 55 １１１０１１
40 ０００１０１ 56 ０００１１１
41 １００１０１ 57 １００１１１
42 ０１０１０１ 58 ０１０１１１
43 １１０１０１ 59 １１０１１１
44 ００１１０１ 60 ００１１１１
45 １０１１０１ 61 １０１１１１
46 ０１１１０１ 62 ０１１１１１
47 １１１１０１ 63 １１１１１１ CURSOR LEFT
SYSTEM ADDRESS(C1～C5) : ００１１０ , EXTENSION BIT (C12,C13) : １１
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
0 ００００００ 16 ００００１０
1 １０００００ TUNER PRESET CH 1 17 １０００１０
2 ０１００００ TUNER PRESET CH 2 18 ０１００１０ RDS
3 １１００００ TUNER PRESET CH 3 19 １１００１０
4 ００１０００ TUNER PRESET CH 4 20 ００１０１０ PTY
5 １０１０００ TUNER PRESET CH 5 21 １０１０１０ TUNER PRESET DOWN
6 ０１１０００ TUNER PRESET CH 6 22 ０１１０１０ TUNER PRESET UP
7 １１１０００ TUNER PRESET CH 7 23 １１１０１０ TUNER BAND
8 ０００１００ TUNER PRESET CH 8 24 ０００１１０ TUNER TUNING MODE
9 １００１００ 25 １００１１０ TUNER TUNING UP
10 ０１０１００ 26 ０１０１１０ TUNER TUNING DOWN
11 １１０１００ 27 １１０１１０
12 ００１１００ TUNER MEMORY 28 ００１１１０
13 １０１１００ TUNER SHIFT 29 １０１１１０
14 ０１１１００ RT 30 ０１１１１０
15 １１１１００ 31 １１１１１０ DIMMER

2007/07/06
4/21
DENON AVR3808 RC CODE
FORMAT SHARP
DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED
REMOTE ID : 1
SYSTEM ADDRESS (C1～C5) : ０１０００ , EXTENSION BIT (C12,C13) : １０
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
0 ００００００ 16 ００００１０
1 １０００００ 17 １０００１０
2 ０１００００ 18 ０１００１０ ZONE3 TV/CBL
3 １１００００ 19 １１００１０ ZONE3 SAT
4 ００１０００ 20 ００１０１０ ZONE3 VCR
5 １０１０００ 21 １０１０１０ ZONE3 DVR
6 ０１１０００ 22 ０１１０１０
7 １１１０００ 23 １１１０１０ ZONE3 V.AUX
8 ０００１００ ZONE3 TUNER 24 ０００１１０
9 １００１００ ZONE3 PHONO 25 １００１１０
10 ０１０１００ ZONE3 CD 26 ０１０１１０
11 １１０１００ 27 １１０１１０
12 ００１１００ 28 ００１１１０
13 １０１１００ 29 １０１１１０ ZONE2 ON/OFF
14 ０１１１００ ZONE3 DVD 30 ０１１１１０
15 １１１１００ ZONE3 HDP 31 １１１１１０
SYSTEM ADDRESS (C1～C5) : ０１０００ , EXTENSION BIT (C12,C13) : １０
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
32 ０００００１ 48 ００００１１
33 １００００１ 49 １０００１１
34 ０１０００１ 50 ０１００１１
35 １１０００１ 51 １１００１１
36 ００１００１ 52 ００１０１１
37 １０１００１ ZONE3 VOLUME DOWN 53 １０１０１１
38 ０１１００１ ZONE3 VOLUME UP 54 ０１１０１１
39 １１１００１ 55 １１１０１１
40 ０００１０１ 56 ０００１１１
41 １００１０１ 57 １００１１１ MAIN ZONE ON
42 ０１０１０１ PURE DIRECT 58 ０１０１１１ MAIN ZONE OFF
43 １１０１０１ 59 １１０１１１ MULTI ZONE2 ON
44 ００１１０１ 60 ００１１１１ MULTI ZONE2 OFF
45 １０１１０１ 61 １０１１１１ MULTI ZONE3 ON
46 ０１１１０１ 62 ０１１１１１ MULTI ZONE3 OFF
47 １１１１０１ 63 １１１１１１

2007/07/06
5/21
DENON AVR3808 RC CODE
FORMAT SHARP
DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED
REMOTE ID : 1
SYSTEM ADDRESS (C1～C5) : ００１００ , EXTENSION BIT (C12,C13) : ０１
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
0 ００００００ 16 ００００１０ DOLBY PL II MUSIC
1 １０００００ WIDE SCREEN 17 １０００１０ DOLBY PL
2 ０１００００ SUPER STADIUM 18 ０１００１０
3 １１００００ ROCK ARENA 19 １１００１０
4 ００１０００ JAZZ CLUB 20 ００１０１０
5 １０１０００ CLASSIC CONCERT 21 １０１０１０ CINEMA MODE
6 ０１１０００ MONO MOVIE 22 ０１１０１０ MUSIC MODE
7 １１１０００ MATRIX 23 １１１０１０ GAME MODE
8 ０００１００ VIDEO GAME 24 ０００１１０
9 １００１００ VIRTUAL 25 １００１１０
10 ０１０１００ 26 ０１０１１０
11 １１０１００ 27 １１０１１０
12 ００１１００ 28 ００１１１０
13 １０１１００ DTS NEO:6 CINEMA 29 １０１１１０ ROOM EQ
14 ０１１１００ DTS NEO:6 MUSIC 30 ０１１１１０
15 １１１１００ DOLBY PL II CINEMA 31 １１１１１０
SYSTEM ADDRESS (C1～C5) : ００１００ , EXTENSION BIT (C12,C13) : ０１
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
32 ０００００１ 48 ００００１１
33 １００００１ 49 １０００１１
34 ０１０００１ 50 ０１００１１
35 １１０００１ 51 １１００１１ INPUT MDE AUTO
36 ００１００１ 52 ００１０１１
37 １０１００１ 53 １０１０１１
38 ０１１００１ 54 ０１１０１１
39 １１１００１ 55 １１１０１１ INPUT MODE EXT.IN
40 ０００１０１ 56 ０００１１１
41 １００１０１ 57 １００１１１
42 ０１０１０１ 58 ０１０１１１
43 １１０１０１ 59 １１０１１１
44 ００１１０１ 60 ００１１１１
45 １０１１０１ 61 １０１１１１
46 ０１１１０１ 62 ０１１１１１
47 １１１１０１ 63 １１１１１１

2007/07/06
6/21
DENON AVR3808 RC CODE
FORMAT KASEIKYO
DATA CONSTRUCTION 48bits
ＤＥＮＯＮ CODE Parity GENRE1(*1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
001010 1 001 0 0 1 1 0 0 0 0 0 0 * * * *
GENRE2(*2) Data ID(*3) Parity(*5)
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
* * * * * * * * * * * * * * * * * * * * * * * *
(*5) Parity :
Delimit of each to 8 bits, and add the 3rd byte and the 4th byte and the 5th byte with modulo 2(exclusive-OR).
3rd byte ( 17 - 24 bit)
4th byte ( 25 - 32 bit)
5th byte ( 33 - 40 bit)

2007/07/06
7/21
REMTOE ID SETTING: (default ID 1)
GENRE1(*1) GENRE2(*2) ID(*3)ID No. ZONE/DEVICE
21 22 23 24 25 26 27 28 39 40
MAIN ZONE 0 01 0 1 0 0 0 0 0 SHARP&K4-1
ZONE2 0 0101 1 0 0 0 0 SHARP&K4-3
ZONE3 0 0101 0 1 0 0 0 SHARP&K4-5
ANALOG TUNER 0 0 1 0 1 0 0 0 0 0 SHARP&K4-1
NET AUDIO 0 0 1 0 1 1 1 0 0 0 K4-7
iPod 0 1 0 0 1 1 0 0 0 0 K2-3
1
XM 1 1 1 0 1 0 1 0 0 0 K4-5
MAIN ZONE 0 010010 0 1 0 K4-2
ZONE2 0 010001 0 1 0 K4-4
ZONE3 0 010011 0 1 0 K4-6
ANALOG TUNER 0 010010 0 1 0 K4-2
NET AUDIO 0 0 1 0 0 0 0 1 1 0 K4-8
iPod 0 1 0 0 1 1 0 0 1 0 K2-3
2
XM 1 1 1 0 1 0 1 0 1 0 K4-5
MAIN ZONE 0 010010 0 0 1 K4-2
ZONE2 0 010001 0 0 1 K4-4
ZONE3 0 010011 0 0 1 K4-6
ANALOG TUNER 0 010010 0 0 1 K4-2
NET AUDIO 0 0 1 0 0 0 0 1 0 1 K4-8
iPod 0 1 0 0 1 1 0 0 0 1 K2-3
3
XM 1 1 1 0 1 0 1 0 0 1 K4-5
MAIN ZONE 0 010010 0 1 1 K4-2
ZONE2 0 010001 0 1 1 K4-4
ZONE3 0 010011 0 1 1 K4-6
ANALOG TUNER 0 010010 0 1 1 K4-2
NET AUDIO 0 0 1 0 0 0 0 1 1 1 K4-8
iPod 0 1 0 0 1 1 0 0 1 1 K2-3
4
XM 1 1 1 0 1 0 1 0 1 1 K4-5

2007/07/06
8/21
MAIN ZONE
ＤＥＮＯＮ CODE Parity GENRE1
４５２３ ０ 4
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
001010 1 001 0 0 1 1 0 0 0 0 0 0 0010
REMOTE ID SET : 1
K4-1 : MAIN ZONE
GENRE2 Data ID parity
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Key Name
0 1 0 0 0 1 0 0 0 0 0 0 1 1 0 0 0 1 1 0 RETURN
1 1 0 0 0 1 0 0 0 0 0 0 1 1 0 0 1 1 1 0 GUI MENU
0 0 1 0 0 1 0 0 1 0 0 0 0 1 0 0 1 0 0 0 QUICK SELECT 1
1 0 1 0 0 1 0 0 1 0 0 0 0 1 0 0 1 0 0 0 QUICK SELECT 2
0 1 1 0 0 1 0 0 1 0 0 0 0 1 0 0 1 0 0 0 QUICK SELECT 3
1 0 0 0 1 1 0 0 1 0 0 0 0 1 0 0 0 0 1 0 DIRECT/STEREO
1 1 0 1 1 0 1 0 1 0 0 0 0 0 1 0 0 1 1 1 NEURAL
1010 0 110100011 1 0 0 0 0 0 INPUT MODE HDMI
1110 0 110100011 1 0 0 1 0 0 INPUT MODE DIGITAL
0011 0 110100011 1 0 1 0 0 1 DECODE MODE
0 0 1 0 0 1 0 0 0 1 0 0 1 1 0 0 0 1 0 0 AUDIO RESTORER
0011 0 10001 0 0 1 1 0 0 0 1 0 1 RESTORER(OFF)
1011 0 10001 0 0 1 1 0 0 1 1 0 1 RESTORER(Mode1)
0111 0 10001 0 0 1 1 0 0 0 0 0 1 RESTORER(Mode2)
1111 0 10001 0 0 1 1 0 0 1 0 0 1 RESTORER(Mode3)
0011 0 110010011 1 0 0 1 0 1 AUDIO DELAY MODE
1011 0 110010011 1 0 1 1 0 1 AUDIO DELAY UP
0111 0 110010011 1 0 0 0 0 1 AUDIO DELAY DOWN
1 0 1 0 0 0 0 1 0 1 0 0 1 0 0 1 1 1 0 0 STATUS REQUEST(for 2way RC)
1 1 1 0 0 0 1 1 0 1 0 0 1 0 1 1 1 0 0 0 NET/USB
0 1 0 1 0 0 1 1 0 1 0 0 1 0 1 1 0 0 1 1 XM
0 0 1 1 0 0 1 1 0 1 0 0 1 0 1 1 0 1 0 1 NET
1 0 1 1 0 0 1 1 0 1 0 0 1 0 1 1 1 1 0 1 iPod
0 1 1 1 0 0 1 1 0 1 0 0 1 0 1 1 0 0 0 1 USB(Playback)
0 0 1 1 1 0 1 1 0 1 0 0 0 0 1 1 0 1 0 1 DVD/HDP
1 1 1 1 1 0 1 1 0 1 0 0 0 0 1 1 1 0 0 1 VCR/DVR
1 0 0 0 1 1 1 1 0 1 0 0 0 1 1 1 1 1 1 0 HDMI MONITOR SELECT
0 1 0 0 1 1 1 1 0 1 0 0 0 1 1 1 0 0 1 0 RESOLUTION
0011 1 101110001 0 1 1 1 0 1 MAIN ZONE REPEAT
1011 1 101110001 0 1 0 1 0 1 MAIN ZONE RANDOM/SHUFFLE
0111 1 101110001 0 1 1 0 0 1 MAIN ZONE USB DIRECT PLAY
1111 1 101110001 0 1 0 0 0 1 MAIN ZONE FAVORITE DIRECT PLAY
0011 0 011110010 1 1 1 1 0 1 MAIN ZONE PRESET CH UP
1011 0 011110010 1 1 0 1 0 1 MAIN ZONE PRESET CH DOWN
0111 0 011110010 1 1 1 0 0 1 MAIN ZONE PRESET CH SHIFT
1110 1 011110000 1 1 0 0 0 0 MAIN ZONE SEARCH(RDS)
0000 0 111110011 1 1 1 1 1 0 MAIN ZONE PLAY/PAUSE
1000 0 111110011 1 1 0 1 1 0 MAIN ZONE STOP
1 0 0 0
1100 0 111110011 1 1 0 0 1 0 MAIN ZONE SKIP MINUS/TUNING DOWN

2007/07/06
9/21
0
010 0 111110011 1 1 1 1 0 0 MAIN ZONE SKIP PLUS/TUNING UP
REMOTE ID SET : 2-4
K4-2 : MAIN ZONE
GENRE2 Data ID Parity
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Key Name
1 0 0 0 0 0 0 0 0 0 * * * * * * * * * * ALL POWER ON/OFF
0 1 0 0 0 0 0 0 0 0 * * * * * * * * * * ALL POWER ON
1 1 0 0 0 0 0 0 0 0 * * * * * * * * * * ALL POWER OFF
0 1 1 0 0 0 0 0 0 0 * * * * * * * * * * MAIN ZONE ON
1 1 1 0 0 0 0 0 0 0 * * * * * * * * * * MAIN ZONE OFF
1 1 0 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR UP
0 0 1 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR DOWN
1 0 1 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR LEFT
0 1 1 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR RIGHT
1 1 1 1 1 0 0 0 0 0 * * * * * * * * * * ENTER
0 1 0 0 0 1 0 0 0 0 * * * * * * * * * * RETURN
1 1 0 0 0 1 0 0 0 0 * * * * * * * * * * GUI MENU
0 0 0 0 1 1 1 0 0 0 * * * * * * * * * * VIDEO SELECT
0 0 1 0 0 1 0 0 1 0 * * * * * * * * * * QUICK SELECT 1
1 0 1 0 0 1 0 0 1 0 * * * * * * * * * * QUICK SELECT 2
0 1 1 0 0 1 0 0 1 0 * * * * * * * * * * QUICK SELECT 3
0 0 0 0 1 1 0 0 1 0 * * * * * * * * * * STEREO
1 0 0 0 1 1 0 0 1 0 * * * * * * * * * * DIRECT/STEREO
0 1 0 0 1 1 0 0 1 0 * * * * * * * * * * DIRECT
1 1 0 0 1 1 0 0 1 0 * * * * * * * * * * PURE DIRECT
0 0 1 0 1 1 0 0 1 0 * * * * * * * * * * STANDARD
0 1 0 1 1 1 0 0 1 0 * * * * * * * * * * DOLBY PLⅡ/PLⅡx CINEMA
1 1 0 1 1 1 0 0 1 0 * * * * * * * * * * DOLBY PLⅡ/PLⅡx MUSIC
0 0 1 1 1 1 0 0 1 0 * * * * * * * * * * DOLBY PROLOGIC
0 1 0 0 0 0 1 0 1 0 * * * * * * * * * * DTS NEO:6 CINEMA
1 1 0 0 0 0 1 0 1 0 * * * * * * * * * * DTS NEO:6 MUSIC
1 0 1 1 0 0 1 0 1 0 * * * * * * * * * * GAME MODE
0 1 1 1 0 0 1 0 1 0 * * * * * * * * * * CINEMA MODE
1 1 1 1 0 0 1 0 1 0 * * * * * * * * * * MUSIC MODE
0 0 0 0 1 0 1 0 1 0 * * * * * * * * * * DSP SIMULATION
1 0 0 0 1 0 1 0 1 0 * * * * * * * * * * 7CH STEREO
0 1 0 0 1 0 1 0 1 0 * * * * * * * * * * WIDE SCREEN
1 1 0 0 1 0 1 0 1 0 * * * * * * * * * * SUPER STADIUM
0 0 1 0 1 0 1 0 1 0 * * * * * * * * * * ROCK ARENA
1 0 1 0 1 0 1 0 1 0 * * * * * * * * * * JAZZ CLUB
0 1 1 0 1 0 1 0 1 0 * * * * * * * * * * CLASSIC CONCERT
1 1 1 0 1 0 1 0 1 0 * * * * * * * * * * MONO MOVIE
0 0 0 1 1 0 1 0 1 0 * * * * * * * * * * MATRIX
1 0 0 1 1 0 1 0 1 0 * * * * * * * * * * VIDEO GAME
0 1 0 1 1 0 1 0 1 0 * * * * * * * * * * VIRTUAL
1 1 0 1 1 0 1 0 1 0 * * * * * * * * * * NEURAL
0 0 0 0 0 1 1 0 1 0 * * * * * * * * * * INPUT MODE SELECT
0 1 0 0
1 0 0 0 0 1 1 0 1 0 * * * * * * * * * * INPUT MODE ANALOG

2007/07/06
10/21
1
010 0 11010* * ******* *INPUTMODEHDMI

2007/07/06
11/21
0110 0 11010* * ******* *INPUTMODEAUTO
1110 0 11010* * ******* *INPUTMODEDIGITAL
0001011010* * ******* *EXT.INSELECT
1001011010* * ********EXT.IN
0011 0 11010* * ******* *DECODEMODE
0000111010* * ********MASTERVOLUMEUP
1000111010* * ********MASTERVOLUMEDOWN
0100111010* * ********MASTERVOLUMEMUTE
0010111010* * ********MASTERVOLPRESET 1(0dB)
1010111010* * ********MASTERVOLPRESET 2(-20dB)
0110111010* * ********MASTERVOLPRESET 3(-40dB)
0101111010* * ********CHSELECT
1101111010* * ********CHLEVEL UP
0011111010* * ********CHLEVEL DOWN
1111111010* * ********TESTTONEON/OFF
0000000110* * ********FLLEVEL UP
1000000110* * ********FLLEVEL DOWN
0100000110* * ********FRLEVEL UP
1100000110* * ********FRLEVEL DOWN
0010000110* * ********CLEVEL UP
1010000110* * ********CLEVEL DOWN
0110000110* * ********SWLEVEL UP
1110000110* * ********SWLEVEL DOWN
0001000110* * ********SLLEVEL UP
1001000110* * ********SLLEVEL DOWN
0101000110* * ********SRLEVEL UP
1101000110* * ********SRLEVEL DOWN
0011000110* * ********SBLLEVEL UP
1011000110* * ********SBLLEVEL DOWN
0111000110* * ********SBRLEVEL UP
1111000110* * ********SBRLEVEL DOWN
0000100110* * ********ALLTREBLEUP
1000100110* * ********ALLTREBLEDOWN
1100100110* * ********ALLBASS UP
0010100110* * ********ALLBASS DOWN
0110100110* * ********TONEDEFEATON/OFF
1110100110* * ********TONEDEFEATON
0001100110* * ********TONEDEFEATOFF
0000001110* * ********PARAMETERON/OFF
0110000001* * ********SURROUND BACK SPEAKER
0101000001* * ********SURROUD SPEAKER
0011 0 10001* * ******* *RESTORER(OFF)
1011 0 10001* * ******* *RESTORER(Mode1)
0111 0 10001* * ******* *RESTORER(Mode2)
1111 0 10001* * ******* *RESTORER(Mode3)
0100010001* * ********NIGHTMODE
0010010001* * ******* *AUDIORESTORER

2007/07/06
12/21
0000110001* * ********SYSTEM SETUP
0011 0 11001* * ******* *AUDIODELAYMODE
1011011001* * ********AUDIODELAYUP
0111011001* * ********AUDIODELAYDOWN
0000111001* * ********ONSCREEN
0000000101* * ********STATUS
1010000101* * ********STATUSREQUEST(for2wayRC)
0000100101* * ********DIMMER
0000001101* * ********PHONO
1000001101* * ********TUNER
0100001101* * ********CD
1110001101* * ********NET/USB
0101001101* * ********XM
0011001101* * ********NET
1011001101* * ********iPod
0111001101* * ********USB(Playback)
0000101101* * ********DVD
1000101101* * ********HDP
0100101101* * ********TV/CBL
1100101101* * ********SAT
1010101101* * ********VCR
0110101101* * ********DVR
1001101101* * ********V.AUX
0011101101* * ********DVD/HDP
1111101101* * ********VCR/DVR
0000 0 11101* * ******* *ROOMEQSELECT
1000111101* * ********HDMIMONITORSELECT
0100111101* * ********RESOLUTION
0011 1 10111* * ******* *MAINZONEREPEAT
1011 1 10111* * ******* *MAINZONERANDOM/SHUFFLE
0111 1 10111* * ******* *MAINZONEUSBDIRECTPLAY
1111 1 10111* * ******* *MAINZONEFAVORITEDIRECTPLAY
0011 0 01111* * ******* *MAINZONEPRESET CH UP
1011 0 01111* * ******* *MAINZONEPRESET CH DOWN
0111 0 01111* * ******* *MAINZONEPRESET CH SHIFT
1110 1 01111* * ******* *MAINZONESEARCH(RDS)
0000 0 11111* * ******* *MAINZONEPLAY/PAUSE
1000 0 11111* * ******* *MAINZONESTOP
1100 0 11111* * ******* *MAIN ZONE SKIP MINUS/TUNING DOWN
0010 0 11111* * ******* *MAIN ZONE SKIP PLUS/TUNING UP

2007/07/06
13/21
ZONE2
ＤＥＮＯＮ CODE Parity GENRE1
４５２３ ０ 4
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
001010 1 001 0 0 1 1 0 0 0 0 0 0 0010
REMOTE ID SET : 1
K4-3 : ZONE2
GENRE2 Data ID Parity
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Key Name
1 1 0 1 1 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 ZONE2 CURSOR UP
0 0 1 1 1 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 ZONE2 CURSOR DOWN
1 0 1 1 1 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 ZONE2 CURSOR LEFT
0 1 1 1 1 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 ZONE2 CURSOR RIGHT
1 1 1 1 1 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 ZONE2 ENTER
0100 0 100000010 0 0 0 1 1 0 ZONE2 RETURN
1100 0 100000010 0 0 1 1 1 0 ZONE2 MENU
0 1 0 0 1 1 1 0 1 0 0 0 0 0 1 0 1 1 1 0 ZONE2 VOLUME MUTE
0000 1 100010000 0 0 0 1 1 0 ZONE2 SYSTEM SETUP
1010 0 001010011 0 1 1 1 0 0 STATUS REQUEST(for 2way RC)
1 1 1 0 0 0 1 1 0 1 0 0 1 1 1 1 1 0 0 0 ZONE2 NET/USB
0101 0 011010011 1 1 0 0 1 1 ZONE2 XM
0 0 1 1 0 0 1 1 0 1 0 0 1 1 1 1 0 1 0 1 ZONE2 NET
1 0 1 1 0 0 1 1 0 1 0 0 1 1 1 1 1 1 0 1 ZONE2 iPod
0 1 1 1 0 0 1 1 0 1 0 0 1 1 1 1 0 0 0 1 ZONE2 USB
1001 1 011010001 1 1 1 1 1 1 ZONE2 V.AUX
0011 1 011010001 1 1 0 1 0 1 ZONE2 DVD/HDP
1111 1 011010001 1 1 1 0 0 1 ZONE2 VCR/DVR
0 0 1 1 1 1 0 1 1 1 0 0 0 0 0 1 1 1 0 1 ZONE2 REPEAT
1 0 1 1 1 1 0 1 1 1 0 0 0 0 0 1 0 1 0 1 ZONE2 RANDOM/SHUFFLE
0 1 1 1 1 1 0 1 1 1 0 0 0 0 0 1 1 0 0 1 ZONE2 USB DIRECT PLAY
1 1 1 1 1 1 0 1 1 1 0 0 0 0 0 1 0 0 0 1 ZONE2 FAVORITE DIRECT PLAY
0 0 1 1 0 0 1 1 1 1 0 0 1 1 1 1 1 1 0 1 ZONE2 PRESET CH UP
1 0 1 1 0 0 1 1 1 1 0 0 1 1 1 1 0 1 0 1 ZONE2 PRESET CH DOWN
0 1 1 1 0 0 1 1 1 1 0 0 1 1 1 1 1 0 0 1 ZONE2 PRESET CH SHIFT
1 1 1 0 1 0 1 1 1 1 0 0 0 1 1 1 0 0 0 0 ZONE2 SEARCH(RDS)
0 0 0 0 0 1 1 1 1 1 0 0 1 0 1 1 1 1 1 0 ZONE2 PLAY/PAUSE
1 0 0 0 0 1 1 1 1 1 0 0 1 0 1 1 0 1 1 0 ZONE2 STOP
1 1 0 0 0 1 1 1 1 1 0 0 1 0 1 1 0 0 1 0 ZONE2 SKIP MINUS/TUNING DOWN
1 1 0 0
0 0 1 0 0 1 1 1 1 1 0 0 1 0 1 1 1 1 0 0 ZONE2 SKIP PLUS/TUNING UP

2007/07/06
14/21
REMOTE ID SET : 2-4
K4-4 : ZONE2
GENRE2 Data ID parity
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Key Name
1010 0 00000 * * * * * * * * * * ZONE2 POWER ON/OFF
0110 0 00000 * * * * * * * * * * ZONE2 POWER ON
1110 0 00000 * * * * * * * * * * ZONE2 POWER OFF
1 1 0 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 CURSOR UP
0 0 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 CURSOR DOWN
1 0 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 CURSOR LEFT
0 1 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 CURSOR RIGHT
1 1 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 ENTER
0100 0 10000 * * * * * * * * * * ZONE2 RETURN
1100 0 10000 * * * * * * * * * * ZONE2 MENU
0010 1 11010 * * * * * * * * * * ZONE2 VOL PRESET 1(0dB)
1010 1 11010 * * * * * * * * * * ZONE2 VOL PRESET 2(-20dB)
0110 1 11010 * * * * * * * * * * ZONE2 VOL PRESET 3(-40dB)
0 1 0 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VOLUME MUTE
0000 1 10001 * * * * * * * * * * ZONE2 SYSTEM SETUP
1010 0 00101 * * * * * * * * * * STATUS REQUEST(for 2way RC)
0000 0 01101 * * * * * * * * * * ZONE2 PHONO
1000 0 01101 * * * * * * * * * * ZONE2 TUNER
0100 0 01101 * * * * * * * * * * ZONE2 CD
1 1 1 0 0 0 1 1 0 1 * * * * * * * * * * ZONE2 NET/USB
0101 0 01101 * * * * * * * * * * ZONE2 XM
0 0 1 1 0 0 1 1 0 1 * * * * * * * * * * ZONE2 NET
1 0 1 1 0 0 1 1 0 1 * * * * * * * * * * ZONE2 iPod
0 1 1 1 0 0 1 1 0 1 * * * * * * * * * * ZONE2 USB
0000 1 01101 * * * * * * * * * * ZONE2 DVD
1000 1 01101 * * * * * * * * * * ZONE2 HDP
0100 1 01101 * * * * * * * * * * ZONE2 TV/CBL
1100 1 01101 * * * * * * * * * * ZONE2 SAT
1010 1 01101 * * * * * * * * * * ZONE2 VCR
0110 1 01101 * * * * * * * * * * ZONE2 DVR
1001 1 01101 * * * * * * * * * * ZONE2 V.AUX
0011 1 01101 * * * * * * * * * * ZONE2 DVD/HDP
1111 1 01101 * * * * * * * * * * ZONE2 VCR/DVR
0 0 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE2 REPEAT
1 0 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE2 RANDOM/SHUFFLE
0 1 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE2 USB DIRECT PLAY
1 1 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE2 FAVORITE DIRECT PLAY
0 0 1 1 0 0 1 1 1 1 * * * * * * * * * * ZONE2 PRESET CH UP
1 0 1 1 0 0 1 1 1 1 * * * * * * * * * * ZONE2 PRESET CH DOWN
0 1 1 1 0 0 1 1 1 1 * * * * * * * * * * ZONE2 PRESET CH SHIFT
1 1 1 0 1 0 1 1 1 1 * * * * * * * * * * ZONE2 SEARCH(RDS)
0 0 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 PLAY/PAUSE
1 0 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 STOP
1 1 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 SKIP MINUS/TUNING DOWN
0 0 1 0
0 0 1 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 SKIP PLUS/TUNING UP

2007/07/06
15/21
ZONE3
ＤＥＮＯＮ CODE Parity GENRE1
４５２３ ０ 4
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
001010 1 001 0 0 1 1 0 0 0 0 0 0 0010
REMOTE ID SET : 1
K4-5 : ZONE3
GENRE2 Data ID parity
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Key Name
1010 0 00000 0 0 1 0 1 0 1 0 0 0 ZONE3 POWER ON/OFF
1101 1 00000 0 0 0 0 1 0 1 1 1 1 ZONE3 CURSOR UP
0011 1 00000 0 0 0 0 1 0 0 0 0 1 ZONE3 CURSOR DOWN
1011 1 00000 0 0 0 0 1 0 1 0 0 1 ZONE3 CURSOR LEFT
0111 1 00000 0 0 0 0 1 0 0 1 0 1 ZONE3 CURSOR RIGHT
1111 1 00000 0 0 0 0 1 0 1 1 0 1 ZONE3 ENTER
0100 0 10000 0 0 1 1 1 0 0 1 1 0 ZONE3 RETURN
1100 0 10000 0 0 1 1 1 0 1 1 1 0 ZONE3 MENU
0100 1 11010 0 0 0 1 0 0 1 1 1 0 ZONE3 VOLUME MUTE
1010 0 00101 0 0 1 0 1 1 1 1 0 0 STATUS REQUEST(for 2way RC)
1110 0 01101 0 0 1 0 0 1 1 0 0 0 ZONE3 NET/USB
0101 0 01101 0 0 1 0 0 1 0 0 1 1 ZONE3 XM
0011 0 01101 0 0 1 0 0 1 0 1 0 1 ZONE3 NET
1011 0 01101 0 0 1 0 0 1 1 1 0 1 ZONE3 iPod
0111 0 01101 0 0 1 0 0 1 0 0 0 1 ZONE3 USB
0011 1 01101 0 0 0 0 0 1 0 1 0 1 ZONE3 DVD/HDP
1111 1 01101 0 0 0 0 0 1 1 0 0 1 ZONE3 VCR/DVR
0011 1 10111 0 0 0 1 1 1 1 1 0 1 ZONE3 REPEAT
1011 1 10111 0 0 0 1 1 1 0 1 0 1 ZONE3 RANDOM/SHUFFLE
0111 1 10111 0 0 0 1 1 1 1 0 0 1 ZONE3 USB DIRECT PLAY
1111 1 10111 0 0 0 1 1 1 0 0 0 1 ZONE3 FAVORITE DIRECT PLAY
0011 0 01111 0 0 1 0 0 1 1 1 0 1 ZONE3 PRESET CH UP
1011 0 01111 0 0 1 0 0 1 0 1 0 1 ZONE3 PRESET CH DOWN
0111 0 01111 0 0 1 0 0 1 1 0 0 1 ZONE3 PRESET CH SHIFT
1110 1 01111 0 0 0 0 0 1 0 0 0 0 ZONE3 SEARCH(RDS)
0000 0 11111 0 0 1 1 0 1 1 1 1 0 ZONE3 PLAY/PAUSE
1000 0 11111 0 0 1 1 0 1 0 1 1 0 ZONE3 STOP
1 1 0 0 0 1 1111 0 0 1 1 010 0 1 0 ZONE3 SKIP MINUS/TUNING DOWN
1 0 1 0
0 0 10 0 11111 0 0 1 1 0 1 1 1 0 0 ZONE3 SKIP PLUS/TUNING UP

2007/07/06
16/21
REMOTE ID SET : 2-4
K4-6 : ZONE3
GENRE2 Data ID parity
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Key Name
1010 0 00000 * * * * * * * * * * ZONE3 POWER ON/OFF
0110 0 00000 * * * * * * * * * * ZONE3 POWER ON
1110 0 00000 * * * * * * * * * * ZONE3 POWER OFF
1101 1 00000 * * * * * * * * * * ZONE3 CURSOR UP
0011 1 00000 * * * * * * * * * * ZONE3 CURSOR DOWN
1011 1 00000 * * * * * * * * * * ZONE3 CURSOR LEFT
0111 1 00000 * * * * * * * * * * ZONE3 CURSOR RIGHT
1111 1 00000 * * * * * * * * * * ZONE3 ENTER
0100 0 10000 * * * * * * * * * * ZONE3 RETURN
1100 0 10000 * * * * * * * * * * ZONE3 MENU
0100 1 11010 * * * * * * * * * * ZONE3 VOLUME MUTE
0010 1 11010 * * * * * * * * * * ZONE3 VOL PRESET 1(0dB)
1010 1 11010 * * * * * * * * * * ZONE3 VOL PRESET 2(-20dB)
0110 1 11010 * * * * * * * * * * ZONE3 VOL PRESET 3(-40dB)
1010 0 00101 * * * * * * * * * * STATUS REQUEST(for 2way RC)
0000 0 01101 * * * * * * * * * * ZONE3 PHONO
1000 0 01101 * * * * * * * * * * ZONE3 TUNER
0100 0 01101 * * * * * * * * * * ZONE3 CD
1110 0 01101 * * * * * * * * * * ZONE3 NET/USB
0101 0 01101 * * * * * * * * * * ZONE3 XM
0011 0 01101 * * * * * * * * * * ZONE3 NET
1011 0 01101 * * * * * * * * * * ZONE3 iPod
0111 0 01101 * * * * * * * * * * ZONE3 USB
0000 1 01101 * * * * * * * * * * ZONE3 DVD
1000 1 01101 * * * * * * * * * * ZONE3 HDP
0100 1 01101 * * * * * * * * * * ZONE3 TV/CBL
1100 1 01101 * * * * * * * * * * ZONE3 SAT
1010 1 01101 * * * * * * * * * * ZONE3 VCR
0110 1 01101 * * * * * * * * * * ZONE3 DVR
1001 1 01101 * * * * * * * * * * ZONE3 V.AUX
1111 1 01101 * * * * * * * * * * ZONE3 VCR/DVR
0011 1 10111 * * * * * * * * * * ZONE3 REPEAT
1011 1 10111 * * * * * * * * * * ZONE3 RANDOM/SHUFFLE
0111 1 10111 * * * * * * * * * * ZONE3 USB DIRECT PLAY
1111 1 10111 * * * * * * * * * * ZONE3 FAVORITE DIRECT PLAY
0011 0 01111 * * * * * * * * * * ZONE3 PRESET CH UP
1011 0 01111 * * * * * * * * * * ZONE3 PRESET CH DOWN
0111 0 01111 * * * * * * * * * * ZONE3 PRESET CH SHIFT
1110 1 01111 * * * * * * * * * * ZONE3 SEARCH(RDS)
0000 0 11111 * * * * * * * * * * ZONE3 PLAY/PAUSE
1000 0 11111 * * * * * * * * * * ZONE3 STOP
1 1 00 0 11111 * * * * * * * * * * ZONE3 SKIP MINUS/TUNING DOWN
0 1 1 0
0 0 10 0 11111 * *** * * * * * * ZONE3 SKIP PLUS/TUNING UP

2007/07/06
17/21
ANALOG TUNER
ＤＥＮＯＮ CODE Parity GENRE1
４５２３ ０ 4
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
001010 1 001 0 0 1 1 0 0 0 0 0 0 0010
REMOTE ID SET : 1
K4-1 : ANALOG TUNER
GENRE2 Data ID parity
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Key Name
1 0 0 1 1 0 0 1 0 0 0 0 1 1 0 1 1 0 1 1 BAND FM1 0 0 0
0 1 0 1 1 0 0 1 0 0 0 0 1 1 0 1 0 1 1 1 BAND AM
REMOTE ID SET : 2-4
K4-2 : ANALOG TUNER
GENRE2 Data ID parity
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Key Name
0 0 0 0 1 0 0 1 0 0 * * * * * * * * * * TUNING UP
1 0 0 0 1 0 0 1 0 0 * * * * * * * * * * TUNING DOWN
0 1 0 0 1 0 0 1 0 0 * * * * * * * * * * PRESET CH UP
1 1 0 0 1 0 0 1 0 0 * * * * * * * * * * PRESET CH DOWN
0 0 1 0 1 0 0 1 0 0 * * * * * * * * * * PRESET CH SHIFT
0 0 0 1 1 0 0 1 0 0 * * * * * * * * * * BAND FM/AM
1 0 0 1 1 0 0 1 0 0 * * * * * * * * * * BAND FM
0 1 0 1 1 0 0 1 0 0 * * * * * * * * * * BAND AM
0 0 1 1 1 0 0 1 0 0 * * * * * * * * * * MODE AUTO/MANUAL
0 0 0 0 0 1 0 1 0 0 * * * * * * * * * * MEMORY
1 1 0 0 0 1 0 1 0 0 * * * * * * * * * * RDS/SEARCH
0 1 1 0 0 1 0 1 0 0 * * * * * * * * * * RT
1 0 0 1 0 1 0 1 0 0 * * * * * * * * * * PTY
0000 1 10100* * * * * * * * * * PRESET 1
1000 1 10100* * * * * * * * * * PRESET 2
0100 1 10100* * * * * * * * * * PRESET 3
1100 1 10100* * * * * * * * * * PRESET 4
0010 1 10100* * * * * * * * * * PRESET 5
1010 1 10100* * * * * * * * * * PRESET 6
0110 1 10100* * * * * * * * * * PRESET 7
1110 1 10100* * * * * * * * * * PRESET 8
0 0 0 1 1 1 1 1 0 0 * * * * * * * * * * SHIFT A
1 0 0 1 1 1 1 1 0 0 * * * * * * * * * * SHIFT B
0 1 0 1 1 1 1 1 0 0 * * * * * * * * * * SHIFT C
1 1 0 1 1 1 1 1 0 0 * * * * * * * * * * SHIFT D
0 0 1 1 1 1 1 1 0 0 * * * * * * * * * * SHIFT E
1 0 1 1 1 1 1 1 0 0 * * * * * * * * * * SHIFT F
0 1 0 0
0 1 1 1 1 1 1 1 0 0 * * * * * * * * * * SHIFT G

2007/07/06
18/21
NET AUDIO
ＤＥＮＯＮ CODE Parity GENRE1
４５２３ ０ 4
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
001010 1 001 0 0 1 1 0 0 0 0 0 0 0010
REMOTE ID SET : 1
K4-7 : NET AUDIO
GENRE2 Data ID parity
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Key Name
1101 1 00000 0 0 0 1 1 0 1 1 1 1 CURSOR UP
0011 1 00000 0 0 0 1 1 0 0 0 0 1 CURSOR DOWN
1011 1 00000 0 0 0 1 1 0 1 0 0 1 CURSOR LEFT
0111 1 00000 0 0 0 1 1 0 0 1 0 1 CURSOR RIGHT
1111 1 00000 0 0 0 1 1 0 1 1 0 1 ENTER
0100 1 00100 0 0 0 1 1 1 0 1 1 0 PRESET CH UP
1100 1 00100 0 0 0 1 1 1 1 1 1 0 PRESET CH DOWN
0010 1 00100 0 0 0 1 1 1 0 0 0 0 PRESET CH SHIFT
0000 0 10100 0 0 1 0 1 1 0 0 1 0 MEMORY
1100 0 10100 0 0 1 0 1 1 1 1 1 0 PAGE SEARCH/CHARA SEARCH
0000 1 10100 0 0 0 0 1 1 0 0 1 0 PRESET 1
1000 1 10100 0 0 0 0 1 1 1 0 1 0 PRESET 2
0100 1 10100 0 0 0 0 1 1 0 1 1 0 PRESET 3
1100 1 10100 0 0 0 0 1 1 1 1 1 0 PRESET 4
0010 1 10100 0 0 0 0 1 1 0 0 0 0 PRESET 5
1010 1 10100 0 0 0 0 1 1 1 0 0 0 PRESET 6
0110 1 10100 0 0 0 0 1 1 0 1 0 0 PRESET 7
1110 1 10100 0 0 0 0 1 1 1 1 0 0 PRESET 8
0001 1 11100 0 0 0 0 0 1 0 0 1 1 SHIFT A
1001 1 11100 0 0 0 0 0 1 1 0 1 1 SHIFT B
0101 1 11100 0 0 0 0 0 1 0 1 1 1 SHIFT C
1101 1 11100 0 0 0 0 0 1 1 1 1 1 SHIFT D
0011 1 11100 0 0 0 0 0 1 0 0 0 1 SHIFT E
1011 1 11100 0 0 0 0 0 1 1 0 0 1 SHIFT F
0111 1 11100 0 0 0 0 0 1 0 1 0 1 SHIFT G
1010 0 00011 0 0 1 1 1 0 0 1 0 0 PLAY
0110 0 00011 0 0 1 1 1 0 1 0 0 0 PAUSE
1110 0 00011 0 0 1 1 1 0 0 0 0 0 STOP
0001 0 00011 0 0 1 1 1 0 1 1 1 1 SKIP PLUS
1001 0 00011 0 0 1 1 1 0 0 1 1 1 SKIP MINUS
0101 0 00011 0 0 1 1 1 0 1 0 1 1 REPEAT ONE
1101 0 00011 0 0 1 1 1 0 0 0 1 1 REPEAT OFF
0011 0 00011 0 0 1 1 1 0 1 1 0 1 RANDOM ON
1011 0 00011 0 0 1 1 1 0 0 1 0 1 RANDOM OFF
1000 1 00011 0 0 0 1 1 0 0 1 1 0 REPEAT ALL
1 1 1 0
0110 1 00011 0 0 0 1 1 0 1 0 0 0 STATUS REQUEST(for 2way RC)

2007/07/06
19/21
REMOTE ID SET : 2-4
K4-8 : NET AUDIO
GENRE2 Data ID parity
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Key Name
1101 1 00000 * * * * * * * * * * CURSOR UP
0011 1 00000 * * * * * * * * * * CURSOR DOWN
1011 1 00000 * * * * * * * * * * CURSOR LEFT
0111 1 00000 * * * * * * * * * * CURSOR RIGHT
1111 1 00000 * * * * * * * * * * ENTER
0100 1 00100 * * * * * * * * * * PRESET CH UP
1100 1 00100 * * * * * * * * * * PRESET CH DOWN
0010 1 00100 * * * * * * * * * * PRESET CH SHIFT
0000 0 10100 * * * * * * * * * * MEMORY
1100 0 10100 * * * * * * * * * * PAGE SEARCH/CHARACTER SEARCH
0000 1 10100 * * * * * * * * * * PRESET 1
1000 1 10100 * * * * * * * * * * PRESET 2
0100 1 10100 * * * * * * * * * * PRESET 3
1100 1 10100 * * * * * * * * * * PRESET 4
0010 1 10100 * * * * * * * * * * PRESET 5
1010 1 10100 * * * * * * * * * * PRESET 6
0110 1 10100 * * * * * * * * * * PRESET 7
1110 1 10100 * * * * * * * * * * PRESET 8
0001 1 11100 * * * * * * * * * * SHIFT A
1001 1 11100 * * * * * * * * * * SHIFT B
0101 1 11100 * * * * * * * * * * SHIFT C
1101 1 11100 * * * * * * * * * * SHIFT D
0011 1 11100 * * * * * * * * * * SHIFT E
1011 1 11100 * * * * * * * * * * SHIFT F
0111 1 11100 * * * * * * * * * * SHIFT G
1010 0 00011 * * * * * * * * * * PLAY
0110 0 00011 * * * * * * * * * * PAUSE
1110 0 00011 * * * * * * * * * * STOP
0001 0 00011 * * * * * * * * * * SKIP PLUS
1001 0 00011 * * * * * * * * * * SKIP MINUS
0101 0 00011 * * * * * * * * * * REPEAT ONE
1101 0 00011 * * * * * * * * * * REPEAT OFF
0011 0 00011 * * * * * * * * * * RANDOM ON
1011 0 00011 * * * * * * * * * * RANDOM OFF
1000 1 00011 * * * * * * * * * * REPEAT ALL
0 0 0 1
0110 1 00011 * * * * * * * * * * STATUS REQUEST(for 2way RC)

2007/07/06
20/21
iPod
ＤＥＮＯＮ CODE Parity GENRE1
４５２３ ０ 2
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
001010 1 001 0 0 1 1 0 0 0 0 0 0 0100
REMOTE ID SET : 1-4
K2-3 : iPod
GENRE2 Data ID parity
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Key Name
1000 0 00000 * * * * * * * * * * PLAY/PAUSE
0010 0 00000 * * * * * * * * * * SKIP PLUS
1010 0 00000 * * * * * * * * * * SKIP MINUS
0001 0 00000 * * * * * * * * * * STOP
0000 1 00000 * * * * * * * * * * REPEAT
1000 1 00000 * * * * * * * * * * SHUFFLE
1010 1 00000 * * * * * * * * * * MANUAL SEARCH PLUS
0110 1 00000 * * * * * * * * * * MANUAL SEARCH MINUS
1110 1 00000 * * * * * * * * * * MENU(iPod)
0001 1 00000 * * * * * * * * * * ENTER
1001 1 00000 * * * * * * * * * * CURSOR UP
0101 1 00000 * * * * * * * * * * CURSOR DOWN
1101 1 00000 * * * * * * * * * * CURSOR LEFT
0011 1 00000 * * * * * * * * * * CURSO RIGHT
1111 1 00000 * * * * * * * * * * STATUS REQUEST(for 2way RC)
0100 0 10000 * * * * * * * * * * PAGE SEARCH
1100 0 10000 * * * * * * * * * * RETURN
0111 0 10000 * * * * * * * * * * BROWSE MODE
1111 0 10000 * * * * * * * * * * REMOTE MODE
0000 0 01000 * * * * * * * * * * SHUFFLE SONGS
1000 0 01000 * * * * * * * * * * SHUFFLE ALBUMS
0100 0 01000 * * * * * * * * * * SHUFFLE OFF
1100 0 01000 * * * * * * * * * * REPEAT ONE
0 010 0 01000 * * * * * * * * * * REPEAT ALL
1 1 0 0
1010 0 01000 * * * * * * * * * * REPEAT OFF
