Denon AVR-2308 User manual

AVR-2308CI
AV Surround Receiver
New model information
A/V Surround Receiver featuring HD Video connectivity,
that enhances your level of entertainment enjoyment.
The Latest HD Video Su ort
• HDMI1.3a inputs/output
• HDMI audio support, Dolby Digital, dts and multi channel PCM
• Deep Color up to 36-bit and xvYCC broader color space support
• Discrete devices for ultimate HD video performance in each block
• Faroudja DCDi Processing up to 1080p from analog sources
• 10-bit video encoder and decoder
• Analog to HDMI up conversion
• 1080p video pass through
MultEQ Auto setu and Room EQ
• New tower type microphone for more
accurate measuring
• Up to six measurement points
• High level resolution filters for satellite
speakers and also subwoofer
Denon Design Solutions for Maximizing Content Quality
• Indentical quality and power for all 7 channels, 100W x 7ch
• Discrete devices for ultimate performance in each block
• New 32-bit floating point DSP
• Minimum signal path design
• Direct Mechanical Ground for stable drive
• Separate unit design
Digital Media Connectivity
• Network Audio/Photo Ready (optional ASD-3N/3W)
• iPod Audio/Photo and Video playback
(optional ASD-1R/3N/3W)
• XM Ready
Com ressed Audio Restorer
Denon's new audio technology for MP3/WMA/AAC compressed audio
formats to reproduce higher frequency range and deeper bass sound.
Ease-of-Use
• Auto set-up and Room EQ, featuring MultEQ from Audyssey
• 3 Quick Select Buttons
• New back panel layout
Multi-Zone Ca ability
• Two Zone multi-source capability
• Zone 2 audio output
• Power amplifier assign for zone 2
• Includes dedicated zone remote control unit
• Remote in/out
• + 12V, 150 mA Trigger output
• RS-232C control
• Optional RC-7000CI/7001RCI 2way control ready
Bullet points
*Shown ASD-3W
*Optional RC-7000CI and RC-7001RCI
*Setup mic included

16940707 A
Denon Brand Company
D&M Building, 2-1 Nisshin-cho, awasaki-ku, awasaki-shi,
anagawa, 210-8569, Japan
www.denon.com
HDMI
Component
S-Video
Composite
Analog audio (Tuner included)
Analog EXT. Input
Digital OPTICAL
Digital COAXIAL
Dock control for iPod
2
3
5
5
9
7.1ch
3
3
1
HDMI Monitor
Component Monitor
S-Video REC
Monitor
Composite REC
Monitor
Analog audio REC
Zone 2
Analog Preout
Digital OPTICAL
Trigger +12V, 150mA
RS-232C
Remote In/Out
1
1
2
1
2
1
2
1
1
1
1
1
1/1
IN OUT
Others
Input / Output terminals Specifications
Power Amplifier Section
Rated output *THD figures are power amp stage values.
Front 100 W + 100 W (8 ohms, 20Hz - 20kHz)
Center 100 W (8 ohms, 20Hz - 20kHz)
Surround 100 W + 100 W (8 ohms, 20Hz - 20kHz)
Surround back 100 W + 100 W (8 ohms, 20Hz - 20kHz)
Preamplifier Section
Input sensitivity/impedance
PHONO(MM) 2.5 mV/47 kohms
Audio inputs 200 mV/47 kohms
Output level/Load impedance
Audio outputs 1.2 V/10 kohms
Rec. Audio outputs 200 mV/47 kohms
FM Section
Tuning frequency range 87.5 - 107.9 MHz
Usable sensitivity 1.0 µV (11.2 dBf)
AM Section
Tuning frequency range 520 - 1710 kHz
Usable sensitivity 18 µV
General
Power supply AC 120 V, 60 Hz
Dimensions (WxHxD) 434 x 171 x 420 mm
17-3/32” x 6-47/64” x 16-17/32”
Weight 12.6 kg, 27.7 lbs
• Design and specifications are subject to change without notice.
• Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.
• DTS is a registered trademark & the DTS logos and symbol are trademarks of DTS, Inc.
• ”DCDi™” is a trademark of Faroudja, a division of Genesis Microchip Inc.
• Audyssey MultEQ is a trademark of Audyssey Laboratories. MultEQ and the Audyssey MultEQ logo are trademarks of Audyssey Laboratories, Inc.
• ©2007 XM Satellite Radio Inc. All rights reserved.
Other Features
• Auto Surround Back Channels ON function, for auto-detection of
supporting sources
• Auto Surround mode
•Audio Delay function (max. 6 frames or 200 msec)
•Night Mode for neighbor friendly listening
•Muting level settings (Full/-40dB/-20dB)
• Audio Level Memory, capable of correcting different signal levels for each
input device
• Volume Level Limiter, for setting maximum volume levels
• Power-ON Volume Level Memory
•Variable subwoofer crossover switching
