AVR-X4500H
INTEGRATED NETWORK AV RECEIVER
Owner’s Manual
Contents Connections Playback Settings Tips Appendix
1
Front panel Display Rear panel Remote Index

Accessories 8
Inserting the batteries 9
Operating range of the remote control unit 9
Features 10
High quality sound 10
High performance 13
Easy operation 17
Part names and functions 18
Front panel 18
Display 22
Rear panel 24
Remote control unit 28
Connections
Speaker installation 32
Connecting speakers 40
Before connecting speakers 40
Speaker configuration and “Amp Assign” settings 44
Connecting 5.1-channel speakers 46
Connecting 7.1-channel speakers 47
Connecting 9.1-channel speakers 51
Connecting 11.1-channel speakers 59
Connecting 7.1-channel speakers: Bi-amp connection of front
speakers 65
Connecting 7.1-channel speakers: Second pair of front speakers 66
Connecting multi-zone speakers 67
Connecting a TV 72
Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel) / eARC
(Enhanced Audio Return Channel) 73
Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel) / eARC
(Enhanced Audio Return Channel) 75
Connection 3 : TV equipped without an HDMI connector 76
Connecting a playback device 77
Connecting a set-top box (Satellite tuner/cable TV) 78
Connecting a DVD player or Blu-ray Disc player 79
Connecting a Blu-ray Disc player compatible with the Denon Link
HD function 80
Connecting a video camcorder or game console 81
Connecting a turntable 82
Connecting a USB memory device to the USB port 83
Connecting an FM/AM antenna 84
Connecting to a home network (LAN) 86
Wired LAN 86
Wireless LAN 87
Connecting an external control device 88
REMOTE CONTROL jacks 88
TRIGGER OUT jacks 89
Connecting the power cord 90
Contents Connections Playback Settings Tips Appendix
2
Front panel Display Rear panel Remote Index

Playback
Basic operation 92
Turning the power on 92
Selecting the input source 92
Adjusting the volume 93
Turning off the sound temporarily (Muting) 93
Playback a DVD player/Blu-ray Disc player 93
Playing a USB memory device 94
Playing files stored on USB memory devices 95
Listening to music on a Bluetooth device 98
Playing music from Bluetooth device 99
Pairing with other Bluetooth devices 101
Reconnecting to this unit from a Bluetooth device 102
Listening to FM/AM broadcasts 103
Listening to FM/AM broadcasts 104
Tuning in by entering the frequency (Direct Tune) 106
RDS Search 106
PTY Search 107
TP Search 108
Radio text 108
Changing the tune mode (Tune Mode) 109
Tuning in to stations and presetting them automatically (Auto
Preset Memory) 109
Presetting the current broadcast station (Preset Memory) 110
Listening to preset stations 110
Specify a name for the preset broadcast station (Preset Name) 111
Skipping preset broadcast stations (Preset Skip) 112
Cancelling Preset Skip 113
Listening to Internet Radio 114
Listening to Internet Radio 115
Playing back files stored on a PC or NAS 116
Playing back files stored on a PC or NAS 117
Contents Connections Playback Settings Tips Appendix
3
Front panel Display Rear panel Remote Index

Getting the HEOS App 120
HEOS Account 121
Playing from streaming music services 122
Listening to the same music in multiple rooms 125
AirPlay function 129
Playing songs from your iPhone, iPod touch or iPad 130
Playing iTunes music with this unit 130
Perform iTunes playback operations with the remote control unit
of this unit 131
Play a song from your iPhone, iPod touch or iPad on multiple
synced devices (AirPlay 2) 132
Spotify Connect function 133
Playing Spotify music with this unit 133
Convenience functions 134
Adding to HEOS Favorites 135
Playing back HEOS Favorites 135
Deleting a HEOS Favorites 136
Adjusting the volume of each channel to match the input source
(Channel Level Adjust) 137
Adjusting the tone (Tone) 138
Displaying your desired video during audio playback (Video
Select) 139
Adjusting the picture quality for your viewing environment (Picture
Mode) 140
Playing the same music in all zones (All Zone Stereo) 141
Selecting a sound mode 142
Selecting a sound mode 143
Direct playback 144
Pure Direct playback 145
Auto surround playback 145
Description of sound mode types 146
Sound mode that can be selected for each input signal 150
HDMI Control function 154
Setting procedure 154
Smart Menu function 155
Sleep timer function 157
Using the sleep timer 158
Quick select plus function 159
Calling up the settings 160
Changing the settings 161
Panel lock function 162
Disabling all key button operations 162
Disabling all button operations except VOLUME 162
Canceling the Panel lock function 163
Contents Connections Playback Settings Tips Appendix
4
Front panel Display Rear panel Remote Index

Remote lock function 164
Disabling the sensor function of the remote control unit 164
Enabling the remote sensor function 164
Web control function 165
Controlling the unit from a web control 165
Playback in ZONE2/ZONE3 (Another room) 167
Connecting ZONE 167
Playback in ZONE2/ZONE3 173
Settings
Menu map 175
Menu operations 179
Audio 180
Center Level Adjust 180
Subwoofer Level Adjust 180
Bass Sync 181
Surround Parameter 181
Restorer 187
Audio Delay 188
Volume 189
Audyssey®190
Graphic EQ 193
Video 195
Picture Adjust 195
HDMI Setup 197
Output Settings 202
Component Video Out 206
On Screen Display 206
4K Signal Format 207
TV Format 209
Inputs 210
Input Assign 210
Source Rename 212
Hide Sources 212
Source Level 213
Input Select 213
Contents Connections Playback Settings Tips Appendix
5
Front panel Display Rear panel Remote Index

Speakers 214
Audyssey® Setup 214
Procedure for speaker settings (Audyssey® Setup) 216
Error messages 222
Retrieving Audyssey® Setup settings 224
Manual Setup 225
Amp Assign 225
Speaker Config. 233
Distances 238
Levels 239
Crossovers 240
Bass 241
Front Speaker 242
2ch Playback 242
Network 245
Information 245
Connection 245
Wi-Fi Setup 246
Settings 248
Network Control 250
Friendly Name 250
Diagnostics 251
HEOS Account 252
You have not signed in 252
You have already signed in 252
General 253
Language 253
ECO 253
ZONE2 Setup / ZONE3 Setup 257
Zone Rename 259
Quick Select Names 259
Trigger Out 1 / Trigger Out 2 260
Front Display 260
Firmware 261
Information 264
Usage Data 265
Save & Load 266
Setup Lock 266
Reset 267
Operating external devices with the remote control unit 268
Registering preset codes 269
Operating devices 272
Initializing registered preset codes 275
Specifying the operating zone with the remote control 275
Resetting the remote control unit 275
Contents Connections Playback Settings Tips Appendix
6
Front panel Display Rear panel Remote Index

Tips
Tips 277
Troubleshooting 279
Power does not turn on / Power is turned off 280
Operations cannot be performed through the remote control unit 281
Display on this unit shows nothing 281
No sound comes out 282
Desired sound does not come out 283
Sound is interrupted or noise occurs 286
No video is shown on the TV 287
The menu screen is not displayed on the TV 289
The color of the menu screen and operations content displayed
on the television is different from normal 289
AirPlay cannot be played back 290
USB memory devices cannot be played back 291
Bluetooth cannot be played back 292
The Internet radio cannot be played back 293
Music files on PC or NAS cannot be played back 294
Various online services cannot be played 295
The HDMI Control function does not work 295
Cannot connect to a wireless LAN network 296
When using HDMI ZONE2, the devices does not function properly 297
Update/upgrade error messages 298
Resetting factory settings 299
Resetting network settings 300
Appendix
About HDMI 301
Video conversion function 304
Playing back a USB memory devices 306
Playing back a Bluetooth device 307
Playing back a file saved on a PC or NAS 308
Playing back Internet Radio 309
Personal memory plus function 309
Last function memory 309
Sound modes and channel output 310
Sound modes and surround parameters 312
Types of input signals, and corresponding sound modes 315
Explanation of terms 318
Trademark information 327
Specifications 330
Index 336
Contents Connections Playback Settings Tips Appendix
7
Front panel Display Rear panel Remote Index

Thank you for purchasing this Denon product.
To ensure proper operation, please read this owner’s manual carefully before using the product.
After reading this manual, be sure to keep it for future reference.
Accessories
Check that the following parts are supplied with the product.
.
Quick Start Guide Safety Instructions Cautions on Using Batteries Notes on radio Cable labels
Sound calibration
microphone stand
Sound calibration
microphone
AM loop antenna
FM indoor antenna
Power cord
Remote control unit
(RC-1219)
R6P/AA batteries External antennas for
Bluetooth/wireless
connectivity
Contents Connections Playback Settings Tips Appendix
8
Front panel Display Rear panel Remote Index

Inserting the batteries
1Slide the rear cover off the remote control unit in the
arrow direction.
.
2Insert two batteries correctly into the battery
compartment as indicated.
.
Batteries
3Put the rear cover back on.
NOTE
0To prevent damage or leakage of battery fluid:
0Do not use a new battery together with an old one.
0Do not use two different types of batteries.
0Remove the batteries from the remote control unit if it will not be in use for long
periods.
0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
30° 30°
Approx. 7 m
Contents Connections Playback Settings Tips Appendix
9
Front panel Display Rear panel Remote Index

Features
High quality sound
0With discrete circuit technology, the power amplifier provides
identical quality for all 9-channels (165 Watts x 9-channels)
For optimum realism and stunning dynamic range, the power amplifier
section features discrete power devices (not integrated circuitry).
By using high current, high power discrete power devices, the amplifier
is able to easily drive high quality speakers.
0Dolby Atmos (v p. 319)
This unit is equipped with a decoder that supports Dolby Atmos audio
format. The placement or movement of sound is accurately reproduced
by the addition of overhead speakers, enabling you to experience an
incredibly natural and realistic surround sound field.
0DTS:X (v p. 322)
This unit is equipped with the DTS:X decoder technology. DTS:X brings
the home theater experience to new heights with its immersive object
based audio technology which removes the bounds of channels. The
flexibility of objects allows for sound to be scaled large or small and
moved around the room with greater accuracy than ever before leading
to a richer immersive audio experience.
0DTS Virtual:X (v p. 322)
DTS Virtual:X technology features DTS’s proprietary virtual height and
virtual surround processing to deliver an immersive sound experience
from any type of input source (stereo to 7.1.4 channel) and speaker
configuration.
zDTS Virtual:X is not for use when Height speakers are connected.
0Audyssey LFC™ (Low Frequency Containment) (v p. 192)
Audyssey LFC™ solves the problem of low frequency sounds
disturbing people in neighboring rooms or apartments. Audyssey
LFC™ dynamically monitors the audio content and removes the low
frequencies that pass through walls, floors and ceilings. It then applies
psychoacoustic processing to restore the perception of low bass for
listeners in the room. The result is great sound that no longer disturbs
the neighbors.
0Discrete subwoofers and Audyssey Sub EQ HT™ (v p. 215)
The unit has two subwoofer output capability and can adjust the level
and delay for each subwoofer individually.
Audyssey Sub EQ HT™ makes the integration seamless by first
compensating for any level and delay differences between the two
subwoofers and then applying Audyssey MultEQ® XT32 to both
subwoofers together for improved deep bass response and detail.
Contents Connections Playback Settings Tips Appendix
10
Front panel Display Rear panel Remote Index

0Denon’s unique high quality playback technology “Denon Link
HD” (v p. 326)
This unit is equipped with our exclusive “Denon Link HD” technology.
When connected to a Denon disc player that has Denon Link HD, the
sound localization becomes more precise, with increased detail and
definition. The system works by carrying the critical clock timing signals
via the dedicated Denon Link HD connection, minimizing the jitter
caused by conventional digital connections. This effect can be applied
to an audio source of any media from a Blu-ray Disc player.
Contents Connections Playback Settings Tips Appendix
11
Front panel Display Rear panel Remote Index

0Auro-3D
This unit is equipped with an Auro-3D decoder.
With Auro-3D, Front Height (FHL + FHR), Surround Height (SHL + SHR) and Top Surround (TS/optional) are added to a conventional 5.1-channel
system to achieve a natural and realistic sound field that is three-dimensional and fully immersive.
You will be able to fully enjoy Auro-3D playback if you properly place the speakers for Auro-3D.
2 Auro-3D playback
.
FHL FHR
SHL SHR
TS
FL FR
SW
SL SR
C
2 Dolby Atmos playback
.
FHL FHR
SHL SHR
TS
FL FR
SW
SL SR
C
0Auro-3D does not support a Dolby Atmos configuration using Top Front, Top Middle or Top Rear speakers.
But it is possible to support both an Auro-3D and Dolby Atmos by adding Front Height and Rear Height speakers* to a 5.1 configuration.
zFor an optimum Auro-3D experience Surround Height speakers are strongly recommended.
Contents Connections Playback Settings Tips Appendix
12
Front panel Display Rear panel Remote Index

High performance
04K 60Hz input/output supported
.
When 4K Ultra HD (High Definition) is used, an input/output speed of 60
frames per second (60p) is achieved for video signals. When connected
to 4K Ultra HD and 60p video signal input compatible TV, you can enjoy
the sense of realism only available from high-definition images, even
when viewing fast-moving video.
This unit also supports image processing for 4K 60p, 4:4:4 and 24-bit
videos. By processing the video at the original resolution, this unit lets
you enjoy flawless, high-definition picture quality.
This unit also supports HDR (High Dynamic Range) and BT.2020 wide
color gamut.
0HDCP 2.2
This unit is compatible with HDCP 2.2 copyright protection standard.
0Digital video processor upscales analog video signals (SD
resolution) to HD (720p/1080p) and 4K (v p. 204)
.
4K
Up scaling
Up to 1080p
This unit is equipped with a 4K video upscaling function that allows
analog video or SD (Standard Definition) video to be output via HDMI at
4K (3840 × 2160 pixels) resolution. This function enables the device to
be connected to a TV using a single HDMI cable, and produces high
definition images for any video source.
0Equipped with HDMI ZONE2 output (v p. 167)
The ZONE2 multi-room output includes an HDMI output that lets you
enjoy a different A/V source in that room, with another program playing
in the main room.
Contents Connections Playback Settings Tips Appendix
13
Front panel Display Rear panel Remote Index

0HDMI connections enable connection to various digital AV
devices (8 inputs, 3 outputs)
.
83
OutIn
For connection to a broad range of digital sources, this unit features 8
HDMI inputs, including 1 on the front panel that lets you quickly and
conveniently connect a camcorder, game console or other HDMI-
equipped device. There are dual HDMI outputs for the main room, and a
third HDMI output for another room.
0eARC (Enhanced Audio Return Channel) function compatibility
The eARC function is compatible with conventional ARC function-
compatible audio formats in addition to multichannel linear PCM, Dolby
TrueHD, Dolby Atmos, DTS-HD Master Audio, DTS:X and other audio
formats a conventional ARC function cannot transmit.
Additionally, connecting to an eARC function-compatible television
enables enjoyment of higher-quality surround playback of the audio
content played from your television.
0The device is equipped with a AirPlay® function in addition to
network functions such as Internet radio etc. (v p. 129)
.
You can enjoy a wide variety of content, including listening to Internet
Radio, playing audio files stored on your PC.
This unit also supports Apple AirPlay which lets you stream your music
library from an iPhone®, iPad®, iPod touch® or iTunes®.
0Supports AirPlay 2® wireless audio
Sync multiple AirPlay 2 compatible devices/speakers for simultaneous
playback.
This unit supports AirPlay 2 and requires iOS 11.4 or later.
Contents Connections Playback Settings Tips Appendix
14
Front panel Display Rear panel Remote Index

0Playback of DSD and FLAC files via USB and networks
This unit supports the playback of high resolution audio formats such as
DSD (5.6 MHz) and FLAC 192 kHz files. It provides high quality
playback of high resolution files.
0Wireless connection with Bluetooth devices can be carried out
easily (v p. 98)
.
You can enjoy music simply by connecting wirelessly with your
smartphone, tablet, PC, etc.
0Multi-Room audio (v p. 141)
.
【MAIN ZONE】【ZONE2】/【ZONE3】
You can select and play back the respective inputs in MAIN ZONE,
ZONE2 and ZONE3.
In addition, when the All Zone Stereo function is used, the music being
played back in MAIN ZONE can be enjoyed in all the zones at the same
time. This is useful when you want to let the BGM propagate throughout
the whole house.
0Energy-saving design
This unit is equipped with an ECO Mode function that allows you to
enjoy music and movies while reducing the power consumption during
use, and also an auto-standby function that automatically turns off the
power supply when the unit is not in use. This helps reduce
unnecessary power use.
Contents Connections Playback Settings Tips Appendix
15
Front panel Display Rear panel Remote Index

0Compatible with the “Denon 2016 AVR Remote” Appz for
performing basic operations of the unit with an iPad, iPhone or
Android™ devices (Google, Amazon Kindle Fire)
.
Along with many new features, the graphics and user interface have
been completely overhauled. The new app gives you full control of the
AVR as well as access to its setup menu for detailed adjustments from
your phones or tablets. “Denon 2016 AVR Remote” App also gives you
quick access to the receiver's status display, option menus, Denon Blu-
ray Disc player control, and online owner's manual for your
convenience.
zDownload the appropriate “Denon 2016 AVR Remote” App for your iOS or
Android devices. This unit needs to be connected to the same LAN or Wi-Fi
(wireless LAN) network that the iPhone or iPod touch is connected to.
0HEOS provides streaming music from your favorite online music
sources
.
HEOS wireless multi-room sound system that enables you to enjoy your
favorite music anywhere and everywhere around your home. By utilizing
your existing home network and the HEOS App (available for iOS,
Android and Amazon devices), you can explore, browse, and play
music from your own music library or from many online streaming music
services.
When multiple HEOS devices are connected to the same network,
HEOS devices can be grouped to play back the same music on all
devices simultaneously, or different music can be played on each
separate HEOS device.
Contents Connections Playback Settings Tips Appendix
16
Front panel Display Rear panel Remote Index

Easy operation
0“Setup Assistant” provides easy-to-follow setup instructions
First select the language when prompted. Then simply follow the
instructions displayed on the TV screen to set up the speakers, network,
etc.
0Easy to use Graphical User Interface
This unit is equipped with a Graphical User Interface for improved
operability.
Contents Connections Playback Settings Tips Appendix
17
Front panel Display Rear panel Remote Index

Part names and functions
Front panel
.
wq re yt
u
For details, see the next page.
Contents Connections Playback Settings Tips Appendix
18
Front panel Display Rear panel Remote Index

.
wq reyt
u
APower operation button (X)
Used to turn the power of the MAIN ZONE (room where this unit is
located) on/off (standby). (v p. 92)
BPower indicator
This is lit as follows according to the power status:
0Green: Power on
0Off: Normal standby
0Red:
0When “HDMI Pass Through” is set to “On” (v p. 197)
0When “HDMI Control” is set to “On” (v p. 199)
0When “Network Control” is set to “Always On” (v p. 250)
CSOURCE SELECT knob
This selects the input source. (v p. 92)
DRemote control sensor
This receives signals from the remote control unit. (v p. 9)
EDisplay
This displays various pieces of information. (v p. 22)
FMASTER VOLUME knob
This adjusts the volume level. (v p. 93)
GDoor
When you are using buttons and/or connectors behind the door, press
the bottom of the door to open it. Be careful not to catch your fingers
when closing the door.
.
Contents Connections Playback Settings Tips Appendix
19
Front panel Display Rear panel Remote Index

With the door open
.
io Q0qw r t y ue
AZONE2 ON/OFF button
This turns the power of ZONE2 (another room) on/off. (v p. 173)
BZONE2 SOURCE button
This selects the input source for ZONE2. (v p. 173)
CZONE3 ON/OFF button
This turns the power of ZONE3 (another room) on/off. (v p. 173)
DZONE3 SOURCE button
This selects the input source for ZONE3. (v p. 173)
ESTATUS button
Each press of this switches the status information that is shown on the
display.
FInformation button (INFO)
This displays the status information on the TV screen. (v p. 265)
GCursor buttons (uio p)
These select items.
HOPTION button
This displays the option menu on the TV screen.
IDIMMER button
Each press of this switches the brightness of the display. (v p. 260)
JQUICK SELECT buttons
With a single press of any of these buttons, you can call up various
settings you’ve registered to each button such as the input source,
volume level and sound mode settings. (v p. 159)
Contents Connections Playback Settings Tips Appendix
20
Front panel Display Rear panel Remote Index
