Thank you for choosing a Denon AV receiver.
This guide provides step-by-step instructions for setting up your
AV receiver.
Welcome Before You Begin
• When connecting this unit to a device that is compatible with the Deep Color,
4K, ARC and eARC functions, use a “High Speed HDMI cable with Ethernet”
that displays the HDMI logo.
• When connecting this unit to a device that is compatible with the 8K and 4K
120Hz video, use a “Ultra High Speed 48 Gbps HDMI cable” that displays the
HDMI logo.
• These drawings are for illustrative purposes only and may not represent the
actual product(s).
TV Speaker cables
HDMI cable Subwoofer cable Speakers
Required for Setup
Optional
Check our
AVR setup tips online
Usa.denon.com/SetupTips
Ca.Denon.com/SetupTips
Call for Assistance
1-855-MY.DENON (USA)
1-855-693-3666
1-800-668-0652 (Canada)
Monday – Friday
10:00AM to 10:00PM E.S.T
Saturday
12:00PM to 8:00PM E.S.T
Please do not return this unit to the store.
If you need help…
LAN cable Wi-Fi router
or
1. AVR-A110E3_QSG_ENG_00A_200714.indd 11. AVR-A110E3_QSG_ENG_00A_200714.indd 1 2020/07/14 16:05:092020/07/14 16:05:09
Printing Color : Black

2
EN
FR
ES
What’s In the Box
Quick Start Guide FM indoor antenna
Safety Instructions AM loop antenna
Notes on radio Sound calibration
microphone
Warranty
(for North America
model only)
Sound calibration
microphone stand
Cable labels Remote control unit
(RC-1221)
Receiver LR6/AA batteries
Power cord
External antennas for
Bluetooth /wireless
connectivity
• The included sound calibration microphone stand is convenient for
use when performing Speaker Calibration. Using your own tripod or
the supplied Sound calibration microphone stand enables settings
to be automatically configured to the optimum listening environment,
providing exceptionally high performance.
1. AVR-A110E3_QSG_ENG_00A_200714.indd 21. AVR-A110E3_QSG_ENG_00A_200714.indd 2 2020/07/14 16:05:102020/07/14 16:05:10
Printing Color : Black

3
Important: External Antennas
The removable external antennas are required for both Bluetooth and
Wireless network connectivity. Please make sure to connect the antennas
before attempting to use the Bluetooth or Wi-Fi features of the AVR-A110.
2Connecting the external antennas for
Bluetooth / Wireless connectivity
For each of the two antennas:
qPlace the antenna evenly over the antenna terminal located at the upper
left or right corner of the rear panel.
wTurn the antenna clockwise until it is fully connected. Do not over
tighten.
eRotate the antenna upwards for the best possible reception.
q w e
1. AVR-A110E3_QSG_ENG_00A_200714.indd 31. AVR-A110E3_QSG_ENG_00A_200714.indd 3 2020/07/14 16:05:102020/07/14 16:05:10
Printing Color : Black

4
EN
FR
ES
Setup
There are four steps to the setup process.
Batteries
1Install batteries in the
remote control unit
1Install batteries in the remote control unit
2Connecting the receiver
3Following the On-Screen Setup Assistant
4Downloading the Mobile Apps
1. AVR-A110E3_QSG_ENG_00A_200714.indd 41. AVR-A110E3_QSG_ENG_00A_200714.indd 4 2020/07/14 16:05:102020/07/14 16:05:10
Printing Color : Black

5
2Connecting the receiver
1Place the receiver near your TV and connect
the power cord
TV
Receiver
Power cord
(supplied)
Connect to household
power outlet
(AC 120 V, 60 Hz)
1. AVR-A110E3_QSG_ENG_00A_200714.indd 51. AVR-A110E3_QSG_ENG_00A_200714.indd 5 2020/07/14 16:05:112020/07/14 16:05:11
Printing Color : Black

6
EN
FR
ES
2Connect the receiver to your home network
Wired LAN
Connect an Ethernet cable (not included) between your receiver and
your network router.
Router
To LAN port
Wireless LAN
When connecting to wireless LAN (Wi-Fi), follow the instructions in
“Connecting the external antennas for Bluetooth / Wireless connectivity”
and connect the antennas.
1. AVR-A110E3_QSG_ENG_00A_200714.indd 61. AVR-A110E3_QSG_ENG_00A_200714.indd 6 2020/07/14 16:05:122020/07/14 16:05:12
Printing Color : Black

7
3Connect the receiver to your TV with an HDMI cable
(ARC/eARC)
HDMI IN
HDMI OUT
MONITOR 1
(ARC/eARC)
HDMI cable
Receiver (Rear panel)
ARC (Audio Return Channel) and eARC (Enhanced Audio Return
Channel) support:
If your TV supports ARC, your TV can send audio back to the AV receiver
when you are using your TV’s built-in video sources (TV tuner, Smart TV
streaming services, etc.) ARC requires that you enable HDMI CEC on your
TV. Please refer to your TV’s Owner’s Manual for instructions on how to
setup HDMI CEC. In addition, if your TV supports eARC, it can also send
back high bitrate audio formats such as Dolby TrueHD, Dolby Atmos,
DTS-HD Master Audio and DTS:X. Please refer to your TV’s Owner’s
Manual for additional information about enabling the eARC function.
1. AVR-A110E3_QSG_ENG_00A_200714.indd 71. AVR-A110E3_QSG_ENG_00A_200714.indd 7 2020/07/14 16:05:122020/07/14 16:05:12
Printing Color : Black

8
EN
FR
ES
4Turn on the TV
TV remote control unit
5Select the appropriate HDMI input on your TV
or TV/
VIDEO
INPUT
TV remote control unit
HDMI
1. AVR-A110E3_QSG_ENG_00A_200714.indd 81. AVR-A110E3_QSG_ENG_00A_200714.indd 8 2020/07/14 16:05:132020/07/14 16:05:13
Printing Color : Black

9
6Turn on the receiver
Press Xto turn on the receiver.
7Verify the connection
Verify that you can see this screen on your TV.
AV Receiver Setup Assistant
Please select a language...
Español
Français
English
If this screen is not displayed, please go back and retry the steps
again in the recommended sequence.
1. AVR-A110E3_QSG_ENG_00A_200714.indd 91. AVR-A110E3_QSG_ENG_00A_200714.indd 9 2020/07/14 16:05:132020/07/14 16:05:13
Printing Color : Black

10
EN
FR
ES
3Following the On-Screen Setup Assistant
Now TV is connected to the receiver.
The Setup Assistant will walk you through connecting and
configuring your speakers and components to your Denon
receiver. Please use the remote control and follow the
on-screen instructions.
AV Receiver Setup Assistant
Please select a language...
Español
Français
English
1. AVR-A110E3_QSG_ENG_00A_200714.indd 101. AVR-A110E3_QSG_ENG_00A_200714.indd 10 2020/07/14 16:05:132020/07/14 16:05:13
Printing Color : Black

11
4Downloading the Mobile Apps
Download both the “HEOS” App and the “Denon 2016 AVR Remote”
App for the full home entertainment experience.
The HEOS App is required to access online music through your AVR.
The HEOS App allows you to explore, browse, and play music from
many online streaming services or from your own music library.
HEOS Denon 2016
AVR Remote
Control your new AVR with the latest Denon 2016 AVR Remote
App. Volume control, sound mode selection and advanced
settings are always only a tap away.
1. AVR-A110E3_QSG_ENG_00A_200714.indd 111. AVR-A110E3_QSG_ENG_00A_200714.indd 11 2020/07/14 16:05:132020/07/14 16:05:13
Printing Color : Black

12
EN
FR
ES
Online Manual
Refer to the Online Manual for other functions information and operation
procedure details.
manuals.denon.com/AVRA110/NA/EN/
