Derpras DPMB168 User manual

Derpras
Derpras
E-mail:[email protected]
DPMB168
Enjoy a wonderful life
DERPRAS

1
Product features:
• LED digital display,show water temperature and bath time.
• Led you easy to select the best water temperature.
• No electricity,no battery.Powered by water flow.
• The led lights automatically while water flows down.
• 304 Stainless Steel mixer valve (3-in-1 diverter + hot/cold control).
LED working water pressure requirements:
• More than 29Psi or 2.0Bar.
Materials:
• 304 Stainless Steel,hand shower(ABS,4 inch),overhead shower(ABS,8 inch)
Flow rate:
• Limited to 2.5 gpm (9.5 L/min) at 80 psi or 5.52 Bar
Quality warranty:
• 5 years for faucet body,18 months for LED parts.
NOTES:
• Shower system installation is a professional job.If you don't have installation experience,please
find help from professional plumbers.
• Before installation, flush the water supply pipes thoroughly to remove debris.Flush for at least
three minutes.Switch off main shut-off valve before installation.
• Especially please put the Thread Sealant Tape(comes with the product) around all threads when
installation. Please ensure place the filter screens (come with the product) in the cold & hot water
inlets of the main body when installation.
• In the premise of water pressure greater than 29Psi, if you find the LED display does not work, It
is possible that there are impurities inside the pipes blocking the water flow. Please following the
video link to clear the impurities:
https://youtu.be/WMyg4WHwdyc
After you have done above cleaning, if the led display still can't work, please contact us for help.
• Whether you encounter any problems, such as leakage, parts damaged, device can't work
properly, etc, we will help you to solve these problems without dismantling the device. What you
need to do is "contact us at [email protected]"

2
7.87''(200mm)
13''(330mm)
7.09''(180mm) Φ=5.91''(150mm)
33.9''(860mm)--46.1''(1170mm) 6.06''(154mm)
31.9''(810mm)
6.22''(810mm)
G1/2
7.87''(200mm)
INSTALLATION DIMENSION

3
email to
[email protected]
Any questions please email to [email protected]
Tools
Thread seal tape

4
16
10 10 1714
3
1
7
5
2
9
4
8
1315
Package includes:
304 304
Derpras
6
11 11
1212

5
16
17
14
3
1
7
5
2
9
4
8
1315
Overall layout：
6
DERPRAS
12
10
12
11
11
10
304
304

6
Installation notes:
• Before installation, flush the water supply pipes thoroughly to remove debris.
Flush for at least 3 minutes.Switch off main shut-off valve before installation.
• Especially please put the Thread Sealant Tape(comes with the products) around all threads when
installation. Ensure place the filter screens (11) in the cold & hot water inlets of the main body.
Normally,before delivery,(11) had been placed in the two water inlets of (5),if you find the (11) is
already in the inlets of (5),you don't need to place them again.
• After installation, keep all remaining accessories and this manual, they will be used in the daily
cleaning and maintenance.
Installation video link:
• https://youtu.be/iqIFDYl2urw
Installation steps:
• Please prepare the hot and cold water inlets on the wall. (Normally, the left is hot water inlet, the
right is the cold water inlet,if opposite, does not affect the normal use, you can continue to install.)
• Connect the two screw nuts (12) to the hot & cold water inlets pre-prepared in the wall. Adjust the
distance between centers of two screw nuts (12) to 5.91inch (150mm).
• Screw the two decorative bases (10) to the two screw nuts (12).
• Install the main body (5).Adjust the two inlets of main body (5) to match the two screw nuts (12)
pre-prepared. Screw the main body (5) to the two screw nuts (12). (Make sure place the filter
screens (11). Normally, before delivery，(11) had been placed in the two water inlets of (5) ).
12
12
10
304 304
304
304
5
4
DERPRAS
10
12
11
11
10
304
304

7
3
• Connect the shower pipe(3) to the main pole(16) and screw them together.
• Confirm the position of the fixing rod (14),and install the fixing rod (14).
First,try to connect the main pole(16) to the main body(5),but do not tighten completely.
(Note:Make sure place the (4)),Second,try to place the fixing rod (14) to fix the main pole,
and confirm the position of the fixing rod (14).Third, remove the main pole(16) and install the fixing
rod (14).
16
16
14
5
4
1315
DERPRAS

8
1
2
9
8
• Install the overhead shower(1) and the handheld shower(9).(Make sure place the 2,8 and 6)
• Install the main pole(16) and fix the main ploe(16).
First ,again,connect the main pole(16) to the main body(5),but do not tighten completely.
(Note:Make sure place the (4)).Second, docking the main pole(16) to the fixing rod (14).
Third,tighten the main pole(16) to the main body(5) and tighten the two screws of fixing rod (14) to
fix the main pole(16).
16
17
14
5
4
6
DERPRAS

9
CLEANING INSTRUCTIONS:
• Clean the finish with mild soap and warm water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc,which
could adversely affect the finish and are not recommended for cleaning. Do not use abrasive
cleaners or solvents on Derpras faucets and fittings.
• In the premise of water pressure greater than 29Psi, if you find the LED display does not work or
the water flow becomes very small,please following the video link to clear the impurities:
https://youtu.be/WMyg4WHwdyc
• Please remember that：Whether you encounter any problems during use, we can solve them for
you, you don’t need to dismantle the device. What you need to do is "contact us at
[email protected]".
