Save this manual for future reference.
®
WARNING: If the information in this manual is not fol-
lowed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s in-
structions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency, or the gas supplier.
WARNING:Improperinstallation,
adjustment, alteration, service,
ormaintenancecancauseinjury
orpropertydamage.Refertothis
manual for correct installation
andoperational procedures.For
assistance or additional infor-
mation consult a qualified in-
staller, service agency, or the
gas supplier.
WARNING: This is an unvented
gas-fired heater. It uses air (oxy-
gen) from the room in which it is
installed.Provisionsforadequate
combustion and ventilation air
mustbeprovided.Referto Airfor
CombustionandVentilation sec-
tion on page 4 of this manual.
This appliance may be installed in an aftermarket* manufactured (mobile) home, where not prohibited by
state or local codes.
*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
DESA INTERNATIONAL
UNVENTED (VENT-FREE)
PROPANE/LP GAS FIREPLACE
Variable Manually-
Controlled "A" Models
and
Thermostatically-
Controlled
“C” Models
with
Split Oak Logs
OWNER’S OPERATION AND INSTALLATION MANUAL

2
104410
UNVENTED PROPANE/LP GAS FIREPLACE
DESA INTERNATIONAL
1. This appliance is only for use with the
typeof gas indicatedon therating plate.
Thisappliance isnotconvertibleforuse
with other gases.
2. Do notplace propane/LPsupply tank(s)
inside any structure. Locate propane/
LP supply tank(s) outdoors.
SAFETY
INFORMATION
DANGER: Carbon monoxide
poisoning may lead to death!
Carbon Monoxide Poisoning: Early
signs of carbon monoxide poisoning re-
sembletheflu,withheadaches,dizziness,or
nausea.Ifyouhavethesesigns,thefireplace
may not be working properly. Get fresh air
at once! Have fireplace serviced. Some
people are more affected by carbon monox-
ide than others. These include pregnant
women,people with heartor lungdisease or
anemia, those under the influence of alco-
hol, and those at high altitudes.
Propane/LP Gas:Propane/LP gas is odor-
less.Anodor-makingagentisaddedtothegas.
Theodorhelpsyoudetectagasleak.However,
theodoraddedtothegascanfade.Gasmaybe
present even though no odor exists.
Make certain you read and understand all
Warnings.Keepthismanualforreference.It
isyourguide tosafe andproperoperation of
this fireplace.
WARNINGICON G001 WARNINGS
IMPORTANT: Read this owner’s
manual carefully and completely
before trying to assemble, oper-
ate, or service this fireplace. Im-
proper use of this fireplace can
causeseriousinjuryordeathfrom
burns, fire, explosion, electrical
shock, and carbon monoxide
poisoning.
WARNING:Anychangetothis
fireplace or its controls can be
dangerous.
3. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touch any electrical switch; do
not use any phone in your building
• immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions
• ifyoucannot reachyour gassupplier,
call the fire department
4. This fireplace shall not be installed in
a bedroom or bathroom.
5. Never install the fireplace
• in a recreational vehicle
• wherecurtains, furniture, clothing,or
otherflammableobjects areless than
42inchesfrom thefront, top, orsides
of the fireplace
• in high traffic areas
• in windy or drafty areas
6. Do not use this fireplace as a wood-
burning fireplace. Use only the logs
provided with the fireplace.
7. Do not add extra logs or ornaments
suchaspine cones,vermiculite, or rock
wool. Using these added items can
cause sooting. Do not add lava rock
aroundbase.Rock anddebris could fall
into the control area of fireplace.
8. Youmustoperate thisfireplace withthe
fireplace screen and hood in place.
Make sure fireplace screen and hood
are in place before running fireplace.
9. This fireplace is designed to be smoke-
less. If logs ever appear to smoke, turn
off fireplace and call a qualified ser-
vice person. Note: During initial op-
eration,slightsmoking couldoccur due
to log curing and fireplace burning
manufacturing residues.
10. To prevent the creation of soot, follow
the instructions in Cleaning and Main-
tenance, page 21.
11. Donotallowfanstoblowdirectlyintothe
fireplace.Avoidanydraftsthatalterburner
flame patterns. Ceiling fans can create
drafts that alter burner flame patterns.Al-
tered burner patterns can cause sooting.
12. Before usingfurniture polish, wax,car-
pet cleaner, or similar products, turn
heater off. If heated, the vapors from
theseproductsmay createa white pow-
der residue within burner box or on
adjacent walls or furniture.
13. Do not use a blower insert, heat ex-
changer insert, fireplace hood or other
accessorynot approvedfor usewith this
heater.
14. This fireplace needs fresh air ventila-
tion to run properly. This fireplace has
an oxygen depletion sensor (ODS) pi-
lot light safety system. The ODS shuts
down the fireplace if not enough fresh
air is available. See Air for Combus-
tion and Ventilation, pages 4 through
6. If fireplace keeps shutting off, see
Troubleshooting, pages 22 through 24.
15. Do not run fireplace
• where flammable liquids or vapors
are used or stored
• under dusty conditions
16. Do not use this fireplace to cook food
or burn paper or other objects.
17. Neverplaceany objectsin the fireplace
or on logs.
18. Fireplace front and screen becomes
very hot when running fireplace. Keep
children and adults away from hot sur-
faces to avoid burns or clothing igni-
tion. Fireplace will remain hot for a
time after shutdown.Allow surfaces to
cool before touching.
19. Carefully supervise young children
whentheyareintheroom withfireplace.
20. Do notuse fireplaceif anyparthasbeen
exposedtoor underwater. Immediately
call a qualified service technician to
inspect the fireplace and to replace any
part of the control system and any gas
control which has been under water.
21. Do not operate fireplace if any log is
broken. Do not operate fireplace if a
log is chipped (dime-sized or larger).
22. Turn fireplace off and let cool before
servicing. Only a qualified service per-
son should service and repair fireplace.
23. Operating fireplaceabove elevations of
4,500 feet could cause pilot outage.
24. To prevent performance problems, do
not use propane/LP fuel tanks of less
than 100 lbs. capacity.

3
104410
OWNER’S MANUAL
PRODUCT
IDENTIFICATION
Figure 1 - Log Base Assembly, Split Oak Set
Front Log
Rear Log
Base Assembly
Front
Burner
Rear
Burner
Crossover Log
Figure 2 - Fireplace
Top Louver
Assembly
Fireplace
Hood
Bottom Louver
Assembly
Screen
Assembly
Top Outer
Casing
Firebox
Support
Blower Assembly
(Models VSGF28PTC and
CSG28PTC Only, Optional
for Model VSGF28PVA)
LOCAL CODES
Install and use fireplace with care. Follow all
localcodes.In theabsence oflocalcodes, use
the latest edition of The National Fuel Gas
CodeANSZ223.1,also knownas NFPA 54*.
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
UNPACKING
1. With utility knife, cut the carton all the
way around above the staples on the
bottom tray. Lift the carton off the
heater. Remove packing. Note: The
hood is located in the packing on the
right hand side of the heater front. Lift
the heater off the bottom tray.
2. Locate two screws above top corners
of the fireplace screen. Remove and
discard these screws. Lift fireplace
screen up and pull out to remove.
3. Removeprotective packagingappliedto
logs, log base assembly, and fireplace.
4. Remove fireplace hood from carton
insert.
5. Check all items for any shipping dam-
age. If damaged, promptly inform
dealer where you bought fireplace.
Middle Log
WARNING: Do not remove
the metal data plates attached to
the heater base assembly. The
data plates contain important
warranty information.

4
104410
UNVENTED PROPANE/LP GAS FIREPLACE
DESA INTERNATIONAL
AIR FOR
COMBUSTION AND
VENTILATION
Today’s homes are built more energy effi-
cient than ever. New materials, increased
insulation, and new construction methods
helpreduceheatlossinhomes.Homeowners
weather strip and caulk around windows and
doorstokeepthecoldairoutandthewarmair
in. During heating months, home owners
want their homes as airtight as possible.
While it is good to make your home energy
efficient,yourhomeneedstobreathe.Fresh
air must enter your home. All fuel-burning
appliances need fresh air for proper com-
bustion and ventilation.
Exhaustfans,fireplaces,clothesdryers,and
fuel burning appliances draw air from the
house to operate. You must provide ad-
equate fresh air for these appliances. This
will insure proper venting of vented fuel-
burning appliances.
Confined Space and Unconfined
Space
The National Fuel Gas Code (ANS Z223.1,
1992 Section 5.3) defines a confined space
as a space whose volume is less than 50
cubicfeetper1,000Btuperhour(4.8m3per
kw) of the aggregate input rating of all
appliances installed in that space and an
unconfined space as a space whose volume
is not less than 50 cubic feet per 1,000 Btu
per hour (4.8 m3per kw) of the aggregate
inputratingofallappliancesinstalledinthat
space.Rooms communicatingdirectlywith
the space in which the appliances are in-
stalled*, through openings not furnished
with doors, are considered a part of the
unconfined space.
This heater shall not be installed in a con-
fined space or unusually tight construction
unlessprovisions areprovided foradequate
combustion and ventilation air.
*Adjoiningroomsarecommunicatingonly
iftherearedoorlesspassagewaysorventila-
tion grills between them.
PROVIDING ADEQUATE
VENTILATION
The following are excerpt from National
Fuel Gas Code. NFPA 54/ANS Z223.1, Sec-
tion5.3,AirforCombustionandVentilation.
Allspacesinhomesfallintooneofthethree
following ventilation classifications:
1. Unusually Tight Construction
2. Unconfined Space
3. Confined Space
The information on pages 4 through 6 will
help you classify your space and provide
adequate ventilation.
Unusually Tight Construction
The air that leaks around doors and win-
dowsmayprovideenoughfreshairforcom-
bustion and ventilation. However, in build-
ings of unusually tight construction, you
must provide additional fresh air.
PRODUCT
FEATURES
OPERATION
This vent-free fireplace is clean burning. It
requiresnooutsideventing.Thereisnoheat
loss out a vent or up a chimney. Heat is
generatedbybothrealisticflamesandglow-
ing embers. When used without the blower,
the fireplace requires no electricity making
it ideal for emergency backup heat.
SAFETY DEVICE
This fireplace has a pilot with an Oxygen
Detection Safety Pilot System (ODS). The
ODS/pilot is a required feature for vent-free
roomheaters. The ODSsystem shutsoff the
fireplace if there is not enough fresh air.
PIEZO IGNITION SYSTEM
This fireplace has a piezo ignitor. This sys-
tem requires no matches, batteries, or other
sources to light fireplace.
BLOWER ASSEMBLY
(VSGF28PTC/CSGF28PTC)
This fireplace has a blower assembly. The
blower operates thermostatically. The
blower circulates heated air from the
fireplace into the room. Use of blower is
optional. Optional blower accessories are
available for models VSGF28PVA.
THERMOSTAT CONTROL
MODELS
(VSGF28PTC/CSGF28PTC)
These fireplaces have a thermostat sensing
bulb and a control valve. The thermostat con-
trols the heat output and flame height. This
maintainsaconsistentroomtemperature.Even
thelowestsettingprovidesrealisticflamesand
glowing embers from two burners. Selecting
highercomfortsettingsallowsfireplacetorun
longer,producinggreaterheatoutput.Atlower
comfort settings, the fireplace will run less.
Thisresultsinincreasedheatingcomfort.This
can also result in lower gas bills.
VARIABLE MANUAL
CONTROL (VSGF28PVA)
These fireplaces have a variable manual
controlvalvewhichallowstheusertochoose
theheatsettingthatbestsuitshisneeds.Any
setting between low and high may be se-
lected by simply turning the control knob.
WARNING: This heater shall
notbeinstalledinaconfinedspace
or unusually tight construction
unless provisions are provided
foradequatecombustionandven-
tilation air. Read the following in-
structions to insure proper fresh
air for this and other fuel-burning
appliances in your home.
Unusually tight construction is de-
fined as construction where:
a. walls and ceilings exposed to the
outside atmosphere have a con-
tinuous water vapor retarder with
a rating of one perm (6 x 10-11 kg
per pa-sec-m2) or less with open-
ings gasketed or sealed and
b. weather stripping has been
added on openable windows and
doors and
c. caulking or sealants are applied
to areas such as joints around
window and door frames, be-
tween sole plates and floors,be-
tween wall-ceiling joints, be-
tween wall panels, at penetra-
tionsforplumbing,electrical,and
gas lines, and at other openings.
If your home meets all of the three
criteria above, you must provide ad-
ditional fresh air. See Ventilation Air
From Outdoors , page 6 .
If your home does not meet all of the
threecriteriaabove,proceedto Deter-
mining Fresh-Air Flow for Fireplace
Location on page 5.

5
104410
OWNER’S MANUAL
AIR FOR
COMBUSTION AND
VENTILATION
Continued
DETERMINING FRESH-AIR FLOW FOR FIREPLACE LOCATION
Determining if You Have a Confined or Unconfined Space
Use this work sheet to determine if you have a confined or unconfined space.
Space: Includes the room in which you will install fireplace plus any adjoining rooms with doorless passageways or ventilation grills
between the rooms.
1. Determine the volume of the space (length x width x height).
Length x Width x Height = _________________cu. ft. (volume of space)
Example: Space size 22 ft. (length) x 18 ft. (width) x 8 ft. (ceiling height) = 3168 cu. ft. (volume of space)
If additional ventilation to adjoining room is supplied with grills or openings, add the volume of these rooms to the total volume of
the space.
2. Divide the space volume by 50 cubic feet to determine the maximum Btu/Hr the space can support.
___________ (volume of space) ÷ 50 cu. ft. = (Maximum Btu/Hr the space can support)
Example: 3168 cu. ft. (volume of space) ÷ 50 cu. ft. = 63.3 or 63,300 (maximum Btu/Hr the space can support)
3. Add the Btu/Hr of all fuel burning appliances in the space.
Vent-free fireplace ____________________ Btu/Hr
Gas water heater* ____________________ Btu/Hr
Gas furnace ____________________ Btu/Hr
Vented gas heater ____________________ Btu/Hr
Gas fireplace logs ____________________ Btu/Hr
Other gas appliances* + ____________________ Btu/Hr
Total = ____________________ Btu/Hr
* Do not include direct-vent gas appliances. Direct-vent draws combustion air from the outdoors and vents to the outdoors.
4. Compare the maximum Btu/Hr the space can support with the actual amount of Btu/Hr used.
_________ Btu/Hr (maximum the space can support)
_________ Btu/Hr (actual amount of Btu/Hr used)
Example: 63,300 Btu/Hr (maximum the space can support)
68,000 Btu/Hr (actual amount of Btu/Hr used)
ThespaceintheaboveexampleisaconfinedspacebecausetheactualBtu/HrusedismorethanthemaximumBtu/Hrthespacecansupport.
You must provide additional fresh air. Your options are as follows:
A. Rework work sheet, adding the space of an adjoining room. If the extra space provides an unconfined space, remove door to adjoin-
ing room or add ventilation grills between rooms. See Ventilation Air from Inside Building, page 6.
B. Vent room directly to the outdoors. See Ventilation Air from Outdoors, page 6.
C. Install a lower Btu/Hr fireplace, if lower Btu/Hr size makes room unconfined.
If the actual Btu/Hr used is less than the maximum Btu/Hr the space can support, the space is an unconfined space. You will need no
additional fresh air ventilation.
Continued
WARNING:Iftheareainwhichtheheatermaybeoperatedissmallerthanthatdefinedasanunconfinedspace
or if the building is of unusually tight construction, provide adequate combustion and ventilation air by one of
the methods described in the National Fuel Gas Code, ANS Z223.1, 1992, Section 5.3 or applicable local codes.
Example:
Gas water heater 40,000 Btu/Hr
Vent-free fireplace +28,000 Btu/Hr
Total =68,000 Btu/Hr

6
104410
UNVENTED PROPANE/LP GAS FIREPLACE
DESA INTERNATIONAL
AIR FOR
COMBUSTION AND
VENTILATION
Continued
VENTILATION AIR
Ventilation Air From Inside
Building
Thisfreshairwouldcomefromanadjoining
unconfined space. When ventilating to an
adjoining unconfined space, you must pro-
vide two permanent openings: one within
12" of the ceiling and one within 12" of the
floor on the wall connecting the two spaces
(seeoptions1and2,Figure3).Youcanalso
remove door into adjoining room (see op-
tion 3, Figure 3). Follow the National Fuel
Gas Code NFPA 54/ANS Z223.1, Section
5.3, Air for Combustion and Ventilation for
required size of ventilation grills or ducts.
Figure 4 - Ventilation Air from Outdoors
Ventilation Air From Outdoors
Provide extra fresh air by using ventilation
grills or ducts. You must provide two per-
manent openings: one within 12" of the
ceiling and one within 12" of the floor.
Connecttheseitemsdirectlytotheoutdoors
orspacesopentotheoutdoors.Thesespaces
include attics and crawl spaces. Follow the
National Fuel Gas Code NFPA 54/ANS
Z223.1,Section5.3,AirforCombustionand
Ventilation for required size of ventilation
grills or ducts.
IMPORTANT: Do notprovide openingsfor
inlet or outlet air into attic if attic has a
thermostat-controlledpowervent.Heatedair
enteringtheatticwillactivatethepowervent.
Figure 3 - Ventilation Air from Inside Building
Outlet
Air Ventilated
Attic
Outlet
Air
Inlet
Air
Inlet Air Ventilated
Crawl Space
To
Crawl
Space
To Attic
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
¢¢¢¢¢¢
¢¢¢¢¢¢
¢¢¢¢¢¢
¢¢¢¢¢¢
¢¢¢¢¢¢
¢¢¢¢¢¢
¢¢¢¢¢¢
,,,,
,,,,
,,,,
,,,,
QQQQ
QQQQ
QQQQ
QQQQ
¢¢¢¢
¢¢¢¢
¢¢¢¢
¢¢¢¢
,,
,,
QQ
QQ
¢¢
¢¢
,,,,,
,,,,,
QQQQQ
QQQQQ
¢¢¢¢¢
¢¢¢¢¢
Or
Remove
Door into
Adjoining
Room,
Option
3
Ventilation Grills
Into Adjoining Room,
Option 2
Ventilation
Grills
Into Adjoining
Room,
Option 1
12"
12"
WARNING: Rework work-
sheet, adding the space of the
adjoiningunconfinedspace.The
combined spaces must have
enough fresh air to supply all
appliances in both spaces.

7
104410
OWNER’S MANUAL
INSTALLATION
Continued
Note: Your fireplaceisdesignedtobeused
inzeroclearanceinstallations.Wallorfram-
ing material can be placed directly against
anyexteriorsurfaceontherear,sides,ortop
of your fireplace, except where standoff
spacers are integrally attached. If standoff
spacers are attached to your fireplace, these
spacers can be placed directly against wall
or framing materials.
Use the dimensions shown for rough open-
ings to create the easiest installation (see
Built-In Fireplace Installation, page 13).
IMPORTANT: Vent-freeheatersaddmois-
ture to the air. Although this is beneficial,
installingfireplaceinroomswithoutenough
ventilation air may cause mildew to form
from too much moisture. See Air for Com-
bustion and Ventilation, pages 4 through 6.
IMPORTANT: Make sure the fireplace is
level.Iffireplaceisnotlevel,logsetwillnot
work properly.
CHECK GAS TYPE
Useonlypropane/LPgas.Ifyourgassupply
is not propane/LP gas, do not install fire-
place. Call dealer where you bought fire-
place for proper type fireplace.
CAUTION: This fireplace cre-
ateswarmaircurrents.Thesecur-
rents move heat to wall surfaces
next to fireplace. Installing fire-
place next to vinyl or cloth wall
coverings or operating fireplace
where impurities (such as to-
bacco smoke, aromatic candles,
cleaning fluids, oil or kerosene
lamps, etc.) in the air exist, may
discolor walls.
WARNING: A qualified ser-
vicepersonmustinstallfireplace.
Follow all local codes.
WARNING: Never install the
fireplace
• in a bedroom or bathroom
• in a recreational vehicle
• where curtains, furniture,
clothing, or other flammable
objectsarelessthan42inches
from the front, top, or sides of
the fireplace
• in high traffic areas
• in windy or drafty areas
WARNING:ModelsVSGF28PTC
/CSGF28PTChaveathree-prong,
grounded electrical plug. This
plug helps protect you against
electrical shock. Only connect
plug to a properly grounded,
three-prong receptacle. Do not
cut or remove the grounding
prong from this plug.
NOTICE: This heater is intended
for use as supplemental heat.
Use this heater along with your
primary heating system. Do not
install this heater as your pri-
mary heat source. If you have a
centralheating system,youmay
run system’s circulating blower
whileusingheater.This willhelp
circulatetheheatthroughoutthe
house. In the event of a power
outage, you can use this heater
as your primary heat source.
Figure 5 - Installing Hood
INSTALLING HOOD
Install hood to rail already installed in fire-
place as shown in Figure 5. Use 3 Phillips
screws provided.
Screw
Hood
Rail
ELECTRICAL HOOKUP
(Models VSGF28PTC/
CSGF28PTC )
Thisfireplacehasablowerassemblywithan
electricalcord.Theelectricalcordisfivefeet
in length. You must locate fireplace within
reach of a 120-volt grounded electrical out-
let.Ifnot,youmustinstallanelectricaloutlet
within reach of fireplace power cord. This
same information applies if installing op-
tional blower accessories to Model
VSGF28PVA.

8
104410
UNVENTED PROPANE/LP GAS FIREPLACE
DESA INTERNATIONAL
INSTALLATION
Continued
Figure 7 - Attaching Brass Trim to
Fireplace
Trim
Hanging
Screws
Assembled
Brass Trim
Hanging
Notches
on Trim
INSTALLING OPTIONAL
BLOWER ACCESSORY (FOR
MODEL VSGF28PVA)
The following instructions are for optional
bloweraccessoriesGA3700andGA3700T.
Ifyoudonothavethisaccessoryandwishto
purchase one, see Accessories on pages 26
and 27 of this manual.
2. Place the blower against lower rear wall
of firebox outer wrapper with the ex-
haust port directed upward. Align the
holes in top mounting tabs of blower
with holes in wall of wrapper (see Fig-
ure 9). Using 2 screws provided, mount
blower and tighten screws securely.
3. Be certain that all wire terminals are
securely attached to terminals on
blower motor and that the screw retain-
ing the green ground wire is tight.
4. Place control knob provided on plastic
control shaft of speed control.
5. Mount the speed control on the front
leg of the left floor support bracket us-
ing 2 screws provided (see Figure 10).
Figure 8 - Removing Log Base from
Fireplace
Figure 9 - Mounting Blower to Firebox
Figure 10 - Attaching Speed Control to
Firebox
Screws
Log Base
Blower
Screws
Screws Speed
Control
Control
Knob
Flexible
Gas Line
Left Floor
Support
Bracket
Control
Shaft
Lower
Rear Wall
of Firebox
Exhaust
Post
1. Remove screws that attach log base as-
semblytofireplace. Carefullylift up log
base assembly and remove from fire-
place,taking careto pullflexible gasline
through the access holes (see Figure 8) .
CAUTION: Do not pick up log
base assembly by burners. This
could damage burners. Only
handle base by grates.
Installing Optional GA3700
Blower Accessory
Figure 6 - Assembling Brass Trim
IMPORTANT: Ifyouarerecessingthefire-
boxina wall,do notattach brasstrimat this
time. See page 13.
Note: The instructions below show assem-
bling and attaching brass trim to fireplace.
1. Remove packaging from three pieces
of brass trim.
2. Locate four brass screws, two adjust-
ing plates with set screws, and two
shims in the hardware packet.
3. Align shim under adjusting plate as
shown in Figure 6.
4. Slide one end of adjusting plate/shim
insloton miterededge of topbrass trim
(see Figure 6).
5. Slide other end of adjusting plate/shim
in slot on mitered edge of side brass
trim (see Figure 6).
6. While firmly holding edges of brass
trim together, tighten both set screws
on the adjusting plate with slotted
screwdriver.
7. Repeat steps 1 through 6 for other side.
8. Tighten trim hanging screws (#10 x
6.25 shoulder) into holes in cabinets.
Placetheassembled trimonto fireplace
cabinet.Align hanging notches on trim
with hanging screws on side of fire-
place (see Figure 7). Push trim firmly
intoplace, sliding hangingnotches over
hanging screws.
ASSEMBLING AND
ATTACHING OPTIONAL
BRASS TRIM
(Included with Mantel
Accessory)
Side Brass
Trim
Top
Brass
Trim
Slot
Mitered Edge
Slot
Shim
Set Screws
Adjusting
Plate

9
104410
OWNER’S MANUAL
6. Plug in blower power cord.
a. Ifyourfireplacesystem isinstalled
as a freestanding unit with an ac-
cessory mantel, determine whether
the power cord will exit the left side
or the right side of the firebox. In-
stall 1 plastic bushing provided into
the 1.5" hole in the floor support
bracket on the exit side (see Figure
11). Install the second plastic bush-
ing provided into the 1.5" hole in the
outer casing through which the
power cord will exit. Route power
cord through both plastic bushings
and plug the power cord into a prop-
erly grounded 3-prong wall recep-
tacle near the firebox.
b.If your fireplace system installa-
tionisrecessed,plug the powercord
into a properly installed duplex out-
let. (If an outlet is not available, the
Vanguard accessory model GA3555
Outletkitwith/ covercan beinstalled
in your fireplace which will supply
a convenient 3-prong grounded elec-
trical outlet for your blower. Refer
to the installation manual provided
with the model GA3555 accessory
for instructions on wiring the duplex
outlet.)
7. Check tomake sure thatthe powercord
is completely clear of the blower wheel
and that there are no other foreign ob-
jects in blower wheel. Turn blower on
and check for operation. Turn blower
offby rotatingknob fullycounterclock-
wise before continuing.
WARNING: Never touch the
blower wheel while in operation.
8. Peel off the backing paper and stick the
suppliedwiringdiagramdecalonthefire-
box bottom approximately 3" to the right
of the blower speed control (Figure 12) .
Figure 11 - Installing Plastic Bushing for
Power Cord
Plastic
Bushing
Right Floor
Support
Bracket
Variable
FanSwitch
White
White Black
Green
On
110/115
V.A.C.
Blower
Motor
Black
Black
Black
Off
Figure12-LocationofWiringDiagramDecal
3" from Blower
Wiring
Diagram
WARNINGICON G 001
WARNING
Never attempt to service heater while it is plugged in,
operating, or hot. Burns and electrical shock could
result. Only a qualified service person should service
or repair heater.
If any of the original wire as supplied with the appliance must be
replaced, it must be replaced with 105°C wire or it’s equivalent.
101584-05
120 Vac. 60 Hz. . 78 Amps
DESA International, Bowling Green, KY
INSTALLATION
Continued
9. Replace logbase assembly infireplace.
Feed flexible gas supply line into fire-
placebase areawhile replacinglog base
assembly. Make sure the entire flexible
gas line is in fireplace base area.
Note: If firebrick is installed, make
sure the back of the firebox bottom
slides under the rear panel of the fire-
brick.(liftthe firebrickup ifnecessary.)
CAUTION: Do not pick up log
base assembly by burners. This
could damage burners. Only
handle base by grates.
Variable
Fan Switch
WhiteWhite Black
Green
On
110/115
V.A.C.
Blower
Motor
Black
Black Black
Off
10. Reattach logbase assembly tofireplace
with screws removed in step 1.
Note: Discardtheremaininghardwareitems.
WARNING:Failuretoposition
thepartsinaccordancewithsup-
plied diagrams or failure to use
only parts specifically approved
withthisheatermayresultindam-
age or personal injury.
Continued

10
104410
UNVENTED PROPANE/LP GAS FIREPLACE
DESA INTERNATIONAL
AUTO
OFF
ON
3
2
1
1. Remove screws that attach log base as-
sembly to fireplace (do not discard).
Carefully lift up log base assembly and
remove from fireplace, taking care to
pull flexible gas line through the ac-
cess holes (see Figure 13).
CAUTION: Do not pick up log
base assembly by burners. This
could damage burners. Only
handle base by grates.
2. Place theblower againstlower rearwall
of firebox outer wrapper with the ex-
haust port directed upward. Align the
holes in top mounting tabs of blower
with holes in wall of wrapper (see Fig-
ure 14). Using two #8 screws provided,
mount blower and tighten screws
firmly.
3. Route terminals end of power cord
through large hole near top of left floor
support bracket. Make sure to pass the
cordfrom theoutside (leftside) towards
the center of firebox (see Figure 15).
4. Using two #6 screws provided attach
power cord mounting plate to the out-
side face of left floor support bracket.
Drive screws from inside (right side)
of floor support bracket. Attach the
plate so that the power cord is directed
towards rear of firebox (see Figure 15).
Tighten screws firmly.
5. Remove the three screws (do not dis-
card) and cover plate from center of
firebox wrapper rear wall. Discard this
cover plate.
6. Mount thesupplied thermostaticswitch
and cover assembly into firebox wrap-
per wall. Do this by feeding terminal
ends of wire harness into the hole. Al-
low wires to fall to bottom of firebox
cavity (see Figure 16).
7. Using three screws from step 5, attach
switch and cover assembly to firebox
wrapper rear wall. Tighten screws
firmly (see Figure 16).
Figure 14 - Mounting Blower to Firebox
Figure 15 - Installing Power Cord,
Mounting Plate, and Selector switch
Figure 16 - Installing Switch and Cover
Assembly
Figure 13 - Removing Log Base from
Fireplace
8. Mount selector switch to front flange
of left floor support bracket. Align
graphics on switch upright and push
firmly to snap switch into rectangular
hole. Push the selector switch to the off
(middle) position (see Figure 15).
9. Install three plastic wire clips provided
intofloorsupport bracket(seeFigure15).
Securebypushing clipsfirmlyintoholes.
WARNING:Failuretoconnect
all wires properly as indicated
maycauseelectricalshortcircuit
or personal injury. A qualified
electrician should check that all
connections are made properly.
10. Attach green ground wire ring termi-
nal to floor support bracket using #10
sheet metal grounding screw provided
(see Figure 15). Tighten screw firmly.
11. Attach all five remaining wiring termi-
nals to the appropriate switch or motor
terminal. Carefully note the correct
color coding (see Figures 17 and 19,
page 11). Push female wire terminals
fully onto male terminal.
12. Secure wires into the appropriate plas-
tic wire clips (see Figure 17, page 11).
INSTALLATION
Continued
Installing Optional GA3700T
Blower Accessory
Screws
Log Base
Flexible
Gas Line
Blower
#8 Screws
Exhaust Port
Lower Rear
Wall of
Firebox Outer
Wrapper
#6 Screws #10 Screw
Wire
Clips
Selector
Switch
Switch and
Cover
Assembly
Floor Support Bracket

11
104410
OWNER’S MANUAL
AUTO
OFF
ON
3
2
1
Figure 17 - Wire Attachment
Figure 18 - Installing Bushings
Bushing Location
for Recessed
Installation
Bushing
Location for
Freestanding
Installation
Blue
Wire
Red Wire
Green
Wire
Black Wire
White
Wire
Blue
Wire
To Switch and
Cover Assembly
Note: To prevent short
circuit, white wire MUST
be connected to motor.
15. Peel off the backing paper and stick the
supplied wiring diagram decal on the
firebox bottom approximately 12" in
front of blower.
Note: If any of the original wire as supplied
with the appliance must be replaced, it must
bereplacedwith105˚Cwireorit'sequivalent.
WARNING: Failure to posi-
tion the parts in accordance with
supplied diagrams or failure to
use only parts specifically ap-
proved with this heater may re-
sultindamageorpersonalinjury.
Figure 19 - Wiring Diagram
BlueBlue
Fan Switch
(Off/On/Auto)
Red Fan
Switch
(N.O.)
Green
White
On
110/115
V.A.C.
Blower
Motor
Black
Off
1
23
Auto
INSTALLATION
Continued
16. Replace log base assembly in fireplace.
Feed flexible gas supply line into fire-
placebase area whilereplacing logbase
assembly. Make sure the entire flexible
gas line is in fireplace base area.
Note: If firebrickis installed,make sure
the back of the firebox bottom slides
undertherear panelof the firebrick(lift
the firebrick up if necessary.
IMPORTANT: Do not pick up
log base assembly by burners.
Thiscoulddamageburners.Only
handle base by grates.
17. Reattach log base assembly to fireplace
with screws removed in step 1, page 10.
Continued
13. Plug in blower power cord.
If your fireplace system is installed
as a freestanding unit with an acces-
sory mantel, install one plastic bush-
ing (provided) into the 1.5" hole in the
lower left side of the outer casing (see
Figure 18). Route power cord through
plastic bushing. Plug the power cord
into a properly grounded three-prong
wall receptacle near the firebox.
If your fireplace system installation
is recessed, install one plastic bushing
provided into the 1.5" hole near the
middle of the left floor support bracket
(see Figure 18). Route power cord
throughplastic bushing.Plugthepower
cord into a properly installed duplex
outlet. (If an outlet is not available, the
accessory model GA3555 Outlet Kit
with cover can be installed in your fire-
place. This will supply a convenient
three-prong grounded electrical outlet
for your blower. Refer to the installa-
tion manual provided with the model
GA3555 accessory for instructions on
wiring the duplex outlet.)
14. Check to make sure that the power cord
and wires are completely clear of the
blower wheel and that there are no other
foreign objects in blower wheel. Turn
bloweron bypushing theselectorswitch
to the on position and check for opera-
tion. Turn blower off before continuing.
WARNING: Never touch the
blower wheel while in operation.

12
104410
UNVENTED PROPANE/LP GAS FIREPLACE
DESA INTERNATIONAL
Figure 22 - Installing Cabinet Mantel
,,,,,
,,,,,
QQQQQ
QQQQQ
¢¢¢¢¢
¢¢¢¢¢
,,,,
,,,,
,,,,
,,,,
,,,,
QQQQ
QQQQ
QQQQ
QQQQ
QQQQ
¢¢¢¢
¢¢¢¢
¢¢¢¢
¢¢¢¢
¢¢¢¢
,,,,,
,,,,,
QQQQQ
QQQQQ
¢¢¢¢¢
¢¢¢¢¢
Electrical
Outlet
Hearth
Base Flexible
Gas Line
Gas
Line
Access
Hole
Cabinet
Mantel
5. Route flexible gas line through access
hole in hearth base.
6. Center cabinet mantel on hearth base
(see Figure 22). Make sure mantel is
flush against wall.
7. Break off nailing flanges (see Figure
23, page 13) with hammer or pliers.
8. Place cardboard or other protective
material on top of hearth base. Care-
fully set fireplace on protective mate-
rial, with back of fireplace inside man-
tel opening.
9. Attach flexible gas line to fireplace gas
regulator. See Connecting Fireplace to
Gas Supply, pages 14 and 15.
10. If bloweris installed, routeblower elec-
trical cord through access holes in ei-
ther side of fireplace. Note: Bushing
may be moved if necessary. Plug elec-
trical cord into electrical outlet.
11. Carefully insert fireplace into cabinet
mantel (see Figure 24, page 13). Be
careful not to scratch or damage hearth
base, cabinet mantel, or any laminate
trimonhearth base.Remove protective
material from top of hearth base and
from front of fireplace (if any). Note:
You can secure fireplace to hearth or
floor. Open lower louver. Locate screw
holes in bottom of base. Tighten wood
screws through these holes and into
hearth or floor.
12. Check allgas connectionsfor leaks.See
Checking Gas Connections, page 15.
INSTALLATION
CLEARANCES
WARNING:Maintainthemini-
mum clearances. If you can, pro-
vide greater clearances from
floor, ceiling, and adjoining wall.
Carefullyfollowtheinstructionsbelow.This
will ensure safe installation.
Minimum Wall and Ceiling
Clearances (see Figure 20)
A. Clearances from the side of the fire-
place opening to any combustible wall
should not be less than 16 inches for a
cabinet mantel or 12 inches for a cor-
ner installation.
B. Clearancesfromthe topof the fireplace
openingto theceilingshouldnotbe less
than 42 inches.
CONVENTIONAL FIREPLACE
INSTALLATION
Conventional installation of this fireplace in-
volves installing fireplace along with the cor-
ner or cabinet mantel with hearth base acces-
soriesagainst awallinyourhome(seeAcces-
sories, page 26 and 27). Follow these instruc-
tions to install fireplace in this manner.
1. Assemble cabinet mantel, hearth base,
andtrim accessories.Assemblyinstruc-
tions are included with each accessory.
2. When installing blower, install a prop-
erly grounded, 120 volt three-prong
electrical outlet at fireplace location if
an outlet is not there. If possible, lo-
cate outlet so cabinet mantel will cover
it when installed (see Figure 21).
3. Install gas piping to fireplace location.
This installation includes an approved
flexible gas line (if allowed by local
codes) after the manual shutoff valve.
The flexible gas line must be the last
iteminstalledon thegas piping. SeeIn-
stalling Gas Piping to Fireplace Loca-
tion, page 14.
4. Place hearth base accessory against
wall at installation location. Cut an ac-
cess hole in hearth top to run flexible
gas line to fireplace (see Figure 21).
Makesureto locateaccess holeso cabi-
net mantel will cover it when installed.
Note: You can secure base to floor us-
ing wood screws. Countersink screw
heads and putty over.
Figure 20 - Minimum Clearance to Wall
and Ceiling
INSTALLATION
Continued
,,,,,
,,,,,
,,,,,
,,,,,
,,,,,
QQQQQ
QQQQQ
QQQQQ
QQQQQ
QQQQQ
¢¢¢¢¢
¢¢¢¢¢
¢¢¢¢¢
¢¢¢¢¢
¢¢¢¢¢
42"
16"
Face or
Cabinet
Mantel
Corner
Mantel
12"
Note : Clearances
are the same if
using optional
cabinet mantel or
built-in installation.
Note: These instructions show installation
using the cabinet mantel and the
G3000F/G3001U/G3004W/G3006F/
G3007Userieshearthbaseaccessories.The
hearth base accessory shown is optional for
this installation. You can install fireplace
andcabinetmanteldirectlyonthefloor.The
cornermantel accessorycannot beinstalled
with the G3000F/G3001U/G3004W/
G3006F/G3007U hearth base. You must
installcorner manteldirectlyon thefloor.If
mounting fireplace and cabinet mantel to
thefloororusing cornermantel,anoptional
G3005 Slim Base kit may be installed.
Figure21-PlacingHearthBaseAccessory
Against Wall
MINIMUM
CLEARANCE
Side Wall - 16"
Cabinet Mantel
Ceiling - 42"
Corner Mantel
Floor - 0"

13
104410
OWNER’S MANUAL
INSTALLATION
Continued
Figure24-InsertingFireplaceIntoCabinet
Mantel
,,,,,
,,,,,
QQQQQ
QQQQQ
¢¢¢¢¢
¢¢¢¢¢
,,,
,,,
,,,
,,,
,,,
QQQ
QQQ
QQQ
QQQ
QQQ
¢¢¢
¢¢¢
¢¢¢
¢¢¢
¢¢¢
Figure 23 - Location of Nailing Flanges
Continued
Actual Framing
Height 32 3/8" 33"
Front Width 34 5/16" 35 1/2"
Depth 16 11/16" 17 3/4"
35 1/2"
17 3/4"
33"
Figure 25 - Rough Opening for Installing
in Wall
BUILT-IN FIREPLACE
INSTALLATION
Built-ininstallationofthisfireplaceinvolves
installing fireplace into a framed-in enclo-
sure. This makes the front of fireplace flush
with wall. If installing a mantel above the
fireplace, but you must follow the clear-
ances shown in Figure 28. Follow the in-
structions below to install the fireplace in
this manner.
Figure 27 - Attaching Fireplace to Wall
Studs
39 3/8" 27 7/8"
55 5/8"
35 1/2"
Figure 26 - Rough Opening for Installing
in Corner
1. Frame in rough opening. Use dimen-
sions shown in Figure 25 for the rough
opening.
If installing in a corner, use dimensions
shown in Figure 26 for the rough open-
ing.The heightis 33"which is thesame
as the wall opening above.
2. If using blower, install and properly
ground GA3555, three-prong 120- volt
electrical outlet, in fireplace. Follow
instructions included in kit.
3. Install gas piping to fireplace location.
This installation includes an approved
flexible gas line (if allowed by local
codes) after the manual shutoff valve.
The flexible gas line must be the last
iteminstalledon thegas piping. SeeIn-
stalling Gas Piping to Fireplace Loca-
tion, page 14.
4. Carefully set fireplace in front of rough
opening with back of fireplace inside
wall opening.
5. Attach flexible gas line to gas supply.
See Connecting Fireplace to Gas Sup-
ply, pages 14 and 15.
6. Plug electrical cord into electrical out-
let installed in step 2.
7. Carefully insert fireplace into rough
opening.
8. Attach fireplace to wall studs using
nails or wood screws through holes in
nailing flange (see Figure 27).
9. Check allgas connectionsfor leaks.See
Checking Gas Connections, page 15.
10. Install brass trim after final finishing
and/or painting of wall (see Figure 7,
page 8).
Mantel Clearances for Built-In
Installation
If placing mantel above built-in fireplace,
youmustmeetminimumclearancebetween
mantel shelf and top of fireplace opening.
If your installation does not meet the above
minimum clearances, you must:
• raise the mantel to an acceptable height,
OR
• remove the mantel.
Nailing Flanges
Nails or
Wood
Screws
Figure 28 - Minimum Mantel Clearances
for Built-In Installation
Mantel Shelf
13" 16" 19" 21"
2
1/2
"
6"
8"
10"
Note:
All Vertical
measurements
are from top of
fireplace
opening to
bottom of
mantel shelf.
Nailing
Flanges

14
104410
UNVENTED PROPANE/LP GAS FIREPLACE
DESA INTERNATIONAL
CAUTION: Do not pick up log
base assembly by burners. This
could damage burners. Only
handle base by grates.
Installation Items Needed
• 5/16" hex socket wrench or nut-driver
• Phillips screwdriver
• sealant (resistant to propane/LP gas, not
provided)
1. Remove fireplace screen. Remove two
screws that hold fireplace screen in
place for shipping. These screws are
located near top of screen. Discard
screws.Lift fireplacescreenupandpull
out to remove.
2. Remove screws that attach log base
assembly to fireplace (see Figure 31).
Carefully lift up log base assembly and
remove from fireplace (see Figure 31).
Note: Ifadding theG8000series brickliner
accessory, install it now. Follow instruc-
tions in G8000 accessory kit.
CONNECTING FIREPLACE
TO GAS SUPPLY
3. Route flexible gas line (provided by
installer) from manual shutoff valve to
fireplace.Route flexible gassupply line
through one of the access holes.
A.G.A. Design-Certified
Manual Shutoff Valve
with 1/8" NPT Tap*
3" Minimum
From
External
Regulator
(11" W.C.
to 14" W.C.
Pressure)
Approved Flexible
Gas Line
Pipe Cap Tee
Nipple Joint
Sediment Trap
Figure 30 - Gas Connection
* Purchase the optional A.G.A. design-cer-
tifiedmanualshutoffvalvefromyourdealer.
See Accessories, pages 26 and 27.
CAUTION: Use only new,
black iron or steel pipe. Inter-
nally-tinned copper tubing may
be used in certain areas. Check
yourlocalcodes.Usepipeof1/2"
diameter or greater to allow
propergasvolumetofireplace. If
pipe is too small, undue loss of
pressure will occur.
Installation must include a manual shutoff
valve, union, and plugged 1/8" NPT tap.
Locate NPT tap within reach for test gauge
hook up. NPT tap must be upstream from
fireplace (see Figure 30).
Check your building codes for any special
requirements for locating manual shutoff
valve to fireplaces.
The installer must supply an external regu-
lator. The external regulator will reduce
incoming gas pressure. You must reduce
incominggaspressuretobetween11and14
inchesofwater.Ifyoudonotreduceincom-
ing gas pressure, heater regulator damage
could occur. Install external regulator with
the vent pointing down as shown in Figure
29. Pointing the vent down protects it from
freezing rain or sleet.
INSTALLATION
Continued
INSTALLING GAS PIPING TO
FIREPLACE LOCATION
Installation Items Needed
Before installing fireplace, make sure you
have the items listed below.
• external regulator (supplied by installer)
• piping (check local codes)
• sealant (resistant to propane/LP gas)
• manual shutoff valve *
• test gauge connection *
• sediment trap
• tee joint
• pipe wrench
• approved flexible gas line with gas con-
nector (if allowed by local codes) (not
provided)
* AnA.G.A.design-certifiedmanualshutoff
valve with 1/8" NPT tap is an acceptable
alternative to test gauge connection. Pur-
chase the optional A.G.A. design-certified
manual shutoff valve from your dealer. See
Accessories, pages 26 and 27.
WARNING: A qualified ser-
vice person must connect fire-
place to gas supply. Follow all
local codes.
CAUTION: Never connect
heater directly to the propane/LP
supply. This heater requires an
externalregulator(notsupplied).
Install the external regulator be-
tweentheheaterandpropane/LP
supply.
CAUTION:Usepipejointseal-
ant that is resistant to liquid pe-
troleum (LP) gas.
Figure 29 - External Regulator with Vent
Pointing Down
Propane/
LP Supply
Tank
External
Regulator
Vent
Pointing
Down
We recommend that you install a sediment
trap in supply line as shown in Figure 30.
Locate sediment trap where it is within
reach for cleaning. Install in piping system
betweenfuelsupplyandheater.Locatesedi-
menttrapwhere trappedmatter is notlikely
to freeze. A sediment trap traps moisture
and contaminants. This keeps them from
going into fireplace gas controls. If sedi-
ment trap is not installed or is installed
wrong, fireplace may not run properly.
Apply pipe joint sealant lightly to male
threads. This will prevent excess sealant
fromgoing intopipe.Excesssealantin pipe
could result in clogged fireplace valves.

15
104410
OWNER’S MANUAL
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
QQQQQQQQQQ
QQQQQQQQQQ
QQQQQQQQQQ
QQQQQQQQQQ
QQQQQQQQQQ
QQQQQQQQQQ
QQQQQQQQQQ
QQQQQQQQQQ
QQQQQQQQQQ
QQQQQQQQQQ
QQQQQQQQQQ
¢¢¢¢¢¢¢¢¢¢
¢¢¢¢¢¢¢¢¢¢
¢¢¢¢¢¢¢¢¢¢
¢¢¢¢¢¢¢¢¢¢
¢¢¢¢¢¢¢¢¢¢
¢¢¢¢¢¢¢¢¢¢
¢¢¢¢¢¢¢¢¢¢
¢¢¢¢¢¢¢¢¢¢
¢¢¢¢¢¢¢¢¢¢
¢¢¢¢¢¢¢¢¢¢
¢¢¢¢¢¢¢¢¢¢
Manual
Shutoff Valve
Manual
Gas Valve
Propane/LP
Supply Tank
Pressure Testing Gas Supply
Piping System
TestPressuresInExcessOf1/2PSIG
1. Disconnect fireplace and its individual
manualshutoffvalvefromgassupplypip-
ingsystem.Pressuresinexcessof1/2psig
will damage fireplace gas regulator.
2. Cap off open end of gas pipe where
manual shutoff valve was connected.
3. Pressurize supply piping system by ei-
ther using compressed air or opening
propane/LP supply tank valve.
4. Check all joints of gas supply piping
system. Apply mixture of liquid soap
and water to gas joints. Bubbles form-
ing show a leak.
5. Correct all leaks at once.
6. Reconnect fireplaceand manualshutoff
valvetogas supply. Check reconnected
fittings for leaks.
CHECKING GAS
CONNECTIONS
WARNING: Test all gas pip-
ing and connections for leaks
after installing or servicing. Cor-
rect all leaks at once.
WARNING:Neveruseanopen
flame to check for a leak. Apply a
mixture of liquid soap and water
to all joints. Bubbles forming
show a leak. Correct all leaks at
once.
Figure31-RemovingLogBaseAssembly
From Fireplace
INSTALLATION
Continued
Figure 32 - Attaching Flexible Gas Lines Together
NOTICE:Mostbuildingcodesdo
not permit concealed gas con-
nections. A flexible gas line is
provided to allow accessibility
fromthefireplace(seeFigure32).
The flexible gas supply line con-
nection to the manual shutoff
valve should be accessible.
4. Attach a 45° flare union gas connector
toflexiblegas linefrom gassupply(see
Figure 32). Connect flare union to flex-
ible gas line attached to gas regulator
of fireplace (see Figure 32).
5. Check allgas connectionsfor leaks.See
Checking Gas Connections.
6. Replace log base assembly back into
fireplace.Feed flexiblegasline intofire-
placebase areawhile replacinglog base
assembly. Make sure the entire flexible
gas line is in fireplace base area. Reat-
tachlogbase assemblyto fireplacewith
screws removed in step 2, page 14.
Continued
Flexible Gas Line
from Fireplace Gas
Regulator Provided
with Fireplace
To Fireplace
Gas Regulator
Flare
Union
Flexible Gas Line from
Manual Shutoff Valve
Provided by Installer
Manual
Shutoff
Valve
➞
To Gas
Supply
TestPressuresEqualToorLessThan
1/2 PSIG
1. Close manual shutoff valve (see Fig-
ure 33).
2. Pressurize supply piping system by ei-
ther using compressed air or opening
propane/LP supply tank valve.
3. Checkalljointsfrom gasmetertomanual
shutoffvalve(seeFigure34).Applymix-
tureofliquidsoapandwatertogas joints.
Bubbles forming show a leak.
4. Correct all leaks at once.
Figure 33 - Manual Shutoff Valve
ON
POSITION
OFF
POSITION
Open
Closed
Manual
Shutoff
Valve
Figure 34 - Checking Gas Joints
Pressure Testing Fireplace Gas
Connections
1. Open manual shutoff valve (see Fig-
ure 33).
2. Open propane/LP supply tank valve.
3. Make sure control knob of fireplace is
in the OFF position.
4. Check all joints from manual shutoff
valve to thermostat gas valve (see Fig-
ure 34). Apply mixture of liquid soap
and water to gas joints. Bubbles form-
ing show a leak.
5. Correct all leaks at once.
6. Light fireplace (see Operating Fire-
place, pages 17 and 18 [Thermostat-
controlled models] or pages 18 and 19
[Manually-controlled models]). Check
all other internal joints for leaks.
7. Turn off fireplace (see To Turn Off Gas
toAppliance,page 18[Thermostat-con-
trolled models] or page 19 [Manually-
controlled models]).

16
104410
UNVENTED PROPANE/LP GAS FIREPLACE
DESA INTERNATIONAL
Figure 35 - Installing Front Log (#1)
Grate
Prongs
Metal Grate Bar
Front Log (#1)
Notch
Rear Log (#3)
Peg
Grate
Prong
Grate
Prong
Rear
Burner
Groove
in Back
of Log
Groove
in Back
of Log
Figure 37 - Installing Rear Log (#3)
INSTALLATION
Continued
Middle Log (#2)
Metal Post
Metal Post
Groove
Groove Grate
Figure 36 - Installing Middle Log (#2)
Figure 38 - Installing Crossover Log (#4)
Crossover
Log (#4)
Hole
Peg
Cutout
Notches
Figure 39 - Installing Fireplace Screen
WARNING:Youmustoperate
this fireplace with the fireplace
screen in place. Make sure fire-
place screen is in place before
running fireplace.
Screws for
Mounting Screen
WARNING:Failuretoposition
thepartsinaccordancewiththese
diagrams or failure to use only
parts specifically approved with
this heater may result in property
damage or personal injury.
INSTALLING LOGS
Each log is marked with a number. These
numberswillhelpyouidentifythelogwhen
installing. It is very important to install
these logs exactly as instructed. Do not
modify logs. Only use logs supplied with
heater.
1. Place front log (#1) on top of the grate.
Make sure the notches in the bottom of
the log fit over the grate prongs (see
Figure 35). Push back of log flush with
metal grate bar.
2. Rest middlelog (#2)behind metalposts
on front burner. Make sure the grooves
inthe bottomof thelog fitover thegrate
(see Figure 36). Bring the log forward
next to the metal posts.
3. Slide the grooves in the back of the rear
log (#3) against the rear grate prongs.
Make sure the peg on the log is on top
(see Figure 37).
4. Place the crossover log (#4) on the rear
log and the middle log. Make sure the
peg on the rear log is in the hole in the
bottom of the crossover log. The cross-
over log should fit in the cutout of the
middle log (see Figure 38).
5. Install fireplace screen by slipping
notches of fireplace screen over screws
on front of fireplace (see Figure 39).
CAUTION:Donot remove the
metal data plates attached to the
heater base assembly. The data
platescontainimportantwarranty
information.

17
104410
OWNER’S MANUAL
Figure 41 - Pilot
CAUTION:Donottrytoadjust
heating levels by using the
manual shutoff valve.
Thermo-
couple
LIGHTING
INSTRUCTIONS
WARNING:Youmustoperate
this fireplace with the fireplace
screen in place. Make sure fire-
place screen is installed before
running fireplace.
NOTICE: During initial operation
of new fireplace, burning logs
will give off a paper-burning
smell. Orange flame will also be
present. Open window to vent
smell. Operate fireplace on HI
position to burn off odor. This
will only last a few hours.
1. STOP! Read the safety information,
column 1.
2. Make sure manual shutoff valve is
fully open.
3. Turncontrolknobclockwise
Clockwise
to the OFF position (see Figure 40).
4. Waitfive(5)minutes toclearout any
gas. Then smell for gas, including
near the floor. If you smell gas,
STOP! Follow “B” in the safety in-
formation, column 1. If you don’t
smell gas, go to the next step.
5. Turn control knob counterclockwise
C-clockwise
to the PILOT position.
Press in control knob for five (5) sec-
onds (see Figure 40).
Note: If running fireplace for first
time, there will be air in gas line.You
may need to press in control knob for
30 seconds or longer. This will allow
air to bleed from the gas system.
6. Continue pressing control knob in.
Pressandreleaseignitorbutton.This
will light pilot. The pilot is attached
to the front burner. If needed, keep
pressing ignitor button until pilot
lights.
Note: If pilot does not stay lit, con-
tact a qualified service person or gas
supplierforrepairs.Untilrepairsare
made,light pilotwithmatch.To light
pilot with match, see Manual Light-
ing Procedure, page 18.
A. Thisappliancehasa pilot which must
belightedbyhand.Whenlighting the
pilot,followtheseinstructionsexactly.
B. BEFORE LIGHTING smell all
aroundtheapplianceareaforgas. Be
suretosmellnext tothefloorbecause
some gas is heavier than air and will
settle on the floor.
WHAT TO DO IF YOU SMELL
GAS
• Do not try to light any appliance.
• Donot touchany electricswitch; do
not use any phone in your building.
• Immediatelycall yourgassupplier
from a neighbor’s phone. Follow
the gas supplier’s instructions.
• If you cannot reach your gas sup-
plier, call the fire department.
C. Useonlyyourhandtopushinorturn
thegascontrolknob.Neverusetools.
If the knob will not push in or turn
by hand, don’t try to repair it, call a
qualified service technician or gas
supplier. Force or attempted repair
may result in a fire or explosion.
D. Do not use this appliance if any part
has been under water. Immediately
call a qualified service technician to
inspect the appliance and to replace
any part of the control system and
any gas control which has been un-
der water.
WARNING: If you do not fol-
low these instructions exactly, a
fireorexplosionmayresultcaus-
ing property damage, personal
injury or loss of life.
FOR YOUR SAFETY
READ BEFORE
LIGHTING
OPERATING
FIREPLACE
Thermostat-Controlled Models
Continued
Figure 40 - Control Knob and Ignitor
Button Location
Ignitor Electrode Pilot Burner
Ignitor Button
Control Knob
7. Keep control knob pressed in for 30
seconds after lighting pilot.After 30
seconds, release control knob.
Note: If pilot goes out, repeat steps
3 through 7. This fireplace has a
safety interlock system.Wait one (1)
minute for system to reset before
lighting pilot again.
• If control knob does not pop out
when released, contact a qualified
service person or gas supplier for
repairs.
8. Turn control knob counterclockwise
C-clockwise
todesiredheating level.The
burners should light. Set control
knob to any heat level between HI
and LO.

18
104410
UNVENTED PROPANE/LP GAS FIREPLACE
DESA INTERNATIONAL
OPERATING
FIREPLACE
Continued
TO TURN OFF GAS
TO APPLIANCE
You can set the thermostat control knob
to any comfort level between HI and LO.
The thermostat will gradually modulate
the heat output and flame height from
higherto lowersettings,orpilot,inorder
to maintain the comfort level you select.
The ideal comfort setting will vary by
householddependingupontheamountof
space to be heated, the output of the
central heating system, etc.
Note: Selecting the HI setting will cause
the burner to remain on without modu-
lating down in most cases.
Shutting Off Fireplace
Turn control knob clockwise
Clockwise
to
the OFF position.
Shutting Off Burners Only (pilot
stays lit)
Turn control knob clockwise
Clockwise
to
the PILOT position.
THERMOSTAT
CONTROL
OPERATION
MANUAL LIGHTING
PROCEDURE
1. Followsteps1through5 underLight-
ing Instructions, page 17.
2. Depress control knob and light pilot
with match.
3. Keep control knob pressed in for 30
seconds after lighting pilot.After 30
seconds, release control knob. Now
follow step 8, page 17.
Manually-Controlled Models
A. Thisappliancehasapilotwhichmust
belighted byhand.Whenlightingthe
pilot,followtheseinstructionsexactly.
B. BEFORE LIGHTING smell all
aroundtheapplianceareaforgas. Be
suretosmellnext tothefloorbecause
some gas is heavier than air and will
settle on the floor.
WHAT TO DO IF YOU SMELL
GAS
• Do not try to light any appliance.
• Donottouchanyelectricswitch;do
notuseany phonein yourbuilding.
• Immediatelycall yourgas supplier
from a neighbor’s phone. Follow
the gas supplier’s instructions.
• If you cannot reach your gas sup-
plier, call the fire department.
C. Useonlyyourhandtopushinorturn
thegascontrolknob.Neverusetools.
If the knob will not push in or turn
by hand, don’t try to repair it, call a
qualified service technician or gas
supplier. Force or attempted repair
may result in a fire or explosion.
D. Do not use this appliance if any part
has been under water. Immediately
call a qualified service technician to
inspect the appliance and to replace
any part of the control system and
any gas control which has been un-
der water.
WARNING: If you do not fol-
low these instructions exactly, a
fireorexplosionmayresultcaus-
ing property damage, personal
injury or loss of life.
FOR YOUR SAFETY
READ BEFORE
LIGHTING
IGNITOR
Figure 42 - Control Knob and Ignitor
Button Location
LIGHTING
INSTRUCTIONS
WARNING:Youmustoperate
this fireplace with the fireplace
screen in place. Make sure fire-
place screen is installed before
running fireplace.
NOTICE: During initial operation
of new fireplace, burning logs
will give off a paper-burning
smell. Orange flame will also be
present. Open window to vent
smell. Operate fireplace on HI
position to burn off odor. This
will only last a few hours.
1. STOP! Read the safety information,
column 2.
2. Make sure manual shutoff valve is
fully open.
3. Turncontrolknob clockwise
Clockwise
to the OFF position (see Figure 42).
4. Waitfive(5)minutes toclearout any
gas. Then smell for gas, including
near the floor. If you smell gas,
STOP! Follow “B” in the safety in-
formation, column 2. If you don’t
smell gas, go to the next step.
5. Slightlydepressandturncontrolknob
counterclockwise
C-clockwise
to the PI-
LOT position. Press in control knob
for five (5) seconds (see Figure 42).
Note: If running fireplace for first
time,therewillbe air ingasline.You
mayneedtopressincontrolknob for
30 seconds or longer. This will allow
air to bleed from the gas system.
Ignitor Button
Control Knob

19
104410
OWNER’S MANUAL
Figure 43 - Pilot
6. Continue pressing control knob in.
Press and release ignitor button. This
will light pilot.The pilot is attached to
thefrontburner.Ifneeded,keeppress-
ing ignitor button until pilot lights.
Note :If pilot does not stay lit, con-
tact a qualified service person or gas
supplierforrepairs.Untilrepairsare
made,light pilotwithmatch.To light
pilot with match, see Manual Light-
ing Procedure, column 3.
7. Keep control knob pressed in for 30
seconds after lighting pilot.After 30
seconds, release control knob.
Note: If pilot goes out, repeat steps
3 through 7.
• If control knob does not pop out
when released, contact a qualified
service person or gas supplier for
repairs.
8. Slightly depress and turn control
knob couterclockwise to the
high position. Both burners should
light. Set control knob to either
HIGH or LOW.
OPERATING
FIREPLACE
Continued
TO TURN OFF GAS
TO APPLIANCE
WARNING: Do not operate
heaterbetweenlockedpositions.
CAUTION:Donottrytoadjust
heating levels by using the
manual shutoff valve.
Thevariablecontrolvalvecanbesettoany
heat setting and flame height desired, by
simply turning the control knob until that
setting is attained. Even the lowest setting
provides realistic flames and glowing em-
bers from two burners. Selecting higher
settingsproducesgreaterheatoutput.This
results in increased heating comfort.
Shutting Off Fireplace
1. Turncontrolknobclockwise
Clockwise
to the HIGH position.
2. Slightly depress control knob and
turnclockwise
Clockwise
to thePILOT
position.
3. Slightly depress control knob and
turn clockwise
Clockwise
to the OFF
position.
Shutting Off Burners Only (pilot
stays lit)
1. Turncontrolknobclockwise
Clockwise
to the HIGH position.
2. Press in and turn clockwise
Clockwise
to the PILOT position.
Thermocouple Ignitor Electrode
Pilot Burner
VARIABLE CONTROL
OPERATION MANUAL LIGHTING
PROCEDURE
1. Followsteps1through5 underLight-
ing Instructions, page 18.
2. Depress control knob and light pilot
with match.
3. Keep control knob pressed in for 30
seconds after lighting pilot.After 30
seconds, release control knob. Now
follow step 8, column 1.

20
104410
UNVENTED PROPANE/LP GAS FIREPLACE
DESA INTERNATIONAL
INSPECTING
BURNERS
Check pilot flame pattern and burner flame
patterns often.
PILOT FLAME PATTERN
Figure 44 shows a correct pilot flame pat-
tern. Figure 45 shows an incorrect pilot
flame pattern. The incorrect pilot flame is
not touching the thermocouple. This will
cause the thermocouple to cool. When the
thermocouple cools, the fireplace will shut
down.
If pilot flame pattern is incorrect, as shown
in Figure 45
• turn fireplace off (see To Turn Off Gas to
Appliance, page 18 [Thermostat-con-
trolled models] or page 19 [Manually-
controlled models])
• seeTroubleshooting, pages 22 through 24
Figure 44 - Correct Pilot Flame Pattern
Figure 45 - Incorrect Pilot Flame Pattern
Thermocouple Pilot Burner
Pilot Burner
Thermocouple
OPERATING
FIREPLACE
Continued
Blower Kit Model GA3700T
This thermostatically-controlled blower
featuresathreepositionswitch.Thethree
settingsare:ON,OFF,andAUTO.Inthe
ONposition,theblowerwilloperatecon-
stantly. In the OFF position, the blower
will not operate. In the AUTO position,
theblowerwillstartwhenthethermostat
senses a sufficient increase in firebox
temperature. When the heater has been
on approximately 5 minutes, turn the
blower on to deliver heated air at the top
louvers.
IMPORTANT: Light your gas appliance
with the blower off.
Note: Your gas logs and thermostat
blower will not turn on and off at the
same time. The fireplace may run for
several minutes before the blower turns
on. After the heater returns to the pilot
position, the blower will continue to run.
Theblowerwillshut off afterthefirebox
temperature decreases.
Note: It is safe to operate fireplace with
blowerturnedoff.However,theblowerhelps
distribute heated air from the fireplace.
Note: Periodically check the louvers of
thefireboxand remove any dust,dirt,or
other obstructions.
Locatetheblowerswitchbyopeninglower
louver on fireplace. Blower switch is lo-
cated at lower left inside louver door.
Thermostat-controlledblowershavethree
settings:ON,OFF,andAUTO. IntheON
position,theblowerwilloperateconstantly.
In the OFF position, the blower will not
operate.IntheAUTOposition,theblower
will start when the thermostat senses a
sufficientincreaseinfireboxtemperature.
Note: Your gas logs and thermostat
blower will not turn on and off at the
same time. The fireplace may run for
several minutes before the blower turns
on.Aftertheheatermodulatestothepilot
position, the blower will continue to run.
The blower will shut off after the firebox
temperature decreases.
Note: It is safe to operate fireplace with
blowerturnedoff.However,theblowerhelps
distribute heated air from the fireplace.
Manual blowers on manually-controlled
models have an ON and OFF position.
BLOWER
OPERATION
WARNING:Thisfireplacehas
a three-prong, grounded electri-
cal plug. This plug helps protect
youagainstelectricalshock.Only
connect plug to a properly
grounded, three-prong recep-
tacle. Do not cut or remove the
grounding prong from this plug.
VSGF28PTC / CSGF28PTC
VSGF28PV MODEL ONLY
Blower Kit Model GA3700
This optional non-thermostat blower kit
features a variable control which allows
you to select the speed you desire. After
about 15 minutes, turn the blower on to
deliver heated air at the top louvers. Fol-
lowtheinstallation instructions onpages
8 and 9 of this manual.
IMPORTANT: Light your gas appliance
with the blower off.
Note: Periodically check the louvers of
the firebox and remove any dust, dirt, or
other obstructions.
